Hioki SW9001 User manual

SW1001
SW1002
Instruction Manual
SWITCH MAINFRAME
EN
Jan. 2022 Revised edition 4
SW1001A961-04 22-01H
Read carefully before use.
Keep for future reference.
When using the instrument for the
rst time Troubleshooting
Safety Information p.4 Maintenance and Service p.125
Measurement Flowchart p.12 Error display and troubleshooting
p.126
Preparation for Measurements p.13
*600510224*
www.hioki.com/
HIOKI SW1001A961-04

HIOKI SW1001A961-04

i
4 Scan Function 39
4.1 Overview of the Scan Function ..........39
4.2 Setting the Scan Channel ...................40
4.3 Setting the Trigger Source for
Scan Operation.....................................40
4.4 Scan Operation.....................................41
4.5 Resetting Scan Operation ...................42
4.6 Scan Measurement Example .............43
5 Other Functions 45
5.1 Checking the Device Status................45
6 Initialization 47
6.1 Initialization Settings ............................47
7 External Control
(EXT. I/O) 49
7.1 External Control Flow ..........................49
7.2 Switching between Sinking Current
(NPN) and Sourcing Current (PNP)...50
7.3 Connection ............................................51
Device connector and compatible
connectors................................................51
Signal Functions .......................................52
Connection to the instrument.....................52
7.4 Timing Chart..........................................53
Channel switching operation and scan
operation reset..........................................53
7.5 InternalCircuitConguration ..............55
Electricalspecications .............................56
Connection examples ...............................57
8 Communication
Function 59
8.1 Interface Overview and Features.......59
8.2 Setting the Communication Setting
Mode ......................................................59
8.3 LAN Interface ........................................60
Communication condition settings .............61
Setting LAN communications ....................62
Connecting the LAN cable.........................63
8.4 USB Interface........................................64
Installing the USB driver............................64
Connecting the USB cable ........................65
Contents
Introduction........................................................1
ConrmingPackageContents........................2
Safety Information ............................................4
Usage Notes......................................................4
1 Overview 7
1.1 Overview of Product...............................7
1.2 Features...................................................7
1.3 Parts Names and Functions .................8
1.4 Block Diagram.......................................10
1.5 Glossary.................................................11
1.6 Measurement Flowchart......................12
2 Preparation for
Measurements 13
2.1 Connecting Instruments and
Controlling the Device..........................13
2.2 Installing the Module ............................15
2.3 Removing the Module..........................16
2.4 Connecting the Measurement Cable.18
2.5 Connecting the Connection Cable .....19
TERMINAL 1 ............................................20
TERMINAL 2 ............................................20
TERMINAL 3 ............................................21
2.6 Setting the Communication Setting
Mode ......................................................22
2.7 Connecting the Power Cord................23
2.8 Turning on/off the Power .....................23
2.9 When the Power is Turned on ............24
3 Channel Switching 25
3.1 Inspection before Measurement.........25
Inspecting the device and peripheral
devices.....................................................25
Checking for relay contact welding ............26
3.2 Overview of Channel Switching..........27
3.3 Procedure for Switching the Channel28
Selecting the connection method...............28
Switching the shield ..................................29
Selecting the channel................................30
3.4 Channel Switching Operation .............31
3.5 Measurement between Two
Instruments............................................32
3.6 Precautions for Measurement ............35
3.7 Channel Delay Function ......................37
SW1001A961-04
10
9
8
7
6
5
4
3
2
1
Index
HIOKI SW1001A961-04

