Honeywell Searchline Excel User manual

1 2
11 12 13 14
Installation Guide
Issue 6 07/2017
MAN0558_EMEAI
2104M0510
© 2017 Honeywell Analytics
Searchline Excel
Open Path Infrared Gas Detector
Find out more
www.honeywellanalytics.com
Contact Honeywell Analytics:
Europe, Middle East, Africa, India
Life Safety Distribution GmbH
Javastrasse 2
8604 Hegnau
Switzerland
Tel: [phone]
Fax: [phone]
India Tel: [phone]
[email protected]
Americas
Honeywell Analytics Inc.
405 Barclay Blvd.
Lincolnshire, IL 60069
USA
Tel: [phone]
Toll free: [phone]
Fax: [phone]
[email protected]
Asia Pacic
Honeywell Analytics Asia Pacic
7F SangAm IT Tower, 434 Worldcup Buk-ro,
Mapo-gu, Seoul 03922
Korea
Tel: [phone]
Fax: [phone]
[email protected]
Technical Services
EMEA: [email protected]
US: [email protected]
11063
Please Note:
While every effort has been made to ensure
accuracy in this publication, no responsibility
can be accepted for errors or omissions.
Data may change, as well as legislation and
you are strongly advised to obtain copies
of the most recently issued regulations,
standards and guidelines. This publication is
not intended to form the basis of a contract.
This guide provides the installation personnel with the basic information
necessary to mechanically install the Searchline Excel system units and
make the necessary electrical connections.
This guide is not intended to replace the associated Searchline Excel
Technical Handbook (2104M0506) which contains the full safety,
installation, commissioning, maintenance and fault nding instructions.
These procedures assume that consideration of the location and
mounting of the system units has already been taken into account in
accordance with the guidelines in the Technical Handbook.
The following diagram shows a typical system conguration and
identies the main parts.
CONTENTS
INSTALLATION INSTALLATION INSTALLATION
1. INTRODUCTION
1. Introduction 2
2. Safety 3
3. Mechanical assembly 4
3.1 General 4
3.2 Transmitter 4
3.3 Receiver 4
3.4 Adjustable Mountings 5
4. Installation 6
4.1 General 6
4.2 Mechanical Installation 6
4.3 Electrical Installation 10
4.3.1 Electrical Connections 10
4.3.2 Electrical Installation 12
4.3.3 Receiver Connections via OELD 12
4.3.4 Receiver Connections via DX100(M) 13
4.3.5 Transmitter Connections 13
4.3.6 Remote Installation Receiver Connections 14
4.3.7 Transmitter Connections - Turbo Heating Disabled 14
INSTALLATION
f. The earth bonding arrangement must ensure that the maximum
peak voltage between the unit case earth and any eld cable
conductor is less than 350V. Voltages in excess of this can cause
permanent damage to the unit’s RFI protection lters.
g. The use of a single, screened cable for each gas detector ensures
maximum screening and minimum crosstalk. Cabling arrangements
which use a single cable for connecting a number of eld devices
compromise screening, increase the potential for crosstalk and
prevent implementation of true star earthing.
h. Any electrical interference induced onto the 4 - 20mA loop
conductors by the installation must be kept below the levels
necessary to comply with the general requirements of EN 60079-
29-1 &, IEC 60079-29-1. In practice, this means that
peak noise currents induced on the current loop should be no
greater than ± 0.25mA
j. The 0V rail of the control card/control system is directly connected
to one side of the 4 - 20mA current sensing resistor. Electrical noise
on this rail is therefore directly connected to the 4 - 20mA input.
In order to avoid additional noise being induced on the 0V rail,
it should not be commoned with the safety earth/ground, which
frequently carries a high level of electrical noise.
k. All electrical equipment connected to the gas detector should
comply with EN61000-6-3 and EN61000-6-2.
l. The 24V supply should be free from large transients and
uctuations.
m. The eld cabling conductors should have sufcient cross sectional
area to ensure that the minimum supply voltage applied to the gas
detector is 18V at a current of 420mA. This corresponds to a
maximum round loop impedance of 14 ohms for a nominal 24V
system supply.
n. Receivers should not be installed in close proximity to the antennae
of high powered radio, radar and satellite communication
equipment.
4.3.3 Receiver Connections via OELD
4.3.2 Electrical Installation
1. Isolate all associated power supplies and ensure that they remain OFF
during this procedure.
