ELECTRIC TOOL PARTS LIST
ROTARY HAMMER 2010 • 01 • 27
Model DH 38YE2 (E1)

By Allen R. 2
PARTS DH38YE2
ITEM
NO. CODE NO. DESCRIPTION NO. USED REMARKS
1 943364 NEEDLE ROLLER D4X20 1
2 331868 FRONT COVER 1
3 981942 SEAL LOCK HEX. SOCKET HD. BOLT M6X25 4
4 985372 STOP LEVER (B) 1
5 331244 O-RING 1
6 981857 O-RING (C) 1
7 331872 STOP WASHER 1
8 331871 STOPPER SPRING 1
9 331870 KNOB 1
10 331863 SECOND HAMMER 1
11 331865 DAMPER WASHER 1
12 331864 DAMPER 1
13 331866 DAMPER HOLDER 1
14 331867 CYLINDER CASE 1
15 991712 HEX. SOCKET HD. BOLT (W/FLANGE) M6X25 4
16 956996 O-RING (1AS-60) 1
17 331862 CYLINDER 1
18 331874 STRIKER 1
19 986104 O-RING 2
20 331964 CLUTCH SPRING 1
21 331528 CLUTCH 1
22 331529 BEVEL GEAR 1
23 331234 THRUST WASHER 1
24 326369 PISTON 1
25 331221 PISTON PIN 1
26 321285 CONNECTING ROD 1
27 983162 SEAL LOCK HEX. SOCKET HD. BOLT M4X12 1
28 331545 CHANGE LEVER 1
29 331548 PIN D2X10 1
30 331873 LEVER HOLDER 1
31 311229 RETAINING RING FOR D20 HOLE 1
32 331543 LEVER SHAFT 1
33 873095 O-RING (P-16) 1
34 331546 LEVER SPRING 1
35 321311 PUSHING BUTTON 1
36 6201DD BALL BEARING 6201DDCMPS2L 1
37 325003 DUST WASHER (B) 1
38 360875U ARMATURE ASS'Y 120V 1 INCLUD.36.37.87.88
39 331252 FAN GUIDE 1
40 953174 HEX. HD. TAPPING SCREW D5X55 2
41 340753D STATOR ASS'Y 120V 1
42 930703 BRUSH TERMINAL 2
43 331251 HOUSING ASS'Y 1 INCLUD.83.84
44 331210 SLIP CLUTCH ASS'Y 1
45 331211 BEVEL PINION 1
46 944109 FEATHER KEY 3X3X8 2
47 331212 COLLAR 1
48 313050 OIL SEAL (A) 1
49 6002DD BALL BEARING 6002DDCMPS2L 1
50 331213 WASHER 1
51 331214 WASHER (A) 1
52 321281 GEAR HOLDER 1
53 331218 SPRING (C) 10
54 331217 NEEDLE 10
55 331215 SECOND GEAR 1
56 331219 SPACER 1
57 629VVM BALL BEARING 629VVC2PS2L 1
58 331220 BEARING WASHER (C) 1
59 992803 SEAL LOCK HEX. SOCKET HD. BOLT M6X20 2
60 986940 SEAL LOCK HEX. SOCKET HD. BOLT M6X45 4

