Hilti TE 70-AVR User manual

TE 70-AVR
TE 70-ATC/AVR
TE 80-ATC/AVR
English
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

English 1
1 Information about the documentation
1.1 About this documentation
• Read this documentation before initial operation or use. This is a prerequisite for safe, trouble-free
handling and use of the product.
• Observe the safety instructions and warnings in this documentation and on the product.
• Always keep the operating instructions with the product and make sure that the operating instructions
are with the product when it is given to other persons.
1.2 Explanation of symbols used
1.2.1 Warnings
Warnings alert persons to hazards that may occur when handling or using the product. The following signal
words are used in combination with a symbol:
DANGER! Draws attention to an imminent hazard that will lead to serious personal injury or
fatality.
WARNING! Draws attention to a potential hazard that could lead to serious personal injury or
fatality.
CAUTION! Draws attention to a potentially dangerous situation that could lead to minor personal
injury or material damage.
1.2.2 Symbols in the documentation
The following symbols are used in this document:
Read the operating instructions before use
Instructions for use and other useful information
1.2.3 Symbols in the illustrations
The following symbols are used in illustrations:
These numbers refer to the corresponding illustrations found at the beginning of these operating
instructions.
The numbering reflects the sequence of operations shown in the illustrations and may deviate
from the steps described in the text.
Item reference numbers are used in the overview illustration and refer to the numbers used in
the key in the product overview section.
This symbol is intended to draw special attention to certain points when handling the product.
1.3 Product-dependent symbols
1.3.1 Symbols on the product
The following symbols are used on the product:
Drilling with hammering action (hammer drilling)
Chiseling
Chisel positioning
Protection class II (double-insulated)
Rated speed under no load
Revolutions per minute
Revolutions per minute
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

2 English
Diameter
Alternating current
1.4 Product information
Hilti products are designed for professional use and may be operated, serviced and maintained only by
trained, authorized personnel. This personnel must be informed of any particular hazards that may be
encountered. The product and its ancillary equipment can present hazards if used incorrectly by untrained
personnel or if used not in accordance with the intended use.
The type designation and serial number are stated on the rating plate.
▶Write down the serial number in the table below. You will be required to state the product details when
contacting Hilti Service or your local Hilti organization to inquire about the product.
Product information
Combihammer TE 70AVR | TE 70ATC/AVR | TE 80ATC/AVR
Generation 03
Serial no.
1.5 Declaration of conformity
We declare, on our sole responsibility, that the product described here complies with the applicable directives
and standards. A copy of the declaration of conformity can be found at the end of this documentation.
The technical documentation is filed and stored here:
Hilti Entwicklungsgesellschaft mbH | Tool Certification | Hiltistraße 6 | 86916 Kaufering, DE
2 Safety
2.1 General power tool safety warnings
WARNING
Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
▶Keep work area clean and well lit. Cluttered or dark areas invite accidents.
▶Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
▶Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
Electrical safety
▶Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
▶Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
▶Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
▶Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the
risk of electric shock.
▶When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
▶If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

English 3
Personal safety
▶Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
▶Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
▶Prevent unintentional starting. Ensure the switch is in the off‐position before connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on
the switch or energising power tools that have the switch on invites accidents.
▶Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
▶Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
▶Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
▶If devices are provided for the connection of dust extraction and collection facilities, ensure these
are connected and properly used. Use of dust collection can reduce dust-related hazards.
Power tool use and care
▶Do not force the power tool. Use the correct power tool for your application. The correct power tool will
do the job better and safer at the rate for which it was designed.
▶Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
▶Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
▶Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
▶Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
▶Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
▶Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
Service
▶Have your power tool serviced by a qualified repair person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained.
2.2 Hammer safety warnings
▶Wear ear protectors. Exposure to noise can cause hearing loss.
▶Use auxiliary handles, if supplied with the tool. Loss of control can cause personal injury.
▶Hold power tool by insulated gripping surfaces, when performing an operation where the cutting
accessory may contact hidden wiring or its own cord. Cutting accessory contacting a "live" wire may
make exposed metal parts of the power tool "live" and could give the operator an electric shock.
2.3 Additional safety instructions for rotary hammer
Personal safety
▶Use the product only when it is in technically faultless condition.
▶Never tamper with or modify the power tool in any way.
▶Use the auxiliary grips supplied with the tool. Loss of control can cause personal injury.
▶Apply appropriate safety measures at the opposite side of the workpiece in work that involves breaking
through. Parts breaking away could fall out and / or fall down causing injury to other persons.
▶Always hold the power tool with both hands on the grips provided. Keep the grips clean and dry.
▶Hold the power tool by the insulated gripping surfaces when performing work in which the accessory
tool might come into contact with concealed wiring. If the accessory tool comes into contact with a live
wire, metal parts of the power tool can also become live, resulting in an electric shock.
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

