Holtkamp DUO XXL User manual

Operating instruction
DUO XXL
Coin and chip card system
Remote maintenance via internet

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 2 -
Important: For safe and proper use, read the instructions for use and further product-related documents carefully and keep
it for later use!
For errors, technical errors, printing errors and incompleteness, we assume no liability.

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 3 -
Südstraße 40 / D-49084 Osnabrück
[e-mail] /
www.holtkamp.de
Telefon: [phone], Fax: [phone]
Geschäftsführung: Magnus Michael, Uwe Staudinger; Sitz der Gesellschaft: Osnabrück, AG Osnabrück HRB 213567
Banken: Deutsche Bank Osnabrück, IBAN: DE28 2657 0090 0039 5251 00; SW IFT/BIC: DEUTDE3B265
Die Lieferung erfolgt zu unseren Allgemeinen Geschäftsbedingungen mit Stand Juni 2011 nach ZVEI unter Einbeziehung der Softwareklausel
zur Überlassung von Standard-Software als Teil von Lieferungen mit Stand April 2012 nach ZVEI.
Zusätzlich gelten unsere Vertragsbedingungen „Hardware/Schaltplan/Layout“ und „Auftragsfertigung“.
Es gelten unsere Einkaufsbedingungen mit Stand Januar 2018.
EU-Konformitätserklärung / European Union conformity explanation
Für das nachfolgend bezeichnete Erzeugnis / For the following designated product
Zeitsteuerung vom Typ / Time control type
DUO XXL
mit Notaus-Timer (110%)-Funktion / with emergency stop timer (110%) function
wird hiermit bestätigt, dass die Bauart, in der von uns in Verkehr gebrachten Ausführung, den unten genannten Normen
entspricht.
It is hereby confirmed, that the construction in that execution brought by us in traffic corresponds to the standards specified
down.
Diese Erklärung gilt für alle Geräte, die nach den beiliegenden technischen Unterlagen, welche Bestandteile dieser Erklärung
sind, hergestellt werden.
This explanation applies to all devices, after the enclosed technical documents, which are components of this explanation,
are manufactured.
Einschlägige EG-Richtlinien / Relevant EC guidelines
RoHS-Richtlinie 2011/65/EU / RoHS Directive 2011/65 / EU
1. 2006/95/EG (Niederspannungsrichtlinie)
2006/95/EG (low-voltage guideline)
geändert durch
changed through
2014/35/EU
2. 2004/108/EG (EMV-Richtlinie)
2004/108/EG (EMV guideline)
geändert durch
changed through
2014/30/EU
Angewendete harmonisierte Normen:
Applied one harmonized standards:
EN 60335-1 von 01/12 (Sicherheit)
EN 60335-1 from 01/12 (security)
EN 55022 von 12/11 (Emissionen)
EN 55022 from 12/11 (emissions)
EN 61000-3, Teil 2 + 3 von (03/2015 und 03/2014) (Emissionen)
EN 61000-3, part 2 + 3 from (03/2015 and 03/2014) (emissions)
EN 61000-6, Teil 1 + 2 von (10/2007 und 03/2006) (Immunität)
EN 61000-6, part 1 + 2 from (10/2007 and 03/2006) (immunity)
Diese Erklärung ist bindend für den Hersteller
This declaration is binding on the manufacturer
Manfred Holtkamp Elektronik GmbH
Südstraße 40 in 49084 Osnabrück
abgegeben durch:
Signature:
M. Hashemizadeh (EMV-Beauftragter)
..........................................
Osnabrück, den 05.09.2018

