Hisense APC12QB Technical manual

Thank you very much for purchasing this Air Conditioner. Please read this use and installation instructions carefully before installing and using this appliance and keep this manual for future reference.Model:Hisense (Guangdong) Air Conditioning Co., Ltd.No.8 Hisense Road，Advanced Manufacturing Jiangsha Demonstration Park,Jiangmen City,Guangdong Province,P.R.China
APC12QB
APH12QB
APC12QC
APH12QC

1
TABLE OF CONTENTS
INSTALLATION REQUIREMENTS................................................
12
Tools and Parts...........................................................................
12
Location Requirements...............................................................
13
Electrical Requirements..............................................................
13
INSTALLATION INSTRUCTIONS..................................................
13
Unpack the Air Conditioner.........................................................
13
Install LocalAir Conditioner(on the window).......................................................
14
LOCAL.........................................
7
IDENTIFICATION OF PARTS............................................10Using the Remote Control..........................................................
19
...Starting Your LocalAir Conditioner........................................
18
Complete Installation...................................................................
16
Draining the Air Conditioner( Heating models)....... ...................2
4
AIR CONDITIONER USE.AIR CONDITIONER SAFETY.........................................................
11
Normal Sounds..........................................................................2
3
Draining the Air Conditioner.......................................................2
4
Cleaning the Air Filter.................................................................2
4
Storing After Use........................................................................2
4
TROUBLESHOOTING..................................................................2
5
LOCAL AIR CONDITIONER CARE.........................................2
4
Cleaning the Outside..................................................................2
4
SAFETY INSTRUCTIONS
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. Children should be supervised to ensure that they do not play with the appliance.If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.The appliance shall be installed in accordance with national wiring regulations.The range of external static pressures is -0.2Pa to 0.2Pa.Keep the unit 5m or more apart from combustible surfaces.Do not operate your air conditioner in a wet room such as a bathroom or laundry room........
SAFEGUARDING THE ENVIRONMENT
This appliance is made of recyclable or re-usable material. Scrapping must be carried out in compliance with local waste disposal regulations. Before scrapping it, make sure to cut off the mains cord so that the appliance cannot be re-used. For more detailed information on handling and recycling this product, contact your local authoritieswho deal with the separate collection of rubbish or the shop where you bought the appliance. SCRAPPING OF APPLIANCE This appliance is marked according to the European Directive 2012/19/EU, Waste Electrical andElectronic Equipment (WEEE). This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal,recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.
............................................2SAFETY PRECAUTIONS.....

Safety precautionsPrecautions for using R290 refrigerant2 However, pay attention to the following points:The basic installation work procedures are the same as the conventional refrigerant (R22 or R410A). CAUTION1.Transport of equipment containing flammable refrigerants Compliance with the transport regulations2.Marking of equipment using signs Compliance with local regulations3.Disposal of equipment using flammable refrigerants Compliance with national regulations4.Storage of equipment/appliances The storage of equipment should be in accordance with the manufacturer's instructions.5.Storage of packed (unsold) equipment Storage package protection should be constructed such that mechanical damage to the equipment inside the package will not cause a leak of the refrigerant charge. The maximum number of pieces of equipment permitted to be stored together will be determined by local regulations.6.Information on servicing6-1 Checks to the area Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimised. For repair to the refrigerating system, the following precautions shall be complied with prior to conducting work on the system.6-2 Work procedure Work shall be undertaken under a controlled procedure so as to minimise the risk of flammable gas or vapour being present while the work is being performed.6-3 General work area All maintenance staff and others working in the local area shall be instructed on the nature of work being carried out. Work in confined spaces shall be avoided. The area around the workspace shall be sectioned off. Ensure that the conditions within the area have been made safe by control of flammable material.6-4 Checking for presence of refrigerant The area shall be checked with an appropriate refrigerant detector prior to and during work, to ensure the technician is aware of potentially flammable atmospheres. Ensure that the leak detection equipment being used is suitable for use with flammable refrigerants, i.e. non-sparking, adequately sealed or intrinsically safe.

