Honeywell VOYAGER 1250G User manual

™
VoyagerTM 1250g
Single-Line Laser Scanner
User’s Guide

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in speci-
fications and other information contained in this document without prior notice,
and the reader should in all cases consult HII to determine whether any such
changes have been made. The information in this publication does not repre-
sent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained
herein; nor for incidental or consequential damages resulting from the furnish-
ing, performance, or use of this material.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied, repro-
duced, or translated into another language without the prior written consent of
HII.
©2011 Honeywell International Inc. All rights reserved.
Other product names or marks mentioned in this document may be trademarks
or registered trademarks of other companies and are the property of their
respective owners.
Web Address: www.honeywellaidc.com

1
Chapter 1 - Getting Started
About This Manual ...................................................... 1-1
Unpacking Your Device............................................... 1-1
Connecting the Device ................................................ 1-1
Connecting with USB ............................................ 1-1
Connecting with Keyboard Wedge........................ 1-2
Connecting with RS232 Serial Port....................... 1-3
Connecting with RS485......................................... 1-4
Reading Techniques ................................................... 1-5
Menu Bar Code Security Settings ............................... 1-5
Setting Custom Defaults ............................................. 1-5
Resetting the Custom Defaults ................................... 1-6
Resetting the Factory Defaults.................................... 1-7
Chapter 2 - Programming the Interface
Introduction ................................................................. 2-1
Programming the Interface - Plug and Play ................ 2-1
Keyboard Wedge................................................... 2-1
IBM PS2 Keyboard................................................ 2-1
RS232 Serial Port.................................................. 2-1
RS485 ................................................................... 2-2
OPOS Mode.......................................................... 2-3
USB IBM SurePos................................................. 2-4
IBM Secondary Interface....................................... 2-4
USB PC or Macintosh Keyboard........................... 2-5
USB HID................................................................ 2-5
HID Fallback Mode................................................ 2-5
USB Serial Commands ............................................... 2-6
USB Serial Emulation............................................ 2-6
CTS/RTS Emulation.............................................. 2-6
ACK/NAK Mode..................................................... 2-7
Communication Timeout ....................................... 2-7
NAK Retries........................................................... 2-8
Support BEL/CAN in ACK/NAK............................. 2-8
Table of Contents

2
Verifone®Ruby Terminal Default Settings ..................2-9
Gilbarco®Terminal Default Settings............................2-9
Honeywell Bioptic Aux Port Configuration .................2-10
Datalogic™ Magellan©Bioptic
Aux Port Configuration ............................................2-10
NCR Bioptic Aux Port Configuration..........................2-10
Wincor Nixdorf Terminal Default Settings..................2-11
Wincor Nixdorf Beetle™ Terminal Default Settings...2-11
Keyboard Country Layout..........................................2-12
Keyboard Wedge Modifiers .......................................2-14
ALT Mode ............................................................2-14
Keyboard Style ....................................................2-14
Keyboard Conversion ..........................................2-15
Keyboard Modifiers..............................................2-16
Inter-Scan Code Delay ........................................2-17
<F0> Break Character .........................................2-18
Keyboard Wedge Defaults...................................2-18
RS232 Modifiers ........................................................2-19
RS232 Baud Rate................................................2-19
RS232 Word Length: Data Bits, Stop Bits,
and Parity .......................................................2-20
RS232 Handshaking............................................2-21
RS232 Timeout....................................................2-22
XON/XOFF ..........................................................2-22
ACK/NAK .............................................................2-23
Communication Timeout......................................2-23
NAK Retries .........................................................2-24
Support BEL/CAN in ACK/NAK ...........................2-25
RS232 Defaults....................................................2-25
NCR Modifiers ...........................................................2-25
NCR ACK/NAK ....................................................2-25
Block Check Character ........................................2-26
NCR Prefix...........................................................2-26
NCR Suffix ...........................................................2-26
NCR Prefix/Suffix.................................................2-27
NCR NOF (Not-on-File) Error ..............................2-27
Scanner to Bioptic Communication............................2-27