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 4 -
Content
1 Legal information......................................................................................................................................................................... 6
2 Warranty ................................................................................................................................................................................ 6
3 Safety notices ............................................................................................................................................................................. 6
4 Devicespecicdata .................................................................................................................................................................... 6
5 General data ................................................................................................................................................................................ 7
6 Illustrations ................................................................................................................................................................................ 7
6.1 Illustration of the device...................................................................................................................................................... 7
6.2 Illustration of electronic / Position of the connectors and switches on the PCB ................................................................. 8
7 Installation ................................................................................................................................................................................ 9
7.1 Installation notes.................................................................................................................................................................9
7.2 Mounting instruction ...........................................................................................................................................................9
7.3 Electrical connection.........................................................................................................................................................10
8 Deployment options .................................................................................................................................................................. 12
9 The chip card types ................................................................................................................................................................... 12
10 Special features ......................................................................................................................................................................... 12
11 Equipment feature ..................................................................................................................................................................... 13
11.1 DIP switches..................................................................................................................................................................... 13
11.2 Jumper..............................................................................................................................................................................13
12 Menu settings ....................................................................................................................................................................... 14
12.1 Menu call ..........................................................................................................................................................................14
12.1.1 Menu call via DIP-switch............................................................................................................................................. 14
12.1.2 Menu call via Holtkamp service card ......................................................................................................................... 14
12.1.3 Menu call via password entry via touch screen (jumper 1 is plugged in) ................................................................... 14
12.1.4 Sequence of the password entry .............................................................................................................................. 15
12.2 General information menu control .................................................................................................................................... 15
12.2.1 Copy and paste........................................................................................................................................................... 16
12.2.2 Turn pages, leave menu ............................................................................................................................................. 17
13 Statistic menu ........................................................................................................................................................................... 17
13.1 Sub menu Statistic............................................................................................................................................................17
13.2 Statistic menu daily counter „Sale“................................................................................................................................... 18
13.3 Statistic menu daily counter „Card revaluation“................................................................................................................ 19
 13.4 Statisticmenudailycounter„di󰀨erent” ............................................................................................................................19
13.5 Statistic menu daily counter „Sales“ ................................................................................................................................. 20
13.6 Statistic menu total counter „Card revaluation“ ................................................................................................................ 21
 13.7 Statisicmenutotalcounter„di󰀨erent“..............................................................................................................................21
13.8 Statistic menu „Service counter“.......................................................................................................................................21
14 Information menu ...................................................................................................................................................................... 22
14.1 Information menu XXL...................................................................................................................................................... 23
14.2 Information menu chip card.............................................................................................................................................. 23
14.4 Information menu internal modules .................................................................................................................................. 24
14.4 Information menu external modules ................................................................................................................................. 24
15 Menu Times and Prices ............................................................................................................................................................ 25
15.1 Sub menu Times and Price menu ................................................................................................................................... 25
15.1.1 Times and Prices „Times“ ........................................................................................................................................... 25
15.2 Menu points „Times and Prices“....................................................................................................................................... 26
15.2.1 Times and Prices „Prices“........................................................................................................................................... 27
16 Menu Clock and Shifting times ................................................................................................................................................ 28
16.1 Sub menu Clock and shifting times .................................................................................................................................. 28
16.1.1 Menu Clock and shifting time „Time and Date“........................................................................................................... 29
16.1.2 Menu Clock and Shifting times „Shifting times“ .......................................................................................................... 29
17 Menu chip card editing and revalue......................................................................................................................................... 31
17.1 General menu points for service chip card type 73 ......................................................................................................... 31
17.2 Chip card editing via service chip card type 73 ................................................................................................................ 31
17.3 Chip card revaluating via service card type 73 ................................................................................................................ 31
17.4 Chip card revalue via cash insertion.................................................................................................................................32

