APPLICATION
Use Excel LonSpec™ Software to configure the
T7300F/Q7300H Thermostat/Subbase for specific
applications. The Excel LonSpec™ User’s Guide,
form 74-2937, provides software operation instructions for
the personal computer. A complete list of Q7300H user
addresses follows.
Q7300H USER ADDRESS
NETWORK VARIABLES.
The following tables provide the applicable details for the
network variables found in the Q7300H.
Table A1. Miscellaneous Points.
Table A2. Configuration Points.
Table A3. Status Points.
Table A4. Alarm Points.
Table A5. Shared Points.
Q7300H Communicating Subbase System
Integration User Address Manual

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
63-4366 2
Table A1. Miscellaneous (Left).
User Address NvName Field Name Engineering Units: English (Metric) or Status plus range
Digital
State or
Value of
State Default
AssignNode AssignFile node 1 to 127 0
AssignObjId AssignFile ObjectId 0 to 65535 0
AssignSchedId AssignFile ScheduleId 0 to 65535 0
AssignSubnet AssignFile subnet 1 to 255 0
AssignNrObj AsssignHdr NumOfObjects 0 to 65535 4
ApplicationType nciApplVer application_type 0 to 255 0
BypTime nciBypassTime 0 to 3 480
DeviceName nciDeviceName ch[ 18 ] 0 0
BugVersion nroPgmVer bug_ver 0 See Rev
Number
EVObjectldin nviRequest object_id 0 to 65535 1
EVObjectRqst nviRequest object_request Normal
Disabled
UpdateStatus
SelfTest
UpdateAlarm
ReportMask
Override
Enable
RemoveOverride
ClearStatus
ClearAlarm
AlarmNotifyEnabled
AlarmNotifyDisabled
ManualControl
Remotecontrol
Program
Null
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
-1
0
ObjectID nvoStatus object_id 0 to 65535 0
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
3 63-4366
Table A1. Miscellaneous (Right).
User Address Comments
AssignNode Node number of the mode to which this node is bound.
AssignObjId Assigned object number of the object in this node to which this node is bound.
AssignSchedId Assigned object number of the schedule object in this node. This should be the same for all four entries and
should be set to SchedulId in the schedule file by the configuration tool.
AssignSubnet Subnet number of the node to which this node is bound.
AssignNrObj There are four entries in this field that specify which nodes are related to the schedule.The four entries specify
which node is bound to the four nvoOccSchudleX ouputs; 0 = nvoOccSchedule0, 1 = nvoOccSchedule1, 2 =
nvoOccSchedule2, 3 = nvoOccSchedule3.
ApplicationType Future use.
BypTime Time between the pressing of the Temporary Occupied button on the thermostat (or initiating Bypass via
DestManOcc) and return to the original scheduled state. DestBypass does not start the Bypass timer. This field
sets the
duration of temporary override
parameter (Installer Setup Parameter No. 26) in the T7300. When the
bypass state has been activated, the bypass timer is set to BypTime. The only valid bypass times allowed are
60 minutes, 180 minutes, 480 minutes, or 720 minutes. If BypTime is not set to one of these times, the
subbase automatically changes the BypTime to the nearest valid time.
DeviceName 18-character field that identifies the node uniquely as one object at the site or project. Contents of DeviceName
is maintained by a management node. If DeviceName is all ASCII blanks, it is unconfigured.
BugVersion Software version per E-Bus Mechanism document.
EVObjectldin EVObjectldin selects the object being referenced by nviRequest. All other EVObjectldin are invalid. The objects
in the node are: 0  Node Object; 1  Thermostat Object.
EVObjectRqst Normal  Report the status (via nvoStatus) of the object addressed by EVObjectldin and enable automatic
control of all outputs. (See StatusCmdMode).
UpdateStatus  Report the status (via nvoStatus) of the object addressed by EVObjectdin.
ReportMask  Report the status bits that are supported in nvoStatus by the object addressed by EVObjectldin.
Bits that are supported by the object are set to one. The other fields are set to False.
Enable  Enable automatic control outputs. (See StatusCmdMode).
Disabled  Disable automatic control and turn off all outputs. (See StatusCmdMode).
AlarmNorifyDisabled  Disable alarm reporting.
AlarmNotifyEnabled  Enable alarm reporting.
