Hitecsa EKWXBA HE 38.2 Instruction manual

INSTALLATION, OPERATION & MAINTENANCE MANUAL
EKWXBA HE
Heat Pump
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
SOLO FRIO
Models: 38.2│44.2 │47.2 │55.2 │59.2 │67.2 │75.2 │95.2 │109.2 │121.4 │132.4 │171.4│193.4 │207.4
Cooling capacities: from 37.9 kW to 206.5 kW
Heat capacities: from 42.3 kW to 246.8 kW
WATER CHILLERS –AXIAL FANS

Thank you for trusting the Hitecsa Products. Our company has been offering the market an extended range of specialized units for
air conditioning and cooling installations for over 35 years. Our approach is based on efficiency, adaptability, usability and practical
solutions. This has been the hallmark of our product catalogue.
The versatility of our factory allows us to contribute solutions, almost tailored to each project’s specifications, in search of a solution
to every problem that arises in design and implementation of air conditioning installations.
From all of us at Hiplus Aire Acondicionado, once again, thank you very much.

3
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
EKWXBA HE / KRONO2HE
INDEX
INTRODUCTION.................................................................................................................... 5
REGULATIONS AND CERTIFICATIONS ............................................................................. 8
RULES AND REGULATIONS:.................................................................................... 8
SAFETY PRECAUTIONS...................................................................................................... 9
TECHNICAL SPECIFICATIONS ......................................................................................... 11
TRANSPORT & RECEPTION ............................................................................................. 17
INSPECTION AT RECEPTION ...................................................................................... 17
RIGGING........................................................................................................................ 17
STORAGE...................................................................................................................... 17
INSTALLATION................................................................................................................... 18
DIMENSIONS................................................................................................................. 18
Models 38.2 - 67.2.................................................................................................... 18
Model 75.2................................................................................................................ 19
Models 95.2 –109.2................................................................................................. 20
Models 121.4 –132.4............................................................................................... 21
Models 171.4............................................................................................................ 22
Models 193.4 –207.4............................................................................................... 23
INSTALLATION SITE..................................................................................................... 24
SERVICE AREA (MM) ..................................................................................................... 24
UNITSETTLEMENT....................................................................................................... 27
Weight distribution.................................................................................................... 27
INSTALLATION OFWATER PIPES............................................................................... 29
Security devices........................................................................................................ 29
Risk of frost............................................................................................................... 29
Glycol additions...................................................................................................... 29
REFRIGERATION DIAGRAM ........................................................................................ 30
EKWXBA HE 38.2 to 67.2....................................................................................... 30
EKWXBA HE - 75.2 to 109.2 ................................................................................... 30
EKWXBA HE - 121.4 to 132.4 .................................................................................. 31
EKWXBA HE - 171.4 to 207.4 .................................................................................. 32
ELECTRICAL DATA....................................................................................................... 33
Installation limits ....................................................................................................... 34
OPERATION LIMITS........................................................................................................... 35
COOLING MODE ........................................................................................................... 35
HEATING MODE............................................................................................................ 35
OPERATION........................................................................................................................ 36
BEFORESTART-UP...................................................................................................... 36
START-UP ..................................................................................................................... 36
THERMOSTATAND CONTROL.................................................................................... 37
MODELS 38.2 - 109.2: CONTROL MCX08............................................................... 37
MODELS 121.4 –207.4: MCX15 CONTROL ........................................................... 38
MCX controller operation.......................................................................................... 39
Commissioning of the unit......................................................................................... 43
Setpoint Temperature Change.................................................................................. 43
OPERATION MODE SELECTION............................................................................ 43
Temperature Regulation Mode Configuration........................................................... 43
Disabling one compressor ........................................................................................ 43

