Banner World-Beam QS18 Series User manual

Instruction Manual
Miniature Self-Contained Photoelectric Sensors in Universal Housing
• Easily fits (or retrofits) almost any mounting situation
• Exceptional optical performance, comparable to larger “MINI-style” or barrel sensors
• 10 V dc to 30 V dc operation, with complementary (SPDT) NPN or PNP outputs, depending
on model
• Bright LED operating status indicators are visible from 360°
• Rugged sealed housing, protected circuitry
• Models available with or without 18 mm threaded “nose”
• Less than 1 millisecond output response for excellent sensing repeatability
• Choose 2 m (6.5 ft) or 9 m (30 ft) cable or 150 mm (6 inch) Pico-style cabled QD
WARNING: Not To Be Used for Personnel Protection
Never use this device as a sensing device for personnel protection. Doing so could lead to serious injury or
death. This device does not include the self-checking redundant circuitry necessary to allow its use in
personnel safety applications. A sensor failure or malfunction can cause either an energized or de-energized
sensor output condition.
Models
Model 1Opposed Mode Range Output
QS186EV (624 nm Visible red)
Effective beam: 13 mm (0.5 inch)
OPPOSED
OPPOSED
20 m (66 ft)
—
QS186E (940 nm Infrared) —
QS18VN6R NPN
QS18VP6R PNP
QS186EB (940 nm Infrared) Effective beam: 13 mm (0.5 inch)
OPPOSED
3 m (10 ft)
—
QS18VN6RB NPN
QS18VP6RB PNP
Model 1Polarized Retroreflective Mode Range Output
QS18VN6LP 630 nm Visible red
P
POLAR RETRO
3.5 m (12 ft)
NPN
QS18VP6LP PNP
Model 1Retroreflective Mode Range Output
QS18VN6LV 628 nm Visible red
RETRO
6.5 m (21 ft)
NPN
QS18VP6LV PNP
1• To order the 9 m (30 ft) PVC cable model, add the suffix "W/30" to the cabled model number. For example, QS186E W/30.
• To order the 4-pin M12/Euro-style integral quick disconnect model, add the suffix "Q8" to the model number. For example, QS186EQ8.
• To order the 4-pin M8/Pico-style integral quick disconnect model, add the suffix "Q7" to the model number. For example, QS186EQ7.
• To order the 150 mm (6 in) PVC cable model with a 4-pin M12/Euro-style quick disconnect, add the suffix "Q5" to the model number. For
example, QS186EQ5.
• To order the 150 mm (6 in) PVC cable model with a 4-pin M8/Pico-style quick disconnect, add the suffix "Q" to the model number. For example,
QS186EQ.
• Models with a quick disconnect require a mating cordset.
WORLD-BEAM®QS18 Series Sensor
Original Document
197052 Rev. C
4 December 2017
197052

Model 1Convergent Mode Range Output
QS18VN6CV15
630 nm Visible red
CONVERGENT
VISIBLE RED
16 mm (0.63 in)
NPN
QS18VP6CV15 PNP
QS18VN6CV45
43 mm (1.7 in)
NPN
QS18VP6CV45 PNP
Model 1Diffuse Mode Range Output
QS18VN6D
940 nm Infrared
DIFFUSE
450 mm (18 in)
NPN
QS18VP6D PNP
QS18VN6DL
600 mm (24 in)
NPN
QS18VP6DL PNP
QS18VN6DB (Diffuse, wide)
DIFFUSE
450 mm (18 in)
NPN
QS18VP6DB (Diffuse, wide) PNP
Model 1Divergent Mode Range Output
QS18VN6W 940 nm Infrared
DIFFUSE
DIVERGENT
100 mm (4 in)
NPN
QS18VP6W PNP
Model 1Fixed Field Mode Range Output
QS18VN6FF50
630 nm Visible red
FIXED-FIELD
50 mm (2 in)
NPN
QS18VP6FF50 PNP
QS18VN6FF100
100 mm (4 in)
NPN
QS18VP6FF100 PNP
QS18VN6FF150
150 mm (6 in)
NPN
QS18VP6FF150 PNP
Model 1Plastic Fiber Optic Mode Range Output
QS18VN6FP 660 nm Visible Red
PLASTIC FIBER
Range varies by sensing mode
and fiber optics used
NPN
QS18VP6FP PNP
Model 1Glass Fiber Optic Mode Range Output
QS18VN6F 940 nm Infrared
GLASS FIBER
Range varies by sensing mode
and fiber optics used
NPN
QS18VP6F PNP
WORLD-BEAM®QS18 Series Sensor
2 www.bannerengineering.com - Tel: [phone] P/N 197052 Rev. C

Wiring Diagrams
QS18 with NPN Outputs
10-30V dc
–
+
1
3
2
4Load
Load
QS18 with PNP Outputs
10-30V dc
–
+
1
3
2
4Load
Load
QS18 Emitters
10-30V dc
–
+
1
3
Key
1 = Brown
2 = White
3 = Blue
4 = Black
Quick disconnect (QD) wiring diagrams are functionally identical.
