Honeywell HWM 500 - UV Warm Moisture Humidifier Operation and maintenance manual

In English 1-10
En français 11-20
En Español 21-30
Portable Electric Warm Mist Humidier (with fan)
Up to 99.999% Germ-Free, Model HWM-500 Series
• Instructions for Operation, Care and Cleaning
• Limited Warranty
READ AND SAVE THESE INSTRUCTIONS
Printed in CHINA
Imprimé en CHINA
Impreso en CHINA
HWM-500_OM.indd 1HWM-500_OM.indd 1 4/5/07 6:07:39 PM4/5/07 6:07:39 PM

2
READ ALL OF THE FOLLOWING INSTRUCTIONS BEFORE
ATTEMPTING TO OPERATE YOUR HUMIDIFIER. FOLLOWING
THESE SIMPLE GUIDELINES FOR USE AND CARE WILL HELP
ENSURE YEARS OF DEPENDABLE AND EFFICIENT SERVICE.
IMPORTANT SAFEGUARDS
CAUTION: BECAUSE HIGH TEMPERATURE IS GENERATED IN THIS HUMIDIFIER,
BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED ESPECIALLY
WHEN CHILDREN ARE PRESENT.
WHEN USING ELECTRICAL APPLIANCES, THESE BASIC SAFETY PRECAUTIONS MUST
BE FOLLOWED:
1. DO NOT operate the humidier without the water tank.
2. ALWAYS use clean, cool tap water to ll the water tank.
3. To avoid risk of re or shock, DO NOT use an extension cord.
4. DO NOT handle the unit with wet hands.
5. NEVER tilt, move, or attempt to empty the unit while it is operating or plugged
in. Shut o, unplug and remove water tank before moving unit.
6. DO NOT place the unit close to heated areas, such as near stoves, heaters or in
direct sunlight.
7. DO NOT operate OUTDOORS. This humidier is intended for indoor use only.
8. DO NOT let water get into the air inlets on the bottom of the enclosure or on the
cord or plug.
9. DO NOT store or use gasoline or other ammable vapors and liquids near the
humidier.
10. ALWAYS make sure the water tank cap and gasket are rmly in place.
11. DO NOT touch hot surfaces.
12. ALWAYS turn the humidier o when the water tanks are empty or when
the unit is not in use. If you turn your unit o for extended periods, ALWAYS
disconnect the power cord and empty the water tank and base.
13. ALWAYS place the unit on a rm at, level, water resistant surface and arrange
the power cord so that the product is unlikely to be upset.
14. DO NOT clean the product or service the UV bulb without disconnecting the
power cord.
15. Before connecting to electric power outlet, check your electrical power supply.
It must be 120 volts A.C. (alternating current). The outlet may be 15 amp or 20
amp. The circuit must be of adequate size and must be protected by fuse or
circuit breaker.
16. This item has a polarized plug. As a safety feature, this plug will t in a polarized
electrical receptacle (outlet) only one way. If the plug does not t fully in the
outlet, reverse the plug. If it still does not t, contact a qualied electrician.
HWM-500_OM.indd 2HWM-500_OM.indd 2 4/5/07 6:07:40 PM4/5/07 6:07:40 PM

3
17. DO NOT attempt to remove MIST NOZZLE during operation, or within 15
minutes after the humidier is turned to the“OFF/RESET”position and
unplugged. Serious injury may result.
DO NOT place hands or face directly over MIST NOZZLE while unit is in
operation.
18. Place unit in an area where it is not accessible to children.
19. Before using the unit, check the power cord for any signs of damage.
20. This humidier requires daily and weekly maintenance.
21. This humidier requires daily and weekly maintenance.
22. Refer to CLEANING AND MAINTENANCE instructions provided. NEVER clean
humidier in any other manner than as instructed by this manual.
23. NEVER clean humidier in any other manner than as instructed by this manual.
24. WARNING – Eye damage may result from directly viewing the light produced by
UV bulb. DO NOT energize unit while lamp door is removed.
25. This product complies with Title 21 Code of Federal Regulations Chapter 1,
Subchapter J.
SAVE THESE INSTRUCTIONS
HWM-500_OM.indd 3HWM-500_OM.indd 3 4/5/07 6:07:40 PM4/5/07 6:07:40 PM

