hilscher NSCP-C100-RE\50 User manual

65
User Manual
netSCOPE Data Acquisition Cards for Real-Time Ethernet
PCI (NSCP-C100-RE\50)
PCI Express (NSCP-C100-RE\50E)
Low Profile PCIe (NSCP-C100-RE\70E)
Compact PCI (NSCP-C100-RE\80)
Mini PCI Express (NSCP-C100-RE\90E)
Installation, Operation and Hardware Description
Hilscher Gesellschaft für Systemautomation mbH
www.hilscher.com
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public

Table of Contents 2/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
Table of Contents
1INTRODUCTION.........................................................................................................5
1.1 About the User Manual...............................................................................................5
1.1.1 List of Revisions ...................................................................................................5
1.1.2 Notes on Hardware, Software and Driver Versions .............................................6
1.1.3 Conventions in this Manual..................................................................................7
1.1.4 Used Terminology ................................................................................................7
1.2 Contents of the netSCOPE LabVIEW DVD................................................................8
1.2.1 Directory Structure of the netSCOPE LabVIEW DVD..........................................8
1.2.2 Documentation .....................................................................................................8
1.3 Legal Notes.................................................................................................................9
1.3.1 Copyright..............................................................................................................9
1.3.2 Important Notes....................................................................................................9
1.3.3 Exclusion of Liability...........................................................................................10
1.3.4 Warranty.............................................................................................................10
1.3.5 Export Regulations.............................................................................................11
1.3.6 Registered Trademarks......................................................................................11
1.3.7 Obligation to read and understand the Manual..................................................11
1.3.8 Hilscher Software License Agreement...............................................................11
2SAFETY ....................................................................................................................12
2.1 General Note ............................................................................................................12
2.2 Intended Use ............................................................................................................12
2.3 Personnel Qualification.............................................................................................12
2.4 Safety Instructions to avoid Personal Injury..............................................................13
2.4.1 Electrical Shock Hazard .....................................................................................13
2.5 Safety Instructions to avoid Property Damage .........................................................14
2.5.1 Device Destruction by exceeding allowed Supply Voltage ................................14
2.5.2 Device Destruction by exceeding allowed Signaling Voltage ............................14
2.5.3 Electrostatically sensitive Devices......................................................................15
2.6 Labeling of Safety Messages....................................................................................16
2.7 References Safety....................................................................................................16
3DESCRIPTIONS AND REQUIREMENTS.................................................................17
3.1 Introduction to netSCOPE ........................................................................................17
3.2 netSCOPE Data Acquisition Cards...........................................................................18
3.3 Recording and analyzing Data Traffic.......................................................................20
3.4 Hardware Requirements...........................................................................................21
3.4.1 PC.......................................................................................................................21
3.4.2 Slot for the netSCOPE Data Acquisition Cards.................................................21
3.4.3 Card Height and Panel Cutout NSCP-C100-RE\90E.........................................22
3.4.4 Power Supply and Host Interface.......................................................................23

Table of Contents 3/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
3.5 Software Requirements............................................................................................24
4GETTING STARTED.................................................................................................25
4.1 Notes for Installation and Operation.........................................................................25
4.2 Installation and Configuration netSCOPE Data Acquisition Card............................26
5DEVICE DRAWINGS................................................................................................28
5.1 netSCOPE Data Acquisition Cards PCI (NSCP-C100-RE\50) and PCI Express
(NSCP-C100-RE\50E)..............................................................................................28
5.2 netSCOPE Data Acquisition Cards Low Profile PCI Express (NSCP-C100-RE\70E)
..................................................................................................................................30
5.3 netSCOPE Data Acquisition Cards Compact PCI (NSCP-C100-RE\80)..................31
5.4 netSCOPE Data Acquisition Cards Mini PCI Express..............................................32
5.4.1 NSCP-C100-RE\90E..........................................................................................32
5.5 AIFX Assembly Interface Ethernet - AIFX-RE ..........................................................33
6SOFTWARE INSTALLATION....................................................................................34
6.1 netSCOPE LabVIEW DVD Autostart Menu..............................................................34
6.2 netANALYZER / netSCOPE Windows Device Driver...............................................34
6.3 netSCOPE for LabVIEW Instrument Driver ..............................................................37
6.4 Microsoft Software Components...............................................................................38
6.5 Documentation..........................................................................................................39
7HARDWARE INSTALLATION AND UNINSTALLING ...............................................40
7.1 Safety Messages on Personal Injury........................................................................40
7.1.1 Electrical Shock Hazard .....................................................................................40
7.2 Property Damage Messages ....................................................................................41
7.2.1 Device Destruction by exceeding allowed Supply Voltage ................................41
7.2.2 Device Destruction by exceeding allowed Signaling Voltage ............................41
7.2.3 Electrostatically sensitive Devices......................................................................41
7.3 Installing netSCOPE Data Acquisition Card............................................................42
7.4 Uninstalling netSCOPE Data Acquisition Cards......................................................46
8TROUBLESHOOTING..............................................................................................48
8.1 Instructions for Problem Solving...............................................................................48
9LED DESCRIPTIONS ...............................................................................................49
10 DEVICE CONNECTIONS..........................................................................................50
10.1 Ethernet Interface.....................................................................................................50
10.1.1 Ethernet Pin Assignment at the RJ45 Socket....................................................50
10.1.2 Ethernet Connection Data..................................................................................50
10.2 Cable Connector.......................................................................................................51
10.2.1 Pin Assignment for Cable Connector Ethernet ..................................................51

