Hioki 8910 User manual

8910
Instruction Manual
CAN ADAPTER
EN
Aug. 2018 Revised edition 7
8910A981-07 18-08H

Contents
i
Contents
Introduction.................................................................................1
Inspection...................................................................................1
Safety Notes...............................................................................4
Notes on Use..............................................................................7
Chapter 1
Product Overview __________________________ 11
1.1 Overview .....................................................................11
1.2 Major Features............................................................12
1.3 Identification of Controls and Indicators......................13
Chapter 2
Preparation________________________________ 15
2.1 Installation of the Instrument.......................................15
2.2 Power Supply Connections.........................................16
2.2.1 Connecting the AC adapter ...........................................16
2.2.2 Connecting the DC Power Supply .................................17
2.3 Connection Procedure ................................................18
2.4 Power On/Off ..............................................................21
Chapter 3
Operation _________________________________ 23
3.1 Modes .........................................................................23
3.2 Conversion Mode........................................................23
3.3 Setting Mode...............................................................24
3.3.1 Activating setting mode .................................................25
3.3.2 Contents of display in setting mode ..............................26
3.3.3 Selecting a channel number ..........................................26
3.3.4 Selecting the CAN definition data to be output ..............27
3.3.5 Setting the D/A conversion format/logic bit position ......28
3.3.6 Returning to conversion mode ......................................29
3.4 Calibration Mode.........................................................30
3.4.1 Activating calibration mode ...........................................30
3.4.2 Selecting a channel number ..........................................31
3.4.3 Outputting a calibration signal .......................................31
3.4.4 Returning to conversion mode ......................................32
3.5 Operation Map ............................................................33
8910A981-07

Contents
ii
Chapter 4
Preparation of the CAN Set Program ___________37
4.1 Overview..................................................................... 37
4.2 Program Setup ........................................................... 38
4.2.1 System requirements ....................................................38
4.2.2 Installation .....................................................................38
4.2.3 Un-Installation ...............................................................39
Chapter 5
Starting the CAN Set Program ________________41
5.1 Connecting the PC to the 8910 .................................. 41
5.2 Starting Up the Condition Setting Program ................ 42
5.3 Menu Items in the Setting Window............................. 45
5.4 Operation Flowchart................................................... 46
Chapter 6
Setting the CAN Definition Data _______________49
6.1 Opening a CAN definition data file ............................. 49
6.1.1 Opening a CAN definition data file ................................49
6.1.2 Creating a new CAN definition data file ........................50
6.2 Editing the CAN Definition Data ................................. 52
6.2.1 Setting the message ID ................................................53
6.2.2 Setting the data length ..................................................53
6.2.3 Setting the data start position .......................................54
6.2.4 Setting the data pattern ................................................55
6.2.5 Setting the sign .............................................................56
6.2.6 Setting the signal name ................................................57
6.2.7 Setting the label name ..................................................57
6.2.8 Setting the unit ..............................................................57
6.2.9 Setting the scaling ........................................................58
6.2.10 Error Massage ..............................................................60
6.3 Deletion of CAN Definition Data................................. 61
6.4 Closing the CAN Definition Data File
(Saving the File) ......................................................... 62
6.5 CAN Definition Data List Detail Display...................... 63
6.6 Editing in Another Window ......................................... 65
6.6.1 Opening a new window .................................................65
6.6.2 Creating a new CAN definition data file ........................69
6.6.3 Opening a CAN definition data file ................................69
6.6.4 Editing CAN definition data ...........................................69
6.6.5 Saving CAN definition data ...........................................69

Contents
iii
Chapter 7
Settings___________________________________ 71
7.1 Registration List Operations........................................71
7.1.1 Opening a registration list ..............................................71
7.1.2 Creating a registration list (registering definition data
to a registration list) .......................................................72
7.1.3 Deleting data from the registration list ...........................74
7.2 Allocation to Output Channels.....................................75
7.2.1 Setting analog output channels .....................................75
7.2.2 Deleting registered data from the analog output
allocation list ..................................................................76
7.2.3 Setting logic output channels ........................................77
7.2.4 Deleting data from the logic output allocation list ..........78
7.3 Massage ID Trigger.....................................................79
7.3.1 Setting the message ID trigger ......................................79
7.3.2 Setting output channels .................................................80
7.4 Setting the ID Filter .....................................................81
Chapter 8
Transfer of Setting Data to the 8910 ___________ 83
8.1 Setting Communication Parameters ...........................83
8.2 Executing Data Transfer .............................................84
8.3 In Case of Errors.........................................................85
8.4 Duplicate Bit Check.....................................................86
Chapter 9
Functions of the Setting Program _____________ 87
9.1 Saving the Setting Data ..............................................87
9.1.1 Saving data with a new name .......................................87
9.1.2 Overwriting ....................................................................88
9.2 Setting Data Printout...................................................89
9.2.1 Printing ..........................................................................89
9.2.2 Print preview .................................................................89
9.2.3 Setting the printer ..........................................................90
9.2.4 Examples of printouts ....................................................90
9.3 Displaying Windows....................................................92
9.4 Password Setting ........................................................93
9.5 Version Check.............................................................94

