HIK VISION DS-2CD2612F-I(S) User manual

1
Camera
Network Camera
Quick Guide
UD.6L0201D0186A01

Network Camera·Quick Guide
1
11
Thank you for purchasing our product. If there are any questions, or requests,
please do not hesitate to contact the dealer.
This manual applies to DS-2CD2612F-I(S), DS-2CD2632F-I(S) cameras.
This manual may contain several technical incorrect places or printing errors, and
the content is subject to change without notice. The updates will be added to the
new version of this manual. We will readily improve or update the products or
procedures described in the manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the performance or
reliability of the security or signaling aspects of this product. UL has only tested
for fire, shock or casualty hazards as outlined in UL’s Standard(s) for Safety,
UL60950-1. UL Certification does not cover the performance or reliability of the
security or signaling aspects of this product. UL MAKES NO REPRESENTATIONS,
WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED
FUNCTIONS OF THIS PRODUCT.
0500001030322

Network Camera·Quick Guide
2
22
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to comply with the
limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operation
EU Conformity Statement
This product and - if applicable - the supplied accessories too
are marked with "CE" and comply therefore with the
applicable harmonized European standards listed under the
Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS
Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this
symbol cannot be disposed of as unsorted municipal waste in
the European Union. For proper recycling, return this product to
your local supplier upon the purchase of equivalent new

Network Camera·Quick Guide
3
33
equipment, or dispose of it at designated collection points. For more information
see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains a
battery that cannot be disposed of as unsorted municipal
waste in the European Union. See the product
documentation for specific battery information. The battery
is marked with this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return
the battery to your supplier or to a designated collection point. For more
information see: www.recyclethis.info.

Network Camera·Quick Guide
4
44
Safety Instruction
These instructions are intended to ensure that user can use the product correctly
to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings are
neglected.
Cautions: Injury or equipment damage may occur if any of the cautions are
neglected.
Warnings
Please adopt the power adapter which can meet the safety extra low voltage
(SELV) standard. And source with DC 12V or AC 24V (depending on models)
according to the IEC60950-1 and Limited Power Source standard.
If the product does not work properly, please contact your dealer or the
nearest service center. Never attempt to disassemble the camera yourself.
(We shall not assume any responsibility for problems caused by unauthorized
repair or maintenance.)
Warnings Follow these
safeguards to prevent serious
injury or death.
Cautions Follow these precautions
to prevent potential injury or
material damage.

Network Camera·Quick Guide
5
55
To reduce the risk of fire or electrical shock, do not expose this product to rain
or moisture.
This installation should be made by a qualified service person and should
conform to all the local codes.
Please install blackouts equipment into the power supply circuit for convenient
supply interruption.
Please make sure that the ceiling can support more than 50(N) Newton
gravities if the camera is fixed to the ceiling.
If the product does not work properly, please contact your dealer or the
nearest service center. Never attempt to disassemble the camera yourself.
(We shall not assume any responsibility for problems caused by unauthorized
repair or maintenance.)
Cautions
Make sure the power supply voltage is correct before using the camera.
Do not drop the camera or subject it to physical shock.
Do not touch sensor modules with fingers. If cleaning is necessary, use a clean
cloth with a bit of ethanol and wipe it gently. If the camera will not be used for
an extended period of time, put on the lens cap to protect the sensor from
dirt.
Do not aim the camera lens at the strong light such as sun or incandescent
lamp. The strong light can cause fatal damage to the camera.
The sensor may be burned out by a laser beam, so when any laser equipment
is being used, make sure that the surface of the sensor not be exposed to the
laser beam.

Network Camera·Quick Guide
6
66
Do not place the camera in extremely hot, cold temperatures (the operating
temperature should be between -30°C ~ 60°C), dusty or damp environment,
and do not expose it to high electromagnetic radiation.
To avoid heat accumulation, good ventilation is required for a proper operating
environment.
Keep out of water and any liquid.
While shipping, the camera should be packed in its original packing.
Improper use or replacement of the battery may result in hazard of explosion.
Please use the manufacturer recommended battery type.

Network Camera·Quick Guide
7
77
Table of Contents
1 Overview.................................................................................................. 8
1.1 Appearance .............................................................................................8
1.2 Wiring ....................................................................................................10
2 Installation ..............................................................................................11
2.1 SD Card Installation...............................................................................11
2.2 Mounting...............................................................................................13
2.2.1 Wall mounting ...........................................................................13
2.2.2 Wall Mounting with a Junction Box .........................................15
2.2.3 Wall Mounting with a Gang Box...............................................17
2.3 View Angle Adjusting............................................................................17
2.4 Zoom and Focus Adjusting ...................................................................19
3 Setting the Network Camera over the LAN .................................................21
4 Accessing via Web Browser .......................................................................26

Network Camera·Quick Guide
8
88
Overview
Appearance
Figure 1-1 Overview
Table 1-1 Overview
No.
Description
1
Sun Shield
2
Front Cover
3
Zoom and Focus Lever
5
4
10
9
7
3
8
6
1
2
12
11

Network Camera·Quick Guide
9
99
4
IR LED
5
Lens
6
Air Vent
7
Video Output Interface
8
Integrated Bracket
9
Reset Button
10
SD Card Slot
11
Power Interface
12
Network Interface
Notes:
To reset the default parameters to the camera, you need to press and hold the
reset button and power on the camera. After the power on the camera, you
must still press and hold the reset button for about 10 seconds.
The DS-2CD2612F-IS and DS-2CD2632F-IS models support audio and alarm
functions. The interfaces are shown as follows.
Figure 1-2 Audio and Alarm Interfaces
Audio
Alarm

