Hisense LCD2004US User manual

English
LCD2004US
Part No. IES050704
USER MANUAL
LCD COLOR TV
R
LANGUAGE ENGLISHLANGUAGE ENGLISH

Important safety instructions ...... .......... .......... .......... .......... .......... .......... .......... ..........
Brief product overview ..................................... .......... .......... .......... .......... .......... .....
Learning about your new TV ........................... ......... .......... .......... .......... .......... ..........
Selecting a location for the TV............................... .......... .......... .......... .......... .......... .....
Connecting your TV......................................... .......... .......... .......... .......... .......... .....
Connecting audio/visual equipment .............. .......... .......... .......... .......... .......... ..........
Connecting the PC or Notebook ........................ .......... .......... .......... .......... .......... .....
Connecting to an Aerial / Cable antenna............... .......... .......... .......... .......... .......... .....
Preparation for using your new TV using the remote control .......... .......... .......... .......... ..........
Preparing the remote control for use.................... .......... .......... .......... .......... .......... .....
Shortcut keys operation .................................... .......... .......... .......... .......... .......... .....
Menu operation............................................. .......... .......... .......... .......... .......... .....
Using the Picture Parameters menu ................... .......... .......... .......... .......... .......... ....
Using the Audio Setting menu ........................ .......... .......... .......... .......... .......... .....
Using the Geometry menu ............................ .......... .......... .......... .......... .......... .....
Using the General Settings menu ...................... .......... .......... .......... .......... .......... .....
Using the Search menu ................................ .......... .......... .......... .......... .......... .....
Appendix ................................................... .......... .......... .......... .......... .......... .....
Cleaning and care ...................................... .......... .......... .......... .......... .......... .....
Trouble shooting ....................................... .......... .......... .......... .......... .......... .....
Specifications .......................................... .......... .......... .......... .......... .......... .....
This is an IEC safety class product and must be grounded for safety.
SAFETY CLASS
Please read all the safety and operating instructions carefully before you begin.
CONTENTS
2
4
6
7
7
7
8
8
10
10
11
14
14
14
15
15
18
19
19
20
21
-1-
LANGUAGE ENGLISHLANGUAGE ENGLISH

-2-
Important safety instructions
CAUTION
CAUTION: TO REDUCE THE RISK OF ELEC-
TRIC SHOCK, DO NOT REMOVE
COVER (OR BACK) .NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flashwith arrowhead symbol within an
equilateral triangle isintended to alertthe user tothe
presence of uninsulateddangerous voltage withinthe
product s enclosure thatmay be ofsufficient magnitude
to constitute arisk of electricshock.
'
The exclamation pointwithin an equilateraltriangle is
intended to alertthe user tothe presence of important
operating and maintenance( servicing )instructions in
the literature accompanyingthe set.
CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLYAPPROVED BYTHE PARTY
RESPONSIBLE FOR COMPLIANCE WITH THE FCC RULES COULD VOID THE
USER S AUTHORITYTO OPERATE THIS EQUIPMENT.'
WARNING: TO PREVENT FIRE OR SHOCKHAZARD, DO NOTEXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
1. READ THESEINSTRUCTIONS
All the safetyand operating instructionsshould be read before the productis operated.
2. KEEP THESE INSTRUCTIONS
Retain safety andoperating instructions forfuture reference.
3. HEEDALL WARNINGS
Adhere to allwarnings on theproduct and inthe operating instructions.
4. FOLLOWALL INSTRUCTIONS
Follow all operatingand use instructions.
5. DO NOTUSE THIS APPARATUS NEAR WATER
Do not usethe product nearwater. Forexample, near abathtub, washbowl, kitchensink, or laundrytub, in awet
basement, or neara swimming pool,and the like.
6. CLEAN ONLY WITHDRY CLOTH
Unplug the TV from thewall outlet before cleaning. Do notuse liquid cleaners or aerosol cleaners.Clean only witha
dry cloth.
7. DO NOTBLOCK ANYVENTILATION OPENINGS
Slots and openingsin the cabinetback or bottomare provided forventilation, to ensurereliable operation ofthe
TV and toprotect it fromoverheating. These openings must notbe blocked orcovered. The openings should never
be blocked byplacing the producton a bed,sofa, rug, orother similar surface.This product should never beplaced
near or overa radiator orheat resource. This product shouldnot be placedin a built-ininstallation such asa bookcase
or rack unlessproper ventilation isprovided or the manufacturer's instructions havebeen adhered to.
8. DO NOTINSTALL NEAR ANYHEAT SOURCES
This product shouldbe situated awayfrom heat sources such as radiators,stoves, or other products (including amplifiers)
that produce heat.
9. DO NOTDEFEAT THE SAFETY PURPOSE OF THEPOLARIZED OR GROUNDING-TYPEPLUG
A polarizedplug has twoblades with one wider than theother.A grounding-type plug hastwo blades anda third grounding
prong. The wide blade orthe third prongis provided foryour safety. If theprovided plug doesnot fit into your outlet, consult
an electrician forreplacement of theobsolete outlet.
10. PROTECT THEPOWER CORD FROMBEING WALKEDON OR PINCHEDPARTICULARLY AT PLUGS, CONVENIENCE
RECEPTACLES, AND THE POINT WHERE THEYEXIT FROM THEAPPARATUS.
11. ONLY USEATTACHMENTS/ACCESSORIES SPECIFIED BYTHE MANUFACTURER.
LANGUAGE ENGLISHLANGUAGE ENGLISH

