Hitachi R-S42YMJ Operating instructions

請妥善保管本使用說明書與保証書。
請詳閱本使用說明書，以達正確使用。
使用前，請務必詳閱「安全上之注意事項」。
■ 箱門的兩側是否調整至水平狀態 ?（ 11頁）
‧ 請使用調整腳將箱門至水平狀態。
■ 清理冰箱內
‧ 用沾濕的軟布擦拭乾淨。
■ 開始運轉後
‧ 當冰箱內尚未充分冷卻時，有時需要花上4 ~ 24小時。
‧ 有巨大的運轉聲，並非異常現象。
■ 使用自動製冰機時（ 24頁）
‧ 初次使用時可能需要24小時才能製作冰塊。
使用前須知
日立無霜全自動式
多門電冰箱
Please read this operation manual carefully and ensure
you use the appliance correctly. In particular, be sure
to read the “Safety Suggestions” section of this
operation manual before use.
Please keep this operation manual along with your guarantee card.
Notice Before Use
型號
Model R-S42YMJ
HOW TO USE HITACHI
REFRIGERATOR-FREEZER
使用說明書
Are the doors leveled? ( Pg. 11)
• Use the adjustable legs to keep the door level.
Internal cleaning
• Clean with a wet soft cloth.
After the operation
• It may take more than 4 ~ 24 hours to fully cool.
• You may hear a loud operation sound but it is not a malfunction.
When using auto ice making ( Pg. 24)
• It may take 24 hours to make the ice for the first time.
五門形式
Five doors
R-S42YMJ (A4).indd 1R-S42YMJ (A4).indd 1 4/17/09 11:33:45 AM4/17/09 11:33:45 AM

2
各部分的名稱與功能
NAME AND FUNCTION OF EACH PART
冷藏室
Refrigerator
compartment
( Pg. 16/16 頁)
Dew condensation may occur on the back surface
when the door is opened and closed frequently. If it is
undesirable, wipe off the condensation with a dry cloth.
頻繁開啟箱門，會在背面產生凝露，可用乾布
擦拭乾淨。
製冰室
26 頁
用於急速製冰時。
Pg. 26
When you want to make ice quickly.
Ice
compartment
把水倒入給水槽內可自動製冰保存。
Automatically makes and keeps ice cubes
just by filling the water supply container
with water.
( Pg. 24/24 頁)
A series of ice making operation starts only after the
interior of the refrigerator is cooled sufficiently.
It may take more than 24 hours to make ice when you
use the ice compartment for the first time.
冰箱內部充分冷卻後才能開始一系列的製冰操作。
首次使用製冰室製冰，有可能需要超過24小時的時間。
MINUS-ZERO Cooling
The effect of cool air and the
cool panel on the back
surface keeps every corner
of the refrigerator cooled.
- 0°C 低溫冷藏
冷風和背面冷卻面板的功能使冰箱
的所有角落保持冷卻。
蔬果保鮮室
Vegetable
compartment
以具有保濕，保護維生素的
特長，使保鮮能力增長。
Preserve moist and vitamins
for long lasting freshness.
( Pg. 23/23 頁)
R-S42YMJ (A4).indd 2R-S42YMJ (A4).indd 2 4/17/09 11:33:46 AM4/17/09 11:33:46 AM

3
( Pg. 20/20 頁)
( Pg. 18/18 頁)
將魚，肉等分別保存。保持食品鮮
度的高速冷凍。
Home freeze to keep meats and fishes.
可以用作平時用的小型冷凍食品空間，如冷凍
包裝，密閉容器等。
肉類、魚等的生鮮食品
Fresh meats, fishes, etc.
將肉類、魚、貝類等的生鮮食品在輕微凍結
的溫度下新鮮保存，以免破壞食品的口味。
Ice Compartment
How to maintain (How to remove parts)
Eco Alarm/Optional
How to Make Ice
Large Ice Cube Making
Care of the Water Supply Container
Cleaning the Ice Maker
Troubleshooting?
Before moving or transporting
About non-CFC refrigerators
Storable weight
What to do in these situations
Taking Care of Water Supply Pipe
Cleaning the Ice Tray
How to Change the Settings of the
Automatic Ice Maker
使用前
目 錄
用法
保養
發生問題時
規格
冷藏室
冷凍室
低溫冷凍 (低溫保存）
超速冷凍
快速冷藏
蔬果保鮮室
製冰室
製冰方法
製冰選擇
切換自動製冰機的設定內容
保養方法 (卸除組件的方法)
給水槽的保養
製冰機清潔
給水管的保養
製冰盤清潔
故障了嗎﹖
環保閃爍/可選配件
這個時候
移動‧搬運時
可收納的食品重量
有關碳氫化合物的冰箱
Before use
How to maintain
When in trouble
Specification
Making the Best Use of Your Refrigerator
Safety Suggestions (Ensure to follow these precautions)
CONTENTS
Preparations
Refrigerator Compartment
Freezer Compartment
Quick Freezing
Vegetable Compartment
Low Temperature Freezer (Low temperature storage)
Quick Cooling
Before use
使 用 前
How To Use
用 法 保養
How To Maintain
When in trouble
發生問題時 規格
Specification
4
12
16
20
23
24
28
34
35
43
45
45
Specification
規格
46
安全上的注意事項（請務必遵守）
初次使用時
14
Control Panel Name of Each Part
Storage Compartment
操作面板 各部分的名稱 儲存室
冰溫室
Chill
room
上層冷凍室
Upper
freezer
Use this freezer as a space for daily use small
frozen items such as freezing packs and airtight
containers.
To preserve freshness and taste of meats, fishes
and shellfishes. by keeping them in a slightly frozen
state.
超速冷凍可保存美味。 21 頁
( Pg. 20/20 頁)
(Quick Freezing)
(超速冷凍室)
因有3層抽屜，可保存大容量的食物。
3-level case to conveniently accommo-
date a large amount of food.
Quick Freezing to preserve food taste. ( Pg. 21)
下 層 冷凍室
Lower
freezer
R-S42YMJ (A4).indd 3R-S42YMJ (A4).indd 3 4/17/09 11:33:47 AM4/17/09 11:33:47 AM