Safety precautions3CAUTION6-5 Presence of fire extinguisher If any hot work is to be conducted on the refrigeration equipment or any associated parts, appropriate fire extinguishing equipment shall be available to hand. Have a dry powder or CO2 fire extinguisher adjacent to the charging area.6-6 No ignition sources No person carrying out work in relation to a refrigeration system which involves exposing any pipe work that contains or has contained flammable refrigerant shall use any sources of ignition in such a manner that it may lead to the risk of fire or explosion. All possible ignition sources, including cigarette smoking, should be kept sufficiently far away from the site of installation, repairing, removing and disposal, during which flammable refrigerant can possibly be released to the surrounding space. Prior to work taking place, the area around the equipment is to be surveyed to make sure that there are no flammable hazards or ignition risks. “No Smoking” signs shall be displayed.6-7 Ventilated area Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot work. A degree of ventilation shall continue during the period that the work is carried out. The ventilation should safely disperse any released refrigerant and preferably expel it externally into the atmosphere.6-8 Checks to the refrigeration equipment Where electrical components are being changed, they shall be fit for the purpose and to the correct specification. At all times the manufacturer's maintenance and service guidelines shall be followed. If in doubt consult the manufacturer's technical department for assistance. The following checks shall be applied to installations using flammable refrigerants: – The charge size is in accordance with the room size within which the refrigerant containing parts are installed; – The ventilation machinery and outlets are operating adequately and are not obstructed; – If an indirect refrigerating circuit is being used, the secondary circuit shall be checked for the presence of refrigerant; – Marking to the equipment continues to be visible and legible. Markings and signs that are illegible shall be corrected; – Refrigeration pipe or components are installed in a position where they are unlikely to be exposed to any substance which may corrode refrigerant containing components, unless the components are constructed of materials

Safety precautions4CAUTION which are inherently resistant to being corroded or are suitably protected against being so corroded.6-9 Checks to electrical devices Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures. If a fault exists that could compromise safety, then no electrical supply shall be connected to the circuit until it is satisfactorily dealt with. If the fault cannot be corrected immediately but it is necessary to continue operation, an adequate temporary solution shall be used. This shall be reported to the owner of the equipment so all parties are advised. Initial safety checks shall include: – That capacitors are discharged: this shall be done in a safe manner to avoid possibility of sparking; – That there no live electrical components and wiring are exposed while charging, recovering or purging the system; – That there is continuity of earth bonding.7.Repairs to sealed components During repairs to sealed components, all electrical supplies shall be disconnected from the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation. Particular attention shall be paid to the following to ensure that by working on electrical components, the casing is not altered in such a way that the level of protection is affected. This shall include damage to cables, excessive number of connections, terminals not made to original specification, damage to seals, incorrect fitting of glands, etc. Ensure that apparatus is mounted securely. Ensure that seals or sealing materials have not degraded such that they no longer serve the purpose of preventing the ingress of flammable atmospheres. Replacement parts shall be in accordance with the manufacturer's specifications. NOTE: The use of silicon sealant may inhibit the effectiveness of some types of leak detection equipment. Intrinsically safe components do not have to be isolated prior to working on them. 8.Repair to intrinsically safe components Do not apply any permanent inductive or capacitance loads to the circuit without ensuring that this will not exceed the permissible voltage and current permitted for the equipment in use. Intrinsically safe components are the only types that can be worked on while

Safety precautions5CAUTION live in the presence of a flammable atmosphere. The test apparatus shall be at the correct rating. Replace components only with parts specified by the manufacturer. Other parts may result in the ignition of refrigerant in the atmosphere from a leak.9.Cabling Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse environmental effects. The check shall also take into account the effects of aging or continual vibration from sources such as compressors or fans.10.Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks. A halide torch (or any other detector using a naked flame) shall not be used.11.Leak detection methods The following leak detection methods are deemed acceptable for systems containing flammable refrigerants: – Electronic leak detectors shall be used to detect flammable refrigerants, but the sensitivity may not be adequate, or may need re-calibration. (Detection equipment shall be calibrated in a refrigerant-free area.) – Ensure that the detector is not a potential source of ignition and is suitable for the refrigerant used. – Leak detection equipment shall be set at a percentage of the LFL of the refrigerant and shall be calibrated to the refrigerant employed and the appropriate percentage of gas (25 % maximum) is confirmed. – Leak detection fluids are suitable for use with most refrigerants but the use of detergents containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode the copper pipe-work. – If a leak is suspected, all naked flames shall be removed/ extinguished. – If a leakage of refrigerant is found which requires brazing, all of the refrigerant shall be recovered from the system, or isolated (by means of shut off valves) in a part of the system remote from the leak. – Oxygen free nitrogen (OFN) shall then be purged through the system both before and during the brazing process.12.Removal and evacuation When breaking into the refrigerant circuit to make repairs – or for any other purpose – conventional procedures shall be used. However, it is important that best practice is followed since flammability is a consideration. The following procedure shall be adhered to: – Remove refrigerant; – Purge the circuit with inert gas;

