USER’S OPERATION MANUAL
Before operating this unit, please read this manual
thoroughly, and retain for future reference
RQ760N4SBFE


Thank you for choosing Hisense. We are sure you will find your new refrigerator a
pleasure to use. However, before you use the appliance, we recommend that you
carefully read the instructions, which provide details about installing and using the
product. Please keep this manual for future reference.

REFRIGERATOR SAFETY............................................................................................ 3
PARTS AND FEATURES............................................................................................. 11
INSTALLATION REQUIREMENTS................................................................................. 12
Location Requirements............................................................................................12
Electrical Requirements........................................................................................... 12
INSTALLATION INSTRUCTIONS.................................................................................. 13
Unpack the Refrigerator...........................................................................................13
Installation Positioning.............................................................................................13
Door Removal.......................................................................................................... 13
Use of water storage box......................................................................................... 14
Complete the Installation........................................................................................ 15
Level Refrigerator..................................................................................................... 15
Align Doors.............................................................................................................. 15
REFRIGERATOR USE................................................................................................. 16
Opening and Closing Doors....................................................................................16
Using the Controls....................................................................................................17
Features...................................................................................................................20
General Use Information..........................................................................................22
REFRIGERATOR CARE.............................................................................................. 24
Cleaning..................................................................................................................24
Lights.......................................................................................................................24
Vacation and Moving Care..................................................................................... 25
Reinstalling/Using Refrigerator Again...................................................................... 25
TROUBLESHOOTING................................................................................................ 26



temperature and humidity sensor outside the box of
appliance and make the appliance run better,add
In order to sense the temperature and humidity near the
appliance.

To avoid contamination of food, please respect the
following instructions:
Opening the door for long periods can cause a signicant
increase of the temperature in the compartments of the
appliance.
Clean regularly surfaces that can come in contact with
food and accessible drainage systems.
Clean water tanks if they have not been used for 48 h;
ush the water system connected to a water supply if
water has not been drawn for 5 days.
Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto
other food.
Two-star frozen-food compartments are suitable for storing
pre-frozen food, storing or making icecream and making
ice cubes.
One-, two- and three-star compartments are not suitable
for the freezing of fresh food.
If the refrigerating appliance is le empty for long periods,
switch o, defrost, clean, dry, and leave the door open to
prevent mould developing within the appliance.














Refrigerator Door Bin
Rotary Separator
Refrigerator LED Light
Ice-Maker
Freezer LED Light
Freezer Tray





Freezer Middle Drawer
Freezer Lower Drawer
Freezer Door Bin
Glass Shelf
Cover
Storage Drawer
Convertible Compartment LED light
Convertible Compartment Tray
Convertible Compartment Middle
Drawer
Convertible Compartmente Lower
Draw
Leveling Leg





























Refrigerator side lights




(
7
7
Water storage box

12
AC 220-240 volt, 50 Hz, AC only 15- or 20-amp fused,
grounded electrical supply is required. It is
recommended that a separate circuit serving only
your refrigerator is provided. Use an outlet that
cannot be turned off by a switch. Do not use an
extension cord.
NOTE: Befor performing any type of installation or
cleaning, disconnect the refrigerator from the
electrical source.When you have finished, reconnect
the refrigerator to the electrical source and reset
the temperature controls to the desired setting.

Unpack the Refrigerator
Door Removal
(only if needed)

,

Use of water storage box
1 . The user pulls out the ice box in the direction of
the arrow.

2. Open the lid of the ice box and add water to it.
3. Close the lid and push back into the ice box in
the direction of the arrow.

1.The ice box can hold up to 4.2L of water.
2.If the water storage box is not in place,
the icon“ ”on the control panel flashes.
3.If the user has more than 7 days of travel
planned,it is recommended to clean the
ice.
4.When the tank is repositioned,the pump
will reverse the water from the ice maker.
After about a minute,a few drops of water
will fall out of the ice outlet,which is normal.
Level Refrigerator if needed
are


your refrigerator to swing the doors open.