Network Camera·Quick Guide
10
1010
Wiring
Figure 1-3 Wiring

Network Camera·Quick Guide
11
1111
Installation
Before mounting, please make sure that the device in the package is in good
condition and all the assembly parts are included.
Notes:
Please make sure that the device in the package is in good condition and all
the assembly parts are included.
Check the specification of the products for the installation environment.
Make sure that all the related equipment is power-off during the installation.
Check whether the power supply is matched with your AC outlet to avoid any
damage.
If the product does not function properly, please contact your dealer or the
nearest service center. Do not disassemble the camera for repair or
maintenance by yourself.
Please make sure that the wall is strong enough to withstand three times the
weight of the camera
SD Card Installation
Steps:
Rotate the TW M3X5 screw counterclockwise about 3 to 4 rounds to
loosen it. Slide the sun shield according to the arrow direction as shown in Figure
2-1(left).
Remove the sun shield according to the arrow direction as shown in
Figure 2-1(right).

Network Camera·Quick Guide
12
1212
Remove the front cover by rotating it counterclockwise as shown in
Figure 2-1(right).
Figure 2-1 Disassemble the Camera
Insert the SD card to the SD card slot.
Rotate the front cover clockwise back to the camera and install the sun
shield according to the arrow direction as shown in Figure 2-2(right).
Figure 2-2 Install the SD Card
SD Card Slot

Network Camera·Quick Guide
13
1313
Slide the sun shield according to the arrow direction as shown in Figure
2-3(left).
Rotate the TW M3X5 screw clockwise to tighten the sun shield.
Figure 2-3 Assemble the Camera
Note: For water-proof, please align the rotating label on the front cover with that
on the camera when you rotate the front cover clockwise. Refer to Figure
2-3(right).
Mounting
This camera is equipped with a bracket on the bottom. It can be mounted to a
wall directly and can also be mounted to a wall with a junction box or a gang box.
Wall mounting
Steps:
Rotating Label

Network Camera·Quick Guide
14
1414
1. Attach the drill template (supplied) to the wall where the camera is to be
mounted.
Drill screw holes in the wall according to the number one holes of the
drill template. Refer to the Figure 2-4.
Figure 2-4 Drilling Holes in the Wall
If you need to route cables through the wall(or ceiling), cut a cable hole
according to the drill template. Skip this step, if you want to route the cables on
the surface of the ceiling.
11
11
2
22
2
1:Screw Hole
for Bracket
2:Screw Hole
for Mounting
Base
Cable Hole
Screw Hole

Network Camera·Quick Guide
15
1515
Route the cables of the camera.
Secure the camera to the wall(or ceiling) with expansion screws. Refer to
the Figure 2-5.
Figure 2-5 Secure the Camera
Wall Mounting with a Junction Box
Before you start:
For mounting with a junction box, you have to purchase a junction box.
Steps:

Network Camera·Quick Guide
16
1616
1. Attach the drill template (supplied) to the wall where the camera is to be
mounted.
Drill holes in the wall according to the number two holes of the drill
template. Refer to the Figure 2-4.
If you need to route cables through the wall(or ceiling), cut a cable hole
according to the drill template. Skip this step, if you want to route the cables on
the surface of the ceiling.
Secure the junction box to the wall with expansion screws.
Route the cables of the camera.
Connect the video output connector to the monitor. Connect the power
connector to the power supply.
Adjust the image and focus. Please refer to the section 2.3 and 2.4 for
more detailed information.
Hook the camera to the junction box with the safety rope. Refer to the
Figure 2-6.
Secure the camera to the junction box with screws.
Safety Rope
Junction Box

Network Camera·Quick Guide
17
1717
Figure 2-6 Secure the Camera
Wall Mounting with a Gang Box
Before you start:
For mounting with a gang box, you have to purchase a gang box.
Steps:
1. Secure the camera attachment to a gang box with screws.
Route the cables of the camera.
Secure the camera to the camera attachment with screws. Refer to the
Figure 2-7.
Figure 2-7 Secure the Camera
View Angle Adjusting
Purpose:
Gang Box
Camera Attachment

Network Camera·Quick Guide
18
1818
3-axis (pan/tilt/rotation) adjusting allows adjustment for optimum camera
rotation and placement. You can use this function to get the angle of view that
you want.
Pan Adjustment
Steps:
1. Loosen the lock screw-1.
Adjust the panning position of the camera. The adjusting range is from 0
degrees to 360 degrees.
Tighten the lock screw-1.
Tilt Adjustment
Steps:
1. Loosen the lock screw-2.
Adjust the tilting position of the camera. The adjusting range is from 0
degrees to 90 degrees.
Tighten the lock screw-2.
Rotation Adjustment
Steps:
1. Loosen the lock screw-3.
Rotate the rotation position to adjust the azimuth angle of the image.
The adjusting range is from 0 degrees to 360 degrees.
Tighten the lock screw-3.

Network Camera·Quick Guide
19
1919
Figure 2-8 Lens Adjustment
Zoom and Focus Adjusting
Purpose:
You can use the zoom lever and focus lever to adjust the zoom value and focus
value.
Steps:
1. Disassemble the camera. Refer to section 2.1.
2. View the camera image using the monitor.
Loosen the zoom lever and move the lever between T(Tele) and W(Wide)
to obtain the appropriate angle of view.
Tighten the zoom lever.
Loosen the focus lever and move the screw between F(Far) and N(Near)
to obtain the optimum focus.
Tighten the focus lever.
7. Assemble the camera. Refer to section 2.1.
Menu Button
Pan
Tilt
Rotation
Lock Screw-1
Lock Screw-2
Lock Screw-3
