Explosion-Proof Dome Network Camera
Quick Start Guide

Network Dome Camera·Quick Start Guide
1
©2021 Hangzhou Hikvision Digital Technology Co., Ltd. All rights
reserved.
About this Manual
The Manual includes instructions for using and managing the
Product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The information
contained in the Manual is subject to change, without notice, due to
firmware updates or other reasons. Please find the latest version of
this Manual at the Hikvision website (https://www.hikvision.com/).
Please use this Manual with the guidance and assistance of
professionals trained in supporting the Product.
Trademarks
and other Hikvision’s trademarks and logos are
the properties of Hikvision in various jurisdictions.
Other trademarks and logos mentioned are the properties of their
respective owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS
MANUAL AND THE PRODUCT DESCRIBED, WITH ITS HARDWARE,
SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH ALL
FAULTS AND ERRORS”. HIKVISION MAKES NO WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,
SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE.
THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO
EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL,
CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING,
AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,

Network Dome Camera·Quick Start Guide
2
BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF
SYSTEMS, OR LOSS OF DOCUMENTATION, WHETHER BASED ON
BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES
FOR INHERENT SECURITY RISKS, AND HIKVISION SHALL NOT TAKE
ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY
LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK,
HACKER ATTACK, VIRUS INFECTION, OR OTHER INTERNET SECURITY
RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL
SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL
APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR
ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A
MANNER THAT DOES NOT INFRINGE ON THE RIGHTS OF THIRD
PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF PUBLICITY,
INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND
OTHER PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR
ANY PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR
PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE
DEVELOPMENT OR PRODUCTION OF CHEMICAL OR BIOLOGICAL
WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY
NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN
SUPPORT OF HUMAN RIGHTS ABUSES.

Network Dome Camera·Quick Start Guide
3
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATTER PREVAILS.
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own
expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement

Network Dome Camera·Quick Start Guide
4
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized
European standards listed under the EMC Directive 2014/30/EU, the
RoHS Directive 2011/65/EU, the ATEX Directive 2014/34/EU.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information
see:www.recyclethis.info
Intended use of the camera
ATEX: II 2 G D Ex db IIC T6 Gb/Ex tb IIIC T80℃ Db IP68
IECEx: Ex db IIC T6 Gb/Ex tb IIIC T80℃ Db IP68
Hazardous Area Classification: Zone 1, Zone 2, Zone 21, Zone 22.
IP Degree: IP68 (2m, 2h)

Network Dome Camera·Quick Start Guide
5
Ex Standards:
IEC 60079-0: 2011
EN 60079-0: 2012/All: 2013
IEC 60079-1: 2014
EN 60079-1: 2014
IEC 60079-31: 2013
EN 60079-31: 2014
Nameplate:
Special Conditions for Safe Use:
1. Ambient Temperature: -40°C to +60°C.
2. DO NOT OPEN WHEN ENERGIZED.
3. POTENTIAL ELECTROSTATIC CHARGING HAZARD – SEE
INSTRUCTIONS.
4. When assembly, operation and maintenance, the operator must
follow the requirements of the IEC 60079-14: latest version
Explosive atmosphere- Part 14: Electrical installation design,
selection and erection, beside of the manufacturer’s operation
instruction or its National equivalent.
5. Repair and overhaul shall comply with IEC 60079-19: latest version
or its National equivalent.

Network Dome Camera·Quick Start Guide
6
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards
requirements.
Warning:
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to
take adequate measures.
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Indicates a hazard with a
high level of risk, which if
not avoided, will result in
death or serious injury.
Indicates a potentially hazardous
situation, which if not avoided,
could result in equipment damage,
data loss, performance degradation,
or unexpected results.

Network Dome Camera·Quick Start Guide
7
●CAUTION: Hot parts! Burned fingers when handling the parts.
Wait one-half hour after switching off
before handling parts. This sticker is to
indicate that the marked item can be hot
and should not be touched without taking care. For device with
this sticker, this device is intended for installation in a restricted
access location, access can only be gained by service persons or
by users who have been instructed about the reasons for the
restrictions applied to the location and about any precautions
that shall be taken.
●Grounding:
The both internal and external earthing shall be connected
reliably.
Ground wire cross-sectional area of not less than the phase
connector cross-sectional area level, at least 4 mm2.
●All the electrical operation should be strictly compliance with
the electrical safety regulations, fire prevention regulations and
other related regulations of the nation and region.
●Make sure that the power has been disconnected before you
wire, install or disassemble the camera. Never wire, install or
disassemble the camera in explosive environment.
●The power source should meet limited power source or PS2
requirements according to IEC 60950-1 or IEC 62368-1
standard.

