Hisense HWFE7510 Mounting instructions

澳大利亚
洗衣机研发部
A
说明书
80g胶版纸
W10592262
W10592262
HWFE7510
技术要求
1:1
审核
标准化
版本号
设计
工艺
更改文件号 重量 比例
第 张 共 张
后附图纸13页
1. 材料：80g双胶纸，正反面印刷；
2. 印刷为黑白色单色印刷；
3. 所有印刷内容正确、清晰，不得有漏印、误印，无印刷缺陷；
4. 幅面：（210±3）X（145±3）（单位：mm）；
5.未注公差按照GB1800(现行).IT15；
6.颜色及整体效果必须经过研发部确认后方能生产，产品检验以封样件为准；
7.符合RoHS现行标准要求和REACH指令。
会签
会签
批准

USER’S OPERATION MANUAL
Before operating this unit, please read this manual thoroughly,
and retain for future reference
W10592262A

NOTE...........................................................................................................................
DESCRIPTION OF THE WASHING MACHINE......................................................
PRECAUTIONS AND GENERAL RECOMMENDATIONS.....................................
Packaging.........................................................................................
Disposing of packaging and scrapping
old washing machines.....................................................................
Location and surroundings.............................................................
General Safety Recommendation...................................................
Child safety (If Available).................................................................
Safety of transport and handling....................................................
Safety of Electrical Connection......................................................
BEFORE USING THE WASHING MACHINE...........................................................
Removing the packaging and inspection......................................
Remove the transport bolts............................................................
Install the washing machine...........................................................
Install Water inlet.............................................................................
Install Drain......................................................................................
Install Electrical connection...........................................................
BEFORE THE FIRST WASH CYCLE.......................................................................
PREPARATION OF THE WASHING........................................................................
Sort the laundry according to ........................................................
Prepare the cloth for washing.........................................................
Adding detergents and additives...................................................
Loading the laundry.........................................................................
DETERGENTS AND ADDITIVES.............................................................................
Dosage..............................................................................................
Stain removal...................................................................................
Dyeing...............................................................................................
Where to put detergent and additives...........................................
How to position the separator in the main wash chamber
for powder or liquid detergent........................................................
HOW TO USE THE FRONT PANEL.........................................................................
SELECT ANY DESIRED OPTION............................................................................
.
.
.
.
Safety of opening and closing door...............................................
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Program Start....................................................................................
.
Rinse Hold..........................................................................................
Extra Rinse.........................................................................................
Eco Wash...........................................................................................
Prewash.............................................................................................
Spin Speed........................................................................................
Temp...................................................................................................
Delay...................................................................................................
Child Lock..........................................................................................
Programme End................................................................................
.
.
.
.
.
.
.
.
.
1
2
3
4
5
6
7
8
9
9
10
1
2
2
2
2
3
4
4
4
4
4
5
5
5
6
6
6
6
7
7
8
8
9
10
10
11
11
11
11
11
11
CARE AND MAINTENANCE.......................................................................................
Appliance exterior and control panel.......................................................
Door seal.....................................................................................................
Filter.............................................................................................................
Removing the Filter....................................................................................
Detergent dispenser...................................................................................
Water supply hose......................................................................................
Mesh filter for water connection...............................................................
Draining residual water..............................................................................
TROUBLESHOOTING GUIDE....................................................................................
The washing machine will not start and no indicator lamps
are on..........................................................................................................
The washing machine will not start..........................................................
The appliance stops during the programme...........................................
Residue from detergent and additives left in the detergent
drawer at end of wash...............................................................................
Machine vibrates during spin cycle.........................................................
Final spin results are poor........................................................................
FAULT DESCRIPTION TABLE...................................................................................
Error code...................................................................................................
If a failure code "F01" and "F02" appears on the display .....................
If a failure code "F03" appears on the display .......................................
If a failure code "F13" appears on the display .......................................
If a failure code "UNB" appears on the display .......................................
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
12
14
17
16
15
14
12
12
13
13
14
15
15
15
16
16
17
17
17
18
AFTER-SALES SERVICE...........................................................................................
18
Hisense Warranty.......................................................................................................
19
Automatic Programs.........................................................................
.12
18
If a failure code "F04" to "F07" appears on the display ........................
.18
15

