homelabs Nugget User manual

Nugget
Ice Maker
Thank you for purchasing our appliance.
Please be sure to read the entirety of
this user manual carefully prior to using
this appliance. If you have any questions
regarding the use of this product,
please contact Customer Service
at homelabs.com/help
or [e-mail].
SKU: HME010694N
Compact and
Portable

Table of Contents
Important Safety Instructions .................. 5
Parts Overview ............................................. 6
Operation ...................................................... 7
Cleaning and Maintenance....................... 11
Specifications.............................................. 11
Daily Cleaning ............................................12
Monthly Cleaning .......................................13
Troubleshooting......................................... 14
Warranty.......................................................15
Manufacturing Information ......................15
Warning.........................................................15
Contact Us ...................................................15
Before First Use
To prevent any internal damage, it is very important to
keep the unit upright throughout its journey. Please leave it standing
upright and outside the box for 24 HOURS before plugging it in.
In the event this product malfunctions, or you believe it is
defective, please contact Customer Service at homelabs.com/help
or [email protected] and hold onto the defective product
(pending further instruction). A defective product should
be clearly marked or stored where it cannot be used by mistake.
Failure to keep the product in its original quality from the time of
receipt may impede hOmeLabs’s ability to correct any legitimate
problem and may limit the extent to which hOmeLabs
may provide recourse.
Before First Use
We recommend running the cleaning
program (See > Page 8) prior to
making ice for the first time.

4 5
Don’t forget to register your product at homelabs.com/reg
for updates, coupons, and other relevant information.
Although greatly appreciated, product registration
is not required to activate any warranty.
on bringing home your new appliance!
Congratulations
When using electrical appliances, basic safety precautions should be followed to reduce the
risk of fire, electrical shock, and injury to persons or property. Read all instructions before
using this appliance.
• Do not use appliance for anything other than its intended use.
• Do not operate this or any other appliance with a damaged cord.
Leave a space of at least 6 inches around the appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer
or a similarly qualified person in order to avoid potential safety hazards.
• This appliance has to be positioned so that the plug is accessible after installation
or assembly.
• Connect to properly grounded outlets only. No other appliance should be plugged
into the same outlet. Be sure that the plug is fully inserted into the receptacle.
• Do not run the Power Cord over carpeting or other heat insulators. Do not cover
the cord. Keep the cord away from high traffic areas. Do not submerge in water.
• We do not recommend the use of an extension cord as it may overheat and become
a fire hazard. If you have to use an extension cord, use No. 14 AWG minimum size
and rated no less than 1875 Watts.
• Unplug the appliance before any cleaning, repairing or servicing. Always grasp the
power plug to remove it from the wall outlet. Do not pull on the power cord itself.
• Exercise caution and provide supervision when this appliance is used in the
presence of children.
• Do not use the appliance outdoors. Place the appliance away from direct sunlight.
• Only use water to make ice.
• Do not clean the appliance with flammable fluids. The fumes can create
a fire hazard or cause an explosion.
• Do not let this appliance tip over.
• If the appliance is brought inside from the cold, please let it warm to
room temperature before plugging it in.
• To avoid hazards due to instability, the appliance must be placed on a flat surface. This
appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance.
WARNING
• This appliance should be properly grounded for your safety. The Power Cord of this
appliance is equipped with a grounding plug which mates with standard grounding
wall outlets to minimize the possibility of electrical shock.
• Improper use of the grounded plug can increase the risk of electrical shock.
If the Power Cord is damaged, please contact Customer Service.
• Plug your appliance into an exclusive, properly installed, grounding wall outlet.
Do not damage the grounding means of the plug under any circumstances. Any questions
concerning power and/or grounding should be directed toward a certified electrician.
• This appliance requires a standard 110–120 V, 60 Hz electrical outlet with good
grounding means.
  