and Super Cool function will be off.
the "Eco" button,"Eco" function will be activated,

turn
Leaving any door open for over 2 minutes will
activate door alarm.The “ ” icon will flicker, the
control panel will display “dr” , and you will hear a
buzzer sound.The buzzer will sound 3 times per
minute and will stop after 8 minutes. In case of
alarm, you can touch the Alarm button to cancel
door alarm, then the “ ” icon stops flickering and
keeps on, the buzzer sound will stop at the same
time.Also door alarm can be stopped by closing
all the doors.
To save energy, please avoid keeping doors open
for a long time when using refrigerator.
The control panel is shown in the diagram below.
Press and hold "Alarm" for 3 seconds to lock the
whole Control Panel including dispenser function
If Control panel is locked, the icon “ ” will be on,
and none of the buttons on the Control panel
work.To unlock the Control panel, please press
and hold “Alarm” for 3 seconds again.
button again, and the icon “ ”will be off.
NOTE: When the “ Ice Off” is on, it only turn off the
ice maker not the dispenser.
be illuminated, the fridge temperature setting will
items in the Fridge, please touch and hold this
You can touch “Ice Off” button to control the ice
maker. When the Child Lock is off, you can touch
the “ Ice Off ”button to turn off the ice maker, and
the icon “ ”will be illuminated. If you want to
turn on the ice maker, please touch the “ Ice Off ”

This appliance may be controlled remotely with a
When selecting the Super Freeze function,ensure
If Eco mode is off, the icon“ “ will go off and the
On the Super Freeze function,when you touch
and Super Freeze mode will be off.
convertible
To freeze fresh food activate
the Super Freeze function at
least 24 hours before placing
the food to complete pre-freezing
The temperature of the fridge is automatically
switched to 6°C and the freezer to -17°C.
temperature setting will revert back to the previous
setting.
If the water tank is not installed in place,the icon
will flicker.If the water tank is installed in place, the
icon “ ” will be extinguished. When the icon “ ”
flicker,long press the Eco button for 3 seconds to
cancel tank alarm and the icon will be extinguished.
If you need to make ice, you still need to put the
tank in place.
“ ” will be illuminated, the freezer temperature
setting will display -24°C.
Super Freeze can quickly lower the temperature and
freeze your food faster than usual. This can retain
more of the vitamins and nutrition in fresh food and
keep your food longer. Super Freeze automatically
switches off after 52 hours, and the freezer
temperature setting will revert back to the previous
setting. When the Super Freeze function is on, you
can touch “Freezer” to switch off the Super Freeze
function.
The Super Freeze is used to perform pre-freezing and
fast freezing in sequence of Freezer compartment
This function accelerates the freezing of fresh food
and,at the same time,protects foodstuffs already
stored from undesirable warming.
Demo mode is for store display,and it prevents the
refrigerator from generating cool air. In this Cooling
off Mode, the refrigerator may seem like it is working
but it will not make cool air. The indicators on the
control panel will show “OF”. To cancel this mode,
press and hold “ Alarm” and “ Wi-Fi” buttons at the
same time for 3 seconds and the buzzer will make
a long sound.
compartment temperature.
When the Child Lock is on,the dispenser will not
work.When the Child Lock is off,you can press the
“Cubed”or “Crushed” option to choose the type of
ice to be dispensed,and press the “Water” button
will activate the water mode.If you choose the
function of Cubed,the “ ” icon will be illuminated,
choose the fuction of Crushed the “ ” icon will be
illuminated,and the “ ” icon will be illuminated
when Water function be choosed.
the "Eco" button,"Eco" function will be activated,

Wi-Fi function
smart phone or a tablet computer.
If the appliance is not connected to the home
network, it will function like a regular appliance.
What do you need to connect the appliance?
•Signal from the local wireless network
(Wi-Fi) should be sufficiently strong in the
spot where the appliance is installed.
•Home network router has to be connected
to the internet, and the Wi-Fi function on the 
appliance should be activated. 
•The smart phone/tablet computer has to be

connected to the internet.
•Operating system on your smart phone/tablet
computer should be compatible with the
ConnectLife app.
•
•
there are no bottles in the freezer compartment.
Bottles and cans may explode.
You can touch this button to turn Eco mode on
and off. When you turn Eco mode on, the Eco
icon “ ” lights.
r$0//&$5"11-*"/$&508J'J
After activating the Wi-Fi function, connect
your device to your home router in order to
connect your appliance with the ConnectLife
mobile app.
Step 1: Set the appliance to normal operation.
Touch the Wi-Fi key for approximately 3 seconds.
"11-*"/$&8J'J45"5&
5IFSFBSFUISFF8J'JTUBUFTBTTIPXOCFMPX
ZPVDBOBDUJWBUFUIFEJTQMBZCPBSE
BDDPSEJOHUPUIFSFMFWBOUTUFQT