4 English
▶Avoid touching rotating parts – risk of injury!
▶Wear suitable protective glasses, a hard hat, ear defenders, protective gloves and light respiratory
protection while using the power tool.
▶Wear protective gloves also when changing the accessory tool. Touching the accessory tool presents a
risk of injury (cuts or burns).
▶Wear eye protection. Flying fragments present a risk of injury to the body and eyes.
▶Before starting work, check the hazard class of the dust that will be produced when working. Use
an industrial vacuum cleaner with an officially approved protection class in compliance with the locally
applicable dust protection regulations. Dust from materials such as lead-based paint, certain types of
wood and concrete/masonry/stone containing quartz, minerals or metal can be harmful to health.
▶Make sure that the workplace is well ventilated and, where necessary, wear a respirator appropriate for
the type of dust generated. Contact with or inhalation of the dust can cause allergic reactions and/or
respiratory or other diseases to the operator or bystanders. Certain kinds of dust such as oakwood
and beechwood dust are classified as carcinogenic, especially in conjunction with additives for wood
conditioning (chromate, wood preservative). Only specialists are permitted to handle material containing
asbestos.
▶Take breaks and do physical exercises to improve the blood circulation in your fingers. Exposure to
vibration during long periods of work can lead to disorders of the blood vessels and nervous system in
the fingers, hands and wrists.
Electrical safety
▶Before beginning work, check the working area for concealed electric cables, gas pipes and water
pipes. External metal parts of the power tool can become live, presenting a risk of electric shock, if you
accidentally damage an electric cable.
Power tool use and care
▶Immediately switch off the power tool if the accessory tool jams. The power tool might twist off-line.
▶Wait until the power tool stops completely before you lay it down.
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

English 5
3 Description
3.1 Product overview
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

6 English
@Dust shield
;Chuck
=Accessory tool release
%Function selector switch
&Control switch lock
(Control switch
)Grip
+Service indicator
§Indicator for half power (ATC version only)
/Button for half power (ATC version only)
:Supply cord
∙Side handle
3.2 Intended use
The product described is an electrically powered combihammer with pneumatic hammering mechanism. It
is designed for drilling in concrete, masonry, wood and metal. The product can also be used for light- to
medium-duty chiseling on masonry and surface finishing work on concrete.
Under certain conditions, the product is also suitable for stirring / mixing.
▶The tool may be operated only when connected to a power source providing a voltage and frequency in
compliance with the information given on the type identification plate.
3.3 Active Vibration Reduction (AVR)
The combihammer has an Active Vibration Reduction (AVR) system, which reduces vibration significantly.
3.4 Active Torque Control – ATC
TE 70-ATC/AVR
TE 80-ATC/AVR
In addition to the mechanical slip clutch, this product also features ATC.
ATC detects sudden, uncontrolled rotation of the power tool about its own axis and switches the tool off
immediately. This can happen, for example, if the accessory tool jams.
When ATC is activated the motor stops. Restart the power tool by releasing the control switch and then
pressing it again.
Note
Always choose a working position that allows your product to turn freely counterclockwise. If this
turning action is not possible, ATC cannot react.
3.5 Service indicator
The combihammer has a service indicator LED.
Status Meaning
The service indicator lights red. • End of service interval – servicing is due.
The service indicator blinks red. • Have the combihammer repaired by Hilti
Service.
3.6 Items supplied
Combihammer, side handle, operating instructions.
You can find other system products approved for your product at your local Hilti Center or online at:
www.hilti.com.
4 Technical data
4.1 Combihammer
Note
For details of the rated voltage, current, frequency and input power, please refer to the power tool’s
country-specific type identification plate.
If the tool is powered by a generator or transformer, the generator or transformer’s power output must
be at least twice the rated input power shown on the rating plate of the tool. The operating voltage of
the transformer or generator must always be within +5% and -15% of the rated voltage of the tool.
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

