Hisense HHU60CEEC Operating manual

User and Installation Manual
MODEL NO.:HHU60CEEC
Built-in Ceramic Hob

The appliance is not to be used by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction. children being supervised not to play with the
appliance.
WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of
electric shock, for hob surfaces of glass-ceramic or similar material which protect live
parts.
WARNING: a steam cleaner is not be used.
That the appliance is not intended to be operated by means of external timer or separated
remote-control system.
Danger of fire: Do not store items on the cooking surfaces.
CAUTION: The cooking process has to be supervised. A short term cooking process has
to be supervised continuously.
WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result
in a fire.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. children shall not play with the appliance.
cleaning and user maintenance shall not be made by children without supervision.
WARNING: The appliance and its accessible parts become hot during use.
Care should be taken to avoid touching heating elements.
12）Children less than 8 years of age shall be kept away unless continuously supervised.
13）WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may
result in fire.
14）NEVER try to extinguish a fire with water, but switch off the appliance and then cover
flame e.g. with a lid or a fire blanket.
WARNING
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●

WARNING
CAUTION: The cooking process has to be supervised. A short term cooking process has
to be supervised continuously.
WARNING: Danger of fire: do not store items on the cooking surfaces.
WARNING: Use only hob guards designed by the manufacturer of the cooking appliance
or indicated by the manufacturer of the appliance in the instructions for use as suitable or
hob guards incorporated in the appliance. The use of inappropriate guards can cause
accidents.
Power cord can’t accessible after installation.
●
●
●
●

SAFETY WARNINGS…………………………………………..……………1
PRODUCT OVERVIEW…..……….……..……….……………………..…...4
PRODUCT INFORMATION………….…….…….………………………4
BEFORE USING YOUR NEW CERAMIC HOB……………………………4
USING THE TOUCH CONTROLS……………………………………..……4
CHOOSING THE RIGHT COOKWARE…………………………………..…5
USING YOUR CERAMIC HOB……………………………………..………6
LOCKING THE CONTROLS…………………………………………………7
USING THE TIMER……………………………………………..……………8
COOKING GUIDELINES………………………………..……………………11
HEAT SETTINGS…..………..…………………..………..………..…..…….12
CARE AND CLEANING…………………………………………………………12
HINTS AND TIPS……………………………………………………………..…13
TECHNICAL SPECIFICATION………………………………………………..14
INSTALLATION……………………………………………………..…………14
WARRANTY CONDITIONS……………………………………………………19
CONTENTS

Your safety is important to us. Please read this information before using your cooktop.
Installation
Electrical Shock Hazard
•Disconnect the appliance from the mains electricity supply before carrying out any work
or maintenance on it.
•Connection to a good earth wiring system is essential and mandatory.
•Alterations to the domestic wiring system must only be made by a qualified electrician.
•Failure to follow this advice may result in electrical shock or death.
Cut Hazard
•Take care - panel edges are sharp.
•Failure to use caution could result in injury or cuts.
Important safety instructions
•Read these instructions carefully before installing or using this appliance.
•No combustible material or products should be placed on this appliance at any time.
•Please make this information available to the person responsible for installing the
appliance as it could reduce your installation costs.
•In order to avoid a hazard, this appliance must be installed according to these
instructions for installation.
•This appliance is to be properly installed and earthed only by a suitably qualified person.
•This appliance should be connected to a circuit which incorporates an isolating switch
providing full disconnection from the power supply.
•Failure to install the appliance correctly could invalidate any warranty or liability claims.
Operation and maintenance
Electrical Shock Hazard
•Do not cook on a broken or cracked cooktop. If the cooktop surface is break or
crack,switch the appliance off immediately at the mains power supply (wall switch) and
contact a qualified technician.
•Switch the cooktop off at the wall before cleaning or maintenance.
•Failure to follow this advice may result in electrical shock or death.
Health Hazard
•This appliance complies with electromagnetic safety standards.
Hot Surface Hazard
•During use, accessible parts of this appliance will become hot enough to cause burns.
SAFETY WARNINGS
1