Contents
ii
11 Multiplexer Module 129
11.1 SW9001 Multiplexer Module
(2-wire/4-wire) .....................................129
Features.................................................129
Specications .........................................129
Switching wiring diagram.........................133
Connector wiring diagram .......................134
Acquiring the relay opening/closing
frequency ...............................................136
11.2 SW9002 Multiplexer Module
(4-terminal pair) ..................................137
Features.................................................137
Specications .........................................137
Switching wiring diagram.........................140
Connector wiring diagram .......................141
Acquiring the relay opening/closing
frequency ...............................................142
11.3 Accuracy Calculation Example.........143
12 Appendix 145
12.1 Measurement cable............................145
12.2 Measuring Object Short Circuit
due to Relay Contact Welding..........148
12.3 Rack Mount .........................................150
Rack mount bracket................................150
L-shape bracket (For installing the
module in automated equipment) ............155
12.4 Outline Drawings ................................156
SW1001 .................................................156
SW1002 .................................................157
13 License Information 159
Index 161
Warranty Certicate
8.5 RS-232C Interface................................66
Connecting the RS-232C cable .................66
Setting RS-232C communications .............68
Setting the controller (PC, PLC, etc.) .........68
8.6 Communication Command
Forwarding Function ............................69
8.7 Communication Method.......................71
Message format........................................71
Output queue and input buffer...................76
Status Byte Register .................................77
Event Registers ........................................79
Initialization items .....................................86
Remote state ............................................86
8.8 Message List .........................................87
8.9 Message Reference.............................90
Standard commands.................................91
Device-speciccommands........................94
8.10 Sample Programs...............................107
Using Visual Basic®5.0 or 6.0 .................107
Using Visual Basic®2013 ........................ 111
9 Specications 119
9.1 SW1001, SW1002
GeneralSpecications.......................119
9.2 SW1001, SW1002
InputSpecications/
OutputSpecications/
MeasurementSpecications.............120
Basicspecications ................................120
9.3 SW1001, SW1002
FunctionalSpecications...................121
9.4 SW1001, SW1002
InterfaceSpecications .....................123
LAN........................................................123
USB .......................................................123
RS-232C ................................................123
EXT. I/O..................................................124
10 Maintenance and
Service 125
10.1 Troubleshooting ..................................125
Before sending the device for repair ........125
Error display and troubleshooting ............126
10.2 List of Device Error Numbers............127
10.3 Repair and Inspection........................128
HIOKI SW1001A961-04

1
Introduction
Introduction
Thank you for purchasing the Hioki SW1001, SW1002 Switch Mainframe. To obtain maximum
performance from the device over the long term, be sure to read this manual carefully and keep it
handy for future reference.
With the optional multiplexer module (hereafter referred to as “module”) installed on this device, the
input of multiple channels can be switched to one or two measuring instruments (hereafter referred
to as simply “instrument”).
Modules can be installed in 3 slots for the SW1001 and 12 slots for the SW1002. Other functions
are common for all the models.
Be sure to also read the separate document “Operating Precautions” before use.
Latest edition of intsruction manual
The contents of this manual are subject to change, for example as a result of product
improvements or changes to specications.
The latest edition can be downloaded from Hioki’s website.
https://www.hioki.com/global/support/download
Target audience
This manual has been written for use by individuals who use the product in question or who teach
others to do so. It is assumed that the reader possesses basic electrical knowledge (equivalent to
that of someone who graduated from the electrical program at a technical high school).
Trademarks
Microsoft, Windows, Visual Studio and Visual Basic are either registered trademarks or trademarks
of Microsoft Corporation in the United States and other countries.
Notations
*Additional information is presented below.
[ ] Menus, dialog boxes, buttons in a dialog box, and other names on the screen are
indicated in brackets.
POWER
(Bold) Indicates the names and keys on the screen and the device in boldface.
(p. ) Indicates the location of reference information.
Accuracy
We dene measurement tolerances in terms of f.s. (full scale), rdg. (reading), and dgt. (digit) with
the following meanings.
f.s. (maximum display value or range)
The maximum display value.
rdg. (reading or displayed value)
The value currently being measured and indicated on the instrument.
dgt.
(resolution)
The smallest displayable unit on a digital measuring device, i.e., the input value that
causes the digital display to show a “1” as the least-signicant digit.
10
9
8
7
6
5
4
3
2
1
Appx. Ind.
HIOKI SW1001A961-04

