Home Accents Holiday TGC0P5402C02 User manual

Christmas Tree
Model: TGC0P5402C02
Sku # 691 620
b. Do not use seasonal products outdoors unless marked
suitable for indoor and outdoor use.When products are
used in outdoor applications, connect the product to a
Ground Fault Circuit Interrupting (GFCI) outlet. If one is
not provided, contact a qualified electrician for proper
installation.
c. This seasonal product is not intended for permanent
installation or use.
d. Do not mount or place the product near gas or electric
heaters, fireplaces, candles, or other similar sources of
heat.
e. Do not secure the wiring of the product with staples or
nails, or place on sharp hooks or nails.
f. Do not let lamps rest on the supply cord or on any wire.
g. Unplug the product when leaving the house, when
retiring for the night, or if left unattended.
h.This is an electric product and not a toy! To avoid risk of
fire, burns, personal injury and electric shock it should
not be played with or placed where small children can
reach it.
i. Do not use this product for other than its intended use.
j. Do not hang ornaments or other objects from cord, wire,
or light string.
k. Do not close doors or windows on the product or exten-
sions cords as this may damage the wire insulation.
l. Do not cover the product with cloth, paper, or any mate-
rial that is not a part of the product when in use.
m.This product has a polarized plug (one blade is wider
than the other) as a feature to reduce the risk of electric
shock.This plug will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician.
Do not use with an extension cord unless plug can be
fully inserted. Do not alter or replace the plug.
n.This product is equipped with push-in type lamps. Do
not twist lamps.
o.This product employs overload protection (fuse). A
blown fuse indicates an overload or short-circuit situa-
tion. If the fuse blows, unplug the product from the
outlet. Also unplug any additional strings or products
that may be attached to the product. Replace the fuse as
per the user servicing instructions (follow product
marking for proper fuse rating) and check the product.
p .Read and follow all instructions that are on the prod uct
or provide with the product.
q. SAVE THESE INSTRUCTIONS
Package Contents
Pre-Assembly
Part Description Quantity
F Tree stand 1
A Tree top, tag 5 1
B Tree center 1, tag 4 1
C Tree center 2, tag 3 1
D Tree center 3, tag 2 1
E Tree bottom, tag 1 1
Assembling the tree stand
Assembly
Step 1. Pull apart the legs of the stand so that they are
snapped into an x-shape, place the tree stand on a
level surface.
Step 2.When inserting the bottom section of the tree into
the assembled stand, insert and turn the eyebolts
into the stand and tighten until the tree pole is
firmly secured.
Step 3.To close the stand, remove the eyebolts, press the
metal button and fold the legs together.
This tree assmebles with Quick Set® technology
---Set up and light up your tree in less than 10
minutes!
Step 1. Remove the protective caps from the tree bottom
and insert the pole into the tree stand.
Step 2. Continue by inserting the upper tree section(s) to
the lower section(s) until inserting the tree top.
Step 3. Shape the branches to your preference by working
from the bottom to the top. When adjusting
branches, ensure that all wires are free of branch
hinges.
Step 4. Insert the green label extension cord plug into the
wall outlet. All your lights should now be lit.
Step 5. When finished shaping the branches, slightly
upsweep all branch tips for a uniform look.
Assembling the tree
Safety Information
IMPORTANT SAFETY
INSTRUCTIONS
a. READ AND FOLLOW ALL
SAFETY INSTRUCTIONS.
When using electrical products, basic precautions should
always be followed, including the following:
Eye Bolt
Click
Eye Bolt

Operation
Turning on the tree
Maintenance
Spare parts
Repairing Loose Hinges
Troubleshooting
Problem Solution
The tree does
not light
Ensure that all tree sections are
plugged into each other and that
the tree is plugged into the wall.
If your tree came with a foot pedal,
step on the On/Off button.
Check for blown fuses at the light
string and power cord plugs.
Replace as needed with the
replacement fuses provided.
Check for loose, broken, or missing
bulbs and replace as needed with
the replacement bulbs provided
NOTE: If some bulbs do not light or flicker, search for any
loose plugs and/or broken, loose, or missing bulbs.
Replace bulbs promptly with the replacement bulbs
provided in order to maintain the performance and life
expectancy of your tree.
Step 1. Connect the light strings of the tree together and
plug the power cord into a wall outlet.
Step 2. If the tree comes with a foot pedal, step on the
On/Off button.
This tree package includes hinge pins, washers, bulbs, and
fuses for any replacement or repair that you need to
perform on your tree. If extra parts are needed, contact the
Customer Service Team at 1-877-527-0313 between the
hours of 8 am and 5 pm EST, Monday through Friday.
Use and Care Instructions
1. Before using or reusing, inspect product carefully.
Discard any products that have cut, damaged or frayed
wire insulation or cords, cracks in the lampholders or
enclosures, loose connections, or exposed copper wire.
2. Before disassembling the tree, unplug the tree and
remove all ornaments and decorations.
3. Gently lift the tree top straight up to remove from the
center section and fold all branches towards the pole.
4. Repeat this step for the center and bottom tree sections.
5.When storing the product, carefully remove the
product from wherever it is placed, including tree,
branches, or bushes, to avoid any
undue strain or stress on the product
conductors, connections, and wires.
Cover the protective cap on the
poles to avoid damaging the internal
parts.
6.When not in use, store neatly in a cool, dry location
protected from sunlight.
Step 1. Place the branch into the slot of the bracket
Step 2. Insert a new hinge pin through the holes of the
bracket and secure with a washer.
Christmas Tree
Model: TGC0P5402C02
Sku # 691 620
a) Grasp plug and remove from the receptacle or other
outlet device. Do not unplug by pulling on cord.
b)Open fuse cover. Slide open fuse access cover on top
of attachment plug towards blades.
c) Remove fuse carefully.
d)Risk of fire. Replace fuse
only with 7 Amp, 125 Volt
fuse for the power cord set.
e)Close fuse cover. Slide closed
the fuse access cover on
top of attachment plug.
f) Risk of fire.Do not replace attachment plug. Contains
a safety device (fuse) that should not be removed.
Discard product if the attachment plug is damaged.
SPARE FUSE
User servicing instructions
Fuse replacement
Section 5
Section 4
Section 3
Section 2
Section 1
Insert
Green Label
Plug Into Wall
Outlet
Foot Pedal
on/off Switch
S100
S100
S100
S100
S50
S100
S100
S50
S100
S100
S50
S100
S50
Do Not Tamper
Internal Parts
Open the
protective
cover
Do Not Tamper
Internal Parts
Open the
protective
cover