警告
WARNING
安全上的注意事項
安全上的注意事項
安全上的注意事項
安全上的注意事項
為了防止危害到使用者或其他人及造成財務上的損失，請務必遵守以下事項。
為了防止危害到使用者或其他人及造成財務上的損失，請務必遵守以下事項。
以下將以標示方式，區分及說明忽視標示內容而誤用時所產生的危害與損失程度。
警告
注意
此標示欄表示「可能會造成死亡或身負重傷之預測內容」。
此標示欄表示「可能會造成死亡或身負重傷之預測內容」。
此圖示標示為「禁止」內容（請勿執行之事項）。
此圖示標示為「禁止」內容（請勿執行之事項）。
此圖示標示為「強制」內容（請務必執行之事項）。
此圖示標示為「強制」內容（請務必執行之事項）。
以下將以圖示標示方式，區分及說明應遵守內容的種類。（以下為圖示標示例）
請確實實施接地。
連接接地線
請勿設置於潮濕或會被水淋到的場所。
避免因電氣絕緣不良而引起觸電．火災的危險。
針對地震等天然災害做好防止翻倒處置。
避免因翻倒而受傷。（ 13 頁）
安裝時
避免因故障．漏電等因素而發生觸電。
請務必委託經銷商執行接地工程。（ 13 頁）
請務必遵守
Ensure to follow these precautions
Suggestions headed by this pictograph indicate "There is high chance of serious injury or
death" if ignored.
此標示欄表示「可能會發生受傷或財務損失之預測內容」。
此標示欄表示「可能會發生受傷或財務損失之預測內容」。
Suggestions headed by this pictograph indicate "There is a high chance of injury or damage
to property" if ignored.
WARNING
CAUTION
■How the suggestions should be taken are indicated and categorized by the following symbols
accompanied by explanations. (The symbols below are examples)
This symbol indicates something you must not do. (Prohibited)
This symbol indicates something you must do. (Compulsory)
Do not install the refrigerator in damp places or where
water may splash on.
This may impair electricity insulation causing electric shock or fire.
禁止淋濕
Wetting Prohibited
Earth Connection
Overturning of the refrigerator could result in personal injury. ( Pg. 13 )
The following pictographs categorize and explain the level of possible harm on damage
that may occur from ignoring suggestions resulting in missing the appliances.
■
Install earth leakage circuit breaker when installing the
refrigerator in a humid or damp environment.
SAFETY SUGGESTIONS
SAFETY SUGGESTIONS
SAFETY SUGGESTIONS
Installation
When using this appliance, personal harm, harm to other people, and also damage to property.
4
Electrical leakage due to failure, etc. could result in electrical shock.
Make sure to contact the dealer for earthing installation.
( Pg. 13 )
Take measures to prevent overturning of refrigerator due to earthquake, etc.
R-S42YMJ (A4).indd 4R-S42YMJ (A4).indd 4 4/17/09 11:33:48 AM4/17/09 11:33:48 AM

（繼續）
安全上的注意事項
為了防止危害到使用者或其他人及造成財務上的損失，請務必遵守以下事項。
此標示欄表示「可能會造成死亡或身負重傷之預測內容」。
此圖示標示為「禁止」內容（請勿執行之事項）。
此圖示標示為「強制」內容（請務必執行之事項）。
禁止
請勿讓電線受損．加工．接近發熱器具．勉強彎曲．扭曲．拉扯．
乘載重物．讓冰箱壓住電線或捆綁電線。
在已受損的狀態下使用時，會引發觸電．短路．火災的危險。
請勿讓電線．插頭破損。
發生觸電的原因。 禁止濕手
請勿用潮濕的手，拔除插頭。
請定期清除插頭上的灰塵。
當插頭堆積灰塵時會因濕氣而造成絕緣不良，進而引起火災。
請拔除插頭再用乾布擦拭乾淨。
此標示欄表示「可能會發生受傷或財務損失之預測內容」。
Do not do anything that may damage the power cord or plug.
The power cord or plug should not be cut, modified, touched with hot implements,
bent by force, twisted, pulled, have heavy objects placed on it, squeezed by the
refrigerator, or be bound or tied up.
Using a damaged power cord may cause electric shock, short circuits, or fire.
Please consult with a retailer about the repair of the power cord or plug.
修理電線．插頭時，請洽經銷商。
Clean the dust on the power plug frequently.
Be sure to unplug the power plug before maintaining the refrigerator.
Insulation failure from moisture when dust collects on the power plug may cause fire.
Unplug the power plug and wipe it with a dry cloth.
Safety Suggestions (Continue)
將電插頭的電線向下，將插頭確實電插座內。
如果電插頭方向相反插入，會給電線增加負擔，成為短路，觸電，起火的原因。
如果電插頭插的不夠完全，也將會成為因觸電，發熱而導致火災的原因。
Connect the power plug firmly to a power outlet with the cord running down.
Connection of the power plug with the cord running up could apply stress on the cord and cause
electrical short or overheat, which could result in electrical shock or fire.
Incomplete connection of the power plug could result in electrical shock or fire due to heat.
SAFETY SUGGESTIONS
有觸電或受傷的危險。（ 28頁）
進行冰箱保養，請務必拔掉插頭。
This may result in electric shock.
Do not insert or remove the power plug with wet hands.
Continued use may cause electric shock or injury. ( Pg. 28 )
Always hold the plug when unplugging it.
請將插頭確實的從插座內拔出。
Prohibited
Wet Hands Prohibited
(Continue)
安全上的注意事項
（繼續）
使用時請勿高於插座或配線器具的額定電流。
請勿使用交流額定電壓以外的電源。 禁止
電源及電源電線
若與其他電器插頭併用，或使用三面插座等，會因異常發熱而造成火災的危險。
請單獨使用額定電流15A以上的插座。
If a power source is shared with other appliances, double or multipoint adapters may heat up beyond normal levels and cause fire.
Use a wall outlet rated above 15 ampere by itself.
Avoid usage that may cause the wall outlet or power cord
components to work beyond the specified voltage.
Also do not use power sources that are not a rated voltage current.
Handling the power and power cable
Prohibited
Before use
使 用 前
警告
WARNING
5
R-S42YMJ (A4).indd 5R-S42YMJ (A4).indd 5 4/17/09 11:33:48 AM4/17/09 11:33:48 AM