ManualControl, SelfTest, Updatealarm, Override, RemoveOverride, ClearStatus ClearAlarm, RemoteControl,
Program, Null, Other Unspecified Value  Not supported. NvoStatus returns an InvalidRequest in the object
status.
ObjectID Set to the current value of EVObjectldin.
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
63-4366 4
Table A1. Miscellaneous (Left Continued).
User Address NvName Field Name Engineering Units: English (Metric) or Status plus range
Digital
State or
Value of
State Default
FileDirAddress nroFileDirectory 0
FileLength nviFilePos rw_length 0 to 65535 0
FilePointer nviFilePos rw_ptr 0 0
FileAuthOn nviFileReq auth_on Off
On 0 10
FileDomain nviFileReq domain 0 or 1 0
FileIndex nviFileReq index 0 to 65535 0
FileNode nviFileReq node 1 to 127 0
FilePriorityOn nviFileReq prio_on Off
On 0 10
FileRcvTimeout nviFileReq receive_timeout 0 to 65535 0
FileRequest nviFileReq request FR_OPEN_TO_SEND
FR_OPEN_TO_RECEIVE
FR_CLOSE_FILE
FR_CLOSE_DELETE_FILE
FR_DIRECTORY_LOOKUP
FR_OPEN_TO_SEND_RA
FR_OPEN_TO_RECEIVE_RA
FR_NUL
0
1
2
3
4
5
6
-1
0
FileRetry nviFileReq retry 0 to 6 0
FileStatDomainId nvoFileStat domain_id 0 0
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
5 63-4366
Table A1. Miscellaneous (Right Continued).
User Address Comments
FileDirAddress FileDirAddress specifies the Excel 10 location address of the configuration parameter directory.
FileLength Used when the file is opened for SENDING or RECEIVING RANDOM access files. FilePointer is first byte
transferred from the beginning of the file. FileLength is the length of the file transfer.
FilePointer Used when the file is opened for SENDING or RECEIVING RANDOM access files. FilePointer is first byte
transferred from the beginning of the file. FileLength is the length of the file transfer.
FileAuthOn Used when the file is opened for SENDING. Explicit address of the RECEIVER (either subnet/node or group
address), retry count, a transaction time used for the request/response message at the end of every window
and an indication whether authenticated and/or priority messaging should be read.
FileDomain Used when the file is opened for SENDING. Explicit address of the RECEIVER (either subnet/node or group
address), retry count, a transaction time used for the request/response message at the end of every window
and an indication whether authenticated and/or priority messaging should be read.
FileIndex Index number of the file to be opened.
FileNode Used when the file is opened for SENDING. Explicit address of the RECEIVER (either subnet/node or group
address), retry count, a transaction time used for the request/response message at the end of every window
and an indication whether authenticated and/or priority messaging should be read.
FilePriorityOn Used when the file is opened for SENDING. Explicit address of the RECEIVER (either subnet/node or group
address), retry count, a transaction time used for the request/response message at the end of every window
and an indication whether authenticated and/or priority messaging should be read.
FileRcvTimeout
FileRequest FR_OPEN_TO_SEND  Opens indicated file to send entire file. Status returned can be FS_OPEN_FAIL,
FS_XFER_UNDERWAY OR FS_XFER_OK.
FR_OPEN_TO_RECEIVE  Opens indicated file to receive entire file. Status returned can be FS_OPEN_FAIL,
FS_XFER_UNDERWAY OR FS_XFER_OK.
FR_CLOSE_FILE  Closes the indicated file. Status returned is FS_XFER_OK.
FR_CLOSE_DELETE_FILE  Closes and backs out any changes to the specified file. Status returned is
FS_XFER_OK.. This is used for backing out of an aborted transfer. The file is restored to the state prior to
the start of transfer.
FR_DIRECTORY_LOOKUP  Retrieves the directory information for the specified file. Status returned is
FS_LOOKUP_OF, FS_LOOKUP_ERR, OR FS_XFER_OK.
FR_OPEN_TO_SEND_RA  Opens the indicated file for sending a portion of the file using random access.
Status returned can be FS_OPEN_FAIL, FS_SEEK_WAIT, FS_XFER_UNDERWAY, OR FS_XFER_OK.
FR_OPEN_TO_RECEIVE_RA  Opens the indicated file for receiving a portion of the file using random
access. Status returned can be FS_OPEN_FAIL, FS_SEEK_WAIT, FS_XFER_UNDERWAY, OR
FS_XFER_OK.
