Hitachi ZAXIS 135US-5B User manual

ENMDCN-1-1ZX135US-5B •225US-5B •225USLC-5B HYDRAULIC EXCAVATOR OPERATOR'S MANUAL
URL:http://www.hitachi-c-m.com
ENMDCN-1-1
PART NO.
Operator's Manual
PRINTED IN JAPAN (E) 2015, 12
135US-5B
225US-5B
225USLC-5B
Serial No.
ZX135US-5B 090001 and up
ZX225US-5B 300001 and up
ZX225USLC-5B 300001 and up
Hydraulic Excavator

©2015 Hitachi Construction Machinery Co., Ltd.
All rights reserved.
INTRODUCTION
All information, illustrations and specifications in this manual are based on the latest product information available at the
time of publication. The right is reserved to make changes at any time without notice.
Read this manual carefully to learn how to operate and
service your machine correctly. Failure to do so could
result in personal injury or machine damage.
This standard specification machine can be operated
under the following conditions without being modified.
Atmospheric Temperature: –20 °C to 40 °C (–4 °F to 104 °F)
Altitude: 0 m to 2000 m (0 ft to 6600 ft)
In case the machine is used under conditions other than
described above, consult your nearest Hitachi dealer.
This manual should be considered a permanent part of
your machine and should remain with the machine when
you sell it.
This machine is of metric design. Measurements in this
manual are metric. Use only metric hardware and tools as
specified.
Right-hand and left-hand sides are determined by
facing in the direction of forward travel.
Write product identification numbers in the Machine
Numbers section. Accurately record all the numbers
to help in tracing the machine should it be stolen.
Your dealer also needs these numbers when you order
parts. If this manual is kept on the machine, also file the
identification numbers in a secure place off the machine.
Be sure to use fuel that complies with JIS K-2204, EN-590
or ASTM D-975 which contains 15 ppm or lower sulfur.
Also use fuel that complies with solid contamination level
of class 18/16/13 of ISO4406-1999 (solid contamination
includes dust). If the fuel specified above is not used,
exhaust gas that exceeds the regulation values may be
discharged, causing serious problem on the engine.
Consult your nearest Hitachi dealer.
Warranty is provided as a part of Hitachi’s support
program for customers who operate and maintain their
equipment as described in this manual. The warranty is
explained on the warranty certificate which you should
have received from your dealer.
This warranty provides you the assurance that Hitachi
will back its products where defects appear within the
warranty period. In some circumstances, Hitachi also
provides field improvements, often without charge to the
customer, even if the product is out of warranty.
Should the equipment be abused, or modified to
change its performance beyond the original factory
specifications, the warranty will become void and field
improvements may be denied.
Setting fuel delivery above specifications or otherwise
overpowering machines will result in such action.
Only qualified, experienced operators officially licensed
(according to local law) should be allowed to operate
the machine. Moreover, only officially licensed personnel
should be allowed to inspect and service the machine.
PRIOR TO OPERATING THIS MACHINE, INCLUDING
COMMUNICATION SYSTEM, IN A COUNTRY OTHER
THAN A COUNTRY OF ITS INTENDED USE, IT MAY
BE NECESSARY TO MAKE MODIFICATIONS TO IT SO
THAT IT COMPLIES WITH THE LOCAL REGULATORY
STANDARDS (INCLUDING SAFETY STANDARDS)
AND LEGAL REQUIREMENTS OF THAT PARTICULAR
COUNTRY. PLEASE DO NOT EXPORT OR OPERATE
THIS MACHINE OUTSIDE OF THE COUNTRY OF ITS
INTENDED USE UNTIL SUCH COMPLIANCE HAS
BEEN CONFIRMED. PLEASE CONTACT HITACHI
CONSTRUCTION MACHINERY CO., LTD. OR ANY OF
OUR AUTHORIZED DISTRIBUTOR OR DEALER IF YOU
HAVE ANY QUESTIONS CONCERNING COMPLIANCE.