2
Conrming Package Contents
Conrming Package Contents
Main unit and accessories
Conrm that these contents are provided.
Model SW1001 or SW1002 Switch Mainframe
Instruction Manual (this document) Power cord
Operating Precautions (0990A905) CD (USB driver)*
* The latest version can be downloaded from our
website.
Options
The following options are available for the device. Contact your authorized Hioki distributor or
reseller when ordering. The options are subject to change. Visit our website for updated information.
Module
Model SW9001 Multiplexer Module
(2-wire/4-wire)
Model SW9002 Multiplexer Module
(4-terminal pair)
HIOKI SW1001A961-04

3
Conrming Package Contents
Connection cable
See: “Before measurement” (p. 5)
Model L2004 Connection Cable Model L2108 Connection Cable
Length: Approx. 910 mm Length: Approx. 840 mm
Maximum rated voltage: 30 V peak Maximum rated voltage: 60 V DC, 30 V AC rms,
42.4 V peak
Maximum rated voltage
to earth:
30 V DC or less, no
measurement category
Maximum rated voltage
to earth:
60 V DC or less, no
measurement category
Maximum rated current: 2.5 A peak Maximum rated current: 2 A peak
Model L4930 Connection Cable Set
Length: Approx. 1.2 m
Maximum rated voltage*: CAT III: 1000 V
CAT IV: 600 V
* Do not input voltage exceeding the rating of this device and the instrument.
Communications cable
Model 9642
LAN Cable
Model L1002
USB Cable (A-B)
Model 9637
RS-232C Cable (9pin-9pin/1.8 m)
10
9
8
7
6
5
4
3
2
1
Appx. Ind.
HIOKI SW1001A961-04

4
Safety Information
Safety Information
Be sure to also read the separate document “Operating Precautions” before use.
Usage Notes
Check before use
Follow these precautions to ensure safe operation and to obtain the full benets of the various
functions.
WARNING
If a connection cable or the device is damaged, there is a risk of an electric shock.
Perform the following inspection before using the device.
•Before using the device, check that the coating of the connection cables are
neither ripped nor torn and that no metal parts are exposed. Using the device
under such conditions could result in an electric shock. Replace any damaged
cable with a new one.
•Before using the device the rst time, verify that it operates normally to ensure
that no damage occurred during storage or shipping. If you nd any damage,
contact your authorized Hioki distributor or reseller.
This device is designed to measure voltages of 60 V or lower. Do not input
voltages over 60 V or measure locations exceeding 60 V from the ground potential.
If the relay of the device fails, the battery of the measuring object may be shorted
(p. 148).
Installing the device and module
CAUTION
Do not position the device on an unstable table or inclined surface. Dropping or
knocking down the device can cause injury or damage to the device.
Installing
To prevent overheating, be sure to leave the specied clearances around the device.
• The device should be operated only with the bottom side downwards.
Rear: 10 mm or moreSide: 50 mm or more
HIOKI SW1001A961-04

5
Usage Notes
Handling the device
This device may cause interference if used in residential areas. Such use must be avoided unless
the user takes special measures to reduce electromagnetic emissions to prevent interference to the
reception of radio and television broadcasts.
Before installing the module
WARNING
•To prevent an electric shock, before removing or replacing a module, conrm
that the device is turned off and that all the measurement cables, connection
cables, and the power cord are disconnected.
•Installing a module while the device is turned on may prevent detection of
the contact state of relays on the module or result in short-circuiting of the
measuring object. Damage of the device or module may cause the measuring
object to be shorted or the instrument to fail.
•Be careful about short circuits when connecting a measuring object with
electromotive force (battery, power supply, etc.).
•The maximum voltage of the device contact is 30 V (rms value) and 42.4 V (peak
value) or 60 V (direct current). Do not directly connect a withstand voltage tester
or an insulation resistance tester.
CAUTION
When installing or removing the module, be sure to observe the following precautions:
• Touch the GND terminal of the device with your hand to release static and then use
antistatic gloves to perform procedures.
• Hold the sheet metal area of the module. Directly touching the board with your hand may
damage the circuit board due to static. If the measurement target has high resistance, the
error component due to factors such as oil from your ngers may increase in magnitude.
Before measurement
DANGER
• Do not short-circuit between electrodes or terminals using a probe when
measuring the battery or capacitor. Doing so may cause an electric arc, resulting
in serious injury.
•Do not use the device or the connection cables that exceed its ratings or
specications. Doing so may damage the device or cause it to become hot,
resulting in a bodily injury.
•Do not use the instrument to be used in conjunction with the device outside of
its ratings or specications. Doing so may damage the instrument or cause it to
become hot, resulting in a physical injury.
WARNING
The maximum rated voltage between the module and ground is 60 V DC. To avoid
an injury and damage to the device, ensure that voltage between channels never
exceeds this limit. Prevent the voltage potential difference of the entire system
from exceeding 60 V DC.
The measurement connector frame of the module is connected to the casing (metal) of the device
as well as the protective ground terminal of the power inlet (conductive).
10
9
8
7
6
5
4
3
2
1
Appx. Ind.
HIOKI SW1001A961-04

