Hill Laboratories Hill Mat User manual
R E F E R E N C E M A N U A
Hill Mat
Treatment Table
Hill aboratories Company has been making
quality a family business since 1945.
Your Hill Mat Table is built in a tradition of
innovation and value that Hill aboratories products
have become known for.
Our good name rests on the confidence that
your Hill Chair will provide you with solid, reliable service
for many years to come.
And welcome to the Hill aboratories family
Congratulations!
Your Hill aboratories Mat Table has been thoroughly tested and inspected before
shipment. All parts are guaranteed against defect in materials for one full year
from date of purchase. During this period, any such defect will be remedied by
Hill aboratories or by a factory-authorized repair service without charge.
Tables damaged by mishandling or accident will be
repaired at a reasonable charge.
All correspondence should be directed to your local dealer, or when this is not
possible, to Hill aboratories directly.
We appreciate your business and your confidence in our product. Our aim is to
provide you with excellent service and satisfaction for many years to come.
President of Hill aboratories Company
Table Serial Number_______________________________
The Hill aboratories Guarantee
At Your Service
3
Ready for use
Your Hill Mat Table comes ready to plu into any 115 v~ outlet.
Vinyl Bumber Guard
Protects table perimeter
Recessed Le s
For easy mobility around the table
Lifting Capacity
700 lbs.
Height Range - 20”-33”
Standard Si es
4'x7', 5'x7', 6'x8'
Table Base Skirting
Acrylic thermo-plastic
Foam
Ultra-Cell®for comfort and shape retention
Shipping Weight
Approximately 250 lbs
Electric Requirements
115 v~, 60 Hz., 5 A (single motor), 10 A (2 motor),
where specified - 230 v~, 50 Hz.
Note: Grounding reliability can only be achieved
when the equipment is connected to an equivalent
receptacle marked hospital only or hospital grade.
There is no EMI concern related to the safe
operation of this table.
Transportation and Storage Conditions
Ambient Temperature Ran e:
-30°C to +60°C (-22°F to 140°F)
Relative Humidity
0% to 90% (non-condensing)
Specifications
Stain Resistant Vinyl Upholstery
Protective
acrylic base
Encloses all
interior parts
Electric Foot Pedal
for height adjustment
Table Care
Your Hill Table comes upholstered in a highly durable vinyl material. Its appearance is guarded by Prefixx™
brand protective finish. Your upholstery may be cleaned with the Hill aboratories Vinyl Cleaner or any non-
abrasive household detergent without change to surface luster. Stubborn stains can be cleaned with most
common solvent cleaners such as naphtha (lighter fluid), rubbing alcohol (IPA type), toluene, Coleman
gas, turpentine (paint thinner), and nail polish remover (50/50 mixture of acetone and water) with no change
to surface luster or color. One hundred percent acetone can also be used for short periods but it is sug-
gested that it first be tested on an inconspicuous area of the table.
Caution: These solvents are highly flammable; exercise proper care when cleaning with these materials and
do not use near open flame or intense heat. Wear rubber gloves during all cleaning activities. When clean-
ing other parts of your table (besides upholstery) use only nonabrasive household detergents and water.
Caution: Be sure to unplug your Hill Table before performing any maintenance on the table.
Caution: The table should be checked once a year to make sure all internal and external bolts are secure.
Caution: The table should be in its lowest height position when not attended.
Caution: In case of power outage, the table will rely on the generator back-up of the facility where the table
is installed for powering the table to its lowest position.
Caution: The power cord shall be located to avoid objects being rolled over or placed on top of it and also to
avoid people tripping over it. Damaged cords should be replaced with another of hospital grade.
Caution:
Grounding reliability can only be achieved when the equipment is connected to an
equivalent receptacle marked hospital only or hospital grade.
Symbols - Each of the symbols below are used in your product labelin . An explanation of
each is below.
Cleanin Your Table
Cautions and Symbol Explanation
4
~
Attention Symbol
consult accompanying
documents
Dan erous Volta e
Symbol
Type BF Applied
Part Symbol
Ground
Symbol
Alternatin Current
Symbol
Table Features
Foot Pedals
Two foot pedals may be included on your Mat Table. One,
marked Hei ht, controls table elevation. For Mat tables with the
lift back function, a second pedal marked Back, controls the
angle of the back cushion. Foot pedals should be carefully locat-
ed so as to avoid creating a tripping hazard.
5
Side Rails
Optional side rails are mounted at each side of the
mat cushion and very helpful for increased security
while patient is positioned on the table. To move the
rails to the down position, loosen the black knob (see
photo), push rail towards the left to disengage the
square locking tube, and then swing the rail to the
down position.
oosen knob, push back,
then swing down
Diagrams
6
RU
[[
[
[
+HLJKW5DQJH
HA90 Dimensions
Wiring Diagrams
7
Sin le Motor Dia ram
Wiring Diagrams
8
Two Motor Dia ram
90D Dermatology
Chair
Podiatry Model
90MD
HA90E
PT Tilting
90C
Mat Table
HA90 ift Back
HA90
Anatomotor
Massage w/Traction
Tables Manufactured by Hill Laboratories
Air90C
Hi- o
Air-Flex
w/4 Drops
HA90V Tilt
Vascular/Diagnostic
Rath Mechanical
McKenzie Technique
PT Mobilization
Repex Table
McKenzie Technique
Counterstrain
(multi-positional)
90W Wound Care Chair
Posture Angel™
Active Rehab System
P.O. Box 2028, 3 Bacto Hill Road, Frazer, PA 19355 • pho e 1-877-445-5020 • 610-644-2867 • fax 610-647-6297 • www.HillLabs.com