INDEX
ENMDCN-1-1
T
MACHINE NUMBERS
SAFETY
SAFETY SIGNS
COMPONENTS NAME
GETTING ON/OFF THE MACHINE
OPERATOR’S STATION
BREAK-IN
OPERATING THE ENGINE
DRIVING THE MACHINE
OPERATING THE MACHINE
TRANSPORTING
MAINTENANCE
HYDRAULIC CIRCUIT AND ELECTRICAL CIRCUIT
MAINTENANCE UNDER SPECIAL ENVIRONMENTAL CONDITIONS
STORAGE
TROUBLESHOOTING
SPECIFICATIONS
INDEX OPTIONAL ATTACHMENTS AND DEVICES
INDEX

CONTENTS
MACHINE NUMBERS .........................................................1
SAFETY .......................................................................... S-1
Recognize Safety Information ....................................................S-1
Understand Signal Words.............................................................S-1
Follow Safety Instructions............................................................S-2
Prepare for Emergencies...............................................................S-3
Wear Protective Clothing..............................................................S-3
Protect Against Noise ....................................................................S-4
Inspect Machine ..............................................................................S-4
General Precautions for Cab........................................................S-5
Use Handholds and Steps ............................................................S-6
Adjust the Operator's Seat ...........................................................S-6
Ensure Safety Before Rising from or
Leaving Operator’s Seat...........................................................S-7
Fasten Your Seat Belt......................................................................S-7
Move and Operate Machine Safely...........................................S-8
Operate Only from Operator's Seat ..........................................S-8
Jump Starting ...................................................................................S-9
Keep Riders off Machine ...............................................................S-9
Precautions for Operations....................................................... S-10
Investigate Job Site Beforehand ............................................. S-11
Install OPG Guard.........................................................................S-12
Restriction of Attachment Installation ................................. S-13
Provide Signals for Jobs Involving Multiple Machines....S-13
Confirm Direction of Machine to Be Driven........................ S-13
Drive Machine Safely................................................................... S-14
Avoid Injury from Rollaway Accidents.................................. S-16
Avoid Injury from Back-Over and Swing Accidents ......... S-17
Keep Person Clear from Working Area.................................. S-18
Never Position Bucket Over Anyone ..................................... S-18
Avoid Undercutting..................................................................... S-19
Avoid Tipping................................................................................. S-19
Never Undercut a High Bank.................................................... S-20
Dig with Caution........................................................................... S-20
Operate with Caution ................................................................. S-20
Avoid Power Lines........................................................................ S-21
Precautions for Lightning.......................................................... S-21
Object Handling ........................................................................... S-22
Protect Against Flying Debris ..................................................S-22
Park Machine Safely..................................................................... S-23
Handle Fluids Safely−Avoid Fires............................................ S-23
Transport Safely ............................................................................ S-24
Practice Safe Maintenance........................................................ S-25
Warn Others of Service Work ................................................... S-26
Support Machine Properly........................................................ S-26
Stay Clear of Moving Parts ........................................................ S-27
Prevent Parts from Flying .......................................................... S-27
Avoid Injury from Attachment Falling Accident .............. S-28
Prevent Burns................................................................................. S-28
Replace Rubber Hoses Periodically........................................ S-29
Avoid High-Pressure Fluids....................................................... S-29
Prevent Fires................................................................................... S-30
