T8190A/191108AJ Heating or Cooling
Thermostat/Wallplate; T8190A/Q682B
Heating/Cooling Thermostat/Subbase
Installation Instructions for the Trained Service Technician.
TABLE 1—SYSTEM COMPATIBILITY FOR NON-BATTERY POWERED THERMOSTATS.
aIf thermostat is not compatible with the system being controlled, the system will not operate. No hazard exists. The
thermostat will not be damaged unless it is used to directly control a line voltage system. For proper system operation, a
Honeywell R841 or R8239D1015 Isolating Relay must be added to the thermostat control circuit.
bConsult manufacturer for installation requirements.
Preparation
Check thermostat and subbase (if used) suitability for the
heating, cooling, or heating/cooling system. Refer to Table 1.
Assemble tools required: flat-bladed screwdriver, hand
or power drill with 3/16-in. drill bit, wire cutter/stripper or
sharp knife, bubble level or plumb bob and line.
Assure power is off to the heating, cooling, or heating/
cooling system at the main fuse panel. Most buildings have
a separate switch box or circuit breaker for disconnecting
power to the heating and cooling (if applicable) equipment.
Thisthermostatiscompatiblewithallheating,coolingor
heating/cooling systems when thermostat is powered by
batteries. If thermostat is not powered by batteries, refer to
Table 1 for thermostat and system compatibility information.
Type of Heating System to be Controlled Conditions/Compatibility
Electric (Line Voltage)—typical baseboard
and radiant • The R8239D1015 Isolating Relay or R841 Silent Switching Center must be installed in the thermostat control circuit.a
Fan Coil Unit • Compatible. Assure correct subbase identity is selected for fan
control.
Gas—Direct Spark Ignition (DSI),
Intermittent Pilot (IP), and Standing
Pilot (SP)
• Compatible. If not using battery backup, assure that 24V control
transformer common is accessible for connection to thermostat
cable conductor and power to the transformer is not regularly
interrupted by high temperature or limit operation.
Heat Pump • Compatible. Assure correct subbase identity is selected for
fan control and changeover control (O terminal for cool and
B terminal for heat).
Hot Water Zone • Honeywell 2-wire valves are compatible.
• Some non-Honeywell 2-wire valves require an R8239D1015
Isolating Relay in the thermostat control circuit.a
• Some 3-wire valves require an R8239A1052 Isolating Relay in the
thermostat control circuit.a, b
Oil • If not using battery backup, assure that the 24V control transformer
common is accessible for connection to thermostat cable conductor
and power to the transformer is not regularly interrupted by high
temperature, purge cycle, or limit operation.
Vent Damper • Honeywell damper motors are compatible.
• Some non-Honeywell damper motors require an R8239D1015
Isolating Relay in the thermostat control circuit.aCheck control
amperage requirement.
Warm Air Zone • Most are compatible.
NOTE: Order Q682B Subbase separately.
Recycling Notice
This control contains mercury in a sealed tube. Do not
place control in the trash at the end of its useful life.
Ifthiscontrolisreplacingacontrolthatcontainsmercury
in a sealed tube, do not place your old control in the trash.
Contact your local waste management authority for in-
structionsregardingrecyclingandthe properdisposalof this
control, or of an old control containing mercury in a sealed
tube.
If you have questions, call Honeywell Inc. at 1-800-
468-1502.
M3375
M3375