4
WEEKLY CLEANING AND MAINTENANCE ADVISORY
At least weekly cleaning is recommended, when the unit has been in use.
Regular cleaning prevents mineral scale buildup in the hot water reservoir. It
also helps prevent buildup of bacteria, molds or other micro-organisms in the
tank or system. This ensures that your humidier will operate at maximum
eciency. (See page 6 for full cleaning instructions.)
HOW YOUR HONEYWELL
WARM MIST
HUMIDIFIER WORKS
This model humidier uses a two-step
approach to eliminate potentially
harmful microorganisms from the
water before they are spread with the
mist into the air. The rst step uses
a UV bulb, located inside the base
of the humidier, that shines on the
water through a special glass tube as
it passes from the cold water reservoir
to the hot water reservoir. The second
step is the boiling action that takes
place in the hot water reservoir just
before the mist is distributed by fan to
the air in the room.
CONTROL PANEL
ON-OFF SWITCH (I/O)
When the switch is turned to
the“ON”(I) setting and the
unit is plugged in, the power
is on.
REPLACE UV BULB
If the “REPLACE UV BULB” signal light is illuminated during normal use, the bulb must
be replaced with the same special 3.5W bulb. See the enclosed order form. The UV
bulb will operate at maximum output for approximately 2,000 hours. The UV bulb may
operate longer than 2,000 hours but at a reduced output. To keep your humidier
operating at maximum eciency it is recommended that the UV bulb be replaced
after 2,000 hours of use.
HWM-500_OM.indd 4HWM-500_OM.indd 4 4/5/07 6:07:40 PM4/5/07 6:07:40 PM

5
REFILL/RESET INDICATOR - When illuminated, the water tank needs relling. See
the section FILLING THE WATER TANK. If still illuminated after full tank is placed on
base, see TROUBLESHOOTING section (Page 9).
RELATIVE HUMIDITY CONTROL - This controls the humidity level. If moderate
humidity is desired, the control should be turned counterclockwise toward“ ”; and if
higher humidity is desired, clockwise toward“ ”.
NOTE: When you unpack your humidier, you may nd it has droplets of water on
some surfaces. This is normal as every unit is tested prior to shipping. Carefully
unpack humidier and remove all packing material.
OPERATING INSTRUCTIONS
1. Place the base of the unit on a rm, at level and water resistant surface.
2. Fill the Water Tank according to the instructions below and place on humidier
base.
3. Plug the power cord rmly and completely into the wall outlet.
4. Turn the switch to the“ON”(I) position. It will be normal for the humidier to take 2
minutes to warm up and begin to mist.
5. When the water tank is empty, (after approximately 24 hours running time), the
“REFILL/RESET WHEN LIT” lamp will go on, and the unit will stop heating. Refer to
the FILLING THE WATER TANK section.
6. Whenever the water falls below the level of the probes during operation, the
heating element will shut o and stop heating.
8. Mount humidier on drip tray if using unit on wood surface or other surface that
could possibly be damaged by accidental water spillage or condensation.
FILLING THE WATER TANK
1. Before lling the water tank, turn the ON-OFF switch to the“OFF”(O) position and
unplug unit.
2. Remove water tank from base, turn the tank upside down and remove tank cap
by turning counterclockwise. Fill tank with clean cold tap water. If using distilled
water, add a few grains of table salt to each tank. Replace the tank cap by turning
clockwise. Tighten rmly.
3. Carefully pick up tank, since it will be heavy when full, and slippery if wet.
4. Place water tank on base. Make sure tank is properly placed, otherwise, the
humidier will not work correctly.
HWM-500_OM.indd 5HWM-500_OM.indd 5 4/5/07 6:07:41 PM4/5/07 6:07:41 PM