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 5 -
18 CongurationMenu................................................................................................................................................................... 33
 18.1 Submenu"Conguration" ...............................................................................................................................................33
  18.1.1Conguration„Language+Currency“ ........................................................................................................................ 33
  18.1.2Conguration„Display+Sound”................................................................................................................................ 34
  18.1.3Conguration„Div.operatingparameters“.................................................................................................................. 36
  18.1.4Conguration„Payment“............................................................................................................................................. 40
  18.1.5Conguration„Tanningmanagement“ ........................................................................................................................ 42
  18.1.6Conguration„Objectdata“......................................................................................................................................... 45
  18.1.7Conguration„Counterstatistic“ ................................................................................................................................. 47
  18.1.8Conguration„Serviceintervals“................................................................................................................................. 48
  18.1.9Conguration„Coinvalidator“ ..................................................................................................................................... 49
  18.1.10Conguration„DataInterfaces“ ................................................................................................................................. 51
19 Operating of the XXL ................................................................................................................................................................. 52
19.1 Time purchase.................................................................................................................................................................. 52
19.1.1 Time purchase via chip card ...................................................................................................................................... 52
19.1.2 Time purchase by coin insert ..................................................................................................................................... 53
19.1.3 Buy more time............................................................................................................................................................. 54
19.1.4 Time sequence ........................................................................................................................................................... 55
19.1.5 Multi-Timer .................................................................................................................................................................. 56
19.2 Card editing and revaluating.............................................................................................................................................57
19.2.1 Card editing with service chip card type 73 ................................................................................................................ 57
19.2.2 Chip card revaluating with service chip card type Typ 73........................................................................................... 58
19.2.3 Chip card revaluating via coin insertion ...................................................................................................................... 59
19.3 Check device version, date and time ...............................................................................................................................59
21 FAQ – Frequently asked questions.......................................................................................................................................... 60
20 Reset to factory settings........................................................................................................................................................... 60
22 Error functions .......................................................................................................................................................................... 61
22.1 Code of error messages................................................................................................................................................... 62
Index ..............................................................................................................................................................................66

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 6 -
1 Legal information
All rights reserved. No part of this manual may not be repro-
duced or copied in any form without permission of Holtkamp
Elektronik GmbH. The rights for contained software in control
and memory blocks are exclusively from the manufacturer.
The reading and copying of the program content is strictly pro-
hibited. The Holtkamp Elektronik GmbH is not liable to the
purchaser of this product or third parties for damages, los-
ses, costs or expenses caused by the buyer or any third party
due to accident, misuse or unauthorized alterations, repairs or
improvements.
The Holtkamp Elektronik GmbH shall remain liable for any loss,
costs, disruptions or consequential damages that result from the
use of the control.
The technical data are up to date. Misprints, errors and modi-
cationsexcepted.Oldermanualsarenolongervalidwiththe
publication of this manual.
ATTENTION:
The installation must be performed by authorized
personnel! Therefore, make sure that the installati-
on is carried out by an electronics specialist! Sin-
cethisisastationarydevicewithmain-sidexed
connection, a circuit breaker must be installed on
the installation side!
4 Device specicdata
After switching on the electricity on the display appears for
approx. 2 seconds: Holtkamp XXL X.x, below in the second
row: T-Timer. This is information about the used software version
(XX.x)aswellastheoperatingtypeoftheDUO(T-Timer).
These details are subject of the advanced development of the
DUOandyourorder.Forfurtherquestionsandordersthesede-
tails will constitute an advantage. Please note all the abbrevia-
tionsappearingonthedisplay,denitely,foranyothertechnical
requests, in the following list.
2 Warranty
Onthefunctionofthedeviceisgrantedforaperiodof12months.
The warranty is limited solely to technical defects of the unit, it
can´tbeacceptedfurtherclaims.Furtherapplyourgeneral
terms and conditions, stand of June 2011, for products and
services of the electrical industry (ZVEI) - also see website: www.
holtkamp.de.
Any liability extinguished by the manipulation of the device.
3 Safety notices
The coin/chip card boxes are built according to the prior art and
the recognized safety rules.
Nevertheless, its use threats to life and limb of the user or third
parties, or cause damage to the device or other equipment
during use. Use the device only in perfect condition, and in-
tended, safety and the risk of danger, in compliance with the
instruction manual! Do immediately eliminate particular dis-
orders,whichmaya󰀨ectsafety!Alwayskeeptheoperating
instructions directly to the coin box! Note, in addition to the
user guide, the generally applicable legal and other man-
datory
regulations relevant to accident prevention and environmental
protection!
Performno changesand/ormodications tothecoin/chip card
box without approval of the manufacturer! Spare parts must meet
therequirementsspeciedbythemanufacturer.Thisisguaran-
teed only for original spare parts. Do observe the in the user
manualspeciedorprescribeddeadlinesforrecurringmain-
tenance intervals! Do provide for the safe and environmen-
tally
friendly disposal of plastic parts and electronic replacement
parts! The manufacturer is not liable for damage caused by
improper use. The user bears the risk. Intended use also inclu-
des compliance with the operating instructions and compliance
with the inspection and maintenance conditions.


Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 7 -
Casing material galvanised steel plate 2mm
Casing color powder coated white RAL 9016
Dimensions h 300 mm x w 218 mm x d 141 mm
Power supply 230 V or 24 V, 50 / 60 Hz
Switched power 6,3 A by cos phi = 1
Power absorption 10 VA
Cable entrance von hinten (3 Bohrungen)
Temperature range 0°C - 50° C
Protection class I bei 230V~ bzw. III bei 24V~
Protection type IP 20
FusecircuitboardSI1 100mA T
FusemainrelaySI2 6,3A MT
Fuserun-outrelaySI3 6,3A MT
Attention: Fuses may only be replaced with the same value!
5 General data
We reserve the right to technical changes in the production and
technical developments
6 Illustrations
6.1 Illustration of the device
1 3,5“ Touch screen
2 Casing
3 Card slot
4 Coin slot
5 Coin reject button
6 Coin return
7 Coin removel
8 Lock
9 Coin bag
10 Fuseplate
11 Holes for 13
12 Securing bolts
13 Securing for the casing
14 Cable entrances
15 Earth terminals
16 SB frame
17 Securing holes
18 Rear wall
1
3
4
5
6
7
8
9
10
11
12
13
14
14
15
13
16
14
13
18 14 2

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 8 -
6.2 Illustration of electronic / Position of the connectors and switches on the PCB
All required connections and switches are located on the power circuit board:
1 2 3 4 5 6 7
8
9
10
11
12
131414151617
1 Card ejection magnet
2 MDB
3 Erase button / blockade
4 DIP switches
5 Remote start/cleaning button
6 Time stop/Door opener
7 RS485 to the PC
8 Expansion board
9 Coin validator (Parallel-EMP)
10 Skin measurment head
11 SD card
12 Bypass switch
13 Overruntimerelayexit
14 2 connections for main and overrun time relay, if
potential-free
15 Main relay exit
16 Fineassurance100mAT(if230V)
17 Power connections
18 Jumper
19 Chip card
Connections and functions in brackets are optional. See further
descriptions of the individual components and connections in the
following chapters!
Changes and errors excepted!
17
2
2
18
19

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 9 -
7 Installation
7.1 Installation notes
Through high quality micro-electronics is the device able to
reachahighstandardofreliabilityinthedailyuse.Only
if the installation has been professionally carried out can the
device be guaranteed. Please consider during the installation...
● Only authorized and qualied electricians carry out the
installation complying with the valid VDE–regulations.
● By the timers with 230 V~ supply voltage is denitely
the protection cable required, by the timers 24 V~ (safety
extra-low voltage) protecting grounding is needed as func-
tion earth
●Thattheoorcoveringisanti-staticandconductorcapable,
to ensure a minimum of static change and so reducing the
danger to the electronics.
●A malfunction or breakdown of the device can be caused
by the switching sparks of the relay contacts. To reduce
these sparks appropriate suppression combinations
must be included parallel to the protection contacts.
 RC combinations for sparks reducing are only a󰀨ective
by direct parallel switching of the relay contacts.
●That the screened control and data cable are laid sepa-
 ratelyfrommainscables.ThescreeningoftheDUOXXL
electronic must be one - side and laid on PE.
●That the feed line are used, which is from a big cross section
 to supply both the DUO XXL and the attached electric
consumer. It should be used an cross section from
1,5mm² at the minimum.