SAVE THESE INSTRUCTIONS
For Household Use Only

6 7
Drainpipe
After cleaning, you
can collect dirty water
from the Drainpipe
(there are two pipes.
One connects to the
evaporator. The other
connects to the Water
Tank under the Drawer).
Metal Housing
Control Panel
Ice Drawer Handle
Transparent Window
View stored ice level
Water Drain Cap
Ice Drawer
Water Tank
Hot Air Outlet
Power Cord
Cooling Vents
Parts Overview
Drip Tray
Operation
PREPARING BEFORE USE
1. Remove the exterior and interior packaging and check if all the accessories are included.
If any part is missing, please contact Customer Service.
2. Clean the interior with warm water, diluted detergent, and a soft cloth.
See the “Cleaning and Maintenance” > Page 11.
3. Place your Ice Maker on a dry, flat, and sturdy surface. Leave a clearance
of 6 inches (15cm) on each side of the Ice Maker for proper ventilation.
4. Allow 24 hours for the refrigerant fluid to settle down before plugging in your Ice Maker.
5. Discard the first few batches of ice when using this appliance for the first time
or after an extended period of time.
6. The power plug must be easily accessible.
“WATER
SHORTAGE”
“ICE” “CLEAN” “LIGHT”
“POWER”
“ICE
F U L L”INDICATORS
BUTTONS
CONTROL PANEL
NOTE:
• The Ice Maker should be far from direct sunlight and other sources of
heat (e.g.: stove, furnace, or radiator).
• Some types of under-cabinet lamps can be hot enough to cause
damage to your appliance top’s appearance.

8 9
FILLING THE WATER TANK
The Water Tank is under the Ice Drawer.
1. Remove the Ice Drawer and pour 0.58 gallon (2.2 liters) potable water into the Water Tank.
Slide in the Ice Drawer.
2. Put the Drip Tray in position.
Operation
IMPORTANT NOTE:
• Use filtered water for better tasting ice and less scale buildup in the Ice Maker.
• For consistently clean and fresh ice, change the water in the tank every 24 hours.
Before storing or non-use for an extended period of time, drain the water from the
tank and wipe it dry.
• To avoid damage to this Ice Maker, fill the Water Tank with room temperature or
cooler water. Do not use hot or boiling water.
• Monitor the water level in the tank and replenish the water periodically. When the
Water Tank has insufficient water, the “Water Shortage” indicator will light up and
the unit enters standby mode. After replenishing water, touch the “ICE” button
twice to start the ice making. If you prefer, wait 15 minutes, the Ice Maker will
resume to work automatically.
Drinking
Water
HOW TO MAKE AND USE ICE
1. Before starting, check the Drainpipe behind the Ice Maker. Ensure the Water Drain Cap is
properly inserted into the Drainpipe.
2. Touch the “ICE” button. The “ICE” indicator will light up. After 5 seconds, the unit will
start flashing and begin making ice. If you touch the “ICE” button again, the unit will stop
making ice. You can check the ice quantity in the Ice Drawer through the Transparent
Window.
3. When the Ice Drawer is full, the “ICE FULL” indicator will light up and the unit will stop
making ice automatically.
4. While the Ice Maker is on, check the water level periodically. When the “WATER
SHORTAGE” indicator lights up, fill the Water Tank.
5. To Open the Ice Drawer: Hold the handle gently and pull it out horizontally until the back
of the Drawer contacts the front panel, then gently push it down. The Drawer will hang
at a slight angle.
6. To Close the Ice Drawer: Reverse the process. Hold the handle and place the Drawer
horizontally, then gently push it in place.
Operation
STARTING THE CLEANING PROGRAM
It is highly recommended to run the cleaning program before first use (or when the unit has
been unused for an extended period). This cleaning process will take about 20 minutes.
1. Plug in the Power Cord. The “POWER” indicator will light up.
2. Check the Drainpipe behind the unit. Ensure the Water Drain Cap is inserted into the
Drainpipe or the appliance will not work properly.
3. Touch the “CLEAN” button. “CLEAN” indicator will light up and flash after 5 seconds.
It will take at least 20 minutes to run the cleaning program. To stop the program, just
touch the “CLEAN” button again.
4. After the cleaning program is complete, move the unit to the edge of the surface while
making sure that the appliance is stable. Place a bowl or container under the appliance.
Release the Drainpipe from the back of the unit and pull out the plug from the Drainpipe.
This will cause the water in the tank under the Drawer and the evaporator to drain into
the water container. Reinsert the Drainpipe plug and replace the Drainpipe.

