Honeywell Hyperion 1300G User manual

™
Hyperion 1300g
General Purpose Handheld Linear Scanner
User’s Guide

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in speci-
fications and other information contained in this document without prior notice,
and the reader should in all cases consult HII to determine whether any such
changes have been made. The information in this publication does not repre-
sent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained
herein; nor for incidental or consequential damages resulting from the furnish-
ing, performance, or use of this material. HII disclaims all responsibility for the
selection and use of software and/or hardware to achieve intended results.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied, repro-
duced, or translated into another language without the prior written consent of
HII.
Web Address: www.honeywellaidc.com
2010-2014 Honeywell International Inc. All rights reserved.
Other product names or marks mentioned in this document may be trademarks
or registered trademarks of other companies and are the property of their
respective owners.
For patent information, refer to www.hsmpats.com.

i
Chapter 1 - Getting Started
About This Manual ...................................................... 1-1
Unpacking the Scanner............................................... 1-1
Connecting with USB .................................................. 1-1
Connecting with Keyboard Wedge.............................. 1-2
Connecting with RS-232 Serial Port............................ 1-3
Connecting with RS485............................................... 1-3
Reading Techniques ................................................... 1-4
Menu Bar Code Security Settings ............................... 1-5
Chapter 2 - Programming the Interface
Introduction ................................................................. 2-1
Programming the Interface - Plug and Play ................ 2-1
Keyboard Wedge................................................... 2-1
Laptop Direct Connect........................................... 2-1
RS232 Serial Port.................................................. 2-2
RS485 ................................................................... 2-2
OPOS Mode .......................................................... 2-3
USB IBM SurePos................................................. 2-4
USB PC or Macintosh Keyboard ........................... 2-5
USB HID POS ....................................................... 2-5
USB Serial Commands ............................................... 2-5
USB Serial Emulation............................................ 2-5
CTS/RTS Emulation .............................................. 2-6
ACK/NAK Mode..................................................... 2-6
Honeywell Bioptic Aux Port Configuration................... 2-6
Datalogic™ Magellan®Bioptic Aux Port Configuration2-7
Wincor Mode A............................................................ 2-7
Keyboard Country Layout ........................................... 2-8
Keyboard Mode Options ........................................... 2-18
ALT Mode............................................................ 2-18
Keyboard Style .................................................... 2-18
Keyboard Modifiers ............................................. 2-19
Table of Contents

ii
RS232 Modifiers ........................................................2-22
RS-232 Baud Rate...............................................2-22
RS-232 Word Length: Data Bits, Stop Bits, and Parity
2-23
RS-232 Handshaking.................................................2-24
RS232 Timeout....................................................2-27
XON/XOFF ..........................................................2-27
ACK/NAK .............................................................2-27
Scanner to Bioptic Communication............................2-28
Scanner-Bioptic Packet Mode .............................2-28
Chapter 3 - Input/Output Settings
Good Read Indicators..................................................3-1
Beeper – Good Read.............................................3-1
Beeper Volume – Good Read................................3-1
Beeper Pitch – Good Read....................................3-2
Beeper Duration – Good Read ..............................3-2
Beeper Pitch – Error ..............................................3-3
LED – Good Read .................................................3-3
Number of Beeps – Good Read ............................3-3
Good Read Delay ........................................................3-4
User-Specified Good Read Delay.......................... 3-4
Trigger Modes..............................................................3-5
Manual/Serial Trigger ............................................3-5
Automatic Trigger ..................................................3-5
Presentation Mode.................................................3-6
Continuous Illumination Mode (Manual Trigger only) .
3-6
Hands Free Time-Out ..................................................3-6
Reread Delay...............................................................3-7
User-Specified Reread Delay ................................3-8
Centering .....................................................................3-8

iii
Output Sequence Overview ...................................... 3-10
To Add an Output Sequence............................... 3-10
Other Programming Selections ........................... 3-10
Output Sequence Editor ...................................... 3-11
Output Sequence Editor ...................................... 3-13
Require Output Sequence................................... 3-13
Multiple Symbols ....................................................... 3-13
No Read .................................................................... 3-14
Video Reverse........................................................... 3-15
Chapter 4 - Data Editing
Prefix/Suffix Overview ................................................. 4-1
To Add a Prefix or Suffix ....................................... 4-2
To Clear One or All Prefixes or Suffixes................ 4-2
To Add a Carriage Return Suffix to All Symbologies4-
3
Prefix Selections.................................................... 4-3
Suffix Selections.................................................... 4-4
Function Code Transmit ........................................ 4-6
Intercharacter, Interfunction, and Intermessage Delays 4-
6
Intercharacter Delay .............................................. 4-7
User Specified Intercharacter Delay...................... 4-7
Interfunction Delay ................................................ 4-8
Intermessage Delay .............................................. 4-8
Chapter 5 - Data Formatting
Data Format Editor Introduction .................................. 5-1
To Add a Data Format........................................... 5-1
Other Programming Selections ............................. 5-2
Interface / Terminal ID Table....................................... 5-4