Table of Contents 4/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
10.3 Pin Assignment at the PCI Bus.................................................................................52
10.3.1 Overview.............................................................................................................52
10.3.2 References PCI Specifications...........................................................................52
10.3.3 Pin Assignment for Mini PCI Express Bus (NSCP-C100-RE\90E) ....................53
11 TECHNICAL DATA ...................................................................................................54
11.1 Technical Data netSCOPE Data Acquisition Cards.................................................54
11.1.1 NSCP-C100-RE\50.............................................................................................54
11.1.2 NSCP-C100-RE\50E..........................................................................................56
11.1.3 NSCP-C100-RE\70E..........................................................................................58
11.1.4 NSCP-C100-RE\80.............................................................................................60
11.1.5 NSCP-C100-RE\90E..........................................................................................62
11.1.6 AIFX-RE .............................................................................................................64
11.2 PCI IDs netSCOPE Data Acquisition Cards on the PCI Bus...................................65
11.3 Supported PCI-Bus Commands ...............................................................................65
12 ANNEX......................................................................................................................66
12.1 Matrix Label..............................................................................................................66
12.2 Disposal of Waste Electronic Equipment..................................................................66
12.3 List of Figures...........................................................................................................67
12.4 List of Tables ............................................................................................................67
12.5 Glossary....................................................................................................................69
12.6 Contacts....................................................................................................................71

Introduction 5/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
1 Introduction
1.1 About the User Manual
This user manual provides descriptions and installation instructions of
the installation of the software and
the installation, operation and hardware
of the netSCOPE data aquistion card PCI, PCI Express, Low Profile PCI
Express, Compact PCI and Mini PCI Express under Windows®XP,
Windows®Vista, Windows®7 and Windows®8, as listed subsequently.
netSCOPE data aquistion card for Real-Time Ethernet:
PCI (NSCP-C100-RE\50)
PCI Express (NSCP-C100-RE\50E)
Low Profile PCIe (NSCP-C100-RE\70E)
Compact PCI (NSCP-C100-RE\80)
Mini PCI Express (NSCP-C100-RE\90E)
for NSCP-C100-RE\90E inclusively the AIFX Assembly Interface1:
Ethernet (AIFX-RE)
for the Real-Time Ethernet system:
EtherCAT
The devices described in this manual are listed in the sections
- netSCOPE Data Acquisition Cards (page 18)
The devices are described in detail in the chapters
- Hardware Installation and Uninstalling (page 40),
- LED Descriptions (page 49),
- Device Connections (page 50) and
- Technical Data (page 54).
1.1.1 List of Revisions
Index Date Chapter Revisions
1 13-10-21 All Created
Table 1: List of Revisions
1The AIFX Assembly Interface is also named as „Detached Network Interface“.

