Hilti SF 22-A User manual

SF 22A
SFH 22A
English
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

English 1
1 Information about the documentation
1.1 About this documentation
• Read this documentation before initial operation or use. This is a
prerequisite for safe, trouble-free handling and use of the product.
• Observe the safety instructions and warnings in this documentation and
on the product.
• Always keep the operating instructions with the product and make sure
that the operating instructions are with the product when it is given to
other persons.
1.2 Explanation of symbols used
1.2.1 Warnings
Warnings alert persons to hazards that may occur when handling or using the
product. The following signal words are used in combination with a symbol:
DANGER! Draws attention to an imminent hazard that will lead to
serious personal injury or fatality.
WARNING! Draws attention to a potential hazard that could lead to
serious personal injury or fatality.
CAUTION! Draws attention to a potentially dangerous situation that
could lead to minor personal injury or material damage.
1.2.2 Symbols in the documentation
The following symbols are used in this document:
Read the operating instructions before use
Instructions for use and other useful information
1.2.3 Symbols in the illustrations
The following symbols are used in illustrations:
These numbers refer to the corresponding illustrations found at the
beginning of these operating instructions.
The numbering reflects the sequence of operations shown in the
illustrations and may deviate from the steps described in the text.
Item reference numbers are used in the overview illustration and
refer to the numbers used in the key in the product overview sec-
tion.
This symbol is intended to draw special attention to certain points
when handling the product.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

2 English
1.3 Product-dependent symbols
1.3.1 Symbols on the product
The following symbols are used on the product:
Rated speed under no load
Revolutions per minute
Drilling without hammer action
Drilling with hammering action (hammer drilling)
1.4 Product information
Hilti products are designed for professional use and may be operated, ser-
viced and maintained only by trained, authorized personnel. This personnel
must be informed of any particular hazards that may be encountered. The
product and its ancillary equipment can present hazards if used incorrectly
by untrained personnel or if used not in accordance with the intended use.
The type designation and serial number are stated on the rating plate.
▶Write down the serial number in the table below. You will be required to
state the product details when contacting Hilti Service or your local Hilti
organization to inquire about the product.
Product information
Drill/driver SF 22-A | SFH 22-A
Generation: 01
Serial no.:
1.5 Declaration of conformity
We declare, on our sole responsibility, that the product described here
complies with the applicable directives and standards. A copy of the
declaration of conformity can be found at the end of this documentation.
The technical documentation is filed and stored here:
Hilti Entwicklungsgesellschaft mbH | Tool Certification | Hiltistrasse 6 | 86916
Kaufering, Germany
2 Safety
2.1 General power tool safety warnings
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
Work area safety
▶Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

English 3
▶Do not operate power tools in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
▶Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
▶Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric
shock.
▶Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
▶Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
▶Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
▶When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk
of electric shock.
▶If operating a power tool in a damp location is unavoidable, use
a residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
Personal safety
▶Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in serious personal
injury.
▶Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
▶Prevent unintentional starting. Ensure the switch is in the off‐position
before connecting to battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power
tools that have the switch on invites accidents.
▶Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
▶Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

4 English
▶Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
▶If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
Power tool use and care
▶Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
▶Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
▶Disconnect the battery pack from the power tool before making any
adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool
accidentally.
▶Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these instructions
to operate the power tool. Power tools are dangerous in the hands of
untrained users.
▶Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power
tools.
▶Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
▶Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and
the work to be performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
Battery tool use and care
▶Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of
fire when used with another battery pack.
▶Use power tools only with specifically designated battery packs. Use
of any other battery packs may create a risk of injury and fire.
▶When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a
fire.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