iv
Data Format Editor Commands ...................................5-4
Send Commands ...................................................5-4
Move Commands...................................................5-7
Search Commands ................................................5-8
Miscellaneous Commands...................................5-10
Data Format Editor ..............................................5-14
Data Formatter.....................................................5-14
Chapter 6 - Symbologies
Introduction .................................................................. 6-1

v
All Symbologies........................................................... 6-2
Codabar Start/Stop Characters ............................ 6-3
Codabar Check Character..................................... 6-4
Codabar Concatenation ........................................ 6-5
Codabar Message Length ..................................... 6-6
Code 39 Start/Stop Characters............................. 6-7
Code 39 Check Character..................................... 6-7
Code 39 Message Length ..................................... 6-8
Code 39 Append ................................................... 6-8
Full ASCII ............................................................ 6-10
Code 39 Code Page............................................ 6-10
Check Digit .......................................................... 6-11
Interleaved 2 of 5 Message Length..................... 6-12
Code 93 Message Length ................................... 6-13
Code 93 Code Page............................................ 6-13
Straight 2 of 5 Industrial Message Length........... 6-15
Straight 2 of 5 IATA Message Length ................. 6-16
Matrix 2 of 5 Message Length ............................. 6-17
Check Digits Required......................................... 6-18
Code 11 Message Length ................................... 6-19
ISBT 128 Concatenation ..................................... 6-19
Code 128 Message Length ................................. 6-20
Code 128 Code Page.......................................... 6-20
Code 128 Function Code Transmit ..................... 6-21
Telepen Output.................................................... 6-22
Telepen Message Length.................................... 6-23
UPC A Check Digit .............................................. 6-24
UPC A Number System....................................... 6-25
UPC A Addenda .................................................. 6-25
UPC A Addenda Required .................................. 6-26
UPC A Addenda Separator ................................. 6-26
UPC E0 and UPC E1 .......................................... 6-28
UPC E0 and UPC E1 Expand ............................. 6-29
UPC E0 and UPC E1 Addenda Required ........... 6-29
UPC E0 and UPC E1 Addenda Separator .......... 6-30
UPC E0 Check Digit ............................................ 6-30
UPC E0 Number System..................................... 6-31

vi
UPC E0 Addenda ................................................6-31
EAN/JAN 13 Check Digit .....................................6-32
EAN/JAN 13 Addenda .........................................6-33
EAN/JAN 13 Addenda Required..........................6-33
EAN/JAN 13 Addenda Separator ........................6-34
ISBN Translate ....................................................6-34
EAN/JAN 8 Check Digit .......................................6-35
EAN/JAN 8 Addenda ...........................................6-36
EAN/JAN 8 Addenda Required............................6-36
EAN/JAN 8 Addenda Separator ..........................6-37
MSI Check Character ..........................................6-37
MSI Message Length...........................................6-38
Plessey Message Length.....................................6-39
GS1 DataBar Expanded Message Length...........6-41
Korea Post Message Length ...............................6-43
Codablock F Message Length .............................6-44
Code 49 Message Length....................................6-45
Chapter 7 - Interface Keys
Keyboard Function Relationships ................................7-1
Supported Interface Keys ............................................7-2
Chapter 8 - Utilities
To Add a Test Code I.D. Prefix to All Symbologies .....8-1
Show Software Revision..............................................8-1
Show Data Format.......................................................8-1
Resetting the Standard Product Defaults ....................8-3
Chapter 9 - Serial Programming Commands
Conventions.................................................................9-1
Menu Command Syntax ..............................................9-1
Query Commands..................................................9-2
Concatenation of Multiple Commands...................9-2
Responses.............................................................9-2
Examples of Query Commands.............................9-3