Introduction 6/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
1.1.2 Notes on Hardware, Software and Driver Versions
Note: The hardware revisions and the versions for the firmware, the driver
or the software listed in this section functionally belong together.
1.1.2.1 Hardware: netSCOPE Data Acquisition Cards
netSCOPE Data Acquisition Card Part No. Hardware Revision
NSCP-C100-RE\50 7330.100 5
NSCP-C100-RE\50E 7330.101 5
NSCP-C100-RE\70E 7330.102 1
NSCP-C100-RE\80 7330.103 3
NSCP-C100-RE\90E,
inclusively Ethernet Assembly
Interface (AIFX-RE)
7330.105 B
Table 2: Reference on Hardware netSCOPE Data Acquisition Cards
1.1.2.2 Drivers and Software
Name File Name Version Path on the
netSCOPE
LabVIEW DVD
Setup netANALYZER / netSCOPE
Windows Device Driver Setup.exe 1.5.x.x Driver
Windows®XP,
Windows®Vista 32-Bit netANALYZER / netSCOPE
Windows Device Driver X86.msi - Driver\MSI
netANALYZER /
netSCOPE
Windows Device
Driver
Windows®7,
Windows®8 64-Bit netANALYZER / netSCOPE
Windows Device Driver X64.msi - Driver\MSI
netSCOPE for LabVIEW Instrument Driver netSCOPE.zip 1.0.x.x
LabVIEW
Table 3: Reference on Drivers
Name File Name Version
NI LabVIEW 2013 Platform
Windows 8/7/Vista/XP/Server DVD Set August 2013
Table 4: Reference on Software

Introduction 7/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
1.1.3 Conventions in this Manual
Notes, operation instructions and results of operation steps are marked as
follows:
Notes
Important: <important note>
Note: <note>
<note, where to find further information>
Operation Instructions
1. <instruction>
2. <instruction>
or
<instruction>
Results
<result>
Safety Instructions
The labeling of safety and warning instructions is explained separately in
chapter Safety, in section Labeling of Safety Instructions.
1.1.4 Used Terminology
netSCOPE data
acquisition card Hilscher netSCOPE data acquisition card based on
the netX technology.
NSCP-C100-RE\50 Example for the type name of a netSCOPE data
aquistion card for Real-Time Ethernet.

Introduction 8/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
1.2 Contents of the netSCOPE LabVIEW DVD
The netSCOPE LabVIEW DVD for the netSCOPE data aquistion card
contains:
The netANALYZER / netSCOPE Windows Device Driver file for 32-bit
and for 64-bit
netSCOPE for LabVIEW Instrument Driver
The documentation
1. netSCOPE User Manual (this document)
2. netSCOPE Operating Instruction Manual
1.2.1 Directory Structure of the netSCOPE LabVIEW DVD
Directory Name Description
Root Directory Flash Animation (netSCOPE-for-LabVIEW.exe)
Documentation Documentation in the Acrobat®Reader Format (PDF), Adobe®Reader Installation
Driver netANALYZER / netSCOPE Windows Device Driver for 32-bit (for Windows®XP and
Windows®Vista) respectively for 64-bit (for Windows®7 and Windows®8)
netSCOPE for LabVIEW Instrument Driver
fscommand Help files for the installation program.
LabVIEW netSCOPE.zip with the LabVIEW instrument driver
Table 5: Directory Structure of the netSCOPE LabVIEW DVD
1.2.2 Documentation
The following documentation overview gives information, for which items
you can find further information in which manual. Available on the
netSCOPE LabVIEW DVD
Document Type Title Document ID File Name
User Manual netSCOPE Data Acquisition
Cards for Real-Time Ethernet [ …]
Installation, Operation and
Hardware Description
DOC131006UMXXEN netSCOPE Data Acquisition Cards for
RTE UM xx EN.pdf
Operating
Instruction
Manual
netSCOPE,
VIs for LabVIEW DOC131005OIXXEN netSCOPE for LabVIEW OI xx EN.pdf
Table 6: Documentations netSCOPE LabVIEW DVD
These documents are available on the DVD delivered with the device
underneath the directory Documentation, in Adobe Acrobat®Reader
format (PDF) or you can download the latest edition of a manual from the
website www.hilscher.com under Support > Downloads > Manuals or
under Products directly with the information about your product.