3
Scanner-Bioptic Packet Mode............................. 2-28
ACK/NAK............................................................. 2-28
Communication Timeout ..................................... 2-28
Chapter 3 - Input/Output Settings
Power Up Beeper........................................................ 3-1
Beep on BEL Character .............................................. 3-1
Good Read and Error Indicators ................................. 3-2
Beeper – Good Read ............................................ 3-2
Beeper Volume – Good Read ............................... 3-2
Beeper Pitch – Good Read ................................... 3-3
Beeper - Transmit Order ....................................... 3-3
Beeper Pitch – Error.............................................. 3-3
Beeper Duration – Good Read.............................. 3-4
Number of Beeps – Good Read............................ 3-4
Number of Beeps – Error ...................................... 3-4
LED Indicators............................................................. 3-6
LED Settings ......................................................... 3-6
LED Brightness ..................................................... 3-7
In-Stand and Out-Of-Stand Settings ........................... 3-7
In-Stand and Out-of-Stand Defaults...................... 3-8
Presentation Modes .............................................. 3-8
Manual Activation Mode........................................ 3-9
End Manual Activation After Good Read............... 3-9
Manual Activation Laser Timeout -
Button Settings............................................... 3-10
CodeGate®.......................................................... 3-11
Object Detection Mode........................................ 3-11
End Object Detection After Good Read .............. 3-12
Object Detection Laser Timeout.......................... 3-12
Object Detection Distance................................... 3-13
Character Activation Mode........................................ 3-13
Activation Character............................................ 3-13
End Character Activation After Good Read......... 3-14
Character Activation Laser Timeout.................... 3-14
Character Deactivation Mode.................................... 3-15

4
Deactivation Character ........................................3-15
Reread Delay.............................................................3-16
User-Specified Reread Delay ....................................3-16
Output Sequence Overview.......................................3-16
Require Output Sequence ...................................3-16
Output Sequence Editor ......................................3-17
To Add an Output Sequence ...............................3-17
Other Programming Selections............................3-17
Output Sequence Editor ......................................3-19
Sequence Timeout...............................................3-19
Sequence Match Beeper .....................................3-20
Partial Sequence .................................................3-20
Require Output Sequence ...................................3-20
No Read.....................................................................3-21
Chapter 4 - Data Editing
Prefix/Suffix Overview..................................................4-1
To Add a Prefix or Suffix:.......................................4-1
To Clear One or All Prefixes or Suffixes ................4-2
To Add a Carriage Return Suffix to
All Symbologies................................................4-3
Prefix Selections..........................................................4-3
Suffix Selections ..........................................................4-4
Transmit Alternate Extended ASCII Characters ..........4-4
Function Code Transmit ..............................................4-6
Communication Check Character................................4-6
Intercharacter, Interfunction, and
Intermessage Delays.................................................4-7
Intercharacter Delay ..............................................4-7
User Specified Intercharacter Delay ......................4-7
Interfunction Delay.................................................4-8
Intermessage Delay...............................................4-9
Chapter 5 - Data Formatting
Data Format Editor Introduction...................................5-1
To Add a Data Format .................................................5-1