•Do not let your body, clothing or any item other than suitable cookware contact the
ceramic glass until the surface is cool.
•Metallic objects such as knives, forks, spoons and lids should not be placed on the hob
surface since they can get hot
•Keep children away.
•Handles of saucepans may be hot to touch. Check saucepan handles do not overhang
other cooking zones that are on. Keep handles out of reach of children.
•Failure to follow this advice could result in burns and scalds.
Cut Hazard
•The razor-sharp blade of a cooktop scraper is exposed when the safety cover is
retracted.Use with extreme care and always store safely and out of reach of children.
•Failure to use caution could result in injury or cuts.
Important safety instructions
•Never leave the appliance unattended when in use. Boilover causes smoking and greasy
spillovers that may ignite.
•Never use your appliance as a work or storage surface.
•Never leave any objects or utensils on the appliance.
•Never use your appliance for warming or heating the room.
•After use, always turn off the cooking zones and the cooktop as described in this manual
(i.e. by using the touch controls).
•Do not allow children to play with the appliance or sit, stand, or climb on it.
•Do not store items of interest to children in cabinets above the appliance. Children
climbing on the cooktop could be seriously injured.
•Do not leave children alone or unattended in the area where the appliance is in use.
•Children or persons with a disability which limits their ability to use the appliance should
have a responsible and competent person to instruct them in its use. The instructor
should be satisfied that they can use the appliance without danger to themselves or their
surroundings.
•Do not repair or replace any part of the appliance unless specifically recommended in
the manual. All other servicing should be done by a qualified technician.
•Do not use a steam cleaner to clean your cooktop.
•Do not place or drop heavy objects on your cooktop.
•Do not stand on your cooktop.
•Do not use pans with jagged edges or drag pans across the Induction glass surface as
this can scratch the glass.
•Do not use scourers or any other harsh abrasive cleaning agents to clean your cooktop,
as these can scratch the ceramic glass.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
•This appliance is intended to be used in household and similar applications such as: -
staff kitchen areas in shops, offices and other working environments; -farm houses; -by
clients in hotels, motels and other residential type environments ; -bed and breakfast
type environments.
2

•WARNING: The appliance and its accessible parts become hot during use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless continuously supervised.
•This appliance can be used by children aged from 8 years and above and persons with
reduced physical,sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
•Children shall not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
•WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result
in fire.NEVER try to extinguish a fire with water, but switch off the appliance and then
cover flame e.g. with a lid or a fire blanket.
•WARNING: Danger of fire: do not store items on the cooking surfaces.
•Warning: If the surface is cracked, switch off the appliance to avoid the possibility of
electric shock, for hob surfaces of glass-ceramic or similar material which protect live
parts
•A steam cleaner is not to be used.
•The appliance is not intended to be operated by means of an external timer or separate
remote-control system.
Congratulations on the purchase of your new Ceramic Hob.
We recommend that you spend some time to read this Instruction / Installation Manual in
order to fully understand how to install correctly and operate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruction /
Installation Manual for future reference.
3

PRODUCT OVERVIEW
Top View
1
23
5
4
6
1. max. 1800 W zone
3. max. 1800 W zone
5. Glass plate
2. max. 1200 W zone
4. max. 1200 W zone
6. Control panel
Control Panel
1 1 2 1 1 3 4
1. Power regulating key
2. Timer regulating key
3. Keylock control
4. ON/OFF control
4

PRODUCT INFORMATION
The microcomputer ceramic hob can meet different kinds of cuisine demands because of
resistance wire heating, micro-computerized control and multi-power selection, really the
optimal choice for modern families.
The ceramic hob centers on customers and adopts personalized design. The hob has safe
and reliable performances, making your life comfortable and enabling to fully enjoy the
pleasure from life.
BEFORE USING YOUR NEW CERAMIC HOB
•Read this guide, taking special note of the ‘Safety Warnings’ section.
•Remove any protective film that may still be on your ceramic hob.
USING THE TOUCH CONTROLS
•The controls respond to touch, so you don’t need to apply any pressure.
•Use the ball of your finger, not its tip.
•You will hear a beep each time a touch is registered.
•Make sure the controls are always clean, dry, and that there is no object (e.g. a utensil or
a cloth) covering them. Even a thin film of water may make the controls difficult to operate.
CHOOSING THE RIGHT COOKWARE
Do not use cookware with jagged edges or a curved base.
5