Introduction 9/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
1.3 Legal Notes
1.3.1 Copyright
© Hilscher, 2013, Hilscher Gesellschaft für Systemautomation mbH
All rights reserved.
The images, photographs and texts in the accompanying material (user
manual, accompanying texts, documentation, etc.) are protected by
German and international copyright law as well as international trade and
protection provisions. You are not authorized to duplicate these in whole or
in part using technical or mechanical methods (printing, photocopying or
other methods), to manipulate or transfer using electronic systems without
prior written consent. You are not permitted to make changes to copyright
notices, markings, trademarks or ownership declarations. The included
diagrams do not take the patent situation into account. The company
names and product descriptions included in this document may be
trademarks or brands of the respective owners and may be trademarked or
patented. Any form of further use requires the explicit consent of the
respective rights owner.
1.3.2 Important Notes
The user manual, accompanying texts and the documentation were created
for the use of the products by qualified experts, however, errors cannot be
ruled out. For this reason, no guarantee can be made and neither juristic
responsibility for erroneous information nor any liability can be assumed.
Descriptions, accompanying texts and documentation included in the user
manual do not present a guarantee nor any information about proper use
as stipulated in the contract or a warranted feature. It cannot be ruled out
that the user manual, the accompanying texts and the documentation do
not correspond exactly to the described features, standards or other data of
the delivered product. No warranty or guarantee regarding the correctness
or accuracy of the information is assumed.
We reserve the right to change our products and their specification as well
as related user manuals, accompanying texts and documentation at all
times and without advance notice, without obligation to report the change.
Changes will be included in future manuals and do not constitute any
obligations. There is no entitlement to revisions of delivered documents.
The manual delivered with the product applies.
Hilscher Gesellschaft für Systemautomation mbH is not liable under any
circumstances for direct, indirect, incidental or follow-on damage or loss of
earnings resulting from the use of the information contained in this
publication.

Introduction 10/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
1.3.3 Exclusion of Liability
The software was produced and tested with utmost care by Hilscher
Gesellschaft für Systemautomation mbH and is made available as is. No
warranty can be assumed for the performance and flawlessness of the
software for all usage conditions and cases and for the results produced
when utilized by the user. Liability for any damages that may result from the
use of the hardware or software or related documents, is limited to cases of
intent or grossly negligent violation of significant contractual obligations.
Indemnity claims for the violation of significant contractual obligations are
limited to damages that are foreseeable and typical for this type of contract.
It is strictly prohibited to use the software in the following areas:
for military purposes or in weapon systems;
for the design, construction, maintenance or operation of nuclear
facilities;
in air traffic control systems, air traffic or air traffic communication
systems;
in life support systems;
in systems in which failures in the software could lead to personal injury
or injuries leading to death.
We inform you that the software was not developed for use in dangerous
environments requiring fail-proof control mechanisms. Use of the software
in such an environment occurs at your own risk. No liability is assumed for
damages or losses due to unauthorized use.
1.3.4 Warranty
Although the hardware and software was developed with utmost care and
tested intensively, Hilscher Gesellschaft für Systemautomation mbH does
not guarantee its suitability for any purpose not confirmed in writing. It
cannot be guaranteed that the hardware and software will meet your
requirements, that the use of the software operates without interruption and
that the software is free of errors. No guarantee is made regarding
infringements, violations of patents, rights of ownership or the freedom from
interference by third parties. No additional guarantees or assurances are
made regarding marketability, freedom of defect of title, integration or
usability for certain purposes unless they are required in accordance with
the law and cannot be limited. Warranty claims are limited to the right to
claim rectification.

Introduction 11/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
1.3.5 Export Regulations
The delivered product (including the technical data) is subject to export or
import laws as well as the associated regulations of different counters, in
particular those of Germany and the USA. The software may not be
exported to countries where this is prohibited by the United States Export
Administration Act and its additional provisions. You are obligated to
comply with the regulations at your personal responsibility. We wish to
inform you that you may require permission from state authorities to export,
re-export or import the product.
1.3.6 Registered Trademarks
Windows® XP, Windows® Vista, Windows® 7 and Windows® 8 are
registered trademarks of Microsoft Corporation.
Adobe-Acrobat®is a registered trademark of the Adobe Systems
Incorporated.
EtherCAT®is a registered trademark and a patented technology of
Beckhoff Automation GmbH, Verl, Germany, formerly Elektro Beckhoff
GmbH.
LabVIEW is a graphical programming system from National Instruments.
PCI™, PCI EXPRESS®and PCIe®or MINI PCI™ are trademarks or
registered trademarks of the Peripheral Component Interconnect Special
Interest Group (PCI-SIG).
CompactPCI™ is a trademark of the PCI Industrial Manufacturers Group
(PICMG).
All other mentioned trademarks are property of their respective legal
owners.
1.3.7 Obligation to read and understand the Manual
Important!
To avoid personal injury and to avoid property damage to your system
or to your netSCOPE data aquistion card, you must read and
understand all instructions in the manual and all accompanying texts to
your netSCOPE data aquistion card, before installing and operating your
netSCOPE data aquistion card.
First read the Safety Instructions in the safety chapter.
Obey to all Safety Messages in the manual.
Keep the product DVD providing the product manuals.
1.3.8 Hilscher Software License Agreement
When you install the Hilscher software you are asked to read the Hilscher
Software License Agreement and explain your acceptance to it.