S3126A
-3-
Important safety instructions
12. USE ONLY WITHCART,STAND, TRIPOD, BRACKET ORTABLE SPECIFIED BY
THE MANUFACTURER,OR SOLD WITHTHE APPARATUS. WHEN ACART IS USED,
USE CAUTION WHENMOVING THE CART/APPARATUS COMBINATION TO AVOID
INJURY FROMTIP-OVER.
Do not placethis TV on a unstablecart, stand, tripod,bracket ,or table.The TV may
fall, causing seriousinjury to someone,and serious damageto the appliance.An TV
and cart combinationshould be movedwith care. Quickstops, excessive force,and
uneven surfaces maycause the productand cart combinationto overturn.
POWER SOURCE
This TV should be operatedonly from thetype of powersource indicated onthe marking label.If you are not sure ofthe type
of power supplyto your home,consult your appliancedealer or localpower company .For TVs intended to operatefrom
battery power,or other sources,refer to theoperating instructions.
16. POWER CORDPROTECTION
Power-supply cords shouldbe routed sothat they arenot likely tobe walked onor pinched byitems placed uponor against
them, paying particularattention to cordsat plugs, conveniencereceptacles, and thepoint where theyexit from theappliance.
17. OUTDOORANTENNA GROUNDING
If an outsideantenna or cablesystem is connectedto
the TV, be sure the antenna orcable system isgrounded
to provide someprotection against voltagesurges
and built-up staticcharges. Section 810of the National
Electrical Code,ANSI/NFPANO.70, provides
information with respectto proper grounding
of the mastand supporting structure,grounding
of the lead-inwire to anantenna discharge unit,
size of groundingconductors, location of
antenna discharge unit,connection to grounding
electrodes, and requirementsfor the grounding
electrode (Fig.A).
18. LIGHTNING
For added protectionfor this TV receiver during
a lightning storm,or when itis left unattendedand
unused for longperiods of time,unplug it fromthe wall outletand disconnect theantenna or cable system. This will prevent
damage to theTV due to lightning andpower line surges.
19. POWER LINES
An outsideantenna system shouldnot be locatedin the vicinityof overhead powerlines, or other electric light orpower
circuits, or whereit can fallinto such powerlines or circuits.When installing anoutside antenna system, extreme care should
be taken tokeep from touchingsuch power linesor circuits ascontact with themmight be fatal.
20. OVERLOADING
Do not overloadwall outlets andextension cords asthis can resultin a riskof fire orelectric shock.
21. OBJECTAND LIQUID ENTRY
Never push objectsof any kindinto this TV through openingsas they maytouch dangerous voltagepoints or shortout parts
that could resultin fire orelectric shock. Neverspill liquid ofany kind intothe TV.
22. SERVICING
Do not attemptto service thisTV yourself as opening orremoving covers mayexpose you todangerous voltage orother
hazards. Refer allservicing to qualifiedservice personnel.
23. REPLACEMENT PARTS
When replacement partsare required, besure the service technician uses replacementparts specified bythe manufacturer
that have thesame characteristics asthe original part.Unauthorized substitutions mayresult in fire,electric shock, injuryto
persons or otherhazards.
24. SAFETY CHECK
Upon completion ofany service orrepairs to thisTV,ask the servicetechnician to perform routine safety checksto determine
that the TV is inproper operating condition.
13. UNPLUG THISAPPARATUS DURING LIGHTNINGSTORMS OR WHEN UNUSED
FOR LONG PERIODSOF TIME.
For added protectionfor this TV receiver duringa lightning storm,or when itis left
unattended and unusedfor long periodof time, unplug it from thewall outlet and
disconnect the antennaor cable system.This will prevent damage tothe TV due to
lightning and powerline surges.
14. REFERALL SERVICING TO QUALIFIED SERVICE PERSONNEL.SERVICING IS REQUIRED WHEN THEAPPARATUS
HAS BEEN DAMAGEDIN ANYWAY,SUCH AS POWER-SUPPLYCORD OR PLUGIS DAMAGED, LIQUIDHAS BEEN
SPILLED OR OBJECTSHAVE FALLEN INTO THEAPPARATUS, THE APPARATUS HAS BEENEXPOSED TO RAIN OR
MOISTURE, DOES NOTOPERATE NORMALLY, OR HASBEEN DROPPED.
15.
ANTENNA LEAD
IN WIRE
ANTENNA
DISCHARGE UNIT
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
EXAMPLE OF ANTENNA GROUNDINGAS PER
NATIONAL ELECTRICAL CODE
FIGURE A
S2898A
GROUNDING WIRES
LANGUAGE ENGLISHLANGUAGE ENGLISH