4
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
ALARMS. Display and reset ..................................................................................... 44
Time Programming................................................................................................... 44
Input and output........................................................................................................ 45
MAINTENANCE................................................................................................................... 48
MAINTENANCE AND CLEANING.................................................................................. 48
REPAIRINGOPERATIONS ........................................................................................... 49
LUBRICANT................................................................................................................... 49
REFRIGERANTCHARGE.............................................................................................. 50
OPTIONS / ACCESSORIES................................................................................................ 51
Technical specifications of equipments with options................................................. 53
REFRIGERATION DIAGRAM................................................................................... 55
EKWXBA HE - from 38.2 to 67.2 cooling only ......................................................... 55
EKWXBA HE - 75.2 to 109.2 cooling only................................................................ 55
EKWXBA HE - from 121.4 to 132.4 cooling only ..................................................... 56
EKWXBA HE - from 171.4 to 207.4 cooling only ..................................................... 56
Hydraulic diagram with buffer tank............................................................................ 57
Weight distribution.................................................................................................... 58
Configuration of Input and Output with buffer tank and reserve pump...................... 60
APPENDIX: SAFETY DATA R410A ................................................................................... 61

5
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
INTRODUCTION
Purpose of this Manual
This manual and any other instructive document attached as refrigeration lines design, electrical
diagrams, etc. have been written to allow a correct installation, commissioning and maintenance of
the unit. Therefore it is essential to read the instructions with due attention.
Verify that all the necessary information for the correct installation of the system is included in the
manuals supplied with this unit and/or the rest of the indoor units, accessories, etc. Otherwise, the
manufacturer declines any responsibility for any damage to persons, animals or things, as a result of
improper use of the unit and/or failure to observe these instructions.
In case of different interpretations and/or errors the documentary priority will be: 1. Characteristics
plate of the unit, 2. IOM (this document), 3. EDM, technical catalogue, 4. UM user manuals.
Conservation of the Manual
This manual and the electric diagram of the unit must be retained and remain available to the operator for any further
consultation.
Updating the Data
The continuous improvement in design and performance to which we are committed gives us the right to modify the
specifications of our products without prior notice.
Electrical Supply
Check that the electrical network features are in accordance to data shown in the data nameplate of
the unit.
Local Safety Regulations
Observe and analyse all possible causes of accidents that may arise in the place or places of installation of the units,
check means and tools to use, etc. It is not possible to anticipate each and every one of the potential circumstances of
danger in this manual. Respect the valid local security standards during installation.
Principles of Security on Installation
The unit is designed and built in a way that does not pose a risk to the health and safety of people. Appropriate solutions
for the project have been adopted to eliminate the possible causes of risk in the installation.
Packaging and Replacement of Equipment
The material of the package (plastic bags, insulating materials, nails, etc.) is a potential source of
danger. Consequently, it should be kept out of the reach of children and properly recycled according to
the valid local safety regulations.
This product should not be mixed with household waste at the end of its life. Due to the refrigerant, oil
and other components contained in this product, it must be dismantled by professional installers, all
waste should be sent, according to its nature to recycling, composting or treatment plants, or an
authorized management agency in accordance with current local legislations.
Utilization
The unit will be used only for the reason it has been conceived. Any other use does not imply any kind of compromise
or link for the manufacturer.
Incorrect Operation
In case of breakdowns or operation faults, turn off unit.

6
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
INTRODUCTION
Periodic Inspections and Maintenance
Carry out periodic inspections to detect possible damaged or broken pieces. If they are not repaired it
could cause damage to people or stuff. Before executing any maintenance operation, cut off the unit
power supply.
Make sure to leave the maintenance areas open. If these areas have to be necessarily invaded by the
construction of air supply and/or lateral return ducts. Verify that the design of the ducts allow the access
to the fans and the change of the filters or that these are accessible from the other lateral.
All operations should be carried out in accordance with local safety regulations.
Repairing Operations
The reparations should be always and exclusively made by trained personal authorized by the
manufacturer using originalspares. The safeties of theunit could be affected due to the failure to comply
with these warnings.
Modifications
The manufacturer will not respond to the warranty and to the possible damages of the unit in case of electrical and/or
mechanical modifications. The unauthorized manipulation, reparation or modification of the unit will automatically
invalidate the warranty.
Refrigerant
This product is hermetically sealed and contains R-410A which is a HFC fluorinated greenhouse gas.