1
2
4
5
6
7
3
NOTE
Before operating your new washing machine, please read this
instruction manual carefully, and keep it for reference.
DESCRIPTION OF THE WASHING MACHINE
1. Worktop
2.Control panel
4.Door
5. Child safety device(if provided, inside the door)
6.Plinth covering pump access
7.Adjustable feet
3.Detergent dispenser
PRECAUTIONS AND GENERAL RECOMMENDATIONS
1. Packaging
2.
Disposing of packaging and scrapping old washing machines
The washing machine is built from reusable materials. It must be disposed of in
compliance with current local waste disposal regulations.
Before scrapping, remove all detergent residues, break the door hook, and cut
off the power cable so that the washing machine becomes unusable.
The symbol on the product, or on the documents accompanying the product,
indicates that this appliance may not be treated as household waste. Instead it
shall be handed over to the applicable collection point for the recycling of
electrical and electronic equipment. Disposal must be carried out in accordance
with local environmental regulations for waste disposal. For more detailed
information about treatment, recovery and recycling of this product, please
contact your local city office, your household waste disposal service or the shop
where you purchased the product.
3. Location and surroundings
The washing machine must only be installed in enclosed spaces. Installation in
the bathroom or other places where air is humid is not recommended.
Do not store flammable fluids near the appliance.
Minimum housing dimensions:
Width: 600 mm
Height: 850 mm
Depth: Refer to Parameter Table in quick basic chart.
4.General Safety Recommendation
Do not leave the appliance plugged in when it is not in use. Never plug or
unplug the power from the mains supply, if your hands are wet.
Always turn off the water supply tap after the use.
Before any cleaning and maintenance, switch off the machine and disconnect
it from the mains.
Clean the outside of the washing machine with a damp cloth. Do not use abrasive
detergents.
The manufacturer reserves the right for any modifications on the product witch might
be deemed necessary or useful without informing about it in this User Manual.
Thank you for choosing a Hisense washing machine.
Please make sure the socket is grounded securely, and the water source connection
is reliable. The manufacturer declines all liability and warranty for damage to property
or injury to persons or animals due to non-compliance with the directions given in
this instruction.
This appliance is not intended for use by persons(including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be super vised to ensure that they do not play with the appliance.
.
.
.
.
The packaging material is entirely recyclable, and marked with the recycling symbol
. Adhere to current local regulations when disposing of packaging material.
.
.
.
.
.
.
1 2
Control panel layout and appearance will depend on the model

To open the door, hold the door handle, press the inside handle and pull the door.
Close the door by pressing it without excessive force until it clicks shut.
Note:
In the case of power outage, please check the water level, if the water is exist in the
drum above the door level , then please drain the water from the drain hose before
opening the door.
.
.
This appliance is not intended for use by persons(including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children must not be allowed to play with the appliance or to climb into the drum
(see also the "Child Safety" Section).
If necessary, the power cable may be replaced with an identical one obtained
from our After-Sales Service. The power cable must only be replaced by a
qualified technician.
Do not allow children to operate, crawl on, be near or inside your washer. Now
that during the wash cycle, the surface temperature of the porthole door may
increase. Close supervision of the children is necessary when the appliance is
used near children.
5. Safety of opening and closing door
Only when the programme turns"End", the door could be opened. Never open the
door forcibly while the machine is running, otherwise you can damage the door
lock.
If you must open the door while the machine is running, press the "Start/Pause"
button on the front of the control panel to pause the current cycle, and then wait for
at least 2 second to turn off the machine, and restart the machine and select new
programme for the door lock to be released and the Lock light turn off from the panel.
6. Child safety(If Available)
To protect the appliance against improper use, turn the plastic screw on the interior of
the door. To do this, use a coin or similar objects.
Slot vertical: the door will not lock.
Slot horizontal - normal position: the door can be locked again.
7.Safety of transport and handling
Never lift the appliance by the worktop when transporting.
Pull out the mains plug.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Turn off the water tap.
Disconnect the inlet and drain hoses.
Drain all remaining residual water from the hoses and from the appliance (see
"Removing the Filter", "Draining Residual Water").
Fit the transport bolts (obligatory).
The machine is over 55 Kg in weight; therefore, two persons are needed to
move it.
8. Safety of Electrical Connection
Only use a socket with an earth connection.
Do not use extension leads or multi sockets.
Electric supply must be adequate for the machine's 10 A Current Rating.
Electrical connections must be made in accordance with local regulations.
The electrical power cable must be replaced exclusively by a licensed
electrician.
BEFORE USING THE WASHING MACHINE
1. Removing the packaging and inspection
After unpacking, ensure that the washing machine is undamaged. If in doubt, do
not use the washing machine. Contact After-Sales Service or your local retailer.
Check that the accessories and supplied parts are all present (see also the
separate Installation guide).
Keep the packaging materials (plastic bags, polystyrene parts, etc.) out of reach
of children, as they are potentially dangerous.
3 4
Never open the loading door forcibly or use it as a step.
Never open the loading door or filter while there is still water in the drum.
.
.
The washing machine is fitted with transport bolts to avoid any possible
damage to the interior part during transport. Before using the machine, it is
imperative that the transport bolts are removed.
After their removal, cover the openings with the 4 enclosed plastic caps.
.
.
2. Remove the transport bolts (see also the separate Installation guide)
3. Install the washing machine (see also separate Installation guide)
Move the appliance without lifting it by the worktop.
Install the appliance on a solid and level floor surface, preferably in a corner of
the room.
Ensure that all four feet are stable and resting on the floor and then check that
the washing machine is perfectly level (use a spirit level).
.
.
.
.
.
In addition to the child safety lock door, the machine is equipped with "Child Lock"
function. Please refer to the "Child Lock" instruction in page 11.

