HIK VISION PTZ-N4225I-DE User manual

Network Speed Dome
User Manual

Legal Informaon
©2021 Hangzhou Hikvision Digital Technology Co., Ltd.
About this Manual
Pictures, charts, images and all other informaon hereinaer are for descripon and explanaon
only. The informaon contained in the Manual is subject to change, without noce, due to
rmware updates or other reasons. Please nd the latest version in the company website ( hps://
www.hikvision.com/ ). Please use this user manual under the guidance of professionals.
Trademarks
and other Hikvision's trademarks and logos are the properes of Hikvision in
various jurisdicons.
Other trademarks and logos menoned below are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH
ALL FAULTS AND ERRORS”. HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
Network Speed Dome User Manual
i

TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.
Network Speed Dome User Manual
ii

Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Product Introducon .............................................................................................................. 1
1.2 Key Funcon .......................................................................................................................... 1
1.3 System Requirement .............................................................................................................. 1
Chapter 2 Device Acvaon and Accessing ................................................................................. 2
2.1 Acvate Device ...................................................................................................................... 2
2.1.1 Acvate Device via Web Browser .................................................................................. 2
2.1.2 Acvate via SADP .......................................................................................................... 3
2.2 Access Device via Web Browser ............................................................................................. 4
2.2.1 Plug-in Installaon ........................................................................................................ 4
2.2.2 Admin Password Recovery ............................................................................................ 5
2.2.3 Illegal Login Lock ........................................................................................................... 5
Chapter 3 PTZ ............................................................................................................................. 7
3.1 PTZ Control ............................................................................................................................ 7
3.2 Set Preset ............................................................................................................................... 9
3.2.1 Special Presets .............................................................................................................. 9
3.3 Set Patrol Scan ..................................................................................................................... 10
3.3.1 Set One-Touch Patrol .................................................................................................. 11
3.4 Set Paern Scan ................................................................................................................... 11
3.5 Set Limit ............................................................................................................................... 12
3.6 Set Inial Posion ................................................................................................................ 13
3.7 Set Scheduled Tasks ............................................................................................................. 13
3.8 Set Park Acon ..................................................................................................................... 14
3.8.1 Set One-Touch Park ..................................................................................................... 14
3.9 Set Privacy Mask .................................................................................................................. 14
3.10 Set Smart Tracking ............................................................................................................. 15
Network Speed Dome User Manual
iii

3.11 Set Power O Memory ...................................................................................................... 16
3.12 Set PTZ Priority ................................................................................................................... 16
3.13 Set Rapid Focus .................................................................................................................. 17
Chapter 4 Live View .................................................................................................................. 18
4.1 Live View Parameters ........................................................................................................... 18
4.1.1 Start and Stop Live View ............................................................................................. 18
4.1.2 Aspect Rao ................................................................................................................ 18
4.1.3 Live View Stream Type ................................................................................................ 18
4.1.4 Quick Set Live View ..................................................................................................... 18
4.1.5 Select the Third-Party Plug-in ..................................................................................... 19
4.1.6 Count Pixel .................................................................................................................. 19
4.1.7 Start Digital Zoom ....................................................................................................... 19
4.1.8 Conduct Regional Focus .............................................................................................. 19
4.1.9 Conduct Regional Exposure ........................................................................................ 20
4.1.10 Light .......................................................................................................................... 20
4.1.11 Lens Inializaon ...................................................................................................... 20
4.1.12 Track Manually .......................................................................................................... 20
4.1.13 Conduct 3D Posioning ............................................................................................. 20
4.1.14 Undervoltage Alarm .................................................................................................. 21
4.1.15 Display Target Informaon on Live View ................................................................... 21
4.2 Set Transmission Parameters ............................................................................................... 21
4.3 OSD Menu ............................................................................................................................ 22
Chapter 5 Video and Audio ....................................................................................................... 23
5.1 Video Sengs ...................................................................................................................... 23
5.1.1 Stream Type ................................................................................................................ 23
5.1.2 Video Type .................................................................................................................. 23
5.1.3 Resoluon ................................................................................................................... 23
5.1.4 Bitrate Type and Max. Bitrate ..................................................................................... 24
Network Speed Dome User Manual
iv

