2010
HDTV
COLLECTION

Intro | 2-3 UltraThin LED LCD | 4-7 UltraVision LCD | 8-11 DVD • BD Combo Series | 12-15 Features Explanations | 16-17 Stepchart | 18-19 Flashback | 20-21
Experience Hitachi Brilliance
Our goal is a simple one: To create a visual experience more sparkling, more breathtaking
than any other. We are guided by generations of skillful artisans; picture and frame are
refined to perfection. Hitachi expertise is the result of over five decades of original television
engineering and manufacturing. Experience Hitachi quality.

Simply the ultimate next generation HDTV. Light Emitting Diode (LED) is the lighting technology
of the future, available today. LED is a highly efficient, environmentally friendly and mercury free
light source that delivers a brighter, more dazzling picture with less electricity. Hitachi LED HDTVs
have stunning UltraThin profiles and a unique black pearl crystal frame.
ULTRATHIN LED
ULTRAVISION LCD HDTV SERIES

1 Please see the owners guide for supported resolutions 2 Manufactured under license from Real Sound Lab, SIA.
ULTRATHIN LED
LE46S704 LE42S704 LE22S304 LE19S314 LE19S304
Advanced Sound Engineering
The new UltraThin UltraVision®HDTVs feature an
advanced 3-speaker design with a dedicated
low-frequency speaker driver to produce smooth,
rich sound. The CONEQ™ Surround technology
creates natural surround sound with accurate
directionality and solid center dialogue. 2
Feature Rich
The UltraThin UltraVision®LED Series offers 6 high
definition inputs, including 4 HDMI®pure digital inputs.
A USB port is conveniently located on the UltraThin side
for a home theater digital photo frame experience.1
Picture Performance
State-of-the-art picture performance generated by
the latest LED and liquid crystal technologies gives
you an incredibly lifelike viewing experience.
More than six million individual points of light are
fine-tuned to create the sharpest, most brilliant
picture possible. The 120Hz panel speed and
Reel120 ®movie motion technologies reveal the
smallest details with exceptional clarity.
Hitachi Quality
Experience matters.
Today’s Hitachi televisions are the result of over fifty
years of expert television engineering. All UltraVision®
TVs are ENERGY STAR® qualified.
High Design
The stunning picture is framed by an luxurious
black pearl crystal frame. The UltraThin and light
design is easily swiveled to accommodate various
viewing positions.

ULTRAVISION
ULTRAVISION LCD HDTV SERIES
Simply the ultimate HDTV. From the stunning Full HD 1080p picture quality to the convenience
of up to 8 high definition inputs, UltraVision®delivers superior Hitachi technology in a series of
some of the most energy efficient, UltraThin and beautiful televisions ever designed.

1 Please see the owners guide for supported resolutions 2 Manufactured under license from Real Sound Lab, SIA.
ULTRAVISION
L55S604 L46S604 L42S504 L32S504
Advanced Sound Engineering
These new UltraVision®HDTVs feature a powerful
24-watt stereo audio system. The CONEQ™ 3D
Sound technology delivers a natural sound stage
for smooth clear dialogue and special effects
through front firing speakers. 2
Feature Rich
The UltraVision®Series offers 7 high definition inputs,
including 4 HDMI®pure digital inputs. You can view
your photos in a slide show using the convenient
side USB input. 1
Picture Performance
The UltraVision®Series’ state-of-the-art picture
performance is generated by the latest 1080p
120Hz LCD technology, creating an incredibly
lifelike viewing experience. Reel120®smooth
movie motion reveals exceptional detail for
a true theater experience.
Hitachi Quality
Experience matters.
Today’s Hitachi televisions are the result of
over fifty years of expert television engineering.
All UltraVision®TVs are ENERGY STAR®qualified.
High Design
The stunning picture is framed by a slim, elegantly
curved gloss black bezel. The UltraVision®Series’ thin
and light design is easily swiveled to accommodate
various viewing positions.

DVD BD COMBO
COMBO LCD HDTV SERIES
These models combine a stunning HDTV viewing experience with the convenience of a
built-in DVD/Blu-ray player. Watch high definition TV, play Blu-rays, DVDs, CDs, and share
PC videos and photos with the ultimate in convenience and the stunning picture quality you
get only from Hitachi.