Safety 12/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
2 Safety
2.1 General Note
The documentation in the form of a user manual, an operating instruction
manual or other manual types, as well as the accompanying texts have
been created for the use of the products by educated personnel. When
using the products, all Safety Messages, Safety Messages, Property
Damage Messages and all valid legal regulations have to be obeyed.
Technical knowledge is presumed. The user has to assure that all legal
regulations are obeyed.
2.2 Intended Use
The netSCOPE data aquistion card described in this User Manual each
work as a passive Ethernet analyzer in RT-Ethernet systems. The
netSCOPE data aquistion card analyze the data in a communication link
and capture the incoming Ethernet frames.
Name netSCOPE Data Acquisition Card
netSCOPE data acquisition card PCI for Real-Time Ethernet NSCP-C100-RE\50
netSCOPE data acquisition card PCI Express for Real-Time Ethernet NSCP-C100-RE\50E
netSCOPE data acquisition card Low Profile PCIe for Real-Time Ethernet NSCP-C100-RE\70E
netSCOPE data acquisition card Compact PCI for Real-Time Ethernet NSCP-C100-RE\80
netSCOPE data acquisition card Mini PCI for Express Real-Time Ethernet NSCP-C100-RE\90E,
inclusively Ethernet Assembly Interface
(AIFX-RE)
Table 7: netSCOPE Data Acquisition Cards
If the netSCOPE data aquistion cards are used outside of the scope
described in this user manual, an error free function can not be guaranteed.
2.3 Personnel Qualification
The netSCOPE data aquistion card must only be installed, configured and
removed by qualified personnel. Job-specific technical skills for people
professionally working with electricity must be present concerning the
following topics:
Safety and health at work
Mounting and connecting of electrical equipment
Measurement and Analysis of electrical functions and systems
Evaluation of the safety of electrical systems and equipment
Installing and Configuring IT systems

Safety 13/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
2.4 Safety Instructions to avoid Personal Injury
To ensure your own personal safety and to avoid personal injury, you
necessarily must read, understand and follow the following safety
instructions and safety messages in this manual about danger causing
personal injury, before you install and operate your netSCOPE data
aquistion card.
2.4.1 Electrical Shock Hazard
The danger of a lethal electrical shock caused by parts with more than 50V
may occur if you open the PC cabinet to install the netSCOPE data
aquistion card.
HAZARDOUS VOLTAGE is present inside of the PC or of the connec-
ting device, into which the netSCOPE data aquistion card is integrated.
Strictly obey to all safety rules provided by the device’s manufacturer in
the documentation!
First disconnect the power plug of the PC or of the connecting device,
before you open the cabinet.
Make sure, that the power supply is off at the PC or at the connecting
device.
Open the PC cabinet and install or remove the netSCOPE data aquistion
card only after disconnecting power.
An electrical shock is the result of a current flowing through the human
body. The resulting effect depends on the intensity and duration of the
current and on its path through the body. Currents in the range of
approximately ½ mA can cause effects in persons with good health, and
indirectly cause injuries resulting from startle responses. Higher currents
can cause more direct effects, such as burns, muscle spasms, or
ventricular fibrillation.
In dry conditions permanent voltages up to approximately 42.4 V peak or
60 V are not considered as dangerous if the contact area is equivalent to
the size of a human hand.
Reference Safety [S2]