Installing Fibers
Cutting Unterminated Plastic Fibers QS18V..6FP
Unterminated plastic fibers are designed to be cut by the user to the length required for the application.
To facilitate cutting, a Banner model PFC-1 cutting device is supplied with the fiber. Cut the fiber as follows:
Cutting Ports
Lift to Open Ports
Figure 1. PFC-1 Cutting Device
Use small ports for fiber sizes:
• 0.25 mm (0.01 inches)
• 0.5 mm (0.02 inches)
Use large ports for fiber sizes:
• 0.75 mm (0.03 inches)
• 1.0 mm (0.04 inches)
• 1.5 mm (0.06 inches)
1. Locate the control end of the fiber (the unfinished end).
2. Determine the length of fiber required for the application. If using a bifurcated fiber, separate the two halves of the fiber at
least 51 mm (2 inches) beyond the fiber cutting location.
3. Lift the top (blade) of the cutter to open the cutting ports.
4. Insert one of the control ends through one of the cutting ports on the cutter so that the excess fiber protrudes from the
back of the cutter.
5. Double-check the fiber length, and close the cutter until the fiber is cut.
6. Using a different cutting port, cut the second control end to the required length.
Note: To ensure a clean cut each time, do not use a cutting port more than once.
7. Gently wipe the cut ends of the fiber with a clean, dry cloth to remove any contamination. Do not use solvents or abrasives
on any exposed optical fiber.
Installing Plastic Fibers QS18V..6FP
Follow these steps to install the plastic fibers.
A
B
CFiber end
Adapter
Adapter Installation
Figure 2. Installing Plastic Fibers
WORLD-BEAM®QS18 Series Sensor
P/N 197052 Rev. C www.bannerengineering.com - Tel: [phone]

1. Slide the fiber gripper up to unlock it (A).
2. If using 0.25 mm or 0.5 mm core fibers, slide the plastic fiber adapters onto the fibers, flush with the fiber ends.
3. Carefully insert the prepared plastic fiber ends into the ports (B) as far as possible without applying extra force.
4. Slide the fiber gripper down to lock the fibers in place (C).
Installing Glass Fibers QS18V..6F
Follow these steps to install the glass fibers.