10 11
To Remove / Reload the Drawer: Hold the handle gently then pull the Drawer outwards
horizontally until the back of the Drawer contacts the front panel. Gently lift the Drawer
up at an angle (as shown) and pull it out. To reload the Drawer, reverse the steps. Tilt the
Drawer in the same direction at an angle (as shown). Put the back of the Drawer into the
unit’s front panel, slowly flatten the Drawer, then gently push it in place.
LIGHT ON/OFF
Touch the “LIGHT” button to illuminate the Ice Drawer interior. To turn off the light, touch
the “LIGHT” button again.
NOTE:
• Always use the scoop to remove the ice from the machine. Do not use your hands
to remove the ice to avoid contamination.
• To maintain a clean and sanitary unit, do not return ice into the Ice Maker once it
has been removed.
ATTENTION:
• Empty the Drawer and Water Tank before turning the unit off, otherwise the water
may overflow.
Operation
COMMON OPERATING NOISES
Your new Ice Maker may make unfamiliar sounds. Most of these sounds are normal. Hard
surfaces like the floor, walls, and countertops can amplify these sounds.
Here are the sounds you may hear and their potential source:
• WHIR – When the appliance is first turned on, you may notice the condenser
fan spinning.
• BUZZ – When the water pump first turns on, it may be dry and slightly noisy.
Once it is filled with water, the noise reduces significantly.
• RATTLE – Rattling noises may be produced from the flow of the refrigerant.
These noises should reduce significantly once the refrigerant system has stabilized.
• GURGLE – When the refrigerant system shuts off, there may be a brief gurgle
as the refrigerant stops flowing.
• HUM – The compressor is a motor. It produces a low hum when running.
• CLICK – As nugget ice is produced, it drops into the Ice Drawer. You will hear the
loudest sounds when the first nuggets impact with the empty ice bin. As the bin fills,
this noise reduces significantly.
Cleaning and Maintenance
To keep your ice tasting fresh and your Ice Maker looking great, clean your Ice Maker regularly.
Unplug the unit before cleaning or maintenance.
Ice Drawer
Remove the Ice Drawer. Clean the interior with diluted detergent, warm water,
and a soft cloth.
Ice Scoop
Clean regularly with warm, soapy water. Dry the scoop before use.
Exterior and Interior
Remove the Water Drain Cap on the back. Drain out any water in the Drainpipes.
Use room temperature water and mild detergent with a soft cloth to clean the interior
of the Ice Maker. Rinse with water. Run 3 cycles of ice with new water and discard the
ice each time.
Dry the interior and exterior with a soft cloth.
Cooling Fan
Regularly check the cooling fan for dirt or dust buildup. With the power OFF,
use a soft, dry brush to gently remove buildup from the outside of the fan cover.
Cooling Vents
Regularly check the Cooling Vents for dirt or dust buildup.
With the power OFF, use a soft, dry brush to gently remove buildup from the vents.
Collect Dirty Water
After clearing the Drainpipes, you can collect dirty water for other uses
(it is non-potable). (See visual in Parts Overview > Page 6)
1. Remove the Drain Cap from the Drainpipe on the back of the appliance.
2. To collect dirty water, empty the Water Tank under the Ice Drawer.
3. Reinsert the Drain Cap and then the Drainpipe.
4. Wash the Water Tank and reinsert it.
Storage Requirements
If the unit will remain unused for an extended period, dump any remaining ice, and drain all
the water from the Water Tank. Completely dry the Ice Drawer and Water Tank. Once dry,
reinsert them into the appliance.
Store the Ice Maker upright in a dry, well-ventilated location.
Specifications
• Vesicant: C₅H₁₀
• Voltage/Current: 115 V~ 60 Hz, 2.7 A
• Net Weight: 33.73 lb
• Dimensions: L 16.1 × W 9.8 × H 16.5 in
NOTE: Do not immerse Ice Maker.

12 13
1. Unplug the Nugget Ice Maker.
2. Take off the drain cap and drain out the
water to a sink. See the figure below.
3. Replace the drain cap. See the figure
below.
4. Mix cleaning solution by diluting one
teaspoon of household bleach with five
cups of water for daily cleaning.
5. Pour the solution into the water reservoir,
up to the “MAX” water level. See the figure
below.
6. Plug in the Nugget Ice Maker and press
the “Clean” button to initiate the cleaning
process (20 mins). See the figure below.
7. When the “cleaning” indicator lights turns
off, take off the drain cap and drain out
the water to a sink.
8. Repeat steps 5 through 7 with fresh water
for two more cycles to rinse the inside.
9. Replace the drain cap. See the figure
below.
10.When completed, fill the unit with fresh
water and press the “Ice” button to start
ice making process. See the figure below.
Monthly Cleaning
1. To remove mineral deposits, use white
vinegar instead of bleach-water solution
used for daily cleaning.
2. Fill the water reservoir halfway with
distilled white vinegar.
3. Plug in the Nugget Ice Maker and press
the “Clean” button to initiate the cleaning
process. Let the cleaning process run for
approximately five (5) minutes. After
5 minutes, unplug the appliance and leave
the white vinegar in the unit for over
12 hours.
4. After 12 h period take off the drain cap
and drain the vinegar in to a sink.
5. Repeat steps 5 through 7 with fresh water
for two more cycles to rinse the inside.
6. Replace the drain cap. See the figure
below.
7. When completed, fill the unit with fresh
water and press the “Ice” button to start
ice making process. See the figure below.
Replace
the drain
cap
Daily Cleaning
Take off
the drain
cap
Untie
the
rope
Remove
the drain
tubes
upward
Take off
the drain
cap
Take off
the drain
cap
Replace
the drain
cap
Replace
the drain
cap