安全上的注意事項
安全上的注意事項
安全上的注意事項
安全上的注意事項
SAFETY SUGGESTIONS
SAFETY SUGGESTIONS
SAFETY SUGGESTIONS
■ Drugs, chemicals, research and experimental substances
should not be stored in the refrigerator.
Substances that require precise conditions for storage
cannot be stored in a domestic refrigerator.
請務必遵守
Ensure to follow these precautions
在一般使用的情況下
在一般使用的情況下
禁止淋濕
禁止
禁止
禁止
禁止接觸
■ 請勿將含水容器放在冰箱上。
翻倒的水會造成電氣組件絕緣不良而發生漏電．火災．觸電的危險。
■ 在附近請勿使用可燃性噴霧用品。
避免因箱門開關等電氣接點引起的火花引發火災。
必須嚴格管理的物品，不可保存於家庭用冰箱內。
■ 請勿在冰箱上放置物品。
避免因開閉箱門，造成物品掉落而受傷。
製冰盤旋轉時，手恐怕會受傷。（ 25 頁）
■ 請勿用來保存藥品或學術試樣。
■ 請勿手觸自動製冰機的機械部位。
■ Do not put water containers on the refrigerator.
Spilled water may impair insulation of electrical components causing faulty
electrical currents. This may result in electric shock or fire.
Prohibited
Prohibited
Prohibited
Wetting Prohibited
■ Do not use flammable sprays near the refrigerator.
Sparks from points of electrical contact such as door switches may ignite a fire.
■ Do not put things on top of the refrigerator.
Opening and closing doors etc. may cause things placed on top of the
refrigerator to fall resulting in injury.
■ Do not touch the machinery components of the
Automatic Ice Maker.
There is a danger of injury when the ice trays are rotating. ( Pg. 25 )
禁止
避免因翻倒，夾到手指而受傷。
■ 請勿懸在箱門上嬉戲，或踏在收納盒上。
Prohibited
■ Do not hang on the doors or step up on the various compartments.
Injury may be caused by the refrigerator tipping over or hands getting caught
between doors.
Contact Prohibited
6
During normal use
警告
WARNING
請勿用水淋濕主體與箱內。
避免因電氣絕緣不足而引起觸電．火災。 禁止淋濕
Do not splash water on or inside the refrigerator.
This may impair electricity insulation causing electric shock or fire. Wetting Prohibited
禁止
請勿放入容易引火的物品。
揮發油．乙醚．LP 瓦斯‧稀釋液．黏著劑會發生引爆的危險。
Do not put in things that may catch fire.
Benzine, ether, LP gas, thinner, adhesives may ignite an explosion. Prohibited
R-S42YMJ (A4).indd 6R-S42YMJ (A4).indd 6 4/17/09 11:33:48 AM4/17/09 11:33:48 AM

安全上的注意事項
SAFETY SUGGESTIONS
在一般使用的情況下
7
（繼續）
(Continue)
■ Do not scratch or damage the main body of the refrigerator with a
sharp object such as screw.
Since the refrigerant used is flammable, any leakage from the pipe inside the wall
may cause ignition and explosion.
若冷媒外洩會有起火、爆炸的危險。
■ 冰箱的周圍請保持充裕的空間。（ 12 頁）
■ 請勿損傷冰箱的冷卻管路。
如需進行廢棄處理時，請聯絡經銷商或環保署資源回收中心專線
(0800-085-717)，交付他們進行專業處理。
若冷媒外洩的情況持續，會有起火、爆炸的危險。
配管損壞時，請儘快將門窗打開，並與經銷商或日立技術中心聯絡。
（ 關於售後服務，請參閱說明書背面）
■ 不可以被螺絲等銳利物品刮傷冰箱本體。
由於使用可燃性的冷媒，當冷媒從冰箱內壁的配管外洩，會有起火、爆炸的危險。
禁止
Prohibited
Leakage of the refrigerant may accumulate and cause ignition and explosion.
Should you damage the refrigerator, open the window to ventilate and contact your dealer or our repair reception desk.
If the refrigerant is wet, it may cause ignition and explosion.
When the interior light is damaged, please contact either the manufacturer, the service
centre or person with required knowledge for replacing the light to avoid injury.
If you happen to damage the refrigerant pipe, stay away from the
refrigerator and avoid using fire and electrical appliances.
冷煤配管損壞時，請將冰箱遠離火源並避免使用電器用品。
■ Do not damage the refrigerant circuit.
■ Allow clearance around the refrigerator when installing it. ( Pg. 12)
■ Please consult your dealer or the Recycle Hotline [phone]) of the Recycle
Centers in the Environmental Protection Administration when discarding the unit.
警告
WARNING
關於冷媒（由於這是一種可燃性的氣體，請注意以下的事項。）
Concerning the refrigerant ( Be careful of the following related to the use of
flammable gas.)
■
■
Disconnect the power plug when replacing the interior light.
■ Use the specified interior light and insert it firmly.
更換內部燈泡時，請拔掉電插頭。
燈泡損壞時，須由製造廠商或其服務處或具有相關資格的人員
加以更換以避免危險。
■
用指定的內部燈泡并牢固地插入。
■
禁止
Prohibited
Safety Suggestions (Continue)
安全上的注意事項
（繼續）
Before use
使 用 前
R-S42YMJ (A4).indd 7R-S42YMJ (A4).indd 7 4/17/09 11:33:48 AM4/17/09 11:33:48 AM