Ensure that the ventilation openings in the base of the washing machine(if
available on your model) are not obstructed by a carpet or other material.
4. Install water inlet(see also separate Installation guide)
Please refer to the Installation guide for installing the water inlet.
5. Install Drain(see also separate Installation guide)
Connect the drain hose to the siphon or hook it over the edge of a sink by means
of the "U" bend supplied.
If the washing machine is connected to an integrated drainage system, ensure
that the integrated drainage system is equipped with a vent to avoid simultaneous
loading and draining of water (siphoning effect).
6. Install Electrical connection
Electrical connections must be carried out by a qualified technician in compliance
with the manufacturer's instructions and current standard safety regulations.
PREPARATION OF THE WASHING
1. Sort the laundry according to ...
Type of fabric /care label symbol
Cottons, mixed fibers, easy care/synthetics, wool, hand wash items.
The wool wash cycle of this machine has been tested and approved by The
Woolmark Company for the washing of Woolmark garments labeled as "machine
wash" provided that the garments are washed according to the instructions on the
garment label and those issued by the manufacturer of this washing machine.
Colour
Separate coloured and white items. Wash new coloured articles separately.
.
.
.
The drain plug should be removed at all time.
Secure the drain hose tightly to prevent spills and scalding during machine
drainage.
The drain hoses must always be securely tighten and remain in an undamaged
state.
.
.
.
.
.
.
Data regarding voltage, power consumption and protection requirements are
given on the back of the washing machine.
The appliance must be connected to the mains by means of a socket with an
earth connection in accordance with current regulations. The washing machine
must be earthed by law. The manufacturer declines all liability for damage to
property or injury to persons or animals due to non-compliance with the directions
given above.
Do not use extension leads or multiple sockets. Make sure the capacity of the
socket is powerful enough to drive the machine during heating.
Before any maintenance on the washing machine disconnect it from the mains
supply.
After installation, access to the mains plug or to disconnection from the mains
supply must be ensured at all times via an electric switch.
Do not operate the washing machine if it has been damaged during transport.
Inform After-Sales Service.
Mains cable replacement is only to be carried out by After-Sales Service.
The appliance must only be used in the household for the prescribed uses.
.
.
.
.
.
.
.
.
Open the tap.
Close the door.
Pour a little amount of detergent (about 30ml) into the main wash
of the detergent dispenser.
Select and start a short programme (see separate quick reference guide).
.
.
.
.
ing chamber
6
Loading
Wash items of different sizes in the same load to improve washing efficiency and
distribution in the drum.
2. Prepare the cloth for washing
Empty all pockets, coins, safety pins etc. can damage your laundry as well as
the appliance drum and tub.
Close the zips and fasten buttons or hooks; loose belts or ribbons should be
tied together.
Wash small items (e.g. nylon stockings, belts etc.) and items with hooks (e.g.
bras) in a cloth bag or pillow case with zip. Always remove curtain rings or wash
curtains with the rings inside a cotton bag.
3. Adding detergents and additives
Please refer to Section Detergent and additives.
.
.
.
.
BEFORE THE FIRST WASH CYCLE
recommend that you carry out a short wash cycle without laundry.
To remove any residual water used during testing by the manufacturer, we
5
4. Loading the laundry
Note: Overloading the machine will result in unsatisfactory washing
results and creased laundry. Please be also careful when loading the
drum with large articles. The unbalance drum could cause the machine
vibration.
Open the door.
Load the articles one at a time loosely into the drum, without overfilling.
Observe the load sizes given in the quick reference guide.
Close the door.
.
.
.
.
.
.