Evacuating in Case of Fire.......................................................... S-32
Beware of Exhaust Fumes.......................................................... S-32
Precautions for Welding and Grinding ................................. S-33
Avoid Heating Near Pressurized Fluid Lines ....................... S-34
Avoid Applying Heat to Lines Containing
Flammable Fluids.................................................................... S-34
Precautions for Handling Accumulator and
Gas Damper .............................................................................. S-34
Remove Paint Before Welding or Heating........................... S-35
Beware of Asbestos and Silicon Dust and Other
Contamination......................................................................... S-35
Prevent Battery Explosions ....................................................... S-36
Service Air Conditioning System Safely ............................... S-36
Handle Chemical Products Safely........................................... S-37
Dispose of Waste Properly......................................................... S-37
Never Ride Attachment.............................................................. S-38
Notes for Muffler Filter................................................................ S-38
Precautions for Communication Terminal........................... S-38
Precaution for Communication Terminal Equipment ..... S-39
Notes on Protection of Operator’s Station When the
Machine Rolls Over................................................................. S-41
SAFETY SIGNS ............................................................. S-42
COMPONENTS NAME.................................................... 1-1
Components Name ........................................................................1-1
GETTING ON/OFF THE MACHINE ................................. 1-2
OPERATOR'S STATION................................................... 1-3
Muffler Filter......................................................................................1-3
Cab Features (Std. Model) ............................................................1-6
Multi Function Monitor.................................................................1-7
Default Setting .................................................................................1-8
Basic Screen.......................................................................................1-9
How to Use Screens..................................................................... 1-10
Displaying Basic Screen........................................................1-10
Hour Meter................................................................................1-13
Clock............................................................................................ 1-13
Fuel Gauge ................................................................................1-13
Coolant Temperature Gauge .............................................. 1-14
Operating Status Icon Display............................................1-14
Security Functions (Optional)..................................................1-15
Input Password ........................................................................ 1-15
Extending Password Duration Time.................................1-16
Alarm Occurrence Screen.......................................................... 1-17
Remedy............................................................................................1-19
Muffler Filter................................................................................... 1-23
Muffler Filter Condition Display.........................................1-23
Muffler Filter Manual Regeneration Request................ 1-24
Manual Regeneration Procedure ......................................1-25
Main Menu...................................................................................... 1-26
Air Conditioner..............................................................................1-27
Circulation Air Mode..............................................................1-27
Air Conditioner ON/OFF.......................................................1-27
Radio.................................................................................................1-28
Work Mode .....................................................................................1-29
Attachment Selection ........................................................... 1-29
Mail (Optional)...............................................................................1-30
Setting Menu .................................................................................1-32
Date and Time................................................................................1-33
Time Adjustment ....................................................................1-33

