HIK VISION E-series User manual

E Series 5-inch Speed Dome
Installation Manual
UD.6L0201A1096A01

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
1
Thank you for purchasing our product. If there is any question or request, please do not hesitate to
contact the dealer.
This manual is applicable to E Series 5-inch Speed Domes.
This manual may contain several technically inaccurate points or printing errors, and the content is
subject to change without notice. The updates will be added into the new version of this manual.
We will readily improve or update the products or procedures described in the manual.
0100011030605

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
2
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to comply with the limits for a digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS
Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collection points. For more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentation for specific battery information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For
more information see: www.recyclethis.info.

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
3
Safety Instruction
These instructions are intended to ensure that user can use the product correctly to avoid danger or
property loss. The precaution measure is divided into Warnings and Cautions:
Warnings: Neglecting any of the warnings may cause serious injury or death.
Cautions: Neglecting any of the cautions may cause injury or equipment damage.
Warnings:
Follow these safeguards to prevent
serious injury or death.
Cautions:
Follow these precautions to
prevent potential injury or
material damage.
Warnings
In the use of the product, you must be strict compliance with the electrical safety regulations of
the nation and region.
Please use the power adapter, which is provided by normal company. The standard of the power
adapter is AC24V10%. The power consumption cannot be less than the required value.
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or fire hazard.
Please make sure that the plug is firmly connected on the power socket.
When the product is installed on wall or ceiling, the device shall be firmly fixed.
If smoke, odors or noise rise from the device, turn off the power at once and unplug the power
cable, and then please contact the service center.
If the product does not work properly, please contact your dealer or the nearest service center.
Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
Cautions
Do not drop the dome or subject it to physical shock, and do not expose it to high
electromagnetism radiation. Avoid the equipment installation on vibrations surface or places
subject to shock (ignorance can cause equipment damage).
Do not place the dome in extremely hot, cold, dusty or damp locations, otherwise fire or
electrical shock will occur. The operating temperature should be -30°C ~ 65°C (outdoor speed
dome) and -10°C ~ 50°C (indoor speed dome).
The dome cover for indoor use shall be kept from rain and moisture.
Exposing the equipment to direct sun light, low ventilation or heat source such as heater or
radiator is forbidden (ignorance can cause fire danger).
Do not aim the camera at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfunction however), and affecting the endurance of sensor at the

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
4
same time.
Please use the provided glove when open up the dome cover, avoid direct contact with the
dome cover, because the acidic sweat of the fingers may erode the surface coating of the dome
cover.
Please use a soft and dry cloth when clean inside and outside surfaces of the dome cover, do not
use alkaline detergents.

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
5
Preparation for Installation
Basic requirements.
All the electronic operation should be strictly compliance with the electrical safety
regulations, fire prevention regulations and other related regulations in your local region.
Check whether all the accessories are included and make sure that the installation place and
mode conform to the demands. If not, please contact the supplier.
Please use this product according to the requirement of working environment.
Check installation space.
Make sure the place have enough space to install the speed domes and its accessories.
Check the intensity of conformation at the installation location.
Please make sure that the ceilings or walls are strong enough to withstand required times the
weight of speed dome and its accessories.
Preparation of cables.
For analog speed dome, choose the video cable according to the transmission distance. The
video should meet the least demands as: 75Ω resistance; 100% copper core conducting wire;
95% weaving copper shield.
For analog speed dome, RS485 communication cable, please refer to Appendix 2.
24V AC power cable, please refer to Appendix 3.
Please keep all wrappers.
Please keep all wrappers after unpack them for future use. In case of any failure occurred, you
need to return the speed dome to the factory with the original wrapper.
Note: Transportation without the original wrapper may result in damage on the speed dome
and lead to additional costs.