5.1.5 Video Quality .............................................................................................................. 24
5.1.6 Frame Rate .................................................................................................................. 24
5.1.7 Video Encoding ........................................................................................................... 24
5.1.8 I-Frame Interval ........................................................................................................... 26
5.2 Audio Sengs ...................................................................................................................... 26
5.2.1 Audio Input ................................................................................................................. 26
5.2.2 Environmental Noise Filter .......................................................................................... 27
5.3 Two-way Audio .................................................................................................................... 27
5.4 ROI ....................................................................................................................................... 27
5.4.1 Set ROI ........................................................................................................................ 28
5.5 Display Info. on Stream ........................................................................................................ 28
5.6 Display Sengs .................................................................................................................... 28
5.6.1 Scene Mode ................................................................................................................ 29
5.6.2 Image Parameters Switch ............................................................................................ 32
5.6.3 Mirror .......................................................................................................................... 33
5.6.4 Video Standard ........................................................................................................... 33
5.6.5 Zoom Limit .................................................................................................................. 33
5.7 OSD ...................................................................................................................................... 33
5.8 Demist .................................................................................................................................. 34
Chapter 6 Video Recording and Picture Capture ........................................................................ 35
6.1 Storage Sengs ................................................................................................................... 35
6.1.1 Memory Card .............................................................................................................. 35
6.1.2 Set FTP ........................................................................................................................ 37
6.1.3 Set NAS ....................................................................................................................... 38
6.1.4 Set Cloud Storage ........................................................................................................ 39
6.2 Video Recording ................................................................................................................... 39
6.2.1 Record Automacally .................................................................................................. 39
6.2.2 Record Manually ......................................................................................................... 41
Network Speed Dome User Manual
v

6.2.3 Playback and Download Video .................................................................................... 41
6.3 Capture Conguraon .......................................................................................................... 42
6.3.1 Capture Automacally ................................................................................................ 42
6.3.2 Capture Manually ........................................................................................................ 42
6.3.3 View and Download Picture ........................................................................................ 42
Chapter 7 Event and Alarm ....................................................................................................... 44
7.1 Basic Event ........................................................................................................................... 44
7.1.1 Set Moon Detecon .................................................................................................. 44
7.1.2 Set Video Tampering Alarm ........................................................................................ 46
7.1.3 Set Excepon Alarm .................................................................................................... 47
7.1.4 Set Alarm Input ........................................................................................................... 48
7.2 Smart Event .......................................................................................................................... 48
7.2.1 Detect Audio Excepon ............................................................................................... 48
7.2.2 Set Face Detecon ...................................................................................................... 49
7.2.3 Set Intrusion Detecon ............................................................................................... 50
7.2.4 Set Line Crossing Detecon ......................................................................................... 51
7.2.5 Set Region Entrance Detecon ................................................................................... 53
7.2.6 Set Region Exing Detecon ....................................................................................... 54
7.2.7 Set Object Removal Detecon .................................................................................... 55
7.2.8 Set Unaended Baggage Detecon ............................................................................ 57
Chapter 8 Arming Schedule and Alarm Linkage ......................................................................... 59
8.1 Set Arming Schedule ............................................................................................................ 59
8.2 Linkage Method Sengs ...................................................................................................... 59
8.2.1 Trigger Alarm Output .................................................................................................. 59
8.2.2 FTP/NAS/Memory Card Uploading ............................................................................. 61
8.2.3 Send Email .................................................................................................................. 61
8.2.4 Nofy Surveillance Center .......................................................................................... 62
8.2.5 Smart Tracking ............................................................................................................ 62
Network Speed Dome User Manual
vi

8.2.6 Trigger Recording ........................................................................................................ 62
Chapter 9 Network Sengs ...................................................................................................... 63
9.1 TCP/IP ................................................................................................................................... 63
9.1.1 Mulcast ..................................................................................................................... 64
9.1.2 Mulcast Discovery ..................................................................................................... 64
9.2 Port ...................................................................................................................................... 65
9.3 Port Mapping ....................................................................................................................... 66
9.3.1 Set Auto Port Mapping ................................................................................................ 66
9.3.2 Set Manual Port Mapping ........................................................................................... 66
9.3.3 Set Port Mapping on Router ....................................................................................... 67
9.4 SNMP ................................................................................................................................... 68
9.5 Access to Device via Domain Name ..................................................................................... 68
9.6 Access to Device via PPPoE Dial Up Connecon .................................................................. 69
9.7 Operate via Mobile Client .................................................................................................... 69
9.7.1 Enable HiLookVision Service on Camera ..................................................................... 70
9.7.2 Set Up HiLookVision .................................................................................................... 71
9.7.3 Add Camera to HiLookVision ...................................................................................... 71
9.8 Wi-Fi ..................................................................................................................................... 72
9.8.1 Connect Device to Wi-Fi .............................................................................................. 72
9.9 Set ISUP ................................................................................................................................ 73
9.10 Set Open Network Video Interface .................................................................................... 73
9.11 Set Network Service ........................................................................................................... 73
9.12 Set Alarm Server ................................................................................................................ 74
9.13 TCP Acceleraon ................................................................................................................ 75
9.14 Trac Shaping .................................................................................................................... 75
9.15 Set SRTP ............................................................................................................................. 75
Chapter 10 System and Security ................................................................................................ 76
10.1 View Device Informaon .................................................................................................... 76
Network Speed Dome User Manual
vii