CONTENTS
Date Adjustment.....................................................................1-35
Display Mode Setting............................................................ 1-37
Attachment Adjustment............................................................1-39
Flow Rate Adjustment........................................................... 1-39
Priority (arm roll-out)............................................................. 1-41
Priority (arm roll-in)................................................................ 1-43
Attachment Name Input............................................................ 1-45
Auto Shut-Down...........................................................................1-47
Auto Shut-Down: ON/OFF ................................................... 1-47
Acting Time Setting................................................................1-48
Muffler Filter Regeneration Inhibited ...................................1-49
Setting Procedure...................................................................1-49
Password Change (Optional)....................................................1-51
Sub Meter........................................................................................1-55
Rear View Camera Monitor ....................................................... 1-57
Rear View Camera ON/OFF..................................................1-57
Brightness Adjustment...............................................................1-59
Language Settings....................................................................... 1-61
Lists of Display Language.......................................................... 1-63
Unit Selection ................................................................................ 1-64
Display Item Selection (Rear View Camera OFF)...............1-66
Main Menu Sequence Change ................................................ 1-68
Information Menu........................................................................1-70
Operation ........................................................................................ 1-71
Fuel Consumption ..................................................................1-71
Breaker Operation ..................................................................1-73
Attachment Operation..........................................................1-75
Travel Operation......................................................................1-77
Actual Operation..................................................................... 1-79
Maintenance ..................................................................................1-81
Remaining Time and Maintenance Interval ..................1-83
Monitoring...................................................................................... 1-85
Switch Panel...................................................................................1-87
Return to Previous Screen (Monitor) ...............................1-88
Return to Basic Screen (Monitor) ...................................... 1-88
Select/Confirm Switch (Monitor).......................................1-88
Temperature Control Switch/Mode Switch
(Air Conditioner) ................................................................1-88
AUTO/OFF Switch/Fan Switch (Air Conditioner).......... 1-88
AM/FM Selector/Tuning Switch (Radio).......................... 1-89
Power Switch/Volume Control Knob (Radio)................ 1-89
Engine Control Dial ................................................................ 1-89
Auto-Idle Switch...................................................................... 1-90
Travel Mode Switch................................................................1-90
Power Mode Switch ............................................................... 1-91
Work Light Switch................................................................... 1-91
Wiper/Washer Switch ............................................................1-92
Overhead Window Wiper and Washer Switch
(Optional) .............................................................................1-93
Numeric Keypad...................................................................... 1-93
Switch Panel (for Optional Equipment)................................ 1-94
Travel Alarm Deactivation Switch..................................... 1-95
Swing Alarm Deactivation Switch (Optional)............... 1-95
Rear Light Switch (Optional)............................................... 1-95
Overload Alarm Switch (Optional).................................... 1-95
Seat Heater Switch ................................................................1-96
Revolving Light Switch (Optional).................................... 1-96
Electrical Control Main Switch (Optional) ...................... 1-96
Key Switch.......................................................................................1-97
Power Boost Switch..................................................................... 1-97
Horn Switch....................................................................................1-97
Electrical Control Main Switch (Optional)............................ 1-98
Cigar Lighter.................................................................................1-100
Using Cigar Lighter ..............................................................1-100
Using Cigar Lighter Port as External Power
Source..................................................................................1-100
Cab Light Switch.........................................................................1-101
Installing Fire Extinguisher (Optional) ................................1-101
Pilot Control Shut-Off Lever ...................................................1-102
Engine Stop Switch....................................................................1-102
Fuse Box.........................................................................................1-103
Auto Air Conditioner .................................................................1-104
Features:...................................................................................1-104
Components Name..............................................................1-105
Controller Part Name and Function ...............................1-106
Cab Heater Operation .........................................................1-108
Cooling Operation................................................................1-109
Defroster Operation.............................................................1-110
Cool Head/Warm Feet Operation....................................1-110
Tips for Optimal Air Conditioner Usage .............................1-111
For Rapid Cooling .................................................................1-111
When Windows Become Clouded ..................................1-111
Off-Season Air Conditioner Maintenance....................1-111
AM/FM Radio Operation..........................................................1-112
Controls on the Radio..........................................................1-112
Tuning Procedure .................................................................1-112
Station Presetting Procedure............................................1-113
Station Auto-Presetting Procedure ................................1-114
TONE Control..........................................................................1-115
Audio Input (Optional) .............................................................1-116
Side Monitor (Optional) ...........................................................1-117
Layout .......................................................................................1-117
Monitor Operation ..............................................................1-117
Cab Door Release Lever ...........................................................1-118
Opening/Closing and Removing Cab Inside
Window ....................................................................................1-119
Opening Upper Front Window..............................................1-120
Removing and Storing Lower Front Window...................1-121
Opening Side Windows............................................................1-122
Opening/Closing Overhead Window (Std. Model) ........1-123
Opening/Closing Overhead Window (Clear Hatch: If
Equipped) ................................................................................1-124
Emergency Exit ...........................................................................1-125
Adjusting Operator's Seat .......................................................1-126
Seat Height and Angle Adjustment ...............................1-126
Console and Seat Fore-aft Adjustment.........................1-126
Seat Fore-Aft Adjustment ..................................................1-126
Suspension Adjustment .....................................................1-126
Backrest Adjustment ...........................................................1-127
Armrest Adjustment ............................................................1-127
Adjusting Operator's Seat (Optional)..................................1-128
Adjusting Seat Height.........................................................1-128