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
6
Table of Contents
Chapter 1 Installation............................................................................................................................................ 7
1.1 Installation and Cabling ................................................................................................................................. 7
1.1.1 Installing the Speed Dome......................................................................................................................... 7
1.1.2 Connecting the Cables..............................................................................................................................12
1.2 DIP Switch Settings.......................................................................................................................................13
1.2.1 Address Settings.......................................................................................................................................13
1.2.2 Baudrate Settings .....................................................................................................................................14
Chapter 2 Mount Dimension................................................................................................................................16
2.1 Long-arm Wall Mount...................................................................................................................................16
2.2 Short-arm Wall Mount..................................................................................................................................16
2.3 Corner Adapter ............................................................................................................................................17
2.4 Pole Adapter ................................................................................................................................................18
Chapter 3 Mounting Applications ........................................................................................................................19
3.1 Wall Mounting Applications..........................................................................................................................19
3.1.1 Mounting Components.............................................................................................................................19
3.1.2 Wall Mounting .........................................................................................................................................19
3.2 Corner Mounting Applications......................................................................................................................21
3.2.3 Mounting Components.............................................................................................................................21
3.2.4 Corner Mounting......................................................................................................................................22
3.3 Pole Mounting Applications..........................................................................................................................24
3.3.1 Mounting Components.............................................................................................................................24
3.3.2 Pole Mounting..........................................................................................................................................25
3.4 In-ceiling Mounting Applications ..................................................................................................................27
3.4.1 Installation Conditions..............................................................................................................................27
3.4.2 In-ceiling Mounting ..................................................................................................................................27
3.5 Ceiling Mounting Applications ......................................................................................................................30
3.5.1 Wiring For Ceiling Mounting Applications.................................................................................................30
3.5.2 Ceiling Mounting......................................................................................................................................31
Appendix.....................................................................................................................................................................34
Appendix 1 Lightning & Surge Protection..................................................................................................................34
Appendix 2 RS485 Bus Connection............................................................................................................................35
Appendix 3 24VAC Wire Gauge & Transmission Distance...........................................................................................38
Appendix 4 Wire Gauge Standards ...........................................................................................................................39

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
7
Chapter 1 Installation
Before you start:
Check the package contents and make sure that the device in the package is in good condition and
all the assembly parts are included.
1.1 Installation and Cabling
1.1.1 Installing the Speed Dome
There are several ways to install the speed dome. The wall mounting is taken as an example below.
Steps:
1. Loosen the two lock screws as shown in the following figure.
2. Remove the lower dome.
Figure 1-1 Disassemble the Speed Dome
3. Remove the protective lens cover, foam and sticker as shown in the following figure.
4. Set the address and baudrate for the analog speed dome. Please refer to the Section 1.2 DIP
Switch Settings for DIP switch settings.
5. Install the lower dome back and tighten the two lock screws.
Lock Screw
Lock Screw

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
8
Figure 1-2 Disassemble the Speed Dome
6. Drill four M8 screw holes on the wall according to the screw holes of the wall mount.
7. Secure the wall mount to the wall with screws.
Notes:
For cement wall mounting, you need to use the expansion screw to fix the mount. The
mounting hole of the expansion pipe on the wall should align with the mounting hole on the
mount.
For wooden wall mounting, you can just use the self-tapping screw to fix the bracket.
protective foam
Protective sticker

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
9
Figure 1-3 Install the Wall Mount
8. Wrap the thread part with the thread tape and rotate the pendant adapter to the wall mount.
9. Secure the pendant adapter to the wall mount with a set screw (supplied) as shown in Figure
1-5.
Figure 1-4 Install the Pendant Adapter

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
10
Figure 1-5 Install the Pendant Adapter
10. Hook the two ends of the safety rope to the back box of the speed dome and the wall mount
respectively. Route the cables through the mount.
11. Loosen the lock screws of the adapter as shown below.
Figure 1-6 Pendant Adapter
12. Align the direction label of pendant adapter with the label of the back box to install the speed
dome as shown below.
①
②

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
11
Figure 1-7 Align the Labels
13. Rotate the back box counterclockwise or clockwise tightly. Secure the back box and the pendant
adapter with the two lock screws.
Figure 1-8 Tighten the Lock Screws
①
②
③
④
⑤

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
12
1.1.2 Connecting the Cables
Before you start:
Please make sure to turn off the power of the dome before connect the cables.
The cable interfaces of analog speed dome and network speed dome are shown in Figure 1-9 and
Figure 1-10. The cables of RS-485, power supply, etc. are distinguished by different colors. Please
refer to the labels attached on the cables for identification.
Figure 1-9 Cables of Analog Speed Dome
RED AC24V
YELLOW/GREEN
BLACK AC24V
BLUE/WHITE AUDIO_OUT
RED/WHITE AUDIO_IN
GREEN/WHITE AUDIO_GND
Figure 1-10 Cables of Network Speed Dome
24V AC Black
GND Yellow-green
24V AC Red
RS485- Yellow
RS485+ Orange
Video Output
24V AC Black
GND Yellow-green
24V AC Red
Audio out Blue-white
Audio in Red-white
Audio GND Green-white
Network Cable