10.2 Restore and Default ........................................................................................................... 76
10.3 Search and Manage Log ..................................................................................................... 76
10.4 Import and Export Conguraon File ................................................................................ 77
10.5 Export Diagnose Informaon ............................................................................................. 77
10.6 Reboot ............................................................................................................................... 77
10.7 Upgrade ............................................................................................................................. 77
10.8 View Open Source Soware License .................................................................................. 78
10.9 Set Live View Connecon ................................................................................................... 78
10.10 Time and Date .................................................................................................................. 78
10.10.1 Synchronize Time Manually .................................................................................... 78
10.10.2 Set NTP Server ........................................................................................................ 78
10.10.3 Set DST .................................................................................................................... 79
10.11 Set RS-485 ........................................................................................................................ 79
10.12 Security ............................................................................................................................ 79
10.12.1 Authencaon ........................................................................................................ 80
10.12.2 Set IP Address Filter ................................................................................................ 80
10.12.3 Set HTTPS ................................................................................................................ 81
10.12.4 Security Audit Log ................................................................................................... 81
10.12.5 Set QoS .................................................................................................................... 82
10.12.6 Set IEEE 802.1X ....................................................................................................... 83
10.12.7 Cercate Management ......................................................................................... 83
10.12.8 Control Timeout Sengs ........................................................................................ 86
10.12.9 User and Account .................................................................................................... 86
Appendix A. Device Command .................................................................................................. 88
Appendix B. Device Communicaon Matrix .............................................................................. 89
Network Speed Dome User Manual
viii

Chapter 1 Overview
1.1 Product Introducon
The Network Speed Dome is an integraon of the HD zoom camera and the PT module, ideal for
remote monitoring. The device is easy to install and operate. Through Ethernet control, the device
is able to compress and transmit images to mulple users. With network aached storage (NAS),
the device is able to store and retrieve data easily.
The device is well suited for HD monitoring in various places, such as rivers, forests, roads, railways,
airports, ports, oil elds, posts, squares, parks, scenic areas, streets, staons, stadiums, residenal
blocks, libraries, shopping malls, hotels, government buildings, museums, and banks.
1.2 Key Funcon
The key funcons of the device are as follows. Actual funcons may vary for dierent models. You
can enable the funcons as you need.
Event Funcon
The device detects basic events and mulple smart events.
PTZ Funcon
The device supports PTZ funcons, such as presets, scans, patrol, and power-o memory.
1.3 System Requirement
Your computer should meet the requirements for proper vising and operang the product.
Recommended Specicaons
Operang System Microso Windows XP/ Windows 7/ Windows 8/ Windows 10
Mac OS 10.13 or later
CPU Intel® Penum® IV 3.0 GHz or higher
RAM 1 G or higher
Display 1024 × 768 resoluon or higher
Web Browser Internet Explorer 10 and above version, Apple Safari 12 and above
version, Mozilla Firefox 52 and above version, Google Chrome 57 and
above version.
Network Speed Dome User Manual
1

Chapter 2 Device Acvaon and Accessing
To protect the security and privacy of the user account and data, you should set a login password
to acvate the device when access the device via network.
Note
Refer to the user manual of the soware client for the detailed informaon about the client
soware acvaon.
2.1 Acvate Device
The device need to be acvated by seng a strong password before use. This part introduces
acvaon using dierent client tools.
2.1.1 Acvate Device via Web Browser
Use web browser to acvate the device. For the device with the DHCP enabled by default, use
SADP soware or PC client to acvate the device.
Before You Start
Make sure your device and your PC connect to the same LAN.
Steps
1. Change the IP address of your PC to the same subnet as the device.
The default IP address of the device is 192.168.1.64.
2. Open a web browser and input the default IP address.
3. Create and conrm the admin password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4. Click OK to complete acvaon and enter Live View page.
5. Modify IP address of the camera.
1) Enter IP address modicaon page. Conguraon → Network → TCP/IP
2) Change IP address.
3) Save the sengs.
Network Speed Dome User Manual
2

