Honeywell GSM-ANTHB User manual

800-02377 7/08 Rev. A
GSM-ANTHB
Antenna Kit
Installation & Setup Guide
Introduction
The GSM-ANTHB Kit provides external antenna capability for GSM and iGSM communications devices.
NOTE: This antenna is for indoor use only.
Contents
This kit consists of an Antenna and Adapter Cable (for connection to the communications device).
WASHER
AND NUT
ANTENNA ADAPTER CABLE
gsm-exppk-002-V0
ANTENNA
Assembly
To assemble, refer to the figure below and perform the following steps:
NOTE: Refer to the communication device's Installation and Setup Guide for mounting, wiring and
programming information.
1. Remove the front cover from the communications device.
2. Install the through-hole connector of the adapter cable in the top hole on the enclosure back of the
communications device. Secure with lock washer and nut.
3. Snap the other end of the adapter cable in the external antenna port of the communications device.
4. Attach the antenna to the connector on top of the enclosure. Replace the front cover.
P/O
GSM-ANTHB
ANTENNA KIT
ANTENNA
WASHER
NUT
gsmt-exppk-003-V0
TB 1
6
7
8
5
10
11
9
2
3
4
1
FOR EXTERNAL ANTENNA
50 OHM MMCX ONLY
PRIMARY POWER: 9 - 16.5 VAC
CURRENT: 900mA PEAK, 70mA STANDBY
BATTERY: 8V. 3.1 AHr FOR 24 Hr BACKUP
FCC:XXXXXXXXXX IC: YYYYYYYYYY
RSSI
M0
M1
GPRS
IBS
RED
BLK
7720P PROGRAMMER PORT
NOT FOR TELEPHONE SERVICE USE!
RED
BLACK
COMMUNICATIONS
DEVICE
MOUNTING SCREWS
AND SPACERS (4)
SMA / MMCX
ADAPTER CABLE
(P/O GSM-ANTHB
ANTENNA KIT)
EXTERNAL
ANTENNA PORT
BATTERY

Ê800-02377MŠ
800-02377 7/08 Rev. A
For the latest warranty information, please go to:
http://www.security.honeywell.com/hsc/resources/wa/
2 Corporate Center Drive, Melville, NY 11747
Copyright©2008 Honeywell International Inc.
www.honeywell.com/security