Safety precautions6CAUTION – Evacuate; – Purge again with inert gas; – Open the circuit by cutting or brazing. The refrigerant charge shall be recovered into the correct recovery cylinders. The system shall be “flushed” with OFN to render the unit safe. This process may need to be repeated several times. Compressed air or oxygen shall not be used for this task. Flushing shall be achieved by breaking the vacuum in the system with OFN and continuing to fill until the working pressure is achieved, then venting to atmosphere, and finally pulling down to a vacuum. This process shall be repeated until no refrigerant is within the system. When the final OFN charge is used, the system shall be vented down to atmospheric pressure to enable work to take place. This operation is absolutely vital if brazing operations on the pipe-work are to take place. Ensure that the outlet for the vacuum pump is not close to any ignition sources and there is ventilation available.13.Charging procedures In addition to conventional charging procedures, the following requirements shall be followed: – Ensure that contamination of different refrigerants does not occur when using charging equipment. – Hoses or lines shall be as short as possible to minimise the amount of refrigerant contained in them. – Cylinders shall be kept upright. – Ensure that the refrigeration system is earthed prior to charging the system with refrigerant. – Label the system when charging is complete (if not already). – Extreme care shall be taken not to overfill the refrigeration system. Prior to recharging the system it shall be pressure tested with OFN. The system shall be leak tested on completion of charging but prior to commissioning. A follow up leak test shall be carried out prior to leaving the site.14.Decommissioning Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of reclaimed refrigerant. It is essential that electrical power is available before the task is commenced. a) Become familiar with the equipment and its operation. b) Isolate system electrically.

Safety precautions7CAUTION c) Before attempting the procedure ensure that: – Mechanical handling equipment is available, if required, for handling refrigerant cylinders; – All personal protective equipment is available and being used correctly; – The recovery process is supervised at all times by a competent person; – Recovery equipment and cylinders conform to the appropriate standards. d) Pump down refrigerant system, if possible. e) If a vacuum is not possible, make a manifold so that refrigerant can be removed from various parts of the system. f) Make sure that cylinder is situated on the scales before recovery takes place. g) Start the recovery machine and operate in accordance with manufacturer's instructions. h) Do not overfill cylinders. (No more than 80 % volume liquid charge). I ) Do not exceed the maximum working pressure of the cylinder, even temporarily. j ) When the cylinders have been filled correctly and the process completed, make sure that the cylinders and the equipment are removed from site promptly and all isolation valves on the equipment are closed off. k) Recovered refrigerant shall not be charged into another refrigeration system unless it has been cleaned and checked.15.Labelling Equipment shall be labelled stating that it has been de-commissioned and emptied of refrigerant. The label shall be dated and signed. Ensure that there are labels on the equipment stating the equipment contains flammable refrigerant.16.Recovery When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all refrigerants are removed safely. When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for holding the total system charge is available. All cylinders to be used are designated for the recovered refrigerant and labelled for that refrigerant (i.e. special cylinders for the recovery of refrigerant). Cylinders shall be complete with pressure relief valve and associated shut- off valves in good working order. Empty recovery cylinders are evacuated and, if possible, cooled before recovery occurs. The recovery equipment shall be in good working order with a set of

Safety precautions 8CAUTION instructions concerning the equipment that is at hand and shall be suitable for the recovery of flammable refrigerants. In addition, a set of calibrated weighing scales shall be available and in good working order. Hoses shall be complete with leak-free disconnect couplings and in good condition. Before using the recovery machine, check that it is in satisfactory working order, has been properly maintained and that any associated electrical components are sealed to prevent ignition in the event of a refrigerant release. Consult manufacturer if in doubt. The recovered refrigerant shall be returned to the refrigerant supplier in the correct recovery cylinder, and the relevant Waste Transfer Note arranged. Do not mix refrigerants in recovery units and especially not in cylinders. If compressors or compressor oils are to be removed, ensure that they have been evacuated to an acceptable level to make certain that flammable refrigerant does not remain within the lubricant. The evacuation process shall be carried out prior to returning the compressor to the suppliers. Only electric heating to the compressor body shall be employed to accelerate this process. When oil is drained from a system, it shall be carried out safely. CAUTION When moving or relocating the air conditioner, consult experienced service technicians for disconnection and reinstallation of the unit. Do not place any other electrical products or household belongings under indoor unit or outdoor unit. Condensation dripping from the unit might get them wet, and may cause damage or malfunction of your property. Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. The appliance shall be stored in a room without continuously operating ignition sources(for example, open flames, an operating gas appliance or an operating electric heater). Do not pierce or burn. Be aware that refrigerants may not contain an odor. To keep ventilation openings clear of obstruction. The appliance shall be stored in a well-ventilated area where the room size corresponds to the room area as specified for operation. The appliance shall be stored in a room without continuously operating open flames (for example an operating gas appliance) and ignition sources (for example an operating electric heater). The appliance shall be stored so as to prevent mechanical damage from occurring.

