Hitecsa ACVBA 351 Instruction manual

Models: 351 │401 │ 501 │ 701 │721 │751 │801 │1001 │1201 │1402 │1502 │1602 │ 2002
│ 2302 │2402
Cooling capacities: from 12.5 kW to 78.5 Kw
Heat capacities: from 13.7 kW to 81.9 kW
Installation, Operation & Maintenance Manual
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT AIR-AIR UNITS
SOLO FRIO

Thank you for trusting the Hitecsa Products. Our company has been offering the market an extended range of
specialized units for air conditioning and cooling installations for over 35 years. Our approach is based on efficiency,
flexibility and on practical solutions. This has been the hallmark of our product catalogue.
The versatility of our factory allows us to deliver solutions that can meet any requirement and we endeavour solving
any problem that may arise in designing and implementing air conditioning installations.
From all of us at Hiplus Aire Acondicionado, once again, thank you very much.

3
12.17 201132 Rev103
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
INDEX
INTRODUCTION ...........................................................................................................................................................5
REGULATIONS AND CERTIFICATIONS ...........................................................................................................................6
SAFETY PRECAUTIONS .................................................................................................................................................7
TECHNICAL SPECIFICATIONS ........................................................................................................................................8
TECHNICAL SPECIFICATIONS FOR THE EC MOTOR (OPTION) ....................................................................................... 11
TRANSPORT & RECEPTION.........................................................................................................................................12
INSPECTION AT RECEPTION ......................................................................................................................................... 12
RIGGING ...................................................................................................................................................................... 12
STORAGE ..................................................................................................................................................................... 12
INSTALLATION ...........................................................................................................................................................13
DIMENSIONS ............................................................................................................................................................... 13
Models 351, 401, 501....................................................................................................................................... 13
Models 701, 721, 751, 801............................................................................................................................... 14
Models 1001, 1201 .......................................................................................................................................... 15
Models 1402, 1502, 1602................................................................................................................................. 16
Models 2002, 2300, 2402................................................................................................................................. 17
INSTALLATION LOCATION............................................................................................................................................ 18
UNIT SETTLEMENT....................................................................................................................................................... 18
SERVICE AREA (MM) ..................................................................................................................................................... 18
WEIGHT DISTRIBUTION (KG) ........................................................................................................................................ 18
WATER DRAIN ............................................................................................................................................................. 19
AIR DUCTS ................................................................................................................................................................... 19
ELECTRICAL INSTALLATION.......................................................................................................................................... 20
ELECTRICAL SPECIFICATIONS....................................................................................................................................... 20
ELECTRICAL DIAGRAM................................................................................................................................................. 21
OPERATION ...............................................................................................................................................................22
BEFORE START UP........................................................................................................................................................ 22
START UP ..................................................................................................................................................................... 22
OPERATING LIMITS...................................................................................................................................................... 22
INDOOR FAN TRANSMISSION ADJUSTMENT ............................................................................................................... 23
ACVBA-ACVA

º
4
IOM_ACVBA-ACVA_351a2402_207958_180107_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
TH TUNE CONTROL ...................................................................................................................................................... 24
Start / Stop ...................................................................................................................................................... 24
Temperature Adjustment................................................................................................................................ 24
System Modes ................................................................................................................................................. 24
Time Schedule .................................................................................................................................................. 24
Alarms.............................................................................................................................................................. 25
MAINTENANCE ..........................................................................................................................................................26
CONSERVATION AND CLEANING ................................................................................................................................. 26
LUBRICANT .................................................................................................................................................................. 27
REFRIGERANT CHARGE................................................................................................................................................ 27
FAN WITH EC MOTOR (OPTIONAL) ............................................................................................................................28
Safety instructions........................................................................................................................................... 28
Working on the device .................................................................................................................................... 29
Modifications / interventions in the device...................................................................................................... 31
Diagnosis / Faults............................................................................................................................................ 32
Status Out with flash code .............................................................................................................................. 33
Rotation caused by an air flow in false direction........................................................................................... 35
Maintenance and repairs................................................................................................................................ 35
Cleaning........................................................................................................................................................... 36
REFRIGERANT CHARGE................................................................................................................................................ 36
APPENDIX: SAFETY DATA R-410A...............................................................................................................................37
ACVBA-ACVA

