Honeywell POWER PRESENTER PLUS 64/128 User manual

POWER PRESENTER PLUS 64/128
Part # PPRF64/128
Part # PPRF64/128Part # PPRF64/128
Part # PPRF64/128
Instruction Manual
The POWER PRESENTER PLUS 64/128 remote is a handy, compact presentation tool. It allows the
user to control slides in most presentation or slide show applications while storing up to 64 or
128MB of data on the internal Flash Memory Drive. The POWER PRESENTER PLUS remote includes
a built in laser pointer. The kit includes: 64 or 128MB of Flash Random Access Memory (RAM), a
remote with laser pointer (battery included), a receiver, a USB cable, one USB 1.1 hub port (used for
connecting one additional USB device to your PC), and a nylon carrying case. The POWER
PRESENTER PLUS uses radio frequency technology, so there is no need to point the remote at the
receiver to control your slides. The maximum operating distance between the remote and the receiver
is 100 feet, depending upon operating environment.
System Requirements
The system requires USB 1.1 or greater compatibility. The POWER PRESENTER PLUS 64/128 is
“plug and play” compatible with MAC OS 10 or higher and Windows XP or higher.
Connecting the Receiver to the Computer
For maximum range, the receiver should be placed as far away as possible from any electronic
devices.
1) Turn on your computer and let it fully boot-up (start-up).
2) Plug the Type-A end of the USB cable into the USB port on your computer (using the rectangular
shaped end of the USB cable).
3) Plug the Type-B end of the USB cable into the USB port on the receiver (using the square
shaped end of the USB cable).
Note:
Note:Note:
Note:
The Type-A USB port on the receiver is used for connecting additional USB devices to your computer
through your Power Presenter Plus receiver unit.
4) The computer should automatically recognize the receiver as a new hardware after 5 to 15
seconds, depending on the computer. Follow the instructions for installing new hardware (you
may need to load the necessary USB driver from your operating system disk). Once your
computer has installed the receiver as new hardware it will not need to run through the same
steps again. Next time you plug the receiver into the same computer, it will take about 5 to 10
seconds to recognize the receiver. During the 5 to 10 seconds there may be little or no
indication that the computer is communicating with the receiver.

5) The USB memory drive should be recognized in the same process as above. If a driver is
needed, please visit our website www.powerremote/resources_drivers.htm to download the
required drivers.
Using the USB Flash Drive
1) The USB Flash drive will be displayed on your desktop as a drive under Windows and the Mac
OS. If the Flash Device is not automatically displayed you may need to load a USB Flash driver.
This driver is available at our website www.powerremote/resources_drivers.htm.
2) Use the drive just as you would an internal or external drive. For presentations you may run
them from your Flash drive or from the computer’s hard disk drive. In some cases, the
presentation might run faster if the file is saved to the computer’s internal hard disk drive for the
presentation.
Connecting Another USB Device
The USB Type-A, female port (rectangular shaped USB female connector) on your POWER
PRESENTER PLUS 64 or 128 receiver is connected to an internal USB hub port. This port will allow
you to connect other USB devices to your computer through your POWER PRESENTER PLUS 64 or
128 receiver unit. To use this port, simply connect a USB device with a Type-A connector into the
port.
Note:
Note:Note:
Note:
USB 2.0 devices will work at USB 1.1 speeds when connected to this port as the POWER PRESENTER
PLUS is a USB 1.1 compatible device.
Training the Remote to the Receiver
The remote has been trained into the receiver at the factory. The receiver can support up to 7 total
remotes.
To train a new remote, or re
To train a new remote, or reTo train a new remote, or re
To train a new remote, or re-
--
-train an existing remote, into the receiv
train an existing remote, into the receivtrain an existing remote, into the receiv
train an existing remote, into the receiver:
er:er:
er:
1) Press and release the program button on the receiver. The LED lights solid.
2) Press the advance button (the largest button) on the remote three times. On the third press, the
LED will turn off, indicating the remote has been successfully trained.
To dele
To deleTo dele
To delete all of the remotes from the receiver:
te all of the remotes from the receiver:te all of the remotes from the receiver:
te all of the remotes from the receiver:
1) Press and hold the program button on the receiver. The LED will light for 3 seconds then go out.
2) Release the program button.
Using the Remote
After connecting the receiver properly, simply start
your presentation or slide show software, put it in
slide show mode, and press the remote’s larger
advance button to advance the slides and the smaller
reverse button to go back to the previous slide. Press
the smallest button to activate the laser pointer.
AVOID EXPOSURE - LASER RADIATION
EMITTED FROM THIS APERATURE
LASER
ACTIVATION
BUTTON
REVERSE
BUTTON
ADVANCE
BUTTON