2.1.2 Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
Before You Start
●Get the SADP soware from the supplied disk or the ocial website hp://
www.hikvision.com/ , and install the SADP according to the prompts.
●The device and the PC that runs the SADP tool should belong to the same subnet.
The following steps show how to acvate one device and modify its IP address. For batch acvaon
and IP address modicaon, refer to User Manual of SADP for details.
Steps
1. Run the SADP soware and search the online devices.
2. Find and select your device in online device list.
3. Input new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4. Click Acvate to start acvaon.
Status of the device becomes Acve aer successful acvaon.
5. Modify IP address of the device.
1) Select the device.
Network Speed Dome User Manual
3

2) Change the device IP address to the same subnet as your computer by either modifying the IP
address manually or checking Enable DHCP.
3) Input the admin password and click Modify to acvate your IP address modicaon.
2.2 Access Device via Web Browser
Before You Start
Check the system requirement to conrm that the operang computer and web browser meets
the requirements. See System Requirement .
Steps
1. Open the web browser.
2. Input IP address of the device to enter the login interface.
3. Input user name and password.
Note
Illegal login lock is acvated by default. If admin user performs seven failed password aempts
(ve aempts for user/operator), the IP address is blocked for 30 minutes.
If illegal login lock is not needed, go to Conguraon → System → Security → Security Service
to turn it o.
4. Click Login.
5. Download and install appropriate plug-in for your web browser.
For IE based web browser, webcomponents and QuickTimeTM are oponal. For non-IE based web
browser, webcomponents, QuickTimeTM, VLC and MJEPG are oponal.
2.2.1 Plug-in Installaon
Certain operaon systems and web browser may restrict the display and operaon of the device
funcon. You should install plug-in or complete certain sengs to ensure normal display and
operaon. For detailed restricted funcon, refer to the actual device.
Operang System Web Browser Operaon
Windows Internet Explorer 10+ Follow pop-up prompts to
complete plug-in installaon.
Windows 7 and above version Google Chrome 57+
Mozilla Firefox 52+
Click to
download and install plug-in.
Mac OS Google Chrome 57+
Mozilla Firefox 52+
Mac Safari 12+
Plug-in installaon is not
required.
Go to Conguraon →
Network → Advanced Sengs
Network Speed Dome User Manual
4

Operang System Web Browser Operaon
→ Network Service to enable
WebSocket or Websockets for
normal view. Display and
operaon of certain funcons
are restricted. For example,
Playback and Picture are not
available. For detailed
restricted funcon, refer to the
actual device.
Note
The device only supports Windows and Mac OS system and do not support Linux system.
2.2.2 Admin Password Recovery
If you forget the admin password, you can reset the password by clicking Forget Password on the
login page aer compleng the account security sengs.
You can reset the password by seng the security queson or email.
Note
When you need to reset the password, make sure that the device and the PC are on the same
network segment.
Security Queson
You can set the account security during the acvaon. Or you can go to Conguraon → System →
User Management , click Account Security Sengs, select the security queson and input your
answer.
You can click Forget Password and answer the security queson to reset the admin password when
access the device via browser.
Email
You can set the account security during the acvaon. Or you can go to Conguraon → System →
User Management , click Account Security Sengs, input your email address to receive the
vericaon code during the recovering operaon process.
2.2.3 Illegal Login Lock
It helps to improve the security when accessing the device via Internet.
Network Speed Dome User Manual
5

Go to Conguraon → System → Security → Security Service , and enable Enable Illegal Login
Lock. Illegal Login Aempts and Locking Duraon are congurable.
Illegal Login Aempts
When your login aempts with the wrong password reach the set mes, the device is locked.
Locking Duraon
The device releases the lock aer the seng duraon.
Network Speed Dome User Manual
6

Chapter 3 PTZ
PTZ is an abbreviaon for pan, lt, and zoom. It means the movement opons of the camera.
3.1 PTZ Control
In live view interface, you can use the PTZ control buons to control the device panning, lng,
and zooming.
PTZ Control Panel
Click and hold the direconal buon to pan/lt
the device.
Note
●You can set Keyboard Control Speed in
Conguraon → PTZ → Basic Sengs . The
speed of pan/lt movement in live view is
based on this speed level.
●You can set Max. Tilt-angle in Conguraon
→ PTZ → Basic Sengs to limit lt
movement range.
Click the buon, then the device keeps panning.
Note
You can set Auto Scan Speed in Conguraon
→ PTZ → Basic Sengs . The higher the value
you set, the faster the device pans.
Drag the slider to adjust the speed of pan/lt
movement.
Note
You can set Manual Control Speed in Conguraon → PTZ → Basic Sengs .
Network Speed Dome User Manual
7