6
Usage Notes
Before starting the external control
WARNING
To prevent an electric shock or damage to the device, always observe the
following precautions when connecting the cables to the EXT. I/O terminals.
•Always turn off the device and any devices to be connected before making
connections.
•Be careful to avoid exceeding the signal ratings of the EXT. I/O terminals.
•During operation, a wire becoming dislocated and contacting another
conductive object can be a serious hazard. Use screws to secure the external
connectors.
•Ensure that devices and systems to be connected to the EXT. I/O terminals are
properly isolated from one another.
Before connecting the communications cables
CAUTION
• Use a common ground for both the device and the PC. Using different ground circuits
will result in a potential difference between the device's ground and the computer's
ground. If the communications cable is connected while such a potential difference
exists, it may result in device malfunction or failure.
• Before connecting or disconnecting any communications cables, always turn off the
device and the PC. Failure to do so could result in equipment malfunction or damage.
• After connecting the communications cables, tighten the screws on the connector
securely. Failure to secure the connector could result in device malfunction or damage.
• To avoid device failure, do not disconnect the communications cables while
communications are in progress.
Precautions during shipment
Store the packaging in which the device was delivered, as you will need it when transporting the
device.
Disc precautions
• Exercise care to keep the recorded side of discs free of dirt and scratches. When writing text on
a disc’s label, use a pen or marker with a soft tip.
• Keep discs inside a protective case and do not expose to direct sunlight, high temperature, or
high humidity.
• Hioki is not liable for any issues your computer system experiences in the course of using this
disc.
HIOKI SW1001A961-04

7
1Overview
1.1 Overview of Product
This device is a module type switching system that is ideal for multi-channel measurement of
batteries. You can choose a main frame from two choices according to the required number of
channels. You can also choose a module from two module types according to the instrument to be
used with the device (2-wire/4-wire module and 4-terminal pair module).
1.2 Features
Reduction of errors when measuring internal resistance
When AC low resistance measurement is performed using the BT4560 Battery Impedance Meter
or the BT3562A Battery HiTester, the inuence of electromagnetic induction (eddy current) on the
measured value can be minimized.
Ability to switch measurement between two instruments
For example, you can connect a BT3562A and DM7276 to the device and use it to switch between
internal resistance measurement and high-precision OCV measurement.
Protection against short circuit with fuses
To protect batteries to be measured if a short circuit occurs in a channel, a protective fuse is built
into each channel.
1 Overview
1
Overview
HIOKI SW1001A961-04

8
Parts Names and Functions
1.3 Parts Names and Functions
Front
The illustration shown here is for the SW1001.
11
22
446677
33
55
88
99
No. Name Description Reference
11POWER lamp Lights up when the main frame power is on. p. 23
22ERROR lamp
Lights up for self-test at the time of startup and
when an error, such as a communications error,
occurs.
p. 23
p. 126
33REMOTE lamp Lights up when communications data is received. p. 86
44TERMINAL 1 Used to connect a 2-wire instrument. p. 20
55TERMINAL 2 Used to connect a 4-wire instrument. p. 20
66TERMINAL 3 Used to connect a 4-terminal pair (BNC terminal)
instrument. p. 21
77SLOT 1 to SLOT 3 Used to attach the module. p. 15
88Measurement cable connector
Used to connect the measurement cable to each
module. For more details, see the chapter for the
multiplexer module.
p. 5
p. 18
p. 134
p. 141
99GND terminal Ground for the device. Connected to the ground. p. 36
HIOKI SW1001A961-04