Brief product overview
1.Connection
Connect the antenna lead or CATV cable or external equipment (such as Antenna, Cable TV, VCD, DVD,
VCR, Set top box, etc.) to the corresponding terminals or interface on the TV rear (please refer to the owner s
manual of the equipment to be connected as well) and confirm that the signal source is available and works.
normally.
2.The remote control
Open the back battery cover on the remote control and insert 2 x 'AAA' size batteries, noting the correct
polarities marked inside the battery compartment . Next close the battery cover.
-4-
OKOK
11
44
2233
77
5566
8899
00
SOURCE SCAN
CCD PARENT LOCK
MENU
SAP
MUTE
P.MODE
S.MODE
RECALL
VOL CH
SLEEP DISPLAY
SCAN: Scan availablechannels
POWER: Power on/off
SOURCE: Select oneof five inputsignal sources
PARENT: Parental control function
LOCK: Set childlock
CCD: Closed captionfunction
SAP: SAP/stereo/mono audio setting selection
MUTE: Mute thesound
MENU: Call upthe main menu
RECALL: Return toprevious channel
S.MODE: Select thesound mode
P.MODE: Select thepicture mode
VOL+/-:Volume up/down
CHANNEL NUMBER: Direct Channelselection
SLEEP: Set thesleep timer
DISPLAY: Display currentStatus information
CH+/-: Channel up/down
/
/
OK: Confirm selectedfunction or returnto the previous menu
: Cursor up/down
: Select oradjust from aparticular menu
AC IN
PC IN
AV OUT
ANT.IN
L R
AUDIO IN 1
S-VIDEOVIDEO
COMPONENT
Y P/C P /C
B B R R
L R
AUDIO IN 2
LANGUAGE ENGLISHLANGUAGE ENGLISH

Note 2: For more detailed information, please refer to the pages that follow.
Note 1: Allbuttons mentioned above are on the remote control unless indicated otherwise.
-5-
3.Switching on/off
1) Connect the TV to power outlet. Switch on the power switch located on the back of the TV (See page 6,
item 21 for location), if the power indicator is red, it means the TV is off now. You need to press the
POWER switch on the TV or the POWER button on the remote control to turn on the TV, and the power
indicator will light up in blue.
2) Press the power switch or the POWER button on the remote control again to turn off the TV.
4.Signal source selection
Press the number [1-9]button or CH+ or CH- button to select TV input;press the SOURCE button to selectTV,
Video, S-Video,VGA,Component.
6.Channel search
In order to accessthis setting, you needto be in theAntenna (TV)source mode
(press SOURCE button repeatedly).
1) Press theMENU button to enter themain menu.
2) Press the button to selectthe itemSearch, and press the button toenter Search menu.
3) Press the button to selectthe itemAuto Search.
4) Press the button to start auto searching for all available channels.
5)Once all the availablechannels have been memorized,you are now ableto use the numericalbuttons
or channel + / - buttonsto watch the channelnumber you desire.
7.Picture adjustment
1) Press the MENU button to enter the main menu.
2) Press the button to select the item Picture Parameters,
and press the button to enter Picture Parameters menu.
3) Press the button to select the item you want to adjust.
4) Press the button to adjust the level.
5) Press OK button to confirm your selection. Press OK again to exit from the menu.
8.Audio adjustment
1) Press the MENU button to enter the main menu.
2) Press the button to select the item Audio Settings,
and press the button to enter Audio Settings menu.
3) Press the button to select the item you want to adjust.
4) Press the button to adjust the level.
5) Press OK button to confirm your selection. Press OK again to exit from the menu.
[ or ]
[ or ]
[ or ]
[ or ]
[ or ]
[ or ]
[ ]
[ ]
[ ]
[ or ]
[ or ] [ ]
quAlier
Treble
Bass
Balance
HeadPhone
Equalizer
50
50
50
Audio Settings
Equalier
Britghtness
Contrast
Saturation
Sharpness
Color Temp Normal
50
50
50
50
Picture Parameters
Hue
50
5.Air/Cable selection
In order to accessthis setting, you needto be in theAntenna (TV)source mode (press SOURCEbutton repeatedly).
You can select thesignal receiving method accordingto the following steps:
1) Press theMENU button to enter themain menu.
2) Press the button to selectthe item Search and press the
buttonto enterSearch menu.
3) Press the button to selectthe item Tuning Mode.
4) Press the button to change the item among Air, Cable.
5) Press OK button to confirm your selection. Press OK again to exit fromthe menu.
[ or ]
[ ]
[ or ]
[ ]
LANGUAGE ENGLISHLANGUAGE ENGLISH