●This device may only be mounted on a suitable surface.
● Thedevicemustbesu󰀩cientlysecured,takeintoconsi-
deration the weight of the inserted coins. There are 6 holes
in the back of the casing to accomplish the mounting pro-
cess. Screws and dowels are included by delivery.
●The device must be mounted horizontally and vertically to
 guaranteeaawlessfunctionofthecoinreceiver.Thatme-
ans the angle of the device can only be maximum 2 º, slo-
ping forward or backward, as well as to the right or the
left.
● Theinputcablesarexedbythreedrilledholesintherear
wall. The device is corresponding to protection type IP 20
an may only be used in dry rooms. Choose a cable cross
section of the feed line adequate big. Attend thereby the
connected electrical load. Attend to the VDE guidelines.
7.2 Mounting instruction
Switch o󰀨 the power supply by switching over the
correspondingdisconnectororswitcho󰀨thefuseor
even by tripping the RCCB.
●Unlock and remove the coin box.
●Loosen the two screws of the fuse plate, remove the fuse
plate and raise the casing so that it is possible to pull out
theelectricalconnectors. Pullouttheelectricalplugconnec-
tions and remove the casing completely.
●The wall plate horizontal and vertically align with the help
of a level.
The tilt angle can only be 2° now mark the drilled
holes.
Drilltheholesandinsertsuitabledowels.Throughtheholes"13”
(see image of the device) on the rear wall connect up the elec-
tricity. With the appropriate screws secure the casing tightly.
Now reinstall the electrical connections. Place the casing on
thexingbolts“12”.Asacountermeasureplacethefuseplate,
throughtheopeningoftheremovedcoinbox,onthexingbolts
“11”andtightenwiththesuppliedscrews


Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 10 -
Control cable and remote start connection have
to be kept away from each other.
The electrical connection has to be carried out by the local
VDE regulations. With a permanent connection, an all pole
mains separator with at least 3 mm contact gap must be used.
Before starting the electric the corresponding circuit must be
disconnected. Shut down the mains input by activating the
separator switch, remove the fuse or release the main safety
fuse. Mains and low voltage cable must be spaced apart. Low
voltage cables should be generally spaced as screened cables.
7.3 Electrical connection
The electrical connection can only be carried out
byauthorizedandqualiedpersonnel!
Outside of o󰀩ce hours, the XXL should be swit-
chedo󰀨 to preservetheimage qualityofthedis-
play for as long as possible (minimize age-related
reduction of contrast and brightness)!


DUO XXL DUO XXL
Fuseoverrun Fuse main r.
violet brown
protective conductor green-yellow
blue black
Remote
start
Fuseoverrun Fuse main r.
violet brown
protective conductor green-yellow
blue black
Remote
start
Connection 230 V~ Connection 24 V~

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 11 -
Connection 230V
After complete installation of XXL you can take it into operation
by switching on the circuit. As soon as the circuit is activated,
appears in the display an information about the operation mode
ofyouDUOXXLandabouttheusedsoftware.TheDUOXXL
is now ready for operation and can now be programmed as you
like. To ensure, that the programming has been correct, you
should make a detailed test run. After this test run all counters
should be deleted to receive a correct account.
Remote start (potential free)
Please make sure that your adjusted main time is appropriated
to the tanning bed. Do not choose the main time too long, becau-
se of the danger of the sun bed customer. Use the adjustment
setting, to limit the maximum time and therefore limiting the ma-
ximum account of buyable main time to reduce to a minimum the
danger to the customer.
Outletwire Overrunrelay(violet) Outletwire main relay (brown)
Main relay
230 VAC
Lead shielding
to a PE jam!
ForDUOXXLversion„Sun“applies:
March 2003 110% disconnection
After norm EN 60335-2-27/A11 (VDE 0700 part 27)
Beginning with 01 may 2003 all our XL devices
are equipped with the disconnection recommen-
ded by the upper mentioned directions.
EN60335-2-27
ThePCBofDUOisprovidedwitha110%-disconnection.Itme-
ans, that an emergency stop timer is controlled by a third relay
onthePCB.Itguaranteestheswitchingo󰀨ofthesunbed,ifthe
mainrelayisnotswitchingo󰀨once,aftertheexpiredtime.


Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 12 -
10 Special features
●daytime switching of prices and peak time via integrated
clock
● FullllingoftheEU-standard60335/2/27(radiationprotec-
tion) while running with tanning beds:
 o 110%safetyswitcho󰀨preventstoolongtanningtime
while technical defect
o skin surveying via integrated skin measuring head
  “DHKM”(specialequipment),oranalysisoftheSkin
ControlorDerma-MED3Controlrecommendedtanning
time (special equipment)
o Tanning series manage: realization of a tanning plan in
cooperation with the customer chip cards.
● FulllingoftheDINEN60335-1standard,chapter“R1pro
 grammableelectriccircuit,usingthesoftware”:
o Hardware- and Software-Watchdogs
 o Oscillator-timingmonitoring(permanent)
 o RAM-andROM-verication(whenswitchingandcycli-
cally at midnight)
9 The chip card types
Forissuetothecustomerasameansofpaymentandforpro-
gramming the standard and special functions there are various
chip card types. Below you can see a tabular list and explanation
of the existing chip card types.
Chip card type
PIN-Card
Function
P11 re-valuation chip card for the customer
P14 re-valuation test chip card for the service technician (second operating)
P15 re-valuation test chip card for the service technician (second operating)
P33 Chip card for querying the statistics and delete daily counters (for owner/personnel)
P43 Chip card for querying and delete the statistic exclusive for the operator (only for owner)
P53 menu programming chip card exclusive for the operator (only for owner)
P63 clock programming chip card exclusive for the operator (only for owner)
P73 Chip card for the activation of the re-valuation function (for owner/personnel)
P83 Congurationcardfromsoftware8.7(selectthecustomercongurationmenus/onlyforowner)
8 Deployment options
The XXL device is used for billing of timed objects (tanning beds,
washingmachines, Whirlpools, Tennis court lighting a.o.). Espe-
cially for the control of tanning beds it has software-supported
optionsforUVdosageandahardwareover110%safetyshut-
down, to prevent a too long tanning time in the case of a techni-
cal defect.
TheDUOXXLareavailablein2di󰀨erentversionsfor2applica-
tions:
1. DUOXXLSingle-Timer(Sun): 
e. g. connection of one tanning bed per device
2. DUOXXLMulti-Timer(Sun): 
e. g. connection up to 8 tanning beds per device
3. DUOXXLSingle-Timer(Washing):
e. g. connection of one washing machine per device
4. DUOXXLMulti-Timer(Washing):
e. g. connection up to 8 washing machines per device

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 13 -
11 Equipment feature
11.1 DIP switches
The DIP-switches are only accessible after opening the
house!
Certain programmings and releases can be made with the DIP
switches (closer information to that at chapter 15 „Menu set-
tings”).ThefunctionoftheDIPswitches1,2and4canbealter-
natively activated via service cards, so the houses does not have
to be opened.
Attention: Only for authorized expert personell!
The device is in dangerous voltage!
1 2 3 4
8 x 10 mm component with 4 little switches
(see chapter 7.2). Condition at delivery: DIP
3switchedon,therestswitcho󰀨
DIP switch 1: Calls up the operator-menu, with delete- and
setting right for statistics, and with settings rights
in all other menus.
DIP switch 2: Releases the initialization of all settings of all
menus and also of the H-numbers of the chip
cards via service cards Typ 20...22.
This initialization is usually carried out by the de-
vice manufacturer! It only has to be repeated if
the XXL device has been to be moved to ano-
ther place.
DIP switch 3: Gives up the possibility to change the values of
the menu with the service cards Typ 43 and Typ
    (alsojumper1a).(T4183FREE)This switch is
    normallyalwayson.Byswitchingo󰀨,youcan
lock lost or stolen cards.
DIP switch 4: Releases the reset on factory data. See identi-
cally named chapter!
11.2 Jumper
The jumpers are accessible after opening the house.
Attention: Only for authorized expert personell!
The device is in dangerous voltage!
The jumpers 1a, 1b and 1c are easily accessible at the XXL-Po-
wer PCB.
Therewithcanbedi󰀨erentfunctionsactivated:
3- times pole strip for jumper (see chapter 7.2).
Jumper 1a: Menu call with password (instead of service cards)
Jumper 1b: unused
Jumper 1c: unused
The rarely needed Jumper 2a, 2b and 2c are on the smaller XXL-
main PCB. Therewith you can activate rare functions:
3- times pole strip for jumper
2c 2b 2a


Jumper 2a: unused
Jumper 2b: large5,7”-display(insteadofasmall3,5”-Display)
only reconnect when the operating voltage is
   switchedo󰀨.
Jumper 2c: unused

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 14 -
12 Menu settings
12.1 Menu call
The menu can be called via the 3 following ways:
12.1.1 Menu call via DIP-switch
Seechapter“DIPswitch”and“Jumper”:
●With DIP switch 1, the operator menu can be called without
any further requirements.
●The menu call is just activated with the service card, when
jumper 1 is not plugged in and DIP-switch is not on. (Lost
service chip cards can be barred with the DIP switch)
●The menu call with password is only activated when jumper
1a is plugged in.
Depending on type of service card or password and
dependingoncongurationappeardi󰀨erentnumber
of buttons on the screen.

