HIOTH TECHNOLOGY CT-HAWF1008-BL User manual

HIOTH TECHNOLOGY CO., LTD. USER MANUAL
www.HiotH.com
Smart Plug
Introduction
As a safe use of electricity protection, it can be used to prevent electrical insulation damage
caused by ground fault, lightning or over-current caused by the fire danger; or for the regional
energy-saving helper to provide a smart and convenient experience.
This product has six major protection functions of leakage protection, overcurrent protection, short
circuit protection, overvoltage protection, under voltage protection, lightning protection, which
completely eliminate electrical fire accidents and extend electrical life. It is ideal for home and
industrial use of energy-saving safety plug.
Technical Information
Local and remote control or combined with timing, linkage and other functions
Combined with timing, linkage and other functions to achieve complete smart control
Using flame retardant PC, safe and reliable
Standard small five-hole design
CT-HAWF1008-BL

HIOTH TECHNOLOGY CO., LTD. USER MANUAL
www.HiotH.com
Specification
1. Wireless protocol: WiFi (802.11 b/g/n)
2. The input / output voltage: 100 ~ 240V AC 50/60Hz
3. The maximum load: 10A/2200W
4. Working temperature: -20 ~ 60℃
5. Power consumption: ≤0.5W
6. Switch life: >50000 times
7. Safety Protection: Child protection
8. Socket jack type: Standard five hole
9. Dimension: 75mm 44mm 58mm
Operation
As shown in Fig.1, there is an on / off button on the side and a small five-hole power jack on the
front.
Fig.1
NETWORK ENTRY
1) Power on the device.
2) Press and hold the on / off button for 5 seconds then release the button, until the WiFi Indi-
cator LED flash quickly with a blue light.
3) Please follow the below menu order on APP to find the network join interface:
Log in > Menu bar > Device Management > Add device

HIOTH TECHNOLOGY CO., LTD. USER MANUAL
www.HiotH.com
4) Choose " Broadlink " to enter the Network Inclusion mode on the APP, then click "".
5) Check the status of the WiFi Indicator LED:
Blue light flashes slowly - the device is connecting to the wireless network;
Blue light stop flashing - the device has entered into the network.
6) When prompt a message “Request Access Success”, please go to the device list interface and
refresh the device list, the device will be displayed.
Installation Instruction
This device is applicable to household appliances, air conditioners, water heaters and other each
kind of size power power on / off, can also be used to measure power appliances.
In addition, when you install the Smart Plug, no wiring requires and only need to insert the jack
into proper place, which can make the installation completed.
PRODUCT INSTALLATION
1) The specification:
Input: 100V ~ 240V AC
Output: 100V ~ 240V AC
2) This device is a WiFi device. Please place it in the WiFi range when installing in order to
ensure the remote control effect.
Safety Notice
This device is a wireless communication product, please do not place the device to work in
the metal container, in case the signal is blocked.
Keep the device away from a strong sunlight, humidity, high temperature, dust or mechanical
shock.
Keep the device away from acid-base and other corrosive substances to avoid damage.