Safety 14/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
2.5 Safety Instructions to avoid Property Damage
To avoid property damage respectively device destruction to the
netSCOPE data aquistion card and to your system, you necessarily must
read, understand and follow the following safety instructions and safety
messages in this manual about danger causing property damage, before
you install and operate your netSCOPE data aquistion card.
2.5.1 Device Destruction by exceeding allowed Supply Voltage
To avoid device destruction due to high supply voltage to your netSCOPE
data aquistion card, you must observe the following instructions. These
instructions apply to all netSCOPE data aquistion cards described in this
manual.
The netSCOPE data aquistion card may only be operated with the specified
supply voltage. Make sure that the limits of the allowed range for the supply
voltage are not exceeded. A supply voltage above the upper limit can
cause severe damage to the netSCOPE data aquistion card! A supply
voltage below the lower limit can cause malfunction in the netSCOPE data
aquistion card. The allowed range for the supply voltage is defined by the
tolerances specified in this manual.
For the netSCOPE data aquistion cards listed hereafter adhere specifically:
The netSCOPE data aquistion card
NSCP-C100-RE\50,
NSCP-C100-RE\50E,
NSCP-C100-RE\70E,
NSCP-C100-RE\80,
NSCP-C100-RE\90E
may not be powered by a 5V supply voltage! The netSCOPE data aquistion
card may only be powered by a 3.3 V dc ±5 % supply voltage.
The data on the mandatory supply voltage for the netSCOPE data
aquistion cards described in this manual you find in section Power Supply
and Host Interface on page 23. There the required and permitted supply
voltage is provided by device type inclusively the permitted tolerance
range.
2.5.2 Device Destruction by exceeding allowed Signaling Voltage
To avoid device destruction due to high signal voltage to your netSCOPE
data aquistion card, you must observe the following instructions. These
instructions apply to all netSCOPE data aquistion cards described in this
manual.
All I/O signal pins at the netSCOPE data aquistion card tolerate only the
specified signaling voltage!
Operating of your netSCOPE data aquistion card with a signaling
voltage other than the specified signaling voltage may lead to severe
damage to the netSCOPE data aquistion card!

Safety 15/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
The data on the mandatory signaling voltage for the netSCOPE data
aquistion cards described in this manual you find in the section Power
Supply and Host Interface on page 23.There the required and permitted
signaling voltage is provided by device type.
2.5.3 Electrostatically sensitive Devices
This equipment is sensitive to electrostatic discharge, which cause internal
damage and affect normal operation. Therefore adhere to the necessary
safety precautions for components that are vulnerable with electrostatic
discharge if you install or replace your device. Follow the guidelines listed
hereafter when you handle this equipment:
Touch a grounded object to discharge potential static.
Wear an approved grounding wriststrap.
Do not touch connectors or pins on the netSCOPE data aquistion card.
Do not touch circuit components inside the equipment.
If available, use a static-safe workstation.
When not in use, store the equipment in appropriate static-safe
packaging.
Reference Safety [S3]

Safety 16/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
2.6 Labeling of Safety Messages
The Section Safety Messages at the beginning of a chapter are
pinpointed particularly. They are highlighted with a specific safety
symbol and a signal word according to the degree of endangerment.
Inside the safety message the danger is exactly named.
The Integrated Safety Messages within an instruction description are
highlighted with a signal word according to the degree of endangerment
and possibly by a principle symbol. Inside the safety message the
danger is exactly named.
Safety
Symbol USA Sort of Warning or Principle
Warning of Personal Injury and Property Damage Message
USA: Warning of Personal Injury
As in the scope of the ANSI Z535 Standard (for USA) instructions to a property damage
message may not contain a warning triangle, this property damage messages are listed
separately for the USA.
Warning of Lethal Electrical Shock
Warning of Damages by Electrostatic Discharge
Principle: Disconnect the Power Plug
Table 8: Safety Symbols and Sort of Warning or Principle
Signal
Word Meaning Meaning (USA)
Indicates a direct hazard with high risk, which
will have as consequence death or grievous
bodily harm if it isn't avoided.
Indicates a Hazardous Situation Which if not
Avoided, will Result in Death or Serious Injury.
Indicates a possible hazard with medium risk,
which will have as consequence death or
(grievous) bodily harm if it isn't avoided.
Indicates a Hazardous Situation Which if not
Avoided, could Result in Death or Serious
Injury.
Indicates a minor hazard with medium risk,
which could have as consequence simple
battery if it isn't avoided.
Indicates a Hazardous Situation Which if not
Avoided, may Result in Minor or Moderate
Injury.
Indicates a Property Damage Message. Indicates a Property Damage Message.
Note Indicates an important note in the manual. Indicates an Important Note in the Manual.
Table 9: Signal Words
In this document all Safety Instructions and Safety Messages are designed
according both to the international used safety conventions as well as to
the ANSI Z535 standard, refer to reference safety [S1].
2.7 References Safety
[S1] ANSI Z535.6-2006 American National Standard for Product Safety Information in
Product Manuals, Instructions, and Other Collateral Materials
[S2] IEC 60950-1, Information technology equipment - Safety - Part 1: General
requirements, (IEC 60950-1:2005, modified); German Edition EN 60950-1:2006
[S3] EN 61340-5-1 and EN 61340-5-2 as well as IEC 61340-5-1 and IEC 61340-5-2