7
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
INTRODUCTION
Name Plate
Description of the name plate attached to the unit.
1. Name of the Unit.
2. Year of manufacture.
3. Unit code.
4. Serial Number.
5. Test Pressure, Refrigerant Side.
6. Cooling Capacity in Rated Conditions (EN-14511)
7. Heating Capacity in Rated Conditions (EN-14511)
8. Water Flowin the Indoor Heat Exchanger.
9. Air Flow in the Outdoor Heat Exchanger (“X” If not
applicable).
10. Water Flow in the Outdoor Heat Exchanger (“X” If
not applicable).
11. Maximum Operating Pressure on the Refrigerant
Side of the Outdoor Heat Exchanger
12. Total Number of Compressors.
13. Protection Code IP (Dust or water tightness).
14. Type of refrigerant needed for unit operation.
15. Refrigerant charge needed for optimum operation
of the unit. In case of difference with the catalogue
value, the value indicated on the name plate is the
most suitable for the particular unit.
16. Total weight of the unit + Option and accessories
in operating conditions.
17. Number of phases (three-phase ± N, single phase,
etc.) and voltage at which this unit must be
supplied.
18. Frequency of the electrical network to which the
machine must be connected.
19. Maximum starting current (all electrical
components running at maximum current and
commissioning of the last stage of compressors)
20. Gross performance of the equipment +
accessories in cooling mode.
21. Maximum current operating in cooling mode.
22. Absorbed power by the unit (standard unit
operating under rated cold conditions ± optional,
etc.)
23. Gross performance of the equipment +
accessories in heating mode.
24. Maximum current operating in heating mode.
25. Unit power input (standard unit operating under
rated heat conditions ± optional, etc.)
26. Lower / higher design temperature according to
pressure equipment directive 97/23/CE (PED).
27. Design pressure (PED).
28. Unit Category (PED) and fluid group (refrigerant)
29. Global warming potential of refrigerant relative to
CO2.
30.CE label and number of the certifying entity (only
category II).

8
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
REGULATIONS AND CERTIFICATIONS
ISO 9001 CERTIFICATION: HIPLUS AIRE ACONDICIONADO S.L., trying always to find the maximum satisfaction of
costumers, has obtained the ISO 9001:2015 Quality System referred to its production activity. This will result in a
continuous determination to improve quality and reliability of all our products; commercial activities, design, raw
materials, production and after-sales service, are the means to reach our goal.
CE MARKING: Our machines have got the CE mark, in conformity with the essential requirements of the applicable
EC directives and their last modifications as well as with the national legislation of each country.
EUROVENT CERTIFICATION: HITECSA participates in the EUROVENT Certification program. Check certified
products on the web.
RULES AND REGULATIONS:
Commission Regulation (EU) 2016/2281 Ecodesign requirements for energy-related products, with regard to
ecodesign requirements for air heating products, cooling products, high temperature process chillers and fan coil units
Text with EEA (European Economic Area) relevance.
Commission Regulation (EU) No 813/2013 Ecodesign requirements for space heaters and combination heaters (Text
with EEA relevance).
Regulation UNE-EN 14511:2014 Air conditioners, Water Chillers and Heat Pumps equipped with an electrical powered
compressor meant for heating or cooling of premises.
Regulation UNE-EN 14825:2016 Air conditioners, Water Chillers and Heat Pumps equipped with an electrical powered
compressor meant for heating or cooling of premises. Tests and classification completed in partial load conditions and
calculation of the seasonal performance.
Regulation UNE-EN 60204 :2007 Machine safety. Electrical part of the machines.
Directive 2014/68/UE of the European Parliament and of the Council of 15 May 2014 on the harmonisation of the laws
of the Member States relating to the making available on the market of pressure equipment (Text with EEA relevance).