5
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
INTRODUCTION
Purpose of this Manual
The present manual together with any other technical document such as refrigeration or
hydraulic lines drawings and electrical diagrams among others have been issued to provide the
necessary information for installation, start-up and maintenance of the unit. Therefore, it is
essential to read the instructions very carefully.
Make sure that all the necessary information for the proper installation of the system is included
in the manuals that have been supplied together with this unit and/or the rest of the indoor units,
accessories, etc. The manufacturer declines any responsibility in case of people/animals injuries
or material damages resulting from an incorrect use of the unit and/or non-compliance with these
instructions.
In case of different interpretations and/or errors, the priority order of validity of the given
documents will be: 1. Name plate of the unit stating the specifications. 2. IOM (the present
document), 3. EDM, technical catalogue, 4. UM user manuals.
Storage of the Manual
This manual and the electrical diagram of the unit must be preserved and remain available to the operator for any further
consultation.
Updating the Data
The continuous improvement in design and performance to which we are committed to gives us the right to modify the
specifications of our products without prior notice.
Electrical Supply
Check that the electrical network features comply with the data shown in the data nameplate of the unit.
Local Safety Regulations
Observe and analyse all the possible causes of accidents that may arise in the place or places of installation of the units,
check all the medium and the tools that will be used, etc. It is not possible to anticipate each one of the potential
circumstances of danger in this manual. Respect the valid local security standards during installation.
Principles of Security on Installation
The unit has been designed and built so that it does not represent any risk to the health and safety of people. Appropriate
solutions for the project have been adopted to eliminate the possible causes of risk in the installation.
Packaging and Replacement of Equipment
The material of the package (plastic bags, insulating materials, nails, etc.) is a potential source of danger.
Consequently, it should be kept out of the reach of children and properly recycled according to the valid
local safety regulations.
Do not mix this product with household waste at the end of its life. Due to the refrigerant, oil and other
components contained in this product, it must be dismantled by professional installers. All the
waste, depending on its nature shall be sent to recycling, composting or treatment plants, or to an
authorized management agency in accordance with the current local legislations.

º
6
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
INTRODUCTION
Utilization
The unit will be used only for the purpose it has been designed for. Any other use does not imply any kind of liability or
responsibility from the manufacturer.
Incorrect Operation
In case of breakdowns or operation faults, turn the unit off.
Periodic Inspections and Maintenance
Carry out periodic inspections to detect possible damaged or broken parts. If these parts are not repaired,
people injuries or material damages could be caused. Disconnect the power supply of the unit before
carrying out any maintenance operation.
Make sure that the maintenance areas are accessible. If these areas have to be necessarily invaded by
the air supply and/or lateral return ducts, verify that the design of the ducts allows the access to the fans
and that they are not a hindrance when replacing the filters. If that is not possible make sure access is
from the other side.
All operations shall be carried out in accordance with local safety regulations.
Repairing Operations
The reparations shall always and exclusively be completed by trained personnel previously authorized by
the manufacturer and only original spares shall be used. The safety devices of the unit may be damaged
in case of non-compliance with these warnings.
Modifications
The manufacturer will not respond to possible warranty claims and damages of the unit in case of electrical and/or
mechanical modifications. The unauthorized manipulation, reparation or modification of the unit will automatically invalidate
the warranty.
Refrigerant
This product is hermetically sealed and contains R-410A which is a HFC fluorinated greenhouse gas.
REGULATIONS AND CERTIFICATIONS
ISO 9001 CERTIFICATION: HIPLUS AIRE ACONDICIONADO S.L., by endeavouring to always gain the maximum
satisfaction from their customers, obtained the ISO 9001: Quality System for its production activity. That result shows our
continuous determination to improve quality and the reliability of all our products. Our commercial activities, design, raw
materials, production processes and after-sales service represent the means to reach our goal.
CE MARKING: Our products are CE marked according to the essential requirements of the applicable EC directives and
their last modifications and comply with the national legislation of each country.
In accordance with Article 1, (m) Subject matter and scope of Regulation (EU) 2016/2281 of November 30th, 2016 concerning the
ecodesign requirements for air heating products, cooling products, high temperature process chillers and fan coil units, the equipment
mentioned in the present document shall be used only for applications of which the primary function is the purpose of producing or storing
perishable materials at specified temperatures by commercial, institutional or industrial facilities and of which space heating and/or space
cooling is a secondary function and for which the energy efficiency of the space heating and/ or space cooling function is dependent on
that of the primary function. Therefore they are not valid for comfort applications in spaces occupied by people.