69-0642—1 2
Installation
WHEN INSTALLING THIS PRODUCT…
1. Read these instructions carefully. Failure to follow
them could cause a hazardous condition.
2. Installer must be a trained experienced service technician.
3. After installation is complete, check out product op-
eration as provided in these instructions.
IMPORTANT: An incorrectly leveled subbase will cause
the temperature control to deviate from setpoint. It is
not a calibration problem.
CAUTION
1. Disconnect power supply to prevent electrical
shock or equipment damage.
2. To prevent interference with the thermostat link-
age, keep wire length to a minimum and run wires
as close as possible to the subbase.
3. Do not overtighten thermostat captive mounting
screwsbecause damage to subbase threads can result.
4. Do not short across coil terminals on relay. This
can burn out the thermostat heat anticipator.
LOCATION
Locate thermostat about 5 ft [1.5m] above the floor in an
area with good air circulation at average temperature.
Donotmountthe thermostatwhereitmaybeaffectedby:
— drafts, or dead spots behind doors and in corners.
— hot or cold air from ducts.
— radiant heat from the sun or appliances.
— concealed pipes and chimneys.
— unheated (uncooled) areas such as an outside wall
behind the thermostat.
Run wires from the heating, cooling or heating/cooling
equipment to the new thermostat location.
Refer to the Typical Wiring Diagrams section to deter-
mine the number of wires required for your application.
UNPACK THERMOSTAT
Handle your new thermostat carefully; rough handling
may interfere with its accuracy. Before unpacking, refer to
Fig. 1.
Remove and discard the shipping wrap.
IMPORTANT: Save package of screws and instructions
for the homeowner.
Remove the thermostat cover by lifting from the bottom.
Set aside cover until needed later.
Carefully remove the material protecting the mercury
switch bulb.
Loosen two captive mounting screws and separate
wallplate (if provided) from back of thermostat base.
Fig. 1—Unpack thermostat.
M1552A
AUTO OFF COOL HEATON
FAN
R
G
O
W
Y
B
3 SCREW HOLES
WITH PLASTIC
ANCHORS
HEATING/COOLING SUBBASE
3 SCREW HOLES
WITH PLASTIC
ANCHORS
WALLPLATE
M1815
Fig. 2—Mounting wallplate or subbase to wall.
35
30
25
20
10
12
11
10
9
8
7
6
5
4
3
2
1
12
11
10
9
8
7
6
CAPTIVE MOUNTING
SCREWS
THERMOSTAT BASE
M8673
REMOVE
PACKING
MATERIAL
LIFT
COVER
THERMOSTAT
COVER
MOUNT WALLPLATE OR SUBBASE
Wall Mounting (Fig. 2)
Holdthewallplate or subbaseinpositionon wall (Fig.2).
Mark holes on the wall for anchors. Use spirit level to
make sure the wallplate or subbase is level.
Drill 3/16-in. holes, and gently tap anchors into holes
until flush with the wall.
Pullwiresthroughthelargewiringholeinthewallplateor
subbase.
Loosely fasten the wallplate or subbase to the wall with
the three screws. Do not completely tighten the screws.
Carefully level the wallplate or subbase (Fig. 3), and
firmly tighten the screws.

3 69-0642—1
Fig. 3—Leveling methods for wallplate or
subbase.
Outlet Box Mounting (Fig. 4)
Use a horizontally mounted outlet box if possible. If a
verticaloutletboxisused,mountthewallplateorsubbaseon
a 193121A (beige) Cover Plate Assembly (ordered sepa-
rately). Follow the instructions provided with the cover
plate assembly.
Align the wallplate or subbase mounting holes on the
outlet box and loosely fasten with two screws.
Carefully level the wallplate or subbase (Fig. 3), and
firmly tighten the screws.
WIRE WALLPLATE OR SUBBASE
Follow the instructions provided by the heating, cooling,
orheating/coolingequipmentmanufacturer.Ifnotavailable,
refer to the Typical Wiring Diagrams section at the end of
this publication.
Disconnect the power supply before making wiring con-
nections to prevent electrical shock or equipment damage.
AUTO OFF COOL HEATON
FAN
B
O
W
Y
R
G
M1555
SPIRIT LEVEL
PLUMB
LINE
PLUMB
BOB OR
WEIGHT
Fig. 4—Mounting wallplate or subbase on horizontal outlet box.
M1553A
EXISTING
HORIZONTAL
OUTLET BOX
HEATING/
COOLING
SUBBASE
AUTO OFF COOL HEATON
FAN
R
G
O
W
Y
B
EXISTING
HORIZONTAL
OUTLET BOX
WALLPLATE
R
W
M1816
M1554A
B
O
W
Y
R
G
VERTICAL
OUTLET
BOX
ADAPTER
RING
1
2
NOT INCLUDED WITH UNIT.
ACCESSORY PARTS AVAILABLE.
SUBBASE OR
WALLPLATE
1
2
2
COVER
PLATE
MOUNTING
SCREWS (2)
NOTE: All wiring must comply with local electrical codes
and ordinances.
This thermostat clock can be powered by a 24 Vac trans-
former with battery backup. Refer to Figs. 15 through 19 for
hookup diagrams of typical powering applications.
For Wallplate (Heating or Cooling Systems)
Refer to Fig. 5 and strip the thermostat wire insulation as
necessary.
For heating-only systems, connect wires to R, W, and C
(ifapplicable)terminals (Fig.20).Forcooling-onlysystems,
connect wires R, Y, and C (if applicable) terminals. Firmly
tighten the screws.

