35
ENGLISH
(1) Do not connect unit to any ac socket in disrepair or with connections.
(2) Do not use in the following locations:
- Next to source of fire.
- An area where oil is likely to splash.
- An area exposed to direct sunlight.
- An area where water is likely to splash.
- Near a bath, a shower or a swimming pool.
- In the green house.
(3) Never insert your fingers or any foreign objects into the air outlet. Take special care to warn children
of these dangers.
(4) Always store the unit upright in order to maintain the compressor in a proper condition.
(5) Be sure to unplug the unit before cleaning.
(6) The heater must not be located immediately below a socket outlet.
(7) If the appliance is covered, there is a risk of overheat.
(8) If the supply tool of this appliance is damaged, it must be replaced by a repair shop appointed by the
manufacturer, because special purpose tools are required.
Note:
The air-conditioner can be connected only to a supply with system impedance no more than 0.4582 ohm. In case necessary,
please consult your supply authority for system impedance information.
SAFETY RULES
Manual 01-05Hiyasu Eng 11/3/05 13:29 Página 35

36
ENGLISH
NAMES OF PARTS
BASE STYLE
FRONT VIEW REAR VIEW SIDE VIEW
A style B style C style
FRONT VIEW FRONT VIEW FRONT VIEW
Operation
panel
Grilles
(horizontal)
RCU
Handle
recess
AC power cord
Filter
cover
Exhaust
air outlet
Drain tank
Casters
Operation
cover
Grilles
(horizontal)
RCU
Drain tank
Top cover
Casters
Operation
panel
Grilles
(vertical)
RCU
Drain tank
Top cover
Operation
cover
Grilles
(vertical)
RCU
Drain tank
Top cover
Note:
The Rear View and Side View as well as the performance of above styles are same as that of base style.
Manual 01-05Hiyasu Eng 11/3/05 13:29 Página 36

37
ENGLISH
•Check all the accessories are included in the package and please refer to the installation instructions for their usage.
ACCESSORIES
PARTS PARTS NAME QUANTITY
Duct 1
Adaptor A (for permanent duct mounting) 1
Adaptor B (for temporary duct mounting) 1
Wall plug 4
Screws 4
Alkaline batteries (the unit is not remote controlled without) 2
Remote control unit (the unit is not remote controlled
without) 1
Manual 01-05Hiyasu Eng 11/3/05 13:29 Página 37

38
ENGLISH
OPERATION PANEL
ON/OFF TIMER BUTTON:
Program the ON/OFF timer
function.
SELECTION
BUTTON: select the
operation mode from
cool, DEHUMIFY,
HEAT and FAN.
FAN SPEED BUTTON: switch
the fan speed to HIGH, MED
or LOW when on COOL and
FAN mode; HIGH or LOW
when on HEAT mode; fixed
speed when on DEHUMIFY
mode.
POWER
BUTTON:
Turn ON/OFF
the unit.
The temperature
is not displayed
under FAN and
DRY mode.
LOUVER BUTTON:
the louver automatically
varies the directions of air
flow.
TEMPERATURE
SETTING BUTTON:
setting the room
temperature you
desired by pressing
button “ ” (up) or
button “ ”
(down).
SIGNAL RECEIVER
(the unit isn’t remote
controlled without).
WATER FULL INDICATOR:
the charactron tube displays
“PI”, water alarm lamp flashes
two times per second when
the drain tank is full.
Manual 01-05Hiyasu Eng 11/3/05 13:29 Página 38

39
ENGLISH
Before Starting This Unit
1- Select a suitable location, make sure you have easy access to an electrical outlet.
2- Install the Flexible Exhaust Hose and the Adjustable Window Slider Kit as depicted in Fig.3 and Fig. 3a.
3- Plug the unit into a 220-240V~50Hz grounded electrical outlet.
4- Make sure the Water tank is correctly positioned inside the cabinet otherwise the unit will not operate (Fig. 4a).
5- To turn the unit on, press the ON/OFF switch.
(1) Before use.
DEHUMIDIFYING AND COOLING OPERATIONS:
•The operating range for dehumidifying is 13ºC-30ºC, and the operating temperature range for cooling operating is
17ºC-30ºC.
•If the cooling or dehumidifying operations have been switched off and need switching on again in a short time, allow
approximately three minutes for the cooling or dehumidifying operations to resume.
•Ensure that the drain tank is properly placed in the unit.
POWER SUPPLY:
•The operation condition is 18ºC-35ºC.
•Insert the AC Power Plug to a AC socket.
•Do not connect the air conditioner to a multiple socket outlet which is also being used for other electrical appliance.
•Be sure the power supply is AC 220-240V~50Hz.
(2) Cooling operation.
•Press the "MODE" button several times until the "COOL" indicator lights.
•Press the button " " (up) or " " (down) to select your desired room temperature. (17ºC- 30ºC)
•Press the "FAN" button to choose the fan speed. (High – Med – Low).
OPERATING
Note:
Step 2 is required only while using the COOLING MODE.
Fig. 3 Fig. 3a
Fig. 4
Manual 01-05Hiyasu Eng 11/3/05 13:29 Página 39