7
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
SAFETY PRECAUTIONS
DANGER
• In case of folding electrical panels, before folding them up in order to access to the interior of the machine, it is
MANDATORY to disconnect the power supply hose from the electrical voltage, IT MUST ALWAYS BE FREE OF
VOLTAGE for this operation.
• Do not touch or adjust the safety elements inside the unit. For repairs use only original spare parts and install
them properly in the same position where the old parts were fitted.
• The installation and maintenance of air conditioning equipment may be dangerous due to the pressure of the
system, the high temperature of some of its parts and the electrical components.
• Do not install the unit in an explosive atmosphere.
ATTENTION!
• Only qualified and trained service staff (technical service) is authorized to carry out installation, commissioning
and maintenance. Unqualified personnel will carry out basic tasks only such as cleaning and replacement of
filters, or filter cleaning (excluding refrigerant filters), etc.
Prevent access to children so that they cannot play with the appliances.
For each visit, all precautions must be taken into account: those recommended in the installation, operation and
maintenance instructions, as well as the ones indicated in the stickers placed on the unit. Do not forget to strictly
follow any other legal safety precautions.
DO NOT introduce objects into the air inlets or outlets that can be drawn into the fan, people, etc.
Use safety glasses, work gloves and any other safety accessory that may be necessary for the operation.
For brazing operations use a quenching cloth and make sure you have fire extinguisher close to you.
This product contains fluorinated greenhouse gases. In case of leakage air may be displaced which may cause
lack of oxygen.
The decomposition of fluorinated gases when being burned during brazing operations for example may cause
the presence of highly toxic and corrosive gases.
• All the safety recommendations must be followed.
Before starting anyinstallation, service or maintenance operation, turn the main power switch
off in order to avoid electrical shock that may cause personal injuries.
WARNING!
In case when the units are equipped with an ELECTRIC HEATERS:
Before starting the equipment, make sure that the water tank is completely full and that the installation
is perfectly drained of air.
WARNING!

º
8
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
TECHNICAL SPECIFICATIONS
MODEL
351
401
501
701
721
CAPACITIES
Cooling capacity
kW
9.8
12.5
14.4
18.9
19.6
Heat capacity
kW
10.4
13.7
15
20
21
EER Coefficient
2.2
2.2
2
2.3
2.1
COP Coefficient
2.5
2.7
2.3
2.6
2.6
Number of refrigerating circuits
1
1
1
1
1
REFRIGERANT
Type
R410A
GWP (1)
2088
Load (2)
3.5
4.2
4
6.2
5.8
COMPRESSOR
Type
Rotational
Scroll
Scroll
Scroll
Scroll
Number
1
1
1
1
1
Oil type
PVE
PVE
PVE
PVE
POE
Oil volume
l
1.3
1.7
1.7
1.7
2.8
Type
FV60S
FV68S
FV68S
FV68S
FV68S
OUTDOOR CIRCUIT FAN
Type
Centrifugal, double aspiration
Nominal air flow
m3/h
4300
3950
4900
6800
6800
Available static pressure
Pa
50
50
50
50
50
Model
10/10 SS
12/12 SS
12/12 SS
15/15 SS
15/15 SS
Power
kW
0.75
0.55
0.75
1.1
1.1
Speed
r.p.m.
1083
825
829
746
746
INDOOR CIRCUIT FAN
Type
Centrifugal, double aspiration
Nominal air flow
m3/h
2315
2600
3540
4720
4720
Available static pressure
Pa
43
50
60
55
55
Model
10/10 DD
10/10 DD
10/10 SS
12/12 SS
12/12 SS
Power
kW
0.25
0.55
0.55
0.75
0.75
Speed
r.p.m.
872
870
1032
809
809
DIMENSIONS AND WEIGHT
Length
mm
937
937
1087
1130
1130
Width
mm
750
750
750
800
800
Height
mm
1603
1603
1603
1900
1900
Weight
kg
251
276
290
367
392
1. GWP: Global Warming Potential (climatic) of 1 kg of greenhouse gas relative to 1 kg of CO2, calculated in terms of 100-year
warming potential.
2. Only units with “FLARE” valve as standard (not option) are loaded with refrigerant, the rest of them are loaded with dry nitrogen
to prevent the entry of moisture.

