Honeywell 26079 User manual

Dolphin 75e Wearable Solution
with Windows Embedded 8.1 Handheld
User’s Guide

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this
document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been
made. The information in this publication does not represent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages
resulting from the furnishing, performance, or use of this material. HII disclaims all responsibility for the selection and use of
software and/or hardware to achieve intended results.
This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document
may be photocopied, reproduced, or translated into another language without the prior written consent of HII.
Copyright 2016 Honeywell International Inc. All rights reserved.
Web Address: www.honeywellaidc.com
Other product names or marks mentioned in this document may be trademarks or registered trademarks of other companies
and are the property of their respective owners.
For patent information, please refer to www.hsmpats.com.

i
Contact Customer Support
Product Service and Repair ...................................................................................................v
Limited Warranty .................................................................................................................... v
Send Feedback ...................................................................................................................... v
Chapter 1 - Getting Started
Overview ..............................................................................................................................1-1
What You Need....................................................................................................................1-1
Belt Mount with Voice.....................................................................................................1-1
Arm Mount with Tethered Ring Scanner ........................................................................1-1
Arm Mount with Voice and Tethered Ring Scanner .......................................................1-1
About this Guide ..................................................................................................................1-1
Additional Documents ....................................................................................................1-1
Before You Begin.................................................................................................................1-2
Minimum Firmware Requirements .................................................................................1-2
Battery............................................................................................................................1-2
Chapter 2 - Installing and Mounting
Arm Mount Applications .......................................................................................................2-1
Install the Terminal in the Arm Mount Sled ....................................................................2-1
Mount the Arm Band and Attach the Terminal...............................................................2-3
Belt Mount Applications .......................................................................................................2-5
Install the Terminal in the Belt Mount Sled.....................................................................2-5
Attach the Sled to the Belt Clip ......................................................................................2-7
Attach the Headset (Optional)..............................................................................................2-7
Adjusting Headset / Microphone and Securing Cable....................................................2-8
Connect the Ring Scanner (Optional) ..................................................................................2-9
Attaching the Ring to your Finger...................................................................................2-9
Trigger Rotation .............................................................................................................2-9
Chapter 3 - About the Hardware
About the Terminal...............................................................................................................3-1
Turn Power On...............................................................................................................3-1
Turn Power Off...............................................................................................................3-1
Sleep Mode (Suspend Mode) ........................................................................................3-1
Restart the Terminal.......................................................................................................3-1
Reset the Terminal.........................................................................................................3-2
About the Arm Mount Sled...................................................................................................3-3
Arm Mount Features ......................................................................................................3-3
Terminal Features Not Used ..........................................................................................3-3
Remove the Terminal from the Arm Mount Sled............................................................3-4
About the Belt Mount Sled ...................................................................................................3-5
Belt Mount Features.......................................................................................................3-5
Terminal Features Not Used ..........................................................................................3-5
Remove the Terminal from the Belt Mount Sled ............................................................3-6
Table of Contents

ii
About the 8620 Ring Scanner ............................................................................................. 3-7
Ring Scanner Features.................................................................................................. 3-7
Eject the Ring Scanner.................................................................................................. 3-8
Remove the Ring Strap/C-Ring ..................................................................................... 3-8
Replace the Ring Strap/C-Ring ..................................................................................... 3-9
Remove the Trigger ....................................................................................................... 3-9
Replace the Trigger ..................................................................................................... 3-10
Battery Specifications ........................................................................................................ 3-11
Storing Batteries .......................................................................................................... 3-11
Guidelines for Battery Pack Use and Disposal ............................................................ 3-11
Replace the Battery ........................................................................................................... 3-12
Chapter 4 - Using the Ring Scanner
Overview.............................................................................................................................. 4-1
Minimum Terminal Software Requirements................................................................... 4-1
Updating the Terminal Software .................................................................................... 4-1
Decoding Bar Codes ........................................................................................................... 4-2
Aiming Beam ................................................................................................................. 4-2
Using Scan Demo to Decode a Bar Code ........................................................................... 4-2
Automatic Scanning....................................................................................................... 4-3
Continuous Scanning..................................................................................................... 4-3
Configuring the Scan Demo Application.............................................................................. 4-4
Scan Settings................................................................................................................. 4-4
Symbology Settings....................................................................................................... 4-4
Profiles........................................................................................................................... 4-5
Advanced Ring Scanner Configuration ............................................................................... 4-5
Custom Profiles ............................................................................................................. 4-5
Microsoft POS APIs....................................................................................................... 4-6
Upgrading Ring Scanner Firmware ..................................................................................... 4-6
Installing EZConfig-Scanning from the Web.................................................................. 4-6
Appendix A - Ring Scanner Specifications
8620 Ring Scanner Specifications.......................................................................................A-1
Supported Bar Code Symbologies ...............................................................................A-2
Field of View ..................................................................................................................A-2
Depth of Field ................................................................................................................A-2
Required Safety Labels .......................................................................................................A-3
Laser Label....................................................................................................................A-3
Laser Aperture Location ......................................................................................................A-3
Appendix B - Coding for POS Barcode Applications
Introduction..........................................................................................................................B-1
Suggested Application Structure .........................................................................................B-1
Suspending and Resuming the Application.........................................................................B-1
Switching Between Applications..........................................................................................B-1

