Homelife CT2 24 UNI DL Technical specifications
Rev. 01 - 26/2018 LG
CT2 24 UNI DL 24V
F
CONTROL UNIT FOR TWO-LEAF GATES
INSTRUCTIONS AND WARNINGS FOR INSTALLATION, USE AND MAINTENANCE
GB
2
DANGER
Important Safety instructions.
It is important for the safety of persons to follow all instructions.
Save these instructions.
The drive shall be disconnected from its power source during cleaning, maintenance and while replacing parts.
Do not allow children to play with the appliance or its controls, including remotes.
Watch the moving door and keep people away until the door is completely opened or closed.
Take care when operating the manual release since an open door may fall rapidly because of the wind and
may cause harm to people or objects.
Frequently examine the installation, in particular check cables, springs and mounting for signs of wear, damage
or imbalance.
Do not use if repair or adjustment is needed since a fault in the installation or an incorrectly balanced door may
cause injury.
Each month check that security features are working correctly and efficent.
If necessary, adjust and re-check since an incorrect adjustment can present a hazard. If re-adjustment does not
Restore the correct operation, contact your authorized service center for assistance.
The automation must not be installed above 2000mt on sea level.
Insert , conforming to the installation regulations, a device that assures a complete disconnection of the power
source with a distance of opening contacts in the overvoltage III category.
If the power cable is damaged it must be replaced by the manifacturer or by it’s technical service or by a
qualified technician in order to prevent any risk.
WARNING
WARNING:
Automatic door -The door may operate unexpectedly, therefore do not allow
anything to stay in the path of the door.
WARNING:
Important safety instructions.
Follow all of the instructions , a wrongful installation may cause damage.
Apply permanently the warning lables against the the entrapment in a clearly
visible spot or near fixed command devices.
Apply permanently the manual unlock label near it’s control unit.
After the installation , make sure that the mechanism is regulated and that the rotation motor inverts its
movement if the door hits an object.
After the installation make sure that the gate structure doesn’t obstruct public roads or sidewalks.
After the installation make sure that the safety features work correctly.
This device can be used by kids older than 8 years of age , by people with disabilities,without experience
or necessary knowledge , as long as they are being accompanied or they recived instructions and they can
comprehend the dangers of the device .
Kids must not play with the device.
Cleaning and mantainance operations destined to be done by the user must not be done by unattended kids.
3
mm. 250
mm. 184
min cm 40
5
3
4
1
2
GEBOX ASSEMBLY INSTRUCTIONS
4
1
2
6
6 - 7
6 - 8
6 - 9
6 - 10
6 - 11
12 - 13
14 - 16
15 - 16
16 +
17 -
CONN-1 24Vac:
33 - 34
- / +
35 - 36 - / +
CONN-2
1 LINKS AND CONNECTIONS
1.1 Central Connections
Clamps
Description ( check electical scheme , page 5)
1
ANTENNA:
2Antenna cable imput.
6COMMON COMMANDS:
6 - 7
STOP: Imput N.C. Commands the gate’s halt.
To this can be connected to safety devices such as an emergency arrest button.
When released the command does not do an automatic arrest , it is instead necessary to give a new
movement command. Leave the bridge in place if no devices are installed.
6 - 8 OPEN: Imput N.O. Commands the opening of the gate.
6 - 9
CLOSE : Imput N.O. Commands the gate’s halt.
6 - 10
SETP-BY-STEP: Imput N.O. Command the gate’s actions following this commands :
SEMI-AUTOMATIC MODE : Open ,Stop,Close,Stop
FOUR STEPS MODE : Open,Pause,Close,Pause.
CONDOMINIUM MODE : Open (automatic closing with the active pause time).
6 - 11 PHOTO:
Imput N.C for photocells and safety devices . While the gate is opening doesn’t intervene ,
12 - 13 RELE’ CONTACT :
14 - 16 ELECTIC LOCK:
Exit 12Vdc for the connection with the electric lock at 12Vdc 15VA; in order to activate
15 - 16
Exit 24 Vdc 25W max to connect the blinker
16 +
17 -
N.C. = contact normally closed - N.O = contact normally open
The command determines the opening of only one side. Can be given by remote or clamps
When using the terminal block a bridge will be obtained and the clamp n°8 will be OPEN , the clamp n°9 will CLOSE
this bridge will be connected to a switch at clamp n°6 common. The command PEDESTRIAN from terminl block
won’t have the OPEN and CLOSE commands.
EXIT 30 Vdc : To power various devices, max 200mA.
CONN-1 24Vac:
Input transformer power
33 - 34 Engine 2, if closed opens second.
Engine 1, if closed opens first.
PHOTO1: With option 1 Led 4 , the imput becomes N.C. in order to connect the photocell that
acts while in the Closing and Opening phase.
Clean contact Relè Max 3A , default for the connection to an open gate LED
With the activation OPTION 2 Led 2 becomes a command for the courtesy light timed at 3 minutes.