■ Before discarding the unit or recycle, remove the door
packing to avoid the risk of an infant or children to be
entrapped inside.
■ 在等待廢棄物再生保管之際、因有幼兒被誤困在內之虞，
請將門襯條拆取下來。
廢棄處分時
警告
WARNING
8
When discarding the unit
■ 請勿自行分解．修理．改造。
禁止分解
■ Do not disassemble, repair, or modify your refrigerator.
Injury may be caused by ignition of fire or faulty running.
避免發生火災，異常動作而受傷。
Please consult with a retailer if any repairs or disassembly are required.
需分解．維修時，請洽經銷代理商。
■ 可燃性氣體外漏時，勿接觸冰箱，請立即開啟窗戶進行換氣。
Sparks from points of electrical contact such as door switches may ignite
explosions causing fire or burn injuries.
■ In the event of a flammable gas leak do not touch
refrigerator and open windows to let air flow.
避免因箱門開關等電氣接點的火花，而發生引爆．火災．燙傷等危險。
■ 當產品異常或故障時，請拔掉插頭停止運轉。
■ 請勿在冰箱內部使用電器用品。
如冷媒外洩，電氣接點所產生的火花，會有起火、爆炸的危險。 禁止
請務在拔除插頭時握住插頭。
萬一有下列情形
Prohibited
禁止
Prohibited
Dissassembly prohibited
Continue may cause electric shock or injury.
If the refrigerant leaks, sparks on the contact may cause ignition and explosion.
■ Stop the refrigerator by unplugging it if it is not running
properly or broken.
■ 不得使用吹風機等發熱器具對冰箱內進行加熱而加快除霜。
■
Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by
manufacturer.
■ Do not use electrical appliances inside the refrigerator.
有觸電或受傷的危險。
In case of emergency
Always hold the plug when unplugging it.
請務必遵守
Ensure to follow these precautions
安全上的注意事項
安全上的注意事項
安全上的注意事項
安全上的注意事項
SAFETY SUGGESTIONS
SAFETY SUGGESTIONS
SAFETY SUGGESTIONS
R-S42YMJ (A4).indd 8R-S42YMJ (A4).indd 8 4/17/09 11:33:49 AM4/17/09 11:33:49 AM

9
Prohibited
Prohibited
禁止
■ 請勿在超大瓶飲料的縫隙間再塞入其他瓶罐。
勉強放入超大瓶飲料瓶後，在開閉箱門時，可能會因掉落而受傷。
注意
■ 同時開啟二個以上的箱門時，或者其他人也在碰觸冰箱時，
請確認手指是否會被冰箱門夾住。
避免手指被門與門之間的縫隙所夾傷。
■ Do not put bottles in the Door Baskets if they do not
sit properly on the bottom of the front section.
Forcing in items like large bottles may result in them getting tipped over, causing injury.
禁止
請勿將瓶子放在冷凍室內裡。
內容物結凍會使瓶子破裂，容易受傷。
■ When two or more doors are being opened or another person is
using the refrigerator, make sure fingers don’t get caught.
Fingers may get caught in the spaces between doors causing injury.
在一般使用的情況下
CAUTION
Prohibited
禁止
■ 請勿讓食品凸出層架。
避免因鉤到瓶罐後掉落而受傷。
■ Do not have food items protruding over the front of the shelves.
■ Do not put the glass bottles in the freezer compartment.
Injury may be caused from items like bottles getting knocked over.
Bottles may break from the contents freezing and cause injury.
During Normal Use
禁止
Prohibited
■ 請勿在容易刮傷的地板上使用冰箱滑輪。
避免因滑輪而刮傷地板。
倘若沒有手持把手，可能會因手滑而受傷。（ 44 頁）
移動‧搬運時
■ 搬運時，請用手持手把搬運。
請在容易刮傷的地板上鋪上保護板。
■ On a floor that is easily scratched do move the refrigerator using the wheels at its base.
■ Use the carrying handle when carrying it.
The wheels may scratch the floor.
For a floor that may be easily scratched, lay a protective mat.
Your hands may slip resulting in injury if you hold the refrigerator in other places apart from at the carry handles. ( Pg. 44)
請僱用2人以上手持手把搬運。
搬運時請如圖示般將箱門朝上。
請不要用起重機等吊起把手。
More than 2 person should carry the refrigerator for safety reasons.
Carry it with the door facing upward; as shown in the illustration.
Never hang the handle with a crane.
When moving or carrying
（繼續）
(Continue)
安全上的注意事項
SAFETY SUGGESTIONS
Safety Suggestions (Continue)
安全上的注意事項
（繼續）
Before use
使 用 前
R-S42YMJ (A4).indd 9R-S42YMJ (A4).indd 9 4/17/09 11:33:49 AM4/17/09 11:33:49 AM

請務必遵守
Ensure to follow these precautions
安全上的注意事項
安全上的注意事項
安全上的注意事項
安全上的注意事項
SAFETY SUGGESTIONS
SAFETY SUGGESTIONS
SAFETY SUGGESTIONS
注意
CAUTION
10
Prohibited
■ Do not have your feet too close when opening
the bottom door of the refrigerator .
When opening this door you may hit the in step or other parts
of your feet resulting in injury.
禁止
■ 開啟最底層的箱門時，請勿讓腳靠近冰箱。
避免在開啟箱門時，碰觸到腳底而受傷。
Prohibited
Prohibited
■ Do not put your hands under the base surface of
the refrigerator.
When cleaning, putting your hands under the base surface of the
refrigerator may result in injury by cutting them on sheet metal parts.
禁止
禁止
■ 請勿食用有異味，已變色的食品。
避免因食品腐敗而引發疾病。
■ 請勿將手伸入冰箱底下。
清理時將手伸入冰箱底下時，可能會被鐵板割傷。
■ Do not eat food that smells strange or has changed color.
Bad foods may cause serious sickness.
初次使用時
初次使用時
Prohibited
Contact
Prohibited
禁止
禁止接觸
■ 關抽屜型的箱門時，請勿手持上方推進。
避免凍傷。（尤其是金屬製產品）
■ Do not hold the top of the doors when closing them.
If you hold the top of a door when closing it you may get your fingers caught
or pinched causing injury.
按住門上方關抽屜會夾住手指容易受傷。
■ Foods and containers inside the freezer compartment
should not be touched with wet hands.
This may cause frost injury. (Especially in the case of metal items)
■ 請勿用潮濕的手碰觸冷凍室內的食品或容器。
PREPARATIONS
R-S42YMJ (A4).indd 10R-S42YMJ (A4).indd 10 4/17/09 11:33:49 AM4/17/09 11:33:49 AM

