OM-2226
05/02/2013 – Original
Operation and Maintenance Manual
with
Illustrated Parts List
for
60CU20
60 kVA, 3 Phase, 115/200 Volt,
400 Hz. Generator Set
Series 500062
ITW GSE Group
Hobart Ground Systems
Palmetto, Florida 34221
U.S.A.

Warranty
HOBART GROUND POWER
PALMETTO, FL 34221
Data Sheet 165
Index: 990223
Replaces: 980601
1. Hobart Brothers Company (hereinafter called HOBART) warrants that each new and unused Hobart Ground Power
Equipment, (hereinafter called the PRODUCT) is of good workmanship and is free from mechanical defects,
provided that (1) the PRODUCT is installed and operated in accordance with the printed instructions of HOBART,
(2) the PRODUCT is used under the normal operating conditions for which it is designed, (3) the PRODUCT is not
subjected to misuse, negligence or accident, and (4) the PRODUCT receives proper care, lubrication, protection,
and maintenance under the supervision of trained personnel.
2. This warranty expires 15 months after shipment by HOBART to the first user, or 12 months after installation,
whichever first occurs.
3. This warranty does not apply to: primary and secondary switch contacts, cable connectors, carbon brushes, fuses,
bulbs, and filters unless found to be defective prior to use.
4. Hobart DOES NOT WARRANT THE FOLLOWING COMPONENTS: Engines, engine components; such as:
starters, alternators, regulators, governors, etc., and cable retrieving devices. Many of the foregoing components
are warranted directly by the manufacturer to the first user and serviced by a worldwide network of distributors and
others authorized to handle claims for component manufacturers. A first user’s claim should be presented directly
to such an authorized component service outlet. In the event any component manufacturer has warranted its
component to HOBART and will not deal directly with a first user then HOBART will cooperate with the first user
in the presentation of a claim to such manufacturer. Under NO circumstances does HOBART assume any liability
for any warranty claim against or warranty work done by or in behalf of any manufacturer of the foregoing
components.
5. This warranty is extended by HOBART only to the purchaser of new PRODUCTS from HOBART or one of its
authorized distributors. The PRODUCTS purchased under this warranty are intended for use exclusively by the
buyer and his employees and by no other persons and, therefore, there shall be no third party beneficiary to this
warranty.
6. A claim of defects in any PRODUCT covered by this warranty is subject to HOBART factory inspection and
judgment. HOBART’S liability is limited to repair of any defects found by HOBART to exist, or at HOBART’S
option the replacement of the defective product, F.O.B. factory, after the defective product has been returned by the
purchaser at its expense to HOBART’S shipping place. Replacement and exchange parts will be warranted for the
remainder of the original Warranty, or for a period of ninety (90) days, whichever is greater.
7. UNDER NO CIRCUMSTANCES whatsoever shall HOBART and its authorized distributors be liable for any
special or consequential damages, whether based on lost goodwill, lost resale profits, work stoppage impairment
of other goods or otherwise, and whether arising out of breach of any express or implied warranty, breach of
contract, negligence or otherwise, except only in the case of personal injury as may be required by applicable law.
8. Continued use of the PRODUCT(S) after discovery of a defect VOIDS ALL WARRANTIES.
9. Except as authorized in writing, this warranty does not cover any equipment that has been altered by any party
other than HOBART.
10. THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HERE
OF. HOBART MAKES NO WARRANTIES, EXPRESSED OR IMPLIED, OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE.
11. HOBART neither assumes nor authorizes any person to assume for HOBART any liability in connection with the
PRODUCTS sold, and there are no oral agreements or warranties collateral to or affecting this written Warranty.
This warranty and all undertakings of HOBART thereunder shall be governed by the laws of the State of Ohio,
United States of America.
WARNING: AT ALL TIMES, SAFETY MUST BE CONSIDERED AN IMPORTANT FACTOR IN THE
INSTALLATION, SERVICING AND OPERATION OF THE PRODUCT, AND SKILLED, TECHNICALLY
QUALIFIED PERSONNEL SHOULD ALWAYS BE EMPLOYED FOR SUCH TASKS.