2. If the units are to be installed with junction boxes other than
OELD or DX100(M) junction boxes, ensure that the boxes:
• have M20 cable gland entries for ATEX / IECEx units, or 3/4 NPT
for UL and CSA.
• have terminals for 5 wires and an earth.
3. Remove the M20 blanking plugs (if tted) and attach the Excel
transmitter and receiver cables to their junction box. Fit the locking
rings (if supplied) before terminating the cables in the junction box.
4. Fit approved cable glands to the junction box cable entries, using
sealing washers where necessary to maintain the ingress protection
rating.
5. Fit approved blanking plugs to all unused cable entries.
6. Make appropriate electrical connections as shown in the following
diagrams.
4.3.4 Receiver Connections via DX100(M)
4.3.7 Transmitter Connections - Turbo Heating Disabled
4.3.6 Remote Installation Receiver Connections
The earth bonding arrangement must ensure
that the maximum peak voltage between the
unit case earth and any eld cable conductor
is less than 350V. Voltages in excess of this
can cause permanent damage to the unit's RFI
protection lters.
Note: The Dx100(M) is housed in a metal
enclosure.
CONTROL
CABINET
CONNECTIONS
4-20mA OUT (TB2/3)
0V (TB2/6)
+24V (TB2/2)
BLACK (0V) TB2/5
RED (+24Vdc) TB2/1
BLUE (B) TB1/3
ORANGE (A) TB1/2
EXCEL RECEIVER WIRING
CABLE SCREEN
INSTRUMENT (CLEAN)
EARTH STAR-POINT
Modbus A (TB1/6)
Modbus B (TB1/5)
Modbus Drain
CABLE SCREEN
SAFETY / PROTECTIVE
GROUND
Where the DX100(M) is not bonded
to a local safety/ protective earth
then an external safety / protective
earth needs to be made as shown.
GREEN/YELLOW (EARTH)
Same potential as Excel body and conduit.
WHITE (4-20mA) TB2/3
CONTROL
CABINET
CONNECTIONS
CABLE SCREEN
CABLE SCREEN
INSTRUMENT
(CLEAN)
EARTH STAR-POINT
Modbus B (TB1/5)
Modbus A (TB1/6)
Modbus Drain
+24V (TB2/2)
4-20mA OUT (TB2/3)
0V (TB2/6)
BLACK (0V) TB2/5
RED (+24Vdc) TB2/1
BLUE (B) TB1/2
ORANGE (A) TB1/3
WHITE (4-20mA) TB2/3
GREEN/YELLOW(EARTH)
Same potential as Excel body and conduit
SAFETY/PROTECTIVEGROUND
Where the DX 100(M) is not
bonded
to a local safety/protective earth the
n
anexternal safety/protective earth
needs to be made as shown.
Note: Using metal cable glands will connect the screen of the cable to the Excel Body.
OELD or DX100(M)
(or other junction box)
Mounting plate
Mounting bracket
Pivot block
Receiver
Flexible conduit
Monitored
path
5 - 200m
Honeywell Analytics
Junction Box
00780-A-0100 (or
other junction box)
Transmitter
4.3.5 Transmitter Connections
CONTROL
CABINET
CONNECTIONS
0V
+24V
EARTH
CABLE SCREEN
INSTRUMENT (CLEAN
)
EARTH STAR-POINT
RED (+24V)
BLACK (0V)
EXCEL
TRANSMITTER
WIRINGJUNCTION BOX
GREEN/YELLOW (EARTH)
Same potential as Excel body and conduit
EXCEL
TRANSMITTER
WIRING
GREEN/YELLOW (EARTH)
Same potential as Excel body and conduit
RED (+24V)
BLACK (0V)
Honeywell Analytics Junction Box
00780-A-0100
CABLE SCREEN
CONTROL
CABINET
CONNECTIONS
EARTH
+24V
0V
INSTRUMENT (CLEAN)
EARTH STAR-POINT
The earth bonding arrangement must ensure that the maximum peak voltage between the
unit case earth and any eld cable conductor is less than 350V. Voltages in excess of this
can cause permanent damage to the unit's RFI protection lters.