Contents
iv
Chapter 10
Connection to Memory HiCorder ______________95
10.1 Using the 8910 with the 8826 MEMORY HiCORDER 96
10.1.1 Displaying the 8910 setting screen ...............................96
10.1.2 8910 setting screen ......................................................98
10.1.3 Setting the block no. .....................................................99
10.1.4 Setting analog channel output ....................................100
10.1.5 Setting logic channel output ........................................102
10.1.6 Displaying the registration list .....................................103
10.1.7 Communication between the 8826 and 8910 .............104
10.1.8 Downloading an setting data file .................................107
10.2 Using the 8910 with the 8841, 8842 MEMORY
HiCORDER............................................................... 109
10.2.1 Displaying the 8910 setting screen .............................109
10.2.2 8910 setting screen ....................................................111
10.2.3 Setting the block no. ...................................................112
10.2.4 Setting analog channel output ....................................113
10.2.5 Setting logic channel output ........................................115
10.2.6 Displaying the registration list .....................................116
10.2.7 Communication between the 8841, 8842 and 8910 ...117
10.2.8 Downloading a setting data file ...................................120
Chapter 11
Specifications_____________________________123
11.1 General Specifications.............................................. 123
11.2 Specifications of Functions....................................... 125
11.3 Specifications of 8910 CAN Set Program
(PC Application)........................................................ 126
11.4 Specifications of CAN Setting Function
(for Memory HiCorder).............................................. 127
11.5 Accessories.............................................................. 128
11.6 Options..................................................................... 128
11.6.1 9713-01 CAN CABLE (one end unprocessed) ...........129
11.6.2 9713-02 CAN CABLE (For automotive connector) .....130
11.6.3 9714-01 LOGIC CABLE (one end unprocessed) ........131
11.6.4 9714-02 LOGIC CABLE (for Memory HiCorder) .........132
11.7 Specifications of Connectors.................................... 133

Contents
v
Chapter 12
Maintenance and Service ___________________ 135
12.1 Service and Cleaning................................................135
12.2 Troubleshooting ........................................................135

Contents
vi

1
Introduction
Introduction
Thank you for purchasing the HIOKI “Model 8910 CAN ADAPTER”. To
obtain maximum performance from the instrument, please read this
manual first, and keep it handy for future reference.
Inspection
When you receive the instrument, inspect it carefully to ensure that no
damage occurred during shipping. In particular, check the
accessories, panel switches, and connectors. If damage is evident, or
if it fails to operate according to the specifications, contact your dealer
or Hioki representative.
Accessories
Instruction manual.....................................1
CD-R ("8910 CAN set program" software
(Japanese/English 2 files) (for PC), CAN
setting function (for Memory HiCorder)).... 1
RS-232C cable (D-sub 9-pin, male-female,
straight cable) (Approx. 1.8 m).................. 1
9418-15 AC ADAPTER ............................ 1

Inspection
2
Options
Power cord ................................................1
9713-01 CAN CABLE (one end
unprocessed) (Approx. 2 m)......................1
9713-01 CAN CABLE (one end unprocessed) (Approx. 2 m)
9713-02 CAN CABLE (For automotive connector) (Approx. 2 m)
(Since this part is made to order, check the specifications document
and delivery date.)
9714-01 LOGIC CABLE (one end unprocessed) (Approx. 1.5 m)
9714-02 LOGIC CABLE (for Memory HiCorder) (Approx. 1.5 m)
9165 CONNECTION CORD (Metal BNC - Metal BNC) (Approx. 1.5 m)
L9217 CONNECTION CORD (Metal BNC - Insulated BNC)
(Insulated BNC for Memory HiCorder) (Approx. 1.7 m)

3
Inspection
Preliminary Checks
Before using the instrument the first time, verify that it operates
normally to ensure that the no damage occurred during storage or
shipping. If you find any damage, contact your dealer or Hioki
representative.
9557 RS-232C CARD (for Memory HiCorder)
Before using the instrument, make sure that the insulation on the
cords and cables are undamaged and that no bare conductors
are improperly exposed. Using the product in such conditions
could cause an electric shock, so contact your dealer or Hioki
representative for repair.

