WARM MOISTURE HUMIDIFIER
3 GALLON (11.4 LITERS) OUTPUT PER DAY*
HWM-950 Series
*Output dependent on room temperature and humidity.
OWNER’S MANUAL
The Honeywell trademark is used by Kaz, Inc. under license from Honeywell International Inc.
Honeywell International Inc. makes no representation or warranties with respect to this product.

READ AND SAVE THESE SAFETY INSTRUCTIONS BEFORE USING
THIS HUMIDIFIER
WHEN USING ELECTRICAL APPLIANCES, BASIC PRECAUTIONS SHOULD ALWAYS
BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, AND INJURY TO
PERSONS, INCLUDING THE FOLLOWING:
1. Before using the humidifier, extend the cord and inspect for any signs of damage.
Do not use product if cord has been damaged.
2. Always place humidifier on a firm, flat, level surface. Keep cord away from heated
surfaces and out of the way, where it cannot be stepped on or tripped over.
3. Do not place the humidifier directly on wood furniture or other surfaces that could be
damaged by water. Protect by placing the humidifier on a non-metallic waterproof surface.
4. Place humidifier in an area that is out of the reach of children.
5. Do not operate outdoors; this appliance is intended for indoor use.
6. Do not remove the Water Tank or Cooling Chamber during operation or within 15 minutes
after the humidifier is turned off and unplugged. Serious injury may result.
7. Do not touch the steam vapor. Steam can cause burns. Do not operate without the
Medicine Cup in place on top the Cooling Chamber.
8. Do not operate without water. Turn off unit when tank is empty.
9. Do not add any medications directly into the Heating Chamber or Water Tank.
Do not cover, or insert objects into, any openings on the unit.
10. Do not immerse the base in water or other liquid. Do not pour water in the outlet.
11. Humidifier should always be unplugged and emptied when not in operation or while being
cleaned. Shut off and unplug humidifier before moving. Do not move or tilt humidifier while
it is operating. Plug and unplug unit with dry hands.
12. The humidifier should not be left unattended in a closed room since air could become
saturated and leave condensation on walls or furniture. Leave room door partly open.
Do not aim outlet directly at children, walls or furniture.
13. This product has a polarized plug (one blade is wider than the other) as a safety feature.
This plug will fit into a polarized outlet only one way. If the plug does not fit fully into the
outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt
to defeat this safety feature.
14. A loose fit between the AC outlet (receptacle) and plug may cause overheating and a
distortion of the plug. Contact a qualified electrician to replace loose or worn outlet.
15. The humidifier requires regular cleaning. Refer to and follow cleaning instructions.
16. When moving or lifting the Tank, use one hand on the Top Tank Handle and the other on
the Bottom Tank Handle.
For household use only.
IMPORTANT SAFETY INSTRUCTIONS

FIRST TIME USE
Top Tank Handle
Water Tank
Bottom
Tank Handle
Water Valve
Tank Cap
Heating Chamber
Night Light
(Green)
Base
Medicine Cup
Cooling
Chamber
Removable
Tray Handle
Removable Tray
Cooling Chamber
Interlock
Power Switch
Reset Light
(Red)
Thank you for purchasing this Humidifier.
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE. WITH PROPER CARE AND
MAINTENANCE, THE HUMIDIFIER SHOULD BE ABLE TO PROVIDE AT LEAST 12 HOURS OF
OPERATION FOR EACH TANK.
• Unpack and remove all packing material from the Water Tank and Base. Completely
unravel power cord and place unit on a flat, stable surface at least 6 inches away from
walls and heat sources (Fig. 1). Do not use product if cord has been damaged. Place cord
out of the way where it cannot be pulled or stepped on. Follow the directions below to fill
and operate the Humidifier.
The manufacturer will not accept responsibility for property damage caused by water spillage.
MODEL - HWM-950:
Your humidifier is made up of these parts:

Always UNPLUG the humidifier before filling.
• Remove the Water Tank from the Base and turn it upside
down. Turn the Tank Cap counterclockwise to
open. (Fig. 2)
• Fill the Water Tank (Fig. 3) with clean, cool, tap water and
replace the Tank Cap by firmly turning clockwise .
Turn the tank upright and check Tank Cap for
leaks. If any water drips from Tank Cap, remove it and
re-tighten.
• Carry Water Tank using one hand on the top handle and
one on the bottom of the Tank.
• Be sure the Removable Water Tray and Cooling Chamber
are in place and the Cooling Chamber Interlock is
engaged.
• Replace the Water Tank on the Base by aligning the Tank
Cap into the Water Tray.
CAUTION: DO NOT ADD ANY MEDICATION OR OTHER
ADDITIVES TO THE WATER. DO NOT POUR ANY WATER
INTO THE OUTLET.
NOTE: WHEN CARRYING THE FILLED WATER TANK PLEASE
USE THE HANDLE AND PLACE YOUR OTHER HAND UNDER
THE TANK FOR ADDITIONAL SUPPORT.
FILLING
Fig. 1
DH-832 Robitussin Figure 2
Fig. 2
Fig. 3

OPERATION
• Do not operate the humidifier without water in the Water Tank or without the
Removable Water Tray, Cooling Chamber and Medicine Cup installed.
• After filling the humidifier, be sure the Power Switch is in the OFF position, then plug
the power cord into a 120 volt AC wall outlet. DO NOT PLUG IN THE CORD WITH WET
HANDS; ELECTRIC SHOCK COULD RESULT.
• You can use Kaz Inhalant or Vicks VapoSteam with your Warm Mist Humidifier.
Remove the Medicine Cup from the unit for easier filling and replace on top of the
Cooling Chamber. Be careful not to overfill the Medicine Cup or spill anything into the
Cooling Chamber.
• Turn the Switch to either the Hi or Low position (Fig. 4).
The Night Light will illuminate and the humidifier will start.
It may take several minutes before mist will appear at the
outlet.
• Direct Outlet away from walls and furniture.
If condensation forms on walls or windows, or if indoor
relative humidity exceeds 50%, turn the Switch to the low
setting, open door to room where humidifier is operating,
or turn unit off.
• Turn the humidifier off before removing and refilling the Water Tank.
RESET PROCEDURE
NOTE: WHEN THE WATER TANK IS EMPTY AND THE WATER IN THE HEATING
CHAMBER IS ALMOST USED UP, THE HUMIDIFIER WILL AUTOMATICALLY SHUT OFF.
THE RESET LIGHT WILL ILLUMINATE TO INDICATE THAT THE HUMIDIFIER IS OUT OF
WATER. THE HUMIDIFIER WILL NOT OPERATE UNTIL THE WATER TANK IS REFILLED
AND THE HUMIDIFIER IS RESET.
• Turn the Power Switch to the Off position. Unplug the humidifier. Allow the humidifier
to fully cool for at least 15 minutes.
• Remove and refill the Water Tank as instructed in the “Filling The Water Tank”
section above.
• After filling the humidifier, plug the power cord into a 120 volt AC wall outlet. DO NOT
PLUG IN THE CORD WITH WET HANDS; ELECTRIC SHOCK COULD RESULT.
• The Reset Light should now be off.
• Turn the Switch to either the Hi or Low poisition. The Nightlight will illuminate and the
humidifier will start. It might take several minutes before mist will appear at the outlet.
Fig. 4