FR_NUL  No operation.
FileRetry Used when the file is opened for SENDING. Explicit address of the RECEIVER (either subnet/node or group
address), retry count, a transaction time used for the request/response message at the end of every window
and an indication whether authenticated and/or priority messaging should be read.
FileStatDomainId If the last operation was an FR_OPEN_TO_SEND, FR_OPEN_TO_RECEIVE, FR_OPEN_TO_SEND_RA, or
FR_OPEN_TO_RECEIVE_RA, these fields contain the full address of the initiator. If there are multiple initiators
then there may be several operations attempted concurrently on the same set of file transfer network variables.
Each initiator is responsible for checking its own address against the value returned in the file status to ensure
that is was granted requested access. An initiator must not close a file unless it was granted access.
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
63-4366 6
Table A1. Miscellaneous (Left Continued).
User Address NvName Field Name Engineering Units: English (Metric) or Status plus range
Digital
State or
Value of
State Default
MajorVersion nroPgmVer major_ver 0 See Rev
Number
FileTxTimer nviFileReq tx_timer 0 0
FileTypeGrp nviFileReq type 0 to 128 0
InUseNumber nviInUse 0 to 65534 Invalid
FileStatDomainLen nvoFileStat domain_length 0 0
FileStatInfo nvoFileStat file_info 0 0
FileStatNode nvoFileStat node 1 to 127 0
FileStatSize nvoFileStat size 0 to 65353 0
FileStatSubnet nvoFileStat subnet 0 to 255 0
FileStatus nvoFileStat status FS_XFER_OK
FS_LOOKUP_OK
FS_OPEN_FAIL
FS_LOOKUP_ERR
FS_XFER_UNDERWAY
FS_IO_ERR
FS_TIMEOUT_ERR
FS_WINDOW_ERR
FS_AUTH_ERR
FS_ACCESS_UNAVAIL
FS_SEEK_INVALID
FS_SEEK_WAIT
FS_NUL
0
1
2
3
4
5
6
7
8
9
10
11
-1
0
InvalidId nvoStatus invalid_id False
True 0 1False
InvalidRequest nvoStatus invalid_request False
True 0 1False
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
7 63-4366
Table A1. Miscellaneous (Right Continued).
User Address Comments
MajorVersion Software version per E-Bus Mechanism document.
FileTxTimer Used when the file is opened for SENDING. Explicit address of the RECEIVER (either subnet/node or group
address), retry count, a transaction time used for the request/response message at the end of every window
and an indication whether authenticated and/or priority messaging should be read.
FileTypeGrp Used when the file is opened for SENDING. Explicit address of the RECEIVER (either subnet/node or group
address), retry count, a transaction time used for the request/response message at the end of every window
and an indication whether authenticated and/or priority messaging should be read.
InUseNumber InUseNumber is used by a management node to indicate to all other management nodes that it is
logged on
to
the Excel 10 node and that they should not try to interact with any of the Excel 10 network variables or
configuration parameters. Before the management node reads or writes any network variables, the
management node checks InUseNumber for a zero value meaning no other management nodes are already
logged on
and that a management node can log on to the node. Then the management node writes a number,
1 through 65534, to InUseNumber and periodically writes the same value to indicate that the management
node is still logged on. If there are no writes made to InUseNumber for approximately 60 seconds, then the
Excel 10 resets InUseNumber to zero to automatically log off the management node. Before interacting with
any network variables, the management node verifies that the InUseNumber has not changed. The
management node
logs off
by writing 0 to InUseNumber.
During power up, an application restart, or return to on-line from off-line, the Excel 10 sets InUseNumber to
65535 to indicate to the management node that it is now on-line.
FileStatDomainLen If the last operation was an FR_OPEN_TO_SEND, FR_OPEN_TO_RECEIVE, FR_OPEN_TO_SEND_RA, or
FR_OPEN_TO_RECEIVE_RA, these fields contain the full address of the initiator. If there are multiple
initiators then there may be several operations attempted concurrently on the same set of file transfer network
variables. Each initiator is responsible for checking its own address against the value returned in the file status
to ensure that is was granted requested access. An initiator must not close a file unless it was granted access.
FileStatInfo A sixteen character string with information about the file.