69-0642—1 4
Push excess wire back into the wall.
Plug the hole in the wall with nonhardening caulk, putty,
or nonflammable insulation to prevent drafts from affecting
thermostat operation.
Subbase (Heating/Cooling Systems)
Refer to Fig. 5 and strip the thermostat wire insulation as
necessary.
Connect the wires to the corresponding terminals on the
subbase. If labels do not agree with your new subbase, refer
to Table 2 and the installation instructions furnished with
the subbase.
NOTE: If wiring a dual transformer system, only the O or
the B terminal may be used.
Push excess wire back into the wall.
Plug the hole in wall with nonhardening caulk, putty, or
nonflammable insulation to prevent drafts from affecting
the thermostat operation.
Fig. 5—Methods of connecting terminals.
BARRIER
FOR WRAPAROUND
CONNECTION—
STRIP 7/16 in. [11 mm]
FOR STRAIGHT
CONNECTION—
STRIP 5/16 in. [8 mm]
M1556B
TABLE 2—SUBBASE TERMINAL DESIGNATIONS.
Subbase Terminal Control Function
R Control transformer power.
RcLine side of 24V power supply; cooling side, 2 transformer heat/cool system.
RhLine side of 24V power supply; heating side, 2 transformer heat/cool system.
W Heating control circuit.
Y Cooling control circuit; jumper to W for heat pump compressor control if no
P terminal on subbase.
G Fan control circuit.
C Clock control (transformer common).
O Cooling damper or changeover/reversing valve, makes continuously in cool.
B Heating damper or changeover/reversing valve, makes continuously in heat.
P Heat pump contactor; P terminal on some models only.
MOUNT THE THERMOSTAT
Note the tabs on the top inside edge of the thermostat
base. These tabs fit the slots molded into the top of the
wallplate or subbase.
Hang the thermostat base on the wallplate or subbase.
Insert the two captive mounting screws located in the
bottom corners of the base (Fig. 6).
Firmly tighten the screws.
INSERT TIMER BATTERIES
Power is supplied to the clock by the 24 Vac transformer
or two AAA alkaline batteries (included), or by the heating
or cooling control circuit. Backup batteries may be installed
to supply power to the clock if power is interrupted when
using 24 Vac powering method.
Install the batteries in the thermostat (Fig. 7).
Once a year or when batteries are dead, replace with two
new AAA alkaline batteries. Properly dispose of old batter-
ies. We recommend Energizer®batteries.
Fig. 6—Thermostat mounting.
TAB (2)
MOUNTING SLOT (2)
CAPTIVE
MOUNTING SCREWS
THERMOSTAT
BASE WALLPLATE
OR SUBBASE
35
30
25
20
10
12
11
10
9
8
7
6
5
4
3
2
1
12
11
10
9
8
7
6
M8674

