Honeywell One Wireless WCX Series User manual

OneWireless
XYR 6000 Wireless Valve Position Sensor
Model: WCX Series
Quick Start Guide
50040850
Revision 1
1/20/09

ii OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide Revision 1
1/15/09
Notices and Trademarks
Copyright 2009 by Honeywell International Inc.
Revision 1 January 20, 2009
While this information is presented in good faith and believed to be accurate, Honeywell disclaims the implied
warranties of merchantability and fitness for a particular purpose and makes no express warranties except as may
be stated in its written agreement with and for its customers.
In no event is Honeywell liable to anyone for any indirect, special or consequential damages. The information and
specifications in this document are subject to change without notice.
Honeywell, PlantScape, Experion PKS, and TotalPlant are registered trademarks of Honeywell International Inc.
Other brand or product names are trademarks of their respective owners.
Automation and Control Solutions
Sensing and Control
Honeywell
1985 Douglas Drive North
Minneapolis, MN 55422
www.honeywell.com/sensing

Revision 1 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide iii
1/20/09
About This Document
This document describes mounting, installation and wiring of the WCX Series Valve Position Sensor and antennas.
Configuration, authentication and operation are covered in other documents.
Honeywell does not recommend using devices for critical control where there is a single point of failure or where
single points of failure result in unsafe conditions. OneWireless is targeted at open loop control, supervisory
control, and controls that do not have environmental or safety consequences. As with any process control solution,
the end-user must weigh the risks and benefits to determine if the products used are the right match for the
application based on security, safety, and performance. Additionally, it is up to the end-user to ensure that the
control strategy sheds to a safe operating condition if any crucial segment of the control solution fails.
Revision Information
Document Name Document ID Revision
Number Publication Date
XYR 6000 Wireless Valve Position Sensor,
Model WCX Series Quick Start Guide 50040850 1 1/20/09
References
The following list identifies all documents that may be sources of reference for material discussed in this
publication.
Document Title
Getting Started with Honeywell OneWireless Solutions
OneWireless Wireless Builder User’s Guide
OneWireless Builder Parameter Reference
OneWireless XYR 6000 Wireless Valve Position Sensor, Model WCX Series User's Manual
OneWireless XYR 6000 Pressure Transmitter User's Manual
OneWireless XYR 6000 Temperature/DI Transmitter User's Manual
OneWireless XYR 6000 SmartCET Corrosion Transmitter User's Manual
OneWireless XYR 6000 HLAI Transmitter User's Manual

Support and contact info
WARNING
Risk of death or serious injury from explosion or fire.
If sensor is to be returned to Honeywell for any reason, both batteries MUST
be removed prior to shipping. Dispose of used batteries promptly per local
regulations or the battery manufacturer’s recommendations. Keep away from
children. Do not disassemble and do not dispose of in fire.
Sales and Service
Honeywell serves its customers through a worldwide network of sales offices, representatives and
distributors. For application assistance, current specifications, pricing or name of the nearest Authorized
Distributor, contact your local sales office or:
E-mail: [email protected]
Internet: www.honeywell.com/sensing
Phone and Fax:
Asia Pacific [phone]
[phone] Fax
Europe [phone]
[phone] Fax
Latin America [phone]
[phone] Fax
USA/Canada [phone]
[phone]
[phone] Fax
iv OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide Revision 1
1/20/09