O-rings
Retaining Clip
Figure 3. Installing Glass Fibers
1. Slide the supplied o-ring on the sensor end of the fibers, as shown.
2. Press the fiber ends firmly into the ports located on the front of the sensor.
3. Slide the supplied u-shaped retaining clip into the slot in the sensor’s barrel until the clip snaps into place.
WORLD-BEAM®QS18 Series Sensor
4 www.bannerengineering.com - Tel: [phone] P/N 197052 Rev. C

Specifications
Supply Voltage
10 V to 30 V dc (10% maximum ripple) at less than 25 mA, exclusive of load
Protected against reverse polarity and transient voltages
Light Source
Glass Fiber Optic, Opposed and Diffuse mode models: Infrared, 940 nm
Plastic Fiber Optic, Retroreflective, Convergent models: Visible red, 660 nm
Fixed-Field models: Visible red, 630 nm
Adjustments
Glass Fiber Optic, Plastic Fiber Optic, Convergent, Diffuse, and
Retroreflective mode models (only): Single-turn sensitivity (Gain) adjustment
potentiometer
Indicators
2 LED indicators on sensor top:
Green solid: Power on
Amber solid: Light sensed
Amber flashing: Marginal excess gain (1 to 1.5 times excess gain)
Required Overcurrent Protection
WARNING: Electrical connections must be
made by qualified personnel in accordance with
local and national electrical codes and
regulations.
Overcurrent protection is required to be provided by end product
application per the supplied table.
Overcurrent protection may be provided with external fusing or via Current
Limiting, Class 2 Power Supply.
Supply wiring leads < 24 AWG shall not be spliced.
For additional product support, go to
www.bannerengineering.com .
Supply Wiring (AWG) Required Overcurrent Protection (Amps)
20 5.0
22 3.0
24 2.0
26 1.0
28 0.8
30 0.5
Repeatability
Opposed Mode: 100 microseconds
DL and FF Modes: 90 microseconds
All Other Modes: 150 microseconds
Output Configuration
Solid-state complementary (SPDT): NPN or PNP (current sinking or
sourcing), depending on model;
Rating: 100 mA maximum each output at 25 °C
DL and FF Modes ON-state Saturation Voltage: less than 1.5 V at 10 mA;
less than 3 V at 100 mA
All Other Modes: ON-state Saturation Voltage: less than 1 V at 10 mA; less
than 1.5 V at 100 mA
Protected against false pulse on power-up and continuous overload or short
circuit of outputs
Output Response
Opposed Mode: 750 microseconds ON; 375 microseconds OFF
FF and DL Modes: 850 microseconds ON/OFF
All Other Modes: 600 microseconds ON/OFF
Note: 100 millisecond delay on power-up; outputs do not conduct during
this time
Construction
ABS housing
3 mm mounting hardware included
Connections
2 m (6.5 ft) 4-wire PVC cable, 9 m (30 ft) 4-wire PVC cable, 4-pin Pico-style
or Euro-style QD, 4-pin Pico-style or Euro-style 150 mm (6 in) QD,
depending on model
Environmental
IEC IP67; NEMA 6
Operating Conditions
Temperature: –20 °C to +70 °C (–4 °F to +158 °F)
95% at +50 °C maximum relative humidity (non-condensing)
Certifications
Note: For performance specifications of the
FF50 and FF100 models built prior to date
code 17090, refer to document p/n
63908 .
Dimensions and Features
Model Suffix E, EV, R, and FF