1 Please see the owners guide for supported resolutions
DVD BD COMBO
Cannot use the logo in box
L32BD304
Advanced Sound Engineering
Enjoy crisp dynamic sound with the built-in
stereo speakers. The speaker wave guide projects
the sound clearly to the audience.
Feature Rich
The Blu-ray™+LCD Series has BD Live and other
advanced internet capabilities. Multiple high definition
inputs, including 2 HDMI®pure digital inputs provide
for the best possible picture. View your PC photos
and videos using the PC RGB input. 1
Picture Performance
Enjoy spectacular color, razor sharp images
and the lifelike realism that only Hitachi can deliver.
The FullHD 1080p display and integrated Blu-ray™
disc player reproduce high definition movies
with lifelike clarity.
Hitachi Quality
Experience matters.
Today’s Hitachi televisions are the result of
over fifty years of expert television engineering.
All Blu-ray™+LCD Series TVs are
ENERGY STAR®qualified.
High Design
The gloss black frame’s gentle curves create
an elegant appearance.

HEADPHONE
READY
NIGHT
DAY
PH O T O V I E W E R
HIGH DESIGN
FEATURE RICH
HITACHI QUALITY
HDTV
Equipped with HDTV tuner for
over the air, live Digital TV (DTV )
broadcasts and QAM tuner for
unscrambled cable channels.
USB Photo Viewer
Slide Show - View your compatible digital
photos on-screen using the USB input on
the side panel.
Models : LE46S704, LE42S704, L55S604,
L46S604, L42S504, L32S504.
Fast Response Time
The Hitachi game mode optimizes
the picture for great game playing
speed and a clear picture.
Models : LE46S704, LE42S704, L55S604,
L46S60 4, L42S504, L 32S504, L32A404.
Black Pearl Crystal Frame
The translucent frame adds style and
sophistication to any home.
Includes all Hitachi HDTVs. Some
models may vary.
Connect Your computer
Hitachi T Vs include RGB inputs so
you can hook your computer directly
to the big screen.
Includes all HItachi HDTVs.
Optimize Your Viewing
The lightweight, elegant design
easily swivels to provide multiple
viewing positions.
Models : LE46S704, LE42S704, L55S604,
L46S60 4, L42S504, L 32S504, L32A404.
Accent Light
The Hitachi accent light can be turned
on or off for convenience.
Models : LE46S704, LE42S704
Energy Saving Design
Rest easy. All of the UltraVision LCD
TVs are energy efcient and
ENERGY STAR® qualied.
Custom Picture Memories
Customize your picture settings for bright
daytime and darker nighttime settings to
save energy and reduce eyestrain. The timer
automatically changes modes for you.
Models : LE46S704, LE42S704, L55S604,
L46S604, L42S504, L32S504.
Intelligent Light Sensor
The light sensor technology automatically
adjusts the picture when the room light
lowered to save energy and reduce
eye strain. Models: LE46S704, LE42S704,
L55S604, L46S6 04.
Lockable Picture Settings
PRO Mode allows you to customize
picture tuning and lock in professionally
calibrated settings.
Models : Models : LE46S704, LE42S704,
L55S604, L46S6 04, L42S504, L32S504
Headphone Ready
The convenient headphone jack
lets you listen to your TV without
disturbing others.
Includes all Hitachi HDTVs.
Power Off Timer
Have you ever fallen asleep with the
TV on? Hitachi’s sleep timer can
automatically turn of f your TV after
a selected time of up to 3 hours.
Includes all Hitachi HDTVs.
Closed Captions Capability
When closed captions are available,
dialogue and sound descriptions can be
added on screen in clear, easy to read text.
Includes all Hitachi HDTVs.
PICTURE PERFORMANCE
3WAYSPEAKER
Movie Motion
Perfect
ADVANCED SOUND
Powerful Equalizing Technology
CONEQ™ delivers clear, rich sound using
professional equalizing technology. Dialog is
clear and music sounds more dynamic when
the speakers are per fectly optimized.
Select Models Only.
1080p Perfected/720p Perfected
1920 pixels wide by 1080 or 1366 pixels
wide by 768 pixels tall results in clearer
details and smoother images.
Only Models: LE46S704, LE42S704, LE22S314,
L55S604, L46S6 04, L42S504, L32S504,
L32BD304 (FullHD 1080p)
Ultra Clear Fast Action
All HDTV displays 60, or 120 frames
per second to make images remarkably
sharp and clear.
Pure Digital Input
HDMI™ is the industry standard for the
highest possible digital audio, video,
and data signals.
Models : (HDMI 1) LE19S304, LE19S314,
LE22S314, (HDMI 2) L32BD304, L26D204,
(HDMI 4) LE46S704, LE42S704
Smooth Movie Motion
This HDTV’s advanced processing
power options delivers 120 frames per
second, ve-ten times faster than
ordinar y movies. Some models may var y.
Smooth Color Transitions
Experience colors that are more
realistic than ever before possible.
Models: LE46S704, LE42S704
Clear Sharp Picture
Noise reduction technology keeps
digital television picture quality
sharp and clear.
Models : UltraVision models only.
Ultra Clear Picture
The AntiGlare screen eliminates
reections so you can enjoy your HDTV
without unwanted distractions.
Models: LE46S704, LE42S704, LE22S314,
LE19S314, LE19S 304
Mercury Free
As part of our Global and social responisibility,
we are taking strong steps in reducing
our carbon footprint on Mother Earth.
Our LED models are mercury free.
Models: LE46S704, LE42S704, LE22S314,
LE19S314, LE19S 304
Energy Saving Modes
Hitachi HDTVs includes several modes
that are programmed to save energy.
Models : LE46S704, LE42S704, L55S604,
L46S60 4, L42S504, L 32S504, L32A404.
Picture Perfect
PicturePerfect processor produces
an exceptionally sharp, detailed and
noise free image.
Includes all models.
UltraThin LED
LED edge lighting enables a sleek,
slim UltraThin prole.
Models : LE46S704, LE42S704, LE22S314,
LE19S314, LE19S304
High Quality Sound
Dolby® Digital offers high quality
sound with HDTV broadcasts
and other sources.
Includes all models.
Stereo Plus Bass Driver
A bass speaker res from the back of the
cabinet for fuller sound.
Models : LE46S704, LE42S704.
Instaport™
Incorporates InstaPort™ advanced
port switching technology
Models: LE46S704, LE42S704,
L55S604, L46S6 04
x2
x3
x1
TM
TM
HIGH HIGH
HIGH GLOSS
Black Pearl Crystal
TECHNOLOGY FEATURES
Standard Features Indude: Energy Star Qualied, PC Ready, Anti-Glare, Picture Perfect, Sleep Timer, Dolby Digital and Headphone Ready Features

