HL Display TurnLoader User manual

Installationmanualfor
TurnLoader
Version2.1-IssuedNovember15th
© HL Display 2019 –All rights reserved

Configuration
2
ID
Item
name
Product
name
1
Frame kit 1510mm
- 1800mm TLMD FA
2
Turnloader
bracket
TLMD
Bracket
TB
3
Adjustable shelf 0
°-12°450 kit
TLMD SK
4
Turnloader
Base shelf
TLMD BS
1
2
3
4

Packlist–framekit
3© HL Display 2019 –All rights reserved
ID
Item
name
Product
name
1
Frame kit 1510mm
- 1800mm TLMD FA
2
Turnloader
bracket
TLMD
Bracket
TB
3
Adjustable shelf 0
°-12°450 kit
TLMD SK
4
Turnloader
Base shelf
TLMD BS
1Frame kit is packed as three sub-assemblies
Top piece Bottom piece
Side
pieces

Bracketspack
includesfittings and side handles
4
ID
Item
name
Product
name
1
Frame kit 1510mm
- 1800mm TLMD FA
2
Turnloader
bracket
TLMD
Bracket
TB
3
Adjustable shelf 0
°-12°450 kit
TLMD SK
4
Turnloader
Base shelf
TLMD BS
2

TLMDSK
Adjustable0°-12°450Shelf kit
461448
5
Pack includes dividers and front stop
Standard front stopper height: 113mm
3
ID
Item
name
Product
name
1
Frame kit 1510mm
- 1800mm TLMD FA
2
Turnloader
bracket
TLMD
Bracket
TB
3
Adjustable shelf 0
°-12°450 kit
TLMD SK
4
Turnloader
Base shelf
TLMD BS

Shelfkit
Frontstopperandfences
6
3
ID
Item
name
Product
name
1
Frame kit 1510mm
- 1800mm TLMD FA
2
Turnloader
bracket
TLMD
Bracket
TB
3
Adjustable shelf 0
°-12°450 kit
TLMD SK
4
Turnloader
Base shelf
TLMD BS

TLMDBS
Turnloaderbaseshelf1250/2
465428
7
4
ID
Item
name
Product
name
1
Frame kit 1510mm
- 1800mm TLMD FA
2
Turnloader
bracket
TLMD
Bracket
TB
3
Adjustable shelf 0
°-12°450 kit
TLMD SK
4
Turnloader
Base shelf
TLMD BS
Pack includes dividers and front stop

Additionaltoolsneeded forinstallation
8
(not included with kit)

Critical dimensions
9

Weightlimitpershelf
10
Max
100 kg
TL MD 1250/450 measurement

Shelfcapacity
11
Faces
Depth
Total
2
4
8
2
5
10
2
6
12
10
7
70
Capacity
100

Unpackingbaseand topframe
12

Unpackingbrackets
13
Fittings for connecting frame
Frame handle
Reversible brackets

Bottomframeassemblywithbottombrackets
14

15
Bottomframewithbrackets

16
Right
Left
Brackets 30
Bottom L/R Brackets 25
Bottom L/R
Checkfitasbracketsarereversible!

17
11a 1b
1c 1d
!

Topframeassemblywithtopbrackets
18

Topframewithbrackets
19

Checkfitasbracketsarereversible!
20
RightLeft
Brackets 30
Top L/R Brackets 25
Top L/R