transmitting power in the operating frequency
radiator and your body.
- Transmitting frequency band(s) and max allowed
You entered network connection menu when
“ - - ”appears in the display.
Step 2: Touch the Fridge key to select “ ”
within 60 seconds.
Step 3: Touch the Wi-Fi key to confirm
the selection mode. The Wi-Fi symbol starts
blinking and the network of this appliance
is now open to connect to,for 5 miniutes.
Step 4: When the Wi-Fi symbol “ ” is on,
it means that the Wi-Fi connection is
successful. The display will return to normal.
Step 4: When the display returns to normal,
it means the PAIR connection is successful.
Step 4: After the device is unbound, it will
automatically enter the distribution network
state, the “ ” icon flashes, and the
distribution network time is up to 5 minutes.
r.6-5*64&31"*3"11-*"/$&
The appliance can be paired with your
mobile device. Simply pair another user to
your appliance. This requires, that your
appliance was already set up before and
is connected to your home network. If not,
go back and select SET UP APPLIANCE. 
Information!
We recommend downloading and
installing the mobile app and creating a
ConnectLife account before attempting to
set up the connection with your appliance.
ConnectLife App
The ConnectLife App is available to
download free of charge from the Apple
App Store or from the Google Play Store.
Installing the ConnectLife app
1. Go to the App Store (on Apple devices),
AppGallery (on Huawei devices) or 
Google Play Store (on Android devices) 
on your phone/tablet computer.
Step 1: Set the appliance to normal operation.
Touch the Wi-Fi key for approximately 3 seconds.
You entered network connection menu when
“ - - ”appears in the display.
Step 2: Touch the Fridge key to select “ ”
within 60 seconds.
Step 3: Touch the Wi-Fi key to confirm
miniutes.
selection mode. The PAIR network of this
appliance is now open to connect to, for 5
t6/#*/%"--64&340'"11-*"/$&
By activating this function, UIFVTFS
JOGPSNBUJPOTUPSFEJOUIFBQQMJBODFXJMMCF
EFMFUFE BOE the appliance will be removed
from all paired app user accounts.
Step 1: Set the appliance to normal operation.
Touch the Wi-Fi key for approximately 3 seconds.
Step 2: Touch the Fridge key to select
within 60 seconds.
You entered network connection menu when
“ - - ”appears in the display.
Step 3: Touch the Wi-Fi key to confirm the
selection mode to realize unbinding.
2. Search for “ConnectLife”.
3. Choose the ConnectLife app and install 
it on your smart phone/tablet computer.
"EE3FGSJHFSBUPSPO"11
4FMFDUĮ"EEBQQMJBODFT įPS Įį
 4FMFDUĮ3FGSJHFSBUPS į
 0QFOUIF$BNFSBPO"QQUPTDBOUIF 
BQQMJBODF4/DPEFCBSDPEF5IFCJU 
CBSDPEFDBOCFGPVOEVOEFSUIFEBUB 
QMBUFPOUIFJOTJEFPGUIFSFGSJHFSBUPS
 4FMFDUĮ4&561"11-*"/$& įGPMMPXUIF 
JOTUSVDUBOENBLFTVSF8J'JGVODUJPOPG 
UIF 
BQQMJBODFJTBDUJWBUFEUIFOTFMFDU
Į/FYU į
8IFOUIFBQQMJBODFIBTDPOOFDUFE 
UPUIFIPNFOFUXPSLBOEPUIFSVTFSTXBOU 
UPQBJSUIFTBNFBQQMJBODFUIFZDBO 
EJSFDUMZTFMFDUĮ1"*3"11-*"/$& įUPCJOE 
 5VSOPOCMVFUPPUIBTQSPNQUFEZPVBSF 
OPXQSFTFOUFEXJUIUIFBQQMJBODF
SFGSJHFSBUPS)*49999UIFOTFMFDUJU
 4FMFDUTFDVSF8J'JPQUJPOJOQVUUIF 
QBTTXPSEBOEDPOOFDU
 4FMFDUUIFMPDBUJPOPGBQQMJBODFBOETBWF
 "EETVDDFTTGVMZPVBSFOPXBCMFUPDPOUSPM
BQQMJBODFSFNPUFMZ
1.
“ ”


to 0 dbm.
- This equipment should be installed and operated
with minimum distance 0 cm between the

2400-2483,5
band(s)
MHz, less than or equal


8KSU\OTM8KVRGIOTMLXKK`KXJXG]KX
passes the rail support.
select what you want to dispense.
(1)
(2)