Compable The control speed is same as Keyboard Control
Speed.
Pedestrian Choose Pedestrian when you monitor the
pedestrians.
Non-motor Vehicle Choose Non-motor Vehicle when you monitor
the non-motor vehicles.
Motor Vehicle Choose Motor Vehicle when you monitor the
motor vehicles.
Auto You are recommended to set it as Auto when
the applicaon scene of the speed dome is
complicated.
To avoid blurred image resulted from fast zoom, you can check Enable Proporonal Pan in
Conguraon → PTZ → Basic Sengs . If you enable this funcon, the pan/lt speed change
according to the amount of zoom. When there is a large amount of zoom, the pan/lt speed will be
slower for keeping the image from moving too fast on the live view image.
Zoom in/out
Click the buon, and the lens zooms in.
Click the buon, and the lens zooms out.
Note
●You can set Zooming Speed in Conguraon → PTZ → Basic Sengs . The higher the value is,
the faster the zooming speed is.
●You can set Zoom Limit in Conguraon → Image → Display Sengs → Other to limit the
maximum value of the total zoom (digital zoom and opcal zoom).
Focus
Click the buon, then the lens focuses near and
the object nearby gets clear.
Click the buon, then the lens focuses far and
the object far away gets clear.
Network Speed Dome User Manual
8

Iris
When the image is too dark, click the buon to
enlarge the iris.
When the image is too bright, click the buon
to stop down the iris.
3.2 Set Preset
A preset is a predened image posion. For the dened preset, you can call the preset No. to view
the posion.
Steps
1. Click to show the seng panel, and click .
2. Use the PTZ control buons to move the lens to the desired posion.
3. Select a preset number from the preset list, and click to nish the seng.
Note
Some presets are predened with special command. You can only call them but not congure
them.
4. Repeat the steps above to set mulple presets.
Click the buon to call the preset.
Click the buon to delete the preset.
Note
You can delete all presets in Conguraon → PTZ → Clear Cong . Click Clear All Presets, and
click Save.
What to do next
Go to Conguraon → PTZ → Basic Sengs to set preset freezing and preset speed.
Aer enabling preset freezing, the live image switches directly from one preset to another, without
showing the areas between these two scenes. It also guarantees the masked area will not be seen
when the device is moving.
3.2.1 Special Presets
You can call the following presets with special demands to enable corresponding funcons.
Network Speed Dome User Manual
9

Preset No. Funcon Preset No. Funcon
33 Auto ip 92 Set manual limits
34 Back to origin 93 Save manual limits
35 Call patrol 1 94 Remote reboot
36 Call patrol 2 95 Call OSD menu
37 Call patrol 3 96 Stop a scan
38 Call patrol 4 97 Start random scan
39 Day mode 98 Start frame scan
40 Night mode 99 Start auto scan
41 Call paern 1 100 Start lt scan
42 Call paern 2 101 Start panorama scan
43 Call paern 3 102 Call patrol 5
44 Call paern 4 103 Call patrol 6
45 One-touch patrol 104 Call patrol 7
46 Day/Night Mode 105 Call patrol 8
3.3 Set Patrol Scan
Patrol scan is a funcon to automacally move among mulple presets.
Before You Start
Note
This funcon is only supported by certain models.
Make sure that you have dened more than one presets. See Set Preset for detailed conguraon.
Steps
1. Click to show the seng panel, and click to enter patrol seng interface.
2. Select a patrol number from the list and click .
3. Click to add presets.
Preset
Select predened preset.
Speed
Set the speed of moving from one preset to another.
Network Speed Dome User Manual
10

Time
It is the duraon staying on one patrol point.
Delete the presets in patrol.
Adjust the preset order.
Note
A patrol can be congured with 32 presets at most, and 2 presets at least.
4. Click OK to nish a patrol seng.
5. Repeat the steps above to congure mulple patrols.
6. Operate patrols.
Call the patrol.
Stop patroling.
Delete the patrol.
Set the patrol.
Note
You can delete all patrols in Conguraon → PTZ → Clear Cong . Click Clear All Patrols, and
click Save.
3.3.1 Set One-Touch Patrol
The device automacally adds presets to one patrol path and starts patrol scan.
Steps
1. Set two or more presets among preset No.1 to preset No.32. For seng presets, refer to Set
Preset .
The device will automacally add presets to patrol path No.8.
2. Choose one of the following methods to enable the funcon.
-Click .
-Call patrol path No.8.
-Select and call preset No.45.
3.4 Set Paern Scan
The device can move as the recorded paern.
Network Speed Dome User Manual
11