English 5
▶Under abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
Service
▶Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
2.2 Additional safety precautions for screwdrivers
Personal safety
▶Only use the product if it is in perfect working order.
▶Never tamper with or modify the tool in any way.
▶Use the auxiliary grip supplied with the tool. Loss of control can cause
personal injury.
▶Always hold the power tool with both hands on the grips provided. Keep
the grips clean and dry.
▶Hold the power tool by the insulated gripping surfaces when performing an
operation where the accessory tool may come into contact with concealed
wiring. If the accessory tool comes into contact with a live wire, metal
parts of the power tool may also become live, causing the operator to
receive an electric shock.
▶Avoid touching rotating parts – risk of injury!
▶Wear suitable protective glasses, a hard hat, ear protection, protective
gloves and light respiratory protection while using the tool.
▶Wear protective gloves also when changing the accessory tool. Touching
the accessory tool presents a risk of injury (cuts or burns).
▶Wear eye protection. Flying fragments present a risk of injury to the body
and eyes.
▶Before starting work, check the hazard class of the dust that will be pro-
duced when working. Use an industrial vacuum cleaner with an officially
approved protection class in compliance with the locally applicable dust
protection regulations. Dust from materials such as lead-based paint,
certain types of wood and concrete/masonry/stone containing quartz,
minerals or metal may be harmful to health.
▶Make sure that the working area is well ventilated and, where necessary,
wear a respirator appropriate for the type of dust generated. Contact with
or inhalation of dust may cause allergic reactions and/or respiratory
or other diseases to the operator or bystanders. Certain kinds of
dust, such as oak and beech dust, are classified as carcinogenic,
especially in conjunction with additives for treating wood (chromate,
wood preservative). Materials containing asbestos may only be handled
by specialists.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

6 English
▶Take breaks between working and do physical exercises to improve the
blood circulation in your fingers. Exposure to vibration during long periods
of work can lead to disorders of the blood vessels and nervous system in
the fingers, hands and wrists.
Electrical safety
▶Before starting work, check the working area for concealed electric cables
or gas and water pipes. If you damage an electric cable accidentally,
external metal parts of the power tool may become live and present a risk
of electric shock.
Careful handling and use of power tools
▶Switch the power tool off immediately if the accessory tool jams. The
power tool may go off course and veer to the side.
▶Wait until the power tool has come to a complete stop before setting it
down.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

English 7
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

8 English
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

English 9
3 Description
3.1 Overview of the product
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

10 English
@Side handle
;Keyless chuck
=Function setting ring
(screwdriving/drilling/hammer
drilling)
%Gear selector switch
&Forward/reverse selector
switch with safety lock
(Control switch (with electronic
speed control)
)Grip
+Release buttons with addi-
tional function (charge status
display activation)
§Rating plate
/Belt hook (optional)
:Charge state and fault display
(Li-ion battery)
3.2 Intended use
The product described is a hand-held cordless drill / driver. It is designed to
be used for driving and removing screws and for drilling in steel, wood and
plastic. The “'SFH” model is also suitable for hammer drilling in masonry.
▶Use only Hilti Li-ion batteries of the B22 series with this product.
▶Use only the Hilti battery chargers of the C4/36 series for these batteries.
3.3 Liion battery display
The charge status of the Li-ion battery and malfunctions of the power tool are
indicated by the display on the Liion battery. The charge status of the Liion
battery is displayed after pressing one of the two battery release buttons.
Status Meaning
4 LEDs light. • Charge status: 75 % to 100 %
3 LEDs light. • Charge status: 50 % to 75 %
2 LEDs light. • Charge status: 25 % to 50 %
1 LED lights. • Charge status: 10 % to 25 %
1 LED blinks, the power tool is
ready for use.
• Charge status: < 10 %
1 LED blinks, the power tool is not
ready for use.
• The battery has overheated or is
completely discharged.
4 LEDs blink, the power tool is not
ready for use.
• The power tool is overloaded or
has overheated.
Note
Battery charge status cannot be displayed while the control switch is
pressed and for up to 5 seconds after releasing the control switch.
If the battery display LEDs blink, please observe the instructions given
in the Troubleshooting section.
3.4 Items supplied
Drill / driver, side handle, operating instructions.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