9
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
TECHNICAL SPECIFICATIONS
MODEL
751
801
1001
1201
1402
CAPACITIES
Cooling capacity
kW
22.7
24.2
30.1
34.9
37.8
Heat capacity
kW
23.9
25.3
31.7
38.2
39.5
EER Coefficient
2.1
2.2
2.3
2.4
2.3
COP Coefficient
2.3
2.6
2.6
2.9
2.6
Number of refrigerating circuits
1
1
1
1
2
REFRIGERANT
Type
R410A
GWP (1)
2088
Load (2)
7.2
7.7
9.5
10.5
2x6.5
COMPRESSOR
Type
Scroll
Scroll
Scroll
Scroll
Scroll
Number
1
1
1
1
2
Oil type
POE
POE
PVE
POE
PVE
Oil volume
l
2.8
2.8
2.8
3.3
2x1.7
Type
FV68S
FV68S
FV68S
160SZ
FV68S
OUTDOOR CIRCUIT FAN
Type
Centrifugal, double aspiration
Nominal air flow
m3/h
7400
7714
10000
12500
13600
Available static pressure
Pa
50
57
50
50
88
Model
15/15 SS
15/15 SS
15/11 G2L
15/11 G2L
2x15/15 SS
Power
kW
1.5
1.5
1.5
2.2
2x1.1
Speed
r.p.m.
834
808
686
760
718
INDOOR CIRCUIT FAN
Type
Centrifugal, double aspiration
Nominal air flow
m3/h
5133
5125
6277
8000
8000
Available static pressure
Pa
53
83
73
91
130
Model
12/12 SS
12/12 SS
12/12 G2L
12/12 G2L
12/12 G2L
Power
kW
1.1
1.1
1.1
1.5
1.5
Speed
r.p.m.
891
910
800
896
962
DIMENSIONS AND WEIGHT
Length
mm
1130
1130
1700
1700
2000
Width
mm
800
800
870
870
939
Height
mm
1900
1900
1900
1900
1997
Weight
kg
423
440
553
558
730
1. GWP: Global Warming Potential (climatic) of 1 kg of greenhouse gas relative to 1 kg of CO2, calculated in terms of 100-year
warming potential.
2. Only units with “FLARE” valve as standard (not option) are loaded with refrigerant, the rest of them are loaded with dry nitrogen
to prevent the entry of moisture.