CARE AND CLEANING
CAUTION: ALWAYS TURN OFF THE POWER SWITCH AND DISCONNECT THE POWER
CORD FROM THE ELECTRICAL OUTLET BEFORE CLEANING.
Humidifiers provide comfort by adding moisture to dry indoor air. For maximized benefit
from your Warm Mist Humidifier, follow instructions carefully. Please note that this is an
electric appliance and requires careful attention when in use.
Tap water may contain pollutants and minerals (scale) that can deposit on the inner
surfaces of the Humidifier and adhere to the Heater element. Such scale can accelerate
the growth of microorganisms and can impair the performance of the Heater Element.
DAILY MAINTENANCE
1. Turn switch to off (O) position and unplug the cord from wall outlet.
2. Be sure the unit has cooled for at least 15 minutes, then lift the Water Tank from Base.
Remove the Tank Cap and drain any water from the Water Tank. Rinse the Water Tank
with lukewarm water after each use. Wipe accessible surfaces of the Water Tank
clean with a soft, damp cloth.
3. Remove the Medicine Cup from the Cooling Chamber. Using the Cooling Chamber
Interlock, release the Cooling Chamber from the Base. Carefully remove the Cooling
Chamber and Removable Water Tray from the base. Wipe the Medicine Cup, Cooling
Chamber and Removable Water Tray clean with a soft, damp cloth.
4. Be sure the Heater Element is completely cool and then wipe the Heater Element and
Heating Chamber clean with a soft, damp cloth.
5. Do not leave water in the Water Tank or Heating Chamber when unit is not in use as it
may result in the build up of mineral deposits and bacteria that can inhibit the output
efficiency of the humidifier. Please note that if water remains in the Water Tank for
more than a day or two, bacterial growth is possible.
6. Do not immerse the Base in water. For storage, wipe dry with a soft, clean cloth.
7. Replace Removable Water Tray, Cooling Chamber, Medicine Cup then the Tank.
Humidifier is now ready for use.

END-OF-THE-SEASON CARE AND STORAGE
• Follow above weekly cleaning procedure at the end of the humidification season,
or when the humidifier will not be used for several days, being sure to dry all parts.
Allow the Water Tank to air dry before storing.
• Leave Tank Cap partially loosened during storage to prevent Tank Cap and Gasket
from sticking together. This will prolong the life of the gasket.
• Store in a cool dry location.
CARE AND CLEANING cont’d.
WEEKLY MAINTENANCE
Removing Scale
1. Remove the Water Tank and empty any remaining water from the Water Tank
2. Turn switch to the OFF (O) position and unplug the cord from wall outlet.
3. Remove the Medicine Cup from the Cooling Chamber. Using the Cooling Chamber
Interlock, release the Cooling Chamber from the Base. Carefully remove the Cooling
Chamber and Removable Water Tray from the base.
4. Soak the Removable Water Tray in a solution of white vinegar and water for 20
minutes. Rinse thoroughly and then wipe dry with a soft clean cloth.
5. Fill the Heating Chamber with undiluted white vinegar. Let stand for 20 minutes.
Dampen soft, clean cloth or sponge with undiluted white vinegar and wipe out Heating
Chamber to remove scale. Do not use soap, detergents or abrasive cleaners.
6. Rinse the Heating Chamber using clean warm water, being careful not to submerge
the base in water.
7. The Water Tray, Medicine Cup, and Cooling Chamber are top shelf dishwasher safe.
Disinfecting the Removable Water Tray and Tank
1. Fill tank with 1 teaspoon of household bleach in 1 gallon of water. Let stand twenty
(20) minutes, shaking vigorously every few minutes, drain and rinse with clean water
until the bleach smell is gone. Dry with a clean cloth or paper towel.
2. Wipe the Removable Water Tray with a soft cloth dampened in the bleach and water
solution. Rinse the Removable Water Tray thoroughly before proceeding. The Water
Tray may also be disinfected using the dishwasher on its top shelf.
3. Wipe all exterior surfaces of the Base with a soft, dry cloth. Do not immerse the Base
in water or use water to clean the base. An electric shock may result or the humidifier
may be damaged.

