Holux UB-93 SPECIFICATION V0.4 User manual

GPS Engine Board
UB-93
SPECIFICATION
1F, No. 30, R&D Rd. II, HsinChu City 300, Science-based Industrial Park, Taiwan
(300) 新竹市科學園區研發二路 30 號1樓
TEL: [phone] FAX: [phone]
Website: www.holux.com
Version : 0.4
All Right Reserved

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
2
Version Change History
Version Date Revised Reason
0.1 2009/04/02 Draft release

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
3
Index
1. Introduction.............................................................................................4
1.1 General introductions..............................................................................4
1.2 Key Features.............................................................................................4
1.3 Applications..............................................................................................4
2Technical Description.............................................................................5
2.1 Block Diagram..........................................................................................5
2.2 Configuration ..................................................... 錯誤! 尚未定義書籤。
2.3 Pin Definition............................................................................................5
2.4 Specification..............................................................................................7
3. Mechanical Dimension ..............................................................................8
3.1 Mechanical Dimension.............................................................................8
4. Package ......................................................................................................9
4.1 Packing.......................................................................................................9
4.2 Reference Product Photo........................................................................10
5. User Interface........................................................................................10
5.1 NMEA Protocol.......................................................................................10
5.2 NMEA Protocol format .........................................................................10
5.3 MTK NMEA Packet Format..................................................................11
6. Reference design..................................................................................12
6.1 Reference circuit .....................................................................................12
6.2 Reference PCB pattern...........................................................................12
6.3 Recommendation reflow profile ...........................................................13

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
4
1. Introduction
1.1 General introductions
UB-93 is an ultra miniature 17 * 22.4 * 3 mm GPS engine board designed by low
power consumption MTK GPS solution. It provides superior sensitivity up to
-159dBm and fast Time-To-First-Fix in navigation application. The stable
performance of UB-93 is your best choice to be embedded in your portable device
design, like PDA、PND、mobile phone、Digital Camera for GPS service.
1.2 Key Features
‧ small form factor:17* 22.4 * 3 mm
‧ RoHS/WEEE compliant
‧ High sensitivity -159dBm
‧ Searching up to 32 Channel of satellites
‧ Fast Position Fix
‧ Low power consumption
‧ RTCM-in ready.
‧ Built-in WAAS/EGNOS/MSAS Demodulator.
‧ Support NMEA0183 V 3.01 data protocol.
‧ Real time navigation for location based services.
‧ For Car Navigation, Marine Navigation, Fleet Management, AVL and
Location-Based Services,Auto Pilot, Personal Navigation or touring devices,
Tracking devices/systems and Mapping devices application
1.3 Applications
‧ Automotive and Marine Navigation
‧ Automotive Navigator Tracking
‧ Emergency Locator
‧ Geographic Surveying
‧ Personal Positioning
‧ Sporting and Recreation
‧ Embedded applications:
‧ Smart phone, UMPC, PND, MP4

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
5
2Technical Description
2.1 Block Diagram
2.2 Pin Definition

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
6
Pin Pin Name Type Function description
1 TX1 O Serial Data Output
2 RX1 I Serial Data Input
3 TX0 O Serial Data Output
4 RX0 I Serial Data Input
5 NC NC NC
6 VCC_IN_3V3 I 3.3 ~ 5 VDC Power Input
7 GND G Ground
8 NC NC NC
9 NC NC NC
10 RESET I System Reset,Active Low
11 V_BAT_3V3 I RTC and backup SRAM ,Power Input: 3.3~ 5 VDC
12 NC NC NC
13 GND G Ground
14 GND G Ground
15 GND G Ground
16 GPS_RF_IN I GPS signal input(DC:2.85V output)
17 GND G Ground
18 VCC_RF O Output Voltage RF section
19 V_ANT I Antenna Biavoltage
20 NC NC NC
21 NC NC NC
22 NC NC NC
23 NC NC NC
24 NC NC NC
25 NC NC NC
26 NC NC NC
27 NC NC NC
28 1PPS O 1 PPS output