Symbol Definitions
The following table lists those symbols used in this document to denote certain conditions.
Symbol Definition
ATTENTION: Identifies information that requires special consideration.
TIP: Identifies advice or hints for the user, often in terms of performing a task.
CAUTION Indicates a situation which, if not avoided, may result in equipment or work (data) on
the system being damaged or lost, or may result in the inability to properly operate
the process.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury. It may also be used to alert against unsafe
practices.
CAUTION symbol on the equipment refers the user to the product manual for
additional information. The symbol appears next to required information in the
manual.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could
result in serious injury or death.
WARNING symbol on the equipment refers the user to the product manual for
additional information. The symbol appears next to required information in the
manual.
WARNING, Risk of electrical shock: Potential shock hazard where HAZARDOUS
LIVE voltages greater than 30 Vrms, 42.4 Vpeak, or 60 VDC may be accessible.
ESD HAZARD: Danger of an electro-static discharge to which equipment may be
sensitive. Observe precautions for handling electrostatic sensitive devices.
Protective Earth (PE) terminal: Provided for connection of the protective earth
(green or green/yellow) supply system conductor.
Functional earth terminal: Used for non-safety purposes such as noise immunity
improvement. NOTE: This connection shall be bonded to Protective Earth at the
source of supply in accordance with national local electrical code requirements.
Earth Ground:Functional earth connection. NOTE: This connection shall be
bonded to Protective Earth at the source of supply in accordance with national and
local electrical code requirements.
Chassis Ground: Identifies a connection to the chassis or frame of the equipment
shall be bonded to Protective Earth at the source of supply in accordance with
national and local electrical code requirements.
continued
Revision 1 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide v
1/20/09

vi OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide Revision 1
1/20/09
Symbol Definition
C-Tick Mark: The C-Tick Mark is a certification trade mark registered to ACMA
(Australian Communications and Media Authority) in Australia under the Trade Marks
Act 1995 and to RSM in New Zealand under section 47 of the NZ Trade Marks Act.
The mark is only to be used in accordance with conditions laid down by ACMA and
RSM. This mark is equal to the CE Mark used in the European Union.
Notified Body: For radio equipment used in the European Union in accordance with
the R&TTE Directive, the CE Mark and the notified body (NB) identification number is
used when the NB is involved in the conformity assessment procedure. The alert sign
must be used when a restriction on use (output power limit by a country at certain
frequencies) applies to the equipment and must follow the CE marking.

Revision 1 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide vii
1/20/09
Contents
Support and contact info........................................................................................................................iv
1. INTRODUCTION....................................................................................................1
1.1 Site preparation.............................................................................................................................1
1.2 European Union Usage.................................................................................................................1
1.3 Certifications and approvals........................................................................................................2
Hazardous location certifications............................................................................................................................2
Radio certifications.................................................................................................................................................2
Ratings...................................................................................................................................................................3
2. SENSOR MOUNTING............................................................................................5
2.1 Weight ............................................................................................................................................5
2.2 Dimensions....................................................................................................................................5
2.3 Sensor location .............................................................................................................................7
WCX Valve Position Sensor models.......................................................................................................................7
2.4 Bracket mounting..........................................................................................................................8
Orientation..............................................................................................................................................................8
Attach bracket to pipe.............................................................................................................................................8
Attach sensor to valve............................................................................................................................................9
Attach sensor to bracket.......................................................................................................................................10
3. PROCESS INSERTION .......................................................................................11
3.1 Basic Requirements....................................................................................................................11
Non-sparking Considerations...............................................................................................................................11
Distance from Multinode.......................................................................................................................................11
Angle to be measured ..........................................................................................................................................11
Sensor update rate...............................................................................................................................................11
Access to cover for configuring sensor, changing batteries..................................................................................11
Proximity to high powered L-band transmitters ....................................................................................................11
3.2 Linkage Alignment......................................................................................................................12
Axis of valve and sensor input shaft.....................................................................................................................12
Alignment of linkage.............................................................................................................................................12
If angle linearity is required...................................................................................................................................12
Coupling with pulleys............................................................................................................................................13
If clockwise is to be translated into counter clockwise..........................................................................................13
3.3 Non-Valve Applications..............................................................................................................14
Door Position Sensing..........................................................................................................................................14
Air Handler Plenum Door Position Sensing..........................................................................................................14
Linear Displacement.............................................................................................................................................14
4. ANTENNA ADJUSTMENT AND MOUNTING .....................................................15
4.1 Requirements ..............................................................................................................................15
Radio installation requirements ............................................................................................................................15
4.2 Integral antenna...........................................................................................................................15
Elbow....................................................................................................................................................................16

