ORIGINAL OPERATING INSTRUCTIONS
DD 500 - CA core drilling machine
It is essential that the operating instructions
are read before the machine is operated for
the first time.
Always keep these operating instructions to-
gether with the machine.
Ensure that the operating instructions are
with the machine when it is given to other
persons.
Contents Page
1 General information 2
2Description 3
3 Technical data 5
4 Safety instructions 6
5 Preparation for core drilling 9
6 The core drilling operation 12
7 Care and maintenance 15
8 Troubleshooting 15
9Disposal 17
10 Manufacturer’s warranty 17
1These numbers refer to the illustrations. You can
find the illustrations at the beginning of the operating
instructions.
In these operating instructions, the designation “the ma-
chine” always refers to the DD 500-CA diamond core
drilling machine.
Core drilling machine 1
@Control panel and display
;Carrying bar
=Type identification plate
%Grip protrusion
&Water drainage plug
(3-way valve
)Chuck
+Connector
§Supply cord guide
/Water connection
:Water flow regulator
·Supply cord
Control panel and display 2
@Gear selector
;Drilling performance indicator
=Temperature monitor / ground fault indicator
%“On” switch
&“Off” switch
(Rebar button (Iron Boost)
)Service indicator
Vacuum base plate (accessory) 3
@Vacuum release valve
;Vacuum hose connector
=Vacuum seal
%Pressure gauge
&Wheel assembly mounting point
(Leveling screws (4×)
DD‑HD 30 drill stand (accessory) 4
@End stop with rail end cap
;Leveling indicator (2×)
=Carriage
%Carrying grip (2×)
&Brace
(Leveling screw (3×)
)Wheel assembly mounting point
+Base plate
§Rail
/Carriage lock
:Eccentricpin(forsecuringthemachine)
·Hand wheel
$Anchor position
£Reduction gearing (1:3)
|Direct drive (1:1)
¡Type identification plate
QHole center indicator
Drill stand fastening set (accessory) 4
WClamping nut
EAnchor spindle
Water collection system (accessory) 4
RSeal
TWater collector
ZWater collector bracket
en
1
Printed: 12.11.2015 | Doc-Nr: PUB / 5236315 / 000 / 01