FileStatNode If the last operation was an FR_OPEN_TO_SEND, FR_OPEN_TO_RECEIVE, FR_OPEN_TO_SEND_RA, or
FR_OPEN_TO_RECEIVE_RA, these fields contain the full address of the initiator. If there are multiple
initiators then there may be several operations attempted concurrently on the same set of file transfer network
variables. Each initiator is responsible for checking its own address against the value returned in the file status
to ensure that is was granted requested access. An initiator must not close a file unless it was granted access.
FileStatSize The number of bytes in the last selected file.
FileStatSubnet If the last operation was an FR_OPEN_TO_SEND, FR_OPEN_TO_RECEIVE, FR_OPEN_TO_SEND_RA, or
FR_OPEN_TO_RECEIVE_RA, these fields contain the full address of the initiator. If there are multiple
initiators then there may be several operations attempted concurrently on the same set of file transfer network
variables. Each initiator is responsible for checking its own address against the value returned in the file status
to ensure that is was granted requested access. An initiator must not close a file unless it was granted access.
FileStatus Internal Use Only.
InvalidId If EVObjectldin is not a valid object, InvalidId is set to True; otherwise it is set to False.
InvalidRequest If EVObjectRqst is not a valid request for the object addressed, InvalidRequest is set to True; otherwise it is set
to False.
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
63-4366 8
Table A1. Miscellaneous (Left Continued).
User Address NvName Field Name Engineering Units: English (Metric) or Status plus range
Digital
State or
Value of
State Default
MemFileAddress MemFileDir pData 0
MemFileSize MemFileDir Size 0
MemFileType MemFileDir Type 0
MemFileVersion MemFileDirHdr Version 0
MemNumFiles MemFileDirHdr NumFIles 0
NrHeatStages nciConfig NrHeatStages 0 1
MinorVersion nroPgmVer minor_ver 0 See Rev
Number
NodeType nroPgmVer id[ 4 ] 0 See Rev
Number
NodeTypeNumber nroPgmVer node_type 0 See Rev
Number
NrFiles nvoFileStat number_of_files 0 0
ManualControl nvoStatus manual_control False
True 0 1False
NrSpecialDays SchedFileHdr NumOfSpecialDays 0 0
NrTemps SchedFileHdr NumOfTemps 0 0
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
9 63-4366
Table A1. Miscellaneous (Right Continued).
User Address Comments
MemFileAddress MemFileAddress specifies the address in the Excel 10 at which the file is located.
MemFileSize For each file there is a record containing the MemFileSize, MemFileType, and MemFileAddress. MemFileSize
is the length of the file.
MemFileType Specifies the LonMark  file type entered into the file directory. Type 1 is a configuration parameter value file.
Type 2 is a configuration parameter template file.
MemFileVersion MemFileVersion (a one byte quantity) specifies the major/minor version of the file. The most significant nibble
contains the major version number and the least significant nibble contains the minor version number.
MemNumFiles MemNumFiles is the number of files in the directory. There is a MemFileSize, MemFileType and
MemFileAddress record for each file following the MemNumFiles.
NrHeatStages 0-3 stages.
MinorVersion Software version per E-Bus Mechanism document.
NodeType NodeType is a four byte ASCII string indicating the type of node (model).
NodeTypeNumber Numeric identifier assigned to the type of node specified in NodeType.
NrFiles Internal use only.
ManualControl When the control loop(s) are disabled and the outputs are controlled manually, then this bit is set to one;
otherwise this bit is set to zero. Manual control of this product is initiated by executing the installer setup
function at the thermostat front panel.
NrSpecialDays There are no special days in this schedule. NrSpecialDays is always zero. Attempts to write another value
causes the write to the file to be ignored.
NrTemps There are no temporary schedules in this schedule. NrTemps is always zero. Attempts to write another value
causes the write to the file to be ignored.
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
63-4366 10
Table A1. Miscellaneous (Left Continued).