Make sure that the base of your pan is smooth, sits flat against the glass, and is the same
size as the cooking zone. Always centre your pan on the cooking zone.
Always lift pans off the ceramic hob – do not slide, or they may scratch the glass.
USING YOUR CERAMIC HOB
To start cooking
•After power on, the buzzer beeps once, all the indicators light up for 1 second then go
out, indicating that the ceramic hob has entered the state of standby mode.
1.Touch the ON/OFF control. all the indicators
show “-“
2.Place a suitable pan on the cooking zone that
you wish to use.
•Make sure the bottom of the pan and the surface
Of the cooking zone are clean and dry.
3.Select a heat setting by touching the “-“ or “+” control.
•If you don’t choose a heat setting within 1
minute, the Induction hob will automatically switch off.
You will need to start again at step 1.
•You can modify the heat setting at any time during cooking.
6

When you have finished cooking
1a. Turn the cooking zone off by scrolling down to“0” or touching “-” and “+” control
together. Make sure the display shows“0”
1b. Turn the whole cooktop off by touching the ON/OFF control.
2. Beware of hot surfaces
H will show which cooking zone is hot to touch. It will disappear when the surface has
cooled down to a safe temperature. It can also be used as an energy saving function if you
want to heat further pans, use the hotplate that is still hot.
LOCKING THE CONTROLS
•You can lock the controls to prevent unintended use (for example children accidentally
turning the cooking zones on).
•When the controls are locked, all the controls except the ON/OFF control are disabled.
To lock the controls
Touch the keylock control. The timer indicator will show “Lo “
To unlock the controls
1.Make sure the ceramic hob is turned on.
2.Touch and hold the keylock control for a while.
3.You can now start using your ceramic hob.
When the hob is in the lock mode, all the controls are disable except the
ON/OFF,you can always turn the ceramic hob off with the ON/OFF control in an
emergency, but you shall unlock the hob first in the next operation.
7

Residual Heat Warning
When the hob has been operating for some time, there will be some residual heat. The
letter “ H ”appears to warn you to keep away from it.
Auto Shutdown
safety feature of the hob is auto shut down. This occurs whenever you forget to switch off
a cooking zone. The default shutdown times are shown in
the table below:
USING THE TIMER
You can use the timer in two different ways:
•You can use it as a minute minder. In this case, the timer will not turn any cooking zone off
when the set time is up.
•You can set it to turn one or more cooking zones off after the set time is up.
•You can set the timer up to 99 minutes.
Using the Timer as a Minute Minder
If you are not selecting any cooking zone
1.Make sure the cooktop is turned on.
Note: you can use the minute minder even if you’re not selecting any cooking zone.
2.Touch”+” the controls of the timer. The minder
indicator will start flashing and “10” will show in
the timer display.
3.Set the time by touching the “-“ or ”+” control of the timer
Hint: Touch the “-“ or ”+” control of the timer
once to decrease or increase by 1 minute.
Touch and hold th“-“ or “+” control of the timer
to decrease or increase by 10 minutes.
4.Touching the “-“ and ”+” together, the timer
is cancelled, and the”00” will show in the minute display.
Pow er level 123456789
Default w orking timer (hour) 2 2 2 2 2 2 2 2 2
8

5.When the time is set, it will begin to count down
immediately. The display will show the remaining
time and the timer indicator will flash for 5 seconds.
6.Buzzer will bips for 30 seconds and the timer
indicator shows “- - “ when the setting time finished.
Setting the timer to turn one or more cooking zones off
If the timer is set on one zone:
1.Touch the”-“ or ”+” of the corresponding cooking
zone you want to set the timer for .
2.Set the time by touching the “-“ or “+” control of
the timer.
Hint: Touch the “-“ or “+” control of the timer once
will decrease or increase by 1 minute.
Touch and hold the ”-“ or “+”control of the timer will
decrease or increase by 10 minutes.
3.Touching the ”-“ and “+” together, the timer is
cancelled, and the ”00” will show in the minute display.
4.When the time is set, it will begin to count down
immediately. The display will show the remaining
time and the timer indicator flash for 5 seconds.
NOTE: The red dot next to power level indicator
will illuminate indicating that zone is selected.
9