-6-
Learning about your new TVLearning about your new TV
Youcan operate yourTV by using the buttonson the front panel or theremote control. Theterminals on the
side and therear panel provideall the connectionsyou will needto connect otherequipment to yourTV.
Side Controls /
Connections
Note: The above figures are for reference only. Please refer to the actual connection jacks to determine their
appearance.
Rear Connections
88
19
MENU
CH
VOL
VOL
CH
1
10
SOURCE
7
22
AC IN
PC IN
AV OUT
ANT.IN
L R
AUDIO IN 1
S-VIDEOVIDEO
COMPONENT
Y P/C P /C
B B R R
L R
AUDIO IN 2
20 21
LANGUAGE ENGLISHLANGUAGE ENGLISH

-7-
Learning about your new TV
Selecting a location for the TV
Place the TV on the floor or on a sturdy platform in a location where light does not directly hit the screen.
Caution: Do not plug the TV in until you have finished connecting all of your equipment.
Connecting your TV
Follow the instructions below to hookup a VCR, DVD, satellite receiver, camcorder, audio amplifier, etc. (Cables not
included). Use the SOURCE button on your remote control to select signal sources.
Connecting audio/visual equipment
Remote control sensor
POWER button (standby)
POWER indicator
Channel up / cursor up
Channel down / cursor down
Volume up / cursor right
Volume down / cursor left
TV / AV / PC input select
MENU button
AV audio input 1 L
CATV antenna input
AV Video input
S-Video input
Y PB/CB PR/CRinput (Component)
AV audio input 1 R
Headphone jack
AC IN
PC IN
ANT.IN
L R
AUDIO
S-VIDEOVIDEO
YPB/CBPR/CR
CC
VCD, DVD, STB
Pb Pr
Connection Details:
Connect using AV inputs (RCAComposite)
- Use 1, 2,4
Connect using S-Video inputs
- Use 1, 2,3
Connect using Y Pb/CbPr/Cr inputs (Component)
- Use 1, 2,5, 6, 7
27 4
3
16
5
AV outputs
20
9
AV audio input 2 L
AV audio input 2 R
PC VGAinput
21
22
POWER Plug
Power switch
AV OUT
L R
AUDIO IN 2
LANGUAGE ENGLISHLANGUAGE ENGLISH

Connecting your TV
-8-
To enjoy the terrestrial signal transmitted by your local TV station, you need an indoor or outdoor aerial (not supplied).
Perfect picture quality requires a good signal and generally means that an outdoor aerial must be implemented. The
exact type and location of the aerial will depend on your particular area. Consult your local dealer or service
personnel for best advice. If you are a subscriber of your local CATV provider, the outdoor or indoor aerial is not needed.
Connect the equipment as follows:
REAR VIEW
Connecting to an Aerial / Cable antenna
PC/NB
To VGA
RGB line
You can use your TV as a monitor for connecting through the PC IN (VGA) connection jack. your PC or Notebook by Connect
the devices as shown below.
Connecting to a Personal Computer or Notebook
NOTE: 1) Headphones are not included.
2) No sound will be heard from the
main unit speakers when a
headphone mini-plug is connected
into the headphone jack.
The refresh rate of your PC & Notebook must be adjusted to 60Hz or below.
NOTE:
PC IN
ANT.IN
AERIAL SOCKET
Loosen the screw Insert the feeder in Tighten the screw
Plug(not supplied)
Adaptor (not supplied)
The signal comes from:
An outdoor antenna
An indoor antenna
CATV net
TWIN-LEAD FEEDER(300 W)
COAXIAL CABLE (75W)
(cable not included)
Headphone
LANGUAGE ENGLISHLANGUAGE ENGLISH