English 7
TE 70AVR TE 70-ATC/AVR TE 80-ATC/AVR
Weight in accordance
with EPTA
procedure 01
8.3 kg 9.5 kg 9.7 kg
Single impact energy in
accordance with EPTA
procedure 05/2009
11.5 J 11.5 J 11.5 J
Ø hammer drill bits 12 mm …45 mm 12 mm …45 mm 12 mm …45 mm
Ø drill bits for wood 10 mm …32 mm 10 mm …32 mm 10 mm …32 mm
Ø drill bits for metal 0 mm …20 mm 0 mm …20 mm 0 mm …20 mm
4.2 Noise and vibration values in accordance with EN 60745
The sound pressure and vibration values given in these instructions were measured in accordance with a
standardized test and can be used to compare one power tool with another. They can also be used for a
preliminary assessment of exposure.
The data given represents the main applications of the power tool. However, if the power tool is used for
different applications, with different accessory tools, or is poorly maintained, the data can vary. This can
significantly increase exposure over the total working period.
An accurate estimation of exposure should also take into account the times when the tool is switched off, or
when it is running but not actually being used for a job. This can significantly reduce exposure over the total
working period.
Identify additional safety measures to protect the operator from the effects of noise and/or vibration, for
example: Maintaining the power tool and accessory tools, keeping the hands warm, organization of work
patterns.
Noise emission values
TE 70AVR TE 70-ATC/AVR TE 80-ATC/AVR
Sound (power) level (LWA)113 dB(A) 113 dB(A) 113 dB(A)
Uncertainty for the sound power level
(KWA)
3 dB(A) 3 dB(A) 3 dB(A)
Emission sound pressure level (LpA)102 dB(A) 102 dB(A) 102 dB(A)
Uncertainty for the sound pressure level
(KpA)
3 dB(A) 3 dB(A) 3 dB(A)
Total vibration
TE 70AVR TE 70-ATC/AVR TE 80-ATC/AVR
Hammer drilling in concrete (ah, HD)10 m/s² 10 m/s² 7.5 m/s²
Chiseling (ah,Cheq)9 m/s² 9 m/s² 7 m/s²
Uncertainty (K) 1.5 m/s² 1.5 m/s² 1.5 m/s²
5 Operation
5.1 Fitting the side handle
CAUTION
Risk of injury! Loss of control over the combihammer.
▶Check that the side handle is fitted correctly and tightened securely. Check that the clamping
band is engaged in the groove provided on the tool.
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

8 English
▶Fit the side handle.
5.2 Fitting / removing the accessory tool
Note
The use of unsuitable grease may cause damage to the tool. Use only genuine Hilti grease.
Always check the accessory tool for damage and uneven wear before each use; replace if necessary.
▶Fit or remove the accessory tool, as applicable.
5.3 Drilling without hammering
Note
Drilling without hammering is possible when drill bits with a special connection end are used. Tools of
this kind are available from the Hilti tools range.
For example, when the keyless quick-release chuck is fitted, smooth-shank drill bits for wood or steel
can be used to drill without hammering.
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

English 9
▶Set the function selector switch to the “Hammer drilling” position .
5.4 Mixing
Note
Use the mixing paddle only with the quick-release chuck.
▶Set the function selector switch to the "Hammer drilling" position and insert the mixing paddle into
the quick-release chuck.
5.5 Setting the power level
TE 70-ATC/AVR
TE 80-ATC/AVR
Note
Power can be set only when the tool is switched on and ready for use.
To set the tool to half power, press the "half power" button. The power indicator lights up to indicate
reduced power. Press the "half power" button again to switch to full power. The power indicator goes
out.
Switching the combihammer off and then on again resets the tool to full power.
▶Set the power level.
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

10 English
5.6 Drilling with hammering action (hammer drilling)
▶Set the function selector switch to the “Hammer drilling” position .
5.7 Chisel positioning
CAUTION
Risk of injury! Loss of control over the chisel direction.
▶Do not operate the tool when the selector switch is set to “Chisel positioning”. Turn the function
selector switch until it engages in the “Chiseling” position.
Note
The chisel can be set to 24 different positions (in 15° increments). This ensures that flat chisels and
shaped chisels can always be set to the optimum working position.
▶Set the function selector switch to the “Chisel positioning” position .
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