Safety precautions 9
Explanation
of
symbols
displayed on the indoor unit or outdoor unit.
WARNING
This symbol shows that this appliance uses a flammable refrigerant.If the refrigerant is leaked and exposed to an external
CAUTION
This symbol shows that the operation manual should be read carefully.
CAUTION
This symbol shows that a service personnel should be handling this equipment with reference to the installation manual.
CAUTION
This symbol shows that information is available such as the operating manual or installation manual.
CAUTIONAny person who is involved with working on or breaking into a refrigerant circuit
should hold a current valid certificate from an industry-accredited assessment
authority, which authorises their competence to handle refrigerants safely inaccordance with an industry recognised assessment specification.Servicing shall only be performed as recommended by the equipment
manufacturer.Maintenance and repair requiring the assistance of other skilled personnelshall be carried out under the supervision of the person competent in the use of
flammable refrigerants.Do not use means to accelerate the defrosting process or to clean, other than
those recommended by the manufacturer.Appliance shall be installed, operated and stored in a room with a floor area
larger than:
14.4m2
The pipe-work shall be complianced with national gas regulations.Spaces where refrigerant pipes shall be compliance with national gas
regulations.Servicing shall be performed only as recommended by the manufacturer.
All working procedure that affects safety means shall only be carried by
competent persons.The maximum refrigerant charge amount is 0.3 kg.Mechanical connectors used indoors shall comply with ISO 14903. Whenmechanical connectors are reused indoors, sealing parts shall be renewed.
When flared joints are reused indoors, the flare part shall be re-fabricated.
The installation of pipe-work shall be kept to a minimum.Mechanical connections shall be accessible for maintenance purposes.
Caution, risk of fire

ON/OFF
MODEFANSWINGSLEEPSUPERSMARTIFEELDIMMERTIMER ONTIMER OFFCLOCK
O
N
O
FF
O
N
O
FF
10

AIR CONDITIONER SAFETY
You can be killed or seriously injured if you don't immediately You can be killed or seriously injured if you don't follow$OO VDIHW\ PHVVDJHV ZLOO WHOO \RX ZKDW WKH SRWHQWLDO KD]DUG LV, WHOO \RX KRZ WR UHGXFH WKH FKDQFH RI LQMXU\andtellyouwhatcanhappen