5
Other Programming Selections ............................. 5-3
Terminal ID Table........................................................ 5-4
Data Format Editor Commands .................................. 5-4
Move Commands .................................................. 5-5
Search Commands................................................ 5-6
Miscellaneous Commands .................................... 5-7
Data Formatter ............................................................ 5-8
Data Format Non-Match Error Tone...................... 5-9
Primary/Alternate Data Formats................................ 5-10
Single Scan Data Format Change....................... 5-10
Chapter 6 - Symbologies
All Symbologies........................................................... 6-1
Message Length Description....................................... 6-2
Codabar ...................................................................... 6-3
Codabar Concatenation ........................................ 6-4
Code 39....................................................................... 6-7
Code 32 Pharmaceutical (PARAF)........................ 6-9
Full ASCII .............................................................. 6-9
Interleaved 2 of 5 ...................................................... 6-11
NEC 2 of 5................................................................. 6-13
Code 93..................................................................... 6-15
Straight 2 of 5 Industrial (three-bar start/stop) .......... 6-16
Straight 2 of 5 IATA (two-bar start/stop).................... 6-18
Matrix 2 of 5 .............................................................. 6-19
Code 11..................................................................... 6-21
Code 128................................................................... 6-24
ISBT 128 ................................................................... 6-25
GS1-128.................................................................... 6-31
Telepen ..................................................................... 6-33
UPC-A ....................................................................... 6-35
UPC-A/EAN-13 with Extended Coupon Code........... 6-38
UPC-A Number System 4 Addenda Required .... 6-38
UPC-A Number System 5 Addenda Required .... 6-39
UPC-E0 ..................................................................... 6-41
EAN/JAN-13.............................................................. 6-45

6
EAN-13 Beginning with 2 Addenda Required......6-46
EAN-13 Beginning with 290 Addenda Required..6-47
EAN-13 Beginning with 378/379
Addenda Required .........................................6-47
EAN-13 Beginning with 414/419
Addenda Required .........................................6-48
EAN-13 Beginning with 434/439
Addenda Required .........................................6-49
EAN-13 Beginning with 977 Addenda Required..6-50
EAN-13 Beginning with 978 Addenda Required..6-50
EAN-13 Beginning with 979 Addenda Required..6-51
ISBN Translate ....................................................6-53
ISSN Translate ....................................................6-54
EAN/JAN-8 ................................................................6-55
MSI ............................................................................6-58
Plessey Code.............................................................6-60
GS1 DataBar Omnidirectional ...................................6-62
GS1 DataBar Limited.................................................6-63
GS1 DataBar Expanded ............................................6-64
Trioptic Code .............................................................6-65
GS1 Emulation...........................................................6-65
Postal Codes .............................................................6-66
China Post (Hong Kong 2 of 5)............................6-66
Chapter 7 - Interface Keys
Keyboard Function Relationships................................7-1
Supported Interface Keys ............................................7-2
Chapter 8 - Utilities
To Add a Test Code I.D. Prefix to All Symbologies .....8-1
Show Software Revision..............................................8-1
Show Data Format.......................................................8-1
Test Menu....................................................................8-2
EZConfig-Scanning Introduction..................................8-2
Installing EZConfig-Scanning from the Web..........8-3

7
Chapter 9 - Serial Programming Commands
Conventions ................................................................ 9-1
Menu Command Syntax.............................................. 9-1
Query Commands ....................................................... 9-2
Responses ............................................................ 9-3
Serial Trigger Commands ........................................... 9-4
Read Time-Out...................................................... 9-4
Resetting the Standard Product Defaults.................... 9-4
Menu Commands........................................................ 9-6
Chapter 10 - Product Specifications
Voyager 1250g Scanner Product Specifications....... 10-1
Standard Cable Pinouts ............................................ 10-2
Keyboard Wedge................................................. 10-2
Serial Output ...................................................... 10-3
RS485 Output ..................................................... 10-4
USB..................................................................... 10-5
Chapter 11 - Maintenance
Repairs...................................................................... 11-1
Maintenance.............................................................. 11-1
Cleaning the Device: ........................................... 11-1
Inspecting Cords and Connectors....................... 11-1
Replacing Cables ...................................................... 11-1
Replacing an Interface Cable.............................. 11-2
Troubleshooting a Voyager Scanner......................... 11-2
Chapter 12 - Customer Support
Symbology Chart.........................................................A-1
ASCII Conversion Chart (Code Page 1252) ...............A-4
Code Page Mapping of Printed Barcodes...................A-6