CONTENTS
Console and Seat Fore-aft Adjustment.........................1-128
Seat Fore-Aft Adjustment ..................................................1-128
Suspension Adjustment .....................................................1-129
Fore-Aft Position Adjustment of Seat Surface............1-129
Angle Adjustment of Seat Surface..................................1-129
Backrest Adjustment ...........................................................1-129
Armrest Adjustment ............................................................1-129
Console Height Adjustment...................................................1-130
Adjusting Procedures..........................................................1-130
Installation and Adjustment of Mirrors ..............................1-131
Seat Belt.........................................................................................1-132
Battery Disconnect Switch......................................................1-133
Switch Operation ..................................................................1-133
BREAK-IN ....................................................................... 2-1
Observe Engine Operation Closely...........................................2-1
Every 8 Hours or Daily....................................................................2-1
After the First 50 Hours .................................................................2-1
After the First 100 Hours...............................................................2-1
OPERATING THE ENGINE .............................................. 3-1
Inspect Machine Daily Before Starting ....................................3-1
Before Starting Engine ..................................................................3-2
Starting the Engine.........................................................................3-3
Check Instruments After Starting..............................................3-7
Using Booster Batteries.................................................................3-8
Stopping the Engine ................................................................... 3-10
Engine Auto-Stop in Extremely Low Temperature...........3-11
DRIVING THE MACHINE ................................................ 4-1
Drive the Machine Carefully........................................................4-1
Steering the Machine Using Pedals..........................................4-2
Steering the Machine Using Levers ..........................................4-3
Travel Mode Switch ........................................................................4-4
Travel Alarm.......................................................................................4-4
Operating on Soft Ground ...........................................................4-5
Raise One Track Using Boom and Arm ....................................4-5
Towing Machine a Short Distance.............................................4-6
Operating in Water or Mud..........................................................4-7
Parking the Machine on Slopes..................................................4-8
Parking the Machine ......................................................................4-8
OPERATING THE MACHINE........................................... 5-1
Control Lever (ISO Pattern) ..........................................................5-1
Attachment Pedal (Hydraulic Breaker) (Optional)...............5-2
Attachment Pedal (Hydraulic Crusher) (Optional)...............5-3
Pilot Control Shut-Off Lever ........................................................5-4
Warming Up Operation.................................................................5-5
Engine Speed Control....................................................................5-6
Auto-Idle.............................................................................................5-7
Auto Shut-Down..............................................................................5-9
Muffler Filter Manual Regeneration....................................... 5-12
Work Mode .....................................................................................5-14
Power Boost Switch..................................................................... 5-17
Power Mode ...................................................................................5-18
Operating Backhoe...................................................................... 5-19
Shovel...............................................................................................5-20
Grading Operation....................................................................... 5-21
Do Not Strike the Ground with Bucket Teeth.....................5-22
Avoid Hammer Work...................................................................5-22
Avoid Abusive Operation .......................................................... 5-23
Avoid Side Load the Bucket......................................................5-23
Do Not Use Wide Track Shoes on Rough Ground. ............ 5-24
Hydraulic Breaker, Hydraulic Crusher and
Quick Coupler...........................................................................5-25
Piping for Breaker and Crusher ...............................................5-26
Operational Procedures for Stop Valves and
Selection Valve.........................................................................5-26
Secondary Relief Pressure Adjustment ................................ 5-27
Precautions for Breaker Operation......................................... 5-28
Change Hydraulic Oil and Replace Full-Flow Filter
Element ......................................................................................5-32
Precautions for Crusher Operation ........................................5-33
Attachment.....................................................................................5-36
Attachment Connection Parts.................................................5-40
Precaution for Arm Roll-In/Bucket Roll-In Combined
Operation................................................................................... 5-42
Shackle Hole Usage ..................................................................... 5-42
Pilot Accumulator Functions....................................................5-43
How to Lower Boom in Case of Emergency and
When Engine Stops................................................................ 5-44
Precautions for After Operations............................................ 5-45
TRANSPORTING ............................................................ 6-1
Transporting by Road ....................................................................6-1
Loading/Unloading on a Trailer .................................................6-2
Fastening Machine for Transporting ........................................6-5
Unloading ..........................................................................................6-5
Lifting Machine ................................................................................6-7
MAINTENANCE.............................................................. 7-1
Correct Maintenance and Inspection Procedures...............7-1
Check the Hour Meter Regularly................................................7-3
Preparations for Inspection and Maintenance .....................7-6
Hood and Access Covers...............................................................7-7
Daily Check........................................................................................7-9
Maintenance Guide ..................................................................... 7-10
Periodic Replacement of Parts................................................. 7-15
Kind of Oils...................................................................................... 7-16
Recommended Engine Oil...................................................7-16
A. Greasing......................................................................................7-19
Front Joint Pins ........................................................................7-19
Swing Bearing .......................................................................... 7-21
Swing Internal Gear................................................................7-22
B. Engine.......................................................................................... 7-23
Engine Oil Level....................................................................... 7-23
Change Engine Oil .................................................................7-25
Replace Engine Oil Filter....................................................... 7-25
Check and Clean Around the Engine...............................7-27
C. Transmission.............................................................................. 7-28
Pump Transmission ...............................................................7-28
Swing Reduction Gear ..........................................................7-29
Travel Reduction Gear...........................................................7-30
D. Hydraulic System..................................................................... 7-32
Inspection and Maintenance of Hydraulic Equipment... 7-32