- 9 -
Connecting to a cable converter box
This television has an extended tuning range and can tune into most cable channels without using a cable
company suppliedconverter box.Some cablecompanies offerpremium pay channels in which the signal is
scrambled. Descramblingthese signals for normal viewing requires the use of a descrambler device which
is generally provided by the cable company.
For subscribers to Basic Cable TV Service
For basic cable service, you do not require a Converter/Descrambler box. Connect the CATV 75 ohm Coaxial
Cable directly to the Antenna Jack on the back of the television.
For subscribers to Scrambled Cable TV Service
If you subscribe to a cable service which requires the use of a Converter/Descrambler box, connect the
incoming cable to the Converter/Descrambler box and connect the output of the box to the Antenna Jack
on the back of the television. Follow the connections shown below. Set the television to the output of the
Converter/Descrambler box (usually channel 3 or 4)and use the Converter/Descrambler box remote control
to select channels.
For Subscribers to Unscrambled Basic Cable with Scrambled Premium Channels
If you subscribe to a cable service in which basic cable channels are unscrambled and premium channels
require the use of a Converter/Descrambled box, you may wish to use a two-set signal splitter (sometimes
Called two set coupler) and an A/B Switch box from the cable installer or an electronics supply store.
Follow the connections shown below. With the switch in the B position, you can directly tune into any
nonscrambled channels on your TV. With the switch in the Aposition, tune your TV to the output of the
Converter/Descrambler box (usually channel 3 or 4) and use the box to tune into scrambled channels.
Note:
When you use a converter box with your TV, there may be TV features that you cannot
access using the remote control that's provided with the converter box. Therefore keep
the TV remote handy.
Preparation for using your new TV
Converter/Descrambler
Converter/Descrambler
Splitter A/B Switch
ANT 75¦¸
LANGUAGE ENGLISHLANGUAGE ENGLISH

Preparing the remote control for use
Installing the remote control batteries
1. Open the battery cover on the back of the remote control.
2. Insert two AAA size(1.5V) batteries (included). Match the + and - signs inside the batteries to the signs
on the battery compartment.
Using the remote control
-10-
3. Close the battery cover.
Note:
1.Dispose of your batteries in a designated disposal area. Do not throw your batteries into fire.
2.Do not mix battery types or combine used batteries with new ones.
3.Remove dead batteries immediately to prevent battery acid from leaking into the battery compartment.
4.If you do not intend to use the remote control for a long time, remove the batteries.
5.The effective range of remote control is suggested in the figure below.
+
+
+
+
6m
30
30
6m
30
30
LANGUAGE ENGLISHLANGUAGE ENGLISH

Shortcut keys operation
Connecting POWER
1. Turn on the power of the connected video equipment.
2 P
3. The sound signal of all input signals except TV is inputted through the same AUDIO INPUT terminals.
ress the SOURCE button to toggle between the source inputs. Select among TV, Video, S-Video, VGA
or Component.
DISPLAY INPUT TERMINAL
TV
Component
VGA
Antenna
Y PB/CB PR/CR
PC IN(D-Sub15)
Selecting the signal source
Press POWER on the remote control to turn off the LCD TV. The POWER indicator will turn red.
Press POWER again to turn the LCD TV back on. The POWER indicator will turn blue.
ON/OFF Standby
ComponentComponent
VGAVGA
S-VideoS-Video
VideoVideo S-Video S-Video
NOTE: The explanation about Video, and S-Video signals.
1.In signal input, the use the same channel.
2.Only one of these two signals can be input and received at one time. Therefore one of the inputs must
always be free. Otherwise the RCAVideo and S-Video signals will affect each other.
Videoand S-Video signals
TVTV Video Video
Please pay attention to the power switch when you use ourTV product firstly. According to the instruction
of sticker label on theleft speaker you will find it and switch TV on easily.
Note:
LANGUAGE ENGLISHLANGUAGE ENGLISH