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
7
2.3 Specification
General
GPS technology MTK GPS chipset MT3318
Frequency L1,1575.42MHZ
C/A Code 1.023MHZ chip rate
Channels 32 channels all in view searching
Sensitivity Better than -159dBm
ReceiverAccuracy (Follow MTK chip specification)
Position Without aid:3.0 M 2D-RMS
DGPS(WAAS, EGNOS, MSAS, RTCM):2.5 M
Velocity Without aid:0.1 M/sec
Time 0.1μs. Sync GPS time
Datum
Datum WGS84(Default) total 219 datum’s
Time to First Fix (Follow MTK chip specification)
Hot start 1 sec. average
Warm start 33 sec. average
Cold start 36 sec. average
Reacquisition ＜1sec.
Protocol
GPS Output Data
NMEA0183(V3.01)- GGA,GLL,GSA,GSV,RMC,VTG
Support Baud rate 4800/9600/…./115200 bps (default 4800),
Data bit:8 , Stop bit:1, No parity.
Update Rata 1Hz(default)
Protocol Support NMEA-0183
1PPS Enable(1Hz pulse 10% duty cycle)
Limitations (Follow MTK chip specification)
Acceleration Limit ＜4G
Altitude Limit ＜18000 meters
Velocity Limit ＜515 M/sec
Jerk Limit 20 M/sec3
Power
Operation Current Acquisition:≒60 [email protected]
Operation Current Tracking:≒＜45m[email protected]

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
8
DC Input Range VCC_IN: 3.3~5.0V
V_RTC:3.3~5.0V
Processing Core
Processor Type ARM7EJ-S
Processor Speeds 48 MHz
Interface CMOS 2.85 V Level
Temperature
Operating Temperature -40 to +85 .
Storage Temperature -40 to +125 .
Operating Humidity 5% to 95%, Non condensing
Physical
Dimension 17 * 22.4 * 3 mm.
Weight <1g.
3. Mechanical Dimension
3.1 Mechanical Dimension
(Unit : mm)

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
9
4. Package
4.1 Packing

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
10
4.2 Reference Product Photo
The photo is for reference, the real content will depend on the real configuration.
Top side :
Bottom side : (The PCB version depend)
5. User Interface
UB-93 provides 2-wire digital UART port for communication of GPS position data
using NMEA protocol or MTK extension protocol. UART port is capable of 4800 to
115200 baud rate.
5.1 NMEA Protocol
UB-93 is default to support standard NMEA-0183 protocol. In addition, a series of
MTK extensions (PMTK messages) have been developed that can be used to provide
extended capabilities common to many applications.
NMEA Protocol format
UB-93 is capable of supporting following NMEA formats:
NMEA RECORD Description
GGA GPS fix data

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
11
GLL Geographic
GSA GNSS DOP and active satellite
GSV GNSS Satellites in view
RMC Recommended minimum specific GNSS data
VTG Course Over Ground and Ground Speed
ZDA Time & Data
5.3 MTK NMEA Packet Format
Preamble TalkerID PktType Datafield * CHK1 CHK2 CR LF
Maximum packet length is restricted to 255 bytes
Field Length Type D
Preamble 1 byte Character
“$＂
TalkerID 4 byte Character string “PMTK＂
PktType 3 byte Character string “000＂to “999＂, an identifier used to tell the decoder how to
decode the packet
DataField Variable “, ＂must be inserted ahead each data filed to help the decoder
process the Data Field
* 1 byte Character
The star symbol is used to mark
the end of Data Field
CHK1
CHK2 2 byte Character string checksum of the data between
Preamble “, ＂and “*＂
CR, LF 2 byte Binary data used to identify the end of a
packet

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
12
6. Reference design
6.1 Reference circuit
Fig 1 is UB-93 uses patch Antenna connects to RS-232 transceiver solutions
intended for portable or hand-held applications.
Fig1
6.2 Reference PCB pattern

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
13
6.3 Recommendation reflow profile
1. We strongly recommend that this module should be designed to mount on top
side of motherboard with main chip together which process the final reflow.
2. The maximum frequency of this module to pass reflow process should be no

UB-93
GPS Module series THE PRO NAME IN GPS
HOLUX Technology, Inc.
1F, No.30, R&D Road, Hsinchu 300, Taiwan (Hsinchu Science Industrial Park)
TEL: [phone] FAX:[phone] E-mail:[e-mail] http:www.holux.com.tw
14
more than twice, including repair operation, otherwise it may cause side
effect to the performance.
3. Below is the recommend reflow profile referred to Main MTK chipSet.