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Revision Log
Page 1
Record of Change
Rev.
No.
Release Date
By
Description
0
May 2, 2013
MLJ
This is a spec roll from OM-2175A (500061A) for release of STD and
DLX configurations.
Note: the 60 kVA is similar to the 90 kVA with the following differences:
•Air cleaner and related air intake components
•AC Ammeter (different ranges)
•ID Resistor (different Power Module Panel assembly)

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Safety Warnings
Page 1
Safety Warnings and Cautions
WARNING
ELECTRIC SHOCK can KILL. Do not touch live electrical parts.
ELECTRIC ARC FLASH can injure eyes, burn skin, cause equipment damage, and
ignite combustible material. DO NOT use power cables to break load and prevent tools
from causing short circuits.
IMPROPER PHASE CONNECTION, PARALLELING, OR USE can damage this and
attached equipment.
IMPORTANT
Protect all operating personnel. Read, understand, and follow all instructions in the
Operating/Instruction Manual before installing, operating, or servicing the equipment.
Keep the manual available for future use by all operators.
WARNING
CALIFORNIA PROPOSITION 65 - DIESEL ENGINES. Diesel engine exhaust and
some of its constituents are known to the State of California to cause cancer, birth
defects and other reproductive harm.
1) General
Equipment that supplies electrical power can cause serious injury or death, damage to other equipment or
property. The operator must strictly observe all safety rules and take precautionary actions. Safe practices
have been developed from past experience in the use of power source equipment. While certain practices
below apply only to electrically powered equipment, other practices apply to engine-driven equipment, and
some practices to both.
2) Shock Prevention
Bare conductors, terminals in the output circuit, or ungrounded, electrically live equipment can fatally shock a
person. Have a certified electrician verify that the equipment is adequately grounded and learn what
terminals and parts are electrically HOT. Avoid hot spots on machine. Use proper safety clothing,
procedures, and test equipment.
The electrical resistance of the body is decreased when wet, permitting dangerous currents to flow through it.
When inspecting or servicing the equipment, do not work in damp areas. Stand on a dry rubber mat or dry
wood, and use insulating gloves when dampness or sweat cannot be avoided. Keep clothing dry, and never
work alone.
a) Installation and Grounding of Electrically Powered Equipment
This equipment must be installed and maintained in accordance with the National Electrical Code,
ANSI/NFPA 70, or other applicable codes. A power disconnect switch or circuit breaker must be
located at the equipment. Check the nameplate for voltage, frequency, and phase requirements. If
only 3-phase power is available, connect any single-phase rated equipment to only two wires of the 3-
phase line. DO NOT CONNECT the equipment grounding conductor (lead) to the third live wire of
the 3-phase line, as this makes the equipment frame electrically HOT,which can cause a fatal shock.

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Safety Warnings
Page 2
Always connect the grounding lead, if supplied in a power line cable, to the grounded switch box or
building ground. If not provided, use a separate grounding lead. Ensure that the current (amperage)
capacity of the grounding lead will be adequate for the worst fault current situation. Refer to the
National Electrical Code ANSI/NFPA 70 for details. Do not remove plug ground prongs and use
correctly mating receptacles.
b) Output Cables and Terminals
Inspect cables frequently for damage to the insulation and the connectors. Replace or repair cracked
or worn cables immediately. Do not overload cables. Do not touch output terminal while equipment
is energized.
3) Service and Maintenance
This equipment must be maintained in good electrical condition to avoid hazards stemming from
disrepair. Report any equipment defect or safety hazard to the supervisor and discontinue use of the
equipment until its safety has been assured. Repairs should be made by qualified personnel only.
Before inspecting or servicing this equipment, take the following precautions:
a) Shut off all power at the disconnecting switch, or line breaker, or by disconnecting battery, before
inspecting or servicing the equipment.
b) Lock switch OPEN (or remove line fuses) so that power cannot be turned on accidentally.
c) Disconnect power to equipment if it is out of service.
d) If troubleshooting must be done with the unit energized, have another person present who is trained
in turning off the equipment and providing or calling for first aid.
4) Fire And Explosion Prevention
Fire and explosion are caused by electrical short circuits, combustible material near engine exhaust pipes,
misuse of batteries and fuel, or unsafe operating or fueling conditions.
a) Electrical Short Circuits and Overloads
Overloaded or shorted equipment can become hot enough to cause fires by self-destruction or by
causing nearby combustibles to ignite. For electrically powered equipment, provide primary input
protection to remove short circuited or heavily overloaded equipment from the line.
b) Batteries
Batteries may explode and/or give off flammable hydrogen gas. Acid and arcing from a ruptured
battery can cause fires and additional failures. When servicing, do not smoke, cause sparking, or use
open flame near the battery.
c) Engine Fuel
Use only approved fuel container or fueling system. Fires and explosions can occur if the fuel tank is
not grounded prior to or during fuel transfer. Shut unit DOWN before opening fuel tank cap. DO NOT
completely fill tank, because heat from the equipment may cause fuel expansion overflow. Remove
all spilled fuel IMMEDIATELY, including any that penetrates the unit. After clean-up, open equipment
doors and blow fumes away with compressed air.