50BContents
52BSymbol Definitions
viii OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide Revision 1
1/20/09
Straight.................................................................................................................................................................16
5. START UP ...........................................................................................................17
5.1 Connect batteries........................................................................................................................17
5.2 Display sequence........................................................................................................................19
5.3 Authentication.............................................................................................................................19
5.4 Calibration....................................................................................................................................19
6. INSTALLATION DRAWINGS ..............................................................................21
6.1 Drawing Availability....................................................................................................................21

50BContents
53BTables
Revision 1 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide ix
1/20/09
Tables
Table 1 Battery Connecting Procedure .......................................................................................................17

50BContents
54BFigures
x OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide Revision 1
1/20/09
Figures
Figure 1 WCX Valve Position Sensor dimensions.........................................................................................5
Figure 2 WCX Valve Position Sensor rt. angle antenna dimensions ............................................................6
Figure 3 WCX Valve Position Sensor straight antenna dimensions..............................................................7
Figure 4 Common bracket orientations .........................................................................................................8
Figure 5 Sensor Mounted Above Valve.........................................................................................................9
Figure 6 Axis Parallel and Linkage 90 degrees with shafts.........................................................................12
Figure 7 Parallelogram formed by linkage...................................................................................................13
Figure 8 Changing CW into CCW................................................................................................................14
Figure 9 Elbow antenna adjustment............................................................................................................16
Figure 10 Integral straight antenna..............................................................................................................16
Figure 11 Battery connecting.......................................................................................................................18
Figure 12 Battery connecting detail.............................................................................................................18

Revision 1 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide 1
1/20/09
1. Introduction
1.1 Site preparation
Wireless devices require proper site preparation to ensure optimum performance and safety compliance.
Do not proceed until you have done the proper planning described in the Wireless Planning Guide.
1.2 European Union Usage
This product may be used in any of the following European Union nations.
Country ISO 3166
2 letter code Country ISO 3166 2 letter code
Austria AT Latvia LV
Belgium BE Liechtenstein LI
Bulgaria BG Lithuania LT
Cyprus CY Malta MT
Czech Republic CZ Netherlands NL
Denmark DK Norway NO
Estonia EE Poland PL
Finland FI Portugal PT
France FR Romania RO
Germany DE Slovakia SK
Greece GR Slovenia SI
Hungary HU Spain ES
Iceland IS Sweden SE
Ireland IE Switzerland CH
Italy IT United Kingdom BG

1. Introduction
1.3. Certifications and approvals
2 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide Revision 1
1/20/09
1.3 Certifications and approvals
Hazardous location certifications
Refer to product label for applicable approvals.
Approval / Item Ratings / Description
cCSAus Explosion Proof
with IS outputs Class I, Division 1, Groups A, B, C & D
Class II, Division 1, Groups E, F & G
Class III
ATEX Flameproof with IS
outputs II 2 G Ex d [ia] IIB T4
II 2 D Ex tD A21 IP66 T85C
IEC Ex Flameproof with
IS outputs Ex d [ia] IIB T4: DIP A21 IP66 T85C
Enclosure Type Types 1, 3, 4, 4X, 6, 6P, 13 and IP66/67
Class II and III installations and for Type 4X/IP66 applications require that all cable and unused entries be
sealed with a Zone 1 certified seal fitting. Seal fittings are supplied by Honeywell.
Radio certifications
Agency Certification Description
Federal
Communications
Commission (FCC)
DSSS FCC ID:
S5750025034
The WCX Series Valve Position Sensors comply with part 15
of the FCC rules. Operation is subject to the following two
conditions.
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Industry Canada (IC) DSSS IC ID:
573I-50025034
The installer of this radio equipment must ensure that the
antenna is located or pointed such that it does not emit RF
fields in excess of Health Canada limits for the general
population; consult Safety Code 6, obtainable from Health
Canada’s web site www.hc-sc.gc.ca/rpb