Model shown is Hitachi’s 2010 LED LCD HDTV
FEATURE
STEP
CHART
ULTRAVISION® LED SERIES ULTRAVISION®SERIES ALPHA SERIES LCD+BLU-RAY LCD+DVD
S704 S314 S304 S604 S504 A404 BD304 D204
46”
LE46S704
42”
LE42S704
22”
LE22S314
19”
LE19S314
19”
LE19S304
55”
L55S604
46”
L46S604
42”
L42S504
32”
L32S504
32”
L32A404
32”
L32BD304
26”
L26D204
Panel
Description
Pixels
1080p
1920x1080
1080p
1920x1080
1080p
1920x1080 720p 720p 1080p 1920x1080
1080p
1920x1080
1080p
1920x1080
1080p
1920x1080
720p
1366 x 768
1080p
1920x1080
720p
1366 x 768
Main Features
Design UltraThin LED UltraThin LED UltraThin LED UltraThin LED UltraThin LED CCFL CCFL CCFL CCFL CCFL CCFL CCFL
Table Stand Square Swivel Square Swivel Square Fixed Square Fixed Square Fixed Square Swivel Square Swivel Square Swivel Square Swivel Oval Swivel Oval Fixed Square Fixed
Auto Motion Speed 120Hz 120Hz 60Hz 60Hz 60Hz 120Hz 120Hz 120Hz 120Hz 60Hz 60Hz 60Hz
Reel120®• • • • • •
HDMI®4 (V.1.4) 4 (V.1.4) 2 (V.1.3) 1 (V.1.3) 1 (V.1.3) 4 (V.1.3) 4 (V.1.3) 4 (V.1.3) 4 (V.1.3) 4 (V.1.3) 2 2
Deep Color • • • •
Panel Bit 10-Bit 10-Bit 8-Bit 8-Bit 8-Bit 10-Bit 10-Bit 10-Bit
Custom White Balance • • • • • •
PreProgrammed Remote Illuminated Illuminated • • • •
Sound Effect CONEQ®Surround
3D
CONEQ®Surround
3D
CONEQ®3D CONEQ®3D CONEQ®3D CONEQ®3D •
Bass Woofer • •
PRO Day & Night Picture Memories with
Timer • • • • • •
MPEG Noise Reduction • • • • • •
HITACHI Logo On/Low/Off • •
USB Photo Viewer • • • • • •
Intelligent Light Sensor • •
Power LED Brightness • • • • • •
Selectable Gamma • • • • • •
Dynamic Gamma (off/Dynamic 1/Dy-
namic 2)
(off/Dynamic 1/Dy-
namic 2)
(on/off) (on/off) (on/off) (on/off)
Blue Only Mode for Calibration • •
Built-in Media DVD/ Blu-ray Player Blu-ray Player DVD Player
Pandora Compatible •
NetFlix Streaming Capable •
Feature Models