VOL
-12-
Press VOL- or VOL+ on the remote control or on the TV to decrease or increase the volume.
Press the MUTE on the remote control to temporarily turn off the sound. To restore the sound, press MUTE
again. The mute function is automatically turned off when any of the following buttons are pressed: POWER,
VOL+.
Adjusting volume
Muting the sound
To change the channel, you can
1.Press CH - or CH+ on the remote control or on the TV.
2.Press the channel number buttons (0-9).
1) To select a one-digit channel : Press the 1-9 button to select channel directly.
2) To select a two-digit channel : Press a button from 1-9 to select the first number, then press a button
from 0-9 again to select the second number. For example, to select channel 28, press the 2 button first ,
2 will appear on the screen, and then press the 8 button; 28 will appear on the screen for one second.
3) To select a three-digit channel: Press the 1 button to select the first number, then press buttons from 0-9
successively to select the other two numbers. For example, to select channel 120, press the button 1,
1 will appear on the screen, then press the button 2 and the button 0 successively.
--
----
Changing channels
Displaying current channel number on screen
Press the DISPLAY button on the remote control; the current channel number and audio mode will display on the
top-right corner of the screen. It will last for 5 seconds, or you can press the DISPLAY button again to clear the screen.
Switching between two channels
Press the RECALL button on the remote control to return to the previous channel that you have just viewed.
Press the RECALL button repeatedly; alternate between the present and previous channel.the screen will
Setting the child lock
Press the LOCK button to unlocklock or the TV.
When the TV is locked, the screen will turn to black background, and nothing can be viewed unless you press
LOCK again to unlock it.
Shortcut keys operation
Setting the sleep timer
Press SLEEP on the remote control to display SLEEP TIMER screen. Press the SLEEP button repeatedly to
progressively set the sleep timer for longer periods of time starting with 5 minutes, 10 minutes, 15 minutes,.......,
120 minutes and then back to 0 minute. Selecting Off turns the sleep timer off.
CH
LANGUAGE ENGLISHLANGUAGE ENGLISH

Shortcut keys operation
Selecting the picture mode
You can select the picture mode instantly from among three preset
modes and one user-set mode. Press the P.MODE button on the remote
control repeatedly to select the desired picture mode.
Selecting the sound mode
You can select a sound effect from among three preset
modes and one user-set mode. Press the S.MODE button on the
remote control repeatedly to select the desired sound effect.
User
Bright
P.MODE
Normal
Soft
User
Music
S.MODE
Norma
Speech
-13-
Selecting MTS/SAP broadcasts
You can enjoy watching TV while you listen to high-fidelity stereo sound with the MTS feature. MTS can
also transmit a second audio program (SAP) containing a second language or other audio information.
Press the SAP button on the remote control to switch among Mono, Stereo and SAP audio modes.
NOTE: In the general settings menu, you are also able to change the audio mode under the MTS setting
Scanning all available channels
You can scan all available channels by pressing the SCAN button on the remote control. Press the SCAN button
again to cancel this function.
Using CCD (Closed Captioning)
You can turn the CCD function on by pressing the CCD button on the remote control . See page 16 for more details .
Using Parental Control (V-Chip Technology)
You can access the parental control function by pressing the PARENT button on the remote control.See page 16
for more details .
LANGUAGE ENGLISHLANGUAGE ENGLISH

Menu operation
Using the Picture Parameters menu
1) Press the MENU button to enter the main menu.
2) Press the button to select the item Picture Parameters, and
press the button to enter menu.
3) Press the button to select the item you want to adjust.
4) Press the button to adjust the level.
The adjusted data is stored automatically as the USER picture preset. To access the USER picture preset,
press the P.MODE button repeatedly until the word 'USER' appears on screen.
NOTE:1) There are some differences among different input modes. For example, Phase will disappear unless the
input signal is from VGA or Component.
2) The item Color Temp is for reference only.
Picture Parameters
[ or ]
[ or ]
Adjust picture settings
[ or ]
Using the Audio Settings menu
[ ]
1) Press the MENU button to enter the main menu.
2) Press the button to select the item , and press
the button to enter menu.
3) Press the button to select the item you want to adjust.
4) Press the button to adjust the level.
The adjusted data is stored automatically as the USER audio preset. To access the USER picture preset,
press the S.MODE button repeatedly until the word 'USER' appears on screen.
5) Press OK button to confirm your selection. Press OK again to exit from the menu.
Audio Settings
Audio Settings
[ or ]
[ or ]
[ or ]
[ ]
-14-
Adjust audio settingsAdjust audio settings
Adjust audio settings
HeadPhone settings
1) Press the MENU button to enter the main menu.
2) Press the button to select the item , and press
the button to enter menu.
3) Press the button to select the item HeadPhone.
4) Press the button to enter .
5
Audio Settings
Audio Settings
HeadPhone menu
) Press the button to select the item you want to adjust.
6) Press the button to adjust the level.
7) Press OK button to confirm your selection. Press OK again to exit from the menu.
[ or ]
[ or ]
[ ]
[ or ]
[ or ]
[ or ]
Equalier
Britghtness
Contrast
Saturation
Sharpness
Color Temp Normal
50
50
50
50
Picture Parameters
quAlier
Treble
Bass
Balance
HeadPhone
Equalizer
50
50
50
Audio Settings
quAlier
Volume
Balance
HeadPhone
50
50
4545
100HZ
4545
300HZ
4545
1K
4545
3K
4545
8K
Equalizer
Equalizer Setting
1) Press the MENU button to enter the main menu.
2) Press the button to select the item , and press
the button to enter menu.
3) Press the button to select the item Equalizer.
4) Press the button to enter Equalizer .
5
Audio Settings
Audio Settings
menu
) Press the button to select the item you want to adjust.
[ or ]
[ or ]
[ ]
[ or ]
[ or ]
6) Press the button to adjust the level
7) Press OK button to confirm your selection. Press OK again to exit from the menu.
[ or ]
Hue
50
5) Press OK button to confirm your selection. Press OK again to exit from the menu.
LANGUAGE ENGLISHLANGUAGE ENGLISH