User Address NvName Field Name Engineering Units: English (Metric) or Status plus range
Digital
State or
Value of
State Default
SelectedFile nvoFileStat selected_file 0 0
OpenCircuit nvoStatus open_circuit False
True 0 1False
OutofLimits nvoStatus out_of_limits False
True 0 1False
OutofService nvoStatus out_of_service False
True 0 1False
ProgFail nvoStatus programming_fail False
True 0 1False
ProgMode nvoStatus programming_mode False
True 0 1False
ReportMask nvoStatus report_mask False
True 0 1False
SchedHour SchedFile hours 0 to 23 0
SchedMinutes SchedFile minutes 0 to 59 0
SchedOcc SchedFile mode Null
Occ
UnOcc
Bypass
Standby
-1
0
1
2
3
OC_NUL
NrTimeModes SchedFileHdr NumOfTimeModes 4 to 4 4
Scheduleld SchedFileHdr ScheduleId 0 to 65535 0
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
11 63-4366
Table A1. Miscellaneous (Right Continued).
User Address Comments
SelectedFile The index number of the file that was last selected for data transfer.
OpenCircuit Not supported, set to zero.
OutofLimits Not supported, set to zero.
OutofService Not supported, set to zero.
ProgFail Not supported, set to zero.
ProgMode Not supported, set to zero.
ReportMask Internal use only.
SchedHour The hour of the event; 0 through 23 hrs.
SchedMinutes The minutes of the event. T7300 implements event times in 15-minute increments. If values other than 0, 15,
30, and 45 are written, SchedMinutes is changed to the nearest permitted value.
SchedOcc The occupancy state of the schedule can be one of the states listed. In case SchedOcc is not one of the
permitted values, SchedOcc is changed to the SchedOcc(read) as listed:
Occ, Bypass, Standby  Space is scheduled to be occupied.
UnOcc  Space is scheduled to be unoccupied.
Null and any other  Schedule entry is ignored.
NrTimeModes There are four time mode events per day in this schedule. NrTimeModes is always four. Attempts to write
another value causes the write to the file to be ignored.
Scheduleld ScheduleId is assigned by a tool for later schedule identification by a user interface that displays or changes
the schedule. Saved in EEPROM.
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
63-4366 12
Table A1. Miscellaneous (Left Continued).
User Address NvName Field Name Engineering Units: English (Metric) or Status plus range
Digital
State or
Value of
State Default
tAuto nvoIO Auto Off
On 0 1Off
tBHeat nvoIO B Off
On 0 1Off
tBuildId nvoIO BuildId 0 0
tcmBlockControl nvoIO cmBlockControl Off
On 0 1Off
tcmBlockEquip nvoIO cmBlockEquip Off
On 0 1Off
tcmBlockSchedandUser nvoIO cmBlockSchedandUser Off
On 0 1Off
tcmBlockSchedule nvoIO cmBlockSchedule Off
On 0 1Off
tcmBlockUser nvoIO cmBlockUser Off
On 0 1Off
tcmBlockUserAndDisplay nvoIO cmBlockUserAndDisplay Off
On 0 1Off
tcmResetWatchDog nvoIO cmResetWatchDog Off
On 0 1Off
tcmUseNetSensor nvoIO cmUseNetSensor Off
On 0 1Off
tCool nvoIO Cool Off
On 0 1Off
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
13 63-4366
Table A1. Miscellaneous (Right Continued).
User Address Comments
tAuto User Mode Switch–Auto setting.True= selected, False= not selected.
NOTE: Only one User Mode Switch may be True at a time.
tBHeat Equipment output relay  B. True = On; False = Off.
tBuildId Thermostat software build identification string.
tcmBlockControl Thermostat control algorithm. False = enabled; True = disabled.
tcmBlockEquip Thermostat or subbase controls HVAC equipment via relay outputs. False = thermostat controls outputs; True
= thermostat blocked, subbase controls outputs.
tcmBlockSchedandUser Thermostat user keys and thermostat time-of-day occupancy schedule enabled/disabled. False = enabled;
True = disabled.
tcmBlockSchedule Thermostat time-of-day occupancy schedule. False = enabled; True = disabled.
tcmBlockUser Thermostat user keys enabled. Some keys may be disabled by the thermostat installer setup.
tcmBlockUserAndDisplay Thermostat user keys and display are enabled/disabled. False – enabled; True = disabled.
tcmResetWatchDog Not used.
tcmUseNetSensor Sensor used to control space temperature. False = use thermostat ensor(s); True = use network sensor via
communications subbase.
tCool User Mode Switch–Cool setting. True = selected, False = not selected.
NOTE: Only one User Mode Switch may be True at a time.
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
63-4366 14
Table A1. Miscellaneous (Left Continued).