Safety Notes
4
Safety Notes
This manual contains information and warnings essential for safe
operation of the instrument and for maintaining it in safe operating
condition. Before using it, be sure to carefully read the following safety
precautions.
Safety symbols
The following symbols in this manual indicate the relative importance
of cautions and warnings.
This instrument is designed to comply with IEC 61010 Safety
Standards, and has been thoroughly tested for safety prior to
shipment. However, mishandling during use could result in injury
or death, as well as damage to the instrument. Be certain that you
understand the instructions and precautions in the manual
before use. We disclaim any responsibility for accidents or
injuries not resulting directly from instrument defects.
In the manual, the symbol indicates particularly
important information that the user should read before
using the instrument.
Indicates AC (Alternating Current).
Indicates DC (Direct Current).
Indicates the OFF side of the power switch.
Indicates the ON side of the power switch.
Indicates that incorrect operation presents an
extreme hazard that could result in serious injury
or death to the user.
Indicates that incorrect operation presents a
significant hazard that could result in serious
injury or death to the user.
Indicates that incorrect operation presents a
possibility of injury to the user or damage to the
instrument.
Indicates advisory items related to performance
or correct operation of the instrument.

5
Safety Notes
Mouse Operation
Indications • Unless otherwise specified, “Windows” represents Windows 95, 98,
Me, Windows NT4.0, Windows 2000, or Windows XP.
• Dialogue box represents a Windows dialog box.
• Menus, commands, dialogs, buttons in a dialog, and other names
on the screen and the keys are indicated in brackets.
Click : Press and quickly release the left button of the mouse.
Right-click : Press and quickly release the right button of the
mouse.
Double click : Quickly click the left button of the mouse twice.
Drag : While holding down the left button of the mouse, move
the mouse and then release the left button to deposit
the chosen item in the desired position.
Activate : Click on a window on the screen to activate that
window.

Safety Notes
6
Measurement categories
To ensure safe operation of measurement instruments, IEC 61010
establishes safety standards for various electrical environments,
categorized as CAT II to CAT IV, and called measurement categories.
These are defined as follows.
CAT II : Primary electrical circuits in equipment connected to an AC
electrical outlet by a power cord (portable tools, household
appliances, etc.)
CAT II covers directly measuring electrical outlet receptacles.
CAT III : Primary electrical circuits of heavy equipment (fixed
installations) connected directly to the distribution panel, and
feeders from the distribution panel to outlets.
CAT IV: The circuit from the service drop to the service entrance, and
to the power meter and primary overcurrent protection device
(distribution panel).
Using a measurement instrument in an environment designated with a
higher-numbered category than that for which the instrument is rated
could result in a severe accident, and must be carefully avoided.
Use of a measurement instrument that is not CAT-rated in CAT II to
CAT IV measurement applications could result in a severe accident,
and must be carefully avoided.

7
Notes on Use
Notes on Use
Follow these precautions to ensure safe operation and to obtain the
full benefits of the various functions.
Connecting the Cables (RS-232C Cable, CAN Cable,
Connection Cord [Analog], Logic Cable)
The ground (GND) conductors of the connecting cables*connect
in common to the Model 8910 chassis ground (they are not
isolated). Care is therefore necessary to ensure that there is no
potential difference between the instrument chassis ground and
the ground of any connecting device. Otherwise, the instrument
or connecting device could be damaged. Refer to “Power
Sources” below.
Power Sources
The ground (GND) conductors of connecting cables*connect in
common to the Model 8910 chassis ground (they are not
isolated). Therefore, supplying power from different sources to
the instrument and a connecting device could cause electric
shock and equipment damage. To avoid these hazards, power
should always be supplied from the same source.
Even when power is supplied from the same source, as a result
of wiring, potential difference between grounds can result in
current flow through the connecting cables* that could damage
the equipment.
To avoid such hazards, we recommend observing the following
precautions for power connections:
(1) When powering the 8910 from the supplied AC adapter,
before connecting devices to the 8910, plug the (supplied)
grounded power cord of the AC adapter into the same outlet
as that used to power the devices to be connected.
❖2.2.1 Connecting the AC adapter (Page 16) and
2.3 Connection Procedure (Page 18)
(2) When powering the 8910 from a DC power source, before
making other connections, first connect the ground of the
8910 to the grounds of the devices to be connected. In this
case, always use the same power source.
❖2.2.2 Connecting the DC Power Supply (Page 17) and
2.3 Connection Procedure (Page 18)
(3) When powering the 8910 from the supplied AC adapter and
powering connecting devices from a DC source (or when
powering the 8910 from DC and connecting devices from
AC), before making other connections to the 8910, first
connect the ground of the 8910 to the grounds of the
devices to be connected. Refer to the following alternatives
regarding common ground connection methods.
(a) Connect the grounds of devices running on DC power to
the AC adapter’s ground.
(b) Connect pin 3 (CAN_GND) of the 9713-01 CAN Cable to
the ground of the device to be connected.
*Connecting cables: Cables and connection cords being connected to the 8910.