if

the

instructions

are

not

followed
:H KDYH SURYLGHG PDQ\ LPSRUWDQW VDIHW\ PHVVDJHV LQ WKLV PDQXDO DQG RQ \RXU DSSOLDQFH. $OZD\V UHDG DQG REH\ DOO VDIHW\ PHVVDJHV.7KLV LV WKH VDIHW\ DOHUW V\PERO.7KLV V\PERO DOHUWV \RX WR SRWHQWLDO KD]DUGV WKDW FDQ NLOO RU KXUW \RX DQG RWKHUV.$OO VDIHW\ PHVVDJHV ZLOO IROORZ WKH VDIHW\ DOHUW V\PERO DQG HLWKHU WKH ZRUG "D$1*(5" RU "WARNING."7KHVH ZRUGV PHDQ:follow instructions.instructions.DANGERWARNING
IMPORTANT SAFETY INSTRUCTIONSWARNING: 7R UHGXFH WKH ULVN RI ILUH, HOHFWULFDO VKRFN RU LQMXU\ ZKHQ XVLQJ \RXU DLU FRQGLWLRQHU, IROORZ WKHVH EDVLF SUHFDXWLRQV:SAVE THESE INSTRUCTIONS8QSOXJ DLU FRQGLWLRQHU EHIRUH VHUYLFLQJ.8VH WZR RU PRUH SHRSOH WR PRYH DQG LQVWDOO DLU FRQGLWLRQHU.3OXJ LQWR D JURXQGHG 3 SURQJ RXWOHW.'R QRW UHPRYH JURXQG SURQJ.'R QRW XVH DQ DGDSWHU.'R QRW XVH DQ H[WHQVLRQ FRUG.
You safety and the safety of others are very important.
DISPOSING OF THE UNIT
%HIRUHWKURZLQJWKHGHYLFHLWLVQHFHVVDU\WRSXOOEDFNWKHEDWWHU\FHOOVDQGJHWULGRIWKHPVDIHW\IRUUHF\FOLQJUHDVRQV
:KHQ\RXQHHGWRGLVSRVDORIWKHXQLWFRQVXOWRXUGHDOHU,ISLSHVDUHUHPRYHGLQFRUUHFWO\UHIULJHUDQWPD\EORZRXWDQG
SOHDVHUHF\FOHRUGLVSRVHRIWKHSDFNDJLQJPDWHULDOIRUSURGXFWLQDQHQYLURQPHQWDOO\UHVSRQVLEOHPDQQHU
1HYHUVWRUHRUVKLSWKHDLUFRQGLWLRQHUXSVLGHGRZQRUVLGHZD\VWRDYRLGGDPDJHWRWKHFRPSUHVVRU
7KHDSSOLDQFHLVQRWLQWHQGHGIRUXVHE\\RXQJFKLOGUHQRULQILUPSHUVRQVZLWKRXWVXSHUYLVLRQ<RXQJFKLOGUHQVKRXOGEH
FRPHLQWRFRQWDFWZLWK\RXUVNLQFDXVLQJLQMXU\5HOHDVLQJUHIULJHUDQWLQWRWKHDWPRVSKHUHDOVRGDPDJHVWKHHQYLURQPHQWV
VXSHUYLVHGWRHQVXUHWKDWWKH\GRQRWSOD\ZLWKWKHDSSOLDQFH
11

INSTALLATION REQUIREMENTS
Tools needed
Scissors Pencil Cordless drill and ¹8” bit
Description Quantity
A. Foam seal
B. Coupling
C. Flexible exhaust hose
D. Window exhaust adapter
E. Rivets
F. Screws
G. Window-lock bracket
H. Outer slider section with vent
I. Inner slider section-short
J. inner slider section
K. Outer slider section
L. Foam seal-long
M. Foam seal-short
N. Drain hose (Heat pump models)
O. Drain hose clip (Heat pump models)
P. Remote control
Q. Standard AAA (1.5 volts) batteries
1 pc
1 pc
1 pc
2 pc
2 pc
2 pc
2 pc
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
4 pc
4 pc
BEST USED BEFORE DATE CODE (MONTH-YEAR)
ON THE BOTTOM
Do Not Mix Old And New Batteries. Do Not Mix Alkaline,
Standard (Carbon - Zinc), Or Rechargeable (Nickel
- Cadmium) Batteries
Caution for ingestion
The battery may cause suffocation if swallowed by children
Non-rechargeable batteries are not to be recharged
Exhausted batteries are to be removed from the product
Tools and Parts
Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here.
Phillips screwdriver
Parts supplied
Part
The following parts are supplied with the portable Air conditioner.
Note
MERCURY FREE SUPER HEAVY DUTY R03 UM-4 SIZE AAA 1.5V
DO NOT DISPOSE OF BATTERIES IN FIRE. BATTERIES MAY EXPLODE OR LEAK.
12

13
Location RequirementsElectrical Requirements
■ The air conditioner should be connected to a 220-
240V, 50 HZ, 16-amp fuse grounded 3 prong outlet.
■ The use of a time-delay fuse or time-delay circuit breaker is recommended.■ All wiring must comply with local and the national electrical codes and be installed by a qualified electrician. If you have any questions, contact a qualified electrician.portable Electrical Shock HazardPlug into a grounded 3 prong outlet.Do not remove ground prong.Do not use an adapter.Do not use an extension cord.Failure to follow these instructions can result in death, WARNINGfire, or electrical shock.NOTES:■ The flexible exhaust hose allows placement of the air conditioner between 60 cm and 170 cm from window or door. For appliances with supplementary heaters, the minimum clearance from the appliances to combustible surfaces is 100cm.■ Portable air conditioners are designed as supplemental cooling to local areas within a room.NOTES:■ To ensure proper ventilation, keep the required distance from the return air outlet to the wall or other obstacles at least 60 cm. ■ Do not block the air outlet.■ Provide easy access to the grounded 3 prong outlet.Vertical Slide WidowHorizontal Slide Window60 cm - 170 cm60 cm - 170 cm100 cm100 cm
Unpack the Air Conditioner
Remove packaging materials■Remove and dispose of/recycle packaging materials. Remove tape and glue residue from surfaces before turning on the air conditioner. Rub a small amount of liquid dish soap over the adhesive with your fingers. Wipe with warm water and dry.■Do not use sharp instruments, rubbing alcohol, flammable fluids, or abrasive cleaners to remove tape or glue. These products can damage the surface of your air conditioner. ■Handle the air conditioner gently.WARNINGExcessive Weight HazardUse two or more people to move and install air conditioner.Failure to do so can result in back or other injury.■
INSTALLATION INSTRUCTIONS
combustible surfacescombustible surfaces