9
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
SAFETY PRECAUTIONS
Before starting any installation, service or maintenance operation, turn off the main power switch in
order to avoid electrical shock that may cause personal damages.
In case of folding electrical panels, before folding them up in order to access to the interior of the machine, it is
MANDATORY to disconnect the power supply hose from the electrical voltage, THE LINE MUST ALWAYS BE
FREE OF VOLTAGE for this operation.
It is absolutely prohibited to realize any operation on parts that are electrically powered on. The protection
class of the opened equipment is IP00!
The absence of voltaje must be confirmed by a minimum two poles voltaje tester.
DANGER
Do not touch or adjust the safety devices inside any unit of the system. For repairs use only original spare
parts and mount them properly in the same position where old parts were placed.
The installation and maintenance of air conditioning equipment may be dangerous because the system is
under pressure, some of its elements have high temperatures and include electrical components.
Do not install the unit in an explosive atmosphere.
The units equipped with water-air, water-water, or refrigerant-water heat exchangers shall be
protected properly against damage caused by frost. A proper protection is obtained by adding the
necessary anti-frost liquid so that the freezing temperature becomes minimum -2°C (6% when using
Ethylene Glycol).
Moreover when the ambient temperature in any part of the installation may reach values lower than
5°C it is COMPULSORY to protect the unit and the whole installation with additional measures such
as heating tubes, draining the unit and the whole installation for water (when the unit is not under
operation) or adding more anti-frost liquid so that the freezing point always will be lower than the
minimum temperature that the ambient air may reach.
Even after disconnecting themain voltage, life-threatening charges may appear between theprotective ground
“PE” and the main connection.
When the motor runs independently due to air flowing through or if it continues to run down after being turned
off, dangerous voltages of over 50 V can arise on the internal connections of the motor through operation of
the generator.
When there are EC motors or motors with variable speed control, the protective earth is conducting high
discharge currents (depending on the switching frequency, current source voltage and motor capacity).
Earthing in compliance with EN specifications shall therefore be observe even for testing and trial conditions
(EN 50 178, Art. 5.2.11). Without earthing, dangerous voltages can be present on the motor housing.
Because of the use of capacitors, danger of death exists even after switching off the device in case of direct
contact with conductive parts or with parts that carry voltage due to fault condition. It is only allowed remove
or open the housing of the controller when the power supply cable is disconnected and after a waiting time of
3 minutes.
The warranty of the unit will not respond to the damages caused by frozen water.
WARNING!

10
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
SAFETY PRECAUTIONS
Only qualified and trained service staff (technical service) must make the installation, commissioning and carry
out maintenance works. Unqualified personnel can only make basic tasks such as cleaning and replacement
of filters, etc.
Prevent access to children so they cannot play with the appliances.
In every visit, all precautions must be taken into account: those recommended in the installation, operation
and maintenance instructions, as well as the ones indicated in labels of the unit. Do not forget to strictly follow
any other safety precautions.
DO NOT introduce objects into the air inlets or outlets that can be drawn into the fan, people, etc.
Use safety glasses, work gloves and any other safety accessory necessary.
The fan / motor may switch on and off automatically for functional reasons.
After power failure or main disconnection automatic restart of the fan may occur when power supply is
back!
Wait for the fan to come to a complete standstill before approaching it!
In the AC external rotor motor the external rotor turns during operation!
For brazing operations use a quenching cloth and take precautions to have at close distance a fire
extinguisher.
This product contains fluorinated greenhouse gases, its leakage can cause displacement of air and cause
insufficient oxygen to breath.
The decomposition of fluorinated gases when being burned due to e.g. brazing operations, may cause the
existence of highly toxic and corrosive gases.
Must follow all safety recommendations.
ATTENTION!
The responsibility of all personal and material damages caused by an unplanned or inappropriate use
will be given to the person or operating company of the unit, and not to the manufacturer.
WARNING!