TROUBLE SHOOTING
If your Humidifier is not working properly, refer to the following:
NOTE: FAILURE TO KEEP THIS UNIT CLEAN FROM MINERAL DEPOSITS NORMALLY
CONTAINED IN ANY WATER SUPPLY WILL AFFECT THE EFFICIENCY OF OPERATION
OF THIS UNIT. CUSTOMER FAILURE TO FOLLOW THESE INSTRUCTIONS MAY VOID
THE WARRANTY.
PROBLEM
• Power Switch is set
to “On” and Power
Indicator is off
• Little or no mist is
produced
• Reset Light illuminated
• Water overflows from
Reservoir
• Condensation forms
around humidifier
or windows.
POSSIBLE CAUSE
• Unit not plugged in
• No power at outlet
• No water in tank
• Unit is not level
• Mineral deposits on Heater
or Removable Water Tray
• Water Tank was washed
with detergent
• Water Tank is empty
• Unit not reset after refill
• Tank may be leaking
• Tank Cap is not tight
• Mist Intensity is set too high
for room size or pre-existing
humidity level.
SOLUTION
• Plug unit in
• Check circuits, fuses,
test outlet.
• Fill Water Tank.
• Place on a level surface.
• Clean Heater and
Removable Water Tray
• Rinse thoroughly with
clean water.
• Refill Water Tank
• Follow Reset Procedure
• Check the Tank for leaks
and replace if necessary
• Tighten Tank Cap
• Decrease mist output to
low or open door to the
room.

CUSTOMER ASSISTANCE
Mail questions or comments to:
Kaz, Incorporated
Consumer Relations Department
250 Turnpike Road
Southborough, MA 01772
E-mail: [email protected]
Please be sure to specify model number.
Call us toll -free at: 1-800-447-0457
Or visit our website at: www.kaz.com
To order replacement parts, visit our website at: www.kaz.com or call us at
1-800-477-0457.
HWM-950-Medicine Cup
HWM-950-Water Tank
HWM-950-Tank Cap
HWM-950-Tray
This product is rated 3.6 Amps at 120V, 60 Hz.
REPLACEMENT PARTS
ELECTRICAL RATINGS

©2010 Kaz USA Inc. All Rights Reserved
PN: 31IMM950190
LIMITED WARRANTY
You should first read all instructions before
attempting to use this product.
A. This 3 year limited warranty applies to
repair or replacement of product
found to be defective in material or
workmanship. This warranty does
not apply to damage resulting from
commercial, abusive, unreasonable
use or supplemental damage. Defects
that are the result of normal wear
and tear will not be considered
manufacturing defects under this
warranty.
KAZ IS NOT LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES
OF ANY NATURE. ANY IMPLIED
WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR
PURPOSE ON THIS PRODUCT IS
LIMITED IN DURATION TO THE
DURATION OF THIS WARRANTY.
Some jurisdictions do not allow the
exclusion or limitation of incidental or
consequential damages or limitations
on how long an implied warranty lasts,
so the above limitations or exclusions
may not apply to you. This warranty
gives you specific legal rights, and you
also may have other rights which vary
from jurisdiction to jurisdiction. This
warranty applies only to the original
purchaser of this product from the
original date of purchase.
B. At its option, Kaz will repair or
replace this product if it is found to be
defective in material or workmanship.
Defective product should be
returned to the place of purchase
in accordance with store policy.
Thereafter, while within the warranty
period defective product may be
returned to Kaz.
C. This warranty does not cover damage
resulting from any unauthorized
attempts to repair or from any use not
in accordance with the instruction
manual.
D. Return defective product to Kaz, Inc.
with a brief description of the problem.
Include proof of purchase and a $10
US/$15.50 CAN check or money order
for handling, return packing and
shipping charges. Please include your
name, address and a daytime phone
number.
You must prepay shipping charges.
Send to:
In U.S.A.:
Kaz USA Inc.
Attn: Returns Department
4755 Southpoint Drive
Memphis, TN 38118
USA
In Canada:
Kaz, Inc.
Attn: Returns Department
510 Bronte Street South
Milton, ON L9T 2X6
Canada
