Homemaker KYT-12-YS-02 User manual

Evaporative Cooler
User Manual
Model No.: KYT-12-YS-02
Item No.: 900598
230 - 240Va.c. 50Hz 60W
Rev 3

Page 2 of 9
1Safety Instructions ............................................................................ 3
2Components ..................................................................................... 5
3Preparation ....................................................................................... 5
4Controls ............................................................................................ 6
4.1 To Turn On ................................................................................ 6
4.2 Speed ........................................................................................ 6
4.3 Auto Off Timer ........................................................................... 6
4.4 Cooler ........................................................................................ 7
4.5 Swing......................................................................................... 7
4.6 Variable Wind Speed ................................................................. 7
5Remote Control................................................................................. 7
6Care and Cleaning ............................................................................ 8
7Storage ............................................................................................. 8
8Warranty Against Defect ................................................................... 9

Page 3 of 9
1 Safety Instructions
When using electrical appliances, basic safety precautions should always be followed,
including the following:
• Carefully read this instruction manual before using appliance.
• Keep appliance out of reach of young children.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Ensure children and babies do not play with plastic bags or any packaging materials.
• Do Not disassemble the appliance. There are no user serviceable parts inside.
• VERY IMPORTANT:
Ensure that appliance does not get wet (water splashes etc.). Do not use appliance with
wet hands.
• Do not immerse appliance in water or other liquids or use near sinks, baths or showers.
• Always operate the appliance from a power source of the same voltage, frequency and
rating as indicated on the product identification plate.
• Position the power supply lead properly so that they will not be walked on or pinched by
items placed on or against them.
• Use appliance only for its intended use. Appliance is intended for household use only and
not for commercial or industrial use.
• Do not use appliance if it has been dropped or any part of appliance (including cord or plug)
has been damaged. Take appliance to your nearest authorised service centre or qualified
dealer for inspection or repair.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
• Use only accessories recommended or supplied by an authorised service centre or
qualified dealer. The use of accessories not intended for use with this appliance may cause
injuries to the user or damage to the appliance.
• Do not install the unit on other appliances, on uneven surfaces or where it could be subject
to: heat sources (e.g. radiators or stoves), direct sunlight, excessive dust or
mechanical vibrations.
• Appliance should not be used outdoors, placed near a hot gas or electrical burner or placed
in a heated oven.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus that produce heat.

Page 4 of 9
• Do not operate appliance underneath or near flammable or combustible materials
(e.g. curtains). Keep at least 300mm clearance around sides, back, front and top.
• Unplug this apparatus during lightning storms or when unused for long periods of time.
• Do not block any ventilation openings.
• Never put objects into the louver when the unit is working
• Turn off and unplug before cleaning or storing.
• Any type of servicing, apart from ordinary cleaning, must be carried out by an authorised
service centre or qualified dealer. There are no user serviceable parts in this appliance.
• If this appliance is used by a third party, please supply the instruction manual with it.
• Do not misuse the cord. Never carry the appliance by the cord or pull to disconnect it from
the outlet. Instead, grasp the plug and pull to disconnect.
• Do not insert or allow foreign objects to enter the grille openings as this may cause damage
to the appliance and/or injury to the user.
• Be sure the unit is placed on stable surface when operating.
• Turn off and unplug the unit before moving. Move the unit slowly and carefully. Never let
the water overflow.
• Do not use the unit in very hot or humid places, such as kitchens, bathrooms or under
direct sunlight.
• Turn off, unplug and empty the water from the unit if you are not going to use it for a long
time.
• No liability can be accepted for any damage caused by non-compliance with these
instructions or any other improper use or mishandling of appliance.
Additional Safety Instr uc t ions
If using an extension cord:
• The cord should be checked and tested by an authorised service centre or a qualified
dealer.
• The technical specifications of the extension cord must match or exceed the
technical specifications of this appliance.
• Do not allow the cord to hang over the edge of the work surface or to come into contact
with stoves or other hot surfaces.
• If the cord or plugs are worn or damaged, do not use.
• Unplug from the power socket by grasping the plug body - Do Not pull on the cord.
Read and Save These Instructions

Page 5 of 9
2 Components
3 Preparation
•When ready to use the cooler, make sure that the power switch is set to OFF
and the unit is disconnected from the power point.
•Ensure the rubber drain plug is fully inserted into the drain hole
(located underneath the appliance).
•Pour clean cold water into the water box through the opening in
the side of the cooler. Fill until the level has reached the Maximum
mark. Do Not Fill with any liquid other than clean cold water. Do
Not add any additives to the water.
•Located in the top rear of the appliance is an Ice Box. This can
be filled with ice blocks during use which will help cool the water.
As the ice melts, it can be topped up by pulling open the ice box
flap and refilling.
9
12
13
1
Control Panel
8
Handle
2
Left-Right Louver
9
Remote Control
3
Up-Down Louver
10
Mesh Filter
4
Front Body
11
Power Cord and Plug
5 Water Level Indicator 12 Ice Box Opening
6
Water Tank Opening
13
Drain Plug (underneath)
7
Castor Wheels