User Address NvName Field Name Engineering Units: English (Metric) or Status plus range
Digital
State or
Value of
State Default
tCool1 nvoIO Cool1 Off
On 0 1Off
tCool2 nvoIO Cool2 Off
On 0 1Off
tCool3 nvoIO Cool3 Off
On 0 1Off
tCoolSetPt nvoIO CoolSetPt 0 0
tCurrentOcc nvoIO CurrentOcc Occ
UnOcc
Bypass
Standby
Null
0
1
2
3
-1
0
tDateCodeMo nvoIO DateCodeMo 0 0
tDateCodeYr nvoIO DateCodeYr 0 0
tEconOn nvoIO EconOn Off
On 0 1Off
tEEPROMid nvoIO EEPROMid 0 0
tEffectOcc nvoIO EffectOcc Occ
UnOcc
Bypass
Standby
Null
0
1
2
3
-1
0
tEmergHeat nvoIO EmergHeat Off
On 0 1Off
tEmHeat1 nvoIO EmHeat1 Off
On 0 1Off
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
15 63-4366
Table A1. Miscellaneous (Right Continued).
User Address Comments
tCool1 Equipment output relay  Cool Stage 1. True = On; False = Off.
tCool2 Equipment output relay  Cool Stage 2. True = On; False = Off.
tCool3 Equipment output relay  Cool Stage 3. True = On; False = Off.
tCoolSetPt Cooling setpoint used by the thermostat to automatically select heating and cooling and to control space
temperature. tCoolSetPt is displayed when the thermostat is calling for cooling. See the section on Space
Temperature Setpoint for more details.
tCurrentOcc Occupancy state called for by the thermostat time-of-day schedule; Occ, UnOcc, Null.
tDateCodeMo Future use.
tDateCodeYr Future use.
tEconOn Equipment output relay  Economizer. True = On; False = Off.
tEEPROMid Future use.
tEffectOcc Occupancy state called for by the thermostat including the local scheduler activation of Temporary Occupied or
Continuous Occupied buttons; Occ, UnOcc.
tEmergHeat User Mode Switch–EmergHeat setting. True = selected; False = not selected.
NOTE: Only one User Mode Switch may be True at a time.
tEmHeat1 Equipment output relay (Emergency Heat stage 1). True = On; False = Off.
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
63-4366 16
Table A1. Miscellaneous (Left Continued).
User Address NvName Field Name Engineering Units: English (Metric) or Status plus range
Digital
State or
Value of
State Default
Time1Jan70 nciApplVer time[ 4 ] 0 0
tEmHeat2 nvoIO EmHeat2 Off
On 0 1Off
tFanAuto nvoIO FanAuto Off
On 0 1Off
tFanOn nvoIO FanOn Off
On 0 1Off
tHeat nvoIO Heat Off
On 0 1Off
tHeat1 nvoIO Heat1 Off
On 0 1Off
tHeat2 nvoIO Heat2 Off
On 0 1Off
tHeatSetPt nvoIO HeatSetPt 0 0
tHtPump nvoIO HtPump Off
On 0 1Off
tLEMode nvoIO LEMode Off
On 0 1Off
tMaxClStg nvoIO MaxClStg 0 to 3 0
tHeat3 nvolO Heat3 Off
Of 0 1Off
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
17 63-4366
Table A1. Miscellaneous (Right Continued).
User Address Comments
Time1Jan70 Time1Jan70 (nciApplVer) is the time stamp of the last change to the Excel 10 application configuration.
Time1Jan70 meets the ANSI C time stamp requirement specifying the number of seconds elapsed since
midnight (0:00:00), January 1, 1970. It is represented in the Intel format.
nciApplVer identifies the Excel 10 application number, version number and time stamp of the last configuration
change. It is set by a management node during configuration and is typically read by any management node.
tEmHeat2 Equipment output relay (Emergency Heat stage 2). True = On; False = Off.
tFanAuto User fan switch  Auto. True = selected; False = not selected. Only one user fan switch may be True at a time.
tFanOn User fan switch  On. True = selected; False = not selected. Only one user fan switch may be True at a time.
tHeat User mode switch - ”Heat” setting. True = selected; False = not selected. Only one user mode switch may be
True at a time.
tHeat1 Equipment output relay  Heat Stage 1. True = On; False = Off.
tHeat2 Equipment output relay  Heat Stage 2. True = On; False = Off.
tHeatSetPt Heating setpoint used by the thermostat to automatically select heating and cooling and to control space
temperature. tHeatSetPt is displayed when the thermostat is calling for heat. See the section on Space
Temperature Setpoint for more details.
tHtPump Subbase is configured to control; True = heat pump, False = conventional fuel.
tLEMode Equipment output relay  LEMode. True = On; False = Off.
tMaxClStg Maximum number of cooling stages allowed by the subbase.
tHeat3 Equipment output relay  Heat Stage 3. True = On; False = Off.