Network Dome Camera·Quick Start Guide
8
●Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
●To avoid fire danger caused by electrostatic charge, never touch
or wipe the camera in explosive environment. Perform the
wiping and replacing accessories only under non-explosive
environment with the provided glove.
●When the camera is installed on wall or ceiling, the device shall
be firmly fixed.
●If smoke, odors or noise rise from the camera, turn off the
power at once and unplug the power cable, and then contact
the service center.
●If the camera does not work properly, contact your dealer or
the nearest service center. Never attempt to disassemble the
speed dome yourself. (We shall not assume any responsibility
for problems caused by unauthorized repair or maintenance.)
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●To ensure explosion-proof performance, do not damage
explosion-proof surface.
●Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.

Network Dome Camera·Quick Start Guide
9
●Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.
●The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of
sensor will not be exposed to the laser beam.
●Do not place the camera in extremely hot, cold (the operating
temperature shall be -40°C to +60°C), dusty or damp locations,
and do not expose it to high electromagnetic radiation.
●To avoid heat accumulation, good ventilation is required for
operating environment.
●To prevent accumulation of electrostatic charge, only damp
cloth can be used during the cleaning.
●Keep the camera away from liquid while in use.
●While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
●Regular part replacement: a few parts (e.g. electrolytic
capacitor) of the equipment shall be replaced regularly
according to their average enduring time. The average time
varies because of differences between operating environment
and using history, so regular checking is recommended for all
the users. Please contact with your dealer for more details.
●Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.

Network Dome Camera·Quick Start Guide
10
●CAUTION: Risk of explosion if the battery is replaced by an
incorrect type. Dispose of used batteries according to the
instructions
ATTENTION: IL Y A RISQUE D'EXPLOSION SI LA BATTERIE EST
REMPLACÉE PAR UNE BATTERIE DE TYPE INCORRECT. METTRE
AU REBUT LES BATTERIES USAGÉES CONFORMÉMENT AUX
INSTRUCTIONS
●Improper replacement of the battery with an incorrect type
may defeat a safeguard (for example, in the case of some
lithium battery types).
●Do not dispose of the battery into fire or a hot oven, or
mechanically crush or cut the battery, which may result in an
explosion.
●Do not leave the battery in an extremely high temperature
surrounding environment, which may result in an explosion or
the leakage of flammable liquid or gas.
●Do not subject the battery to extremely low air pressure, which
may result in an explosion or the leakage of flammable liquid or
gas.
●If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)

Network Dome Camera·Quick Start Guide
11
Table of Contents
1 Introduction .............................................................................12
1.1 Overview ............................................................................12
1.2 Model Description.............................................................12
2 Appearance Description............................................................14
2.1 Overview ............................................................................14
2.2 Cable Description ..............................................................15
3 Installation...............................................................................16
3.1 Wall Mounting ...................................................................17
3.2 Pendant Mounting.............................................................20
4 Activate and Access Network Camera........................................22

Network Dome Camera·Quick Start Guide
12
1Introduction
1.1 Overview
Explosion-proof network camera is a video security product capable
of smart encoding and network transmitting. It adopts an embedded
system and a high-performed hardware process platform to achieve
good stability and reliability.
You can visit and configure your camera via web browser and client
software.
Explosion-proof network camera adopts a stainless steel enclosure,
receiving an IP68 rating for ingress protection.
Application Scenarios: oil industry, mine fields, chemical industry,
port, grain processing industry, etc.
1.2 Model Description
This manual is applicable to the following models:
Table 1-1 Applicable Model List
Model List
DS-2XE6126FWD-HS
DS-2XE6136F-HS
DS-2XE6146F-HS
DS-2XE6166F-HS
DS-2XE6186F-HS
DS-2XE6127FWD-HS
DS-2XE6147F-HS
DS-2XE6157F-HS
DS-2XE6167F-HS
DS-2XE6126FWD-S
DS-2XE6146F-S
DS-2XE6166F-S
DS-2XE6186F-S