15.0 mm
(0.59")
31.0 mm
(1.22")
3.0 mm
(0.12")
17.1 mm
(0.67")
24.1 mm
(0.95")
35.0 mm
(1.38")
Yellow
LED
Green
LED
Ø3.3 mm (0.13")
Max. torque 0.6 Nm (5 in-lbs)
Model Suffix EB, RB
3.0 mm
(0.12")
21.1 mm
(0.82")
Model Suffix DB, W
3.0 mm
(0.12")
21.1 mm
(0.82")
WORLD-BEAM®QS18 Series Sensor
P/N 197052 Rev. C www.bannerengineering.com - Tel: [phone]

Model Suffix FP
15.0 mm
(0.59")
7.5 mm
(0.30")
13.4 mm
(0.53")
7.6 mm
(0.30")
17.1 mm
(0.67")
27.5 mm
(1.09")
5.2 mm
(0.21")
31.0 mm †
(1.22")
3.0 mm
(0.12")
† CV Models:
33.2 mm (1.31")
Model Suffix CV15, CV45, D, DL, LV, LP
Single-turn
Sensitivity
Adjustment
M18x1 Thread
Max. torque 2.3 Nm (20 in-lbs)
Model Suffix F
17.1 mm
(0.67")
36.9 mm
(1.45")
19.8 mm
(0.78")
Slot for
Fiber Clip
Model Suffix Q7 Model Suffix Q8
Model Suffix Q
(e.g. QS186EQ)
Model Suffix Q5
(e.g. QS186EQ5) (e.g. QS186EQ7) (e.g. QS186EQ8)
150 mm (6")
Pico-style
Pigtail
150 mm (6")
Euro-style
Pigtail
41.5 mm
(1.63") 49 mm
(1.93")
Integral
4-pin
Pico-Style QD
Integral
4-pin
Euro-Style QD
M18 x 1 Jam Nut Packing List
8.0 mm
(0.32")
24.2 mm
(0.95")
M3 hardware packet contents:
2 - M3 x 0.5 x 20 mm stainless steel screw
2 - M3 x 0.5 stainless steel hex nut
2 - M3 stainless steel washer
Sensor
M18 x 1 jam nut
M3 hardware packet
Installation sheet, p/n 63687
Performance Curves
Opposed Mode
Excess Gain Curve Beam Pattern Excess Gain Curve Beam Pattern
1
10
100
1 m
3.3 ft
10 m
33 ft
100 m
330 ft
0.1 m
0.3 ft
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
QS186E, EV and
QS18...R
Opposed Mode
20 m
66 ft
16 m
52 ft
12 m
40 ft
8 m
26 ft
4 m
12 ft
0
0
250 mm
500 mm
750 mm
250 mm
500 mm
750 mm
0
10 in
20 in
30 in
10 in
20 in
30 in
DISTANCE
QS186E, EV and QS18...R
Opposed Mode
1
10
100
0.1 m
0.33 ft
1 m
3.3 ft
10 m
33 ft
0.01 m
0.03 ft
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
QS186EB and
QS18...RB
Opposed Mode
3.75 m
12.5 ft
3.0 m
10 ft
2.25 m
7.5 ft
1.5 m
5 ft
.75 m
2.5 ft
0
0
150 mm
300 mm
450 mm
150 mm
300 mm
450 mm
0
6 in
12 in
18 in
6 in
12 in
18 in
DISTANCE
QS186EB and QS18...RB
Opposed Mode
WORLD-BEAM®QS18 Series Sensor
6 www.bannerengineering.com - Tel: [phone] P/N 197052 Rev. C

Polarized Retroreflective Retroreflective
Excess Gain Curve Beam Pattern Excess Gain Curve Beam Pattern
1
10
100
0.1 m
0.33 ft
1 m
3.3 ft
10 m
33 ft
0.01 m
0.03 ft
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
QS18...LP
Retroreflective Mode
with BRT-84 Reflector
3.75 m
12.5 ft
3.0 m
10 ft
2.25 m
7.5 ft
1.5 m
5 ft
.75 m
2.5 ft
0
0
10 mm
20 mm
30 mm
10 mm
20 mm
30 mm
0
0.4 in
0.8 in
1.2 in
0.4 in
0.8 in
1.2 in
DISTANCE
QS18...LP
Retroreflective Mode
with BRT-84 Reflector
1
10
100
0.1 m
0.33 ft
1 m
3.3 ft
10 m
33 ft
0.01 m
0.03 ft
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
QS18...LV
Retroreflective Mode
with BRT-84 Reflector
7.5 m
25 ft
6.0 m
20 ft
4.5 m
15 ft
3.0 m
10 ft
1.5 m
5 ft
0
0
50 mm
100 mm
150 mm
50 mm
100 mm
150 mm
0
2 in
4 in
6 in
2 in
4 in
6 in
DISTANCE
QS18...LV
Retroreflective Mode
with BRT-84 Reflector
Convergent (Performance is based on a 90% reflectance white test card.)