11
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
TECHNICAL SPECIFICATIONS
EKWXBA HE
38.2
44.2
47.2
55.2
59.2
67.2
CAPACITIES
COOLING CAPACITY (1 )
Cooling capacity
kW
37.9
44.1
47.3
55.4
59.3
66.6
Total power input
kW
14.5
16.9
19.2
21.3
24.1
28.0
Water flow
m3/h
6.2
7.1
8.0
9.3
10.3
11.3
Available static pressure
KPa
165
162
160
156
154
149
EER
-
2.62
2.61
2.47
2.60
2.47
2.37
SEER
-
4.09
3.94
3.83
4.06
3.95
3.80
ηs cooling
%
160.6
154.7
150.3
159.5
155.2
149.2
HEAT CAPACITY (2)
Heating capacity
kW
42.3
48.9
55.2
63.5
71.7
79.6
Total power input
kW
15.3
17.8
20.8
22.6
26.2
29.3
COP
-
2.76
2.74
2.66
2.81
2.73
2.72
Water flow
m3/h
7.4
8.5
9.6
11.1
12.5
13.8
Available static pressure
KPa
153
150
147
142
137
131
HEAT CAPACITY (3)
Heating capacity
kW
43.65
49.71
56.0
65.5
72.9
82.36
Total power input
kW
11.93
14.49
17.1
19.0
21.7
24.64
COP
-
3.66
3.43
3.26
3.45
3.36
3.34
Water flow
m3/h
7.6
8.7
9.8
11.4
12.7
14.3
Available static pressure
KPa
149
146
143
137
132
128
SCOP
-
3.21
3.20
3.20
3.21
3.20
3.20
ηs heating
%
125.4
125.0
125.0
125.4
125.0
125.0
Note:
(1) AC application. COOLING MODE: Outdoor temperature 35ºC, inlet water temperature 12ºC, outlet
water temperature 7ºC.
(2) IT application. HEATING MODE: Outdoor temperature 7ºC B.S. / 6ºC B.H., inlet water temperature
40ºC, outlet water temperature 45ºC.
(3) LT application.HEATING MODE: Outdoor temperature 7ºC B.S. / 6ºC B.H., inlet water temperature
30ºC, outlet water temperature 35ºC.

12
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
TECHNICAL SPECIFICATIONS
EKWXBA HE
38.2
44.2
47.2
55.2
59.2
67.2
ELECTRICAL DATA
Power supply
V / ~/Hz
400/3+N/50
Max. current
A
47
53
57
65
71
81
Start-up current
A
120
168
169
177
189
232
REFRIGERANT
Number of circuits
-
1
Gas type
-
R-410A
Global Warming Potential (GWP) (4)
-
2088
Total refrigerant charge (EKWXB without options)
kg
11.1
11.2
11.3
12.8
13.6
14.5
COMPRESSORS
Type
-
Scroll
Total number of compressors
Units
2
Number of stages Power
-
2
Oil type
-
POE
Oil volume
L
2x3
2x3.6
Crankcase resistance
W
2x48
0
OUTDOOR FAN
Type
-
Axial EC
Total number
-
2
Max. air flow
m3/h
34468
34384
34329
38059
37990
37885
Available static pressure
Pa
0
Nominal power
kW
2 x 1.95
Max. current
A
2 x 3.2
2 x 3.3
OUTDOOR HEAT EXCHANGER
Type
-
Coil of finned copper tubes
Number
-
2
Coil area (total)
m²
1.5+1.5
WATER CIRCUIT
Connection type
-
GROOVED –VICTAULIC TYPE
Connection outer diameter
"
2"
WATER PUMP
Model
-
CEA 210/3
Number
-
1
Max. operating current one pump
A
2.5
INDOOR HEAT EXCHANGER
Type
-
PLATES (Water/Refrigerant)
Quantity
-
1
Water volume
L
6
7
Antifrost resistance
W
100
0
SOUND LEVEL
Sound power (Lw)
dB(A)
86
87
88
Sound pressure (Lp 5m) (5)
dB(A)
65
66
67
0
DIMENSIONS and WEIGHT
Length
mm
2215
Width
mm
1350
Height
mm
1520
WEIGHT (without options nor charge) - EKWXBA
kg
634
657
660
690
690
698
WEIGHT –COOLING ONLY
kg
628
650
653
683
683
691
Note:
(4) GWP: Global Warming Potential (climatic) of 1 kg of greenhouse gas relative to 1 kg of CO2, calculated in terms of 100-year
warming potential.
(5) Conditions measured in open field, directivity 2 and at 1.5 m from the ground.