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
63-4366 18
Table A1. Miscellaneous (Left Continued).
User Address NvName Field Name Engineering Units: English (Metric) or Status plus range
Digital
State or
Value of
State Default
tMaxHtStg nvoIO MaxHtStg 0 to 3 0
tNextOcc nvoIO NextOcc Occ
UnOcc
Bypass
Standby
Null
0
1
2
3
-1
0
tOCool nvoIO O Off
On 0 1Off
tOff nvoIO Off Off
On 0 1Off
tOKrdwrStPts nvoIO OKrdwrStPts Off
On 0 1Off
tPgmVer nvoIO PgmVer 0 0
tPump nvoIO Pump Off
On 0 1Off
tReHum nvoIO ReHum Off
On 0 1Off
tSubBaseId nvoIO SubBaseId 0 0
tSystemState nvoIO SystemState 0 0
tTAT nvoIO TAT Off
On 0 1Off
tTmpSetPt nvoIO TmpSetPt Off
On 0 1Off
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
19 63-4366
Table A1. Miscellaneous (Right Continued).
User Address Comments
tMaxHtStg Maximum number of heating stages allowed by the subbase.
tNextOcc Occupancy state called for next by the thermostat time-of-day schedule. Occ, UnOcc, Null.
tOCool Equipment output relay  O. True = On; False = Off.
tOff User Mode Switch–Off setting. True= selected; False= not selected.
NOTE: Only one User Mode Switch may be True at a time.
tOKrdwrStPts Future use.
tPgmVer Each thermostat program code version has a PgmVerCode. Each subbase code version is only compatible
with the tPgmVer specifically designed for subbase compatibility. The subbase reads the tPgmVer and checks
for compatibility. If the subbase is not compatible, a tPgmVerAlrm is generated and the Q7300 no longer
communicates with the subbase. If the subbase is compatible, the subbase uses tPgmVer to change its
functionality to be compatible with the software version of the thermostat. The only tPgmVer currently
recognized is 0.
tPump Equipment output relay  Pump. True = On; False = Off.
tReHum Equipment output relay  Relative Humidity. True = On; False = Off.
tSubBaseId Future use.
tSystemState The thermostat internal system state flag. Some of the values are listed in hexadecimal:
A8 = Real time clock is invalid after thermostat startup.
7E = Continuous onoccupied state.
69 = Temporary occupied 9timed bypass) state).
tTAT Equipment output relay  TAT. True = On; False = Off.
tTmpSetPt A temporary setpoint is displayed and used by the thermostat; True = Yes, False = No.
(continued)

Q7300H COMMUNICATING SUBBASE SYSTEM INTEGRATION USER ADDRESS MANUAL
63-4366 20
Table A1. Miscellaneous (Left Continued).
User Address NvName Field Name Engineering Units: English (Metric) or Status plus range
Digital
State or
Value of
State Default
unusedF1 nviFileReq unused1 0 0
unusedF2 nviFileReq unused2 0 0
tTuncos nvoIO Tuncos 0 0
tUserState nvoIO UserState 0 0
tValidDuctTemp nvoIO ValidDuctTemp Off
On 0 1Off
tValidLocalTemp nvoIO ValidLocalTemp Off
On 0 1Off
tValidRemoteTemp nvoIO ValidRemoteTemp Off
On 0 1Off
UnitCool nvoUnitStatus cool_output 0 to 100 percent
UnitEcon nvoUnitStatus econ_output 0 to 100 percent
UnitFan nvoUnitStatus fan_output 0 to 100 percent
UnitHeat nvoUnitStatus heat_output_primary 0 to 100 percent
UnitSecHeat nvoUnitStatus heat_output_secondary 0 to 100 percent
(continued)