安全上的注意事項
SAFETY SUGGESTIONS
11
初次使用時
初次使用時
初次使用時
初次使用時
初次使用時
調節腳每次旋轉的量，1圈約相差1mm。
冰箱與地板之間會慢慢的達到水平狀態，
需要大約1∼5天。
用調節腳將左右箱門進行水平固定
防止出現門體下垂．噪音．震動
手持底座蓋的兩端，用力拉向身前再予以卸除。
往下旋轉左右端的調節腳，以水平固定於地面。
用左右的調節腳將冰箱的左右門調整成水平的狀態。
將底座蓋卡榫（左右）插入安裝孔內。
右側垂下時 左側垂下時
降低左側的調節腳 降低右側的調節腳
Adjusting the refrigerator legs to keep it level
卡榫
底座蓋
調節腳
安裝孔
Leg cover
Adjustable legs
Pins
Leg holes
The left door is lowerThe right door is lower
Lower the left adjustable leg Lower the right adjustable leg
To remove the leg cover, hold both ends and pull it towards to you applying some force.
Prevents sound, vibration and doors hanging downwards
Turn both adjustable legs to lower them and fix the refrigerator.
Turn the left and right adjustable legs so they come down and make contact with the floor.
This will hold the refrigerator level.
Insert the pins (left and right) of the leg cover into the leg holes.
The door step indicates 1mm for a turn.
Use this index to turn the adjustable leg.
It could take some days (1~5 days) until the refrige-
ration fits the floor and the door is finally parallel.
PREPARATIONS
PREPARATIONS
PREPARATIONS
Safety Suggestions (Continue)
安全上的注意事項
（繼續）
Before use
使 用 前
R-S42YMJ (A4).indd 11R-S42YMJ (A4).indd 11 4/17/09 11:33:50 AM4/17/09 11:33:50 AM

初次使用時
初次使用時
初次使用時
初次使用時
初次使用時
PREPARATIONS
PREPARATIONS
PREPARATIONS
12
達到充分冷卻時，需要
花上約 4小時。
It takes about 4 hours
to fully cool down after
the power is on.
安裝場所
冰箱不是用來「提昇食品新鮮度」之用，而是用來盡可能降低食品鮮度受損之用。請按照操作說明書規定正確使用， 並
做
請在可能會導致冰箱因熱而變色或變形狀的地毯．榻榻米．
塑膠地板上鋪設堅固的板塊。
(夏季時，地板的溫度可能會高達50∼60°C。)
若地板不夠堅固，請在地板上鋪設堅固的板塊，否則冰箱會
翻倒。
以下的場合，要將1厘米厚的結實的木板鋪在冰箱的下面。
In the following places, place a hard board of approximately
1cm thick under the refrigerator to cover the whole portion of
the bottom face.
無熱源．不直接照射陽光之處。
不潮濕．通風佳之處。
左右至少1cm以上，上方為5cm以上 。
堅固．水平的地板。
A location away from direct sunlight and
heat is recommended.
The floor should be sturdy and flat.
Put some kind of sturdy boarding on the floor if the refrigerator leans
to one side, in the case of carpets that may change color from heat
exposure, or flooring and vinyl chloride floor cover. (The temperature
of the floor surface may reach 50-60°C in summer.)
The refrigerator could incline on a flexible and fragile floor.
This will reduce adverse effects to refrigerating power and keep
electricity costs down.
Direct sunlight will cause discoloration to the plastic parts of the
refrigerator.
防止降低冷卻能力，造成電力的浪費。
直射陽光也會造成部份塑料變色。
This will reduce rusting and help keep electricity costs down.
由於冰箱是用來冷藏食品，因此會從周圍散熱。若要有效發揮冷藏效果，則
請讓周圍保有充裕的空間。
本體側面中央比顯示尺寸稍大，為了提高散熱效率，請準備較富裕的安裝尺寸。
雖然背面會貼壁，但出現震動音或者壁材變黑時（受到壓縮機週邊的空氣所
影響），請讓冰箱遠離壁面。
A location is not damp and has good air
flow.
A minimum of 1cm on both sides and 5cm above.
The back of the refrigerator can be placed next to a wall; but if there is a vibrating
sound or the wall color blackens (this is caused by the air around the compressor),
then move the refrigerator away.
The refrigerator releases heat in order to keep the food cold. For efficient cooling,
allow enough space around the refrigerator.
Dimension of the center part of the side of the main body is slightly larger than the
displayed dimension. Extra dimension should thus be allowed when installing the
refrigerator for better radiation efficiency.
防止生鏽。也防止電力的浪費。
A refrigerator is not something that "increases the freshness" of food. At best "a brake that some degree will slow down food going bad" is a
l
operation manual closely and take care to use your refrigerator correctly so you can keep foods at their best.
Installation location
標貼
Sticker
請勿將背面的標貼撕掉。
會導致冰箱冷卻效能變
弱。
Do not tear off the sticker
at the back.
It may result in inefficiency
of coldness.
R-S42YMJ (A4).indd 12R-S42YMJ (A4).indd 12 4/17/09 11:33:50 AM4/17/09 11:33:50 AM