2010
Hitachi’s First LED TV.
Simply the ultimate next
generation HDTV.
Light Emitting Diode (LED)
is the lighting technology
of the future, available today.
The Channel Tunnel
(Chunnel) opens
between Britain
and France. Hong Kong is returned to China.
Barack Obama
inaugerated as president
Vancouver
Winter
Olympics
The 2002 FIFA World Cup begins,
co-hosted by South Korea and Japan.
Barry Bonds breaks Hank Aaron’s home run record
John Kennedy is
inaugurated as
president, the
youngest ever,
and promises a
“New Frontier.”
MTV is launched
as first music video
channel.
1956 1960 1961 1962 1963 1964 1965 1966 1967 1968 1969 1970 1971 1972 1973 1974 1975 1976 1977 1978 1979 1980 1981 1982 1983 1984 1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010
1973
Developed the
world’s first B/W
TV equipped
with a picture
pausing/storing
function.
(MV-1)
1981
The world’s first Picture-
in-Picture color TV.
(C26-750) 1993
Ultra thin 39” wide TV
with 39.5 cm depth.
(C39-WE40)
2000
Introduced the
“Ultravision” Plasma
TV series including the
industry’s first 32” model.
2002
Introduced world’s first
Ultravision Director’s
Series with Hybrid
Wideneck CRT and
Super Contrast Lens.
(65XWX20)
2007
World’s First 60”
Full HD1080 with
Reel60™ Film
Processing
Technology,
presenting the
motion of movies
more accurately
than ever before.
(P60X901)
2008
World’s First UltraThin
1.5 Television. Measures
just under 1.5 inches thick.
Slim, sleek, beautifully
crafted masterpiece for
a luxurious display.
The Hitachi Group celebrates its 100th Anniversary in 2010
HISTORY OF 1956-2010
EXCELLENCE
IN TELEVISION
MANUFACTURING
Elvis Presley
emerges as one
of the world’s first
rock stars
The first Paralympics
are held in Rome.
“One small step for man, one giant leap for mankind.”
First man on the moon, Neil Armstrong becomes the
first man to walk on the moon
Hank Aaron breaks Babe Ruth’s career home run
record and goes on to hit 755 career home runs.
E-Mail is invented by Ray Tomlinson of the BBN.
1969
The world’s first full
automation of the five
picture adjustments.
(CN-710CU)
1961
Launched the world first
12” B/W portable TV.
(TWX-760)
1960
Launched First
color TV.
(CT-150 21”)
1956
Memorable First B/W TV
F-100
1972
Launched the
world’s first
sound multiplex
color TV.
(CN-820LW)

© 2010 Hitachi America Ltd. All trademarks are the property of their respective owners.
Closed Caption
This television receiver provides display of television closed captioning
in accordance with Sec. 15.119 of the FCC rules.
TManufactured under license from Dolby Laboratories. Dolby and the
double-D symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI Logo and High-Denition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
Manufactured under license from Real Sound Lab, SIA. CONEQ is a
trademark of Real Sound Lab, SIA. CONEQ™ delivers clear, rich sound
using proprietary professional equalizing technology. Dialog is clear and
music sounds more dynamic when the speakers are perfectly optimized.
CONEQ HA Mode™ (Hearing Aid) technology produces natural sound
for the hearing impaired. The listener can enjoy details in music and clear
dialog often without the help of a hearing aid.
CONEQ™ Surround provides a natural surround sound with
accurate directionality and solid center dialogue. It is compatible
with all TV programs.
All specications, features and dimensions are subject to
change without notice. Refer to www.hitachi.us/tv for updates or
more information.
Celebrating 100 years of the Hitachi Group
Hitachi marked its 100th anniversary in 2010.
TM