40
ENGLISH
(3) Dehumidifying operation.
•Press the "MODE" button several times until the "DRY" indicator lights.
•The fan will run at a fixed speed at this setting.
•Keep windows and doors closed for the best dehumidifying effect.
•Do not put the duct to window.
(4) Heating operation (cooling only type without).
•Press the "mode" button several times until the "heat" indicator lights.
•Press the button "down” or "up” to select your desired room temperature. (17ºC - 30ºC).
•Press the "fan" button to choose the fan speed. (HIGH – MED – LOW).
•Do not put the duct to window.
(5) Fan operation.
•Press the "MODE" button several times until the "FAN" indicator lights.
•Press the "FAN" button to choose the fan speed. (HIGH – MED – LOW).
•Do not put the duct to window.
(6) Timer operation.
1- Press the “TIMER ON” or “TIMER OFF” button can pre-select a time that will turn on and turn off the unit automa-
tically at specified times (between 0~24 hrs). The setting time is relative time that means the time you set is the delay
of the current time. If the setting time is not zero, the led indicator light will come on indicating the timer is set.
2- The unit will start automatically and the led indicator light will turn off when the specified timer on time is achieved.
The unit will stop automatically and the led indicator light will turn off when the timer off time is achieved.
3- Both “TIMER ON” and “TIMER OFF” time can be set simultaneously. The air conditioner operates to the nearest
time for either “TIMER ON” or “TIMER OFF”.
4- Press “ON/OFF” button will cancel the auto-timed program, but any interruption to the electrical power supply of
the unit has no affection to it.
(7) Automatic louver.
•Press the “SWING” button and the vertical grille will automatically move to control direction of air flow.
(8) Drain tank indicator.
1- When the water tank is full, the water full indicator light starts flashing continuously, the led indicator light turns dark
and the charactron tube will display “PI”. At this time the dehumidification process will immediately stop. However, the
fan motor will continue to operate.
2- Carefully remove the water tank from the cabinet and dispose of the water.
Replace the water tank back to its original position and the dehumidifying process
will automatically resume. It will take 3 minutes for the compressor to re-start. This
is normal.
(9) Continuous drainage.
•Drain water can be collected externally by directing the plastic tube inside the
drain tank cabin to any vessel such as bucket. Remove the plastic tube cap before
operate.
•Do not take out the water tank during drainage.
OPERATING
Note:
The fan speed of heating operation is different from that of cooling operation. Under heating operation, the med
fan speed is the same as the high fan speed.
Manual 01-05Hiyasu Eng 11/3/05 13:29 Página 40

41
ENGLISH
1- IMPORTANT:
Install the mobile air conditioner in a flat and spacious location where
the air outlets will not be covered up. A minimum clearance of 30 cm
from a wall or other obstacles should be kept. The appliance shall not
be used in the laundry. The plug shall accessible after appliance is
positioned. Wiring shall be done according to National rules.
2- DUCT MOUNT INSTALLATION
A) TEMPORARY
1. Attach one end of the duct to the exhaust air outlet of the mobi-
le air condition. According to the arrow direction, first fit the left side
of the duct on the exhaust air panel, then the right side duct. Push it
downwards, be sure to fix thoroughly. (See the figures).
2. Attach the other end of the duct to adaptor B.
3. Put the end of duct to a nearby window.
B) PERMANENT
1. Attach one end of the duct to the exhaust air outlet of the mobi-
le air conditioner. According to the arrow direction, first fit the left side
of the duct on the exhaust air panel, then the right side duct. Push it
downwards, be sure to fix thoroughly. (See the figures).
2. Install the adaptor A onto the wall by using 4 wall plug and
screws.
3. Attach the other end of the duct to adaptor A.
4. Cover the hole using the adaptor cap when not in use.
•The duct can be compressed or extended between 500 mm and 2000
mm, but it is desirable to keep the duct length to a minimum.
INSTALLATION
IMPORTANT: DO NOT OVER BEND THE DUCT (SEE FIGURE)
Exhaust air
outlet
AC power
cord
max 120 cm
min 30 cm
Exhaust
air outlet
Duct
Adapter A
Screws
Wall plug
Manual 01-05Hiyasu Eng 11/3/05 13:29 Página 41