Descriptions and Requirements 17/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
3 Descriptions and Requirements
3.1 Introduction to netSCOPE
The main characteristics of the netSCOPE data aquistion cards are:
Process monitoring
Process documentation
Data acquisition of process values directly from the network
No additional signal wiring
No modification in PLC necessary
You can use the netSCOPE data aquistion cards to record and analyze
data of Ethernet based automation network or its components conforming
to the Ethernet II IEEE 802.3 specification.
For visualization, archiving or machine diagnosis purposes, not even
network telegrams but process values are captured from the network. The
netSCOPE data aquistion card is connected to the automation network as a
purely passive node.
Process values are converted to be displayed in LabVIEW for analyzing
purposes without changing your PLC program at all. All data from the
network is recorded with precision timestamp. All collected process data is
being recorded in a way that it is associated to a certain network cycle
("communication cycle accurate"). At any point of time the record is
complete, allowing examination of information like measurements, status
and control values by going back in time to find out what had happen in
your process.
A detailed description how to use the netSCOPE instrument driver in
LabVIEW you find in the Operating Instruction Manual netSCOPE, VIs
for LabVIEW.

Descriptions and Requirements 18/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
3.2 netSCOPE Data Acquisition Cards
netSCOPE Data Acquisition Cards with integrated Ethernet Interface
netSCOPE Data
Acquisition Card Description
NSCP-C100-RE\50
netSCOPE data acquisition card PCI for Real-Time Ethernet
NSCP-C100-RE\50E
netSCOPE data acquisition card PCI Express for Real-Time Ethernet
NSCP-C100-RE\70E
netSCOPE data acquisition card Low Profile PCIe for Real-Time Ethernet

Descriptions and Requirements 19/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
netSCOPE Data
Acquisition Card Description
NSCP-C100-RE\80
netSCOPE data acquisition card Compact PCI for Real-Time Ethernet
Table 10: netSCOPE Data Acquisition Cards with integrated Ethernet Interface
The netSCOPE data aquistion cards NSCP-C100-RE\50, NSCP-C100-
RE\50E, NSCP-C100-RE\70E and NSCP-C100-RE\80 provide an
integrated Ethernet interface.
netSCOPE Data Acquisition Card with AIFX Assembly Interface
Ethernet
netSCOPE Data
Acquisition Card Description
NSCP-C100-RE\90E
netSCOPE data acquisition card Mini PCI Express for Real-Time Ethernet
inclusively Ethernet Assembly Interface AIFX-RE (with Ethernet interface)
Table 11: netSCOPE Data Acquisition Card with AIFX Assembly Interface Ethernet
The netSCOPE data aquistion card NSCP-C100-RE\90E is composed of a
basic card and an assembly interface AIFX. The basic card NSCP-C100-
RE\90E is equipped with a Cable Connector Ethernet, to connect the
Ethernet assembly interface (AIFX-RE).
Important! Operating the netSCOPE data aquistion card Mini PCI
Express NSCP-C100-RE\90E requires proper connection of the Ethernet
assembly interface (AIFX-RE) to the basic card!
Note: The device height and the power input of the netSCOPE data
aquistion card NSCP-C100-RE\90E do not comply with the standard
specifications.

Descriptions and Requirements 20/71
netSCOPE Data Acquisition Cards for Real-Time Ethernet | Installation, Operation and Hardware Description
DOC131006UM01EN | Revision 1 | English | 2013-11 | Released | Public © Hilscher, 2013
3.3 Recording and analyzing Data Traffic
For devices with EtherCAT communication the netSCOPE data aquistion
card captures the Ethernet frames, provides them with time stamps and
analyzes the recorded data.
So the netSCOPE data aquistion card must be connected over two
Ethernet connection cables from the netSCOPE data aquistion card TAP to
the Ethernet interface of the EtherCAT Master and to the Ethernet interface
of the Slave 1.
Master Slave 1
netSCOPE Card
TAP
Ethernet
Ethernet
Ethernet
Figure 1: Connection Schema - Capturing and analyzing the Communication between a
EtherCAT Master and the EtherCAT Slave 1