12.1.2 Menu call via Holtkamp service card
Service card type 33
●calls up the basic menu-overview with the right to delete
statistics
Service card type 43
●calls up the basic menu-overview with the right to delete
statistics:
o Button „Statistics“ invokes the above shown statistics
submenu.
o Button „Info“ rcalls up the information menu.
Service card type 53
●calls up the operator menu selection with all buttons
o Delete and setting rights at „Statistics“
o Setting rights at all other menus
12.1.3 Menu call via password entry via touch screen
(jumper 1 is plugged in)
●Bottom left in the corner of the screen there is an invisible
button.Thisonemustbeheldfor2seconds,tocallupthepass-
word entry.
Touch here!
It appears the menu password entry:

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 15 -
12.1.4 Sequence of the password entry
●Use the keyboard which is shown on the screen.
●Note uppercase and lowercase!
●Switching to the lowercase letter occurs with the button
„abc”etc.
● Afterthecompleteinputofthepassword,conrmwiththe
green „OK“
● The password can be changed in conguration menu.
It is recommended to enter individual passwords!
See chapter „Conguration/Various operating parame-
ters“.
●If 2 passwords are the same, the higher access right is
awarded.
● Forgottenpasswordscanberesettotheirinitialvalues,see
chapter „Reset to factory data”!
12.2 General information menu control
In the following the setting of the menu will be described by an
example.
Openthemenu„Service intervals”overthemenupoint„Congu-
ration”accordingtooneoftheabovedescribedoptions.
Touchforexample,theeldService interval 1.
This activates it.
Thecursorashesintheyelloweldandtheshownaccountcan
be changed with the Plus and Minus button.

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 16 -
By touching the green OK button the cursor moves to the next
digit which can be changed with the Minus and Plus button.
12.2.1 Copy and paste
If service interval 2 should have the same account like service
interval 1 you have to copy the numeric value.
TouchtheeldServiceinterval 1.
It will be activated.
If you hold the green button OK for a second the change will be
conrmed.
Press the yellow button Copy.
A new window will be opened.
Press the button copy. The window will close.

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 17 -
Touch the button Service interval 2 to activate it.
Press again the yellow button copy, the window will open again.
Press the button paste.The copy window will be closed.
The account has now been inserted into the Service interval 2.
If desired, you can change the value with the buttons Plus, Mi-
nus and OK.
Finallyyoupressthegreen button for a second so that the ch-
anges are saved.
12.2.2 Turn pages, leave menu
With the orange arrow keys you can change between the single
menu pages.
More menu items will be available.
The submenu will be left by pressing the red arrow key.
Themenuwillbeleftbyswitchingo󰀨theDIPswitchorremoving
the service card.
When it was called by password, it can be left with the red button
at the bottom left of the screen. It also stops itself when no button
is pressed for a certain amount of time.
13 Statistic menu
Calling up the menu:
See chapter „Calling up the menu”or„General information about
menu control”
13.1 Sub menu Statistic
The shown buttons are inuenced by the settings of the sub-
menu:
● Conguration/Various operating parameters/Operating
mode
● Conguration/Tanningmanagement
● Conguration/Countersstatistic
● Conguration/Chipcardedit/Revaluatingfunctioncard
● Conguration/Serviceinterval
In this menu, collected data can be viewed and, if necessary,
deletedorsettoadenedstartingvalue:
●The day counters can be deleted depending on the type of
card and the menu settings.
●The total counters are optionally erasable and optionally
adjustable (specify when order).
●The service hour counters are always erasable and
adjustable.

Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 18 -
13.2 Daily counter „Sale“
This intermediate menu will only appear in the mode of „Multi-Ti-
mer“.
If the button „Daily counter (Sale)“ will be pressed, this interme-
diate menu may appear.
Here you can choose for which timer/cabin which counter is valid.
The object numbers is to be regarded as an example.
(See „Conguration/Various operating parameters“)
The daily counters are used for daily reading and deleting by the
sta󰀨.
The represented menu items and their access op-
tions are dened in the sub menu „Conguration/
Service interval“.
Possible counters:
These counters sum up the money transactions made with vari-
ous optional funds („Cards“ = Holtkamp chip card type 11, „Cas-
hless“ = Creditcards a.o.). Also overpaid amounts, for which no
main time was awarded, are counted
These counters count the number of customers who have
bought time with the various means of payment. („Cards“ = Holt-
kamp chip card type 11, „Cashless“ = Creditcards a.o.). They
only count once per main time session (do not count on buying
additional main time).
Operatinghourscounting(durationthemainrelaywasswitchon).
Sales made with the test chip cards type 14 and 15 are
not counted. The operating hours are counting!
All counters will go to „0” after reaching their maximum
valueandstartcountingagain(moneycounter„9999,99”;
operatingtime„9999:59hours”,customercounter„9999”)



Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 19 -
13.3 Daily counter „Card revaluation“
The daily counter should be read or deleted daily by the perso-
nell.
The represented menu points and their access items
aredenedinthesubmenu„Conguration/Chipcard
edit/ Revalue“.
These counters sum up the amounts which were revalued by the
personell via chip card type 73 on chip cards type 11:
●the revalued money amount (amount paid by the custo-
mer)
●the additional revalued amount of money
●the amount of money deleted from the cards
●the amount of revalued and/or deleted cards
These counters sum up the amounts which were revalued by the
customers via coin insert (coin validator) on chip cards type 11:
●the revalued money amount (amount paid by the custo-
mer)
●the additional revalued bonus amount
●the numbers of the revalued cards
Sales with the test chip cards type 14 and 15 are not coun-
ted.
All counters will go to „0” after reaching their maximum
valueandstartcountingagain(moneycounter„9999,99”;
cardscounter„9999”).
13.4 Daily counter „di󰀨erent”
The daily counter should be read or deleted daily by the perso-
nell.
The represented menu points and their access items
aredenedinthesubmenu„Conguration/Tanning
management/Revalue“andalso„Conguration/Chip
card edit/Revalue“.
Possible counters:
Counter for the amount of skin measuring procedures performed
with integrated skin measuring head (one procedure consists of
3 single measurements).
The skin measuring head is an optional accessory, see same
named chapter. There is also described the cleaning which has
to be conduct routinely!
Counter for the amount of changes of the tanning counter (these
can be changed with the revalued card type 73).
 All counters will go to „0” after reaching their maximum
 value(„9999”)andstartcountingagain.





Holtkamp Electronics DUO XXL techn.stand 01.2018 4022_01.2018/V05.2020
- 20 -
13.5 Daily counter „Sales“
Submenu(onlyatmode„Multi-Timer”)
If you use the button “Total counter (sales)”occursthissubmenu.
Here you choose for which timer/cabin the following counters
valid are.
The object numbers are seen as examples (see „Conguration/
Various operating parameters”).
The total counters should be read routinely by the operator.
The shown menu points and their access options are
inthesubmenus„Conguration/Countersstatistic“
and"Conguration/Serviceinterval“.
Possible daily counters:
These counters sum up the turnovers which are made with dif-
ferent optional currencies. Also overpaid amounts, for which no
main time was awarded are counted


These counters are counting die amount of customers who
boughttime withdi󰀨erentcurrencies („Cards“=Holtkamp chip
card type 11). They count the main time just once (repurchases
are not counted).
Operatinghourscounter(durationthatthemainrelaywasturn
on).
Sales with the test chip cards type 14 and 15 are not
counted (amounts of money and customer).
But the operating hour counter counts!
All counters will go to „0” after reaching their maximum
value and start counting again.
(money counter „9999,99”; operating time „9999:59
hours”,customercounter„9999”)