9
Parts Names and Functions
Rear
The illustration shown here is for the SW1001.
11
66778899
33
22
44
55
1010
1111
No. Name Description Reference
11Power switch Turns on/off the power. p. 23
22Power inlet Used to connect the provided power cord. p. 23
33EXT. I/O terminal Used to connect the device to be externally controlled. p. 51
44EXT. I/O MODE
change-over switch Left: Sinking current (NPN), Right: Sourcing current (PNP) p. 50
55Communication
setting mode switch
Perform communication using xed settings when the
communication settings are unknown. p. 22
66USB connector Used to connect the PC. p. 64
77HOST
RS-232C connector Used to connect the PC. p. 66
88INSTRUMENT
RS-232C connector
Used to connect the RS-232C connector of the instrument for
scan measurement. p. 70
99LAN connector Used to connect the PC. p. 60
1010 Serial number
The serial number consists of 9 digits. The rst two (from
the left) indicate the year of manufacture, and the next two
indicate the month of manufacture.
Required for production control. Do not peel off the label.
–
1111 MAC address MAC address of the LAN. p. 105
1
Overview
HIOKI SW1001A961-04

10
Block Diagram
1.4 Block Diagram
The conguration of this device is shown in the following block diagram.
...
PC/PLC
I/F EXT. I/O
Switch Mainframe
Internal analog bus
Terminal Module
Instrument Measuring object
Connection cable Measurement cable
Module
HIOKI SW1001A961-04

11
Glossary
1.5 Glossary
Terms Description Reference
Measurement cable Connects the measuring object and the module.
It is prepared by the customer.
p. 145
Connection cable Connects the switch mainframe and instrument.
Prepare the optional cable.
p. 19
Terminal Connects the instrument.
The terminal to be used varies depending on the connection method
(2-wire/4-wire/4-terminal pair)
p. 28
Module For the switching circuit.
The connection method varies depending on the module type.
p. 129
Slot Used to attach the module.
The number of slots varies depending on the switch mainframe type.
p. 30
Channel Channel inside the module.
Specify the slot and channel and select the measuring object.
p. 30
Analog bus Common analog signal inside the switch mainframe.
The analog buses for 4 systems are built in.
The analog bus to be used is determined based on the connection
method.
p. 27
Channel relay Switches the channel inside the module. p. 27
Bus relay Connects the measurement signal selected for the channel relay to
the analog bus.
It is built into the module.
Switching the bus relay allows you to select the connection method.
p. 27
Connection method You can select the measurement connection from 2-wire, 4-wire, or
4-terminal pair.
Selecting a connection method determines the connection terminal for
the instrument.
p. 28
Shield For the measurement cable (cable for the measuring object).
The destination to which the shield is connected inside the module
can be switched.
Switching the connection destination can reduce the inuence of
noise depending on the instrument to be used or the measurement
environment.
p. 29
Scan Switches the pre-registered channel (scan list) in sequence.
Connecting the instrument and this device using EXT. I/O enables
the channel to be switched and trigger measurement to be performed
automatically.
p. 39
1
Overview
HIOKI SW1001A961-04