初次使用時
初次使用時
PREPARATIONS
（繼續）
（Continue）
13
Preparations (Continue)
初次使用時 （繼續）
Before use
使 用 前
左右至少1cm以上左右至少1cm以上
Minimum of 1cm or
above on both side
包括4枚螺絲
帶子
Belt
Four screws supplied
連接於專用插座上。
安裝後插入專用插座上。
電源110Ｖ額定電流15A以上。
Connected to an exclusive wall outlet.
The refrigerator can be connected
to an exclusive wall outlet soon
after it is installed.
Power 110V Rated 15A or more.
上方為5cm以上上方為5cm以上
5cm above
，
並做好適當的食品管理。
※ 若安裝於有硫化物產出的溫泉地區，有需要對配管進行防鏽處理時，請預先與指定的經銷商聯絡。
※
If you wish to install the refrigerator in a hot spring area exposed to sulfide gas, you may need to apply anti-rust treatment
to the piping. Contact your dealer in advance. Failure caused by gas damage will not be covered under guarantee.
d
" is all it is. Please follow the
接地端子
接地安裝螺絲
建議使用防止冰箱倒翻專用皮帶。「防止冰箱倒翻專用皮帶」
將皮帶穿過背面把手（2處），再固定於堅固的牆壁或支柱上。
地震對策
接地作業之實施
有接地端子時
請委託經銷商實接地工程 （丁種接地工程‧需付費）。
無接地端子時
除了實施接地之外，還具有設置漏電遮斷器材的義務。詳細內容
請洽詢經銷店。
設置於潮濕場所時
請將接地線連接於背面左下的接地安裝螺絲（ 符號）與插座上的
接地端子上。「接線圖（2.5m）」（選購品）組件型號NW-60R6 052。
接地線 (銅線直徑 1.6mm )
自來水管（有觸電的危險）
瓦斯管 （有爆炸的危險）
電話線或避雷針的接地（打雷時會發生危險）
不可連接的地方
When there is an earth terminal
Connect the earth wire to the earth connection screw on the lower left of
the rear surface ( mark) and the earth terminal on the power outlet.
“Earth wire (2.5m)” (accessory) Part No. NW-60R6 052.
When there is no earth terminal
Consult with your dealer for grounding (Type D grounding, to be charged).
It is mandatory to install an earth leakage circuit breaker as well
as grounding. Consult with your dealer for further information.
（選購品）組件型號 R-826CV 300 ×2個詳細內容請洽詢經銷店。
Pass the belt through the handles (in two places) on the
back and fix the refrigerator to the sturdy wall and poles.
We recommend using a safety belt to guard against the risk of the
refrigerator overturning.
"Safety belt against overturning for refrigerators" (option) Part number
R-826CV 300 x 2. Contact your dealer for details.
Water pipe (Danger of electric shock)
Gas pipe (Danger of explosion)
Telephone line or the earth of lighting rod
(Danger when lighting)
Must not connect
To prepare for an earthquake
Earth line
(Copper wire with diameter
of 1.6mm)
About Grounding
It is recommended to ground the refrigerator to prevent possible electrical
shock and noise interference.
Make sure to ground the appliance especially in the following places.
Damp place such as earth floor or wash place.
Humid place such as basement.
為 了防止觸電與雜音干擾，建議您實施接地作業。尤其是符合以下
情況時，請務必實施接地。
設置於土質地面或清洗場所等時。
設置於地下室等潮濕場所時。
When installing the refrigerator in a particularly
damp place
Screws
Earth terminal
R-S42YMJ (A4).indd 13R-S42YMJ (A4).indd 13 4/17/09 11:33:50 AM4/17/09 11:33:50 AM

14
操作面板
操作面板
各部分的名稱
各部分的名稱
儲存室
儲存室
操作面板 各部分的名稱 儲存室
操作面板 各部分的名稱 儲存室
CONTROL PANEL NAME OF EACH PART STORAGE COMPARTMENT
CONTROL PANEL NAME OF EACH PART STORAGE COMPARTMENT
CONTROL PANEL NAME OF EACH PART STORAGE COMPARTMENT
CONTROL PANEL NAME OF EACH PART STORAGE COMPARTMENT
• To preserve fresh taste of food in low temperature. ( Pg. 22 )
低溫保存食品的新鮮味道。( 22 頁)
Internal Control Panel 冰箱內操作面板
• Refrigerator compartment 冷藏室 ( Pg. 19/19 頁)
• Freezer compartment 冷凍室 ( Pg. 22/22 頁)
To set the temperature of refrigerator and freezer compartment
冷藏室和冷凍室溫度設定
• Select standard/large ice cube. ( Pg. 26
)
選擇通常∕大顆冰塊。( 26 頁)
• To stop automatic ice making function. ( Pg. 27 )
自動停止製冰功能。( 27 頁)
To select the Large ice cube making
製冰選擇設定
• Ｗhen cleaning the automatic ice maker. ( Pg. 33
)
清洗自動製冰器時 。( 33 頁)
Cleaning the ice maker
製冰機清潔
To switch the mode of refrigerator, freezer and ice compartment.
切換冷藏室，冷凍室和製冰室的模式。
• To cool the food and drinks quickly. ( Pg. 19
)
快速冷藏食品和飲品。( 19 頁)
Quick Cooling
快速冷藏
Low Temperature Freezer
低溫冷凍
• To freeze the food quickly. ( Pg. 21
)
超速冷凍食品 。( 21 頁)
Quick Freezing
超速冷凍
One Touch Panel 門上操作面板
R-S42YMJ (A4).indd 14R-S42YMJ (A4).indd 14 4/17/09 11:33:50 AM4/17/09 11:33:50 AM