4
Window Installation1.Roll the air conditioner to selected location. see “LocationRequirements.”2.Attach the dummy coupling to the flexible exhaust hose. Turnanticlockwise until securely locked into place.Install Exhaust Hose and Adapter3.Attach the window exhaust adapter to the flexible exhausthose. Turn anticlockwise until securely locked into place.Your window slider kit has been designed to fit most standard vertical and horizontal window applications. Roll the air conditioner to selected location. see “Location Requirements.”1.Insert the windows exhaust adapter into the slot on the windowslider kit.A. Window slider kitB. Window exhaust adapter4.Insert the dummy coupling into the slot on the back of the airconditioner.5. Slide down to lock the hose into place.AB
Install Portable Air Conditioner(on the window)
A. Evaporator air intakeB.Dummy couplingC. Flexible exhaust hoseD. Condenser air intake
A
C
B
D
A. Flexible exhaust hoseB. Window exhaust adapter
AB
2.Open the window.3. Measure the window opening. If the window opening is too narrow for the window slider kit, remove the inner slider section from the window slider kit.■A. Inner slider sectionB. Outer slider section Using a saw, cut the inner slider section to fit the window opening. Slide the inner slider section into the outer slider section of the window slider kit. ■■4. Place the window slider kit into the window, extending it to fitthe width of the window. Be sure the rain cover is on theoutside of the window.
AB

5
NOTE: For casement window installation, the window slider kit may be installed vertically with the window slider kit opening at the bottom.5. Inset ½” screw (provide 2) into the hole in the inner slider
section that is closest to the end of the outer slider section
A. ½”screw (provide 2)B. Inner slider sectionC. Outer slider section6. Close the window onto the window slider kit to secure.A. To air conditionerB.OutdoorsportableC. Window slider kitD. Window exhaust adapterE. Flexible exhaust hoseABCCABDE

16
Complete Installation
1. Place the window-lock bracket on top of the lower window and against the upper window sash.2. Use 1/8” drill bit to drill a starter hole through the hole in the bracket. 3. Attach the window-lock bracket to the window sash with wood screw(provide 4) to secure the window in place.A. Upper window sashB. Window-lock bracket4. Insert the foam seal behind the top of the lower window sash and against the glass of the upper window.A. Top of lower window sashB. Foam seal
AB
Electrical Shock HazardPlug into a grounded 3 prong outlet.Do not remove ground prong.Do not use an adapter.Do not use an extension cord.Failure to follow these instructions can result in death, WARNINGfire, or electrical shock.5. Plug into a grounded 3 prong outlet.
AB

LOCAL AIR CONDITIONER USE
Operating your air conditioner properly helps you to local
obtain the best possible results. This section explains proper air conditioner operation.IMPORTANT:
NOTE: In the event of a power failure, your air conditioner will operate at the previous settings when the power is restored.
The air conditioner display shows the setting temperature.
If changing modes while the air conditioner is running,
the compressor will stop for 3 to 5 minutes.
■■Only in standby mode the display shows ambient ■ temperature If a button is pressed during this time, the compressor will not restart fo another 3 to 5 minutes. In Cooling or Dry mode, the compressor and condenser fan will stop when the room temperature reaches the set temperature.■■Operating condition HEATINGCOOLINGDRYooThe best room temperature for the appliance work is 7 C~20 CoThe best room temperature for the appliance work is 21oC~35CooThe best room temperature for the appliance work is 19 C~35 CThe temperature of some products is allowed beyond the range. In specific situation, please consult the merchant.If the air conditioner runs in COOLING or DRY mode withdoor or window opened for a long time when relative humidity is above 80%,dew may drip down from the outlet.
7

18
SILENT

DO NOT DISPOSE OF BATTERIES IN FIRE. BATTERIES MAY EXPLODE OR LEAK.
19
SILENT
SILENT
SILENT