5.When cooking timer expires, the corresponding
cooking zone will be switch off automatically.
Other cooking zone will keep operating if they are turned on previously.
If the timer is set on more than one zone:
1.When you set the time for several cooking zones simultaneously, decimal dots of the
relevant cooking zones are on. The minute display shows the min. timer. The dot of the
corresponding zone flashes.
(set to 15 minutes) (set to 45 minutes)
2.Once the countdown timer expires, the corresponding zone will switch off. Then it will
show the new min. timer and the dot of corresponding zone will flash.
(set to 30 minutes)
10

COOKING GUIDELINES
Cooking Tips
•When food comes to the boil, reduce the power setting.
•Using a lid will reduce cooking times and save energy by retaining the heat.
•Minimise the amount of liquid or fat to reduce cooking times.
•Start cooking on a high setting and reduce the setting when the food has heated through.
Simmering, cooking rice
•Simmering occurs below boiling point, at around 85˚C, when bubbles are just rising
occasionally to the surface of the cooking liquid. It is the key to delicious soups and tender
stews because the flavours develop without overcooking the food. You should also cook
egg-based and flourthickened sauces below boiling point.
•Some tasks, including cooking rice by the absorption method, may require a setting
higher than the lowest setting to ensure the food is cooked properly in the time
recommended.
Searing steak
To cook juicy flavoursome steaks:
1.Stand the meat at room temperature for about 20 minutes before cooking.
2.Heat up a heavy-based frying pan.
3.Brush both sides of the steak with oil. Drizzle a small amount of oil into the hot pan and
then lower the meat onto the hot pan.
4.Turn the steak only once during cooking. The exact cooking time will depend on the
thickness of the steak and how cooked you want it. Times may vary from about 2 – 8
minutes per side. Press the steak to gauge how cooked it is
– the firmer it feels the more ‘well done’ it will be.
5.Leave the steak to rest on a warm plate for a few minutes to allow it to relax and become
tender before serving.
For stir-frying
1.Choose an ceramic compatible flat-based wok or a large frying pan.
2.Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking
large quantities, cook the food in several smaller batches.
3.Preheat the pan briefly and add two tablespoons of oil.
4.Cook any meat first, put it aside and keep warm.
5.Stir-fry the vegetables. When they are hot but still crisp, turn the cooking zone to a lower
setting, return the meat to the pan and add your sauce.
6.Stir the ingredients gently to make sure they are heated through.
7.Serve immediately.
11

HEAT SETTINGS
CARE AND CLEANING
Heat setting Suitability
1 - 2 •delicate warming for small amounts of food
•melting chocolate, butter, and foods that burnquickly
•gentle simmering
•slow warming
3 - 4 •reheating
•rapid simmering
•cooking rice
5 - 6 •pancakes
7 - 8 •sauteing
•cooking pasta
9•stir-frying
•searing
•bringing soup to the boil
•boiling water
What? How ? Important!
Everyday soiling on
glass (fingerprints,
marks, stains left by
food or non-sugary
spillovers on the glass)
1. Switch the power to the
cooktop off.
2. Apply a cooktop cleaner while
the glass is still warm (but not
hot!)
3. Rinse and wipe dry with a
clean cloth or paper towel.
4. Switch the power to the
cooktop back on.
•When the power to the cooktop is
switched off, there will be no ‘hot
surface’ indication but the cooking zone
may still be hot! Take extreme care.
•Heavy-duty scourers, some nylon
scourers and harsh/abrasive cleaning
agents may scratch the glass. Always
read the label to check if your cleaner or
scourer is suitable.
•Never leave cleaning residue on the
cooktop: the glass may become
stained.
12