25
CONTROL
CABINET
CONNECTIONS
0V
+24V
EARTH
CABLE SCREEN
INSTRUMENT (CLEAN)
EARTH STAR-POINT
GREEN/YELLOW (EARTH)
Same potential as Excel body and conduit
BLACK (0V)
RED (+24V)
EXCEL
TRANSMITTER
WIRING JUNCTION BOX
Shows wires reversed to
disable turbo heating
EXCEL
TRANSMITTER
WIRING
GREEN/YELLOW (EARTH)
Same
potential as Excel body and conduit
BLACK (0V)
RED (+24V)
CONTROL
CABINET
CONNECTIONS
CABLE SCREEN
EARTH
+24V
0V
INSTRUMENT
(CLEAN)
EARTH STAR-POINT
Honeywell Analytics Junction Box
part number 00780-A-0100
OELD Ope rating Instr uctions
Green /Yellow (S afety/P rotectiv e Ground)
Red (+24 Vdc)
Black (0 Vd c)
White (4-20 mA Ou tput)
0 V
+24 Vdc in
4-20 mA
OELD
Field
Wiring Blue ( RS-485B)
Orange ( RS-485A )
4.3.6.1 Remote installation via OELD - refer to Section 4.3.3
EXCEL
RECEIVER
ORANGE(A ) TB1/2
RED(+24V) TB2/1
BLACK(0V) TB2/5
WHITE (4-20mA) TB2/3
DX100(M) JUNCTION BOX
(mounted in a convenient and accessible position)
CABLESCRE EN
SAFETY/ PR OTECTIVE
GROUND
Where theDX100 (M)is not bonded
to aloca lsafe ty/protective ea rth
then an externalsafety / protective
earth needsto be ma deas shown.
LOCAL JUNCTION BOX
(mountedon Receiver mounting plate)
WHITE (4-20mA)
BLACK (0V)
RED +24V
BLUE (B)
ORANGE (A)
GREEN/YELLOW (EARTH)
Samepotential as Excel body and conduit
Use isolating glands where necessary
EXCEL
RECEIVER
DX100(M) JUNCTION BOX
(mountedin a convenient and accessible position)
CABLE SCREEN
GREEN/YELLOW (EARTH)
BLUE (B) TB1/3
RED (+24V) TB2/1
BLACK (0V) TB2/5
WHITE (4-20mA) TB2/3
SAFETY/PROTECTIVE GROUND
Where the DX 100(M) is not bonded
to a local safety/protective earth then
an external safety/protective earth
needsto be made as shown.
CABLE SCREEN
CONTROL
CABINET
CONNECTIONS
4-20mA OUT (TB2/3)
0V (TB2/6)
+24V (TB2/2)
CABLE SCREEN
INSTRUMENT (CLEAN)
EARTH STAR-POINT
Modbus A (TB1/6)
Modbus B (TB1/5)
Modbus Drain
CABLE SCREEN
CONTROL
CABINET
CONNECTIONS
CABLE SCREEN
CABLE SCREEN
INSTRUMENT(CLEAN)
EARTHSTAR-POINT
ModbusB (TB1/5)
ModbusA (TB1/6)
ModbusDrain
+24V (TB2/2)
4-20mA OUT (TB2/3)
0V (TB2/6)
4.3.6.2 Remote installation via DX100(M)
NOTE: FOR DNV VERSIONS, REFER TO THE SEARCHLINE EXCEL TECHNICAL
HANDBOOK FOR SPECIAL INSTRUCTIONS ON THE INSTALLATION,
ALIGNMENT AND COMMISSIONING USING THE MARITIME BRACKET AND
HARDWARE

34
8 9 10
56
7
2. SAFETY 3. MECHANICAL ASSEMBLY
Ensure that you read and understand these instructions BEFORE
handling or operating the equipment. Please pay particular attention to
the Safety Warnings.
WARNINGS
1. The Searchline Excel gas detector is certied for and intended for use in potentially
hazardous areas. Install and use the Searchline Excel gas detector in accordance with
the latest regulations.
2. For installations in the UK, the Code of Practice SELECTION, INSTALLATION AND
MAINTENANCE OF ELECTRICAL APPARATUS FOR USE IN POTENTIALLY
EXPLOSIVE ATMOSPHERES should be strictly observed. General recommendations are
given in BS EN 60079-14 & IEC 60079-14. Refer to BS EN 60079-29-2
& IEC 60079-29-2 in the UK or the appropriate local or national regulations.
3. For installations in North America, the national Electrical Code (NFPA 70) or later
issues should be strictly observed.
4. Elsewhere, the appropriate local or national regulations should be used.
5. The Searchline Excel gas detector must be properly earthed to protect against electrical
shock and minimise electrical interference. For electrical installation design
considerations refer to Section 3.
