Hitachi CR 13VC Manual

POWER TOOLS
TECHNICAL DATA
AND
SERVICE MANUAL
RECIPROCATING SAW
CR 13VC
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
LIST No. 0792 Aug. 2002
C
MODEL
CR 13VC

ELECTRIC TOOL PARTS LIST
LIST NO.
RECIPROCATING SAW
Model CR 13VC
2002
•
8
•
30
(E1)
0792
501
502
503
1
2
3
4
5678910 11 12 11
13
14 15
16 17 18 19
20 21 22
23 24 25 26 27 28 28 29 30
31 32
33
34 24
35
36 37
38
39 40
41
42
43
44 45
46
47
48
49 50 51 52
53
54 55 56 57
58 59

*ALTERNATIVE PARTS
--- 2 ---
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
PARTS
8 -- 02
CR 13VC
1 321-116 BASE (B) 1
2 321-125 FRONT COVER (C) 1
3 321-132 BLADE HOLDER (A) 1
4 321-120 PLUNGER (B) 1
5 321-123 GEAR COVER (B) 1
6 318-458 FELT WASHER 1
7 321-117 WASHER (H) 1
8 318-459 V-RING 1
9 321-118 O-RING 1
10 321-214 METAL (B) 1
11 321-136 SWING ROLLER 2
12 318-491 PIN D6 1
13 321-126 COVER CLIP 1
14 321-133 SPECIAL BOLT M4 1
15 321-130 CAP 1
16 321-131 LEVER (A) 1
17 321-135 SPRING (D) 1
18 321-134 HOLDER PIN (B) 1
19 318-483 SPRING (B) 1
20 318-451 NYLOCK BOLT (W/FLANGE) M6X35 1
21 318-452 WASHER (G) 1
22 996-399 HEX. SOCKET HD. BOLT (W/FLANGE) M5X12 1
23 600-2DD BALL BEARING 6002DDCMPS2L 1
24 314-430 SLOTTED HD. SCREW (SEAL LOCK) M4X10 5
25 321-129 SUB SHAFT (B) 1
26 967-261 RETAINING RING FOR D17 SHAFT 1
27 321-121 RECIPRO PLATE 1
28 600-3VV BALL BEARING 6003VVCMPS2L 2
29 939-556
RETAINING RING FOR D35 HOLE (10 PCS.) 1
30 321-128 SECOND SHAFT (B) 1
31 321-127 GEAR (B) 1
32 608-VVM BALL BEARING 608VVC2PS2L 1
33 321-124 INNER COVER (B) 1
34 600-1VV BALL BEARING 6001VVCMPS2L 1
* 35 360-581C ARMATURE 110V 1
* 35 360-581U ARMATURE ASS’Y 120V 1 INCLUD.34,39
* 35 360-581E ARMATURE 220V-230V 1
* 35 360-581F ARMATURE 240V 1
36 321-122 FAN GUIDE 1
37 961-501 HEX. HD. TAPPING SCREW D5X60 2
* 38 340-479H STATOR ASS’Y 110V-115V 1 INCLUD.37
* 38 340-479G STATOR ASS’Y 120V-127V 1 INCLUD.37
* 38 340-479E STATOR ASS’Y 220V-230V 1 INCLUD.37
* 38 340-479K STATOR ASS’Y 240V 1 INCLUD.37
* 38 340-479J STATOR ASS’Y 220V-230V 1
INCLUD.37 FOR NZL,FIJ,GBR,EUROPE,NOR,SWE,
DEN,FIN
39 608-VVM BALL BEARING 608VVC2PS2L 1
40 318-506 HOUSING (GREEN) 1
41 945-161 BRUSH CAP 2
42 999-043 CARBON BRUSH (1 PAIR) 2
43 958-900 BRUSH HOLDER 2