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
13
1.2 DIP Switch Settings
Note: This section is only for analog speed dome.
The DIP switch is used for setting the address and baudrate for the speed dome, with value ON=1
and OFF=0, as shown in Figure 1-11.
The SW1 switches from the first to the eighth are used to set the address. The SW2 switches are
used to set the baudrate. Please refer to the section 1.2.1 and 1.2.2 for detailed settings.
Notes:
The default dome address is 0. The default baudrate is 2400.
The speed dome is self-adaptive to the Pelco-P, Pelco-D and Private-Code. You don’t have to set
the RS-485 control protocol by the DIP switch.
ON
1 2 3 4 5 6 7 8 12
Figure 1-11 DIP Switch Settings
1.2.1 Address Settings
The SW1-switches from 1 to 8 are used for setting the address of speed dome. You can refer to Table
1-1 for details of setting the speed dome address to a specific number.
Table 1-1 Set the Dome Address between 0 and 31
Switch Number
Dome Address
1
2
3
4
5
6
7
8
0
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
3
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
DIP Switch

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
14
4
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
5
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
6
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
7
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
8
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
9
ON
OFF
OFF
ON
OFF
OFF
OFF
OFF
10
OFF
ON
OFF
ON
OFF
OFF
OFF
OFF
11
ON
ON
OFF
ON
OFF
OFF
OFF
OFF
12
OFF
OFF
ON
ON
OFF
OFF
OFF
OFF
13
ON
OFF
ON
ON
OFF
OFF
OFF
OFF
14
OFF
ON
ON
ON
OFF
OFF
OFF
OFF
15
ON
ON
ON
ON
OFF
OFF
OFF
OFF
16
OFF
OFF
OFF
OFF
ON
OFF
OFF
OFF
17
ON
OFF
OFF
OFF
ON
OFF
OFF
OFF
18
OFF
ON
OFF
OFF
ON
OFF
OFF
OFF
19
ON
ON
OFF
OFF
ON
OFF
OFF
OFF
20
OFF
OFF
ON
OFF
ON
OFF
OFF
OFF
21
ON
OFF
ON
OFF
ON
OFF
OFF
OFF
22
OFF
ON
ON
OFF
ON
OFF
OFF
OFF
23
ON
ON
ON
OFF
ON
OFF
OFF
OFF
24
OFF
OFF
OFF
ON
ON
OFF
OFF
OFF
25
ON
OFF
OFF
ON
ON
OFF
OFF
OFF
26
OFF
ON
OFF
ON
ON
OFF
OFF
OFF
27
ON
ON
OFF
ON
ON
OFF
OFF
OFF
28
OFF
OFF
ON
ON
ON
OFF
OFF
OFF
29
ON
OFF
ON
ON
ON
OFF
OFF
OFF
30
OFF
ON
ON
ON
ON
OFF
OFF
OFF
31
ON
ON
ON
ON
ON
OFF
OFF
OFF
…
…
…
…
…
…
…
…
…
255
ON
ON
ON
ON
ON
ON
ON
ON
1.2.2 Baudrate Settings
The number 1 and 2 SW2-switches are used for setting the baudrate of the speed dome. The
baudrate can be 2400bps, 4800bps, 9600bps and 19200bps. The baudrate will be set as 2400bps by
default if it is out of this range. Refer to the following table:
Table 1-2 Set the Baudrate of the Dome
Switch Number
Baudrate
1
2
2400
OFF
OFF
4800
ON
OFF

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
15
9600
OFF
ON
19200
ON
ON

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
16
Chapter 2 Mount Dimension
2.1 Long-arm Wall Mount
Figure 2-1 Long-arm Wall Mount
2.2 Short-arm Wall Mount

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
17
Figure 2-2 Short-arm Wall Mount
2.3 Corner Adapter
Please use the wall mount with corner adapter according to your demand.
Figure 2-3 Corner Adapter

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
18
2.4 Pole Adapter
Please use the wall mount with pole adapter according to your demand.
Figure 2-4 Pole Adapter

Installation Manual of E Series 5-inch Speed Dome
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
19
Chapter 3 Mounting Applications
Before you start:
For cement wall, you need to use the expansion screw to fix the mount. The mounting hole of
the expansion pipe on the wall should align with the mounting hole on the mount.
For wooden wall, you can just use the self-tapping screw to fix the mount.
3.1 Wall Mounting Applications
3.1.1 Mounting Components
Wall Mount
Applicable to indoor/outdoor pendant domes.
Figure 3-1 Wall Mount
Mounting Accessories
Figure 3-2 Nuts and Flat Washers
3.1.2 Wall Mounting
Before you start:
