INSTALLATION INSTRUCTIONS
69-2685ES-01
HE240, HE280 Humidifier and
Installation Kit
M33322
SAVE THIS DOCUMENT
FOR FUTURE REFERENCE
READ BEFORE INSTALLING
69-2685ES_A.book Page 1 Thursday, August 8, 2019 11:09 AM

HE240, HE280 HUMIDIFIER AND INSTALLATION KIT
69-2685ES—01 2
Safety Definitions
These safety terms identify information you must read prior to installing or
operating the humidifier.
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could cause bodily injury or
property damage.
Safety Precautions
Make sure you read and understand the following safety hazards before installing,
using, or working with the humidifier:
WARNING
Serious Personal Injury Hazard.
Can cause electrical shock and injury from moving parts.
Disconnect power and shut off water supply before removing cover.
WARNING
Hazardous Voltage
Can cause personal injury or equipment damage.
Do not cut or drill into any air conditioning or electrical accessory.
CAUTION
Chemical Hazard.
Can cause personal injury or equipment damage.
Do not use any line connected to an air conditioner.
Do not use gas line.
CAUTION
Temperature and Static Pressure Hazard.
Can cause property or equipment damage.
Locate humidifier where ambient temperature is between 32 and 120 °F (0 to 49 °C).
Do not install humidifier where freezing temperatures could occur.
Be sure supply plenum static pressure is no greater than 0.4 in. wc and water pressure
is no greater than 120 psi.
CAUTION
Sharp Edges Installation Hazard.
Can cause personal injury.
Wear gloves and safety glasses.
69-2685ES_A.book Page 2 Thursday, August 8, 2019 11:09 AM

HE240, HE280 HUMIDIFIER AND INSTALLATION KIT
3 69-2685ES—01
IMPORTANT
Read and save these instructions.
WELCOME
Congratulations on your purchase of an HE240 or HE280 whole-house humidifier.
Proper use of a whole-house humidifier has numerous benefits related to your
family’s health and comfort, as well as helping to safeguard and protect your home.
How Your Humidifier Works
HE240 and HE280 humidifiers use the principle that vapor (evaporated water) is
created when warm air blows over a water-soaked area. As the vapor circulates, the
relative humidity rises.
Your humidity control monitors the relative humidity and activates the humidifier
accordingly. The humidifier has a water supply that dispenses water evenly over a
humidifier pad. The warm dry air from the furnace passes over the humidifier pad
and picks up the moist air to circulate it throughout your home.
Humidified air feels warmer and more comfortable so you may be able to lower your
thermostat heating setpoint, which saves money on your heating fuel bills. The end
result is that your humidifier gives you a comfortable environment that is also energy
efficient.
Model Specific Features
The HE280 humidifier has water savings technology built in that could save up to
30% versus leading brands. This translates to up to 20 gallons of water saved per
day!
APPLICATION
This kit contains your new HE240 or HE280 Humidifier, H8908 Humidistat and all
the accessories required for installation.
Input: 120 V - 24 V~ 60 Hz
69-2685ES_A.book Page 3 Thursday, August 8, 2019 11:09 AM

HE240, HE280 HUMIDIFIER AND INSTALLATION KIT
69-2685ES—01 4
PREPARING FOR THE INSTALLATION
Be sure to identify all the required (Table 1) accessories (included) and make sure
the appropriate tools are available before beginning the installation.
Included Accessories
Required Tools
Tools required for installation include:
•Tinsnip
• Screwdriver
•Pliers
• Adjustable or open-end wrench
• Drill
• Level
• 3/4 in. (19 mm) sheet metal drill bit
Table 1. Included Accessories.
Quantity Accessory
48 in. (1.22 m) Bypass ducting including:
6 in. (155 mm) diameter flexible duct
20 ft (6.2 m) 18 gauge, two-strand thermostat wire
20 ft (6.2 m) 1/4 in. (6.35 mm) OD feed water tubing
10 ft (3.1 m) 1/2 in. (12.7 mm) ID drain tubing
1 bag Connecting and mounting hardware: 4 mounting screws
1 drain tube clamp
1 H8908 Humidistat
1 bag
Saddle Valve Assembly:
1 saddle valve and top clamp
1 threaded bottom clamp
2 bolts
1 rubber gasket
1 brass insert
1 plastic bushing
1 eyelet
1 Plug-in transformer
1 Foil tape roll
1 bag
1 plastic elbow
1 grommet
1 connector strap
1 PVC tubing
1 wire nut
1 Mounting template
69-2685ES_A.book Page 4 Thursday, August 8, 2019 11:09 AM

HE240, HE280 HUMIDIFIER AND INSTALLATION KIT
5 69-2685ES—01
Determining Best Location for Humidifier
• Select a location for the humidifier on the supply (warm air stream) duct. See
Fig. 1 for examples. Return duct mounting is acceptable if there are space
restrictions on the supply duct. If you are mounting the humidifier on the return
duct, simply swap “return duct” for “supply duct” throughout these instructions.
• Select a location that cannot damage the air conditioner A-coil during
installation.
• Do not locate the humidifier on the furnace body.
• Mount the humidifier in a conditioned space to prevent freezing.
• Mount the humidifier at least 3 in. (78 mm) above the furnace body to allow
adequate space for the solenoid valve and drain line.
Fig. 1. Typical humidifier installation locations.
M12248D
HORIZONTAL
DOWN
FLO
LOWBOY
HIGHBOY
HUMIDIFIER
BYPASS
COLLAR
69-2685ES_A.book Page 5 Thursday, August 8, 2019 11:09 AM

HE240, HE280 HUMIDIFIER AND INSTALLATION KIT
69-2685ES—01 6
Fig. 2. Typical humidifier installation locations.
Selecting Location for Humidistat
• Select a location for the humidistat on the return plenum or on the wall in the
living space.
• Mounting on the return plenum is the easiest installation for the control wiring
circuit.
IMPORTANT
The humidistat must be mounted upstream from the humidifier or bypass duct to
ensure it is properly sensing the relative humidity of the living space. Locate the
control at least 8 in. (203 mm) upstream from the humidifier in the return air duct.
(See Fig. 3.)
Fig. 3. Selecting duct location for humidistat.
Locating Closest 120 V Electrical Outlet
• Select location with access to an outlet. If not available, contact an electrician to
have one installed.
• Make sure that the 20 ft (6.2 m) of thermostat wire is adequate to reach from the
humidifier to the humidistat, and also from the humidifier to the transformer.
Please note that the thermostat wire will need to be cut into the 2 correct lengths.
See “Wiring” on page 14 for more information.
CHOOSE A LOCATION IN A CONDITIONED
SPACE THAT HAS ACCESS TO A WATER SUPPLY
PIPE. COLD OR HOT WATER CAN BE USED.
SELECT A SURFACE ON THE HVAC SUPPLY OR
RETURN DUCT WITH CLEARANCE FOR THE
SOLENOID VALVE, DRAIN LINE AND COVER
REMOVAL.
LOCATION MUST ALSO HAVE ACCESS TO 120
VAC POWER.
ENSURE THE LOCATION IS NEAR A DRAIN.
CONSULT LOCAL PLUMBING CODES FOR
PROPER DRAINAGE.
M33410
ALTERNATE LOCATION
RETURN
AIR RETURN AIR
6 in. (152 mm)
MINIMUM 15 in. (381 mm)
MINIMUM
BEST
LOCATION
RETURN AIR DUCT M12831
69-2685ES_A.book Page 6 Thursday, August 8, 2019 11:09 AM

HE240, HE280 HUMIDIFIER AND INSTALLATION KIT
7 69-2685ES—01
INSTALLATION
1. Turn off power to the air handling system at the circuit breaker.
2. Draw a level line on the plenum in the selected location.
IMPORTANT
To ensure optimal product performance, be sure the mounting template is
level before marking. Use of a small level is recommended.
3. Locate the template (form number 69-2710 included in the box). For the
HE240 model, cut out the template along the dotted line.
4. Tape the template in position and trace around the template.
5. Remove the template and carefully cut the rectangular opening using tin snips.
6. Disassemble the humidifier; remove the cover and take out the humidifier pad
assembly. See Fig. 4.
Fig. 4. Disassembling humidifier.
M33323
WATER
FEED NOZZLE
FRAME
HUMIDIFIER
HOUSING
WATER
FEED TUBE
HUMIDIFIER
PAD ASSEMBLY
COVER
SIDEWALL
BY-PASS SIDEWALL
69-2685ES_A.book Page 7 Thursday, August 8, 2019 11:09 AM