How to Change the Remote Keystrokes
The Power Presenter Plus comes preprogrammed to use the commands page-up/advance (remote –
top button), page-down/reverse (remote-middle button) and b for Blank screen (remote top and
middle buttons simultaneously). For other applications, the user may wish to change the keystrokes.
The Power Presenter has a predetermined list of available keystrokes.
Setup:
Setup:Setup:
Setup:
1) With your computer fully logged-in and running. Plug the USB into the back of your computer.
2) Plug the Power Presenter Base/Receiver into the cable.
3) Launch a text editing software application (i.e. MS Word).
4) Open a blank document and display it as the front window of your monitor.
Program Keys:
Program Keys:Program Keys:
Program Keys:
1) On the back of the Base/Receiver, press
the Program Button three (3) times.
Keyboard commands will begin
appearing on your open text window
2) When the command you need for your
software, is displayed, immediately
press the remote button that you wish to
match to that keystroke.
Notes:
Notes:Notes:
Notes:
(1) For Power Point the normal commands are:
• Page Down – Top Button
• Page Up – Middle Button
• b (blank screen) – Top and Middle Buttons pressed together
(2) For Media Shout the normal commands are:
• F10 – Top Button
• F9 – Middle Button
• F6 (blank screen) – Top and Middle Buttons pressed together
3) When a command is recognized, the LED on the Base / Receiver will flash and the scrolling text
will pause. The scrolling will continue until all three button command options (top, middle, both)
are programmed
Note:
Note:Note:
Note: If you do not wish to use all three keystroke commands, simply unplug your Base/Receiver from the
cable to stop the process.
Test Remote:
Test Remote:Test Remote:
Test Remote:
1) Close your text software.
2) Test your remote to confirm that the proper commands are functional.

Changing the Battery in the Remote
1) There are two “alignment dots” on the back of the remote case and one “alignment dot” on the
battery cover. Insert a quarter into the slot on the battery cover and turn counter clockwise until
the dot on the battery cover is lined up with the LEFT dot on the remote case. The battery cover
will release.
2) Pull the battery out of the holder. Dispose of the battery in an environmentally proper manner.
3) Insert the new battery with the positive side facing you. The 3.0 volt lithium battery number is
CR2032.
4) Make sure that the “alignment dot” on the battery cover is lined up with the LEFT “alignment
dot” on the remote case as you replace the battery cover. Then turn clockwise until the dot on
the battery cover is lined up with the RIGHT dot on the remote case.
Battery Replacement
Battery ReplacementBattery Replacement
Battery Replacement
It is recommended that you always carry a spare battery.
It is recommended that you always carry a spare battery.It is recommended that you always carry a spare battery.
It is recommended that you always carry a spare battery.

Product Specifications
Transmitter:
Transmitter:Transmitter:
Transmitter:
• Range: Up to 100 feet, depending upon
operating environment
• Dimensions: 2.6” (66mm)L x 1.5”(38mm)W x
0.5”(13mm)H
• Weight: 1 oz (24 g) with batteries
•RadioFrequency: 433.92 MHz
• Laser: Diode Laser, 5mW max output at
650NM, Class IIIa
• Power: One 3.0 V CR2032 lithium battery
• Battery life: 1 year under normal operation
Receiver:
Receiver:Receiver:
Receiver:
• Interface: USB port
• Memory: 64MB or 128MB Flash RAM
• Dimensions: 2.6”(66mm)L x 3.4” (86mm)W x
1.2” (31mm)H
• Weight: 2 oz (59g) excluding cable
Cable:
Cable:Cable:
Cable:
• 3ft USB cable (A/B)
General:
General:General:
General:
• Warranty: 1 year, limited
• Compliance: FCC Part 15; Class B for U.S.,
Industry Canada RSS-210, FDA 21 CFR 1040
Laser Pointer Information
Due to the potential of radiation exposure from the laser, the Food and Drug
Administration (FDA) requires that any user of this product report and return a
defective unit to the manufacturer. DO NOT point the laser light directly into the
eye area or attempt to open or disassemble this product for any reason.
Tampering with the laser product may be hazardous and will automatically VOID
the manufacturers warranty.
This product fully complies with FDA 21 CFR 1040.10 and 1040.11.
Troubleshooting
“I’m pressing the advance button but the slides are not advancing.”
“I’m pressing the advance button but the slides are not advancing.”“I’m pressing the advance button but the slides are not advancing.”
“I’m pressing the advance button but the slides are not advancing.”
1) Check the cable connections.
2) Verify that the LED on the remote comes on solid when the advance or reverse button is pushed
and that the laser pointer is at full brightness when the laser button is pushed. If not, replace the
battery.
3) Verify that the transmitter has been trained to the receiver. Follow the instructions under
“Training the Remote to the Receiver”.
4) Verify that the correct operating system driver is loaded on your computer. Try reloading the
driver, or try unplugging the receiver, waiting 10 seconds, and then plugging it back in.
“The LED on the remote flashes or does not turn on when I push the advance or reverse button, or
“The LED on the remote flashes or does not turn on when I push the advance or reverse button, or“The LED on the remote flashes or does not turn on when I push the advance or reverse button, or
“The LED on the remote flashes or does not turn on when I push the advance or reverse button, or
the l
the lthe l
the laser pointer is dim or does not work when the laser button is pushed.”
aser pointer is dim or does not work when the laser button is pushed.”aser pointer is dim or does not work when the laser button is pushed.”
aser pointer is dim or does not work when the laser button is pushed.”
1) The battery is dead. Replace the battery.
“The internal Flash Drive does not mount on my computer.”
“The internal Flash Drive does not mount on my computer.”“The internal Flash Drive does not mount on my computer.”
“The internal Flash Drive does not mount on my computer.”
1) Verify USB compatibility on your computer.
2) Download and install the needed Flash Driver (see section Using the USB Flash Drive).
“I’m getting a USB 2.0 hub error.”
“I’m getting a USB 2.0 hub error.”“I’m getting a USB 2.0 hub error.”
“I’m getting a USB 2.0 hub error.”
1) The USB device you are plugging into the Power Presenter hub port is a USB 2.0 device. Since
the Power Presenter is a USB 1.1 device, your USB 2.0 product will only work at the slower 1.1
speed. This should not cause any problems for your USB 2.0 device, but please check your
users manual for that device to confirm.