º
10
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
TECHNICAL SPECIFICATIONS
MODEL
1502
1602
2002
2302
2402
CAPACITIES
Cooling capacity
kW
43.4
50.2
63.1
73.6
78.5
Heat capacity
kW
44.2
51.9
65.5
81.9
81.9
EER Coefficient
2.5
2.5
2.4
2.6
2.3
COP Coefficient
2.7
2.9
2.9
3
2.8
Number of refrigerating circuits
2
2
2
2
2
REFRIGERANT
Type
R410A
GWP (1)
2088
Load (2)
2 x 7.1
2 x 6.6
2 x 8.0
2 x 10.3
2 x 9.0
COMPRESSOR
Type
Scroll
Scroll
Scroll
Scroll
Scroll
Number
2
2
2
2
2
Oil type
POE
POE
POE
POE
POE
Oil volume
l
2 x 2.8
2 x 2.8
2 x 2.8
2 x 2.3
2 x 3.3
Type
FV68S
FV68S
FV68S
160SZ
160SZ
OUTDOOR CIRCUIT FAN
Type
Centrifugal, double aspiration
Nominal air flow
m3/h
15600
16000
22000
23000
23000
Available static pressure
Pa
110
110
123
142
142
Model
2x15/15 SS
2x15/15 SS
2x18/18 SS
2x18/18 SS
2x18/18 SS
Power
kW
2 x 1.5
2 x 1.5
2 x 2.2
2 x 3
2 x 3
Speed
r.p.m.
808
808
671
734
787
INDOOR CIRCUIT FAN
Type
Centrifugal, double aspiration
Nominal air flow
m3/h
10000
10000
11000
12000
12000
Available static pressure
Pa
145
145
175
160
160
Model
12/12 G2L
12/12 G2L
15/11 G2L
15/11 G2L
15/11 G2L
Power
kW
2.2
2.2
3
3
3
Speed
r.p.m.
913
913
734
787
734
DIMENSIONS AND WEIGHT
Length
mm
2000
2000
2600
2600
2600
Width
mm
939
939
980
980
980
Height
mm
1997
1997
2174
2174
2174
Weight
kg
810
820
1080
1115
1135
1. GWP: Global Warming Potential (climatic) of 1 kg of greenhouse gas relative to 1 kg of CO2, calculated in terms of 100-year
warming potential.
2. Only units with “FLARE” valve as standard (not option) are loaded with refrigerant, the rest of them are loaded with dry nitrogen
to prevent the entry of moisture.

11
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS FOR THE EC MOTOR (OPTION)
MODEL
801
1001
1201
1402
1502
1602
2002
2302
2402
Type
RADIAL with EC motor (Plug-Fan type)
Quantity / Size
- / mm
1 / 400
2 / 400
2 / 400
2 / 450
2 / 450
2 / 450
2 / 450
2 / 450
2 / 450
ELECTRICAL SPECIFICATIONS (for one fan)
Power supply
V / ~ / Hz
380V-480V / 3~ / 50Hz
Nominal power of the
motor
kW
2.4
2.4
2.4
2.0
2.0
2.0
2.0
2.0
2.0
Max. Current (400V)
A
3.7
3.7
3.7
3.2
3.2
3.2
3.2
3.2
3.2
NOMINAL OPERATING CONDITIONS
Nominal air flow
m3/h
5150
6200
8000
8000
10000
10000
11000
12000
12000
Nominal static pressure
Pa
62
75
75
75
75
100
100
100
100
Total power input
kW
0.72
0.68
1.06
0.82
1.35
1.44
1.31
1.61
1.61
Speed
rpm
1706
1252
1488
1103
1324
1344
1342
1448
1448
Total sound pressure
(Lw)
dBA
80
73
78
74
79
79
81
83
83
LIMIT OPERATING VALUES
Max. available pressure
Pa
813
1059
961
840
665
665
637
610
610
Max. speed
r.p.m.
2400
2400
2400
1880
1880
1880
1880
1880
1880
Max. sound power
dBA
87
93
91
87
86
86
86
87
87
Sound power at 400Pa
dBA
81
80
82
80
83
83
83
85
85

º
12
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
TRANSPORT & RECEPTION
INSPECTION AT RECEPTION
It is advisable to examine the equipment carefully upon reception.
Check that the equipment has not been damaged during transport and that it is complete with all the parts
specified in the order and/or the options stated in the order. If this is not the case please contact the transport
company immediately (within 48h).
Verify the correct voltage of the nameplate and make sure it is in accordance with local power supply.
In case of any flaw or anomaly detected, please contact HITECSA.
RIGGING
Before moving the unit, make sure that all panels are fixed properly.
Raise and put the equipment down carefully.
Do not tilt the unit more than 15 degrees during transportation.
Always transport the unit in its original packaging to the place of installation.
All units come with a particular rigging diagram of that model similar to the one shown below. Be sure to hoist the
machine through the points indicated in the diagram.
Make sure that the unit is balanced, stable and without any deformations during the lifting operations.
STORAGE
If the equipment is going to be stored before the installation, please follow the following instructions in order to avoid
damages, corrosion or deterioration:
Move it carefully.
Do not place the machine in places exposed to ambient temperatures above 50ºC and preferably keep the unit away
from direct sunlight.
Avoid placing the unit with plastic wrapping protection under the sun as the pressure of the circuits could reach values
that could lead to the activation of the safety valves.
Moreover, with decreasing temperatures water condensation may occur inside the machine and the plastic wrap.
Avoid placing other objects on top of the unit (unless this is done within the limits of the overlap planes indicated on the
packaging, etc. Follow these indications).
Avoid prolonged storage before installation, water penetration, dust and objects in general due to invasion orbiological,
meteorological and/or human impacts.
Minimum storage temperature: 5ºC
Maximum relative humidity: 90%.