vii
Trigger Commands ..................................................... 9-4
Resetting the Standard Product Defaults.................... 9-4
Menu Commands........................................................ 9-5
Chapter 10 - Product Specifications
Hyperion 1300g Product Specifications .................... 10-1
Standard Connector Pinouts ..................................... 10-2
Chapter 11 - Maintenance
Repairs...................................................................... 11-1
Maintenance.............................................................. 11-1
Cleaning the Device ............................................ 11-1
Inspecting Cords and Connectors....................... 11-1
Replacing the Interface Cable ............................. 11-2
Troubleshooting ........................................................ 11-2
Chapter 12 - Customer Support
Limited Warranty ....................................................... 12-1
Symbology Charts....................................................... A-1
Linear Symbologies............................................... A-1
Postal Symbologies............................................... A-3
ASCII Conversion Chart (Code Page 1252) ...............A-3
Lower ASCII Reference Table .................................... A-5
ISO 2022/ISO 646 Character Replacements .............. A-9

viii

1 - 1
1
Getting Started
About This Manual
This User’s Guide provides installation and programming instructions for the
Hyperion 1300g. Product specifications, dimensions, warranty, and customer
support information are also included.
Honeywell bar code scanners are factory programmed for the most common
terminal and communications settings. If you need to change these settings,
programming is accomplished by scanning the bar codes in this guide.
An asterisk (*) next to an option indicates the default setting.
Unpacking the Scanner
After you open the shipping carton containing the product, take the following
steps:
• Check for damage during shipment. Report damage immediately to the
carrier who delivered the carton.
• Make sure the items in the carton match your order.
• Save the shipping container for later storage or shipping.
Connecting with USB
A scanner can be connected to the USB port of a computer. The scanner emu-
lates the keyboard.
1. Connect the appropriate interface cable to the scanner first, then to the com-
puter.
2. The scanner beeps.

1 - 2
3. Verify the scanner operation by scanning a bar code from the Sample
Symbols in the back of this manual.
For additional USB programming and technical information, refer to the Honey-
well “USB Application Note,” available at www.honeywellaidc.com.
Connecting with Keyboard Wedge
A scanner can be connected between the keyboard and PC as a “keyboard
wedge,” where the scanner provides data output that is similar to keyboard
entries. The following is an example of a keyboard wedge connection:
1. Turn off power and disconnect the keyboard cables from the back of the ter-
minal/computer.
2. Connect the appropriate interface cable to the scanner and to the terminal/
computer.
3. Turn the terminal/computer power back on. The scanner beeps.
4. Verify the scanner operation by scanning a bar code from the Sample
Symbols in the back of this manual. The scanner beeps once.
The unit defaults to an IBM PC AT and compatibles keyboard wedge interface
with a USA keyboard. A carriage return (CR) suffix is added to bar code data.
only if
power
supply is
included

1 - 3
Connecting with RS-232 Serial Port
1. Turn off power to the terminal/computer.
2. Connect the appropriate interface cable to the scanner.
3. Plug the serial connector into the serial port on your computer. Tighten the
two screws to secure the connector to the port.
4. Once the scanner has been completely connected, power up the computer.
5. This interface programs 38,400 baud, 8 data bits, no parity, and 1 stop bit.
Connecting with RS485
A scanner can be connected for an IBM POS terminal interface.
only if
power
supply is
included

1 - 4
1. Connect the appropriate interface cable to the device, then to the computer.
2. Turn the terminal/computer power back on. The scanner beeps.
3. Verify the scanner operation by scanning a bar code from the Sample
Symbols in the back of this manual. The scanner beeps once.
4. For further RS485 settings, refer to RS485 on page 2-2.
Reading Techniques
The scanner has a bright red aiming beam that corresponds to its horizontal
field of view. The aiming beam should be centered horizontally over the bar
code; it will not read if the aiming beam is in any other direction.
Good Technique
Bad Technique
Bad Technique

1 - 5
The best focus point for reading most code densities is about 5 inches (12.7 cm)
from the unit. To read a single bar code or multiple bar codes (on a page or on
an object), hold the scanner at an appropriate distance from the target, pull the
trigger, and center the aiming beam on the bar code.
Menu Bar Code Security Settings
Honeywell scanners are programmed by scanning menu bar codes or by send-
ing serial commands to the scanner. If you want to restrict the ability to scan
menu codes, you can use the Menu Bar Code Security settings. Contact Tech-
nical Support (seeCustomer Support on page 12-1) for further information.
Setting Custom Defaults
You have the ability to create a set of menu commands as your own, custom
defaults. To do so, scan the Set Custom Defaults bar code below before each
menu command or sequence you want saved. If your command requires scan-
ning numeric codes from the back cover, then a Save code, that entire
sequence will be saved to your custom defaults. Scan the Set Custom
Defaults code again before the next command you want saved to your custom
defaults.
You may have a series of custom settings and want to correct a single setting.
To do so, just scan the new setting to overwrite the old one. For example, if you
had previously saved the setting for Beeper Volume at Low to your custom
defaults, and decide you want the beeper volume set to High, just scan the Set
Custom Defaults bar code, then scan the Beeper Volume High menu code.
The rest of the custom defaults will remain, but the beeper volume setting will be
updated.
Resetting the Custom Defaults
If you want the custom default settings restored to your scanner, scan the Acti-
vate Custom Defaults bar code below. This resets the scanner to the custom
default settings. If there are no custom defaults, it will reset the scanner to the
factory default settings. Any settings that have not been specified through the
custom defaults will be defaulted to the factory default settings.
Set Custom Defaults
Activate Custom Defaults