Excess Gain Curve Beam Pattern Excess Gain Curve Beam Pattern
1
10
100
10 mm
0.4 in
100 mm
4.0 in
1000 mm
40.0 in
1 mm
0.04 in
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
QS18...CV15
Convergent Mode
50 mm
2.0 in
40 mm
1.6 in
30 mm
1.2 in
20 mm
0.8 in
10 mm
0.4 in
0
0
2 mm
4 mm
6 mm
2 mm
4 mm
6 mm
0
.08 in
.16 in
.24 in
.08 in
.16 in
.24 in
DISTANCE
Convergent Mode
QS18...CV15
1
10
100
10 mm
0.4 in
100 mm
4.0 in
1000 mm
40.0 in
1 mm
0.04 in
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
QS18...CV45
Convergent Mode
75 mm
3.0 in
60 mm
2.4 in
45 mm
1.8 in
30 mm
1.2 in
15 mm
0.6 in
0
0
2 mm
4 mm
6 mm
2 mm
4 mm
6 mm
0
.08 in
.16 in
.24 in
.08 in
.16 in
.24 in
DISTANCE
Convergent Mode
QS18...CV45
Diffuse (Performance is based on a 90% reflectance white test card.)
Excess Gain Curve Beam Pattern Excess Gain Curve Beam Pattern
1
10
100
10 mm
0.4 in
100 mm
4.0 in
1000 mm
40.0 in
1 mm
0.04 in
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
QS18...D
Diffuse Mode
500 mm
20.0 in
400mm
16.0 in
300 mm
12.0 in
200 mm
8.0 in
100 mm
4.0 in
0
0
2 mm
4 mm
6 mm
2 mm
4 mm
6 mm
0
.08 in
.16 in
.24 in
.08 in
.16 in
.24 in
DISTANCE
QS18...D
Diffuse Mode
1
10
100
1000
DISTANCE (mm)
EXCESS GAIN
1 10 100 1000
QS18 DL
0 200 400 600 800
0
2 mm
2 mm
4 mm
4 mm
6 mm
6 mm
8 mm
8 mm
10 mm
10 mm
DISTANCE (mm)
QS18 DL
Diffuse (Performance is based on a 90% reflectance white test card.) Divergent (Performance is based on a 90% reflectance white test card.)
Excess Gain Curve Beam Pattern Excess Gain Curve Beam Pattern
1
10
100
10 mm
0.4 in
100 mm
4.0 in
1000 mm
40.0 in
1 mm
0.04 in
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
QS18...DB
Diffuse Mode
500 mm
20.0 in
400mm
16.0 in
300 mm
12.0 in
200 mm
8.0 in
100 mm
4.0 in
0
0
10 mm
20 mm
30 mm
10 mm
20 mm
30 mm
0
0.4 in
0.8 in
1.2 in
0.4 in
0.8 in
1.2 in
DISTANCE
QS18...DB
Diffuse Mode
1
10
100
10 mm
0.4 in
100 mm
4.0 in
1000 mm
40.0 in
1 mm
0.04 in
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
QS18...W
Divergent
Diffuse Mode
100 mm
4.0 in
80 mm
3.2 in
60 mm
2.4 in
40 mm
1.6 in
20 mm
0.8 in
0
0
10 mm
20 mm
30 mm
10 mm
20 mm
30 mm
0
0.4 in
0.8 in
1.2 in
0.4 in
0.8 in
1.2 in
DISTANCE
Divergent
Diffuse Mode
QS18...W
WORLD-BEAM®QS18 Series Sensor
P/N 197052 Rev. C www.bannerengineering.com - Tel: [phone]

Fixed Field
Excess Gain Curve (50 mm) Excess Gain Curve (100 mm) Excess Gain Curve (150 mm) Spot Sizes
1
10
100
1000
0.1 1 10 100
Distance (mm)
QS18..FF50
Excess Gain
1
10
100
1000
0.1 1 10 100 1000
Distance (mm)
QS18..FF100
Excess Gain
1
10
100
1000
0.1 1 10 100 1000
Distance (mm)
QS18..FF150
Excess Gain
50 mm Models:
At 25 mm: 8 × 5.5 mm
At 50 mm: 6 × 5 mm
100 mm Models
At 50 mm: 6 × 4 mm
At 100 mm: 3 × 3 mm
150 mm Models
At 75 mm: 5 × 3.5 mm
At 150 mm: 6 × 6 mm
Opposed - Plastic Fiber Bifurcated - Plastic Fiber (Performance is based on a 90% reflectance white test
card.)