13
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
INSTALLATION
DIMENSIONS
Models 351, 401, 501
MODEL
A
B
C
D
E
F
G
H
I
J
K
L
M
351
937
300
804
71
62
651
143
277
750
176
294
280
500
401
937
300
804
71
62
651
143
301
750
176
294
280
500
501
1087
375
904
91
92
731
143
277
750
176
294
280
500

º
14
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
INSTALLATION
DIMENSIONS
Models 701, 721, 751, 801

15
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
INSTALLATION
DIMENSIONS
Models 1001, 1201
MODEL
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
1001
1700
1294
203
1900
650
589
870
193
349
328
50
875
265
30
1250
225
298
403
298
1201
1700
1448
126
1900
650
610
870
193
349
328
50
875
265
30
1400
150
298
403
298

º
16
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
INSTALLATION
DIMENSIONS
Models 1402, 1502, 1602

17
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
INSTALLATION
DIMENSIONS
Models 2002, 2300, 2402
DISCHARGE AND AIR ADMISSION (AVAILABLE AS OPTIONS)
MODEL
A
B
ACVA-ACVBA 351-501
294
109
ACVA-ACVBA 701-801
347
104
ACVA-ACVBA 1001-1201
349
114
ACVA 1002-1502
349
115
ACVBA 1402-1602
349
207
ACVA 2002-2402
411
41
ACVBA 2002-2402
411
89

º
18
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
INSTALLATION
INSTALLATION LOCATION
Read and comply with the local rules and regulations applying to the installation of air conditioning systems.
Choose a clean place without dust nor debris.
Remain within the appropriate service area prepared for the equipment.
Verify that the ground or the structure prepared for the equipment is strong enough to support its weight during
operation.
Install shock absorbers throughout the installation to prevent the transmission of noise and vibration.
Check that the direction of the sound level will not disturb anybody.
UNIT SETTLEMENT
Make sure that the equipment is levelled correctly.
The bed frame should have sufficient strength to support unit weight.
Be sure that after settlement the unit drain is working properly.
SERVICE AREA (mm)
Make sure to respect the following measurements for the correct operation of the unit.
WEIGHT DISTRIBUTION (kg)
MODEL
1
2
3
4
351
63
63
63
63
401
69
69
69
69
501
73
73
73
73
701
92
92
92
92
721
98
98
98
98
751
106
106
106
106
801
110
110
110
110
1001
138
138
138
138
1201
147
147
147
147
1002
183
183
183
183
1402
203
203
203
203
1502
205
205
205
205
2002
270
270
270
270
2302
279
279
279
279
2402
284
284
284
284

19
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
INSTALLATION
WATER DRAIN
The indoor drain unit (of condensate water) has a 3/4” gas (ISO 228-1, BSPP) male connection.
The condensate drain pipe diameter should be equal or larger than the unit connection depending on the line
length and general building configuration.
The drainage line should be inclined a minimum 2% for proper water evacuation.
When drain line is exposed to air temperatures below 0 degrees, it is necessary to cover with thermal insulation
or electrical heating wire to avoid water freezing and tube damage.
It is convenient to install the drain trap with proper dimensions (see diagram).
AIR DUCTS
The air duct dimensions will be determined according to the air flow and the available static pressure of the unit.
They shall be designed by qualified technicians. An incorrect design may reduce the unit’s performance and may
be a hindrance when access to the unit for maintenance operations is needed (in particular where there is only
one possible access).
Use ducts made of non-inflammable material in order to avoid any risk of fire as a consequence of the deflagration
of gases. It is advisable to use insulated metal ducts.
Use flexible conduits to connect air ducts to the unit so as to avoid vibration and noise transmission.
Recommended drain trap
measures