Notes on Use
8
Note: In method (b) above, because of wire length and CAN cable
wiring conditions, some potential difference may remain
between grounding points, so we recommend (a) as the
preferred method.
❖2.2.1 Connecting the AC adapter (Page 16),
2.2.2 Connecting the DC Power Supply (Page 17) and
2.3 Connection Procedure (Page 18)
Power Supply Connections
Before turning the instrument on, make sure the supply voltage
matches that indicated on the its power connector. Connection to
an improper supply voltage may damage the instrument and
present an electrical hazard.
Grounding the Instrument
To avoid electrical accidents and to maintain the safety
specifications of this instrument, connect the power cord
provided only to a 3-contact (two-conductor + ground) outlet.
❖2.2 Power Supply Connections (Page 16)
Before Powering on
Check the power supply is correct for the rating of the unit.
Usage Precautions for the CD-R
• Always hold the disc by the edges, so as not to make fingerprints on
the disc or scratch the printing.
• Never touch the recorded side of the disc. Do not place the disc
directly on anything hard.
• Do not wet the disc with volatile alcohol or water, as there is a
possibility of the label printing disappearing.
• To write on the disc label surface, use a spirit-based felt pen. Do not
use a ball-point pen or hard-tipped pen, because there is a danger of
scratching the surface and corrupting the data. Do not use adhesive
labels.
• Do not expose the disc directly to the sun's rays, or keep it in
conditions of high temperature or humidity, as there is a danger of
warping, with consequent loss of data.
• To remove dirt, dust, or fingerprints from the disc, wipe with a dry
cloth, or use a CD cleaner. Always wipe radially from the inside to
the outside, and do no wipe with circular movements. Never use
abrasives or solvent cleaners.
• Hioki shall not be held liable for any problems with a computer
system that arises from the use of this CD-R, or for any problem
related to the purchase of a Hioki product.

9
Notes on Use
Installation Environment
• Do not use the instrument where it may be exposed to corrosive or
combustible gases. The instrument may be damaged.
• The instrument should be installed and operated indoors only,
between -10 and 55°C and 30 to 80% RH.
• Do not store or use the instrument where it could be exposed to
direct sunlight, high temperature or humidity, or condensation. Under
such conditions, the instrument may be damaged and insulation may
deteriorate so that it no longer meets specifications.
Others
• To prevent an electric shock accident, confirm that the white or red
portion (insulation layer) inside the cable is not exposed. If a color
inside the cable is exposed, do not use the cable.
• Carefully read and observe all precautions in this manual.
• Using an connection cord other than that specified by HIOKI may
damage the BNC connector or result in measurement errors due to
contact failure.
• Even when using the 8910 within the permitted operating temperature
(-10 to 55°C) and humidity ranges, display on the LCD may become
difficult to read at very low or high ambient temperatures. (In such case,
alter the viewing angle.) Note that this change does not affect instrument
operation.
•This
instrument may cause interference if used in residential areas.
Such use must be avoided unless the user takes special measures to
reduce electromagnetic emissions to prevent interference to the
reception of radio and television broadcasts.

Notes on Use
10

11
1.1 Overview
• 8910 CAN ADAPTER is a signal converter that acquires necessary
signals from CAN signals flowing on a CAN bus, converts the
signals to analog or logic signals, then generates output.
• The type of data to be acquired is set by using a PC, with settings
transferred and saved in internal memory of the 8910 via the RS-
232C.
• Internal memory can store up to 50 items of CAN definition data.
Since you can change allocated output channels by using the LCD
and operation keys on the front panel, the instrument can be used in
various applications without a PC.
Product
Overview Chapter 1
1.1 Overview

1.2 Major Features
12
1. Compact size and lightweight
The main unit is compact and lightweight for easy portability.
2. Ample output channels
The 8910 is equipped with ample output channels - 12 channels for
analog signal output and 24 bits for logic signal output.
3. Two independent input ports
Since CAN1 and CAN2 are independent, two networks with different
baud rates can be connected.
4. Automatic baud rate setting
Because the 8910 monitors the CAN bus and automatically sets the
baud rate, there is no need to manually set the baud rate. (Supported
baud rates are 125 kbps, 250 kbps, 500 kbps, and 1 Mbps.)
5. Detailed settings using a PC
Easy-to-use PC application software enables the detailed settings of
data to be acquired from a CAN bus.
6. Observation with your existing recorder
The output signal level ranges from -5 to +5 V, and the value is held
until subsequent signal output. Therefore, output from the 8910 can be
connected to an ordinary recorder. Thus, you can observe CAN
signals by connecting the 8910 to your existing recorder.
7. Real-time output
CAN signals are converted into analog/logic signals and output in real
time.
8. Mixed recording
By using the 8910 with a recorder such as the Memory HiCorder,
"sensor data or control signal on CAN" and "signal that cannot be
acquired on CAN" can be recorded together.
1.2 Major Features