CONTENTS
Check Hydraulic Oil Level ....................................................7-36
Change Hydraulic Oil............................................................. 7-37
Air Bleeding Procedures....................................................... 7-39
Suction Filter Cleaning.......................................................... 7-40
Replacement of Full-Flow Filter .........................................7-41
Replace Pilot Oil Filter............................................................7-44
Replace Air Breather Element............................................. 7-45
Check Hoses and Lines .........................................................7-46
E. Fuel System ................................................................................ 7-50
Recommended Fuel...............................................................7-50
Refueling.................................................................................... 7-51
Drain Fuel Tank Sump............................................................ 7-52
Drain Fuel Filter........................................................................ 7-53
Replace Fuel Main Filter Element...................................... 7-57
Replace Fuel Pre-Filter Element.........................................7-59
Clean Solenoid Fuel Pump Strainer.................................. 7-61
Check Water Separator .........................................................7-63
Check Fuel Hoses .................................................................... 7-65
F. Air Cleaner................................................................................... 7-66
Clean and Replace Air Cleaner Element (Outer)..........7-66
Clean or replace the outer element. ................................ 7-66
G. Cooling System ........................................................................7-69
Check Coolant Level ..............................................................7-70
Check and Adjust Fan Belt Tension .................................. 7-71
Change Coolant.......................................................................7-73
Clean Radiator/Oil Cooler/Inter Cooler Core................. 7-75
Clean Oil Cooler, Radiator and Inter Cooler Front
Screen....................................................................................7-77
Clean Air Conditioner Condenser..................................... 7-77
Clean Fuel Oil Cooler ............................................................. 7-77
H. Electrical System......................................................................7-78
Battery......................................................................................... 7-79
Replace Battery........................................................................7-82
Replacing Fuses.......................................................................7-84
I. Miscellaneous.............................................................................7-86
Check and Replace Bucket Teeth ...................................... 7-86
Change Bucket.........................................................................7-92
Convert Bucket Connection Into Face Shovel.............. 7-93
Adjust Bucket Linkage ..........................................................7-94
Remove Travel Levers ............................................................ 7-95
Check and Replace Seat Belt...............................................7-95
Check Windshield Fluid Level............................................. 7-96
Check Track Sag....................................................................... 7-97
Clean and Replace Air Conditioner Filter .....................7-101
Check Air Conditioner.........................................................7-104
Clean Cab Floor......................................................................7-106
Retighten Cylinder Head Bolt...........................................7-107
Inspect and Adjust Valve Clearance...............................7-107
Measure Engine Compression Pressure........................7-107
Check Starter and Alternator............................................7-107
Check and Replace EGR Device .......................................7-107
Clean EGR Cooler ..................................................................7-107
Check Turbocharger.............................................................7-107
Check Gas Damper...............................................................7-108
Tightening and Retightening Torque of
Nuts and Bolts...................................................................7-108
J. Muffler Filter .............................................................................7-123
Check and Clean Filter Element of Muffler Filter.......7-123
Check and Clean Muffler Filter.........................................7-123
HYDRAULIC CIRCUIT AND ELECTRICAL CIRCUIT ........ 8-1
Hydraulic Circuit ..............................................................................8-1
Electrical Circuit ...............................................................................8-2
MAINTENANCE UNDER SPECIAL ENVIRONMENTAL
CONDITIONS ................................................................. 9-1
Maintenance Under Special Environmental Conditions...9-1
STORAGE ..................................................................... 10-1
Storing the Machine.................................................................... 10-1
TROUBLESHOOTING................................................... 11-1
Troubleshooting ...........................................................................11-1
SPECIFICATIONS ......................................................... 12-1
Specifications.................................................................................12-1
ZX135US-5B .............................................................................. 12-1
Working Ranges (Grouser shoe)..............................................12-2
ZX135US-5B .............................................................................. 12-2
Shoe Types and Applications...................................................12-3
ZX135US-5B .............................................................................. 12-3
Bucket Types and Applications ...............................................12-4
ZX135US-5B .............................................................................. 12-4
Specifications.................................................................................12-5
ZX225US-5B, 225USLC-5B.................................................... 12-5
Working Ranges (Grouser shoe)..............................................12-6
ZX225US-5B, 225USLC-5B.................................................... 12-6
Shoe Types and Applications...................................................12-7
ZX225US-5B .............................................................................. 12-7
ZX225USLC-5B .........................................................................12-7
Bucket Types and Applications ...............................................12-8
ZX225US-5B, 225USLC-5B.................................................... 12-8
OPTIONAL ATTACHMENTS AND DEVICES................. 13-1
Using Pad Crawler Shoe.............................................................13-1
Traveling and Other Cautions.................................................. 13-2
Transporting................................................................................... 13-3
Precautions for Transporting Machines with
Pad Crawler Shoes .................................................................. 13-3
Long Arm Operation --- If Equipped......................................13-8
Blade Lever .....................................................................................13-9
Avoid Hitting Blade with Front-End Attachment............13-10
Blade Maintenance....................................................................13-11
Specifications...............................................................................13-12
ZX135US-5B with Blade......................................................13-12
Working Ranges..........................................................................13-13
ZX135US-5B with Blade......................................................13-13
Shoe Types and Applications.................................................13-14
ZX135US-5B with Blade......................................................13-14
Specifications...............................................................................13-15
ZX225USLC-5B with Blade.................................................13-15
Working Ranges (Grouser shoe)............................................13-16
ZX225USLC-5B with Blade.................................................13-16
Shoe Types and Applications.................................................13-17
ZX225USLC-5B with Blade.................................................13-17