15
操作面板 各部分的名稱 儲存室
CONTROL PANEL NAME OF EACH PART STORAGE COMPARTMENT
Control Panel Name of Each Part Storage Compartment
操作面板 各部分的名稱 儲存室
Before use
使 用 前
儲存冷凍食品，冰淇淋及乾量。
低溫可以更長久維持冷凍食品的新鮮
味道。
Store frozens foods, ice-cream
and dried foods.
冷藏食品
箱門置物架會自上表溫度而出現若干升高的情況。
Refrigerating foods
The temperature of door pocket is slightly high.
蔬菜，水果，飲料
Vegetable, fruits, drink
上層冷凍室
Upper freezer
下層冷凍室
Lower freezer
( Pg. 22/22 頁 )
( Pg. 20/20 頁 )
( Pg. 23/23 頁 )
Refrigerator compartment (About 2°C~6°C)
冷藏室 (約2°C~6°C)
( Pg. 16/16 頁 )
低溫冷凍
Low temperature freezer
(Below -20°C)
(-20°Cʔ)
Vegetable compartment (About 3°C~7°C)
蔬果保鮮室 (約3°C~7°C)
溫度顯示僅供參考，實際溫度可能會隨運轉環
境上下波動。
Chill room (About -1°C~3°C)
冰溫室 (約-1°C~3°C)
( Pg. 18/18 頁 )
將自動製冰機所製造的冰塊儲藏。
Store the ice cube made by auto ice
making function.
Ice compartment
(About -20°C~-18°C)
製冰室 (約-20°C~-18°C)
( Pg. 24/24 頁 )
Lower temperature of this compartment
keeps fresh taste of frozen food longer.
The temperature shown is an indication only.
It fluctuates depending on the operating conditions.
將肉類、魚、貝類等的生鮮食品在輕微凍結的
溫度下新鮮保存，以免破壞食品的口味。
To preserve freshness and taste of meats, fishes
and shellfishes. by keeping them in a slightly
frozen state.
R-S42YMJ (A4).indd 15R-S42YMJ (A4).indd 15 4/17/09 11:33:52 AM4/17/09 11:33:52 AM

用於快速冷卻食品時。
冷藏室
冷藏室
冷藏室
冷藏室
16
( Pg.19/19 頁)
置物架(上層)
可配合食品調整高度。
可調式層架
容器置物架
快速冷藏區
快速冷藏區
( Pg.19/19 頁)
固定層架
Height adjustable shelves
可調式置物架
Height adjustable pocket
When you want to cool the food quickly.
Door pocket (upper)
置物架(下層)
Door pocket (lower)
蛋架（十四個）
Egg stand (14 pcs)
Door basket
Fixed shelf
冰溫室
Chill room
ADJUSTABLE TEMPERATURE
( Pg.30/30 頁)
翻轉式層架
Reversible shelf
Internal Control Panel
冰箱內操作面板
可調式層架
用作一般層架
可配合食品高度或用法進行調整。
卸除方法
倒翻後安裝於最下層
倒翻
放入稍具高度的食品時 放入具相當高度的食品時
請不要翻轉固定層架，應直接使用。
在移動層架的高度時，請勿放置食物。
Quick cooling corner
Height Adjustable Shelves
Shelves can be adjusted according to the height
of food items and how foods are used.
稍微將層架底層抬高，往身拉出後就可取出。
按照各自高度的需要，將層架插入冰箱卡榫，要插牢。
As a normal shelf
When storing food items
that have some height
When storing food items
that are higher still
How to remove
Turn over Turn over and use the
bottom level
Reversible Shelf 翻轉式層架
Remove the food first when charging the shelves. Use the fixed shelf as it is.
Height can be adjusted
according to food size.
REFRIGERATOR COMPARTMENT
REFRIGERATOR COMPARTMENT
REFRIGERATOR COMPARTMENT
REFRIGERATOR COMPARTMENT
By lifting the back of the shelves and
pulling towards you can be taken out.
To insert the shelf, align it with the
desired position and push it in until it
makes contact with the back of the
compartment.
(About 2°C~6°C)
(About 2°C~6°C)
(About 2°C~6°C)
R-S42YMJ (A4).indd 16R-S42YMJ (A4).indd 16 4/17/09 11:33:53 AM4/17/09 11:33:53 AM

冷藏室
Refrigerator Compartment (Continue)
冷藏室
（繼續）
17
（繼續）
(Continue)
快速冷藏區
放入食物時，請勿讓食品用力碰觸燈罩或兩旁的側板，避免燈罩或側板破裂。
請勿將剛做好的火鍋．熱開水等熱騰騰的食品放入冷藏室內。（層架的耐熱溫度約50°C）
柑橘類的水果在切開剖皮後在放入冰箱保存時，請勿直接放置在層架上，因為柑橘類所產生的精油會使塑
膠聚合物變質。
如果將水分較多的食品放在冷風口前面，可能會結凍。特別需要注意的是，飲料瓶結凍後容易破裂，請勿
放在冷風口前面。
將食品間適當分開來保存。
Avoid bumping the lamp cover with any degree of force with food items as you put them in. This may break the lamp cover.
Do not put hot cooking utensils such as kettles or pots just after they have been used for cooking in the fresh food compartment.
(The shelves are heat resistant to 50°C).
Never place cut or peeled citrus fruits directly on the shelf. The volatile oil constiuents of the citrus fruits will alter the plastic.
Never place food containing juice, especially canned beverages, in front of the supply opening as they may breeze and blow up.
Place the foods with the adequate gap.
Caution
注意事項
REFRIGERATOR COMPARTMENT
(About 2°C~6°C)
可根據食品改變位置。
Height can be adjust depending on the food.
可調式置物架
Height Adjustable Pocket
500mL cans will fit into top level. 350mL cans will fit into top level.
上層可裝入500mL罐。 上層可裝入350mL罐。
安裝到下側 安裝到上側
Lower Setting Upper Setting
輕輕敲打左右底面，再抬高予以卸除。
Remove by lifting while lightly tapping
the bottom surface at both ends.
How To Use
用 法
R-S42YMJ (A4).indd 17R-S42YMJ (A4).indd 17 4/17/09 11:33:54 AM4/17/09 11:33:54 AM

