Holux Tracker-007 User manual

GPS Tracking System
Tracker-007
User’s Manual

Table of Contents
Introduction 1
Application 1
Parts names and Functions........................................................................................................................... 2
LED Indication ............................................................................................................................................... 3
Package Contents ......................................................................................................................................... 4
Before You Getting Started 5
Possible Additional Fee................................................................................................................................. 5
About GP ..................................................................................................................................................... 5
About Power .................................................................................................................................................. 5
For XP P3 Users ......................................................................................................................................... 5
About IM PIN Code & GPR ...................................................................................................................... 6
Notice: 6
Installing SIM Card and Battery 7
ezSpot Service 9
User Utility (TrackerConfig) 10
Installing Device Driver for Virtual Comm Port............................................................................................ 10
Parameter etting and Retrieval ................................................................................................................. 12
Read Device information ............................................................................................................................. 13
Change Password and Reset Password..................................................................................................... 13
Report Phone Number etting .................................................................................................................... 14
Message Type etting................................................................................................................................. 15
APN etting................................................................................................................................................. 15
Phone Number etting ................................................................................................................................ 16
Continuous Tracking ................................................................................................................................... 16
IM PIN ....................................................................................................................................................... 17
EPO etting................................................................................................................................................. 18
Basic Operation 19
Turn on Tracker ........................................................................................................................................... 19
Turn off Tracker ........................................................................................................................................... 19
Position Request ......................................................................................................................................... 19
Position Lock (Park) .................................................................................................................................... 20
Emergency Report ( O ) ........................................................................................................................... 20
Terminology 22
Appendix A Specifications 23

Physical Characteristics .............................................................................................................................. 23
ystem......................................................................................................................................................... 23
GPR Protocol ............................................................................................................................................ 23
G M Antenna .............................................................................................................................................. 23
Certification.................................................................................................................................................. 23
G M module................................................................................................................................................ 23
GP ............................................................................................................................................................. 23
Power Consumption .................................................................................................................................... 24

Holux Tracker-007
- 1 -
Introduction
Tracker-007 is a multi-functional tracker. Combining with GPR and high performance
GP , the device can be used to track and report device’s position and status to mobile
phone through M or Main Data erver (MD ) through HTTP. The operation modes
include continuous tracking and position lock (park). O buttons can be used to send
emergency call. All configurations can be set through M or U B interface. The wireless
communication includes UDP, TCP/IP, HTTP and M . With MTK EPO, it can get shorter
TTFF at distressed environment.
Application

Holux Tracker-007
- 2 -
Parts names and Functions
Power ignal (Amber) & tatus
ignal (Green)
GP tatus (Blue LED)
Park Key
U B Connector
O , Press two
keys together.

Holux Tracker-007
- 3 -
LED Indication
Item LED LED icon /color Status Indication
1 Power
Amber
Blinks every 4
seconds
Battery is low
2
Amber
Glows steadily Battery is recharging
3
Green
Glows steadily Battery is full
4
Green
Blinks every 4
seconds
Device is functioning
normally
5
Green
Blink every 0.5
second
Device is powering off
when battery is normal
6
Amber
Blink every 0.5
second
Device is powering off
when battery is low
7
Green
Blink 2 times every 2
seconds
GPR connection fails
or IM card is invalid
when power is normal.
8
Amber
Blink 2 times every 2
seconds
GPR connection fails
or IM card is invalid
when power is low.
9 GP
Blue
Blinks every 2
seconds
Acquisition in process
10
Blue
Blinks every 4
seconds
Acquisition fails
11
Blue
Turns off Acquisition succeed and
position is fixed
12 tatus
Amber
Blinks 6 times in 3
seconds. All LED
turn off.
O mode is activated
13
Green
Blinks every 2
seconds
Park mode is activated
14
Amber
Blinks every 2
seconds
Park mode and battery
is low

Holux Tracker-007
- 4 -
Package Contents
Thank you for purchasing the Tracker-007 wireless GP logger. Before you start, make
sure that the following items are included in your package. If any of these items are missing,
please contact your original local HOLUX dealer or distributor.
Tracker-007 Device 1 set
Power adapter 1 set
Car Charger 1 set
U B Cable 1 set
Tool CD 1 pcs
Quick Guide 1 pcs
Warranty Card 1 pcs
Battery 1 pcs
crew and cap 4 pcs

Holux Tracker-007
- 5 -
Before You Getting Started
Possible Additional Fee
• Position request and position response sent by M will be charged.
• Each zoom operation will be charged also according to data quantity transferred.
About GPS
• GP signals are incapable of penetrating solid objects that are non-transparent.
The signals will be also be affected by surface cover such as tall buildings, tunnels,
elevated expressways, forests etc., or weather conditions such as overcast and
rain. If the vehicle is poorly insulated against heat and contains metal parts, GP
signals will not be able to penetrate.
• All wireless communication devices such as cell phones, or traffic police speed
detectors can interfere with the reception of GP signals and results in unstable
signals.
• To get position fix successfully, please hold the GP logo or function key up for
better signal orientation.
• There is no guaranty that O message will be successfully sent at distressed
environment where GP or G M signals are weak.
About Power
• Though this device is U B compliant and can be bus powered, it is NOT
recommended to charge the device though your computer via U B connection.
The manufacturer disclaims any liabilities for damage to the handset or personal
PC caused by any improper use.
• It takes 5 ~ 120 seconds for the device to be completely powered off. If the device
is in the process of acquiring position fix or position report, the power-offing will not
be performed until the previous process is complete.
• Tracker-007 cannot be powered on if battery voltage is below 3.5 volts.
For XP SP3 Users
• Due to the incompatibility problem between Windows XP P3 and the virtual
Comm port of Windows driver, usbser sys for XP P2 is required for XP P3
users to install the utility. For more information, please refer to FAQ at
http://www.holux.com