13
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
TECHNICAL SPECIFICATIONS
EKWXBA HE
75.2
95.2
109.2
CAPACITIES
COOLING CAPACITY (1 )
Cooling capacity
kW
75.3
96.6
115.5
Total power input
kW
26.2
35.6
45.0
Water flow
m3/h
13.0
17.0
19.4
Available static pressure
KPa
164
143
134
EER
-
2.87
2.71
2.57
SEER
-
4.10
3.85
3.81
ηs cooling
%
161.1
150.8
149.4
HEATING CAPACITY (2)
Heating capacity
kW
84.8
109.8
131.2
Total power input
kW
27.5
41.9
48.2
COP
-
3.08
2.62
2.72
Water flow
m3/h
14.4
19.1
22.3
Available static pressure
KPa
136
122
110
HEATING CAPACITY (3)
Heating capacity
kW
87.47
111.2
133.5
Total power input
kW
23.55
33.8
41.0
COP
-
3.71
3.29
3.25
Water flow
m3/h
14.9
19.3
23.4
Available static pressure
KPa
127
114
101
SCOP
-
3.27
3.20
3.20
ηs heating
%
128.0
125.1
125.0
Note:
(1) AC application. COOLING MODE: Outdoor temperature 35ºC, inlet water
temperature 12ºC. Water outlet temperature 7ºC.
(2) IT application. HEATING MODE: Outdoor temperature 7ºC B.S. / 6ºC B.H., inlet
water temperature 40ºC, outlet water temperature 45ºC.
(3) LT application.HEATING MODE: Outdoor temperature 7ºC B.S. / 6ºC B.H., inlet
water temperature 30ºC, outlet water temperature 35ºC.

14
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
TECHNICAL SPECIFICATIONS
EKWXBA HE
75.2
95.2
109.2
ELECTRICAL DATA
Power supply
V / ~/Hz
400/3+N/50
Max current
A
81
111
125
Start-up current
A
233
259
287
0
REFRIGERANT
Number of circuits
-
2
Gas type
-
R-410A
Global Warming Potential (GWP) (4)
-
2088
Total refrigerant charge
kg
18.0
22.5
23.0
0
COMPRESSORS
Type
-
Scroll
Total number of compressors
2
Number of stages Power
-
2
Oil type
POE
Oil volume
L
2x3.6
2x6.7
Crankcase resistance
W
2x48
2x56
0
OUTDOOR FAN
Type
-
Axial EC
Total number
-
2
3
Max. air flow
m3/h
44000
50100
54000
Available static pressure
Pa
0
Nominal power
kW
2 x 1.95
3 x 1.95
Max. current
A
2 x 3.3
3 x 3.2
0
OUTDOOR HEAT EXCHANGER
Type
Aluminium fin coil and copper tubing
Number
1
Coil area (total)
m²
1 x 6.7
0
WATER CIRCUIT
Connection type
GROOVED –VICTAULIC TYPE
Connection outer diameter
"
2"
WATER PUMP
Model
CEA 370/2
Number
1
Max. operating current one pump
A
3.4
INDOOR HEAT EXCHANGER
Type
Plates (Water/refrigerant)
Quantity
-
1
Water volume
L
10
Antifrost resistance
W
100
0
SOUND LEVEL
Sound power (Lw)
dB(A)
90
92
Sound pressure (Lp 5 m) (5)
dB(A)
69
71
0
DIMENSIONS and WEIGHT
Length
mm
3200
Width
mm
1350
Height
mm
2150
WEIGHT (without options nor charge) - EKWXBA
kg
855
970
WEIGHT –COOLING ONLY
kg
835
945
Note:
(1) GWP: Global Warming Potential (climatic) of 1 kg of greenhouse gas relative to 1 kg of CO2,
calculated in terms of 100-year warming potential.
(2) Conditions measured in open field, directivity 2 and at 1.5 m from the ground.