English 11
• You can find other system products approved for use with your product
at your local Hilti Center or online at: www.hilti.group.
4 Drill/driver
SF 22-A SFH 22-A
Rated voltage 21.6 V 21.6 V
Weight in accordance with EPTA
procedure 01
2.52 kg 2.58 kg
Speed 1st gear •/• 0 /min …370 /min
2nd gear •/• 0 /min …1,250 /min
3rd gear •/• 0 /min …2,140 /min
Torque (soft joint) ≤ 50 Nm ≤ 50 Nm
Torque range (15 settings) 2 Nm …12 Nm 2 Nm …12 Nm
Ø drill bit (softwood) 1.5 mm …32 mm 1.5 mm …32 mm
Ø drill bit (hardwood) 1.5 mm …20 mm 1.5 mm …20 mm
Ø drill bit (metal) 1.5 mm …13 mm 1.5 mm …13 mm
4.1 Noise information and vibration values in accordance with
EN 60745
The sound pressure and vibration values given in these instructions have
been measured in accordance with a standardized test and may be used to
compare one power tool with another. They may be used for a preliminary
assessment of exposure.
The data given represents the main applications of the power tool. However,
if the power tool is used for different applications, with different accessory
tools or is poorly maintained, the data may vary. This may significantly
increase exposure over the total working period.
An accurate estimation of exposure should also take into account the times
when the power tool is switched off, or when it is running but not actually
being used for a job. This may significantly reduce exposure over the total
working period.
Identify additional safety measures to protect the operator from the effects
of noise and/or vibration, for example: Maintaining the power tool and
accessory tools, keeping the hands warm, organization of work patterns.
Noise emission values
SF 22-A SFH 22-A
Emission sound pressure level (LpA)75 dB(A) 96 dB(A)
Uncertainty for the sound pressure
level (KpA)
3 dB(A) 3 dB(A)
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

12 English
SF 22-A SFH 22-A
Sound (power) level (LWA)86 dB(A) 107 dB(A)
Uncertainty for the sound power level
(KWA)
3 dB(A) 3 dB(A)
Total vibration
SF 22-A SFH 22-A
Vibration emission value for screwdriv-
ing (ah)
< 2.5 m/s² < 2.5 m/s²
Uncertainty for screwdriving (K) 1.5 m/s² 1.5 m/s²
Drilling in metal (ah,D)< 2.5 m/s² < 2.5 m/s²
Uncertainty for drilling in metal (K) 1.5 m/s² 1.5 m/s²
5 Operation
5.1 Preparations at the workplace
CAUTION
Risk of injury! Inadvertent starting of the product.
▶Remove the battery before making any adjustments to the power tool
or before changing accessories.
Observe the safety instructions and warnings in this documentation and on
the product.
5.1.1 Inserting the battery
CAUTION
Risk of injury! Unexpected starting and/or short circuiting.
▶Before fitting the battery, check that the drill/driver is switched off
and that the switch safety lock is activated.
▶Make sure that the contacts on the battery and the contacts on the
drill / driver are free of foreign objects.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

English 13
▶Push the battery into the tool from the rear until it engages with an audible
click.
5.1.2 Removing the battery
▶Remove the battery.
5.1.3 Fitting and adjusting the side handle
▶Fit or adjust the side handle.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

14 English
5.1.4 Fitting the accessory tool
1. Set the forward/reverse switch to the middle position or remove the
battery from the power tool.
2. Check that the connection end of the accessory tool is clean. Clean the
connection end if necessary.
3. Open the keyless chuck.
4. Insert the accessory tool into the keyless chuck and then turn the chuck
firmly by hand until tight and several clicks are heard.
5. Check that the accessory tool is held securely.
5.1.5 Removing the accessory tool
1. Set the forward/reverse switch to the middle position or remove the
battery from the power tool.
2. Open the keyless chuck.
3. Pull the accessory tool out of the keyless chuck.
5.1.6 Fitting the belt hook (optional)
WARNING
Risk of injury. A falling power tool may present a risk of injury to
yourself and others.
▶Check that the belt hook is fitted securely before beginning work.
▶Fit the belt hook.
◁The belt hook allows the power tool to be attached close to the body
on a belt worn by the operator. The belt hook can be fitted to allow
attachment on the left or right side of the body.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

English 15
5.2 Types of work
Warning! Risk of damage!
▶Operation of the direction of rotation and/or function selector switch
while the tool is running may result in damage to the tool.
▶Do not operate this switch while the tool is running.
Observe the safety instructions and warnings in this documentation and on
the product.
5.2.1 Setting forward or reverse rotation
▶Set the forward/reverse switch to the desired direction of rotation.
◁An interlock prevents switching while the motor is running. In the middle
position the switch is locked (safety lock).
5.2.2 Selecting the gear
▶Select the gear.
5.2.3 Switching on
▶Press the control switch.
◁Speed can be controlled steplessly right up to maximum by varying
how far the control switch is pressed in.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