6. Operators must be fully aware of the action to be taken if the gas concentration exceeds
an alarm level.
7. Dismantling or repair of equipment should be carried out in the safe area only.
8. Test gases may be toxic and/or combustible. Refer to Material Safety Sheets for
appropriate warnings.
9. Do not drill holes in any housing as this will invalidate the explosion protection.
10. In order to maintain electrical safety, the unit must not be operated in atmospheres with
more than 21% oxygen.
11. Ensure that the bolts which secure ameproof enclosures are fully tightened. The
securing bolts used are made from a special certied grade of steel. Only bolts supplied
by Honeywell Analytics should be tted for this purpose.
12. Do not open the enclosure in the presence of an explosive atmosphere.
13. The transmitter unit contains high voltages when operational. These are discharged when
the unit is removed from its enclosure.
14. The conduit and cable glands tted to Searchline Excel should not be modied. If,
however, it becomes necessary to make modications they must comply with the
relevant national Codes of Practice.
15. The irradiance and power emitted by the Searchline Excel transmitters is less than
5 mW/mm2and 15 mW/mm2respectively.
Honeywell Analytics Limited reserve the right to change or revise the
information supplied in this document without notice and without
obligation to notify any person or organisation of such revision or
change. If further details are required that do not appear in this
document, contact Honeywell Analytics Limited or one of their agents.
4. INSTALLATION
INSTALLATION
4.1 GENERAL
Searchline Excel is designed to allow installation to be performed by a
single operator.
The installation procedure is split into mechanical installation and
electrical installation. Each unit needs to mounted to a supporting
structure before making the electrical connections. The diagrams show
different ways of orientation for the mountings.
4.2 MECHANICAL INSTALLATION
This mechanical installation procedure applies to both the receiver and
the transmitter.
1. Ensure that the equipment to be
installed is correct for the type
of installation required (i.e. short/
medium/long range).
2. Fit the mounting bracket to the
mounting plate for the unit, as
shown.
3. Fit the mounting plate to the
supporting structure in one of the
following ways:
• by through bolts directly to a at surface.
• by U-bolts (2 off) to a single 150mm diameter pipe/pole.
• by U-bolts (4 off) to two 55mm diameter pipes/poles,
166mm apart.
Identify the mounting holes using the following diagram and the
accompanying table. The subsequent diagrams show the different
types of mountings.
3.1 GENERAL
This section details the mechanical assembly information and important
dimensions necessary for installing the system units. Adjustable parts which form
part of the mounting assemblies are also shown.
NOTE: FOR DNV VERSIONS, REFER TO THE SEARCHLINE EXCEL TECHNICAL
HANDBOOK FOR SPECIAL INSTRUCTIONS ON THE INSTALLATION, ALIGNMENT AND
COMMISSIONING USING THE MARITIME BRACKET AND HARDWARE
3.2 TRANSMITTER
MECHANICAL ASSEMBLY
INSTALLATION
7. Fit an adjustment clamp to the unit’s pivot block mounting stud
so that it sits on the stud’s shoulder with the correct orientation as
shown in the diagram.
INSTALLATION INSTALLATION
4.3 ELECTRICAL INSTALLATION
4.3.1 Electrical Connections
All ranges of Searchline Excel comply with the EMC requirements
EN50270. In order to maintain compliance with these standards it is
essential that the electrical installation of Excel is engineered correctly.
Electrical installation standards vary for different countries, companies
and applications and it is the responsibility of the installation design
authority to determine the applicable standards and ensure compliance
with them. When designing electrical installations for Excel,
Honeywell Analytics Limited recommend that the installation design
authority considers the following:
a. The unit cases should not, if possible, be connected to electrically
noisy (dirty) metalwork or conductors. Preferably, the case
(internally connected to the green/yellow GND wire) should be
connected to a low noise instrument (clean) earth. See also para e.
below. In order to facilitate electrical isolation of the Searchline
Excel from a noisy earth an isolation kit is supplied. This kit should
be tted as standard unless local regulations forbid this.
b. The entire length of the eld cabling connected to each unit should
be fully shielded. This should be connected to a low noise (clean)
earth.
c. The low noise instrument (clean) earth system should only be
connected to safety earth (usually dirty) at a single point on the
entire site/installation. This connection should be made in such a
manner that it does not introduce noise onto the low noise
instrument earth. Star earthing arrangements minimise earth current
crosstalk.
d. The shields of the eld cabling should not be connected such that
earth loops are produced, or in a manner that will result in the
shields carrying large currents from heavy plant or equipment.
e. Ideally, the eld cable shield should be connected to the unit’s
green/yellow GND wire, providing a single, continuous earth shield.