8

Product Agency Compliance
USA
FCC Part 15 Subpart B Class B
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radi-
ate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio or television technician for
help.
If necessary, the user should consult the dealer or an experienced radio/
television technician for additional suggestions. The user may find the fol-
lowing booklet helpful: “Something About Interference.” This is available at
FCC local regional offices. Honeywell is not responsible for any radio or
television interference caused by unauthorized modifications of this equip-
ment or the substitution or attachment of connecting cables and equipment
other than those specified by Honeywell. The correction is the responsibil-
ity of the user.
Use only shielded data cables with this system. This unit has been tested
with cables less than 3 meters. Cables greater than 3 meters may not meet
class B performance.
Caution: Any changes or modifications made to this equipment not
expressly approved by Honeywell may void the FCC authorization to oper-
ate this equipment.
UL Statement
UL listed: UL60950-1, 2nd Edition.

This product is intended to be supplied by a Listed Direct Plug-In Power
unit marked "Class 2" or "LPS" and rated 5 Vdc - 5.2 Vdc, 1A.
Canada
Industry Canada ICES-003
This Class B digital apparatus complies with Canadian ICES-003. Opera-
tion is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Conformité à la règlementation canadienne
Cet appareil numérique de la Classe A est conforme à la norme NMB-003
du Canada. Son fonctionnement est assujetti aux conditions suivantes :
1. Cet appareil ne doit pas causer de brouillage préjudiciable.
2. Cet appareil doit pouvoir accepter tout brouillage reçu, y compris le
brouillage pouvant causer un fonctionnement indésirable.
C-UL Statement
C-UL listed: CSA C22.2 No.60950-1-07, 2nd Edition.
Europe
The CE marking indicates compliance to 2004/108/EC EMC Directive
with Standards EN55022 CLASS B, EN55024, EN61000-3-2,
EN61000-3-3. In addition, complies to 2006/95/EC Low Voltage Direc-
tive, when shipped with recommended power supply.
For further information please contact:
Honeywell Imaging & Mobility Europe BV
Nijverheidsweg 9-13
5627 BT Eindhoven
The Netherlands
Honeywell International Inc. shall not be liable for use of our product with
equipment (i.e., power supplies, personal computers, etc.) that is not CE
marked and does not comply with the Low Voltage Directive.
Waste Electrical and Electronic Equipment
Information
Honeywell complies with Directive 2002/96/EC OF THE EUROPEAN PAR-
LIAMENT AND OF THE COUNCIL of 27 January 2003 on waste electrical
and electronic equipment (WEEE).

This product has required the extraction and use of natural resources for its
production. It may contain hazardous substances that could impact health
and the environment, if not properly disposed.
In order to avoid the dissemination of those substances in our environment
and to diminish the pressure on the natural resources, we encourage you to
use the appropriate take-back systems for product disposal. Those sys-
tems will reuse or recycle most of the materials of the product you are dis-
posing in a sound way.
The crossed out wheeled bin symbol informs you that the product
should not be disposed of along with municipal waste and invites you to
use the appropriate separate take-back systems for product disposal.
If you need more information on the collection, reuse, and recycling sys-
tems, please contact your local or regional waste administration.
You may also contact your supplier for more information on the environ-
mental performances of this product.
Australia/NZ
C-Tick Statement
Conforms to AS/NZS 3548
Mexico
Conforms to NOM-019.
Russia
Gost-R certificate
Tawain
BSMI Standard: CNS13438, CNS 14336