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Safety Warnings
Page 3
5) Toxic Fume Prevention
Carbon monoxide - Engine exhaust fumes can kill and cause health problems. Pipe or vent the exhaust
fumes to a suitable exhaust duct or outdoors. Never locate engine exhausts near intake ducts of air
conditioners.
6) Bodily Injury Prevention
Serious injury can result from contact with fans or hot spots inside some equipment. Shut DOWN such
equipment for inspection and routine maintenance. When equipment is in operation, use extreme care in
doing necessary troubleshooting and adjustment. Do not remove guards while equipment is operating.
7) Medical and First Aid Treatment
First aid facilities and a qualified first aid person should be available for each shift for immediate treatment
of all injury victims. Electric shock victims should be checked by a physician and taken to a hospital
immediately if any abnormal signs are observed.
EMERGENCY
FIRST AID
Call physician immediately. Seek additional assistance. Use First Aid techniques
recommended by American Red Cross until medical help arrives.
IF BREATHING IS DIFFICULT, give oxygen, if available, and have victim lie down.
FOR ELECTRICAL SHOCK, turn off power. Remove victim; if not breathing, begin
artificial respiration, preferably mouth-to-mouth. If no detectable pulse, begin external
heart massage. CALL EMERGENCY RESCUE SQUAD IMMEDIATELY.
8) Equipment Precautionary Labels
Inspect all precautionary labels on the equipment monthly. Order and replace all labels that cannot be
easily read.

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Safety Warnings
Page 4
This page intentionally left blank.

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Table of Contents
Page 1
Table of Contents
Chapter 1
Description/Operation
Chapter-Section/Page#
Section 1
Description
1-1/1
General
1-1/1
Optional Equipment - Appendix A
1-1/1
Orientation
1-1/1
Specifications
1-1/3
Special Features
1-1/5
Canopy
1-1/5
Engine and Generator
1-1/5
Control Box Assembly
1-1/11
Power Module Panel Assembly
1-1/22
Cold Weather Start System
1-1/24
Transformer-Rectifier (T-R) Assembly
1-1/25
Section 2
Preparation for Use, Storage or Shipping
1-2/1
Preparation For Use
1-2/1
Preparation for Storage
1-2/5
Preparation for Shipment
1-2/6
Section 3
Operation
1-3/1
General
1-3/1
400 Hz. Operation Procedure
1-3/1
DC Operation Procedure
1-3/6
Simultaneous AC and DC Operation
1-3/6
Chapter 2
Servicing / Troubleshooting
Chapter-Section/Page#
Section 1
Maintenance Inspection/Check
2-1/1
General
2-1/1
Maintenance Schedule
2-1/1
Inspection / Check
2-1/3