1 - 6
The Serial Programming Commands starting on page 9-1 lists the factory
default settings for each of the commands (indicated by an asterisk (*) on the
programming pages).

2 - 1
2
Programming the Interface
Introduction
This chapter describes how to program your system for the desired interface.
Programming the Interface - Plug and Play
Plug and Play bar codes provide instant scanner set up for commonly used
interfaces.
Note: After you scan one of the codes, power cycle the host terminal to have
the interface in effect.
Keyboard Wedge
If you want your system programmed for an IBM PC AT and compatibles key-
board wedge interface with a USA keyboard, scan the bar code below. Key-
board wedge is the default interface.
Note: The following bar code also programs a carriage return (CR) suffix.
Laptop Direct Connect
For most laptops, scanning the Laptop Direct Connect bar code allows opera-
tion of the scanner in parallel with the integral keyboard. The following Laptop
Direct Connect bar code selects terminal ID 03, programs a carriage return
(CR) suffix and turns on Emulate External Keyboard (page 2-19).
IBM PC AT and Compatibles with CR Suffix
Laptop Direct Connect
with CR suffix

2 - 2
RS232 Serial Port
The RS232 Interface bar code is used when connecting to the serial port of a
PC or terminal. The following RS232 Interface bar code also programs a car-
riage return (CR) and a line feed (LF) suffix, baud rate, and data format as indi-
cated below.
RS485
Scan one of the following “Plug and Play” codes to program the scanner for an
IBM POS terminal interface.
Note: After scanning one of these codes, you must power cycle the cash
register.
Option Setting
Baud Rate 38,400 bps
Data Format 8 data bits, no parity bit, 1 stop bit
RS232 Interface
IBM Port 5B Interface
IBM Port 9B
HHBCR-1 Interface
IBM Port 17 Interface
IBM Port 9B
HHBCR-2 Interface

2 - 3
Each bar code above also programs the following suffixes for each symbology:
* Suffixes programmed for Code 128 with IBM 4683 Port 5B, IBM 4683 Port 9B
HHBCR-1, and IBM 4683 Port 17 Interfaces
**Suffixes programmed for Code 128 with IBM 4683 Port 9 HHBCR-2 Interface
OPOS Mode
The following bar code configures your scanner for OPOS (OLE for Retail Point
of Sale) by modifying the following OPOS-related settings:
Symbology Suffix Symbology Suffix
EAN 8 0C Code 39 00 0A 0B
EAN 13 16 Interleaved 2 of 5 00 0D 0B
UPC A 0D Code 128 * 00 0A 0B
UPC E 0A Code 128 ** 00 18 0B
Option Setting
Interface RS232
Baud Rate 38400
RS232
Handshaking
Flow Control, No Timeout
XON/XOFF Off
ACK/NAK Off
Data Bits, Stop
Bits, and Parity
8 Data, 1 Stop, Parity None
Prefix/Suffix Clear All Prefixes and Suffixes
Add Code ID and AIM ID Prefix
Add CR Suffix
Intercharacter
Delay
Off
Symbologies Enable UPC-A with check digit and number system
Enable UPC-E0 with check digit
Enable EAN/JAN-8 with check digit
Enable EAN/JAN-13 with check digit
Enable Code 128
Enable Code 39
Enable OPOS with automatic disable off

2 - 4
USB IBM SurePos
Scan the following “Plug and Play” codes to program the scanner for an IBM
SurePos (USB handheld scanner) interface.
Note: After scanning the code below, you must power cycle the cash register.
The bar code above also programs the following suffixes for each symbology:
Symbology Suffix Symbology Suffix
EAN 8 0C Code 39 00 0A 0B
EAN 13 16 Interleaved 2 of 5 00 0D 0B
UPC A 0D Code 128 00 18 0B
UPC E 0A Code 39 00 0A 0B
OPOS Mode
USB IBM SurePos
(USB Handheld Scanner)
Interface
USB IBM SurePos
(USB Tabletop Scanner)
Interface