5 69-0642—1
Fig. 7—Insert timer batteries.
BATTERY LOCATION FOR
(2) AAA BATTERIES;
INSTALL WITH POSITIVE
ENDS UP
M8585
SET TIMER
Adjust the timer by moving the knob clockwise .
Do not reverse the knob.
When time is correctly set, the time indicator arrow
(triangle shape) points to the correct time and the corre-
sponding daytime (light) or nighttime (dark) portion of the
program dial (Fig. 8).
SET HEAT ANTICIPATOR
Adjust the heat anticipator lever to match the current
ratingoftheprimarycontrolforthepropercyclerate(Fig.9).
Adjustable anticipation must be set for total current of heat
and fan control.
The current rating is usually stamped on the control or
valve (Fig. 10), or a setting may be given in the device
instructions.
If no current rating or heat anticipator setting is given,
measure the current with an ammeter. Proceed with the
following steps.
Remove the thermostat from the wallplate or subbase.
Connect an ac ammeter of appropriate range (about 0A to
2A) between the R and W terminals on the wallplate or
subbase, except for electric heat and heat pump systems.
Fig. 8—Set timer.
TIMER
SETTING
KNOB
TIME
INDICATOR
ARROW
M821A
PROGRAM DIAL
PROGRAM
PIN (6)
Let the system operate for one minute.
Adjust the heat anticipator lever to match the number that
reads on the ammeter.
Fig. 9—Adjust heat anticipator.
M7317
ANTICIPATOR
SCALEPLATE
ANTICIPATOR
SETTING LEVER
Fig. 10—Current rating of primary control.
V8043E 1004 4
24V 50/60CY
.32 AMP @ 60CY
8406
24 Vac 50/60 Hz
0.4 AMP
30 VAC
0.2 AMP
T
F
T
F
OIL BURNER CONTROL
SHOWS
CURRENT
DRAW SHOWS LOW
VOLTAGE
M6116A
FROM MAIN
FUEL SUPPLY
SHOWS
VOLTAGE
RATING TO
BURNER
SHOWS
ANTICIPATOR
SETTING
TYPICAL GAS VALVE
ZONE VALVE
SHOWS
VOLTAGE
RATING
SHOWS
ANTICIPATOR
SETTING

69-0642—1 6
ATTACH THERMOSTAT COVER
Make sure the packing inserts in the thermostat base are
removed.
Place the two tabs on the upper edge of the cover into the
mounting slots in the thermostat base (Fig. 11).
Swing the cover downward until it catches at the bottom
of the base.
Fig. 11—Attach cover.
50 60 70 80
M8604
SET TEMPERATURE CONTROL LEVERS
Thetwoleversonthetopofthethermostatcontrolthelow
and high temperatures for energy savings and comfort con-
trol (Fig. 12). The lever on the left (blue mark) controls the
lowertemperature.Theleverontheright(redmark)controls
the higher temperature.
We recommend pushing the levers together at an appro-
priate temperature for either heat or cool until the occupant
programs the thermostat and makes the final temperature
selections.
Fig. 12—Temperature control levers.
50 60 70 80
HIGH TEMPERATURE
(RED MARK)
SET LEVER
LOW TEMPERATURE
(BLUE MARK)
SET LEVER
M859
SET SUBBASE SWITCHES (IF APPLICABLE)
The subbase system switch controls system operation as
follows:
HEAT: Heating system is controlled by the thermostat.
Cooling system is off.
COOL: Cooling system is controlled by the thermostat.
Heating system is off.
OFF: Both the heating and cooling systems are off. If the
fan switch is in the AUTO position, the fan is also off.
Thesubbase fanswitchcontrols fanoperationas follows:
ON: Fan operates continuously.
AUTO: Fan operates with the cooling equipment as
controlledbythethermostatorwiththeheatingequip-
ment as controlled by the plenum switch. In electric
heat, heat pump, and fan coil systems, the fan is
controlled by the thermostat in heating and cooling.
To switch positions, use thumb or index finger to slide
levertothedesiredposition.Switch levermuststopindetent
over the desired function indicator mark for proper circuit
operation.
Checkout
CAUTION
Do not check operation by shorting across the
terminals of the system controls. This will damage
the heat anticipator.
HEATING-ONLY SYSTEM
Turn on power to the furnace.
Pushboth temperaturesettinglevers togetheratleast5°F
[3°C] above the room temperature. The main burner should
come on. The fan will start when the furnace heats up.
Move both levers 5°F [3°C] below the room tempera-
ture. The burner should shut off.
Operate the entire heating system at least one complete
cycle.
If thermostat fails any test, refer to the Troubleshooting
Guide in the Owner’s Manual.
Reset both temperature setting levers to the desired
temperatures.
COOLING-ONLY SYSTEM
Turn on power to the cooling equipment.
Pushboth temperaturesettinglevers togetheratleast 5°F
[3°C] below the room temperature. The cooling equipment
will operate, and the fan will start. Allow for any time delay
that may be built into the compressor control circuit.
NOTE: To avoid compressor damage, do not operate the
systemwhenoutdoortemperatureisbelow50°F[10°C].
Refer to manufacturer recommendations.
Move both levers 5°F [3°C] above room temperature.
The cooling equipment and the fan should shut off.
Operate the entire cooling system at least one complete
cycle.
If thermostat fails any test, refer to the Troubleshooting
Guide in the Owner’s Manual.
Reset both temperature setting levers to the desired
temperatures.
HEATING/COOLING SYSTEM
Turn on power to the furnace and cooling system.
Place the system switch lever to HEAT and fan switch
lever to AUTO.
Pushboth temperaturesettinglevers togetheratleast 5°F
[3°C] above room temperature. The main burner should
come on. The fan will start when the furnace heats up. (If
central electric heat, fan coil or heat pump system, fan starts
immediately.)
Move both levers 5°F [3°C] below room temperature.
The burner should shut off.
PlacethesystemswitchlevertoCOOLandthefanswitch
levertoAUTO. Thecoolingequipmentwill operate, andthe
fanwillstart.Allowforanytimedelaythatmaybebuiltinto
the compressor control circuit.