- / +
35 - 36 - / +
- Before proceeding with the links and connections carefully read what is presented in the PRESCRIPTIONS AND
WARNINGS FOR SECURITY and PRESCRIPTIONS AND WARNINGS FOR THE INSTALLATION.
- All of the linking and connecting operations must be performed with the power source disconnected , if the device is not
visible a sign must be applied : “ WARNING UNDER MAINTENANCE ”.
Stocking antenna input , use RG58-50 Ohm cable.
ANTENNA:
For the imputs: STOP - OPEN - CLOSE - STEP BY STEP - PHOTO.
BLINKER:
PEDESTRIAN:
Connections bottom of the control unit
CONN-2 Connection battery charger AGECH-2
while closing it dertermines the inversion of the motion until the complete opening.
Leave the bridge open if no devices are installed.
select the function from the Options meù n°1 Led n°3
5
- -
-
START
16
17
16
16
14
15
F3 3.15A-T
F2 10A-T
12 Vdc 15 VA
Relè 3A
30 Vdc 200mA Max
N.O.
COM.
24 Vac
13 12
POWER
13 12
POWER
L7
L8
L9
L10
L11
AGECH2
F1 3.15A-T
CONN1
CONN2
230Vac
ELECTRICAL CONNECTION
ELECTRIC LOCK
FLASHING
INDICATOR LIGHT
DEFAULT
POWER
POWER
COURTESY LIGHT
OPTIONS N.2
Led 2 On
INDICATOR LIGHT N.6
COURTESY LIGHT N.7
FLASHING
ELECTRIC LOCK
L7
L8
L9
L10
L11
SIGNALS LED
The leds under the terminal block
show the entry state .
L7 and L11 are imputs N.C and must
be turned on , they turn o when
the corresponding imput is activated
L8-L9-L10 are imputs N.O. must be
turned o and they will automatically
turn on when the corresponding
imput is activated
6
OFF
230V
OFF
13
ON
ON
230V
2
OFF
230V
OFF
230V
OFF
12
ON
ON
230V
Energy Saving
12
12
In order to optimize electrical consumption
we introduced the ES function.
After 10’ from the central
programmation the Leds of the front
panel will turn o and the keyboardwill
be deactivated.
To re-activate the keyboard turn the
central unit o and on again
2.2 RUN PROGRAMMATION AND SHUTTERS OFFSET
will first turn on and then they will blink.
As soon as this process is done the two green Leds will start blinking , while the two red Leds will stay on
If the result is not satisfying it is possible to execute a manual programmation to define different
offsets.Refer to chapter n°7.
a) Position the shutters at a 45° angle.
b) Press the button for 5” , the 5 Leds
c) Press the gate will execute this sequence :
- Closing Shutter 2,
- Closing Shutte 1,
- Opening Shutter 1, with offset
- Opening Shutter 2,
- Closing Shutter 2, with offset
- Closing Shutter 1.
N.B. In case only one motor is being used connect it with the n°35 and n°36 clamps.
Make sure to fix the mechanical limit switches of opening and closing of the automation
When the programmation is done for 10 minutes the button can be used as a STEP command
N.B.
In order to totally reset the unit , before giving power, press and keep pushed the button, release
after the central unit.
2 CENTRAL UNIT PROGRAMMATION
2.1 TOTAL RESET
ATTENTION
START
START
START
START
7
12
12
12
3 REMOTE GESTION
The control unit is equipped with an integrated radio receiver with 750 code memory, on a frequency of
433.92 MHz with LIFE Rolling Code and Auto-Code coding
3.3 Deleting all of the remotes settings
3.1 REMOTE LEARNING
a) Press the button for 5” , the left green
led will turn on and then start blinking.
b) Push for 5” the button and the leds will blink
alternately
As soon as the Leds will stop blinking all
of the remotes settings will be deleted.
a) Press the button for 5” , the left green led
will firstly turn on and then will start blinking.
b) Keep on pressing the remote button until all of the
five Leds will light up the remote
setting will be deleted.
3.2 Removing an already existing remote setting
TOTAL OPENING
a) Press the button the left green Led and the
[A] Led will turn on.
b) Keep the button P1 of the radio control pressed until
all five LEDs light up
a) Press twice the button and the left green led
and the [B] Led will turn on
b) Hold down the P2 button of the radio control until
all five LEDs light up
SHTTER N°1 PEDESTRIAN OPENING
Wait for 20” or press the button again
to anticipate the exit from the programmation mode.
+
+
+
+
++
+
+
8
5 s
10 s
30 s
60 s
120 s
1
2
1
2
+
+
+
+
+
+
5”
+
+
+
+
+
+
4 REGOLATIONS AND OPTIONS
4.1 AUTOMATIC CLOSURE
An automatic closure is activated after a set PAUSE TIME.