18
冰溫室
Chill Room
將肉類、魚、貝類等的生鮮食品在輕微凍結的溫度下新鮮保存，以免破壞食品的口味。
To preserve freshness and taste of meats, fishes and shellfishes. by keeping them in a slightly
frozen state.
請務必在冰溫盒已被推入的狀態下關閉箱門 。若在 冰溫盒被 拉
出 的狀態下關閉箱門，會造成箱門及冰溫盒受損。
請勿將豆腐，優格等富含水份的食品放入冰溫盒內，以防食品
結凍 。
Make sure the chill room case is fully pushed in before closing the
refrigerator compartment door. Closing the refrigerator compartment door
when the chill room case is pulled out may damage the door and case.
Do not store foods that have a high water content such as tofu or yogurt in
the fresh room case. These kinds of food will be frozen.
冷藏室
冷藏室
冷藏室
冷藏室
REFRIGERATOR COMPARTMENT
REFRIGERATOR COMPARTMENT
REFRIGERATOR COMPARTMENT
REFRIGERATOR COMPARTMENT
冰溫盒
Chill room case
R-S42YMJ (A4).indd 18R-S42YMJ (A4).indd 18 4/17/09 11:33:55 AM4/17/09 11:33:55 AM

19
冰箱內操作面板
Internal Control Panel
用於快速冰鎮食品或飲料時。
按下「快速冷藏」
按鍵。 約45分鐘「快速冷
藏」運轉自動完成。
將食品放入快速冷藏
區內。
快速冷藏區位於冷藏室的最
上層。（ 16頁）
富含水份的食品與罐裝飲料結凍後容易產生破裂，請勿放在冷風口前面。
先推入真空室或小型食品收藏盒的滑動盒，然後再關閉冰箱箱門否則容易損傷箱門、滑動盒和∕或食品。
中途欲停止時，請再度按
下「快速冷藏」按鍵。
快速冷藏
當轉鈕被轉至“強”或“弱”，冰溫盒內的溫度將會隨之改變。
箱門置物架會自上表溫度而出現若干升高的情況。
通常使用溫度要在“中”的位置。溫度可隨使用條件的不同而變動。
上表表示的溫度是在常溫30度，冰箱內放入食品，冰箱門關閉的情況下設定的。
Press "Quick Cooling"
button.
"Quick cooling" will finish
automatically in
approximately 45 minutes.
To stop this function before
it is completed, press "Quick
Cooling" button again.
Never place any food contains a lot of water or beverage cans in front of the supply opening as they may freeze and subsequently
explode.
注意事項
Push in the slide case of the vacuum compartment or the small-item storage case before closing the refrigerator compartment door.
If the door is closed while the slide case is pulled out, the door, case and/or food may be damaged.
冷藏室旋鈕
比“中”約低 1∼3°C
約2∼6°C
比“中”約高 1∼3°C
Quick Cooling
When you want to refrigerate food or drinks fast.
Put the items in the quick
refrigerate corner.
The quick refrigerate corner is the
highest level shelf in the fresh food
compartment. ( Pg. 16)
棚（最上層）
食品放在圖中位置時，可更快速的冷卻食品。
Shelves (upper part)
Food can be cooled much faster by positioning it as shown in the diagram.
Caution
When the dial is set to “MAX” or “MIN”, the temperature of the fresh room case changes accordingly.
The temperature of the door pocket / basket will be slightly higher than the temperature shown above.
Usually set the dial to “MID”. The temperature may slightly vary depending on the operating conditions.
The temperature shown on the above table is the rough indication of the fresh food compartment temperature when ambient
temperature is 30ºC, there is no food in the compartment and the temperature became stable after the door is closed.
門上操作面板
One Touch Panel
（繼續）
(Continue)
MID
MAX
Approximately 1 ~ 3°C higher than
"MID"
Approximately 1 ~ 3°C lower than
"MID"
About 2 ~ 6°C
Refrigerator Compartment Dial
MIN
Refrigerator Compartment (Continue)
冷藏室
（繼續）
冷藏室
REFRIGERATOR COMPARTMENT
How To Use
用 法
顯示燈亮燈
Light ON
顯示燈熄燈
Light OFF
嗶
嗶嗶
R-S42YMJ (A4).indd 19R-S42YMJ (A4).indd 19 4/17/09 11:33:57 AM4/17/09 11:33:57 AM

20
冷凍室
冷凍室
冷凍室
冷凍室
冷凍室
( 22頁)( Pg. 22)
．
．
．
．
．
．
Use this compartment to preserve food freshness and store foods according to the sizes.
Adjustable temperature
要保持食品的新鮮度，將食品按大小分別收藏時使用的。
Upper Freezer
上層冷凍室
Lower Freezer
下層冷凍室
FREEZER COMPARTMENT
FREEZER COMPARTMENT
FREEZER COMPARTMENT
Slimline slide case
Lower freezer case
Slide case
滑動盒
下層冷凍盒
薄滑動盒
如冰淇淋等小型的食品等。
冷凍置物袋或密封容器等。
冷凍食品或土司麵包等。
Ice cream, small items, etc.
Frozen goods, airtight
container, etc.
Frozen goods, bread, etc.
上層冷凍盒
Upper freezer case
Can be used as a daily
storage space for small-size
frozen food such as freezing
pack and airtight container.
可以用作每日儲存空間，儲存
小型冷凍食品，如冷凍包裝、
密封容器。
鋁盤 （超速冷凍區）
Aluminium tray
(Quick Freezing corner)
(About- 20°C~-16°C)
(About -20°C~-18°C)
(About -20°C~-18°C)
R-S42YMJ (A4).indd 20R-S42YMJ (A4).indd 20 4/17/09 11:33:57 AM4/17/09 11:33:57 AM