16 English
5.2.4 Switching off
▶Release the control switch.
5.2.5 Drilling
1. Set the function selector ring to the symbol.
2. Set the forward/reverse switch to the “forward” position.
5.2.6 Drilling with hammering action (hammer drilling)
1. Set the function selector ring to the symbol.
2. Set the forward/reverse switch to the “forward” position.
5.2.7 Screwdriving
1. Set the function selector ring to the required torque setting.
2. Set the forward/reverse switch to the desired direction of rotation.
6 Care and maintenance of cordless tools
WARNING
Risk of electric shock! Attempting care and maintenance with the
battery fitted in the tool can lead to severe injury and burns.
▶Always remove the battery before carrying out care and maintenance
tasks!
Care and maintenance of the tool
• Carefully remove stubborn dirt from the tool.
• Clean the air vents carefully with a dry brush.
• Use only a slightly damp cloth to clean the casing. Do not use cleaning
agents containing silicone as these may attack the plastic parts.
Care of the Liion batteries
• Keep the battery free from oil and grease.
• Use only a slightly damp cloth to clean the casing. Do not use cleaning
agents containing silicone as these may attack the plastic parts.
• Avoid ingress of moisture.
Maintenance
• Check all visible parts and controls for signs of damage at regular intervals
and make sure that they all function correctly.
• Do not operate the cordless tool if signs of damage are found or if parts
malfunction. Have the tool repaired by Hilti Service immediately.
• After cleaning and maintenance, fit all guards or protective devices and
check that they function correctly.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

English 17
7 Transport and storage
Transport
CAUTION
Inadvertent starting during transport. Uncontrolled starting during
transport may occur if the battery is fitted, thereby resulting in damage
to the tool.
▶Always remove the battery before transporting the tool.
▶Remove the battery.
▶Transport the tool and battery individually packaged.
▶Never transport batteries in bulk form (loose, unprotected).
▶Check tools and batteries for damage before use after long periods of
transport.
Storage
CAUTION
Inadvertent damage caused by defective battery. A leaking battery
may damage the tool.
▶Always remove the battery before storing the tool.
▶Store the tool and battery in a place that is as cool and dry as possible.
▶Never store batteries in direct sunlight, on heating units or behind a
window pane.
▶Store the tool and batteries in a place where they cannot be accessed by
children or unauthorized persons.
▶Check the tool and batteries for damage before use after long periods of
storage.
8 Troubleshooting
If the trouble you are experiencing is not listed in this table or you are unable
to remedy the problem by yourself, please contact Hilti Service.
8.1 Troubleshooting
Trouble or fault Possible cause Action to be taken
The power tool
doesn’t run.
The battery is not fully
inserted.
▶Push the battery in
until it engages with
an audible double
click.
Low battery. ▶Change the battery
and charge the empty
battery.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

18 English
Trouble or fault Possible cause Action to be taken
The power tool
doesn’t work and all
four LEDs blink.
The power tool has been
overloaded briefly.
▶Release the control
switch and then press
it again.
The overheating cut-out
has been activated.
▶Allow the power tool
to cool down. Clean
the air vents.
The power tool
doesn’t work and
one LED flashes.
Low battery. ▶Change the battery
and charge the empty
battery.
The battery is too hot or
too cold.
▶Bring the battery to
the recommended op-
erating temperature.
The on/off button
can’t be pressed, i.e.
the button is locked.
The forward/reverse
selector switch is in the
middle position.
▶Push the
forward/reverse
switch to the left or
right.
No hammering ac-
tion.
The operating mode is
not set correctly at the
selector ring.
▶Set the selector ring to
the “Hammer drilling”
position .
The battery runs
down more quickly
than usual.
Very low ambient tem-
perature.
▶Allow the battery to
warm up slowly to
room temperature.
The battery doesn’t
engage with an audi-
ble double click.
The retaining lugs on the
battery are dirty.
▶Clean the retaining
lugs and push the
battery in until it
engages. Contact
Hilti Service if the
problem persists.
The tool or battery
gets very hot.
The tool is overloaded
(application limits ex-
ceeded).
▶Pay attention to the
power and perfor-
mance rating of the
product before using
it, i.e check its suitabil-
ity for the job on hand.
See the “Technical
data” section.
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04