Menu operation
-15-
H Clipping: The item allows you to extend or shorten the TV image
in the horizontal direction.
H Position: The item allows you to move the TV image in the
horizontal direction.
V Position: The item allows you to move the TV image in the
vertical direction.
Auto Configuration: When the image looks abnormal, you can try to choose
the Auto Configuration item to correct the image.
example :NOTE: The disabled items will disappear. For H Clipping will disappear
unless the valid input signal is VGA or Component.
Geometry
[ or ]
1) Press the MENU button to enter the main menu.
2) Press the button to select the item Geometry, and press the button to enter geometry menu.
3) Press the button to select the item you want to adjust.
4) Press the button to change the value.
5) Press OK button to confirm your selection. Press OK again to exit from the menu.
[ or ]
[ or ]
[ ]
Equalier
50
50
50
H Postion
H Clipping
V Postion
Auto configuration
Geometry
Using the General Settings menu
Timer
[ or ]
1) Press the MENU button to enter the main menu.
4) Press the button to enter the Timer menu.
5
2) Press the button to select the item General Settings, and press
the button to enter General Settings menu.
3) Press the button to select Timer.
) Press the button to select the item you want to adjust.
6) Press the button to change the value
7) Press OK button to confirm your selection. Press OK again to exit from the menu.
[ or ]
[ or ]
[ ]
[ or ]
[ or ]
Clock: This item allows you to set the local time on the TV.
On/Off : The item allows the TV automatically to turn on
or jump to a preset channel or switch to standby
mode when the preset time is reached.
Time: The item allows you to set the preset time, turn
on time, standby time.
Program: the item allows you to preset the channel number that the TV will turn to at the preset time.
Equalier
Clock 00:00
On/Off Time Program
Off 00:00 0
Off 00:00 PowerOff
Off 00:00 0
Off 00:00 0
Timer
Using the Geometry menu
Equalier
Timer
General Settings
Osd language English
CC mode Off
Vchip menu
MTS Off
Reset Menu Off
LANGUAGE ENGLISHLANGUAGE ENGLISH

Menu operation
-16-
[ or ]
OSD Language: Press the button to change the OSD Language.
Reset Menu : Press the button to switch between On and Off and if
the item is switched to On,the Option menu will appear when you turn on the TV the next time.
[ or ]
CC Mode: Press the button to switch among the different Closed Captioning options CC1~4, T1~4
and Off.
MTS : Press the button to switch among Stereo, SAP and Mono audio modes.
[ or ]
[ or ]
V-Chip Menu (Parental Control)
[ or ]
1) Press the MENU button to enter the main menu.
4) Press the button to enter the .
Note:
2) Press the button to select the item General Settings, and press
the button to enter General Settings menu.
3) Press the button to select Vchip Menu.
Vchip Menu
By pressing the PARENT button on the remote control,
you can access the same menu
[ or ]
[ or ]
[ ]
Password change:
Equalier
Password change
Vchip Menu
MPAA rating NA
TV PG rating
Canadian English NA
Canadian French NA
Enter the Vchip password:
xxxx
Confirm the password:
xxxx
[ or ]
Password is a four-digit number. The preset password is 0000.
You must enter a password to access the next three operations
1) Press the button to select Password change, and press the button to enter .
2) Press the 1-9 button to input the new password. Enter the new password
again to confirm the password change.
[ ]
MPAA Rating /TV PG Rating/Canadian English/Canadian French:
1) Press the button to select MPAA Rating /TV /PG Rating/
Canadian English or Canadian French, and press the button to enter it
2) Press the button to select the rating, and press button
to block or unblock the selected rating
[ ]
[ or ]
[ ]
[ or ] [ or ]
The Motion Picture Association of America (MPAA) uses a rating system to qualify motion picture content.
Television broadcasters employ a rating system to qualify the content of televison programs as well.
The MPAA and TV ratings work with the V-CHIP feature and allow you to block out programming above
the rating limits you determine.
Rating Defined as
G
PG
PG-13
R
NC-17
X
General audience
Parental Guidance suggested
Parents strongly cautioned
Restricted
No one 17 and under admitted
Adult audience only
About MPAA Rating: LANGUAGE ENGLISHLANGUAGE ENGLISH