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Table of Contents
Page 2
Section 2
Maintenance Procedures
2-2/1
General
2-2/1
Engine Lubrication 2-2/2
Servicing the Air Cleaner
2-2/6
Engine Fuel
2-2/7
Engine Fuel System 2-2/8
Engine Cooling System
2-2/11
Drive Belt
2-2/14
Generator Maintenance 2-2/14
Section 3
Adjustments / Tests
2-3/1
General 2-3/1
Testing the 400 Hz. Generator Set
2-3/1
Generator Set Adjustments
2-3/12
Generator and Exciter Test 2-3/15
Diode Test
2-3/16
Testing the Transformer-Rectifier
2-3/16
Adjusting the Transformer-Rectifier 2-3/18
Section 4
Troubleshooting Procedures
General 2-4/1
Equipment for Troubleshooting
2-4/1
Parts Replacement
2-4/1
Normal Operation 2-4/2
Check Connections and Leads
2-4/2
Engine Troubleshooting
2-4/2
Illustrations 2-4/2
Connection and Schematic Diagrams
2-4/2
GPU Control Monitoring
2-4/3
Troubleshooting Charts 2-4/10
…Engine Controls
2-4/10
…Generator Excitation Circuits
2-4/13
…Load Contactor Operating Circuits 2-4/14
…Protective Circuit
2-4/16
…Generator
2-4/18
…T-R Controls and Components 2-4/19
Troubleshooting Tables – GPU Commands
2-4/21
Troubleshooting Tables – GPU Faults
2-4/22

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Table of Contents
Page 3
Chapter 3
Overhaul / Major Repair
Chapter-Section/Page#
Section 1
Exciter Armature
3-1/1
General
3-1/1
Exciter Armature
3-1/2
Exciter Armature Replacement
3-1/3
Exciter Armature Installation
3-1/6
Section 2
Dual Bearing Flexible Coupling
General
3-2/1
Disassembly
3-2/1
Coupling Service
3-2/4
Coupling Installation
3-2/5
Reassemble Engine and Generator
3-2/6
Run-in and Periodic Check
3-2/7
Section 3
Generator Assembly
General
3-3/1
Generator Assembly Removal
3-3/1
Generator Assembly Installation
3-3/2
Chapter 4
Illustrated Parts List
Chapter-Section/Page#
Section 1
Introduction
4-1/1
General
4-1/1
Purpose
4-1/1
Arrangement
4-1/1
Explanation of Parts List
4-1/1
Section 2
Manufacture's Codes
4-2/1
Explanation of Manufacture's (Vendor) Code List
4-2/1

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Table of Contents
Page 4
Section 3
Illustrated Parts List
4-3/1
Explanation of Parts List Arrangement
4-3/1
Symbols and Abbreviations 4-3/1
Figure 1: General Assembly
4-3/2
Figure 2:Trailer / Frame Assembly
4-3/4
Figure 3: Canopy Frame Assembly 4-3/6
Figure 4: Canopy Assembly
4-3/8
Figure 5: Internal Components
4-3/10
Figure 6: Control Box and Door Assembly 4-3/12
Figure 7: Control Box Interior Components
4-3/14
Figure 8: Control Switch Panel Components
4-3/16
Figure 9: 400 Hz. Power Module Assembly 4-3/18
Figure 10: Engine Cooling System Assembly
4-3/20
Figure 11: Engine Ground Plate and Battery Disconnect Switch
4-3/22
Figure 12: Engine Fuel Filter and Fuel Lines 4-3/24
Figure 13: Engine Exhaust Components
4-3/26
Figure 14: 12 VDC Battery System
4-3/28
Figure 15: Engine Air Intake Assembly 4-3/30
Figure 16: Engine Components
4-3/32
Figure 17: Engine Electrical Panel Components
4-3/34
Figure 18: Generator Assembly 4-3/36
Figure 19: Transformer-Rectifier Assembly – Part 1
4-3/38
Figure 20: Transformer-Rectifier Assembly – Part 2
4-3/40
Section 4
Numerical Index
4-4/1
Explanation of Numerical Index
4-4/1
Chapter 5
Manufacture's Literature
Appendix A Options/Features
Wet Stacking
Unusual Service Conditions