iii
Connecting and Disconnecting External Scanners .............................................................B-1
DeviceAdded()...............................................................................................................B-1
DeviceRemoved() ..........................................................................................................B-2
DeviceUpdated()............................................................................................................B-2
DeviceEnumCompleted()...............................................................................................B-2
DetectorStopped() .........................................................................................................B-2

iv

v
Contact Customer Support
To search our knowledge base for a solution or to log in to the Technical Support portal and report a problem, go to
www.hsmcontactsupport.com.
For our latest contact information, see www.honeywellaidc.com/locations.
Product Service and Repair
Honeywell International Inc. provides service for all of its products through service centers throughout the world. To find
your service center, go to www.honeywellaidc.com and select Support. Contact your service center to obtain a Return
Material Authorization number (RMA #) before you return the product.
To obtain warranty or non-warranty service, return your product to Honeywell (postage paid) with a copy of the dated pur-
chase record.Limited Warranty
Limited Warranty
For warranty information, go to www.honeywellaidc.com and click Resources > Warranty.
Send Feedback
Your feedback is crucial to the continual improvement of our documentation. To provide feedback about this manual, con-
tact the Honeywell Technical Communications department at ACSHSMTechnicalCommu[email protected].

vi

1 - 1
1
Getting Started
Overview
The Dolphin 75e Wearable Solution consists of a Dolphin 75e terminal, a wearable sled, a ring scanner (optional), and/or head-
set (optional). The wearable sled is available in one of the following configurations:
• Arm Mount Sled (page 3-3)
• Belt Mount Sled (page 3-5)
The terminal is available in either standard or extended battery versions. The Dolphin 75e Wearable Solution is IP 54 rated.
What You Need
There are several use cases for the Honeywell Wearable Solution. The examples below indicate the typical items used in sam-
ple use cases. The Dolphin 75e terminal and accessories may be packaged separately from the other wearable accessories.
Belt Mount with Voice
• Dolphin 75e
• Belt mount sled
• Belt mount clip
• Headset adapter cable
• Headset
Arm Mount with Tethered Ring Scanner
• Dolphin 75e
• Arm mount sled
• Armband
• Tethered Ring Scanner
Arm Mount with Voice and Tethered Ring Scanner
• Dolphin 75e
• Arm mount sled
• Armband
• Audio end cap (to replace standard end cap)
• Headset adapter cable
• Headset
• Tethered Ring Scanner
About this Guide
This guide provides assembling and mounting instructions as well as information about terminal setup and configuration as a
wearable solution. Daily use instructions are included. This document describes only those features of the Dolphin 75e unique
to the Wearable Solution.
Additional Documents
This guide is intended to supplement the following documents available at www.honeywellaidc.com:
• Dolphin 75e with Windows Embedded Handheld 8.1 User’s Guide
• 8620 Ring Scanner Command Reference Manual

1 - 2
Before You Begin
Here is a list of things you should check before you begin.
Minimum Firmware Requirements
The minimum software requirements for the terminal (Settings:
• Software version 57.1.2.160 or higher
To update your software see page 4-1.
Battery
The Dolphin 75e is designed for use with battery part numbers BAT-STANDARD-02 (Li-ion 3.7 V, 6.179 watt hour) and BAT-
EXTENDED-02 (Li-ion 3.7 V, 12.358 watt hour) manufactured for Honeywell International Inc.
We recommend use of Honeywell Li-ion battery packs. Use of any non-Honeywell battery may result in damage not
covered by the warranty.
Install the Battery
1. Unlock and remove battery door.
2. Insert the battery.
!

1 - 3
3. Close battery door. Apply pressure to the edges of the battery door to ensure the door is properly closed. Engage
the door lock.
Charge the Battery
For best results, use a freshly charged battery for each shift. For information on charging the terminal and the charge
bases that are available, see the User’s Guide for your terminal.