DETERGENTS AND ADDITIVES
Always use high efficiency, low foam detergent for a front loadmachine.
The choice of detergent depends on:
Type of fabric (cottons, easy care/synthetics, delicate items, wool)
Colour
The wash temperature
Degree and type of soiling
Note: Use only specific detergents for washing wool
Remarks:
Any whitish residues on dark fabrics are caused by insoluble compounds used in
modern phosphate-free powder detergents. If this occurs, shake or brush out the
fabric or use liquid detergents. Use only detergents and additives specifically
produced for domestic washing machines. When using descaling agents, dyes
or bleaches for the pre-wash, make sure that they are suitable for use in domestic
washing machines. Descalers could contain products which could damage your
washing machine. Do not use any solvents (e.g. turpentine, benzine). Do not
machine wash fabrics that have been treated with solvents or flammable liquids.
Dosage
Follow the dosage recommendations on the detergent pack. They depend on:
Degree and type of soiling.
Size of wash.
Follow the detergent manufacturer's instructions for a full load.
Half load: 3/4 of the amount of detergent used for a full load.
Minimum load (about 1 kg): 1/2 the amount of detergent used for a full load.
Depends on water hardness in your area (ask for information from your water
company) Soft water requires less detergent than hard water.
Notes:
Too much detergent can result in excess foam formation, which reduces washing
efficiency. If the washing machine detects too much foam, it may prevent
spinning. Insufficient detergent may result in grey laundry in time and also calcifies
the heating system, drum and hoses.
Stain removal
Blood, milk, eggs etc. are generally removed by the automatic enzyme phase of the
programme.
To remove red wine, coffee, tea, grass and fruit stains add a stain remover to the
main wash chamber of the detergent dispenser.
Pre-treat heavily-soiled areas with stain remover if necessary.
.
.
.
.
.
.
.
.
.
.
.
.
7 8
How to position the separator in the main wash
chamber for powder or liquid detergent
For use with powder detergent: Place the separator in the
higher position. Lift the separator until its top can be
reclined. Place its hooks on the upper end of the
back guide rails and slightly push the separator down to
fix it(Fig." "B and Fig. " "C ).
Only use dyes that are suitable for washing machines.
Follow the Manufacturers instructions.
Plastic and rubber parts of the washing machine can be stained by dyes.
Where to put detergent and additives
The detergent drawer has three chambers (Fig. "A") .
Pre-wash chamber
Detergent for the pre-wash / soak
Main wash chamber
Detergent for the main wash
Stain remover
Water softener (water hardness class 4)
.
.
.
.
.
.
Dyeing
Softener chamber
Fabric softener
Liquid starch
Pour additives only up to the "MAX" mark.
.
.
If you want to improve the rinse performance in the case of too much detergent
used, you can add the rinse times before you start the program.
A gap should remain between the separator and the bottom of the main wash
chamber, if the separator has been correctly installed (Fig. "B" and Fig. "C").
For use with liquid detergent: place the separator in the lower position. Secure the
separator in the chamber using the front guide rails. Position the separator so that it
touches the bottom of the main wash chamber (Fig. "D")
.
.
.