6
MINERAL ABSORPTION PAD INSTRUCTIONS
Warm mist humidiers do not spread ne mineral dust into the air that you breathe
nor on your furniture, the way that other type humidiers do. The mineral dust
remains trapped in the humidier hot water reservoir. Use of mineral absorption pads
will play a major role in capturing and removing minerals from hot water reservoir,
and preventing a stubborn mineral buildup. The unit can run without pads, but more
frequent cleaning will be required. This unit uses pad HMP-15P.
1.
Before starting humidier, place mineral absorption pad in the hot water reservoir.
After the humidier has been operating, the water will become HOT, and CAUTION
should be exercised when handling mineral absorption pad. It is best to allow
humidier water to cool down, and to use tongs or long tweezers when handling pad.
2. The useful life of the mineral absorption pad will vary, depending on the mineral
content of the water used. In areas of moderate mineral content water supply,
the mineral absorption pad should be changed after approximately (3) weeks of
continuous use. If the water is“Hard Water”, the pad should be changed more
frequently. The best way to tell when the pad should be changed is to examine it
AFTER the water has cooled down, to see if it is still soft and pliable. When the pad
is near the end of its life, it becomes sti and hard and should be replaced with a
new pad. Another sign to change pad is when scale begins to buildup on interior
of hot water reservoir.
CLEANING AND MAINTENANCE
Water contains minerals and other particles. During operation most of these minerals
will remain in the water reservoir. Gradual buildup of deposits will coat the hot water
reservoir and reduce its eciency. The importance of routine cleaning and care
cannot be over-emphasized. Hard water contains more minerals and other particles.
If pad appears to disintegrate (normally due to use of softened water) discontinue use
of pads.
CLEANING INSTRUCTIONS
Failure to perform the necessary cleaning steps will damage unit.
1. Before cleaning, set CONTROLS to“OFF”(O) position and unplug unit.
2. Remove water tank from humidier base, and drain water from tank.
3. Allow at least 15 minutes for the hot water to cool after shutting unit “OFF”(O)
before moving base, or removing mineral absorption pad. Remove mineral
absorption pad from hot water reservoir using tweezers or tongs to prevent burns
from hot water. When the cleaning procedure is completed, replace mineral
absorption pad. To drain water from humidier base, grasp with both hands and
tilt to the side, draining water into the sink. BE CAREFUL NOT TO HAVE DRAINING
WATER FALL INTO CONTROLS OR VENT OPENINGS. DO NOT drain in any manner
other than indicated. WARNING: DO NOT place directly under running faucet. Turn
the base upside down and remove the cap by turning it counterclockwise. Clean
out any foreign matter that has accumulated inside the tting from which the
cap was removed. After cleaning, replace this cap tightly by hand. Pour a small
amount of water into the hot water reservoir and check for leaks from this cap
under the base.
4. Pour about 1 cup of white vinegar into either reservoir and allow it to soak for only
20 to 30 minutes.
HWM-500_OM.indd 6HWM-500_OM.indd 6 4/5/07 6:07:41 PM4/5/07 6:07:41 PM

7
5. Hold the base of the humidier over the sink and tilt it on its side to empty the
vinegar. Fill the cold and hot water reservoirs with clean, warm water to remove all
traces of the vinegar. Remove any buildup of minerals in the hot water reservoir
and from the two metal water level probes (they appear like two metal wires)
using a small brush, such as a toothbrush. NOTE: The buildup is due to water
hardness. The harder your water, the more often this maintenance will be needed.
Empty all of this water by turning the unit on its side.
DO NOT ALLOW WATER TO ENTER THE BOTTOM OF THE HUMIDIFIER BASE OR ANY
OTHER OPENINGS, OR IMMERSE THE CORD AND PLUG.
6. Disinfect the water tank using a solution of one teaspoon of household chlorine
bleach in 1 gallon of water. Let the solution sit for 20 minutes, swishing every few
minutes to wet all surfaces. Empty the tank completely; rinse thoroughly until all
of the bleach smell is gone. Fill the tank with fresh, cool water and replace it onto
the humidier base.
7. NEVER use any metal or hard objects to clean plastic parts which may cause
scratching of the plastic parts. The only exception to this is the metal part of the
hot water reservoir. A metal scraper can be used to clean this part only. NEVER use
gasoline, kerosene, glass cleaner, furniture polish, paint thinner or other household
solvents to clean any part of the humidier.
8. Each day the reservoir and tank should be drained, rinsed and relled with fresh
tap water.
9. To clean exterior surfaces, use a solution of water and mild detergent with a wrung-
out damp cloth. Rinse and wring out the cloth and wipe the exterior surfaces
again. Finally, wipe with a dry cloth. Allow sucient time to dry before plugging
the electrical cord into the outlet.
10. Replace tank. Plug in the unit and resume normal use.
CHANGING THE UV BULB
1. If the “REPLACE UV BULB” indicator illuminates during normal use, it is time to
change the UV bulb, which is a special 3.5W bulb, EUV-13B.
2. Turn the ON-OFF switch to the“OFF”(O) position, unplug it and allow it to cool.
3. Remove the water tank from the base of the humidier.
4. Place the base of the humidier over the sink and tilt the unit to remove any
remaining water.
5. Carefully turn the base of the humidier over and place it upside down on a at
level surface. You will see a door that is closed with a screw.
6. Using a Phillips head screwdriver, carefully turn the screw(s) counterclockwise until
the screw(s) separate from the door.
7. Open the door. The UV light bulb will be visible.
8. Take a replacement 3.5W UV bulb that you purchased from HONEYWELL or another
supplier and change the bulb. To prolong the life of the bulb, limit your direct
contact with the glass of the bulb by using a cloth or tissue to screw it into place.
9. When the new bulb is in place, close the door and replace the screw(s) by using
your Phillips head screwdriver and rotating it clockwise until it is just tight. DO NOT
OVER TIGHTEN.
HWM-500_OM.indd 7HWM-500_OM.indd 7 4/5/07 6:07:41 PM4/5/07 6:07:41 PM