FCC Statement
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interferences that may cause undesired operation.
FCC ID: Transmitter: KFR-LSRTSReceiver: KFR-LSRRFS
Federal Communications Commission (FCC) Part 15 Statement
This equipment has been tested to FCC requirements and has been found acceptable for use.
The FCC requires the following statement for your information:
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict
accordance with the manufacturer’s instructions, may cause interference to radio and television reception. It has
been type tested and found to comply with the limits for a Class B computing device in accordance with the
specifications in Part 15 of FCC Rules, which are designed to provide reasonable protection against such
interference in a residential installation. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause interferences to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• If using an indoor antenna, have a quality outdoor antenna installed.
• Reorient the receiving antenna until interference is reduced or eliminated
• Move the receiver away from the control/communicator.
• Move the antenna leads away from any wire runs to the control/communicator.
• Plug the control/communicator into a different outlet so that it and the receiver are on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/television technician for additional
suggestions. The user or installer may find the following booklets prepared by the Federal Communications
Commission helpful:
“Interference Handbook” This booklet is available from the U.S. Government Printing Office, Washington, DC
20402. The user shall not make any changes or modifications to the equipment unless authorized by the
installation instructions or User’s Manual. Unauthorized changes or modifications could void the user’s authority
to operate the equipment.

Limited Warranty
Honeywell International Inc. (“Seller”), 12800 Brook Printer Place, Poway, California 92064, warrants its product
to be in conformance with its own plans and specifications and to be free from defects in material and
workmanship under normal use and service for 12 months from the date of original purchase. Seller’s obligation
shall be limited to repairing or replacing, at its option, free of charge for materials or labor, any product that is
proved not in compliance with Seller’s specifications or proves defective in materials or workmanship under
normal use and service. Seller shall have no obligation under this Limited Warranty or otherwise if the product is
altered or improperly repaired or serviced by anyone other than Honeywell International Inc.
When returning a product, a Return Material Authorization number (RMA#) is required and must be obtained
from Honeywell International Inc. The RMA# must be clearly displayed on the outside of the shipping carton and
the product must be accompanied by documentation that explains the problem and provides proof of date of
purchase.

This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions.
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may
cause undesired operation.
Per FCC 15.21, you are cautioned that changes or modifications not expressly approved by
the part responsible for compliance could void the user’s authority to operate the equipment.

12800 Brook Printer Place
12800 Brook Printer Place12800 Brook Printer Place
12800 Brook Printer Place
Poway, California 92064
Poway, California 92064Poway, California 92064
Poway, California 92064
Copyright © 2004 Honeywell International Inc.
Copyright © 2004 Honeywell International Inc.Copyright © 2004 Honeywell International Inc.
Copyright © 2004 Honeywell International Inc.
www.powerremote.com
www.powerremote.comwww.powerremote.com
www.powerremote.com