42
ENGLISH
Window Kit Installation
Your window kit has been designed to fit most standard “Vertical”
and “Horizontal” window applications, However, it may be neces-
sary for you to improvise/modify some aspects of the installation
procedures for certain types of window. Please refer to Fig. 2 & Fig.
2a for minimum and maximum window openings.
Water Tank Safety Feature
This unit is equipped with a full safe switch mechanism which pre-
vents the unit from condensing water in the event the water tank is
accidentally displaced, and/or FULL with water. If this situation
occurs, the WATER FULL indicator light will flash red continuously
until the Drain Tank is correctly positioned and/or emptied.
INSTALLATION
Horizontal
window
Window Slider Kit
Minimum: 67.5 cm (2.22ft).
Maximum: 123 cm (4.04ft). Fig. 2
Vertical
window
Window Slider Kit
Minimum: 67.5 cm (2.22ft).
Maximum: 123 cm (4.04ft).
Fig. 2a
Manual 01-05Hiyasu Eng 11/3/05 13:29 Página 42

43
ENGLISH
1- AIR FILTER
•Clean the air filter at least once every two weeks to prevent infe-
rior fan operation because of dust.
•Removal.
Pull out the filter cover and remove the air filter from the filter
cover.
•Cleaning.
Wash the air filter by immersing it gently in warm water (about
40ºC) with a neutral detergent. Rinse the filter and dry it in a shady
place.
•Mounting.
Attach the air filter to the filter cover using the attachment hooks
on the inner surface of the cover. Put the filter cover back to the unit.
2- UNIT ENCLOSURE.
•Use a lint-free cloth soaked with neutral detergent to clean the
unit enclosure. Finished by a dry clean cloth.
3- DRAIN TANK.
• Wash the tank using warm water (about 40ºC) with neutral deter-
gent. Rinse and dry it in a cool place. Put the tank back to place after
it is dried completely.
MAINTENANCE
IMPORTANT
1. BE SURE TO UNPLUG THE UNIT BEFORE CLEANING OR SERVICING.
2. DO NOT USE GASOLINE, THINNER OR OTHER CHEMICALS TO CLEAN THE UNIT.
3. DO NOT WASH THE UNIT DIRECTLY UNDER A TAP OR USING A HOSE. THE ELECTRICAL COMPONENTS
INSIDE MAY BE DAMAGED AND CAUSE DANGER.
4. IF THE POWER CORD IS DAMAGED, IT SHOULD BE REPAIRED BY MANUFACTURE OR ITS AGENCY.
Manual 01-05Hiyasu Eng 11/3/05 13:29 Página 43

44
ENGLISH
TROUBLE SHOOTING
TROUBLES
1. UNIT DOES NOT
START WHEN PRES-
SING ON/OFF BUTTON
2. POWER SHUT OFF AT
HEATING MODE
3. NOISY OR VIBRATION
4. GURGLING SOUND
POSSIBLE CAUSES SUGGEST REMEDIES
• Water full indicator blinks, water tank is full. Dump the water in the water tank.
• Green lamp does not light. It is not yet three
minutes after switching off.
Wait until three minutes have passed.
• Room temperature is higher than the set
temperature.(Heating mode).
Reset the temperature.
• Room temperature is lower than the set
temperature.(Cooling mode).
Reset the temperature.
• The automatic over heat protection function.
When the temperature at the air outlet
exceed 75°C, the device will stop.
Switch on again after the unit has cool down.
• The ground is not level or not flat enough. Place the unit on a flat, level ground if possible.
• The sound comes from the flowing of the
refrigerant inside the air-conditioner.
It is normal.
Manual 01-05Hiyasu Eng 11/3/05 13:29 Página 44