" "
Press the Start/Pause button or the Option button, and then the washing
" "
machine will start spinning progress automatically. When spinning finishes,
the programme will end automatically.
The picture is only for reference and it might be different on each model
If the selected programme and option cannot be combined,these functions will be
disabled automatically and indicator will turn off automatically.
If you select Rinse Hold , the laundry remains in the last rinse water without
" "
progressing to the final spin cycle, to avoid creasing and prevent colours
fading.
It is recommended to select this function when washing synthetic or delicate
cloths.
If you want to delay the spin, selecting this function will be useful.
Note:When the programme runs to the step before the spin, the machine will delay
spinning.
SELECT ANY DESIRED PUSH BUTTON OPTION:
Press the selected push button option once, and the corresponding indicator lights
turns on.
Rinse Hold
To cancel the Rinse Hold function
Programme End
When programme finished its running, it will display"end",user can press Power button
for 2 seconds to turn off the machine,otherwise if no operation is taken in 30 seconds,
.
.
.
Close the tap.
Open the door and take the washed clothes out.
Slightly open the door to remove moisture in the pump.
Extra Rinse
Adding extra number of rinse to prolong rinse time.
The function is suitable for areas with soft water, or to wash baby cloth, or for the
people with allergies.
If this function is selected, Eco wash option will be disabled.
You can set up manually the spin speed, temperature, rinse hold, extra rinse, Eco
and prewash.
.
. Press the" Start/Pause" button to start the program .
The time display shows the remaining of the programme time.
.
.
Notes:
Keep detergents and additives in a safe, dry place out of the reach of children.
Liquid detergents can be used for programmes with pre-wash. However, in this
case a powder detergent must be used for the main wash.
Do not use liquid detergents when activating the " Delay " function (if available
on your washing machine).
To prevent dispensing problems when using highly concentrated powder and
liquid detergents, use the special detergent ball or bag supplied with the
detergent and place it directly inside the drum.
When using descaling agents, bleaches or dyes, make sure that they are suitable
for washing machines. Descalers could contain compounds that can damage
parts of your washing machine.
Do not use any solvents in the washing machine (e.g. turpentine, benzine).
If you use starch powder, proceed as follows:
1.Wash your laundry using the desired wash programme.
2.Prepare the starch solution according to the starch manufacturer's instructions.
3.Select the "Rinse + Spin " programme, reduce the speed to 800 rpm and start the
programme.
4.Pull out the detergent drawer until you can see about 3cm of the mai n wash
chamber .
.
.
.
.
.
.
.
9 10
5.Pour the starch solution into the main wash chamber while the water is
running into the detergent drawer.
6.If there are starch residues in the detergent drawer when the programme has
finished, clean the main wash chamber.
HOW TO USE THE FRONT PANEL
Program Start
Open the tap, add detergent, load the drum and close the door.
.
Turn the selector to choose the right wash cycle for the type of fabric you are
washing. These program are including cotton, Synthetics, Delicate, Wool,
Intensive,Quick, Rinse+Spin and Spin.
.
the machine will turn off automatically.

" "
Eco Wash
This option has a shorter wash time and temperature.Therefore, it reduces the
water and energy consumption.
If the Eco Wash Function is selected, all other options will be disabled.
Prewash
This option is suitable for heavily soiled (e.g.soil, dust). The programme is
prolonged for 18 minutes.
If the Prewash function is selected, Eco Wash option will be disabled.
Spin Speed
The programme predefined spin is set to the max. Spin speed.
Press the Spin Speed button to select desired spin speeds.
If spin speed 0 is selected, the last spin process will be canceled and the
""
machine only drains the water before ending the programme.
Temp.
On selecting a program, press the Temp. button,a predefined temperature is
displayed. Then press the Temp. button again to adjust another temperature
value.
" "
Delay
Delay function allows to run the machine at the consumers convenience, for example,
at night when electricity is cheaper.To set the delay time follows this:
Select the desired programme, and options.
Press the Spin Speed +Temp. buttons simultaneously to select the delay time " "
from minimum 30 minutes to 24 hours, the minimum delay time will be vary and
depends on the selected programme.
.
The delay time displayed on the digital indicates the time when the wash
programme will be finished.
Press the Start/Pause button, the digital window will display the remaining delay
" "
time and Delay symbol alternatively.
The Delay symbol disappears when the programme starts and it is replaced
by the washing time.
To cancel the"Delay"
Before pressing Start/Pause button, turn the programme selector to another " "
programme position.
After having pressed the Start/Pause button, press the Power button for 2 " " "
seconds to turn off the machine,turn the programme selector to another programme
position.
Child Lock
In addition to the child safety lock door, the machine is equipped with Child Lock " "
function.
When the programme starts, press the Temp.+Option buttons simultaneously, LED " "
" "
" "
" "
"
will display SAFE ON after buzzing, and then Child Lock is set up." "
When the child lock is set, all function buttons will be disabled from the touch.
To unlock this during the wash if changes required to the wash program, press
Temp.+ Option buttons simultaneously, LED will display SAFE OFF after buzzing,
" "
and then Child Lock is released.
" "
At the end of program or When power is shut down, the child lock function is released.
Change programme or optional function after the programme starts.
Press Power button for 2 seconds to turn off the machine.
Turn the machine on and add some detergent if it is necessary.
select the new programme and desired options.
Re-press Start/Pause button to run the new programme. " "
Automatic Programs
This washing machine provides 8 automatic programs. Turn the selector to choose
the right wash cycle for the type of fabric you are washing. These program are
including Cotton ,Synthetics ,Delicate,Wool,Intensive,Quick, Rinse+Spin and Spin.
Press the "Start/Pause" button to start the selected wash cycle.
The picture is only for reference and it might be different on each model