Excess Gain Curve Beam Pattern Excess Gain Curve Beam Pattern
1
10
100
10 mm
.40 in
100 mm
4.0 in
1000 mm
40 in
1 mm
.04 in
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
QS18..FP
QS18..FP
Opposed Mode
Plastic Fibers
PIT66U Fiber
PIT46U Fiber
250 mm
10 in
200 mm
8 in
150 mm
6 in
100 mm
4 in
50 mm
2 in
0
0
20 mm
40 mm
60 mm
20 mm
40 mm
60 mm
0
0.8 in
1.6 in
2.4 in
0.8 in
1.6 in
2.4 in
DISTANCE
QS18..FP
QS18..FP
PIT46U
PIT66U
Opposed Mode
Plastic Fibers
1
10
100
1 mm
.04 in
10 mm
.4 in
100 mm
4 in
.1 mm
.004 in
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
Diffuse Mode
Plastic Fibers
PBT66U Fiber
PBT46U Fiber
QS18..FP
QS18..FP
100 mm
4.8 in
80 mm
3.2 in
60 mm
2.4 in
40 mm
1.6 in
20 mm
0.8 in
0
0
10 mm
20 mm
30 mm
10 mm
20 mm
30 mm
0
0.4 in
0.8 in
1.2 in
0.4 in
0.8 in
1.2 in
DISTANCE
QS18..FP
QS18..FP
PBT46U
PBT66U
Diffuse Mode
Plastic Fibers
Opposed - Glass Fiber (Performance is based on a 90% reflectance white test
card.)
Bifurcated - Glass Fiber (Performance is based on a 90% reflectance white test
card.)
Excess Gain Curve Beam Pattern Excess Gain Curve Beam Pattern
1
10
100
.1 m
.33 ft
1 m
3.3 ft
10 m
33 ft
.01 m
.033 ft
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
QS18F
Opposed Mode
Glass Fibers
IT23S Fibers
w/L9 lenses
IT23S
Fibers
IT13S
Fibers
500 mm
20 in
400 mm
16 in
300 mm
12 in
200 mm
8 in
100 mm
4 in
0
0
25 mm
50 mm
75 mm
25 mm
50 mm
75 mm
0
1 in
2 in
3 in
1 in
2 in
3 in
DISTANCE
QS18F
Opposed Mode
IT13S IT23S
1
10
100
10 mm
.4 in
100 mm
4 in
1000 mm
40 in
1 mm
.04 in
1000
E
X
C
E
S
S
G
A
I
N
DISTANCE
QS18F
Diffuse Mode
Glass Fibers
BT23S Fiber
BT13S Fiber
37.5 mm
1.5 in
30 mm
1.2 in
22.5 mm
0.9 in
15 mm
0.6 in
7.5 mm
0.3 in
0
0
0.65 mm
1.3 mm
1.9 mm
0.65 mm
1.3 mm
1.9 mm
0
0.025 in
0.050 in
0.075 in
0.025 in
0.050 in
0.075 in
DISTANCE
QS18F
Diffuse Mode
BT23SBT13S
Accessories
Cordsets
4-Pin Threaded M12/Euro-Style Cordsets
Model Length Style Dimensions Pinout (Female)
MQDC-406 1.83 m (6 ft)
Straight
44 Typ.
ø 14.5
M12 x 1
2
3
4
1
1 = Brown
2 = White
3 = Blue
4 = Black
MQDC-415 4.57 m (15 ft)
MQDC-430 9.14 m (30 ft)
MQDC-450 15.2 m (50 ft)
WORLD-BEAM®QS18 Series Sensor
8 www.bannerengineering.com - Tel: [phone] P/N 197052 Rev. C

4-Pin Threaded M12/Euro-Style Cordsets
Model Length Style Dimensions Pinout (Female)
MQDC-406RA 1.83 m (6 ft)