Holux Tracker-007
- 6 -
About SIM PIN Code & GPRS
Notice: IM PIN should be unlocked before being inserted into the device. IM PIN can be
disabled through ordinary mobile phone.
• IM card GPR function enabled is required for normal operation.
• The default PIN code in device is 0000. If IM lock is enabled and password is
incorrect, power on/off device three times will make the IM card locked
permanently. Only PUK code can unlock the IM in such case. If IM PIN is
enabled, make sure the PIN code is set to device by TrackerConfig. The PIN code
set will be saved in non-volatile memory.
• If the IM card is not inserted or IM card is invalid, position fix function will be
disabled.
• Google map installed in your cell phone will be downloaded by GPR
automatically when ez pot is well installed.
Download documents, Driver and Utility
All related documents, driver and utility programs can be downloaded from the ez pot
server at http://ezspot.holux.com/Holux.

Holux Tracker-007
- 7 -
Installing SIM Card and Battery
Tracker-007 without IM card, battery and bottom cover
 lide the IM card into IM socket and lock the IM socket.
 Install the included battery into Tracker-007 as the arrow sign shown; see below.

Holux Tracker-007
- 8 -
 Restore the bottom cover.
 The final assembly of Tracker-007. ecure the case by fasting the screws and
inserting cap for water proof.
 Make sure that battery is fully charged before using this device.

Holux Tracker-007
- 9 -
ezSpot Service
 ezSpot Service is a multi-functional Holux tracker system which includes ez pot in
mobile phone and ez pot server at internet. ez pot can work with Tracker-005 and
Tracker-007 from Holux. The compatibility will be guaranteed for Holux products in
the future. There are three position report operation modes in tracker: ez pot,
ez pot server or both. In ez pot mode, user can change settings in and request
real-time position from Tracker through mobile phone. For ez pot server mode,
tracker will report position to server through HTTP. For third operation mode, tracker
will report position to both ez pot and ez pot server. The operation mode can be set
by PC utility program TrackerConfig through U B connection.
 ezSpot server provides log history for user to view through web browser. Please
access more service from http://ezspot.holux.com/Holux/. Updated driver and utility
programs can be downloaded from ez pot server also. Please register with email
and IMEI to get access of the server and its services.
 For more information please refer to “Holux_ez pot_User_Manual”

Holux Tracker-007
- 10 -
User Utility (TrackerConfig)
Note: Power on Tracker-007 before plugging in U B cable and connecting with
TrackerConfig. Configurations can be set or read correctly only after system initialization
being complete.
The Tracker-007 enable users the communication with mobile phone through M as
default. Through this utility program, Tracker-007 can be configured to communicate with
ez pot server through HTTP. Continuous tracking mode can be enabled to make device
getting position fix and report to server at preset interval. The APN and server domain
name can be set for internet connection. The IM PIN can be enabled or disabled. IM PIN
code can be changed by the utility also. The program can run only for Windows O . No
support for Linux or Mac O .
Installing Device Driver for Virtual Comm Port
Plug in 5-pin mini-U B cable. When connecting the device first time, O will request to
install the virtual COMM port driver.
Please choose Win2XMcom.inf for Windows XP ( P2 and earlier version) and
Win2XMcom_Vista.inf for Windows Vista.

Holux Tracker-007
- 11 -
A new MODEM device in device manager will appear after installation. Check Comm port
number from Modem page.

Holux Tracker-007
- 12 -
Parameter Setting and Retrieval
Press “Connect” button. After program connecting to the device, it will show a “Next”
message in new Diagnostic page and the button name will be changed to “Close”.

Holux Tracker-007
- 13 -
If IM card is not detected or is locked, “Ready” will not be shown on message frame.
Read Device information
Check “Read” button will get all information in device.
Change Password and Reset Password
Press “ et” button in password group to change password.
Execute “Reset Password” button will reset password to default “12345”. This function can

Holux Tracker-007
- 14 -
be used when password is forgotten.
Report Phone Number Setting
There are 4 phone numbers that can be set. Device will respond position request if caller
phone number is in the list.

Holux Tracker-007
- 15 -
Message Type Setting
The function can be used to set parameter for report target. Tracker-007 can report position
to ez pot in mobile phone or ez pot server
[ezSpot]: Tracker-007 will send position to ez pot through M .
[ezSpot Server]: Tracker-007 will send position to ez pot server (or MD ) through HTTP.
[both]: Tracker-007 will send position to ez pot through M and ez pot server through
HTTP.
APN Setting
This item is to get and set MD server setting.
[APN]: This indicates Access Point Name
[APN User Name]: This indicates the user name for APN.
[APN Password]: This indicates the user password for APN.
[APN DNS]: This indicates the APN domain name server.
[MDS Server IP]: MD (or ez pot server) IP or domain name. Default is
“ezspot.holux.com”. The parameters will be set automatically by selecting Country and
Telecom. Default will be “internet”. Manual input changes are allowable if necessary.
1
2
3.

Holux Tracker-007
- 16 -
Phone Number Setting
[Number]: Number (M I DN) is the phone number of IM card in Tracker-007.
Continuous Tracking
[Continuous tracking setting]
In continuous tracking mode, Tracker-007 will report position to ez pot server at the preset
interval.
1
2.
1
2