4.2 AUTOMATIC CLOSURE
a) Press the button the green right Led turns on
- If none of the leds is turned on the
Wait 20” or press the button again
in order to anticipate the exit from programming mode.
automatic closure is not active , press the
button to activate it .
- If at least one of the leds is on
the automatic closure is activated, in order to
deactivate it press the button untill all of the
Leds are off.
By pressing and you can set the various
values for the PAUSE TIME
Work cycle:
OPEN - PAUSE - CLOSE - PAUSE
MINIMUM
4.3 ADJUSTMENT TIME OF DECELERATION
a) Press the for 5” the Led green and red on the
right will turn on:
ATTENTION:
The deceleration CAN’T be completely eliminated , in this phase the limit switch’s push force will determine
the Stop in the motor’s run.
By pressing and you can adjust the value
of he DECELERATION TIME
MAXIMUM
DEFAULT
LEDS ON
LEDS ON PAUSE TIME
DECELERATION TIME
CHIUSURA NON ATTIVA
+
+
+
+
+
Wait 20” or press the button again
in order to anticipate the exit from programming mode.
9
+
+
+
+
+
+
5”
2
+
+
+
+
+
+
80%
85%
95%
2
1
1
5 SPEED AND SENSIBILITY
5.1 ADJUSTING SPEED
Wait 20” or press the button again to anticipate the exit from the programming mode.
SENSITIVITY
MINIMUM
5.2 MOTOR SENSITIVITY ADJUSTMENT
a) Press the button for 5” the green and red
Led on the left will turn on.
MAXIMIUM
DEFAULT
LED ON SPEED
MINIMUM 75%
a) Press the button and left red led will turn on:
By pressing or the speed can be adjusted.
MAXIMUM 100%
DEFAULT 90%
LED ON
ATTENZIONE:
Based on the gate’s structure and on its usage parameters such as sensitivity and speed mus be setted
accordingly to the laws of the country.
+
By pressing or the sensitivity can be
adjusted .
+
Wait 20” or press the button again to anticipate the exit from the programming mode.
10
5”
+
+
+
+
+
+
+
+
+
+
+
+.............................................................................
6 OPTIONS MENU
6.1 OPTIONS 1
LED ON OPTIONS 1
Press the button in order to enter insde the OPTIONS MENU 1 , press in sequence the
buttonto advance in the selection , the blinking led will indicate the poeistion , with the button it will be
activated Red fixed Led , with the button it is deactivated.
No active function.
Condominium: Command Step Open only.
Mode: OPEN-STOP-CLOSE-STOP.
Electric lock activation.
The imput CLOSE becomes PHOTO1.
The activation of PHOTO anticipates the closure.
6.2 OPTIONS 2
LED ACCESI OPZIONI 2
Press the button for 5” in order to enter the OPTION MENU 2 , press in sequence the button
to advance in the selection the led blinking shows the position and with the button it is activated , fixed
red Led, with the button it deactivates .
Faster slowing-down speed.
The exit Relè 12-13 becomes a COURTESY LIGHT
Delay of safety interventions during movement.
Funcioning with PRESENT MAN.
.............................................................................
Wait for 20” or press the again to exit programming mode.
+
No active function.
Wait for 20” or press the again to exit programming mode.
+
11
1
2
2
1
12
12
12
12
1
2
2
1
7 MANUAL PROGRAMMING
Press for 5 seconds , the 5 leds will light up and then
start blinking.
Manual programming can be done with a button
connected to terminals 6 - 10 (Step-by-Step) or with
radio control previously memorized, page 7 cap.3.1.
Position the motors at 45 °.
7.1 CLOSING FINISHES LEARNING
During the flashing of the 5 LEDs give a command of
Step by step the leaf [2] must move first in closing,
when he arrives at the stop he has to stop and the Led of the
Right goes on with fixed red light.
Give a second Step-by-Step command the leaf [1] must
move in closing, when it comes in batting it must stop and
the Left LED lights up with a fixed red light.
Give a Step-by-Step command the leaf [1] opens, al
reaching the point where you want to open also
the leaf [2] give a further step-by-step command.
The two wings now proceed in opening until they reach the
respective mechanical stops, the two red LEDs of left and
right they remain in red light.
Give a Step-by-Step command the leaf [2] closes, al
reaching the point where you want to close also
the leaf [1] give a further step-by-step command.
The two doors proceed now in closing until they reach the
respective mechanical stops, the two red LEDs of left and
right they remain in red light.
7.3 LEARNING CLOSING OFFSET
7.2 LEARNING OFFSET AND FINISHES
The automation is now programmed in semi-automatic mode.
If the result obtained is not satisfactory, perform the
reset the control panel and restart from point 7.
START
Address: Via Sandro Pertini,3/5 31014 COLLE UMBERTO (TV) Italia
Telephone: + 39 0438 388592
Telefax: + 39 0438 388593
http www.homelife.it
