HOBBY ENGINE CRAWLER CRANE 0705 User manual

HTEBT
HOBBY ENGINE
Hobbyengine Model Limited
Address: Rm 619,6/F., Peninsula Centre,67 Mody Road, Tsim Sha Tsui East, Kowloon, Hong Kong.
Website: www.hobbyengine.com.hk

On scaleCRAwLER CRANE model with 2.4G Radio control system.
Hidden antenna on CMWLER CRANE & remote controller.
Aged decoration-traces of oil,rusted,mudded.
Full digital proportional control
Working platform turn left & right 360 degrees freely.
Body spin 360 degrees freely.
Climb up to 20 degrees.
lndividual track control.

1. Turn screw anti-clockwise on battery door under CRAWLER CRANE to open.
2. Plug wilh fully charged battery pack on socket in battery compartment.
3. Cover the battery door and tighten the screw clockwise.
4. Activate CRAWLER CRANE by sliding switch to "ON'
REMARKS: Charge the battery pack 6 hours for the first time, 4 hours from 2dtime.
1. Slide remote controller power switch to "ON". LED luminated to Red.
2. Slide CRAWLER CRANE power switch to "ON".
3. Press "tulATCHlNG" button on top deck of CRAWLER CRANE. The LED on side will be flashed for 5 seconds.
4. LED stop tlashing, lhe CRAWLER CRANE is already matched with controller and ready to work.

R3
R2
R1
!I9II!Urqg]Itri{glr
t
FoMard bv oushinq both iovstick to the ftont. Backward by pushing both joystick to the back.
Left turn by pushing leftjoystick to front. Right turn by pushing rightjoystick to front.

Left spin by pushing left ioystick to front and
rightjoystick to back. Right spin by pushing rightjoystick to front and
left joystick to back.
Working platform left turn by pressing
(11) button. Working platform right turn by pressing
(R'1) button.
Latticed boom tilt up by pressing (L2)
button.
Latticed boom tilt down by pressing
(R2) button.

tReleasing hoist rope by pressing (L3) button.
t
Tighten up hoist rope by pressing (R3) button.
Open bucket by pressing (L4) button. Close bucket by pressing (R4) buhon.
@
1. Check the battery connection on remote controller or replace with new battery.
2. Check the battery connection inside CRAWLER CRANE battery compartment
or recharge battery.
3. Repeat matching procedure by switching remote and CRAWLER CRANE
on again. Press the matching button.
4. Contact us at our Email: [email protected]
q
1. operation t€mperature 5oC-38oC
2. Recharge battery ONLY with charger
included in packing.
" The products can be used on the sand or mud, but do not put sand from the top of the products

ItrB?N
HOBBY ENGINE C€t6 E FE