11 12
Cleaning the door seal also remove the door odour which could be caused by the
CARE AND MAINTENANCE
Appliance exterior and control panel
Could be washed down with a soft, damp cloth. A little neutral detergent
(nonabrasive) can also be used. Dry it with a soft cloth.
Door seal
Clean with a damp cloth when it is necessary.
residual powder in the period of time.
Check the condition of the door seal periodically.
.
.
.

14
Filter
Check and clean the filter regularly, at least two or three times a year (see
"Removing the filter section)."
Do not use flammable fluids for cleaning the appliance.
.
.
year.
Especially:
If the appliance is not draining properly or if it fails to perform spin cycles.
If the pump is blocked by a foreign body (e.g. buttons, coins or safety pins).
.
.
Removing the Filter
We recommend that you check and clean the filter regularly, at least twice or three
times a
IMPORTANT: Ensure that the water has cooled before draining the appliance.
.
Stop the appliance and unplug it.
Depending on the model, remove the plinth by holding it tightly on both
sides, pushing it downward and tilting it to the front. Or, push down on
the tabs provided on both the sides and remove it .(Fig. "a")
Place a container beneath it.
Wait until all the water has drained.
1
2
3
4
5
Now unscrew the filter completely and remove it (Fig. "b").
Check that the pump rotor moves freely.
6
7
8
9
Clean the filter and the filter chamber.
a
d
e
Detergent dispenser
downward and remove the drawer (Fig. "d").
Remove the cover grid from the fabric softener
compartment.
Remove the separator from the main wash compartment
by pulling it upward (Fig. "e").
Wash all the parts under running water.
Refit the separator and the grid in the detergent drawer
and fit the drawer back inside its housing.
Press the release lever in the main wash compartment
.
.
.
.
.
13
Water supply hose
Check the supply hose regularly for brittleness and cracks and
replace it if necessary using a new hose of the same type
(available from After-Sales Service or specialist dealer).
Mesh filter for water connection
Check and clean regularly.
For washing machines with an inlet hose as shown on Fig."f ".
f
Close the tap and loosen the inlet hose on the tap.
Clean the internal mesh filter and screw the water inlet hose back onto the tap.
.
.
Now unscrew the inlet hose on the rear of the washing machine.
.
.
Refit the mesh filter and screw the inlet hose on again.
Turn on the tap and ensure that the connections are completely water-tight.
.
.
Pull of the mesh filter from the washing machine connection with universal pliers
Open the filter but do not remove it completely. Slowly turn the filter
counterclockwise until all the water has drained.
b
Pour about 1 litre of water into the detergent drawer to check that the filter is
inserted properly and securely. .
10
11
Reinstall the plinth.
12
Re-insert the filter and screw it in clockwise as far as it will go.
To re-insert the filter make sure the small lug/clip(as shown in the Fig."c")is
facing up and then push the filter into the hosing first. After that start screwing
the filter in clockwise as far as it will go(Fig."c").
Plug in the appliance once again.
Select a programme and start it.
13
14
c