About TV PG Rating:
The TV ratings are divided into two groups: age-based and content-based.
Age Defined as
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
All children
Directed to older children
General audience
Parental Guidance suggested
Parents Strongly cautioned
Mature Audience only
Contents Defined as
FV
D
L
S
V
Fantasy Violence
Suggestive dialogue
Strong language
Sexual situations
Violence
Menu operation
-17-
NOTE: As you block ratings, all ratings higher than the ones you select are blocked as well. For example, if you
choose
to block the MPAA rating R, the higher ratings, NC-17 and X, are automatically blocked too.
Rating Description
EExempt
CChildren
C8+ Children eight years and older
GGeneral Programming, suitable for all
audiences
PG Parental Guidance
14+ Viewers 14 years and older
18+ Adult Programming
NA Rating not applicable
About Canadian English:
About Canadian French:
Ratin
g
Description
EExempt
GGeneral
8+ 8+ General –Not recommended for young
children
13+ Programming may not be suitable for
children under the age of 13
16+ Programming is not suitable for children
under the age of 16
18+ Programming restricted to adults
NA Rating not applicable
LANGUAGE ENGLISHLANGUAGE ENGLISH

1) Press the MENU button to enter the main menu.
2) Press the button to select the item , and press the button to enter menu.
4) Press the button to skip or unskip the present channel.
NOTE: The 'skipped' channels cannot be accessed by CH+ or CH- , but you can access them by digit button.
Search Search
3) Press the button to select Skip.
Skip
[ or ]
[ or ]
[ or ]
[ ]
1) Press the MENU button to enter the main menu.
2) Press the button to select the item Search, and press the
button to enter menu.
3) Press the button to select Auto Search.
4) Press the button to start auto search.
Search
Auto Search
[ or ]
[ or ]
[ or ]
[ ]
Using the Search menu
Equalier
Program
Tuning Mode
Skip
Auto search
1
Off
Air
Search
1 48 MH Z
Auto Search
You can set Tv source as aerial or cable antenna input.
1) Press the MENU button to enter the main menu.
2) Press the button to select the item Search, and press
the button to enter menu.
3) Press the button to select Tuning Mode.
4) Press the button to switch among Air, Cable.
Search
[ or ]
[ or ]
[ or ]
[ ]
TV Reception Mode
-18-
Allows you to skip a preset TV channel. This is handy when you want to avoid accessing a channel regularly.
LANGUAGE ENGLISHLANGUAGE ENGLISH

Appendix
Cleaning and care
WARNING: TV sets use high voltage. Do not try to remove the back cabinet yourself. There areno user
serviceable parts inside. Note that opening the cabinet could void your warranty. Refer
servicing to qualified service technicians.
To clean the TV screen:
1) Unplug the TV to avoid possible shock hazard.
2) Use a damp cloth or clean cellulose sponge to clean the TV screen and trim. Do not allow water to spill
into the cabinet or damage may occur.
3) Wipe off any excess moisture with a clean dry cloth.
4) Polish the cabinet with a quality furniture polish to maintain the finish and appearance of the cabinet.
Caution: Never use strong solvents such as thinner, benzene, or other chemicals on or near the cabinet.
These chemicals can damage the finish of the cabinet.
-19-
Important notice
1. When the TV does not behave properly for some reason, please unplug the power and plug it back in.
2. Displaying a still picture for a long time will cause image sticking when the input signal is interlaced. The
image sticking will disappear when you turn off the TV for a moment. When using an interlaced input
signal, we recommend not to display a still image for a long time.
LANGUAGE ENGLISHLANGUAGE ENGLISH
