Hioki Z3230 User manual
無線 LANアダプタ
WIRELESS LAN ADAPTER
取扱説明書 / Instruction Manual
Oct. 2020 Revised edition 2
Z3230A960-02 20-10H
Z3230
JA/EN
HIOKI Z3230 LAN
Z3230 LR8450-01
LR8450-01
PDF
Introduction
Thank you very much for choosing the Hioki Z3230
Wireless LAN Adapter. The Z3230 is attachable to
wireless modules dedicated to the LR8450-01 Memory
HiLogger. For instructions about how to attach the
Z3230, see the Instruction Manual included with each
wireless module.
For more information, such as operating precautions
and specications, see the Quick Start Manual and
Instruction Manual (PDF) included with the LR8450-01.
/ Supported Models
Z3230
The Z3230 is attachable to the following models:
LR8530
Wireless Voltage/Temp Unit
LR8531
Wireless Universal Unit
LR8532
Wireless Voltage/Temp Unit
LR8533
Wireless High Speed Voltage Unit
LR8534
Wireless Strain Unit
/ Package Contents
Z3230 LAN
Z3230 Wireless LAN Adapter 1
Instruction Manual (this manual) 1
Precautions Concerning Use of Equipment that
Emits Radio Waves
LAN
Because the instrument incorporates the wireless LAN
technology, the instrument emits radio radiation. Use of
devices that emit radio radiation requires approval in the
country of use, and use of the instrument in a country or
region other than in the following wireless certication
list may be subject to penalty as a violation of law.
For the latest list of the usable countries, please visit our
website.
/ Wireless certication
Japan Contains
211-160604
United States Contains
FCC ID: YOPGS2200M
Canada Contains
IC: 9154A-GS2200M
European Union
and Others
EN 300 328
EN 301 489-1
EN 301 489-17
Korea R-R-HKo-Z3230
R-C-tWs-GS2200MIZ
Singapore N2589-20 (LR8530 c/w Z3230)
N2744-20 (LR8531 c/w Z3230)
N2745-20 (LR8532 c/w Z3230)
N2746-20 (LR8533 c/w Z3230)
N2748-20 (LR8534 c/w Z3230)
Thailand NTC TS 1035-2562
China CMIIT ID: 2020DJ8224
Taiwan Contains
NCC ID: CCAK20LP1710T8
Chile N°
15262 / DO N° 71426 / F23
HIOKI Z3230A960-02
Caution for use in the United States
Products not bearing the mark that begins with “Con-
tains FCC ID” cannot be used.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause un-
desired operation.
FCC CAUTION
Changes or modications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
The transmitter module must not be co-located or
operating in conjunction with any other antenna or
transmitter.
This equipment complies with FCC radiation expo-
sure limits set forth for an uncontrolled environment
and meets the FCC radio frequency (RF) Exposure
Guidelines. This equipment should be installed and
operated keeping the radiator at least 20cm or more
away from person’s body.
Caution for use in Canada
Products not bearing the mark that begins with “Con-
tains IC” cannot be used.
This device contains licence-exempt transmitter(s)/
receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt
RSS(s). Operation is subject to the following two con-
ditions:
1. This device may not cause interference.
2. This device must accept any interference, includ-
ing interference that may cause undesired opera-
tion of the device.
This equipment complies with ISED radiation expo-
sure limits set forth for an uncontrolled environment
and meets RSS-102 of the ISED radio frequency (RF)
Exposure rules. This equipment should be installed
and operated keeping the radiator at least 20cm or
more away from person’s body.
L’émetteur/récepteur exempt de licence contenu
dans le présent appareil est conforme aux CNR d’In-
novation, Sciences et Développement économique
Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux condi-
tions suivantes :
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélec-
trique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.
Cet équipement est conforme aux limites d’exposition
aux rayonnements énoncées pour un environnement
non contrôlé et respecte les règles d’exposition aux
fréquences radioélectriques (RF) CNR-102 de l’ISDE.
Cet équipement doit être installé et utilisé en gardant
une distance de 20 cm ou plus entre le radiateur et le
corps humain.
Certication in Thailand
This telecommunication equipment conforms to the
technical standards or requirements of NBTC.
Certication in Singapore
Complies with
IMDA Standards
DA106438
한국에서의 사용에 대한 주의사항
국가통합인증마크(KC마크)가 없는 제품은 사용할 수 없습니
다.
사용자 안내문
이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은
기기로서 가정용 환경에서 사용하는 경우 전파간섭의 우려가 있
습니다.
"CMIIT ID"
1.
•2.4 - 2.4835 GHz
•(EIRP)
<10 dBi≤100 mW ≤20 dBm
•
<10 dBi≤10 dBm / MHz (EIRP)
•20 ppm
•(2.4 - 2.4835 GHz)
≤-80 dBm / Hz (EIRP)
•( ) (2.5 )
≤-36 dBm / 100 kHz (30 - 1000 MHz)
≤-33 dBm / 100 kHz (2.4 - 2.4835 GHz)
≤-40 dBm / 1 MHz (3.4 - 3.53 GHz)
≤-40 dBm / 1 MHz (5.725 - 5.85 GHz)
≤-30 dBm / 1 MHz (1 - 12.75 GHz)
2.
(
)
3.
4.
5.
NCC
•
•
電
HIOKI Z3230A960-02