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Introduction
Page 1
Introduction
This manual contains operation and maintenance information for a diesel engine-generator manufactured by
Hobart Ground Systems, Palmetto, Florida 34221.
This manual, including all information contained thereon, is exclusive and confidential property of
Hobart Ground Systems. This manual is not to be copied, reproduced, or delivered or disclosed to
others, in whole or in part, except with express written permission of Hobart Ground Systems.
This manual is not intended to be a textbook on electricity or electronics. Its primary purpose is to provide
information and instructions to experienced operators, electricians, and mechanics that have never operated
this equipment. It is the intent of this manual to guide and assist operators and maintenance personnel in the
proper use and care of the equipment.
Use of the manual should not be put off until trouble or a need for help develops. Read the instructions
before starting the unit. Learn to use the manual and to locate information contained in it. Its style and
arrangement are very similar to commercial aircraft manuals.
The manual is divided into five chapters plus an appendix. Each chapter is divided into as many sections as
required. Each new section starts with page 1. Each page is identified by chapter, section and page number,
which are located in the lower, outside corner.
When information located in another portion of the manual is referred to, a chapter, section, and paragraph or
figure number identify its location. For example: “(see Section 2-3, Paragraph 1.a.)” refers to information
located in Chapter 2, Section 3, Paragraph 1.a. If a chapter and section are not indicated in a reference, the
referenced material is located in the same section as the reference, for example: “(see Paragraph 1.a.).”
The appendix is the last section. It contains a list of available options that may be purchased or have been
purchased with that unit. Items on the list with check marks next to them have been added to the standard
unit per the customer’s order. Literature for each option follows. The appendix will help control the
information in the manual making it unique to the unit purchased.
In addition to operation and maintenance instructions, the manual contains an illustrated parts list in Chapter
4 and a collection of manufacturer’s literature and supplemental information in Chapter 5.
Contents of the manual are arranged as follows:
Chapter 1 Description/Operation
Chapter 2 Servicing/Troubleshooting
Chapter 3 Overhaul/Major Repair
Chapter 4 Illustrated Parts List
Chapter 5 Manufacturer’s Literature
Appendix A Options

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Introduction
Page 2
If you have any questions concerning your Hobart Ground Power equipment, immediately contact our Service
Department by mail, telephone, FAX, or E-Mail.
Write: Hobart Ground Systems
Service Department
11001 US Highway 41, North
Palmetto, FL 34221
U.S.A.
Call Inside U.S.A.: [phone] (Parts)
[phone] (Service)
Call From Foreign Countries: [phone] (Parts)
[phone] (Service)
FAX Inside U.S.A. [phone]
FAX From Foreign Countries: [phone]
E-Mail : [e-mail]
Web Page : www.hobartsystems.com

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Chapter 1-1
Page 1
Chapter 1
Description/Operation
Section 1
Description
1) General
The basic generator set covered in this manual, manufactured by ITW GSE Group, Hobart Ground
Systems is rated at 60 kVA and is designed to produce and deliver 115/200-volt, 400 Hz, 3-phase AC
power to a parked aircraft or other load. Some generator models with the TR option also provide 28.5
volts DC for aircraft having those requirements.
The number 500061 identifies the model or series of the GPU. The part number is followed by a different
dash number that separates the basic units available. Figure 1 uses the part number to identify the
variations covered in this manual.
Part & Dash
Number
Fuel
Tank
Exhaust
Mounting
AC
Outputs
28.5 DC
Output
500062-STD
Composite
Vertical
Trailer
Single
---
500062-DLX
Composite
Vertical
Trailer
Single
---
500062TR-STD
Composite
Vertical
Trailer
Single
Yes
500062TR-DLX
Composite
Vertical
Trailer
Single
Yes
Table 1: Series 500062 Generator Set Part Number Descriptions
2) Optional Equipment - Appendix A
Chapters 1 through 5 of this Operation and Maintenance Manual identify only the stripped down version
of the 60CU20 generator set. A list of optional equipment appears in Appendix A.
3) Orientation
For purpose of orientation when designating RIGHT and LEFT throughout this manual, the radiator is
considered to be at the FRONT of the unit and the generator and controls are at the REAR. RIGHT and
LEFT are determined by standing at the REAR facing the machine. As an example, the fuel filler neck is
mounted on the LEFT REAR side of the unit.