CONTENTS
Bucket Teeth (Transverse-Type-Pin-Used Type) ..............13-18
INDEX........................................................................... 14-1

CONTENTS
MEMO
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................

1
MACHINE NUMBERS
The manufacturing Nos. explained in this group is the
individual number (serial No.) given to each machine and
hydraulic components. These numbers are requested when
inquiring any information on the machine and/or components.
Fill these serial Nos. in the blank spaces in this group to
immediately make them available upon request.
Machine
TYPE :
PRODUCT
IDENTIFICATION
NUMBER :
Product Identification Number
fNOTE:
*HCMDCN20L00030001*
Engine
TYPE :
MFG. NO. :
M157-00-001
MDAA-00-001
(ZX225US-5B,
225USLC-5B)
(ZX135US-5B)
Marks to indicate the
start and end of the PIN
PRODUCT IDENTIFICATION NUMBER (PIN)
M157-12-008
M178-00-002

MACHINE NUMBERS
2
Muffler Filter
TYPE :
MFG. NO. :
DOC (Diesel Oxidation Catalyst)
TYPE :
MFG. NO. :
Travel Motor
TYPE :
MFG. NO. :
Swing Motor
TYPE :
MFG. NO. :
M178-07-047
M178-07-086
MDAA-00-002
MDAA-00-002

MACHINE NUMBERS
3
Hydraulic Pump
(ZX135US-5B)
TYPE :
MFG. NO. :
(ZX225US-5B, 225USLC-5B)
TYPE :
MFG. NO. :
MDAA-00-003
MDAA-07-072

MACHINE NUMBERS
4
MEMO
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................

S-1
SAFETY
SA-688
SA-1223
Recognize Safety Information
These are the SAFETY ALERT SYMBOLS.
When you see these symbols on your machine or in this
manual, be alert to the potential for personal injury.
Follow recommended precautions and safe operating
practices.
Understand Signal Words
On machine safety signs, signal words designating the
degree or level of hazard - DANGER, WARNING, or CAUTION
- are used with the safety alert symbol.
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury.
CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
DANGER or WARNING safety signs are located near
specific hazards. General precautions are listed on
CAUTION safety signs.
Some safety signs do not use any of the designated signal
words above after the safety alert symbol are occasionally
used on this machine.
To avoid confusing machine protection with personal
safety messages, a signal word IMPORTANT indicates a
situation which, if not avoided, could result in damage to
the machine.
NOTE: indicates an additional explanation for an
element of information.

SAFETY
S-2
SA-003
Follow Safety Instructions
Carefully read and follow all safety signs on the machine
and all safety messages in this manual.
Safety signs should be installed, maintained and replaced
when necessary.
If a safety sign or this manual is damaged or missing,
order a replacement from your authorized dealer in the
same way you order other replacement parts (be sure to
state machine model and serial number when ordering).
Learn how to operate the machine and its controls correctly
and safely.
Allow only trained, qualified, authorized personnel to
operate the machine.
Keep your machine in proper working condition.
Unauthorized modifications of the machine may impair
its function and/or safety and affect machine life.
Do not modify any machine parts without authorization.
Failure to do so may deteriorate the part safety, function,
and/or service life. In addition, personal accident,
machine trouble, and/or damage to material caused by
unauthorized modifications will void Hitachi Warranty
Policy.
Never attempt to modify or disassemble the inlet/exhaust
parts and the muffler filter. Avoid giving shocks on the
muffler filter by striking elements with other objects or
dropping the elements. Failure to do so may affect the
exhaust gas purifying device, possibly damaging it or
lowering its performance.
Do not use attachments and/or optional parts or
equipment not authorized by Hitachi. Failure to do so
may deteriorate the safety, function, and/or service life
of the machine. In addition, personal accident, machine
trouble, and/or damage to material caused by using
unauthorized attachments and/or optional parts or
equipment will void Hitachi Warranty Policy.
The safety messages in this SAFETY chapter are intended
to illustrate basic safety procedures of machines. However
it is impossible for these safety messages to cover every
hazardous situation you may encounter. If you have any
questions, you should first consult your supervisor and/
or your authorized dealer before operating or performing
maintenance work on the machine.