English 11
5.8 Chiseling
▶Set the function selector switch to the “Chiseling” position .
5.9 Control switch lock
Note
When chiseling, the control switch can be locked in the “on” position.
▶Press the control switch lock.
6 Care and maintenance
WARNING
Danger of electric shock! Carrying out care and maintenance while the supply cord is connected to
the power outlet presents a risk of serious injuries including burns.
▶Always unplug the supply cord before carrying out all care and maintenance tasks.
Care
• Carefully remove stubborn dirt from the tool.
• Clean the air vents carefully with a dry brush.
• Use only a slightly damp cloth to clean the casing. Do not use cleaning agents containing silicone as
they can attack the plastic parts.
Maintenance
WARNING
Danger of electric shock! Improper repairs to electrical components may lead to serious injuries
including burns.
▶Repairs to the electrical section of the tool or appliance may be carried out only by trained electrical
specialists.
• At regular intervals, check all visible parts and the controls for signs of damage and make sure that they
all function correctly.
• Do not operate the power tool if signs of damage are found or if parts malfunction. Have damage repaired
immediately by Hilti Service.
• After cleaning and maintenance, refit all guards or protective devices and check that they function
correctly.
Note
To help ensure safe and reliable operation, use only genuine Hilti spare parts and consumables. Spare
parts, consumables and accessories approved by Hilti for use with the product can be found at your
local Hilti Center or online at: www.hilti.com
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

12 English
7 Transport and storage
• Do not transport electric tools with accessory tools fitted.
• Always unplug the supply cord before storing an electric tool or appliance.
• Store tools and appliances in a dry place where they cannot be accessed by children or unauthorized
persons.
• Check electric tools or appliances for damage after long periods of transport or storage.
8 Troubleshooting
If the trouble you are experiencing is not listed in this table or you are unable to remedy the problem by
yourself, please contact Hilti Service.
8.1 Troubleshooting
Trouble or fault Possible cause Action to be taken
Combihammer does not start. Interruption in the electric supply. ▶Plug in another electric tool or
appliance and check whether it
works.
The generator is in sleep mode. ▶Apply a load to the generator
by connecting a second power
consumer (e.g. worklight).
Switch the tool off and then on
again.
The electronic restart interlock is
activated after an interruption in
the electric supply.
▶Switch the power tool off and
then on again.
The carbon brushes are worn. ▶Have checked, and if necessary
replaced, by a trained electrical
specialist.
No hammering action. The power tool is too cold. ▶Bring the tip of the accessory
tool into contact with the
working surface, switch the
power tool on and allow it to
run. If necessary, repeat the
procedure until the hammering
mechanism begins to operate.
Combihammer does not
achieve full power.
The extension cord is too long or
the conductor cross-section is
inadequate.
▶Use an extension cord of an
approved length and / or of
adequate conductor cross-
section.
The control switch is not fully
pressed.
▶Press the control switch as far
as it will go.
The voltage provided by the elec-
tric supply is too low.
▶Connect the power tool to a
different power source.
TE 70-ATC/AVR
TE 80-ATC/AVR
The half-power button is engaged.
▶Press the "half-power" button.
Drill bit does not rotate. The function selector switch is not
engaged or is in the "Chiseling"
position or the "Chisel position-
ing" position .
▶With the motor at a standstill,
set the function selector switch
to the “Hammer drilling”
position.
Drill bit is not released. The chuck is not pulled back fully. ▶Pull the chuck back as far
as it will go and remove the
accessory tool.
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

English 13
Trouble or fault Possible cause Action to be taken
Drill bit is not released. The side handle is not fitted cor-
rectly.
▶Disengage the side handle and
refit it correctly so that the
clamping band and side handle
engage in the recess.
The service indicator blinks
red.
A fault has occurred in the tool. ▶Have the product repaired by
Hilti Service.
The service indicator lights
red.
The carbon brushes are worn. ▶Have checked, and if necessary
replaced, by a trained electrical
specialist.
9 Disposal
Most of the materials from which Hilti tools and appliances are manufactured can be recycled. The
materials must be correctly separated before they can be recycled. In many countries, your old tools,
machines or appliances can be returned to Hilti for recycling. Ask Hilti Service or your Hilti representative
for further information.
▶Disposal of electric tools or appliances together with household waste is not permissible.
10 Manufacturer’s warranty
▶Please contact your local Hilti representative if you have questions about the warranty conditions.
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

14 English
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03

Hilti = registered trademark of Hilti Corp., Schaan
**
20161128
Printed: 02.02.2017 | Doc-Nr: PUB / 5150803 / 000 / 03