Page 6 of 9
4 Controls
4.1 To Turn On
•Insert the power plug into an outlet and switch on.
•Press the “ON/SPEED” button on the control panel. The unit will start in the
default “Medium” Speed as indicated by the light above “M”.
Note: Only the fan will be running at this time. Press the “OFF” button to turn
the appliance off.
4.2 Speed
•By default, when the unit is turned "ON", it starts at “Medium” speed.
•Each press of the “ON/SPEED” button advances the Speed setting as follows
and as indicted by the lights above the “ON/SPEED” button:
Default is “Med”, Press Once = "High", Press again = “Low + the 4th Indicator
Light”. This function is a Variable speed mode to give the effect of nature’s
varying wind speeds. Press again = "Low", press again = “Med”.
•Press the “OFF” button to turn the appliance off.
4.3 Auto Off Timer
•Use this power-saving feature if you want the appliance to turn off
automatically.
•To select the Off time, press the “TIMER” button once. It will advance to 0.5h
as indicated by the indicator lights above the “TIMER” button. Each
consecutive press will advance the timer at 0.5h increments until it reaches a
maximum time of 7.5h.
The time set will be indicated by the sum of the lights which are illuminated.
i.e. if the 0.5h + 2h + 4h lights are illuminated, this adds up to be 6.5 hours.
•Press the “OFF” button to turn the appliance off.

Page 7 of 9
+ facing Up
+ facing Down
4.4 Cooler
•Press the “COOLER” button if you want to have cooler wind blowing from the
air cooler.
This activates the cooling water mechanism inside the appliance causing the
air to be cooler.
The Indicator light above the button will be illuminated when this feature is
On.
•Press the “COOLER” button again to turn this function off.
•Press the “OFF” button to turn the appliance off.
4.5 Swing
•Press this button if you want to swing the vertical louver from left to right.
•Press it again to stop the left to right louver from swinging.
4.6 Variable Wind Speed
•Refer to the section “Speed”.
5 Remote Control
The Cooler comes with a remote control for your convenience.
To install the batteries remove the back battery cover.
Insert the batteries as shown and then refit the cover.
Battery Type: LR44 Button Cell

Page 8 of 9
6 Care and Cleaning
•Turn off and unplug the unit prior to cleaning.
•Clean the air cooler regularly especially the rear air inlet filter. Do not allow
this filter to become blocked.
This can be cleaned by using a vacuum cleaner hose with a brush
attachment. Ensure the mesh is dry before vacuuming.
Alternatively, use a soft damp cloth or rag and mild detergent for cleaning and
wipe dry.
•Never spray with liquids or submerge the unit in water or any other liquid.
•Do not use flammable liquids, chemicals, abrasive creams, steel wool or
scouring pads for cleaning.
7 Storage
•Switch off and unplug the unit.
•Coil the cable loosely. Do not kink or pull the cable tight.
•When storing away for the winter, drain all excess water from the unit by
removing the rubber drain plug from underneath the appliance.
When the tank is empty, replace the plug by pushing it all the way back in.
•When the appliance it totally dry, store in a dry well-ventilated area.
Read and Save These Instructions

Page 9 of 9
8 Warranty Against Defect
12 Month Warranty
Thank you for your purchase from Kmart.
Kmart Australia ltd warrants your new product to be free from defects in materials
and workmanship for the period stated above, from the date of purchase, provided
that the product is used in accordance with accompanying recommendations or
instructions where provided.
This warranty is in addition to your rights under the Australian Consumer Law.
Kmart will provide you with your choice of a refund, repair or exchange (where
possible) for this product if it becomes defective within the warranty period. Kmart
will bear the reasonable expense of claiming the warranty. This warranty will no
longer apply where the defect is a result of alteration, accident, misuse, abuse or
neglect.
Please retain your receipt as proof of purchase and contact our Customer Service
Centre on 1800 124 125 (Australia) or 0800 945 995 (New Zealand) or
alternatively, via email at [e-mail] for any difficulties
with your product. Warranty claims and claims for expense incurred in returning
this product can be addressed to our Customer Service Centre at 690 Springvale
Rd, Mulgrave Vic 3170.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
For New Zealand customers, this warranty is in addition to statutory rights
observed under New Zealand legislation.