º
20
IOM_ACVBA-ACVA_351a2402_207958_180109_EN
ACVBA-ACVA
PACKAGED VERTICAL COMPACT UNITS
AIR-AIR
INSTALLATION
ELECTRICAL INSTALLATION
The unit power supply should be within 10% of volts indicated on the unit nameplate. Damage caused by the
start-up of the unit in an incorrect voltage line is not covered by Hitecsa’s warranty.
When making electrical connections always use the unit wiring diagram.
Be sure that the compressor crankcase heater can be energized before unit start.
The line protection elements have to be placed by the installer according to the current legislation local laws.
The interconnecting wires have to be placed in a protection tube or an electrical cable conduits, cable trays, etc.
ELECTRICAL SPECIFICATIONS
MODEL
351
401
501
701
721
Power supply (50 Hz)
V
400-3+N
400-3+N
400-3+N
400-3+N
400-3+N
Total power input cooling (1)
kW
4.6
5.7
7.3
8.4
9.27
Total current input cooling (1)
A
9.2
10.5
13.3
16
17.8
Total power input heating (3)
kW
4.2
5.1
6.5
7.9
8.16
Total current input heating (3)
A
8.4
9.7
11.8
14.7
15.8
Max. power input cooling (2)
kW
5.4
7.3
9.5
11
11.1
Max. current input cooling (2)
A
9.7
12.3
15
19.3
19.5
Max. power input heating (4)
kW
5
6.3
7.5
9
9.21
Max. current input heating (4)
A
8.9
10.9
12.6
15.6
16.5
Start-up current
A
48
63
66
67
102
MODEL
751
801
1001
1201
1402
Power supply (50 Hz)
V
400-3+N
400-3+N
400-3+N
400-3+N
400-3+N
Total power input cooling (1)
kW
10.9
10.9
13.4
14.4
16.6
Total current input cooling (1)
A
20.2
20.4
24.5
27.8
31
Total power input heating (3)
kW
10.3
9.6
12.4
13.2
15.9
Total current input heating (3)
A
19.3
18.3
22.3
25.6
28.4
Max. power input cooling (2)
kW
13.8
13.6
16.5
17.8
14.2
Max. current input cooling (2)
A
23.5
23.2
28
30.9
37.4
Max. power input heating (4)
kW
12.3
12
15.8
16.4
18.3
Max. current input heating (4)
A
21.2
20.5
26
28.5
30.1
Start-up current
A
102
102
102
158
67
MODEL
1502
1602
2002
2302
2402
Power supply (50 Hz)
V
400-3+N
400-3+N
400-3+N
400-3+N
400-3+N
Total power input cooling (1)
kW
17.5
20.8
27
28.3
34.2
Total current input cooling (1)
A
35.6
37
48.1
56.1
57.2
Total power input heating (3)
kW
16.5
18.6
23.7
27
28.9
Total current input heating (3)
A
33.4
35.8
44.1
52.7
52.7
Max. power input cooling (2)
kW
25.4
26.6
33.2
33.5
42.7
Max. current input cooling (2)
A
40.5
43
55
58.8
63.9
Max. power input heating (4)
kW
21.3
22.6
30.2
30.6
36.2
Max. current input heating (4)
A
38.2
39.3
51.4
55
58.7
Start-up current
A
102
102
158
179
158
(1) Nominal cooling: Outdoor air temperature –35ºC / Indoor air wet temperature: 19ºC
(2) Max. Cooling: Outdoor air temperature –46ºC / Indoor air wet temperature: 21ºC
(3) Nominal heat: Outdoor air wet temperature –6ºC / Indoor air temperature: 20ºC
(4) Max. Heat: Outdoor air wet temperature –18ºC / Indoor air temperature: 26ºC
Turn the main power switch off before starting any type of operation.
WARNING!