Right-Angle
32 Typ.
[1.26"]
30 Typ.
[1.18"]
ø 14.5 [0.57"]
M12 x 1
MQDC-415RA 4.57 m (15 ft)
MQDC-430RA 9.14 m (30 ft)
MQDC-450RA 15.2 m (50 ft)
4-Pin Snap-on M8/Pico-Style Cordsets
Model Length Style Dimensions Pinout (Female)
PKG4-2 2 m (6.56 ft) Straight
ø 9.0
32 Typ.
4
31
2
1 = Brown
2 = White
3 = Blue
4 = Black
PKW4Z-2 2 m (6.56 ft) Right-Angle
ø 10.9
29 Typ.
15 Typ.
WORLD-BEAM QS18 Brackets
SMB18A
• Right-angle mounting
bracket with a curved slot
for versatile orientation
• 12-ga. stainless steel
• 18 mm sensor mounting
hole
• Clearance for M4 (#8)
hardware
30
41
46
AB
C
Hole center spacing: A to B = 24.2
Hole size: A = ø 4.6, B = 17.0 × 4.6, C = ø 18.5
SMB312S
• Stainless steel 2-axis,
side-mount bracket
46
B
C
A
32 20
A = 4.3 × 7.5, B = diam. 3, C = 3 ×
15.3
All measurements are in millimeters.
Retroreflective Targets
Go to www.bannerengineering.com or see the Accessories section of your current Banner Engineering Corp catalog for complete
information.
Note: Polarized sensors require corner cube type retroreflective targets only.
Plastic and Glass Fiber Optics
Go to www.bannerengineering.com or see the Accessories section of your current Banner Engineering Corp catalog for a list of
plastic and glass fiber optic cables.
WORLD-BEAM®QS18 Series Sensor
P/N 197052 Rev. C www.bannerengineering.com - Tel: [phone]

Banner Engineering Corp. Limited Warranty
Banner Engineering Corp. warrants its products to be free from defects in material and workmanship for one year following the date of shipment. Banner Engineering Corp. will repair or
replace, free of charge, any product of its manufacture which, at the time it is returned to the factory, is found to have been defective during the warranty period. This warranty does not
cover damage or liability for misuse, abuse, or the improper application or installation of the Banner product.
THIS LIMITED WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES WHETHER EXPRESS OR IMPLIED (INCLUDING, WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE), AND WHETHER ARISING UNDER COURSE OF PERFORMANCE, COURSE OF DEALING OR TRADE USAGE.
This Warranty is exclusive and limited to repair or, at the discretion of Banner Engineering Corp., replacement. IN NO EVENT SHALL BANNER ENGINEERING CORP. BE LIABLE TO
BUYER OR ANY OTHER PERSON OR ENTITY FOR ANY EXTRA COSTS, EXPENSES, LOSSES, LOSS OF PROFITS, OR ANY INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES
RESULTING FROM ANY PRODUCT DEFECT OR FROM THE USE OR INABILITY TO USE THE PRODUCT, WHETHER ARISING IN CONTRACT OR WARRANTY, STATUTE, TORT,
STRICT LIABILITY, NEGLIGENCE, OR OTHERWISE.
Banner Engineering Corp. reserves the right to change, modify or improve the design of the product without assuming any obligations or liabilities relating to any product previously
manufactured by Banner Engineering Corp. Any misuse, abuse, or improper application or installation of this product or use of the product for personal protection applications when the
product is identified as not intended for such purposes will void the product warranty. Any modifications to this product without prior express approval by Banner Engineering Corp will
void the product warranties. All specifications published in this document are subject to change; Banner reserves the right to modify product specifications or update documentation at
any time. Specifications and product information in English supersede that which is provided in any other language. For the most recent version of any documentation, refer to:
www.bannerengineering.com .
WORLD-BEAM®QS18 Series Sensor
©Banner Engineering Corp. All rights reserved