Network Dome Camera·Quick Start Guide
13
On-board Storage Logo(F/Blank, nothing to do with explosion-proof properties) F:supports on-board storage,blank:no supports on-board storage
DS-2 X E 6 1 2 6 F -H S
Hikvision Front-end Product Logo
For Specialized Application Logo(XE) XE:professional products
Product Type (6) 6:professional products
Product Shape Logo(1) 1:dome camera
Max.Resolution Logo(0~9/A~Z, nothing to do with explosion-proof properties) 0:WD1, 1: 1.3 MP, 2: 2.0 MP, 3: 3.0 MP, 4: 4.0 MP, 5: 5.0 MP, 6: 6.0 MP, 8: 8.0 MP, 9: 9.0 MP, etc.
Hardware Performance Logo(0-9, nothing to do with explosion-proof properties) 0:hardware version V-0, 1:hardware version V-1, 2:hardware version V-2, 3:hardware version V-3, 4:hardware version V-4, 5:hardware version V-5, 6:hardware version V-6, 7:hardware version V-7,etc.
Interface Logo (S/Blank） S :audio I/O, alarm I/O, RS-485 interface; blank: without Audio I/O, Alarm I/O, RS-485 interface
WD
Wide-dynamic Function Logo(WD/Blank, nothing to do with explosion-proof properties) WD:supports 120dB wide-dynamic ,blank:no supports 120dB wide-dynamic range
Heater Logo(H/Blank) H: have heater; blank: without.
Figure 1-1 Model Explanation

Network Dome Camera·Quick Start Guide
14
2Appearance Description
2.1 Overview
Figure 2-1 Explosion-Proof Network Dome Camera Overview

Network Dome Camera·Quick Start Guide
15
2.2 Cable Description
1
2
3
4
5
1
1
1
2
4
4
8
1
Figure 2-2 Overview of Cables
Table 2-1 Description of Cables
No.
Description
No.
Description
1
RS-485
4
Power cord (12 VDC)
2
Alarm input and output
5
RJ45 Ethernet interface
3
Audio input and output

Network Dome Camera·Quick Start Guide
16
3Installation
Before you start:
●Make sure the device in the package is in good condition and all
the assembly parts are included.
●The standard power supply is PoE or 12 VDC. Please make sure
your power supply matches with your camera.
●Make sure all the related equipment is power-off during the
installation.
●Check the specification of the products for the installation
environment.
●Make sure that the wall is strong enough to withstand four
times the weight of the camera and the bracket.
For the camera that supports IR, you are required to pay attention to
the following precautions to prevent IR reflection:
●Dust or grease on the dome cover will cause IR reflection.
Please do not remove the dome cover film until the installation
is finished. If there is dust or grease on the dome cover, clean
the dome cover with clean soft cloth and isopropyl alcohol.
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing reflection.
●The foam ring around the lens must be seated flush against the
inner surface of the bubble to isolate the lens from the IR LEDS.
Fasten the dome cover to camera body so that the foam ring
and the dome cover are attached seamlessly.

Network Dome Camera·Quick Start Guide
17
3.1 Wall Mounting
Before you start:
There is no wall mounting bracket included in the package. You have
to prepare a wall mounting bracket if you choose this mounting type.
The shown bracket below is only for demonstration.
Ø 110
4-Ø 3.5
77.8
77.8
3-Ø 6.5
Ø 100
Ø 80
Ø 136
353.4
204.3
Figure 3-1 DS-1695ZJ Wall Mount
Steps:
1. Fix the dome camera to wall mount with four screws (SC-PSFM3 ×
8-SUS).

Network Dome Camera·Quick Start Guide
18
Figure 3-2 Fix Camera to Wall Mount
2. Mark the 3 screw holes on desired mounting surface according to
the wall mount.
3. Drill screws holes (Ø10.5 mm, 0.413 inch) for expansion bolts.
4. Secure the wall mount to wall.

Network Dome Camera·Quick Start Guide
19
Expansion
Bolt
Nut
Flat Washer
Spring Washer
Figure 3-3 Secure Wall Mount