1. Introduction
1.3. Certifications and approvals
Revision 1 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide 3
1/20/09
Ratings
Item Ratings / Description WCX
Process
Connections n/a n/a
Temperature
Limits Max Process Temperature n/a
Ambient Temperature Limits Cold: –40°C
Ambient Temperature Limits Hot: +70°C
Entry Plugs 3/4 NPT or M25 1
Field Wiring
(Supplied by
others)
Conduit (Explosionproof Not
Required) n/a
Cable Gland n/a

2. Sensor Mounting
2.1 Weight
Sensor model Weight
WCX1X1...
Aluminum housing & antenna 4.5 lbs (2.04 kg)
WCX1X2...
Bronze housing & stainless steel antenna 11.1 lbs (5.03 kg)
2.2 Dimensions
Figure 1 WCX Valve Position Sensor dimensions
Revision 1 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide 5
1/20/09

2. Sensor Mounting
2.2. Dimensions
Figure 2 WCX Valve Position Sensor rt. angle antenna dimensions
6 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide Revision 1
1/20/09

2. Sensor Mounting
2.3. Sensor location
Figure 3 WCX Valve Position Sensor straight antenna dimensions
2.3 Sensor location
WCX Valve Position Sensor models
Process Suggested location Explanation
Gases Above the gas line or gas valve The condensate drains away from the
sensor.
Liquids •Above but close to the
elevation of the process
valve or other control.
•Level with the process valve
or other control..
•The condensate drains away from
the sensor.
•This facilitates a horizontal linkage
between valve and sensor.
Revision 1 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide 7
1/20/09

2. Sensor Mounting
2.4. Bracket mounting
2.4 Bracket mounting
Orientation
The WCX Series sensor may be mounted in any vertical, horizontal or angled orientation. The main
consideration is to facilitate coupling of the valve or other device to the input shaft of the sensor.
For best signal, it is generally recommended that the antenna be oriented vertically (see section 4).
A higher elevation may give better signal range than a lower elevation, depending on obstacles.
Attach bracket to pipe
Figure 4 shows some commonly used customer-provided bracket and pipe orientations. Not all
possibilities are shown; any bracket (flat or angle) and orientation (parallel or transverse) may be used to
get the desired input shaft positioning with respect to the valve being monitored.
When considering brackets with flanged sides (as in illustration), insure that the whole portion of the
exposed input shaft extends past the flanges to provide sufficient clearance from the connecting linkage to
be used.
Position bracket on 2-inch (50.8 mm) pipe and install “U” bolt around pipe and through holes in bracket.
B
EF
CD
A
Figure 4 Common bracket orientations
8 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide Revision 1
1/20/09

2. Sensor Mounting
2.4. Bracket mounting
Attach sensor to valve
Figure 5 shows a "U" shaped mounting bracket specifically fabricated to allow mounting of the sensor
above a valve. This allows the sensor input shaft to be coupled to the valve shaft, permitting easy manual
activation of the valve.
This will not be suitable for valves or devices with more than a 270 degree range of rotation.
Figure 5 Sensor Mounted Above Valve
Revision 1 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide 9
1/20/09

2. Sensor Mounting
2.4. Bracket mounting
Attach sensor to bracket
Align appropriate mounting holes in sensor with holes in bracket and secure the sensor to the bracket with
bolts and washers as needed. Use a backing plate for added strength as needed
Brackets and mounting hardware are user-supplied.
Sensor Mounting Attachment to bracket Example
Base of sensor mounted to
bracket, using threaded bolts
(sensor with threaded holes)
Alternate mounting holes
in end of heads, using
bolts, washers, and
lockwashers.
Base of sensor mounted to
bracket, using through bolts
(sensor with through holes)
Alternate mounting holes
in end of heads, using
nuts, bolts, washers, and
lockwashers. Use backing
plate if needed.
Side of sensor base mounted
to bracket, using threaded
bolts (sensor with threaded
holes)
Select two mounting holes
in end of heads, using
bolts, washers, and
lockwashers. Use backing
plate if needed.
10 OneWireless XYR 6000 Wireless Valve Position Sensor Quick Start Guide Revision 1