By Allen R. 3
WWW.HITACHIPOWERTOOLS.COM for more Breakdowns
Parts DH38YE2
ITEM
NO. CODE NO. DESCRIPTION NO. USED REMARKS
61 331245 CRANK COVER 1
62 HITACHI LABEL 2
63 994192 HEX. SOCKET HD. BOLT (W/FLANGE) M5X16 6
64 878713 CYLINDER O-RING (B) 1
65 331523 CRANK CASE 1
66 331549 SEAL PACKING 1
67 939540 RETAINING RING FOR D10 SHAFT (10 PCS.) 1
68 331208 CRANK SHAFT 1
69 948391 RETAINING RING FOR D40 HOLE 1
70 6203DD BALL BEARING 6203DDCMPS2L 1
71 996363 O-RING (S-40) 1
72 321274 OIL SEAL (B) 1
73 331209 FIRST GEAR 1
74 939299 NEEDLE BEARING (M661) 1
75 331253 GEAR COVER 1
76 307947 WING BOLT M6X12 1
77 331248 MOUNT 1
78 949556 NUT M6 (10 PCS.) 1
79 330209 SIDE HANDLE 1
80 331247 HANDLE BOLT 1
81 331246 BAND 1
82 945161 BRUSH CAP 2
83 999043 CARBON BRUSH (1 PAIR) 2
84 958900 BRUSH HOLDER 2
85 938477 HEX. SOCKET SET SCREW M5X8 2
86 331547 DUST SEAL 1
87 331202 TAIL COVER 1
88 982631 WASHER (A) 1
89 608VVM BALL BEARING 608VVC2PS2L 1
90 331254 BEARING HOLDER 1
91 302089 TAPPING SCREW (W/FLANGE) D5X20 (BLACK) 4
92 NAME PLATE 1
93 331204 HANDLE 1
94 958049 CORD ARMOR D8.2 1
95 930804 TERMINAL M4.0 (10 PCS.) 1
96 313093 SWITCH (C) (2P SCREW TYPE W/O LOCK) 1
97 938307 PILLAR TERMINAL 1
98 307028 TAPPING SCREW (W/FLANGE) D4X25 (BLACK) 2
99 331205 HANDLE COVER 1
100 960266 CORD CLIP 1
101 984750 TAPPING SCREW (W/FLANGE) D4X16 2
102 500434Z CORD 1

By Allen R. 4
WWW.HITACHIPOWERTOOLS.COM for more Breakdowns and Information
STANDARD ACCESSORIES DH38YE2
ITEM
NO. CODE NO. DESCRIPTION NO. USED REMARKS
501 993245 DUST COVER 1
502 331965 CASE 1
503 971786 STOPPER ROD 1
OPTIONAL ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION NO. USED REMARKS
601 981840 GREASE (A) FOR HAMMER.HAMMER DRILL (30G) 1
602 308471 GREASE FOR HAMMER.HAMMER DRILL (70G) 1
603 980927 GREASE FOR HAMMER.HAMMER DRILL (500G) 1
604 320859 SYRINGE (BLOW-OUT BULB TYPE) 1
605 318085 SYRINGE (BELLOWS TYPE) 1
606 985376 DRILL BIT 2 CUTTER (1-1/2"X16") 1
607 725062 DRILL BIT 2 CUTTER (1/2"X16") 1
608 725074 DRILL BIT 2 CUTTER (1"X16") 1
609 985377 A-TAPER SHANK ADAPTER 1
610 985378 B-TAPER SHANK ADAPTER 1
611 944477 COTTER 1
612 725105 DRILL BIT 4 CUTTER (1-1/2"X22") 1
613 725090 DRILL BIT 4 CUTTER (3/4"X16") 1
614 725095 DRILL BIT 4 CUTTER (1"X16") 1
615 725103 DRILL BIT 4 CUTTER (1 3/8"X16") 1
616 725087 DRILL BIT 4 CUTTER (5/8"X16") 1
617 985383 BULL POINT 300MM (12") 1
618 985381 COLD CHISEL W25X300L (1"X12") 1
619 985382 COLD CHISEL W25X460L (1"X18") 1
620 724891 GROUND ROD DRIVER 1
621 985386 ROUND CLAY SPADE 5”X7”X16” 1
622 728805 ROUND ASPHALT CUTTER 4 ½” X15” 1
623 725791 SPLINE SHANK TO SDS+ ADAPTER 1
624 725793 SPLINE SHANK TO SDS MAX ADAPTER 1
625 725797 SPLINE SHANK TO 3-JAW ½” THREAD ADAPTER 1