8
10. DO NOT turn power on, while UV Lamp Door is open, and DO NOT view
illuminated bulb directly because eye damage may occur.
11. Turn the unit upright, place the water tank on top of the base of the humidier,
plug the unit in, and turn the ON-OFF switch to the“ON”(I) position. The “REPLACE
UV BULB” indicator should no longer be lit.
IMPORTANT NOTE: Even though you will not
receive maximum germicidal eects, you can still
use your humidier until the replacement bulb
arrives.
NOTE: You will hear a rattling sound and notice
a small round object inside your bulb. This is
normal. Your bulb is fully operational.
Lamp contains mercury. Manage in
accordance with disposal laws.
See www.lamprecycle.org or call 1-800-895-8842.
STORAGE TIPS
If you do not plan to use your humidier for an extended period of time, such as
during the summer months, it is important that you follow these instructions to help
prevent problems from developing in the unit.
1. Clean your humidier as instructed in the section titled,“Cleaning and
Maintenance”.
2. Make sure all water is emptied from the tank and the hot and cold water reservoirs.
3. Dry your unit thoroughly.
4. Leave the tank cap o to expose the tank to air.
5. Pack your humidier in its original carton and store it in a cool, dry place.
SERVICE
DO NOT attempt to repair this humidier yourself. For repairs covered under the
warranty, contact Honeywell by telephone or mail for a Return Authorization Number.
HWM-500_OM.indd 8HWM-500_OM.indd 8 4/5/07 6:07:41 PM4/5/07 6:07:41 PM

9
TROUBLESHOOTING
TROUBLE POSSIBLE CAUSES SOLUTION
Unit does not mist Unit is not plugged in Plug in unit.
Power failure Check circuit breaker
Water tank empty Remove and rell.
Power switch not turned on Turn on switch.
Unit not reset after relling tank Check that there is water in
the hot water reservoir.
Using distilled or treated water Add a“pinch”of table salt.
that does not contain enough
ions.
Water tank not properly Reposition water tank.
located on base unit
Humidity level set is achieved Turn Relative Humidity
Control to higher setting
Water leaks from unit Drain cap, drain cap gasket,
Tank cap or tank cap Tighten cap.
gasket is missing or Replace tank cap
improperly positioned or reposition cap gasket.
Moist air output low Mineral buildup in hot water Clean unit as per
reservoir instructions.
PROBLEMS OR QUESTIONS?
DO NOT RETURN THIS UNIT TO THE STORE.
CALL US, WE CAN HELP. 1-800-477-0457
HWM-500_OM.indd 9HWM-500_OM.indd 9 4/5/07 6:07:41 PM4/5/07 6:07:41 PM

10
3 YEAR LIMITED WARRANTY
You should rst read all instructions before attempting to use this product.
A. This 3 year limited warranty applies to repair or replacement of product found
to be defective in material or workmanship. This warranty does not apply to
damage resulting from commercial, abusive, unreasonable use or supplemental
damage. Defects that are the result of normal wear and tear will not be considered
manufacturing defects under this warranty.
KAZ IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES OF ANY
NATURE. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE
DURATION OF THIS WARRANTY.
Some jurisdictions do not allow the exclusion or limitation of incidental or
consequential damages or limitations on how long an implied warranty lasts, so
the above limitations or exclusions may not apply to you. This warranty gives
you specic legal rights, and you also may have other rights which vary from
jurisdiction to jurisdiction. This warranty applies only to the original purchaser of
this product from the original date of purchase.
B. At its option, Kaz will repair or replace this product if it is found to be defective in
material or workmanship.
C. This warranty does not cover damage resulting from any unauthorized attempts to
repair or from any use not in accordance with the instruction manual.
D. Return defective product to Kaz, Incorporated with a brief description of the
problem. Include proof of purchase and a $10 US/$15.50 CAN check or money
order for handling, return packing and shipping charges. Please include your
name, address and a daytime phone number.
You must prepay shipping charges. We suggest having tracking or delivery
conrmation. Send to:
In U.S.A.:
Kaz, Incorporated
Attn: Returns Department
4755 Southpoint Drive
Memphis, TN 38118
USA
In Canada:
Kaz Canada Inc.
Attn: Returns Department
510 Bronte Street South
Milton, ON L9T 2X6
Canada
©2007 Kaz, Incorporated. All Rights Reserved.
P/N: 31IMM500190
HWM-500_OM.indd 10HWM-500_OM.indd 10 4/5/07 6:07:41 PM4/5/07 6:07:41 PM