12
Measurement Flowchart
1.6 Measurement Flowchart
Thoroughly read “Usage Notes” (p. 4) beforehand.
Installation, connection, and turning on of power
Installing the device. (p. 4)
Attaching the module to the device. (p. 15)
Connecting the measurement cable to the module. (p. 18)
Connecting the device and the instrument using the connection cable. (p. 19)
Connecting the communications cable and making settings.
• Set the communication setting mode (p. 22).
• Connect the LAN, USB, or RS-232C cable to the PC (p. 59).
Connecting the device and the external control device. (for scan measurement)
• Connect the device to an external device such as a PLC using EXT. I/O (p. 49).
Connecting the power cord. (p. 23)
Turning on the power. (p. 23)
Inspection before measurement (p. 25)
Setting before measurement
Selecting the module connection method. (p. 28)
Switching the shield. (p. 29)
Selecting the channel to be measured. (p. 30)
Starting the measurement
Sending a measurement command to the instrument.
Receiving measurement results.
• For information on the measurement processing and receiving measurement results, see the
instruction manual of the instruments to be used.
Ending the measurement
Turning off the power. (p. 23)
HIOKI SW1001A961-04

13
2Preparation for Measurements
2.1 Connecting Instruments and Controlling the
Device
This section describes how to connect one or more measuring instruments and control the device.
A PC or PLC must be connected in order to control the device. A PC or PLC connection is also
required in order to control instruments and acquire measured values.
The device utilizes the connection and control methods described below.
Basic control
Connect the PC to the device and instrument via separate communications interfaces.
Control the device to switch channels and control the instrument to congure settings, perform
measurement, and acquire measured values.
See: “3.2 Overview of Channel Switching” (p. 27)
PC
LAN/USB/RS-232C
LAN/USB/RS-232C
SW1001
Instrument
Controlling an instrument via the device
You can also use the device’s functionality for forwarding communication commands to control
instruments simply by sending commands to the device.
See: “8.6 Communication Command Forwarding Function” (p. 69)
PC
LAN/USB/RS-232C
SW1001 Instrument
RS-232C only
INSTRUMENT
connector
Performing automatic scan measurement using EXT. I/O
You can switch channels and perform a series of measurements in accordance with a previously
created scan list by connecting the device and an instrument via the EXT. I/O interface. You can
also acquire measured values by using the instrument’s data output function (to automatically send
measured values) or memory function.
See: “4 Scan Function” (p. 39)
PC
LAN/USB/RS-232C
LAN/USB/RS-232C
SW1001
Instrument
EXT. I/O
2 Preparation for Measurements
2
Preparation for Measurements
HIOKI SW1001A961-04

14
Connecting Instruments and Controlling the Device
Performing automatic scan measurement using EXT. I/O
(using the communication command forwarding function)
Furthermore, you can perform automatic scan measurement over a single communications
interface by using the device’s communication command forwarding function.
PC
LAN/USB/RS-232C
SW1001 Instrument
RS-232C only
INSTRUMENT
connector
EXT. I/O
Connecting two instruments
You can perform measurement by connecting two instruments to the device.
See: “3.5 Measurement between Two Instruments” (p. 32)
PC
LAN/USB/RS-232C
SW1001
LAN/USB/RS-232C
Instrument 1
LAN/USB/RS-232C
Instrument 2
HIOKI SW1001A961-04

15
Installing the Module
2.2 Installing the Module
Thoroughly read “Before installing the module” (p. 5) beforehand.
The following settings are initialized when you install a new module into a slot or change the type of
module installed in a given slot.
• Connection method
• Shield switching
• Channel delay
• Scan list
Required items: Phillips screwdriver (No. 2), antistatic gloves
Front
1
1
Touch the GND terminal with
bare hands.
2
Wear antistatic gloves.
Rear
3
3
Turn off the device.
Front
4
Remove all the measurement
cables connected to the device
and module.
(To prevent electric shock and short
circuit of the measuring object.)
Blank panel
Screw
(M3 × 6 mm)
5
Loosen the two screws
(M3 × 6 mm) and then remove
the blank panel.
Store the blank panel and screws.
You need the screws when using the
device after removing the module.
2
Preparation for Measurements
HIOKI SW1001A961-04

16
Removing the Module
Align with the guide rail
6
Insert the module to the back.
Screw
7
Tighten the two screws to
secure the module in place.
2.3 Removing the Module
Required items: Phillips screwdriver (No. 2), antistatic gloves
Front
1
1
Touch the GND terminal with
bare hands.
2
Wear antistatic gloves.
Rear
3
3
Turn off the device.
HIOKI SW1001A961-04