14 15
PROBLEM POSSIBLE CAUSE SOLUTION
No ice cubes
inside
There is an obstruction
inside the appliance
Remove the obstruction inside,
orclean the interior surface of the
Drawer. Unplug the unit and restart it.
“LIGHT” and “ICE”
icons flashing
The ambient temperature
or water temperature in
the inner tank is too high
Run the Ice Maker below 90°F and pour
colder water into the tank.
Refrigerant liquid leakage Touch the “ICE” button twice to restart
the ice making program then wait for
50 minutes. If this problem reoccurs,
contact Customer Service.
Cover motor is broken
The cooling system pipe is
blocked
Slow ice
production
Hot Air Outlet has been
blocked
Hot Air Outlet must be guaranteed to
have more than 5.9 inches of clearance
for ventilation.
Water temperature in
inner tank is too high
Water temperature should be between
45–90°F.
Malfunctioning
refrigeration system
Contact Customer Service.
Water leakage Drain Cap is not in place Put the Drain Cap in place.
Loose pipe joint Contact Customer Service.
The seal has reached the
end of its service life
Contact Customer Service.
Mold Various causes If you notice mold or other residue
buildup on the Ice Maker, turn the unit
off then give it a thorough cleaning.
Use room temperature water and mild
detergent with a soft cloth to clean all
interior surfaces, rinse with water, then
run 3 cycles of ice making with new
water each time, discarding the ice.
Ideally, use a professional ice machine
descaler and sanitizing solution, while
following the manufacturer’s specific
instructions for use.
If the water, scoop, ice machine, and
immediate environment are kept clean
and hygienic, mold formation should be
avoided.
The water
indicator flashes
when the water
tank is filled
The Ice Maker is started
before being filled with
water
Touch the “ICE” button twice to restart
the appliance.
hOmeLabs offers a limited one-year warranty (“warranty period”) on all of our products
purchased new and unused from hOmeLabs, LLC or an authorized reseller, with an original
proof of purchase and where a defect has arisen, wholly or substantially, as a result of
faulty manufacturing, parts, or workmanship during the one-year warranty period. The
warranty does not apply where damage is caused by other factors, including, but without
limitation to: (a) normal wear and tear; (b) abuse, mishandling, accident, or failure to follow
operating instructions; (c) exposure to liquid or infiltration of foreign particles; (d) servicing or
modifications of the product other than by hOmeLabs; (e) commercial or non-household use.
The hOmeLabs warranty covers all costs related to restoring the proven defective product
through repair or replacement of any defective part and necessary labor so that it conforms
to its original specifications. A replacement product may be provided instead of repairing a
defective product. hOmeLabs’s exclusive obligation under this warranty is limited to such
repair or replacement.
A receipt indicating the purchase date is required for any claim, so please keep all
receipts in a safe place. We recommend that you register your product on our website:
homelabs.com/reg. Although greatly appreciated, the product registration is not required
to activate any warranty and product registration does not eliminate the need for the
original proof of purchase. The warranty becomes void if attempts at repair are made by
non-authorized third parties and/or if spare parts, other than those provided by hOmeLabs,
are used. You may also arrange for service after the warranty expires
at an additional cost.
These are our general terms for warranty service, but we always urge our customers to
reach out to us with any issue, regardless of warranty terms. If you have an issue with
a hOmeLabs product, please contact Customer Service at homelabs.com/help
or [e-mail].
This warranty gives you specific legal rights, and you may have other legal rights which vary
from state to state, province to province, or country to country. The customer may assert
any such rights at their sole discretion.
Manufacturing Information
This manual covers all items with these model numbers:
SKU: HME010694N
Rated Voltage/Frequency: 115V~ 60Hz
WarrantyTroubleshooting
HME010694N
Contact Us
[email protected]
EMAIL US
homelabs.com/help
CHAT WITH US
WARNING:
Keep all plastic bags away from children.

Distributed by hOmeLabs™, LLC
350 Springfield Avenue, Suite #200,
Summit, NJ 07901
[e-mail]
homelabs.com/help
All rights reserved, hOmeLabs™.
Made in China.
For Household Use Only