7 69-0642—1
NOTE: To avoid compressor damage, do not operate the
systemwhenoutdoortemperatureisbelow50°F[10°C].
Refer to manufacturer recommendations.
Movebothtemperaturesettingleverstogetheratleast5°F
[3°C] above the room temperature. The cooling equipment
should shut off.
Place the fan switch to ON. The fan should run continu-
ously with the system switch in any position.
Place the system switch to OFF. Move both temperature
setting levers to various positions. The heating and cooling
systems should not operate.
Operate the entire system for at least one complete cycle
with the system switch at COOL and one complete cycle
with the switch at HEAT.
If thermostat fails any test, refer to the Troubleshooting
Guide in the Owner’s Manual.
Reset both temperature setting levers to the desired tem-
peratures.
Leave Owner’s Manual and Assistance Information in a
convenient place for the building occupant or provide with
other appliance manuals.
Calibration
THERMOMETER
The thermometer in your thermostat was accurately cali-
brated at the factory. The thermometer should need adjust-
mentonlyifithasbeendroppedorshiftedduetomishandling.
If the setpoint lever and the thermometer reading do not
agree:
1. Remove the thermostat cover by pulling up from the
bottom of cover until it clears the mounting slots.
2. Set the thermostat cover on a table near an accurate
thermometer.
3. Allow five minutes for cover thermometer to sense
area temperature; compare the readings. Be careful not to
touch thermometer or breathe on it.
4. If the readings are the same, replace cover and put the
system into operation.
5. Ifthereadingsare different, insert asmallscrewdriver
in the thermometer and turn it until the thermometers have
the same reading (Fig. 13).
6. Replace thermostat cover and put the system into
operation.
NOTE: Radiant heat from your hands will offset the ther-
mometerreading. Aftermakingeachadjustment,waitfive
or ten minutes for the thermometer to stabilize before
comparing.
THERMOSTAT
This thermostat was calibrated at the factory and should
not need recalibration in the field. If recalibration seems
necessary, first be sure wallplate or subbase is accurately
leveled. Then check thermometer calibration.
To check thermostat calibration, allow several hours of
operation after installation. Then read thermometer and
remove cover. Push temperature levers together to a setting
below room temperature. Slowly move them up the scale
together until the mercury slides across the tube. If the
thermometer reading and the high temperature lever posi-
tion are approximately the same at the instant the mercury
moves to the other end, no recalibration is needed.
Fig. 13—Thermometer calibration.
M5128
INCREASE
If calibration is necessary, proceed as follows:
1. Remove the cover.
2. Place open-end calibration wrench, part no. 104994A
(orderedseparately),on the hex nut under the bimetallic coil
controlledby theredlever(Fig.14).Holdlever soitdoesnot
move, and gently turn the wrench clockwise until the
mercury rests securely in the right end of the tube.
3. Put the thermostat cover on and wait ten minutes.
4. Read the thermometer. Then remove the cover. Mov-
ing both levers, place the HIGH lever at the thermometer
reading. Hold lever so it does not move, and gently turn the
wrench counterclockwise until the mercury just slides
totheleftendofthetubebutnofarther.Trytodothisquickly
so the heat from your hands does not affect the thermostat.
5. Repeat this procedure for the blue lever.
Fig. 14—Use of 104994A calibration wrench.
.35
.30
.25
.20
.10
M8583
ANTICIPATOR
SETTING
LEVER
ANTICIPATOR
SCALEPLATE
CALIBRATION
WRENCH

