Honeywell Eltek UniLED User manual

Honeywell Life Safety AS, Po. Box 3514, N-3007 Drammen, Norway
T45769-B4
Important notice
when installing
luminaires within the same area!!!
To avoid that luminaires perform their
battery test at the same day, connect
the battery packs with more than 1,5
minutes inbetwee
n.
In case of
mains power disconnection
for a period of more than two months,
the battery must be disconnected.
Uni
LED

Honeywell Life Safety AS, Po. Box 3514, N-3007 Drammen, Norway
T45769-B4
Escape route
Max. permitted spacing
Installation height
(meter)
2,5
4,33 10,60 9,09 7,16 2,59
3,0
4,62 11,02 9,97 7,31 2,52
4,0
3,48 11,68 9,27 7,21 2,13
5,0
2,86 9,92 8,30 6,67 1,42
6,0
- 9,90 7,92 5,94 -
Anti-panic area
Max. permitted spacing
Installation height
(meter)
2,5
6,02 11,45 8,84 4,01
3,0
5,84 12,68 9,54 4,02
4,0
6,59 11,37 10,16 4,06
5,0
5,46 11,70 10,38 3,84
6,0
5,50 11,70 10,13 3,41
At the end of their useful life the
packaging, product and batteries
should be disposed of via a
suitable recycling centre. Do not
dispose of with your normal
household waste. Do not burn.
Green LED lit
No LEDs lit
Green and yellow LED lit
Green and red LED lit
All LEDs lit
Red LED blinking
Yellow LED blinking
Test button
Flashing green LED=
Battery charge mode,
no battery test possible
from test button.
1-5 seconds
5-10 seconds
Press and release
after 10 seconds.
L
umen output
(normal/emergency)
:
200/250 lm
Operation voltage: 220-240VAC 50/60Hz
Emergency mode duration: Minimum 1 hour
Battery: 4,8V / 1,2Ah NiMH
Battery protection: Overcharge and full discharge
Maximum power consumption: 14VA
Charging time: 13 hours
Ambient temperature range: 5 to 40°C
Relative humidity: Up to 95%
Weight: 970g
Classification: EN 60598-2-22
For IP20 installations only!
Expected battery lifetime 4 years
Max. permitted spacing= min. 1 lux on floor, 0 –reflection, maintenance factor= 0.8, corridor width= 2.0m, acc. to EN1838
Indicator LEDs
Max. permitted spacing= min. 0.5 lux on floor, 0 –reflection, maintenance factor= 0.8, distance from wall= 0.5m, acc. to EN1838