International
Laser Safety Statement
This device has been tested in accordance with and complies with
IEC60825-1 ed2.0 and 21 CFR 1040.10 and 1040.11, except for deviations
pursuant to Laser Notice No. 50, dated June 24, 2007.
LASER LIGHT, DO NOT STARE INTO BEAM, CLASS 2 LASER PROD-
UCT, 1 mW MAX OUTPUT: 630-650nM.
Scanner Laser Beam
Wavelength 630 - 650 nm
Divergence < 1.5 mrad. per IEC 60825-1 worst case
Max power output < 1mw
Embedded Laser
Wavelength 630 - 650 nm
Divergence < 1.5 mrad, per IEC 60825-1 worst case
Max power output < 10 mw
Caution: Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
CB Scheme
Certified to CB Scheme IEC60950-1, Second Edition.
Solids and Water Protection
The Voyager 1250g has a rating of IP42, immunity of foreign particles and drip-
ping water.
Patents
For patent information, please refer to www.honeywellaidc.com/patents.
LASER LIGHT: DO NOT STARE INTO
BEAM. CLASS 2 LASER PRODUCT.
LASERSTRAHLUNG: NICHT IN DEN
STRAHL BLICKEN. LASER KLASSE 2.
LUMIERE LASER: NE PAS REGARDER
DANS LE FAISCEAU. APPAREIL A LASER.
DE CLASSE 2 630-650nm, 1mW.

Required Safety Label Locations
Part Number,
Serial Number
Laser Label,
and Revision
Information
location
Laser Safety
information
Laser Output

1 - 1
1
Getting Started
About This Manual
This User’s Guide provides installation and programming instructions for the
Voyager 1250g single-line laser scanner. Product specifications, dimensions,
warranty, and customer support information are also included.
Honeywell bar code scanners are factory programmed for the most common
terminal and communications settings. If you need to change these settings,
programming is accomplished by scanning the bar codes in this guide.
An asterisk (*) next to an option indicates the default setting.
Unpacking Your Device
After you open the shipping carton containing the product, take the following
steps:
• Check for damage during shipment. Report damage immediately to the
carrier who delivered the carton.
• Make sure the items in the carton match your order.
• Save the shipping container for later storage or shipping.
Connecting the Device
Connecting with USB
A scanner can be connected to the USB port of a computer.
1. Connect the appropriate interface cable to the scanner first, then to
the computer.

1 - 2
2. The scanner beeps.
3. Verify the scanner operation by scanning a bar code from the Sample
Symbols in the back of this manual.
The unit defaults to a USB PC Keyboard. Refer to page 2-5 for other USB
terminal settings.
For additional USB programming and technical information, refer to “USB
Application Note,” available at www.honeywellaidc.com.
Connecting with Keyboard Wedge
A scanner can be connected between the keyboard and PC as a “keyboard
wedge,” plugged into the serial port, or connected to a portable data termi-
nal in wand emulation or non decoded output mode. The following is an
example of a keyboard wedge connection:
1. Turn off power and disconnect the keyboard cable from the back of the
terminal/computer.
2. Connect the appropriate interface cable to the scanner and to the
terminal/computer.
3. Turn the terminal/computer power back on. The scanner beeps.
4. Verify the scanner operation by scanning a bar code from the Sample
Symbols in the back of this manual. The scanner beeps once.
The unit defaults to an IBM PC AT and compatibles keyboard wedge inter-
face with a USA keyboard. A carriage return (CR) suffix is added to bar
code data.
only if
power
supply is
included

1 - 3
Connecting with RS232 Serial Port
1. Turn off power to the terminal/computer.
2. Connect the appropriate interface cable to the scanner.
3. Plug the serial connector into the serial port on your computer.
Tighten the two screws to secure the connector to the port.
4. Once the scanner has been fully connected, power up the computer.
This interface programs 9600 baud, 8 data bits, no parity, and 1 stop bit.
only if
power
supply is
included

1 - 4
Connecting with RS485
A scanner can be connected for an IBM POS terminal interface.
1. Connect the appropriate interface cable to the device, then to the com-
puter.
2. Turn the terminal/computer power back on. The scanner beeps.
3. Verify the scanner operation by scanning a bar code from the Sample
Symbols in the back of this manual. The scanner beeps once.
For further RS485 settings, refer to RS485, page 2-2.