15
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
TECHNICAL SPECIFICATIONS
EKWXBA HE
121.4
132.4
171.4
193.4
207.4
CAPACITIES
COOLING CAPACITY (1 )
Cooling capacity
kW
120.6
131.5
171.3
193.3
206.5
Total power input
kW
45.4
50.6
62.4
71.7
79.9
Water flow
m3/h
20.4
22.3
29.1
32.8
35.1
Available static pressure
KPa
153
149
150
144
140
EER
-
2.65
2.60
2.75
2.70
2.58
SEER
-
3.94
3.85
3.91
3.84
3.80
ηs cooling
%
154.4
151.1
153.3
150.5
149.0
HEATING CAPACITY (2)
Heating capacity
kW
133.7
141.2
196.5
221.5
242.3
Total power input
kW
49.5
53.1
69.1
75.4
88.5
COP
-
2.70
2.66
2.85
2.94
2.74
Water flow
m3/h
23.2
24.6
34.1
38.5
42.0
Available static pressure
KPa
140
138
135
127
120
HEATING CAPACITY (3)
Heating capacity
kW
137.66
144.96
200.2
227.7
246.8
Total power input
kW
40.79
43.36
55.8
61.7
73.3
COP
-
3.37
3.34
3.59
3.66
3.37
Water flow
m3/h
23.9
25.2
34.8
39.1
42.8
Available static pressure
KPa
135
133
130
122
115
SCOP
-
3.21
3.20
3.21
3.20
3.20
ηs heating
%
125.4
125.0
125.4
125.0
125.0
Note:
(1) AC application. COOLING MODE: Outdoor temperature 35ºC, inlet water temperature
12ºC. Water outlet temperature 7ºC.
(2) IT application. HEATING MODE: Outdoor temperature 7ºC B.S. / 6ºC B.H., inlet water
temperature 40ºC, outlet water temperature 45ºC.
(3) LT application.HEATING MODE: Outdoor temperature 7ºC B.S. / 6ºC B.H., inlet water
temperature 30ºC, outlet water temperature 35ºC.