1 - 4

2 - 1
2
Installing and Mounting
Arm Mount Applications
This section describes how to install and mount the arm mount configuration.
Install the Terminal in the Arm Mount Sled
1. If the end cap is installed on the sled, slide the lock down to release the end
cap.
2. Push up on the right side (the side with the lock) of end cap. Do not attempt to remove the end cap
without sliding the lock first!
3. Pull the end cap off the sled.
4. Make sure the USB door is closed. Rotate the door on the right side of the Dolphin 75e to close.
5. Press until the door is flush with the side of the terminal.
Note: If the door is not flush, it may be difficult to remove the terminal from the sled.

2 - 2
6. Slide the Dolphin 75e into the sled.
7. If using the audio end cap, make sure audio jack door is open. Pull the rubber door out and rotate
the door 180º as shown to prevent damage.
8. If using the audio end cap, make sure the audio cable is not installed in the end cap.
9. Slide the end cap straight onto the sled until it clicks in place.
10. Slide the lock closed to secure the end cap.
Standard End
Cap
Audio End Cap

2 - 3
Mount the Arm Band and Attach the Terminal
It is recommended that each user have their own arm band for hygiene reasons. The arm band can be washed between
uses. Be sure to remove the sled from the arm band before washing the arm band.
Note: The illustrations in this procedure assume the sled has not yet been mounted to the arm band. However the sled can
be mounted to the arm band before the user puts the arm band on.
1. If the arm band straps are not fed through the buckles, feed them through to form a loop before placing the arm band on
the arm. For ease of installation, the straps should be kept looped through the buckles.
2. Place and balance the arm band assembly on the top of the desired arm with the buckles toward the outside of the arm.
3. Using the other hand, pull each strap end straight away from the arm until the
arm band is comfortably secured.
4. Ensure the latch on each buckle is through a hole in the strap.
1. If there is excess strap length:
• Loop the excess strap behind the
horns on the sled, as shown, or

2 - 4
• Trim the straps to length and use the provided clips to terminate the strap end.
2. Align the sled assembly with the arm band and press
on the sled until it latches onto the arm band. Be sure
to align tabs on the back of sled with the notches on
the arm band. The end of the sled with the ring
scanner connector must face toward the hand.
3. If using the ring scanner (see Connect the Ring
Scanner (Optional) on page 2-9.), slide the ring
scanner over the index finger and adjust the strap (if
applicable) for a comfortable fit.
4. To remove the sled assembly, unbuckle and loosen the straps. It is not necessary to remove the strap from the buckle.

2 - 5
Belt Mount Applications
This section describes how to install and mount the belt mount configuration.
Install the Terminal in the Belt Mount Sled
1. If the end cap is installed on the sled, slide the lock down to release the end
cap.
2. Push up on the right side (the side with the lock) of end cap. Do not attempt to remove the end cap
without sliding the lock first!
3. Pull the end cap off the sled.
4. Make sure the USB door is closed. Rotate the door on the right side of the Dolphin 75e to close.
5. Press until the door is flush with the side of the terminal.
Note: If the door is not flush, it may be difficult to remove the terminal from the sled.

2 - 6
6. Slide the Dolphin 75e into the sled.
7. Make sure audio jack door is open. Pull the rubber door out and rotate the door 180º as
shown to prevent damage.
8. Make sure the audio cable is not installed in the end cap.
9. Slide the end cap straight onto the sled until it clicks in place.
10. Slide the lock closed to secure the end cap.

2 - 7
Attach the Sled to the Belt Clip
Attach the Headset (Optional)
1. Align the sled assembly with the belt clip and press on the sled until it latches onto
the belt clip. Be sure to align tabs on the back of sled with the notches on the belt
clip.
2. Slide the clip over a belt to wear the assembly.
1. Make sure the audio jack door is open as shown in the previous section.
2. Slide the 3.5mm audio connector into the end cap.
3. Attach the quick disconnect end of the headset adapter cable to the
headset’s cable.

2 - 8
Adjusting Headset / Microphone and Securing Cable
The headset consists of an earpiece, a microphone, a clothing clip and a cable. The headset attaches to the audio cable
end of the voice cable which attaches to the audio end cap.
Do not twist the microphone boom when adjusting the microphone. The microphone should be adjusted to be about one or
two finger widths from your mouth.
Make sure the microphone is pointed at your mouth. Note the small “Talk” label near the mouthpiece. Make sure the Talk
label is in front of your mouth. The microphone cable can be routed over or under clothing.
Under Clothing
Leave the cable exposed only at the top of the collar. Be sure to leave a small loop of cable to allow movement of your
head.
Over Clothing
Use clothing clips to hold the cable close to your body. Tuck the cable under the belt, but leave a small loop where it goes
under the belt. Do not wear the cable on the front of your body. It may get in your way or get caught on protruding objects.
4. Slide the cable ends together until they click. Do not twist or bend the connectors.