HE240, HE280 HUMIDIFIER AND INSTALLATION KIT
69-2685ES—01 8
7. Make sure the humidifier housing is
level, then position it in the opening
so the plastic tabs are in place on the
lower sheet metal edge of the
opening. Use pliers, as necessary, to
flatten cut edges. See Fig. 5.
8. Secure the humidifier housing to the
opening at the top and bottom using
sheet metal screws.
9. Use the 6 in. (155 mm) starter collar
as a template to mark the opening for
the bypass. The starter collar end can
be identified by the pliable metal tabs.
Fig. 5. Installing humidifier on duct.
10. Carefully cut the opening for the 6 in. (155 mm) starter collar end of the 48 in.
(1.22 m) flex duct. See Fig. 6. Use a drill to start the cut in the middle of the
circle. Cut in an outward spiral to assist in controlling the cut.
Fig. 6. Cutting bypass opening.
DUCT
LEVEL
SHEET METAL
SCREWS (4)
PLASTIC
TABS (2)
DRAIN TUBING
M33324
OPENING
TO AIR DUCT
STARTING
HOLE
6 IN. ROUND TEMPLATE
M20172
69-2685ES_A.book Page 8 Thursday, August 8, 2019 11:09 AM

HE240, HE280 HUMIDIFIER AND INSTALLATION KIT
9 69-2685ES—01
11. Reassemble humidifier side plates to customize the orientation for your specific
install. The side plate with the humidifier port needs to be on the side of the
humidifier that is closest to the 6 in. (155mm) hole cut in Step 10.
12. Insert flex duct with starter collar into the 6" (155mm) hole that was cut in
Step 10. Reach into hole THROUGH THE FLEX DUCT so that the pliable metal
tabs can be bent outwards into the hole. These tabs, when bent outwards, will
help secure the flex duct into your home's duct work.
13. Slide remaining loose end of flex duct over the humidifier port on the HE240/
HE280, making sure that the flex duct advances past the raised plastic tabs on
the port. These tabs will help to hold the flex duct in place. Verify that the
damper blade has adequate clearance to move back and forth between the
summer and winter positions. Secure the flex duct in place with the plastic
connector strap.
14. Seal the duct connections with foil tape. Seal both
1) the connection between the starter collar end of the flex duct and the home's
duct work and
2) the end of the flex duct to the humidifier over the top of the connector strap.
15. Reinstall the humidifier pad assembly in the humidifier housing.
16. Hinge the cover in place and secure with the thumbscrew located at the bottom
of the cover.
Fig. 7. Connecting bypass ducting.
M33325
HUMIDIFIER PORT
CONNECTOR STRAP
69-2685ES_A.book Page 9 Thursday, August 8, 2019 11:09 AM

HE240, HE280 HUMIDIFIER AND INSTALLATION KIT
69-2685ES—01 10
Connecting the Plumbing
Use hot or cold water and either hard or softened water in the humidifier.
NOTE: Using hot water will increase operating costs, but may provide a small
increase in the amount of humidity delivered.
IMPORTANT
Please consult local plumbing code for proper plumbing regulations before
beginning. Use of a manual shutoff valve may be required to meet code in your area.
1. Shut off the water.
2. Use the self-piercing saddle valve
(included) to tap into the water supply
line at the location selected. Turn the
handle on the top of the saddle valve to
the right (clockwise) until the needle
pierces the water supply line. Leave the
needle in this position until the
humidifier is fully installed to prevent
leaking (even though the water supply
is turned off, there can still be water in
the line that will leak as soon as the
needle is backed out). See Fig. 8. If
tapping into galvanized pipe, drain the
line and pre-drill 3/16 in. tap for the
saddle valve. Fig. 8. Installing the saddle valve.
NOTE: The saddle valve is not designed to regulate water flow. The valve is
either open or closed.
IMPORTANT
To prevent debris from clogging the solenoid in-line filter, be sure to install the
saddle valve handle pointing toward the ceiling.
3. Use 1/4 in. (6 mm) OD tubing and
connect the saddle valve to the
inlet side of the solenoid valve on
the humidifier (see Fig. 9).
a. Place the brass compression nut
over the tubing.
b. Slide the plastic compression
ring over the tubing. (Discard
copper compression ring
provided with valve.)
c. Install brass insert into end of
tubing.
Fig. 9. Installing feed tubing.
NOTE: To prevent leaking, use plastic (Delrin) compression rings with plastic
tubing. Use copper sleeve rings only with copper tubing.
M20175
SCREW DRIVER
WATER LINE
M33404
BRASS COMPRESSION NUT
PLASTIC
COMPRESSION
RING
BRASS INSERT
69-2685ES_A.book Page 10 Thursday, August 8, 2019 11:09 AM