69-0642—1 8
Typical Wiring Diagrams
Fig. 15—Typical hookup for timer powered by
separate 24-Vac transformer.
L1
(HOT)
L2
1
L1
(HOT)
L2
1
CCRW
HEAT
RELAY
TIMER
THERMOSTAT
SUBBASE
1
2
2
POWER SUPPLY. PROVIDE DISCONNECT MEANS
AND OVERLOAD PROTECTION AS REQUIRED.
BATTERY BACKUP MAY BE USED IF POWER TO
TIMER IS INTERRUPTED. M822A
BATTERY
Fig. 16—Typical hookup for timer powered by
two AAA alkaline batteries only.
L1
(HOT)
L2
1
1POWER SUPPLY. PROVIDE DISCONNECT MEANS
AND OVERLOAD PROTECTION AS REQUIRED.
CCRW
HEAT
RELAY
TIMER
THERMOSTAT
SUBBASE
M823A
BATTERY
Fig. 17—Typical hookup for timer powered by
system transformer. Timer powered by battery
when system is not powered (e.g., power to
system is off or interrupted).
L1
(HOT)
L2
1
CCRW
HEAT
RELAY
TIMER
THERMOSTAT
SUBBASE
1POWER SUPPLY. PROVIDE DISCONNECT MEANS
AND OVERLOAD PROTECTION AS REQUIRED.
M824A
BATTERY
Fig. 18—Typical hookup for timer powered
through control system. Timer powered by
battery when heating or cooling equipment is
on; timer takes power from system when
heating equipment is off.
L1
(HOT)
L2
1
1L1
(HOT)
L2
1
HEAT
RELAY
COMPRESSOR
CONTACTOR
TIMER
POWER SUPPLY. PROVIDE DISCONNECT MEANS AND
OVERLOAD PROTECTION AS REQUIRED.
JUMPER RH-RC TERMINALS WHEN ONE TRANSFORMER
POWERS BOTH HEATING AND COOLING.
FOR POWER STEALING ON HEATING, JUMPER
C-RH AND C-W TERMINALS.
2
3
32
THERMOSTAT
BATTERY
SUBBASE
C C RH RC WY
M825A

9 69-0642—1
Fig. 19—Typical hookup for timer powered through control system. Timer powered by battery when
heating or cooling equipment is on; timer takes power from system when cooling equipment is off.
L1
(HOT)
L2
1
1L1
(HOT)
L2
1
HEAT
RELAY
COMPRESSOR
CONTACTOR
TIMER
POWER SUPPLY. PROVIDE DISCONNECT MEANS AND
OVERLOAD PROTECTION AS REQUIRED.
JUMPER RH-RC TERMINALS WHEN ONE TRANSFORMER
POWERS BOTH HEATING AND COOLING.
FOR POWER STEALING ON COOLING, JUMPER C-RC
AND C-Y TERMINALS.
2
3
32
THERMOSTAT
BATTERY
SUBBASE
C C RH RC WY
M826A
Fig. 20—Internal schematic and typical hookup for T8190A Thermostat/191108AJ Wallplate in heating-
only system.
H
FALL
C
L1
(HOT)
L2
1
1
H
FALLC
POWER SUPPLY. PROVIDE DISCONNECT MEANS AND OVERLOAD PROTECTION AS REQUIRED.
HEAT
ANTICIPATOR
HEAT
ANTICIPATOR
CCRWY
HEAT
RELAY
TIMER
THERMOSTAT
WALLPLATE
M827A

69-0642—1 10

11 69-0642—1

69-0642—1 12
QUALITY IS KEY
Home and Building Control Home and Building Control Helping You Control Your World
Honeywell Inc. Honeywell Limited—Honeywell Limitée
1985 Douglas Drive North 740 Ellesmere Road
Golden Valley, MN 55422 Scarborough, Ontario
M1P 2V9
Printed in Mexico