Boilovers, melts, and
hot sugary spills on
the glass
Remove these immediatelywith a fish
slice, palette knife or razor blade
scraper suitable for ceramic glass
cooktops, but beware of hot cooking
zone surfaces:
1. Switch the power to the
cooktop off at the wall.
2. Hold the blade or utensil at a 30°
angle and scrape the soiling or spill
to a cool area of the cooktop.
3. Clean the soiling or spill up with a
dish cloth or paper towel.
4. Follow steps 2 to 4 for
‘Everyday soiling on glass’
above.
•Remove stains left by melts
and sugary food or spillovers
assoon as possible. If left to
cool on the glass, they may be
difficult to remove or even
permanently damage the glass
surface.
•Cut hazard: when the safety
cover is retracted, the blade in a
scraper is razor-sharp. Use with
extreme care and always store
safely and out of reach of
children.
Spillovers on
the touch
controls
1. Switch the power to the
cooktop off.
2. Soak up the spill
3. Wipe the touch control area with a
clean damp sponge or cloth.
4. Wipe the area completelydry with a
paper towel.
5. Switch the power to the
cooktop back on.
•The cooktop may beep and turn
itself off, and the touch controls
may not function while there is
liquid on them. Make sure you
wipe the touch control area dry
before turning the cooktop back
on.
Hints and Tips
Problem Possible causes What to do
The cooktop
cannot Be turned
on.
No power. Make sure the cooktop is connected
to the power supply and that it is
switched on.
Check whether there is a power
outage in your home or area. If
you’ve checked everything and the
problem persists, call a qualified
technician.
The touch controls are
unresponsive.
The controls are locked. Unlock the controls. See section
‘Using your ceramic cooktop’ for
instructions.
The touch controls are
difficult to operate.
There may be a slight film of water
over the controls or you may be
using the tip of your finger when
touching the
controls.
Make sure the touch control area is
dry and use the ball of your finger
when touching the controls.
13

The glass is
being
scratched.
Rough-edged cookware.
Unsuitable, abrasive scourer or
cleaning products being used.
Use cookware with flat and smooth
bases. See ‘Choosing the right
cookware’.
See ‘Care and cleaning’.
Some pans make This may be caused by the This is normal for cookware and
crackling or clicking
noises.
construction of your cookware
(layers of different metals
does not indicate a fault.
vibrating differently).
Cooking Hob HHU60CEEC
Cooking Zones 4 Zones
Supply Voltage 220-240V~/380-415V 2N~
Installed Electric Power 6000W
Product Size L×W×H(mm) 590X520X55
Building-in Dimensions A×B (mm) 560X490
TECHNICAL SPECIFICATION
Weight and Dimensions are approximate. Because we continually strive to
improve our products we may change specifications and designs without prior
notice.
INSTALLATION
Selection of installation equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 50mm space shall be preserved
around the hole.
Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant
work surface material to avoid larger deformation caused by the heat radiation from the
hotplate. As shown below:
14

L(mm) W(mm) H(mm) D(mm) A(mm) B(mm) X(mm)
590 520 55 51 560 490 50 mini
Under any circumstances, make sure the ceramic cooker hob is well ventilated and the air
inlet and outlet are not blocked. Ensure the ceramic cooker hob is in good work state. As
shown below
Note: The safety distance between the hotplate and the cupboard above the
hotplate should be at least 760mm.
15

locating the fixing brackets
The unit should be placed on a stable, smooth surface (use the packaging). Do not apply
force onto the controls protruding from the hob.
Fix the hob on the work surface by screw four brackets on the bottom of hob (see picture)
after installation.
Adjust the bracket position to suit for different work surface’s thickness.
Cautions
1.The ceramic cooker hob must be installed by qualified personnel or technicians. We
have professionals at your service. Please never conduct the operation by yourself.
2.The ceramic cooker hob shall not be mounted to cooling equipment, dishwashers and
rotary dryers.
3.The ceramic cooker hob shall be installed such that better heat radiation can be ensured
to enhance its reliability.
4.The wall and induced heating zone above the work surface shall withstand heat.
5.To avoid any damage, the sandwich layer and adhesive must be resistant to heat.
6.A steam cleaner is not to be used.
7.This ceramic can be connected only to a supply with system impedance no more than
0.427 ohm. In case necessary, please consult your supply authority for system
impedance information.
16