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Chapter 1-1
Page 2
1. Fuel Filler Neck
2. Operator’s Control Panel
3. Output Cable Trays
4. 5th Wheel Assembly
5. Rear Drop Axle Assembly
6. Emergency Stop Switch (S28)
7. Exhaust Stack Outlet
8. Engine Air Intake
9. Lift Off Access Doors
10. CAC/Radiator End
11. Generator End
12. Cable Rollers (optional)
13. Block Heater Receptacle (optional)
14. Forklift Pockets (optional)
Figure 1: General Assembly of Generator Set
11
2
3
4
1
5
6
7
9
9
10
12
13
14
8

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Chapter 1-1
Page 3
4) Specifications
a) Physical Specifications
Physical
Basic Unit
(Fixed Mount)
With Trailer
Length
74 in. (1880 mm)
101 in. (2570 mm) w/ tow bar up
Width
67 in. (1702 mm)
67 in. (1702 mm)
Height
59 in. (1499 mm)
67 in. (1702 mm)
Weight
4000 lb. (1814 kg.)
4300 lb. (1950 kg.)
Weight with 28.5 VDC T-R
4300 lb. (1950 kg.)
4600 lb. (2087 kg.)
b) AC Generator Specifications
Output power rating
60 kVA (48 kW)
Output voltage
115 / 200 VAC
Rated load capacity
174 Amps
Frequency
(at not load and rated load)
400 Hz. ± 2 Hz.
Power factor
0.8
Duty Cycle
100%
Operating speed
2000 RPM
Overload capacity 125% rated load
218 Amps
Output cable size
2/0
c) AC Generator Protective System Specifications
Condition
Trip Point
Time Delay
Over voltage
126 volts
1-second
140 volts
160 milliseconds
180 volts
50 milliseconds
Under voltage
any voltage below 100 volts
7 seconds
Over frequency
420 Hz to 480 Hz
5 seconds
above 480 Hz
immediate
Under frequency
380 Hz. or less
7-seconds
Output overload
125% load of 60 kVA
on either or both outputs
approximately 5 minutes
150% load
30 seconds
200% load
10 seconds

OM-2226 / Operation and Maintenance Manual
60CU20 / Series 500062 / 400 Hz. Generator Set
May 2, 2013
Chapter 1-1
Page 4
d) DC Output Specifications (with optional TR unit)
Output Power Rating
17.1 kW
Output Voltage
28.5 VDC
Load Capacity (Continuous)
600 A
Current Limiting Capability
100 to 2500 A
Peak/Starting Load Capacity 2000 A for 10 seconds
Output cable size 4/0
e) DC Protective System Specifications
Condition
Trip Point
Time Delay
Over Voltage
32-34 VDC
2 seconds
Output Overload
2700 A
2 seconds
2000 A
10 seconds
1500 A
30 seconds
1200 A
90 seconds
750 A
600 seconds
f) Engine Specifications
Manufacturer and Model
Cummins Engine Company / QSB4.5
Type
4 cylinder, 4 cycle diesel, electronic controlled
Bore and Stroke
4.21 in. x 4.88 in. (107 mm x 124 mm)
Displacement
275 in3(4.5 L)
Horsepower
109 hp (81 kW)
Idle speed
1000 ± 50 rpm
Normal governed speed
2000 rpm
Firing Order
1-3-4-2
Electrical system
12 VDC
Lubricating oil capacity (w/ filter)
11.6 quarts (11 liters)
Coolant capacity system
20 quarts (18.9 liters)
g) Normal Operating Characteristics
Engine oil pressure (warm and at rated speed 2000 RPM)
45 to 90 PSI (445 to 621 kPa).
Engine coolant temperature (normal operation)
160 to 200º F (71 to 93º C).