*ALTERNATIVE PARTS --- 3 ---
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
PARTS
8 -- 02
CR 13VC
44 NAME PLATE 1
45 307-224
MACHINE SCREW (W/WASHERS) M5X60 (BLACK) 4
46 HITACHI LABEL 1
47 307-028 TAPPING SCREW (W/FLANGE) D4X25 (BLACK) 5
* 48 321-140 HANDLE (B) 1
* 48 321-141 HANDLE (B) 1 FOR NZL,FIJ,AUS
* 49 981-373 TUBE (D) 2 EXCEPT FOR USA,CAN
50 318-499 SWITCH TRIGGER 1
* 51 318-505 SWITCH 1
* 51 318-817 SWITCH 1 FOR TPE,GBR (110V)
* 51 318-504 SWITCH 1 FOR USA,CAN
* 51 320-142 SWITCH (1P SCREW TYPE) W/SAFETY LOCK 1 FOR NZL,FIJ,AUS
52 981-373 TUBE (D) 2
53 321-139 HANDLE (A) 1
* 54 938-108 TERMINAL 1 FOR NOISE SUPPRESSOR
* 55 994-273 NOISE SUPPRESSOR 1 FOR NZL,FIJ,AUS,GBR,EUROPE,NOR,SWE,DEN,
FIN
56 984-750 TAPPING SCREW (W/FLANGE) D4X16 2
57 937-631 CORD CLIP 1
* 58 953-327 CORD ARMOR D8.8 1
* 58 938-051 CORD ARMOR D10.1 1
* 59 500-245Z CORD 1 (CORD ARMOR D8.8)
* 59 500-201Z CORD 1
(CORD ARMOR D10.1) FOR TPE,THA,PHI,PER,
BRN,BAN,BOL,TUN,MOZ
* 59 500-234Z CORD 1 (CORD ARMOR D8.8) FOR EUROPE,INA,EGY,
TUR, NGR,SAU,MAR,VIE
* 59 500-247Z CORD 1 (CORD ARMOR D8.8) FOR NOR,SWE,DEN,FIN
* 59 500-439Z CORD 1 (CORD ARMOR D8.8) FOR NZL,FIJ,AUS
* 59 500-423Z CORD 1 (CORD ARMOR D8.8) FOR SIN,MAL,SRI
* 59 500-434Z CORD 1 (CORD ARMOR D8.8) FOR USA,CAN
* 59 500-435Z CORD 1 (CORD ARMOR D8.8) FOR GBR (230V)
* 59 500-237Z CORD 1 (CORD ARMOR D8.8) FOR GBR (110V)

*ALTERNATIVE PARTS --- 4 ---8 -- 02
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
CR 13VC
OPTIONAL ACCESSORIES
STANDARD ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
Printed in Japan
(020830N)
501 944-458 HEX. BAR WRENCH 4MM 1
* 502 318-613
SABER SAW BLADES NO.103 150L P.14 (5 PCS.) 1
* 502 318-621
SABER SAW BLADES NO.132 203L (5 PCS.) 1 FOR USA,CAN
503 321-142 CASE 1
601 959-610 SABER SAW BLADES NO.1 (5 PCS.) 1
602 958-182 SABER SAW BLADES NO.2 (5 PCS.) 1
603 958-183 SABER SAW BLADES NO.3 (5 PCS.) 1
604 959-611 SABER SAW BLADES NO.4 (5 PCS.) 1
605 958-185 SABER SAW BLADES NO.5 (5 PCS.) 1
606 958-188 SABER SAW BLADES NO.8 (5 PCS.) 1
607 318-611
SABER SAW BLADES NO.101 150L P.10 (5 PCS.) 1
608 318-612
SABER SAW BLADES NO.102 228L P.10 (5 PCS.) 1
609 318-614
SABER SAW BLADES NO.104 228L P.14 (5 PCS.) 1
610 318-615
SABER SAW BLADES NO.105 150L P.18 (5 PCS.) 1
611 318-616
SABER SAW BLADES NO.106 228L P.18 (5 PCS.) 1
612 318-617
SABER SAW BLADES NO.107 150L P.24 (5 PCS.) 1
613 318-618
SABER SAW BLADES NO.108 228L P.24 (5 PCS.) 1
614 318-619
SABER SAW BLADES NO.121 305L P.6 (5 PCS.) 1
615 318-620
SABER SAW BLADES NO.131 305L P.10/14 (5PC.) 1
616 318-621 SABER SAW BLADES NO.132 203L (5 PCS.) 1