This connection must not be allowed to complete an earth loop.
160mm (SR)
211mm
(MR/LR)
291 (SR) 353 (MR/LR)
Approximately 300mm
417 (SR)
433 (MR/LR)
160mm
291mm
Approximately 300mm
3.3 RECEIVER 417mm
3.4 ADJUSTABLE MOUNTINGS
Adjustment Clamp
lock screw (2 off)
Mounting Bracket
adjusting screws (2 off)
Clamp Nut
Adjustment Clamp
lock screw (2 off)
Pivot Block
adjusting screw (2 off)
Clamp Nut
Notes: 1. Drawing is not to scale.
2. Mountingplatexingholesareclear.SearchlineExcelsystem
componentmountingholesarethreaded.
 3. Themountingplatexingsarenotsupplied.
4. Fit an adjustment clamp to the unit’s pivot block mounting stud
so that it sits on the stud’s shoulder with the correct orientation as
shown in the diagram.
5. Tighten the adjustment clamp’s
grubscrews until they just grip the
unthreaded part of the mounting stud.
6. Fit the pivot block to the mounting bracket
using a clamp nut and spring washer (M12
or M16) with the correct orientation as
shown in the diagram. Do not fully tighten
the nut.
Ensure that the adjustment clamp’s
stub lever is positioned approximately
centrally between the mounting bracket’s
grubscrews. Adjust the screws if required.
Pivot
Block
Mounting Stud
Adjustment
Clamp
Mounting
Bracket
Clamp Nut
and Spring
Washer
Mounting
Bracket
Grubscrew
Mounting
Stud
Adjustment
Clamp
Stub Lever
8. Tighten the adjustment clamp’s
grubscrews until they just grip
the unthreaded part of the unit’s
mounting stud.
9. Fit the unit to the pivot block using
a self-locking clamp nut and washer
(M12 or M16).
Do not fully tighten the nut.
Ensure that the adjustment clamp’s
stub lever is approximately centrally
positioned between the pivot block’s
grub screws. Adjust the screws if
required.
10. Fit a suitable junction box, e.g. OELD,
DX100(M) or other suitable type of
junction box, to the mounting plate
Note: Forinformationaboutalternative
typesofjunctionboxseeSection
4.3ElectricalInstallation.
11. Measure the distance (in metres)
between the transmitter and receiver
units.
This distance is required by the
system commissioning personnel.
Surface Mounting Single Pipe/Pole Dual Pipes/Poles
Identity Quan-
tity
Size Used For
A 8 ø7.5mm Dual 2’’ pipe or pole mounting, at
surface mounting
B 8 ø9.5mm Single 6’’ pole, at surface mounting,
Dual 2.5’’ ID pipe
C 4 M6 tapped 00780-A-0100 junction box mounting
D 3 M6 tapped DVC100(M) junction box mounting.
D1 2 M6 tapped DVC100(M) MK2 junction box (used in
conjunction with bottom two D holes)
E 4 M10 tapped DX100(M) junction box mounting
F 2 M6 tapped Killark/Akron junction box mounting
G 4 M6 tapped Sun/heat shade mounting
H 3 M8 tapped Short range Transmitter and all Receiver
brackets.
J 3 M10 tapped Medium/Long range Transmitter
mounting bracket.
K 2 M10 tapped XNX Universal Transmitter
Always mount
plate this
way up
60x45° 2 POSNS
6mm thick
stainless steel
plate
A
D1
D
D1
D
EC
C
F F
DG
GG
G
C
C
E E
E
K K
J
J
J
H
H H
A
B
B
B
B B B
B B
A
A
A
A A
A
224
15
15
49
83
133.2
181
215
249
299.2
380
209
Mounting
Bracket
Mounting Plate
Isolation
Kit
NOTE: FOR DNV VERSIONS, REFER TO THE SEARCHLINE
EXCEL TECHNICAL HANDBOOK FOR SPECIAL
INSTRUCTIONS ON THE INSTALLATION, ALIGNMENT
AND COMMISSIONING USING THE MARITIME BRACKET
AND HARDWARE