SAFETY
S-3
SA-437
SA-438
Prepare for Emergencies
Be prepared if a fire starts or if an accident occurs.
Keep a first aid kit and fire extinguisher on hand.
Thoroughly read and understand the label attached on
the fire extinguisher to use it properly.
To ensure that a fire extinguisher can be always used
when necessary, check and service the fire extinguisher
at the recommended intervals as specified in the fire
extinguisher manual.
Establish emergency procedure guidelines to cope with
fires and accidents.
Keep emergency numbers for doctors, ambulance
service, hospital, and fire department posted near your
telephone.
Wear Protective Clothing
Wear close fitting clothing and safety equipment
appropriate to the job.
You may need:
A hard hat
Safety shoes
Safety glasses, goggles, or face shield
Heavy gloves
Hearing protection
Reflective clothing
Wet weather gear
Respirator or filter mask.
Be sure to wear the correct equipment and clothing for the
job. Do not take any chances.
Avoid wearing loose clothing, jewelry, or other items that
can catch on control levers or other parts of the machine.
Operating equipment safely requires the full attention of
the operator. Do not wear radio or music headphones while
operating the machine.

SAFETY
S-4
SA-435
Protect Against Noise
Prolonged exposure to loud noise can cause impairment or
loss of hearing.
Wear a suitable hearing protective device such as
earmuffs or earplugs to protect against objectionable or
uncomfortably loud noises.
Inspect Machine
Inspect your machine carefully each day or shift by walking
around it before you start it to avoid personal injury.
In the walk-around inspection be sure to cover all points
described in the "Inspect Machine Daily Before Starting"
section in the operator’s manual.
SA-434

SAFETY
S-5
General Precautions for Cab
Before entering the cab, thoroughly remove all dirt and/or
oil such as mud, grease, soil or stones that may mess up
the cab from the soles of your work boots. If any controls
such as a pedal is operated while with dirt and/or oil on
the soles of the operator’s work boots, the operator’s foot
may slip off the pedal, possibly resulting in a personal
accident.
Do not mess up around the operator’s seat with parts,
tools, soil, stones, obstacles that may fold up or turn
over, cans or lunch box. The levers or pedals become
inoperable if obstacle jams in operation stroke of the
travel levers/pedals, pilot control shut-off lever or control
levers, which may result in serious injury or death.
Avoid storing transparent bottles in the cab. Do not
attach any transparent type window decorations on
the windowpanes as they may focus sunlight, possibly
starting a fire.
Refrain from listening to the radio, or using music
headphones or mobile telephones in the cab while
operating the machine.
Keep all flammable objects and/or explosives away from
the machine.
After using the ashtray, always cover it to extinguish the
match and/or tobacco.
Do not leave cigarette lighters in the cab. When the
temperature in the cab increases, the lighter may
explode.
Use proper floor mat dedicated to the machine. If another
floor mat is used, it may be displaced and contact with
the travel pedals during operation, resulting in serious
injury or death.

SAFETY
S-6
SA-439
SA-378
Use Handholds and Steps
Falling is one of the major causes of personal injury.
When you get on and off the machine, always face the
machine and maintain a three-point contact with the
steps and handrails.
Do not use any controls as hand-holds.
Never jump on or off the machine. Never mount or
dismount a moving machine.
Before getting on or off the machine, check the condition
of the steps and handrails for sticking of slippery material
like grease or mud. Thoroughly remove such material if
stuck. In addition, repair the damage to the steps and/or
handrails. Retighten loose bolts.
Never get on and off the machine with tools in your
hands.
Adjust the Operator's Seat
A poorly adjusted seat for either the operator or for the
work at hand may quickly fatigue the operator leading to
misoperations.
The seat should be adjusted whenever changing the
operator for the machine.
The operator should be able to fully depress the pedals
and to correctly operate the control levers with his back
against the seat back.
If not, move the seat forward or backward, and check
again.
Adjust the rear view mirror position so that the best rear
visibility is obtained from the operator’s seat. If the mirror
is broken, immediately replace it with a new one.