16
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
TECHNICAL SPECIFICATIONS
EKWXBA HE
121.4
132.4
171.4
193.4
207.4
ELECTRICAL DATA
Power supply
V / ~/Hz
400/3+N/50
Max current
A
138
152
186
223
237
Start-up current
A
283
294
327
353
409
0
REFRIGERANT
Number of circuits
-
2
Gas type
-
R-410A
Global Warming Potential (GWP) (4)
-
2088
Total refrigerant charge
kg
21.5 x 2
23 x 2
23.5 x 2
24 x 2
0
COMPRESSORS
Type
-
Scroll
Total number of compressors
4
Number of stages Power
-
4
Oil type
POE
Oil volume
L
2 x 6.9
2 x 13.4
Crankcase resistance
W
4x56
0
OUTDOOR FAN
Type
-
Axial EC
Total number
-
4
6
Max. air flow
m3/h
91780
91626
87660
100428
100222
Available static pressure
Pa
0
Nominal power
kW
4 x 1.95
6 x 1.95
Max. current
A
4 x 3.3
6 x 3.2
0
OUTDOOR HEAT EXCHANGER
Type
Aluminium fin coil and copper tubing
Number
2
Coil area (total)
m²
2 x 6.7
0
WATER CIRCUIT
Connection type
GROOVED –VICTAULIC TYPE
Connection outer diameter
"
2 1/2"
3"
WATER PUMP
Model
CEA 210/3
CEA 370/2
Number
2
Max. operating current one pump
A
2.5
3.4
INDOOR HEAT EXCHANGER
Type
Plates (Water/refrigerant)
Quantity
-
2
Water volume
L
14
19
Antifrost resistance
W
2 x 100
0
SOUND LEVEL
Sound power (Lw)
dB(A)
90
93
95
Sound pressure (Lp 5 m) (5)
dB(A)
69
72
74
0
DIMENSIONS and WEIGHT
Length
mm
3200
Width
mm
2215
Height
mm
2150
WEIGHT (without options nor charge) - EKWXBA
kg
1621
1733
1865
1898
1901
WEIGHT –COOLING ONLY
kg
1605
1716
1846
1879
1882
Note:
(4) GWP: Global Warming Potential (climatic) of 1 kg of greenhouse gas relative to 1 kg of CO2, calculated in terms of 100-year
warming potential.
(5) Conditions measured in open field, directivity 2 and at 1.5 m from the ground.

17
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
TRANSPORT & RECEPTION
INSPECTION AT RECEPTION
It is advisable to check the equipment carefully upon reception.
Check that the equipment has not been damaged during transport and has been supplied complete with all parts
specified in the order and/or with the optional specified in the order. If this is not the case contact the transport
company immediately (within 48h)
Verify the correct voltage of the nameplate and make sure it is in accordance with the local power supply.
In case of any flaw or anomaly detected, please contact HITECSA.
RIGGING
Before moving the unit make sure that all the panels are well fixed.
Raise and set down the equipment carefully.
Do not tilt the unit more than 15 degrees during transportation, (Pict. 1).
Always transport the unit in its original packaging to the place of installation.
All units come with a particular rigging diagram of that model similar to the one shown below. Be sure to hoist the
machine through the points indicated in the diagram.
Make sure that the unit is balanced, stable and without any deformations when it is lifted.
STORAGE
If the equipment is going to be stored before the installation, please follow the instructions below in order to avoid
damages, corrosion or deterioration:
Move it carefully.
Do not place the machine in places exposed to ambient temperatures above 50ºC and preferably keep the unit
away from direct sunlight.
Avoid placing the unit with plastic wrapping protection under the sun as the pressure of the circuits could assume
values that could lead to the intervention of the safety valves.
In addition, when cooling, water condensation occurs inside the machine and the plastic wrap.
Avoid placing other objects on top of the unit (unless it is done within the limits of the overlap planes indicated on
the packaging, etc. Follow these indications).
Avoid prolonged storage before installation, water penetration, dust and objects in general due to invasion or
biological, meteorological and/or human impacts.
Minimum storage temperature: 5ºC.
Maximum relative humidity: 90%.
Pict. 1

18
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
INSTALLATION
DIMENSIONS
Models 38.2 - 67.2
Unit with buffer tank
1. Water inlet Ø 2”
2. Water outlet Ø 2”
3. Electrical panel board
4. Main switch
5. Power supply input

19
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
INSTALLATION
DIMENSIONS
Model 75.2
1. Water inlet Ø 2”
2. Water outlet Ø 2”
3. Electrical panel board
4. Main switch
5. Power supply input
Buffer tank (as an option)
Unit with buffer tank (as an option)

20
IOM_EKWXBA HE_38.2a207.4_207810_190100_EN
EKWXBA HE
WATER CHILLERS
AXIAL FANS
INSTALLATION
DIMENSIONS
Models 95.2 –109.2
Buffer tank (as an option)
1. Water inlet Ø 2”
2. Water outlet Ø 2”
3. Electrical panel board
4. Main switch
5. Power supply input
